Coelbo SWITCHMATIC 1 Setup guide

1
SWITCHMATIC 1 / 1 plus
SWITCHMATIC 2 / 2 plus
SWITCHMATIC 3 / 3 plus
ADVANCED SETTINGS
Risk of damaging the pressure assemblies and/or the plant.
Risk by electric shock.
Risk for people and/or objects.

2
GENERAL
Read carefully the instructions before installing this unit. Verify the tech-
nical characteristics of the motor in order to assure the compatibility with
the device.
DESCRIPTION (diagram A)
SWITCHMATIC 1 is an electronic pressure switch with integrated digital
manometer. It manages the start and stop of a single-phase pump up to
2.2kW (3 HP) (SW1-2). Cut-in and cut-out pressures are easily adjustable
through the users control panel.
Wiring is analogous to the traditional electromechanical switch.
It can operate as a dierential pressure switch and as reverse pressure
switch.
Unit SWITCHMATIC 2 in addition to all the features of the basic SWITCH-
MATIC includes instantaneous reading of current drawn. This patented
system controls and manages the overcurrent, dry-run operation and
fast-cycling.
Unit SWITCHMATIC 2 in addition to all the features of individual assembly
includes the option to be synchronized to another unit SWITCHMATIC 2
managing and protecting 2 pumps operating in cascade with alternated
starting sequence. The SWITCHMATIC 3 unit is ideal for a control panel as
it has a dry contact output.
CLASSIFICATION AND TYPE
According to IEC 60730-1 and EN 60730-1 this unit is a control sensor
device, electronic, independent assembly, programming type A with action
type 1B (microdisconnection). Operating value: I <20% I learned. Pollution
degree 2 (clean environment). Rated impulse voltage: cat II / 2500V. Tem-
peratures for ball test: enclousure (75) and PCB (125).
OPERATING CHARACTERISTICS (diagram C)
• Adjustable cut-in and cut-out pressures.
• Integrated digital pressure gauge with bar and psi indication.
• Inner pressure transmitter.
• Dry-run protection:
• Through minimum adjusted height for basic SWITCHMATIC 1/3.
• Through the instantaneous current consumption in case of SW2.
• Overcurrent protection.
• Overvoltage protection.
• ART Function (Automatic Reset Test). When the device has stopped
the pump by the intervention of the dry-running protection system,
the ART tries, with scheduled basis, to re-start the pump in order to
restore the water supply. See “ART. Automatic reset function“. Must be
activated in the step 6 of the ADVANCED MENU (Ar1).
• Fast cycling: when the hydropneumatic tank has lost too much air and,
consequently, frequent start-stop cycles are produced this alarm is
activated and is delayed the start of the pump. Activated (rc2).
• Manual start push-button (ENTER).
• 3 operation modes: dierential, reverse and synchronized.
• Control panel with 3-digit display, LED indicator lights and push-
buttons.
• Available settings:
• Stand-by mode.
• Minimum period between fast cycles.
• Start and stop delay.
• Volt-free contact for monitoring the alarms displayed in the screen (only
version A).
TECHNICAL CHARACTERISTICS
• Rated motor power: 0,37-2,2 kW (SW1-SW2)
• Power supply: ~1 x 110-230 V (SW1-SW2)
~1 x 48-230 Vac/Vdc (SW3)
• Electric outlet: Dry contact (SW3)
• Nominal pressure 1MPa/10bar (plus: 1,3MPa / 13bar)
Frequency: 50/60Hz
• Max. current: 16 A, cos ≥ 0.6
• Protection degree: IP55
• Max water Temperature: 50ºC
• Max environment Temperature: 60ºC
• Cut-in range (start pressure) 0,5÷7 bar (version plus=11 bar)
• Cut-ot range (stop pressure) 1÷8 bar (version plus=12 bar)
• Max. dierential (Pstop-Pstart) 7,5 bar (version plus=11,5 bar)
• Minimum dierential (Pstop-Pstart)) SW: 0,5 ba
SW2 synchro: 1 bar
• Factory setting (start/stop) 3/4 bar
• Hydraulic inlet G1/4” Female - NPT 1/4” Fem.
• Net weight (without cables) 0,3 kg
HYDRAULIC INSTALLATION (diagram A)
SWITCHMATIC equipment must be threaded to a tting G1/4” male
at the pump´s outlet.
Before connecting the SWITCHMATIC verify that the hydraulic system is
properly installed, especially if the hydropneumatic tank is pressurized.
ELECTRIC CONNECTION (diagram B)
The electric connection must be performed by qualied personal in
compliance with regulation of each country. Before doing manipulations
inside the device, it must be disconnected from the electric supply.
Wrong connection could spoil the electronic circuit.
The manufacturer declines all responsability in damages caused by
wrong connections.
When carrying out the electrical connection it is compulsory to use a dieren-
tial switch of high sensitivity: I = 30 mA (clase A o AC). It is compulsory to use a
magnetothermic switch adapted at the motor load.
Check if power supply is between 115-230V (SW1-2).
If you have purchased the unit without cables follow diagram B:
• Use cables type H07RN-F 3G1 or 3G1,5 with section enough to the power
installed.
• Do the pump connection U, V and (SW1-2) o 1, 2 y al cuadro (Only
SW3)
• Do the power supply connection L1, N and .
• The earth conductor must be longer than the others. It will be the rst
one to be mounted during the assembly and the last one to be discon-
nected during the dismantling. The earth conductors connections are
compulsory!
• (Only version A) The device has a volt-free contact for monitoring the alarms
displayed in the screen originated by irregularities or problems of the system.
For the connection see Diagram C.
CONTROL PANEL (diagram C)
The meanings of the dierent control panel elements are summarized on the
following tables, where:
• O means lit LED light.
• ( ( O ) ) means slow-ashing.
• (((O))) means fast-ashing.
DISPLAY ACTION
OPERATION MODE Is showed on screen instantaneous pressure or instanta-
neous current consumption
ADJUSTMENT MODE
Is displayed on screen the adjusted start pressure
blinking.
Is displayed on screen the adjusted stop pressure blin-
king.
Is displayed the adjusted rated current blinking (only
SW2).
ALARM MODE Is displayed the alarm code
STAND-BY MODE Are displayed 3 ashing dots
BASIC CONFIGURA-
TION MODE Is displayed the sequence of basic conguration para-
meters
ADVANCED CONFI-
GURATION MODE Is displayed the sequence of advanced conguration
parameters
LEDS STATE MEANING
bar
OIt indicates the instantaneous pressure in bar
( ( O ) ) It indicates the instantaneous pressure in bar +
pump operating (only SW1/SW3)
psi
OIt indicates the instantaneous pressure in psi
( ( O ) ) It indicates the instantaneous pressure in psi +
pump operating (only SW1/SW3)
A
(only SW2)
OIt indicates the instantaneous current consumption
in Ampere units
( ( O ) ) Pump ON
START O Is displayed the start pressure
( ( O ) ) Adjusting start pressure
STOP O Is displayed the stop pressure
( ( O ) ) Adjusting stop pressure
ORatied dry-running or overload alarms
( ( O ) ) Dry-running alarm performing ART or overload
alarm preforming any of the 4 restore attempts
(((O))) Fast-cycling alarm

3
P-BUTTON TOUCH ACTION
click!
From state ON: unit OFF.
From state OFF: the pump starts and keeps opera-
ting until reaching Pstop.
From any conguration MENU: the parameter
value is accepted.
HOLD
DOWN
From state ON: unit OFF.
From state OFF: the pump starts and keeps opera-
ting until the push-button is released.
click! Pstart is displayed on the screen for 3 seconds.
3” Pstart adjustment mode.
click! Pstop is displayed on the screen for 3 seconds.
3” Pstop adjustment mode.
click!
Is displayed on the screen instantaneous current
consumption.
If it is already displayed then we switch to instanta-
neous pressure view.
3” Rated current adjustment.
STARTUP (diagram C)
Before starting the device please read the previous sections, espe-
cially “Hydraulic Installation” and “Electrical connection”.
Follow next steps:
1. Only for type SW2 set the pump rated current intensity value.
- Press during 3 seconds.
- The current intensity value is displayed on screen, LED A lights up and
display is ashing.
- By mean of and is adjusted the rated current reected in the
characteristics plate of the motor. See Note 1.
- Press for validation.
2. Start the device by pressing .
3. Set the cut-in (start) pressure:
- Press during 3 seconds.
- The start pressure value is displayed on screen, LED START lights up
and display is ashing.
- By mean of and is adjusted the start pressure from 0,5 to 7
bar (+ version=11 bar).
- Press for validation.
4. Set the cut-out (stop) pressure:
- Press during 3 seconds.
- The stop pressure value is displayed on screen, LED STOP lights up
and display is ashing.
- By mean of and is adjusted the stop pressure from 1 to 8 bar
(+ version=12 bar).
- Press for validation.
5. The unit is ready to operate but more optional adjustments can be set
through basic and advanced MENUS. See the next chapter.
Remark 1: it is important to introduce exactly the rated current
specied on the nameplate of the pump.
BASIC MENU + (diagram C)
- Press simultaneously + during 5 seconds.
- By mean of or the values can be changed.
- Press for validation.
- The parameters sequence is:
it TYPE SYSTEM REACTION FACTORY
SETTING
1 BAR P We can select the pressure units displayed
beetween bar and psi. bar
2rc0 rc2
Fast-cycling alarm:
- rc0: alarm unabled.
- rc1: activated, when hammering is detected
it is delayed the start in order to protect
the pump.
- rc2: alarm is activated and the pump is stop-
ped upon detection.
rc2
3 r.01 r.99
Only if fast-cycling alarm has been activated in
the previous step (rc1&rc2). It can be choosed
the maximum time period between 3 consecu-
tive starts that will be considered fast cycling
(between 1 sec. and 99 sec.)
3 se-
conds
4 Sb0 Sb1 Stand-by mode activated (Sb1), for low power
consumption, or unabled (Sb0). Sb0
ADVANCED MENU + +
- Press simultaneously + + during 5 seconds.
- By mean of or the values can be changed.
- Press for validation.
- The parameters sequence is:
it TYPE SYSTEM REACTION FACTORY
SETTING
1 nc no Select the operation MODE as a conventio-
nal pressure switch (nc = normally closed) or
reverse (no = normally open). *see remark 3 nc
2 E00 E01/02
(Only Switchmatic2). Select the operation
mode Individual (E00) or Master/Slave (E01/
E02) in case of be assembled in groups of
two pumps.
E00
2.1 d.05 d.1 (Only Switchmatic 2). Sets the minimum gap
between Pstart 1 and Pstart 2 and/or Pstop
1 and Pstop 2. d.05
3 ct0 ct9 Sets a time delay between 0 and 9 seconds
to the start (is not available in synchronized
operation mode). ct0
4 dt0 dt9 Sets a time delay between 0 and 9 seconds
to the stop. dt0
5 Ar0 Ar1 Activation of the automatic restore system
ART (Ar1) o disable (Ar0). Ar0
6 P0.0 Px.x
It allows setting a minimum operating
pressure under which the device would
determine dry-running operation. It is very
usefull in the basic model SWITCHMATIC
where there is no reading of current intensi-
ty drawn. See Note 2.
0 bar
0 psi
6.1 t05 t99
Set the time period between 5 and 99
seconds below the minimum operating
pressure that will be considered a dry-
running operation.
20”
7 c10 c30 It allows setting a % of nominal current
above which the device will activate the
overcurrent protection. c20
8 rS0 rS1 If we change rS0 to rS1 and push ENTER
default values are restored. rS0
Remark 2:
Basic SWITCHMATIC 1/3 can only detect dry-running
operation through the minimum pressure. This means that
plumber must determine the water column of the installa-
tion, the start pressure of the pump and place the minimum
pressure below the start pressure.
It can also occur that pumping system is running out of its
curve so that the pump is unable to provide the minimum
pressure because the ow requirement is excessive. In this
case SWITCHMATIC 1/3 would activate a false dry-running
alarm.
If these concepts are not clear, it is preferable not congure
this protection or install the SWITCHMATIC 2 with accurate
and easy setting of dry-run detection.
Remark 3:
By choosing “no” (normally open) it will operate as an auxi-
liary pressure control element in the suction of the pump. It
will restart when the suction pressure reaches the congu-
red PStart.
Example: - PStop: 0,9 bar
- PStart: 1,2 bar

4
SYNCHRONISATION (ONLY FOR SWITCHMATIC 2)
SWITCHMATIC 2 can be synchronized to another unit SWITCHMATIC 2
managing and protecting 2 pumps operating in cascade with alternated
starting sequence. Next steps must be followed:
1. GO TO ADVANCED MENU: + +
- In step 2: select E01 in a unit (this one will be the master) and select E02
in the other unit (this one will be the slave).
- In step 3: select identical parameters of gap between pressures d.XX.
This is the dierence beetween the starting pressure of main and au-
xiliary pumps, it is also the dierence beetween stop pressures of both
pumps.
2. Press repeatedly until exit the ADVANCED MENU.
3. SET identical cut-in and cut-out pressures in both units.
To optimize the synchronization, the minimum dierence between
the start and stop pressures must be at least 1 bar.
4. Press in order to disable the units. Is displayed “OFF”.
5. Press again in both units in order to activate the synchronization.
Remark 4: after 10 cycles the unit congured E01 will display pressu-
re and the unit congured E02 will display current in Amps.
PRESSURE SENSOR CALIBRATION
In case of wrong lecture of the pressure sensor it can be adjusted again.
For the pressure sensor calibration is necessary to have a pressure gauge
in the installation. Proceed following next steps:
ZERO REGULATION
1. Open the taps living the hydraulic net without pressure.
2. Press simultaneously the buttons and until the display show 0.0
ashing.
3. Press to validate.
FULL SCALE
1. Start the pump until cut-out of the pressure switch.
2. Press simultaneously the buttons and till the display ashes with
a gure.
3. Adjustthe pressurewith the arrowspush-buttons to getthe pressurede-
sired.
4. Press to validate.
Remark 5: pressure sensor decalibration should not be a normal
event. If it is frequently repeated contact the technical service.
WARNINGS AND ALARMS
COD. DESCRIPTION SYSTEM REACTION
A01
O
DRY-RUNNING
(Only for
SWITCHMATIC 2)
When is detected a dry-run operation the
pump is automatically stopped. By mean
of ENTER the normal operation can be
manually restored.
( ( O ) )
After the activation of the dry-running
alarm if the Automatic system reset (ART)
is enabled, a rst attempt at 5 minutes and
then an attempt every 30 minutes for 24
hours is performed in order to restore the
normal operation. This alarm can also be
reset manually with the ENTER push-but-
ton. If the alarm persists after 24 h we nd
a denitive alarm.
A11 O
DRY-RUNNING
(BY MINIMUM
PRESSURE)
Is displayed during normal operation if the
pressure is below the minimum pressure
(Px.x) - previously set - during a period
(txx) - also previously set - in the ADVAN-
CED MENU.
If at any time the pressure exceeds the mi-
nimum pressure, the operation is restored
automatically and the alarm is cleared.
Normal operation can also be restored
manually by pressing ENTER.
A02
O
OVERLOAD
(Only SW2)
Overcurrent alarm is activated when the
nominal pump current is exceeded.
4 automatic reset attempts prior to the
nal alarm are performed.
During the attempts display will show
current.
Normal operation can also be restored
manually by pressing ENTER.
( ( O ) )
A04 (((O))) FAST CYCLING
(Hammering)
This alarm can be unabled or activated in
the BASIC MENU. The alarm is activated
when 3 consecutive cycles occur in a range
lower than the set time (between cycle and
cycle).
If it has been activated rc1, this alarm does
not stop the normal operation but are
added 5 seconds to the start delay in order
to protect the electric pump.
If it has been activated rc2, the pump is
stopped.
To RESET the normal operation press
ENTER.
A05 O
DAMAGED PRES-
SURE TRANS-
MITTER
CONTACT WITH YOUR SUPPLIER.
EC STAMENT OF COMPLIANCE
COELBO CONTROL SYSTEM, S.L.
States, on our own responsibility, that all materials here with related com-
ply with the following European Directives:
- 2014/35/EU.
- 2014/30/EU.
- 2011/65/EU.
Name: - SWITCHMATIC 1 /1+
- SWITCHMATIC 2/2+
- SWITCHMATIC 3/3+
Standards : EN-60730-2-6, EN-60730-1, EN-61000-6-1, EN-61000-6-3, IEC-
60730-1, IEC-60730-2-6
F. Roldán Cazorla
Director Técnico
04/05/2016
COELBO CONTROL SYSTEM, S.L.
Ctr de Rubí, 288 - P.I. Can Guitard
08228 Terrassa - BARCELONA (SPAIN)

5
~1x48-230Vac/Vdc
DIAGRAM A INDIVIDUAL
GROUPAL (ONLY SW2)
SWITCHMATIC 1/2 SWITCHMATIC 3

6
Ausgang
alarms
DIAGRAM B
Press to release
CABLE:
max. 1.5mm²
mín. 0.2mm²
CONTACT RATING
Max. switching voltage:
- 230VAC / 220 VDC
Max. switching power:
- 62,5VA / 30W
(Alarm monitoring)

7
SWITCHMATIC 1/2
SWITCHMATIC 1/3
SWITCHMATIC 2A/3/3A
SWITCHMATIC 2
DIAGRAM C
DIMESIONS
V11_042019
Other manuals for SWITCHMATIC 1
2
This manual suits for next models
5
Table of contents
Other Coelbo Relay manuals
Popular Relay manuals by other brands

GE
GE IAC Series Instruction booklet

Circutor
Circutor WRU-10 quick start guide

Greystone Energy Systems
Greystone Energy Systems GT-AR2 Series installation instructions

F&F
F&F BIS-411i quick start guide

Dossena
Dossena DER3BDUAL quick start guide

Veris Industries
Veris Industries Hawkeye 740 installation guide
