Coleman POWERSPORTS AT125-B User manual

BEFORE OPERATING THIS VEHICLE, THE OWNER AND EACH
OPERATOR MUST HAVE READ AND HAVE AN UNDERSTANDING
OF ALL THE INSTRUCTIONS FOR PROPER ASSEMBLY AND SAFE
OPERATION, AS WELL AS THE INSTRUCTIONS CONCERNING
THE ENGINE AND ALL OTHER PORTIONS OF VEHICLE.
POWERSPORTS
AT125-B
ATV
This is a category “T” ATV
No one under the age of 14 should operate thisATV
REV 012418

CONTENTS
COLEMAN POWERSPORTS LIMITED WARRANTY--------- 1
1. INTRODUCTION---------------------------------------------------3
2. SAFETY---------------------------------------------------------------9
3. SAFETY WARNING-----------------------------------------------11
4. DAILY PRE-RIDE INSPECTION------------------------------- 15
5. OPERATION WARNINGS----------------------------------------16
6. V.I.N-------------------------------------------------------------------32
7. CONTROLAND PARTS FUNCTIONS-------------------------33
8. STARTING THE ENGINE---------------------------------------- 43
9. VEHICLE BREAK-IN PERIOD----------------------------------44
10. RIDING GEAR---------------------------------------------------- 45
11. CARRYING LOADS--------------------------------------------- 46
12. RIDING------------------------------------------------------------- 48
13. BATTERY---------------------------------------------------------- 60
14. EXHAUST SYSTEM---------------------------------------------63
15. MAINTENANCE------------------------------------------------- 64
16. TROUBLE SHOOTING----------------------------------------- 84
17 SPECIFICATION-------------------------------------------------- 89
18 WIRING DIAGRAM---------------------------------------------- 90

1
COLEMAN POWERSPORTS LIMITED WARRANTY
Coleman Powersports offers the following warranty to the initial
purchaser of this new Coleman Powersports product. The initial
purchaser is defined as the first person to purchase a new Coleman
Powersports product from an Authorized Retailer of Coleman Powersports
products.
The limited warranty period for this product is 1 year from the date of
purchase shown on the original sales receipt.
What is a Defect? The Product is warranted to be free from
manufacturing defects in material and workmanship for a period of 1
year from the date of purchase shown on the sales receipt. During this
period of time Coleman Powersports will, at its option, either repair or
replace any original Coleman Powersports part which is covered by this
warranty and is proven to be defective in workmanship or material.
To qualify for this warranty the part:
1. Must have been purchased from Coleman Powersports or from an
authorized Coleman Powersports Retailer.
2. This warranty does not apply to any vehicle which is used in
competition or used in a manner not consistent with the normal
and proper intended use for the vehicle. This vehicle is not
intended for rental or commercial use.
Who Can Perform Repairs Under this Warranty?
Repairs under this warranty should be performed by an authorized
Coleman Powersports retailer or comparable servicing dealer.
How to get service under this warranty
To get warranty service call Coleman Powersports at 888-405-8725 for
the location of your local servicing retailer / dealer. Please do not
return the product to the retailer where the product was purchased unless
instructed to do so by Coleman Powersports. The retailer of this
product does not make any warranty of its own and has no authority to
implement this warranty on behalf of Coleman Powersports without the
approval of Coleman Powersports. A COPY OF YOUR SALES RECEIPT IS
REQUIRED FOR WARRANTY SERVICE.
What this Warranty Does Not Cover
This warranty does not cover the following

2
1. Damage due to lack or improper maintenance as described in this
manual.
2. Damage which is caused by normal use and not caused by a
defect in materials or workmanship.
3. Use of the product which is not consistent with the intended use as
described in the operating instructions.
4. Any expendable maintenance item which need replacement or
service as part of normal maintenance, unless such items have
defects in material or workmanship which cause failure or
premature wear.
5. Any product which has been altered or modified in a manner not
consistent with the original design of the product or in a manner
not approved by Coleman Powersports.
6. Tires
7. Damage or failures due to abuse, neglect, or misuse of the
product.
Limitations of this Warranty
This warranty does not cover and Coleman Powersports disclaims any
responsibility for
1. Loss of time or loss of use of the product.
2. Transportation costs to and from the authorized service center.
3. Other loss or damage to other equipment or personal items.
Length of Implied Warranties
Any implied warranties are limited to the duration set forth in this
warranty. Coleman Powersports does not make any claim as to the
merchantability or fitness for a particular purpose which would extend
longer than the duration of this written warranty.
Check your State Laws as some State Laws do not allow limitations as to
the duration of an implied warranty. Some States may also not allow
limitation or exclusions based on incidental or consequential damages.

3
1. INTRODUCTION
Congratulations on the purchase of your Coleman ALL Terrain Vehicle (ATV).
We take pride in offering you this product engineered and manufactured to the
highest performance and quality standards. We are sure that you will enjoy
superior levels of performance, reliability, riding comfort, and safety.
This manual is provided to help the owner and operators of this ATV become
familiar with the operating characteristic, and the many features offered on the
ATV. The manual also covers information on the care and maintenance of your
ATV.
Please read this manual carefully. The information contained in this Owner’s
Manual, the Warning Labels supplied with this product will help your ATV.
Make sure that you understand and follow all Warnings and Instructions in this
material.
If you did not receive any of the material listed above, please call your dealer
and request to have them sent to you.
Important Safety Notice
Never make any modifications to the engine, drive system, mechanical or
electrical systems of your ATV. Never install after market parts or accessories
intended to increase the speed or power of yourATV.
Failure to follow these warnings increases the possibility of accidents leading
to DEATH or SERIOUS INJURY!
Additionally, failure to follow these requirements will void the Warranty on
your ATV.
Note
The addition and use of certain accessories including, (but not limited to)
mowers, blades, sprayers, winches and windshields will change the handling
characteristics of your ATV.

4
Practice Responsible ATV Riding
Make sure that you understand and follow all local, state/province, and
federal/national riding laws and requirements.
Remember……Respect your vehicle, respect the environment and respect the
property of others. You are responsible for your safety and the safety of others
around you when you ride!
WARNING
YOUR VEHICLE CAN BE HAZARDOUS TO OPERATE.
A collision or rollover can occur quickly if you fail to take proper precautions,
even during routine maneuvers such as turning and driving
on hills or over obstacles.
For your safety, understand and follow all the warnings contained in this
Operator’s Guide and on the labels on your vehicle. Failure to follow these
warnings can result in SEVERE INJURY OR DEATH!
Keep this Operator’s Guide with the vehicle at all the times.
WARNING
Disregarding any of the safety precautions and instructions contained in this
Operator’s Guide and on-product labels can result in severe injury
including the possibility of death.
WARNING
This product contains or emits chemicals known to the state of California to
cause cancer and birth defects or other reproductive harm.

5
Know Before you go
To learn how to reduce the risk for you or bystanders being injured or killed,
read this Operator’s Guide before you operate the vehicle.
Also, read all safety labels on yourATV.
Failure to follow the warnings contained in this Operator’s Guide can result in
SERIOUS INJURY or DEATH.
Age Recommendation
These vehicles AT125-B is a category “T” (Transition Model), always
follow this age recommendation:
AT125-B is intended for recreational use by an operator age 14, 15 or older
under adult supervision, or by an operator age 16 or older.
-Also, never allow continued use of an ATV by a child if the child not have the
abilities to operate it safely, regardless of age.
Training Course
Never operate this vehicle without proper instruction. Take a training course.
All operators should receive training from a certified instructor.
FOR MORE INFORMATION ABOUT ATV SAFETY, contact your dealer,
Coleman Powersports 888-405-8725 or call SVIA 1-800-887-2887 to find out
about available training courses nearest you.
About this Operator’s Guide
Keep this Operator’s Guide in the vehicle so that you can refer to it for things
such as maintenance, troubleshooting and for instructing others.
The information contained in this document are correct at the time of
publication. However, Coleman Powersports maintains a policy of continuous
improvement of its products without imposing upon itself any obligation to
install them on products previously manufactured. Due to late changes, some
differences between the manufactured product and the descriptions and/or
specifications in this guide may occur. Coleman Powersports reserves the right
at any time to discontinue or change specifications, designs, features, models

6
or equipment without incurring an obligation upon itself.
This Operator’s Guide should remain with the vehicle when it’s sold.
Notice to Parents
Review this Operator’s Guide with any user of the vehicle.
Please take time with the children to review the instructions on its safe and
proper use, and pay particular attention to the on-product safety labels, before
allowing them to ride the vehicle.
Understand the controls and operation of the vehicle and carefully read the
Operator’s Guide.
Always remember that your approach to safety influences the child.
WARNING
This ATV is not a toy.
-Children differ in skills, physical abilities, and judgement. Some children
may not be able to operate anATV safely.
-No one under age 16 should operate an ATV without adult supervision at
all times.
-Never allow continued use of the vehicle by a child if he does not have the
abilities, the strength or the judgement to operate it safely.
While reading this Operator’s Guide, remember that:
WARNING
Indicates a potential hazard that, if not avoided, could result in serious
injury or death.
AN ATV CAN BE HAZARDOUS TO OPERATE. An ATV handles
differently from other vehicles including motorcycles and cars. A collision
rollover can occur quickly, even during routine maneuvers such as turning and
driving on hills or over obstacles, if you fail to take proper precautions.
SERIOUS INJURY OR DEATH can result if you do not

7
follow these instructions.
·Read this manual and all labels carefully and follow the operating procedures
described.
·Never operate an ATV without proper instruction. Take a training course.
Beginners should receive training from a certified instructor. Contact an
authorized ATV dealer to find out about the training courses nearest you.
·Never allow anyone under the age of 14 to operate this category TATV
·Never permit a guest to operate this ATV unless the guest has read this
manual and all product labels and has completed a certified training course.
·Always avoid operating an ATV on any paved surfaces, including sidewalks,
driveways, parking lots and streets.
·Never operate an ATV without wearing an approved helmet (DOT and/or
SNELL) that fits properly. You should also wear eye protection (goggles or
face shield), gloves, boots, a long-sleeved shirt or jacket, and long pants.
·Never consume alcohol or drugs before or while operating this ATV.
·Never operate at excessive speeds. Always travel at a speed which is proper
for the terrain, visibility and operating conditions, and your experience.
·Never attempt wheelies, jumps or other stunts.
·Always inspect your ATV each time you use it to make sure it is in safe
operating condition, always follow the inspection and maintenance procedures
and schedules described in this manual.
·Always keep both hands on the handlebars and both feet on the footrests of
the ATV during operation.
·Always go slowly and be extra careful when operating on unfamiliar terrain.
Always be alert to changing terrain conditions when operating theATV.
·Never operate on excessively rough, slippery or loose terrain.
·Always follow proper procedures for turning as described in this manual.
Practice turning at low speeds before attempting to turn at faster speeds. Do
not turn at excessive speeds.
·Always have the ATV checked by an authorized dealer if it has been involved
in an accident.
·Never operate ATV on hills too steep for the ATV or for your abilities.
Practice on smaller hills before attempting larger hills.
·Always follow proper procedures for climbing hills as described in this
manual. Check the terrain carefully before you start up any hill. Never climb
hills with excessively slippery or loose surfaces. Shift your weight forward.
Never open the throttle suddenly or make sudden gear changes. Never go over

8
the top of any hill at high speed.
·Always follow proper procedures for going downhill and for braking on hills
as described in this manual. Check the terrain carefully before you start down
any hill. Shift your weight backward. Never go down a hill at high speed.
Avoid going down a hill at an angle, which would cause the vehicle to lean
sharply to one side. Go straight down the hill when possible.
·Always follow proper procedures for crossing the side of a hill as described
in this manual. Avoid hills with excessively slippery or loose surfaces. Shift
your weight to the uphill side of the ATV. Never attempt to turn the ATV
around on any hill until you have mastered the turning technique described in
this manual on level ground. Avoid crossing the side of a steep hill when
possible.
·Always use proper procedures if you stall or roll backwards when climbing a
hill. To avoid stalling, maintain a steady speed when climbing a hill. If you
stall or roll backwards, follow the special procedure for braking described in
this manual. Dismount on the uphill side, or to either side if pointed straight
uphill. Turn the ATV around and remount, following the procedure described
in this manual.
·Always check for obstacles before operating in a new area. Never attempt to
operate over large obstacles, such as large rocks or fallen trees. Always follow
proper procedures when operating over obstacles as described in this manual.
·Always be careful of skidding or sliding. On slippery surfaces, such as ice,
go slowly and be very cautious in order to reduce the chance of skidding or
sliding out of control.
·Avoid operating the ATV through deep or fast-flowing water. Avoid water
which exceeds the recommended maximum depth, go slowly, balance your
weight carefully avoiding sudden movements, and maintain a slow and steady
forward motion. Do not make sudden turns or stops, and do not make sudden
throttle changes.
·Wet brakes may have reduced stopping ability. Test your brakes after leaving
water. If necessary, apply them lightly several times to let friction dry out the
pads.
·Always be sure there are no obstacles or people behind you when you operate
in reverse. When it is safe to proceed in reverse, go slowly. Avoid turning at
sharp angles in reverse.
·Always use the size and type of tires specified in this manual“17.
SPECIFICATION”. Always maintain proper tire pressure as described in this
manual“17. SPECIFICATION”.

9
·Never modify anATV through improper installation or use of accessories.
·Never exceed the stated load capacity for an ATV. Cargo should be properly
distributed and securely attached. Reduce speed and follow instructions in this
manual for carrying cargo. Allow greater distance for braking
2. UNDERSTANDING WARNINGS
ATTENTION:
THIS VEHICLE IS NOTATOY!
READ AND UNDERSTAND WARNINGS AND OWNER’S MANUAL
BEFORE OPERATION.
KNOW YOUR VEHICLE BEFORE YOU BEGIN RIDING!
Read this manual thoroughly referring to the various areas which are being
discussed on your machine. Operating this vehicle carries with its
responsibilities for your personal safety, the safety of others, and the protection
of our environment.
NOTE:Illustrations used in this manual are for general representation only.
Your model may differ.

10
Safety alert
WARNINGS identify special instructions or procedures which, if not
correctly followed, could result in personal injury, or loss of life. Read all
WARNINGS in this manual care fully. Follow their instructions to remain
safe.
The following precautionary signal words are used throughout this manual to
convey the following messages:
This is the safety alert symbol. When you see this symbol
on your machine or in this manual, be alert to the potential
for personal injury. Your safety is involved!
WARNING
Indicates a potential hazard which could result in severe injury or death.
CAUTION
Indicates a potential hazard which may result in minor personal injury or
damage to theATV.
CAUTION
Indicates a situation that can result in damage to the machine.
NOTE The word “NOTE” in this manual will alert you to key
information or instructions.

11
3. SAFETY WARNING
NOTE：
Warning decals have been placed on the vehicle for your protection. Read and
follow the instructions on each decal carefully. In the event any decal becomes
illegible or comes off, contact your dealer for a replacement.

12
1. General Warning Label

13
2.Age Recommendation Warning Label forAT125-B
3. Combined Tire Pressure and Overloading Warning Label forAT125-B

14
4. Passenger Warning Label
5. Certification Label

15
4. DAILY PRE-RIDE INSPECTION
WARNING
You must inspect your ATV each time before riding to ensure it is in proper
working order. If proper inspection is not done, severe injury or death could
result.
Use the following checklist to verify your machine is in proper working order
each time you ride.
Item/Inspection procedure
1. Tire-check condition and pressures.
2. Fuel tank-fill the fuel tank to its proper lever.
3. All brakes-check operation, adjustment and fluid level (includes auxiliary
brake).
4. Throttle-check for free operation and closing.
5. Headlight / Taillight / Brakelight-check operation of all indicator lights and
switches.
6. Engine stop switch-check for proper function.
7. Wheels-check for tightness of wheel nuts and axle nuts; check that axle nuts
are secured by cotter pins.
8. Air cleaner element-check for dirt; clean or replace.
9. Steering-check for free operation noting any unusual looseness in any area.
10. Loose parts-visually inspect vehicle for any damaged components or loose
nuts/bolts or fasteners.
11. Operators’helmets, goggles and clothing.

16
5. OPERATION WARNINGS
WARNING
POTENTIAL HAZARD
Operating this ATV without proper instruction.
WHAT CAN HAPPEN
The risk of an accident is greatly increased if the operator does not know how
to operate the ATV properly in different situations and on different types of
terrain.
HOW TO AVOID THE HAZARD
Beginning and inexperienced operators should complete the certified training
course. They should then regularly learn techniques described in the Owner’s
Manual.
For more information about the training course, contact an authorized ATV
dealer.
WARNING
POTENTIAL HAZARD
Operating this ATV without wearing an approved helmet, eye protection and
protective clothing.
WHAT CAN HAPPEN
Operating without an approved helmet increases your chances of a severe head
injury or death in the event of an accident.
Operating without eye protection can result in an accident and increases your
chances of a severe injury in the event of an accident.
HOW TO AVOID THE HAZARD
Always wear an approved helmet which fits properly.
You should also wear: eye protection (goggles or face shield), gloves, boots,
long-sleeved shirt or jacket, and long pants.

17
WARNING
POTENTIAL HAZARD
Carrying a passenger on this ATV.
WHAT CAN HAPPEN
Greatly reduces your ability to balance and control this ATV.
Could cause an accident, resulting in harm to you and /or your passenger.
HOW TO AVOID THE HAZARD
Never carry a passenger.

18
WARNING
POTENTIAL HAZARD
Operating this ATV on paved surfaces, including sidewalks, paths, parking lots,
and driveways.
WHAT CAN HAPPEN
Paved surfaces may seriously affect the handling and control of the ATV, and
may cause the vehicle to go out of control.
HOW TO AVOID THE HAZARD
Avoid operating the ATV on pavement.
