TECHNICAL GUIDE

LX SERIES

SPLIT SYSTEM

HEAT PUMPS

14 SEER – R-410A – 3 PHASE

2.5 THRU 5 NOMINAL TONS

MODELS: THE18 THRU 60

Due to continuous product improvement, specifications

are subject to change without notice.

Visit us on the web at

www.simplygettingthejobdone.com and

www.colemanac.com

Additional rating information can be found at

www.ahridirectory.org

WARRANTY SUMMARY*

Standard 1-Year limited parts warranty.

Standard 5-Years limited compressor warranty.

*Does not apply to R-22 models or internet sales.

See Limited Warranty certificate in User's Information Manual for details.

FOR INSTALLATION IN ALL US REGIONS AND CANADA

Installation Allowed

5591307-CTG-E-0220

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

DESCRIPTION

The THE model outdoor units are optimized for the 14 SEER /

8.2 HSPF Minimum Efficiency in all US Regions, and are spe-

cifically designed to be matched with Coleman indoor coils, fur-

naces, and air handlers to provide a complete system solution.

FEATURES

•Easier Installation - Independent panels provide quick

access for unit setup. Installation time is reduced by easy

power and control wiring access. The factory installed filter-

drier and factory charge for a 15-Ft lineset means less time

spent brazing and charging the system. The small base

dimension and reduced unit clearances make for easier ret-

rofits.

•Accessible Information - QR code on unit provides quick

access to technical documents and warranty information.

•Durable Finish - The coated steel wire fan guard, coated

external fasteners, and pre-treated G90-equivalent galva-

nized steel chassis components resist corrosion and rust

creep. Champagne colored powdercoat paint further protects

external panels.

•Rugged Coil Protection - Coils are protected from mechan-

ical damage by a proven stamped steel coil guard design.

•Quality Coils - Enhanced aluminum fins are mechanically

bonded to copper tubing.

•Protected Compressor - Compressors are protected inter-

nally by a high pressure relief valve and a temperature sen-

sor, and externally by the system high and low pressure

switches. The liquid line filter-drier is factory installed to pro-

tect the compressor against moisture and debris.

•Reliable Operation - Ball bearing fan motors provide supe-

rior performance in extreme temperatures. Factory installed

accumulator ensures proper functioning across a wide range

of conditions.

•Environmentally Friendly - CFC-free R-410A refrigerant

delivers environmentally friendly performance with zero

ozone depletion.

•Top Discharge - Warm air is blown up, away from the struc-

ture and any landscaping and allows compact location on

multi-unit applications.

•Low Operating Sound Levels - Developed using CFD and

FEA tools, the sturdy cabinet and top design provides sound

performance of 76 dBA or lower. Compatible accessories for

further sound reduction are also available.

•Better Service Access - Diagonal base valves with open

access for low-loss fittings, single panel access to the electri-

cal controls, full corner access, and removable fan guard

allow easy access for unit maintenance.

•Agency Listed - Safety certified by CSA to UL 1995 / CSA

22.2. Performance certified to ANSI/AHRI Standard 210/240

in accordance with the Unitary Small Equipment certification

program.

5591307-CTG-E-0220

2 Johnson Controls Ducted Systems

LIST OF SECTIONS

DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3

DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4

SYSTEM CAPACITY - Single Piece and Modular Air Handlers . . 5

SYSTEM CAPACITY - Upflow, Downflow & Horizontal

Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . . . . . . . . . . . 7

SYSTEM CAPACITY - With High Efficiency Motor Furnaces . . . . 8

APPLICATION & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . 21

SOUND POWER RATINGS - COOLING . . . . . . . . . . . . . . . . . . . . . 21

MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 22

TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 24

PERFORMANCE DATA - 2.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 25

PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 31

PERFORMANCE DATA - 3.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 35

PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 39

PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 43

NOMENCLATURE

BRAND TT= Factory Branded

PRODUCT TYPE HH= Heat Pump

NOMINAL

SERIES EFFICIENCY

AND STAGING EE= 14 SEER / 1-Stage

NOMINAL

UNIT CAPACITY

(MBH) 36 30 = 2.5 Ton 48 = 4 Ton

36 = 3 Ton 60 = 5 Ton

42 = 3.5 Ton

REFRIGERANT BB= R-410A

VOLTAGE

(Voltage-Phase-Hertz) 33= 208/230-3-60

4= 460-3-60

GENERATION

(MAJOR REVISION) 11= 1st Gen

2= 2nd Gen

etc

FACTORY OPTION SS= Standard (No Options)

STYLE LETTER

(MINOR REVISION)

NOT USED

FOR ORDERING

AA= Style A

B= Style B

etc

5591307-CTG-E-0220

Johnson Controls Ducted Systems 3

‡ Adapter fitting must be field installed for the required 1-1/8” line set.

All dimensions are in inches and are subject to change without notice.

Overall height is from bottom of base pan to top of fan guard.

Overall length and width include screw heads.

PHYSICAL AND ELECTRICAL DATA

MODEL THE30

B31S THE36

B32S THE42

B32S THE48

B32S THE60

B32S THE30

B41S THE36

B42S THE42

B42S THE48

B42S THE60

B42S

Unit Supply Voltage 208-230V, 3, 60Hz 460V, 3, 60Hz

Normal Voltage Range 1

1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.

187 to 252 432 to 504

Minimum Circuit Ampacity 12.5 15.8 19.7 18.5 21.3 6.0 8.8 9.1 8.7 10.4

Max. Overcurrent Device Amps 2

2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.

20 25 30 30 35 15 15 15 15 15

Min. Overcurrent Device Amps 3

3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.

15 20 20 20 25 15 15 15 15 15

Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll

Rated Load Amps 9.9 10.4 13.5 15.3 17.8 4.7 5.8 6.0 6.9 8.6

Locked Rotor Amps 58.0 73.0 88.0 83.1 110.0 38.0 38.0 44.0 41.0 52.0

Crankcase Heater No No No No No No No No No No

Factory External Discharge Muffler Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

Fan Diameter Inches 24 26 26 26 26 24 26 26 26 26

Fan Motor

Type PSC ECM ECM PSC PSC PSC ECM ECM PSC PSC

Rated HP 1/4 1/3 1/3 1/4 1/4 1/4 1/3 1/3 1/4 1/4

Rated Load Amps 1.30 2.8 2.8 1.30 1.30 0.65 1.6 1.6 0.60 0.60

Nominal RPM 850 834 834 850 850 850 834 834 850 850

Nominal CFM 2995 3715 4000 4100 4100 2995 4000 4000 4100 4100

Coil Face Area Sq. Ft. 23.82 26.40 26.40 26.40 28.80 23.82 26.40 26.40 26.40 28.80

Rows Deep 1 1 1 2 2 1 1122

Fins / Inch 22 22 22 18 18 22 22 22 18 18

Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8

Vapor Line Set OD (Field Installed)4

4. For applications with non-standard vapor line sizes, see the “Applications & Accessories” section of this Technical Guide.

3/4 3/4 7/8 7/8 1-1/8‡3/4 3/4 7/8 7/8 1-1/8‡

Unit Charge (Lbs. - Oz.) 5

5. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or subtract

the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.

7 - 15 9 - 1 10 - 5 15 - 4 14 - 10 7 - 15 9 - 1 10 - 5 15 - 4 14 - 10

Charge Per Foot, Oz. 0.62 0.62 0.67 0.67 0.75 0.62 0.62 0.67 0.67 0.75

Operating Weight Lbs. 181 235 235 240 261 181 235 235 240 261

$

DIMENSIONS

Unit

Model

Dimensions

(Inches) Refrigerant Connection

Service Valve Size

A B C Liquid Vapor

THE30B(3,4)1S 39-1/2 35-1/4 31-3/4

3/8

3/4

THE36B(3,4)2S 39-1/2 38 34-1/4

THE42B(3,4)2S 39-1/2 38 34-1/4 7/8

THE48B(3,4)1S 39-1/2 38 34-1/4

THE60B(3,4)1S 42-3/4 38 34-1/4 7/8‡

5591307-CTG-E-0220

4 Johnson Controls Ducted Systems

CHARGING PROCEDURES:

1. Check the Factory Unit Charge listed on the unit data plate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 feet of

interconnecting lineset.

2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the above table.

3. Add additional charge for the amount of interconnecting lineset greater than 15 feet at the rate specified in the Physical and Electrical Data Table.

4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.

5. Once the charge adders for matched indoor unit and for lineset have been weighed in, verify the system operation against the temperatures and pressures in the

Charging Chart for the outdoor unit. Locate Charging Charts on the outdoor unit and also in the Service Data Application Guide on

www.simplygettingthejobdone.com. Follow the Subcool or the Superheat charging procedure in the Installation Manual according to the type of indoor metering

device in the system, and allow ten minutes after each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the

Charging Chart.

6. Permanently stamp the unit data plate with the TOTALSYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge

adder for matched indoor unit (+ or -) charge adder for actual lineset length + charge adjustments to match the Charging Chart.

SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS

Outdoor Unit THE30B(3,4)1S THE36B(3,4)2S THE42B(3,4)2S THE48B(3,4)1S THE60B(3,4)1S

Required TXV 1,2

1. For applications requiring a TXV, use S1-1TVM*** series kit.

2. A TXV kit must be used with these indoor units to obtain system performance.

BA1 or BB1 BA1 BC1 BC1 BG1 or BC1

Defrost jumper pin setting 23242

Indoor Unit 3,4,5

3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.

4. CF coils cannot be used in horizontal applications.

5. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified

system matches. Obtain certified system ratings from www.ahridirectory.org.

Additional Charge, oz

AP30B 0 – – – –

AP36B 0 – – – –

AP36C – – – – –

AP37C – 8 – – –

AP42C – – – – –

AP48(C,D) – – 0 – –

AP60(C,D) – – – – –

AE30B 0 – – – –

AE36(B,C) 0 – – – –

AE42C 3 8 0 – –

AE48(C,D) – 8 0 0 –

AE60C – – – 8 –

AE60D – – – – 2

AVC30B 0 – – – –

AVC36(B,C) 0 – – – –

AVC42C 3 8 0 – –

AVC48(C,D) – 8 0 0 –

AVC60C – – – 8 –

AVC60D – – – – 2

CF/CM/CU30(A,B,C) 0 – – – –

CF/CM/CU36(A,B,C) 0 – – – –

CF/CM/CU42(B,C,D) 3 – – – –

CF/CM/CU48(C,D) – 8 0 0 –

CF/CM/CU60(C,D) – – – 8 –

CF/CM64D – – – – 2

Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved coil

only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.

FOOTNOTES:

5591307-CTG-E-0220

Johnson Controls Ducted Systems 5

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

THE30B(3,4)1S AE30BX21 17.5 – 1000 28.4 21.1 14.00 12.00 28.0 19.2 8.20 7.13 3.36 2.40

THE30B(3,4)1S AE36BX21 17.5 – 1000 29.4 21.8 15.50 13.00 29.0 19.5 9.00 7.82 3.96 2.76

THE30B(3,4)1S AE36CX21 21.0 – 1000 29.4 22.0 15.75 13.00 29.0 19.4 9.00 7.82 4.00 2.80

THE30B(3,4)1S AE42CX21 21.0 – 1000 29.6 22.2 16.00 13.00 28.6 19.4 9.00 7.82 4.06 2.84

THE30B(3,4)1S AP30BX21 17.5 – 1000 28.8 21.2 14.00 12.00 29.6 20.0 8.55 7.43 3.74 2.62

THE30B(3,4)1S AP36BX21 17.5 – 1000 28.8 21.4 14.00 12.00 29.6 20.0 8.55 7.43 3.76 2.64

THE30B(3,4)1S AVC30BX21 17.5 – 1000 28.4 21.1 14.00 12.00 28.0 19.2 8.20 7.13 3.36 2.40

THE30B(3,4)1S AVC36BX21 17.5 – 975 29.4 21.8 15.50 13.00 29.0 19.4 9.00 7.82 3.98 2.78

THE30B(3,4)1S AVC36CX21 21.0 – 975 29.6 21.8 16.00 13.00 28.8 19.3 9.00 7.82 4.04 2.82

THE30B(3,4)1S AVC42CX21 21.0 – 975 29.2 21.8 15.75 13.00 28.6 19.3 9.00 7.82 4.04 2.84

THE30B(3,4)1S ME12BN21 17.5 CF/CM36B 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S ME12BN21 17.5 CF42B 975 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S ME14DN21 24.5 CF/CM36D 1000 29.4 22.0 16.00 13.00 29.0 19.3 9.00 7.82 4.02 2.80

THE30B(3,4)1S ME14DN21 24.5 CF/CM42D 1000 29.8 22.2 16.00 13.00 28.4 18.9 9.00 7.82 4.04 2.78

THE30B(3,4)1S ME16CN21 21.0 CF/CM36C 1000 29.2 21.6 14.75 12.25 29.2 19.7 9.00 7.82 3.86 2.70

THE30B(3,4)1S ME16CN21 21.0 CF/CM42C 1000 29.4 21.8 15.00 12.50 28.8 19.2 9.00 7.82 3.88 2.68

THE36B(3,4)2S AE42CX21 21.0 – 1000 36.0 25.8 15.75 13.00 34.8 22.4 8.75 7.95 3.64 2.58

THE36B(3,4)2S AE48CX21 21.0 – 1250 36.6 28.6 15.75 13.00 35.0 22.6 9.00 8.10 3.80 2.62

THE36B(3,4)2S AE48DX21 24.5 – 1100 36.2 26.8 15.75 13.00 34.8 22.4 9.00 8.05 3.76 2.62

THE36B(3,4)2S AP37CX21 21.0 – 1200 36.0 25.2 14.00 12.00 35.8 23.4 8.75 7.75 3.54 2.46

THE36B(3,4)2S AP48DX21 24.5 – 1350 36.0 29.2 14.00 11.75 36.0 23.6 8.50 7.75 3.56 2.46

THE36B(3,4)2S AVC42CX21 21.0 – 1150 36.2 27.2 15.75 13.00 35.0 22.6 9.00 8.00 3.70 2.58

THE36B(3,4)2S AVC48CX21 21.0 – 1275 36.6 29.0 15.75 13.00 35.0 22.6 9.00 8.05 3.76 2.60

THE36B(3,4)2S AVC48DX21 24.5 – 1025 36.0 25.8 15.75 13.00 34.8 22.4 9.00 7.95 3.66 2.58

THE36B(3,4)2S ME12CN21 21.0 CF/CM48C 1000 36.0 25.6 15.75 12.75 34.8 22.6 8.75 7.50 3.62 2.58

THE36B(3,4)2S ME14DN21 24.5 CF/CM48D 1025 36.0 25.8 15.75 13.00 34.8 22.4 9.00 7.95 3.66 2.58

THE36B(3,4)2S ME16CN21 21.0 CF/CM48C 1100 36.0 26.6 15.75 13.00 35.0 22.6 9.00 8.00 3.70 2.58

THE36B(3,4)2S ME20DN21 24.5 CF/CM48D 1275 36.6 28.8 15.75 13.00 34.8 22.4 9.00 8.10 3.82 2.64

THE36B(3,4)2S MVC12CN21 21.0 CF/CM48C 1000 36.0 25.8 15.75 13.00 34.8 22.4 8.75 7.95 3.64 2.58

THE36B(3,4)2S MVC14DN21 24.5 CF/CM48D 1000 36.0 25.8 15.75 13.00 34.8 22.4 9.00 8.00 3.66 2.60

THE36B(3,4)2S MVC16CN21 21.0 CF/CM48C 1025 36.0 25.8 15.75 13.00 34.8 22.4 9.00 7.95 3.66 2.58

THE36B(3,4)2S MVC20DN21 24.5 CF/CM48D 1175 36.6 27.8 15.75 13.00 34.8 22.4 9.00 8.10 3.78 2.62

THE42B(3,4)2S AE42CX21 21.0 – 1150 40.0 29.2 15.00 12.25 40.0 25.2 8.20 7.25 3.36 2.64

THE42B(3,4)2S AE48CX21 21.0 – 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.44 2.66

THE42B(3,4)2S AE48DX21 24.5 – 1250 40.5 30.8 15.50 12.50 39.5 25.0 8.50 7.50 3.50 2.70

THE42B(3,4)2S AP48CX21 21.0 – 1450 41.0 30.2 14.00 11.75 40.5 25.8 8.20 7.55 3.34 2.58

THE42B(3,4)2S AP48DX21 24.5 – 1475 41.0 33.2 14.00 11.25 40.5 26.0 8.20 7.25 3.36 2.56

5591307-CTG-E-0220

6 Johnson Controls Ducted Systems

3. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.

— = Not applicable.

* Notates “Hot Heat Pump” performance. These ratings are notAHRI listed.

MP ModularAir Handlers use Coil Only Ratings.

THE42B(3,4)2S AVC42CX21 21.0 – 1150 40.0 29.2 15.00 12.25 40.0 25.4 8.20 7.25 3.34 2.62

THE42B(3,4)2S AVC48CX21 21.0 – 1200 40.5 30.0 15.00 12.25 40.0 25.4 8.20 7.25 3.38 2.64

THE42B(3,4)2S AVC48DX21 24.5 – 1150 40.5 29.6 15.50 12.25 40.0 25.2 8.20 7.25 3.38 2.66

THE42B(3,4)2S ME14DN21 24.5 CF/CM48D 1200 40.5 30.0 15.25 12.25 40.0 25.2 8.20 7.25 3.40 2.66

THE42B(3,4)2S ME16CN21 21.0 CF/CM48C 1325 40.5 31.6 15.00 12.20 40.0 25.4 8.20 7.25 3.42 2.64

THE42B(3,4)2S ME20DN21 24.5 CF/CM48D 1275 41.0 31.2 15.50 12.50 39.5 25.2 8.50 7.50 3.46 2.66

THE42B(3,4)2S MVC14DN21 24.5 CF/CM48D 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68

THE42B(3,4)2S MVC16CN21 21.0 CF/CM48C 1150 40.5 29.6 15.25 12.25 40.0 25.2 8.20 7.25 3.36 2.66

THE42B(3,4)2S MVC20DN21 24.5 CF/CM48D 1175 40.5 29.8 15.50 12.50 40.0 25.0 8.20 7.25 3.40 2.68

THE48B(3,4)1S AE48CX21 21.0 – 1,400 46.0 31.8 14.25 12.00 47.5 31.4 9.00 7.82 3.58 2.64

THE48B(3,4)1S AE48DX21 24.5 – 1,400 46.5 32.0 14.50 12.25 47.5 31.4 9.00 7.82 3.62 2.66

THE48B(3,4)1S AE60CX21 21.0 – 1,520 47.0 33.3 15.00 12.50 47.5 31.4 9.00 7.82 3.66 2.66

THE48B(3,4)1S AVC48CX21 21.0 – 1,375 46.0 31.6 14.25 12.00 47.5 31.4 9.00 7.82 3.56 2.62

THE48B(3,4)1S AVC48DX21 24.5 – 1,400 46.5 31.6 14.75 12.25 47.5 31.2 9.00 7.82 3.60 2.66

THE48B(3,4)1S AVC60CX21 21.0 – 1,350 46.5 31.6 15.00 12.50 47.5 31.2 9.00 7.82 3.56 2.62

THE48B(3,4)1S ME14DN21 24.5 CF/CM48D 1,400 46.5 32.0 14.50 12.25 47.5 31.4 9.00 7.82 3.60 2.66

THE48B(3,4)1S ME14DN21 24.5 CF/CM60D 1,400 46.5 32.0 14.25 12.00 48.0 31.4 9.00 7.82 3.54 2.60

THE48B(3,4)1S ME16CN21 21.0 CF/CM48C 1,400 46.0 31.8 14.50 12.00 47.5 31.4 9.00 7.82 3.58 2.64

THE48B(3,4)1S ME16CN21 21.0 CF/CM60C 1,400 47.0 32.2 14.50 12.25 47.5 31.2 9.00 7.82 3.58 2.62

THE48B(3,4)1S ME20DN21 24.5 CF/CM48D 1,400 46.5 31.8 14.50 12.00 47.5 31.4 9.00 7.82 3.60 2.66

THE48B(3,4)1S ME20DN21 24.5 CF/CM60D 1,400 47.0 32.2 14.75 12.25 47.5 31.2 9.00 7.82 3.58 2.64

THE60B(3,4)1S AE60DX21 24.5 – 1640 55.5 38.5 14.25 12.00 57.0 37.8 9.00 7.82 3.88 2.82

THE60B(3,4)1S AVC60DX21 24.5 – 1550 55.5 38.5 14.25 12.00 57.0 37.8 9.00 7.82 3.88 2.82

THE60B(3,4)1S ME20DN21 24.5 CF/CM64D 1600 55.0 38.0 14.25 12.00 57.0 37.6 9.25 8.04 3.88 2.82

Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.

1. Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.

EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.

SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in watt-hours during the same period.

2. Heating MBH based on AHRI standards of 70°F DB (Dry Bulb) entering indoor air, 72% RH (Relative Humidity) outdoor air with 25 feet of interconnecting piping and no supplemental electric heat operation.

HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric power input during the same period.

COP (Coefficient of Performance) equals Heating MBH output divided by (total KW input x 3.412).

SYSTEM CAPACITY - Single Piece and Modular Air Handlers

UNIT

MODEL

AIR HANDLER COIL

MODEL3RATED

CFM

COOLING 1HEATING 2

MODEL WIDTH NET MBH SEER EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5591307-CTG-E-0220

Johnson Controls Ducted Systems 7

— = Not Applicable.

MP ModularAir Handlers use Coil Only Ratings.

PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.

SYSTEM CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings)

UNIT MODEL COIL CFM RANGE

(MIN.-MAX.)

COOLING HEATING

MODEL WIDTH RATED

CFM NET MBH SEER 1EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

THE30B(3,4)1S CF/CM/CU36B 17.5 800 - 1200 1000 28.8 21.2 14.00 12.00 29.6 20.0 8.55 7.43 3.74 2.62

THE30B(3,4)1S CF/CM/CU36C 21.0 800 - 1200 1000 28.8 21.2 14.00 12.00 29.6 20.0 8.55 7.43 3.74 2.62

THE30B(3,4)1S CF/CM/CU36D 24.5 800 - 1200 1000 28.8 21.2 14.00 12.00 29.6 20.0 8.55 7.43 3.74 2.62

THE30B(3,4)1S CF/CM/CU42C 21.0 800 - 1200 1000 29.2 21.6 14.00 12.00 29.2 19.6 8.55 7.43 3.74 2.60

THE30B(3,4)1S CF/CM/CU42D 24.5 800 - 1200 1000 29.2 21.6 14.00 12.00 29.2 19.6 8.55 7.43 3.74 2.60

THE30B(3,4)1S CF/CM36A 14.5 800 - 1200 900 28.4 20.2 14.00 12.00 29.4 20.0 8.55 7.43 3.68 2.62

THE36B(3,4)2S CF/CM/CU48C 21.0 1000 - 1400 1200 36.0 27.6 14.25 12.20 35.8 23.4 8.50 7.75 3.54 2.46

THE36B(3,4)2S CF/CM/CU48D 24.5 1000 - 1400 1200 36.0 27.6 14.25 12.20 35.8 23.4 8.50 7.75 3.54 2.46

THE42B(3,4)2S CF/CM/CU48C 21.0 1200 - 1600 1400 40.5 32.0 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54

THE42B(3,4)2S CF/CM/CU48D 24.5 1200 - 1600 1400 40.5 32.0 14.00 11.25 40.5 26.0 8.20 7.30 3.32 2.54

THE48B(3,4)1S CF/CM/CU60C 21.0 1400 - 1600 1,600 47.0 33.8 14.00 11.75 47.5 32.0 8.20 7.13 3.54 2.50

THE48B(3,4)1S CF/CM/CU60D 24.5 1400 - 1600 1,600 47.0 33.8 14.00 11.75 47.5 32.0 8.20 7.13 3.54 2.50

For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.

1. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60 second time delay.

5591307-CTG-E-0220

8 Johnson Controls Ducted Systems

SYSTEM CAPACITY - With High Efficiency Motor Furnaces1

UNIT

MODEL

FURNACE COIL

MODEL2

COOLING HEATING

MODEL WIDTH RATED

CFM NET MBH SEER EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

THE30B(3,4)1S TM8V060A12MP11 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 7.60 3.80 2.66

THE30B(3,4)1S TM8V080B12MP11 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 7.60 3.86 2.70

THE30B(3,4)1S TM8V080B12MP11 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 7.60 3.86 2.66

THE30B(3,4)1S TM8V080C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 7.82 3.88 2.76

THE30B(3,4)1S TM8V080C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 7.82 3.92 2.72

THE30B(3,4)1S TM8V100C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 7.82 3.88 2.76

THE30B(3,4)1S TM8V100C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 7.82 3.92 2.72

THE30B(3,4)1S TM8X060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 7.60 3.86 2.72

THE30B(3,4)1S TM8X080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 7.82 3.92 2.74

THE30B(3,4)1S TM8X080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM8X080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8X080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8X100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8X100C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8X100C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X100C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X100C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8X100C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8X120C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X120C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8X120C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8X120C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8Y060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 7.60 3.86 2.72

THE30B(3,4)1S TM8Y080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 7.82 3.92 2.74

THE30B(3,4)1S TM8Y080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM8Y080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8Y080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8Y100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8Y100C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

5591307-CTG-E-0220

Johnson Controls Ducted Systems 9

THE30B(3,4)1S TM8Y100C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y100C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y100C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8Y100C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM8Y120C20MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y120C20MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TM8Y120C20MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TM8Y120C20MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TM9E040A10MP11 14.5 CF/CM36A 875 28.6 20.2 14.50 12.00 29.2 19.8 8.75 7.60 3.74 2.66

THE30B(3,4)1S TM9E060B12MP11 17.5 CF/CM/CU36B 900 28.8 20.4 15.25 12.50 29.0 19.5 9.00 7.82 3.86 2.74

THE30B(3,4)1S TM9E060B12MP11 17.5 CF42B 900 29.6 21.0 15.50 13.00 28.4 19.0 8.75 7.60 3.86 2.70

THE30B(3,4)1S TM9E080B12MP11 17.5 CF/CM/CU36B 900 28.8 20.4 15.25 12.50 29.0 19.5 9.00 7.82 3.86 2.74

THE30B(3,4)1S TM9E080B12MP11 17.5 CF42B 900 29.6 21.0 15.50 13.00 28.4 19.0 8.75 7.60 3.86 2.70

THE30B(3,4)1S TM9E080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.72

THE30B(3,4)1S TM9E080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.74

THE30B(3,4)1S TM9E080C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 7.60 3.90 2.70

THE30B(3,4)1S TM9E080C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM9E100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.72

THE30B(3,4)1S TM9E100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.74

THE30B(3,4)1S TM9E100C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 7.60 3.90 2.70

THE30B(3,4)1S TM9E100C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM9E100C20MP11 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 12.75 29.0 19.4 9.00 7.82 3.96 2.78

THE30B(3,4)1S TM9E100C20MP11 21.0 CF/CM/CU36D 975 29.2 21.6 15.75 13.00 29.0 19.4 9.00 7.82 3.98 2.78

THE30B(3,4)1S TM9E100C20MP11 21.0 CF/CM/CU42C 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 7.82 4.00 2.76

THE30B(3,4)1S TM9E100C20MP11 21.0 CF/CM/CU42D 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 7.82 4.02 2.76

THE30B(3,4)1S TM9E120D20MP11 24.5 CF/CM/CU36D 975 29.2 21.6 16.00 13.00 28.8 19.3 9.00 7.82 4.00 2.80

THE30B(3,4)1S TM9E120D20MP11 24.5 CF/CM/CU42D 975 29.8 22.2 16.00 13.00 28.4 18.9 9.00 7.82 4.04 2.78

THE30B(3,4)1S TM9V060B12MP11 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 7.82 3.88 2.72

THE30B(3,4)1S TM9V060B12MP11 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 7.82 3.90 2.70

THE30B(3,4)1S TM9V080B12MP11 17.5 CF/CM/CU36B 950 29.0 21.2 15.00 12.50 29.0 19.6 9.00 7.82 3.88 2.72

THE30B(3,4)1S TM9V080B12MP11 17.5 CF42B 925 29.8 21.4 15.50 13.00 28.6 19.0 9.00 7.82 3.90 2.70

THE30B(3,4)1S TM9V080C16MP11 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 7.82 3.96 2.78

THE30B(3,4)1S TM9V080C16MP11 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 7.82 3.98 2.74

THE30B(3,4)1S TM9V100C16MP11 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 13.00 29.0 19.4 9.00 7.82 3.96 2.78

THE30B(3,4)1S TM9V100C16MP11 21.0 CF/CM/CU42C 975 29.6 22.0 15.75 13.00 28.6 19.0 9.00 7.82 3.98 2.74

THE30B(3,4)1S TM9V100C20MP11 21.0 CF/CM/CU36C 1075 29.0 22.4 15.00 12.50 29.2 19.6 8.75 7.60 3.96 2.74

THE30B(3,4)1S TM9V120D20MP11 24.5 CF/CM/CU36D 1125 29.8 23.2 16.00 13.00 29.0 19.3 9.25 8.04 4.12 2.84

SYSTEM CAPACITY - With High Efficiency Motor Furnaces1

UNIT

MODEL

FURNACE COIL

MODEL2

COOLING HEATING

MODEL WIDTH RATED

CFM NET MBH SEER EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

5591307-CTG-E-0220

10 Johnson Controls Ducted Systems

THE30B(3,4)1S TM9V120D20MP11 24.5 CF/CM/CU42D 1125 29.8 23.2 15.50 13.00 29.0 19.7 9.00 7.82 4.04 2.80

THE30B(3,4)1S TM9Y040A10MP11 14.5 CF/CM36A 875 28.6 20.2 14.50 12.00 29.2 19.8 8.75 7.60 3.74 2.66

THE30B(3,4)1S TM9Y060B12MP11 17.5 CF/CM/CU36B 900 28.8 20.4 15.25 12.50 29.0 19.5 9.00 7.82 3.86 2.74

THE30B(3,4)1S TM9Y060B12MP11 17.5 CF42B 900 29.6 21.0 15.50 13.00 28.4 19.0 8.75 7.60 3.86 2.70

THE30B(3,4)1S TM9Y080B12MP11 17.5 CF/CM/CU36B 900 28.8 20.4 15.25 12.50 29.0 19.5 9.00 7.82 3.86 2.74

THE30B(3,4)1S TM9Y080B12MP11 17.5 CF42B 900 29.6 21.0 15.50 13.00 28.4 19.0 8.75 7.60 3.86 2.70

THE30B(3,4)1S TM9Y080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.72

THE30B(3,4)1S TM9Y080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.74

THE30B(3,4)1S TM9Y080C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 7.60 3.90 2.70

THE30B(3,4)1S TM9Y080C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM9Y100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.6 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.72

THE30B(3,4)1S TM9Y100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.00 12.50 29.2 19.6 8.75 7.60 3.90 2.74

THE30B(3,4)1S TM9Y100C16MP11 21.0 CF/CM/CU42C 1000 29.4 22.0 15.25 12.50 28.8 19.2 8.75 7.60 3.90 2.70

THE30B(3,4)1S TM9Y100C16MP11 21.0 CF/CM/CU42D 1000 29.4 22.0 15.25 12.75 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TM9Y100C20MP11 21.0 CF/CM/CU36C 975 29.2 21.6 15.50 12.75 29.0 19.4 9.00 7.82 3.96 2.78

THE30B(3,4)1S TM9Y100C20MP11 21.0 CF/CM/CU36D 975 29.2 21.6 15.75 13.00 29.0 19.4 9.00 7.82 3.98 2.78

THE30B(3,4)1S TM9Y100C20MP11 21.0 CF/CM/CU42C 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 7.82 4.00 2.76

THE30B(3,4)1S TM9Y100C20MP11 21.0 CF/CM/CU42D 975 29.6 22.2 16.00 13.00 28.6 18.9 9.00 7.82 4.02 2.76

THE30B(3,4)1S TM9Y120D20MP11 24.5 CF/CM/CU36D 975 29.2 21.6 16.00 13.00 28.8 19.3 9.00 7.82 4.00 2.80

THE30B(3,4)1S TM9Y120D20MP11 24.5 CF/CM/CU42D 975 29.8 22.2 16.00 13.00 28.4 18.9 9.00 7.82 4.04 2.78

THE30B(3,4)1S TMLV060A12MP11 14.5 CF/CM36A 975 28.8 21.2 14.25 12.00 29.4 19.8 8.75 7.60 3.80 2.66

THE30B(3,4)1S TMLV080B12MP11 17.5 CF/CM/CU36B 1025 29.2 21.8 14.75 12.50 29.4 19.7 8.75 7.60 3.86 2.70

THE30B(3,4)1S TMLV080B12MP11 17.5 CF42B 1000 29.4 21.8 15.00 12.50 29.0 19.3 8.75 7.60 3.86 2.66

THE30B(3,4)1S TMLV080C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 7.82 3.88 2.76

THE30B(3,4)1S TMLV080C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 7.82 3.92 2.72

THE30B(3,4)1S TMLV100C16MP11 21.0 CF/CM/CU36C 925 28.8 20.6 15.25 12.75 28.8 19.5 9.00 7.82 3.88 2.76

THE30B(3,4)1S TMLV100C16MP11 21.0 CF/CM/CU42C 925 29.8 21.4 15.75 13.00 28.4 19.0 9.00 7.82 3.92 2.72

THE30B(3,4)1S TMLX060A12MP11 14.5 CF/CM36A 975 29.0 21.2 15.00 12.50 29.2 19.6 8.75 7.60 3.86 2.72

THE30B(3,4)1S TMLX080B12MP11 17.5 CF/CM/CU36B 1000 29.2 21.8 15.25 12.75 29.2 19.6 9.00 7.82 3.92 2.74

THE30B(3,4)1S TMLX080B12MP11 17.5 CF42B 1000 29.4 22.0 15.25 12.50 28.8 19.1 9.00 7.82 3.92 2.70

THE30B(3,4)1S TMLX080C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TMLX080C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TMLX080C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

THE30B(3,4)1S TMLX080C16MP11 21.0 CF/CM/CU42D 1000 29.6 22.0 15.50 12.75 28.6 19.0 9.00 7.82 3.96 2.74

THE30B(3,4)1S TMLX100C16MP11 21.0 CF/CM/CU36C 1000 29.2 21.8 15.25 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TMLX100C16MP11 21.0 CF/CM/CU36D 1000 29.2 21.8 15.50 12.75 29.0 19.5 9.00 7.82 3.94 2.76

THE30B(3,4)1S TMLX100C16MP11 21.0 CF/CM/CU42C 1000 29.6 22.0 15.50 13.00 28.6 19.1 9.00 7.82 3.96 2.72

SYSTEM CAPACITY - With High Efficiency Motor Furnaces1

UNIT

MODEL

FURNACE COIL

MODEL2

COOLING HEATING

MODEL WIDTH RATED

CFM NET MBH SEER EER NET MBH HSPF

Region IV HSPF

Region V COP

TOTAL SENS. 47°F OD 17°F OD 47°F OD 17°F OD

Other manuals for LX SERIES

This manual suits for next models

Table of contents

Other Coleman Heat Pump manuals

Coleman

Coleman TH4B1821S Quick start guide

Coleman

Coleman LX SERIES Quick start guide

Coleman

Coleman LX SERIES Quick start guide

Coleman

Coleman HC8B024F1 Quick start guide

Coleman

Coleman LX SERIES Quick start guide

Coleman

Coleman HC6B024 THRU 060 Quick start guide

Coleman

Coleman LX SERIES Quick start guide

Coleman

Coleman BB-03 User manual

Popular Heat Pump manuals by other brands

Daikin

Daikin RXL12QMVJU Service manual

AIREDALE

AIREDALE BluCube CUR092V16-1CO-0 Installation and maintenance manual

Calyenty

Calyenty RBH 125 Customer's manual

GRE

GRE HPGI50 owner's manual

Carrier

Carrier 30XW Installation, operation and maintenance instructions

Hayward

Hayward SUMHEAT HP5131DT3 Installation instructions manual

REMKO

REMKO SQW 400 Electrical wiring

Sanyo

Sanyo SAP120FCH Service manual

Daikin

Daikin EHYHBH05AA Operation manual

Panasonic

Panasonic WH-SDF03E3E5 Design handbook

Airxcel

Airxcel 45000 Series Installation, operation and maintenance instructions

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Service manual

Dimplex

Dimplex LI 16I-TUR Installation and operating instruction

Carrier

Carrier WSHP Open v3 Integration guide

Mitsubishi Electric

Mitsubishi Electric EHSE-YM9EC Service manual

TGM

TGM CTV14CN018A Technical manual

Carrier

Carrier 38MGQ Series installation instructions

Kokido

Kokido K2O K880BX/EU Owner's manual & installation guide
