Comen C80 User manual

Multi-parameter Veterinary monitor
C80
User Manual
Shenzhen Comen Medical Instruments Co., Ltd.

I
Copyright
Version: A
Time: 2012 /09
Part No. 046-000333-00
Statements
Our Company makes no warranty of any kind with regard to this material, including(but not
limited to) the implied warranties of merchantability and fitness for a particular purpose. Our
Company assumes no responsibility for any errors that may appear in this document, or for
incidental or consequential damage caused by the providing, performance and using of this
manual.
This manual includes the proprietary information which is protected by the copyright law. All
rights reserved, any part of this manual can not be copied or photocopied by any form or method
without the consent of the Our Company.
Responsibility of the Manufacturer
Our Company only considerers itself responsible for the safety, reliability and performance of the
instrument under the following situations, as:
♦Assembly operations, extensions, re-adjustments, improvements and repairs are all
conducted by the personnel authorized by Our Company
♦The related electrical equipment complies with the national standards
♦Theinstrument is used in accordance with the instruction for use.
Note: This device is not intended for home use.
Warning :
This device is not intended for treatment.
Note: Nowadays, Our Company will provide the circuit diagram conditionally if the user requests
and in addition list to instruct the calibration methods and other information so as to help the user
to repair the parts which have been classified by the Our Company that the user can repair with
appropriate and qualified personnel.
Guide to Labels in the Manual
Warning :
The information you should know for how to avoid the damage that the patients and

II
medical staff may suffer.
Caution :
You should know the information for how to avoid the damage the equipment may
suffer.
Note: The important information you should know.

III
Contents
Chapter1General Information...............................................................................................1
1.1General Information..................................................................................................2
1.2Button Functions and Basic Operations....................................................................3
1.3Screen display ...........................................................................................................4
1.4External Socket .........................................................................................................9
1.4.1Left Panel ..........................................................................................................9
1.4.2Right Panel........................................................................................................9
1.4.3Rear Panel .......................................................................................................10
1.5Built-in charge battery.............................................................................................11
Chapter2MonitorAssembly .................................................................................................12
2.1Open Package and Check........................................................................................12
2.2Connect with AC Cable...........................................................................................12
2.3Power on .................................................................................................................13
2.4Connect with Sensor ...............................................................................................13
2.5Check Recorder.......................................................................................................13
Chapter3System Menu .........................................................................................................14
3.1PATIENT MANAGE ..............................................................................................14
3.2Survey setup............................................................................................................16
3.3SELECTION...........................................................................................................16
3.3.1ALARM Volume.............................................................................................16
3.3.2HEART BEAT VOLUME...............................................................................17
3.3.3KEY VOL (Keyboard Vol ).............................................................................17
3.3.4LCD LIGHT（LCD Brightness) ....................................................................17
3.4MONITOR SETUP (Monitor Setting) ....................................................................17
3.4.1ALARM SETUP .............................................................................................18
3.4.2RECORD (Record output setting)...................................................................18
3.4.3TIME SETUP (System Time Setting) .............................................................19
3.4.43.4.4 NURSE CALL SETUP ..........................................................................19
3.4.5MODULE SETUP ..........................................................................................19
3.5WORK INTERFACE SELECTION .......................................................................20
3.6TREND SCREEN ...................................................................................................20
3.7TREND TABLE (TREND Figure)..........................................................................21
3.8NIBP RECALL .......................................................................................................22
3.9Reviewing alarm .....................................................................................................23
3.10WAVE RECALL .....................................................................................................25
3.11INFO (Monitoring Information)..............................................................................25
3.12DRUG CALCULATION & TITRATION LIST .....................................................26
3.13Maintenance............................................................................................................26
3.14DEMO (Password: 5188)........................................................................................26
3.15SCR LOCK(screen lock).........................................................................................27
Chapter4System Work Interface .........................................................................................28
4.1Work Interface Selection.........................................................................................28

IV
4.1.1STANDARD ...................................................................................................28
4.1.2LIST FACE .....................................................................................................28
4.1.3TREND SCREEN ...........................................................................................29
4.1.4OxyCRG SCREEN .........................................................................................30
4.1.5BIG FONT INTERFACE................................................................................31
4.1.67-CH MULTI-LEADS DISPLAY...................................................................32
4.1.7ANESTHESIA-GAS SCREEN (optional)......................................................33
Chapter5Recording...............................................................................................................34
5.1General Information on the Recorder......................................................................34
5.2Record Type ............................................................................................................34
5.2.1Real-time record..............................................................................................34
5.2.2Frozen waveform record .................................................................................35
5.2.3The contents of the real time recording...........................................................35
5.3Operation and Status Information of Recorder .......................................................35
5.3.1Requirements on record paper.........................................................................35
5.3.2Normal service ................................................................................................35
5.3.3Insufficient paper ............................................................................................35
5.3.4Paper loading procedures ................................................................................36
5.3.5Solution to paper jam ......................................................................................36
Chapter6Trend ......................................................................................................................37
6.1TREND GRAPH (TREND Diagram).....................................................................37
6.1.1Select trend diagrams for various parameters to be displayed: .......................38
6.1.2Select 1-hour or 120-hour TREND diagrams:.................................................38
6.1.3Observe TREND diagrams of later or earlier duration: ..................................38
6.1.4Change the display zoom ................................................................................38
6.1.5Obtain the TREND data at certain time in the current TREND diagram........38
6.1.6Operation sample ............................................................................................39
6.2TREND TABLE (TREND Figure)..........................................................................39
6.2.1Select TREND Figures in various resolutions.................................................40
6.2.2Observe earlier or later TREND curves ..........................................................41
6.2.3Observe TREND data of various parameters ..................................................41
6.2.4Operation sample ............................................................................................41
6.3NIBP RECALL .......................................................................................................41
Chapter7Drug Calculation & Titration List.......................................................................43
7.1DRUG CALC..........................................................................................................43
7.2TITRATION............................................................................................................45
Chapter8Alarm......................................................................................................................47
8.1Alarm Type..............................................................................................................47
8.2Alarm Level ............................................................................................................47
8.3Alarm Mode ............................................................................................................48
8.4Lighting Alarm........................................................................................................48
8.5Sound Alarm ...........................................................................................................48
8.6Alarm Information ..................................................................................................49
8.7Alarm Parameter Flashing.......................................................................................49

V
8.8Icon of Alarm Status................................................................................................49
8.9Setting the upper and lower limits of alarm ............................................................50
Chapter9Patient Safety.........................................................................................................51
9.1Environment............................................................................................................51
9.2Power Source ..........................................................................................................51
9.3Monitor earthing .....................................................................................................52
9.4Equal-potential earthing..........................................................................................52
9.5Condensation...........................................................................................................52
9.6Explanations on Symbols Used in the Monitor.......................................................53
Chapter10Maintenance & cleaning.......................................................................................54
10.1Maintenance check..................................................................................................54
10.2Cleaning and Sterilization .......................................................................................54
10.2.1Note on Cleaning and Sterilization .................................................................54
10.2.2Cleaning ..........................................................................................................55
10.2.3Sterilization .....................................................................................................55
Chapter11ECG Monitoring....................................................................................................57
11.1Definition of ECG Monitoring................................................................................57
11.2Attentions during ECG Monitoring.........................................................................57
11.3Monitoring Procedures............................................................................................58
11.3.1Preparation ......................................................................................................58
11.3.2Install ECG leads.............................................................................................59
11.3.3ECG lead connection recommended for surgery patients...............................60
11.3.4Use the 5-lead ECG device. ............................................................................61
11.4ECG Hot Key ..........................................................................................................61
11.5ECG Menu ..............................................................................................................63
11.5.1ECG setting in parameter area ........................................................................63
11.5.2ECG setting in waveform area ........................................................................64
11.5.3ECG setting in measurements .........................................................................66
11.5.4About ST Monitoring......................................................................................67
11.5.5Arrhythmia Analysis .......................................................................................71
11.6ECG Alarms & Reminders......................................................................................75
Chapter12RESP Measurement..............................................................................................78
12.1Measure RESP ........................................................................................................78
12.1.1How to measure RESP....................................................................................78
12.1.2Setting of RESP monitoring............................................................................78
12.2RESP Setting in parameter area ..............................................................................79
12.3RESP setting in waveform area...............................................................................81
12.4RESP setting in measurements................................................................................81
12.5RESP alarm information and prompt information ..................................................82
12.6Maintenance & Cleaning.........................................................................................83
Chapter13SpO2 Monitoring...................................................................................................84
13.1Definition of SpO2 Monitoring...............................................................................84
13.1.1Principle for Measurement of SpO2 Volume Recording Parameter................84
13.1.2BOS/Pulse Monitoring....................................................................................84

VI
13.2Precautions in SpO2/Pulse Monitoring ...................................................................85
13.3Monitoring Procedures............................................................................................86
13.4Measurement restriction..........................................................................................87
13.5SpO2 Setting in the parameter area.........................................................................88
13.6SPO2 setting in waveform area...............................................................................89
13.7SPO2 setting in measurements................................................................................89
13.8Alarms & Reminders...............................................................................................90
13.9Maintenance & Cleaning.........................................................................................92
13.9.1Cleaning: .........................................................................................................93
Chapter14NIBP Monitoring...................................................................................................94
14.1General Information................................................................................................94
14.2NIBP Monitoring.....................................................................................................94
14.2.1NlBP Measurement .........................................................................................94
14.2.2Operational guide............................................................................................97
14.2.3Measurement restriction..................................................................................98
14.2.4NIBP Parameter Setting & Adjustment...........................................................99
14.3NIBP setting in parameter area ...............................................................................99
14.4NIBP setting in measurements ..............................................................................101
14.5NIBP Pressure Calibration ....................................................................................102
14.6Gas leakage detection............................................................................................103
14.7NIBPAlarms & Reminders....................................................................................104
14.8NIBP alarm information........................................................................................107
14.9Maintenance & Cleaning.......................................................................................107
14.9.1Recyclable blood pressure cuff .....................................................................107
14.9.2One-time blood pressure cuff........................................................................108
Chapter15TEMP Monitoring...............................................................................................109
15.1TEMP Monitoring.................................................................................................109
15.1.1TEMP measurement setting ..........................................................................109
15.2TEMP setting in parameter area............................................................................110
15.3TEMP setting in measurements.............................................................................111
15.4Alarm information and prompt information.......................................................... 111
15.5Maintenance & Cleaning.......................................................................................112
Chapter16CO2 Monitoring..................................................................................................114
16.1General..................................................................................................................114
16.2Measuring Principle and Working Process............................................................115
16.3Operating Instruction for CO2Connection............................................................115
16.4CO2Measurement Procedures ..............................................................................118
16.4.1Measuring Procedure of RESPIRONICS Branded Mainstream and Sidestream
Modules 118
16.4.2Measuring Procedure of PHASEIN Branded Sidestream and Mainstream
Analyzers ......................................................................................................................121
16.5CO2 Settings in Parameter Area............................................................................123
16.6CO2 Settings in Waveform Area...........................................................................125
16.7CO2Settings in Measurement Setup .....................................................................125

VII
16.8Discharging Waste Gases ......................................................................................126
16.9Maintenance and Cleaning of RESPIRONICS Branded Mainstream and Sdestream
Modules 127
16.9.1Common Cleaning ........................................................................................127
16.9.2Airway Adapter for Cleaning Reusable Mainstream Sensor.........................127
16.9.3Method for Sterilizing Reusable Adapter......................................................127
16.9.4Sterilization Times for Reusable Airway Adapter.........................................128
16.9.5Zeroing..........................................................................................................128
16.10PHASEIN Branded Mainstream and Sidestream Analyzer Related Information .128
16.10.1Zeroing ..................................................................................................128
16.10.2CO2Module Lighting Information........................................................129
16.10.3Others....................................................................................................129
Chapter17IBP Monitoring....................................................................................................130
17.116.1 General information ......................................................................................130
17.2Considerations of IBP monitoring.........................................................................130
17.3Monitoring procedure............................................................................................131
17.4IBP Menu ..............................................................................................................132
17.4.1IBP<1,2>setup in the parameter area ............................................................132
17.4.2IBP<1,2>setup in the waveform area............................................................135
17.4.3IBP<1,2>setup in the measurement setup.....................................................136
17.5Zero calibration of sensor: ....................................................................................137
17.6Mercury manometer calibration procedures: ........................................................138
17.7Alarm information and prompt information..........................................................140
17.7.1Alarm information.........................................................................................140
17.8Maintenance and Cleaning....................................................................................140
Chapter18Measurement of Anesthetic Gases .....................................................................143
18.1Overview...............................................................................................................143
18.2Measurement Principle and Work Process............................................................143
18.3AG Display ...........................................................................................................144
18.4MAC Value............................................................................................................145
18.5Preparations for Measurement ..............................................................................146
18.6AG Setup...............................................................................................................147
18.6.1CO2 Settings .................................................................................................147
18.6.2O2 Settings....................................................................................................149
18.6.3N2O Settings.................................................................................................151
18.6.4AG AA Settings.............................................................................................152
18.7Aderse effects on performance..............................................................................154
18.8Safety Alarm Information .....................................................................................155
18.8.1ISA Sidestream Gas Analyzer Safety Warning Information..........................155
18.8.2ISA Mainstream Gas Analyzer Safety Warning Information ........................157
18.9Airway Obstruction...............................................................................................159
18.10Discharging Waste Gases ......................................................................................160
18.11Consumables .........................................................................................................160
18.12Safety Symbol Information...................................................................................160

VIII
18.13Patents and Trademarks.........................................................................................162
18.14Maintenance..........................................................................................................162
18.15Cleaning the Analyzer...........................................................................................163
Appendix I.Accessories...................................................................................................164
Appendix II.Specification.................................................................................................166
Appendix III.Description of System Alarm Prompt........................................................174

1
Chapter1 General Information
For information about the monitor, please read the General Information on the Monitor chapter.
For introduction on various information displayed on screen, please read the Screen Display
chapter.
For operational methods, please read the Button Functions and Basic Operations chapter.
For locations of various interfaces, please read the External Interfaces chapter.
For notices of using the monitor with power supply from a battery, please read the Built-in
Chargeable Battery chapter.
Warning
This monitor is to monitor clinical patients, only for doctors and nurses’use.
Warning
Don’t open cover of the equipment to avoid possible risks in electric shock. Any
maintenance or upgrading on the monitor must be conducted by service personnel
trained and authorized by Our Company.
Warning
Don’t use this monitor where there are flammables such as anesthetic agent, so as to
prevent from explosion.
Warning
Users before starting use should check whether the equipment and its accessories can
work properly and safety.
Warning
Please make sufficient alarming setting for each patient in order to prevent from
delayed therapy and make sure there is voice effect during alarming.
Warning
Don’t use mobile phones around the monitor. Mobile phones will generate strong
emission fields and disturb the monitor.
Warning
During defibrillation don’t touch patients, tables and the machine.

2
Warning
Equipments inter-connected with the monitor should form an equal-potential body (as
protective effective earthing).
Warning
Users (doctors or nurses) should ensure safety of patients under monitoring, when the
monitor is used together with electrosurgical equipments.
1.1 General Information
Transport and Storage:
Temperature: -20℃～+40℃
Humidity: ≤80%
Atmospheric Pressure: Pressure: 50kPa～106kPa
Working:
Temperature: 5℃～+40℃
Humidity: ≤80%
Atmospheric Pressure: 86kPa～106kPa
Voltage:
a.c.100V~240V 50Hz/60Hz
FUSET1.6A
The portable Veterinary Monitor is of rich functions, applicable for bedside monitoring on
Veterinary, such as cat, dog, the small animals.
This monitor can monitor main parameters including ECG, RESP, SpO2, NIBP, Double TEMP,
IBP, EtCO2 and Anesthesia Gas. It integrates parameter measurement modules, display and record
output to build such a solid and light monitor. Its replaceable built-in battery makes convenience
for patient movement and it will clearly display 7 waveforms and all the monitoring parameter
information on the high-resolution interface.
Notice:
IBP , CO2 and Anesthesia Gas are optional.
From left to right they are in turn:
(1) ALARM INDICATOR; (2)Waveform area; (3) ON/OFF button ; (4)Function button; (5)Knob;
(6)MENU; (7)Parameter area; (8)Information area. The Knob has three working methods as
turning left, turning right and pressing to confirm parameters are mainly applied to the operation
of menu.

3
The outlet of the recorder is located on the left side of monitor and AC power line sockets are on
the rear panel of the monitor.
Figure 1-1 Multi-parameter Patient Monitor
This monitor has rich functions, able to provide various functions such as visual/audio alarming,
TREND storage & output, NIBP measurement save and review, medicine calculation, ST analysis,
pulse analysis, heart rate turbulence analysis, etc.
This monitor has a friendly operation interface, able to provide all functions with the keys and
buttons on the front panel, refer to Function Keys part for details.
1.2 Button Functions and Basic Operations
The monitor can be operated through use of the buttons and knobs. Here are the functions of the
buttons as follows:
(SILENCE button): Press this button and the alarm will be silence for 3
minutes (this item can be set in the “Alarm Setting” menu). Press this button
over 1 second and the alarm sound can be shielded. In the information area
appears sign. Repress this button again to pause alarm, resume heart beat
sound and cancel some technical alarm (ECG off, SPO2 off), and the sign
disappears.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)

4
(FREEZE button): Press this button and all waveforms on the screen can be
frozen in the normal mode. Press this button once again and the frozen
waveforms can be freed.
(PRINT button): Press this button to start a real-time recording. The recording
length is determined according to the “real-time recording time” in the
“Recorder” submenu of “Setting” menu. Press this button once again in the
recording process and the recording will stop at once. Each interval of pressing
this button should be greater than 2 seconds and the frequency should not be
excessively high.
（To start/stop NIBP measurement）, press to inflate the cuff to start a blood
pressure measurement. When measuring, press to stop the measurement and
deflate the cuff.
(MENU button): Press this button to have the main menu pop up when the
interface is in the state of non-window setting.
(ON/OFF button): Press this button to control the startup and shutdown of the
monitor.
a.c. INDICATOR
Work INDICATOR
JOG-DIAL JOG-DIAL to select and change the settings. Operation can be performed by
turning it clockwise, counterclockwise or pressing it down. JOG-DIAL is
mainly used in menu and window operation
1.3 Screen display
This monitor has a color LED screen, able to concurrently display collected patient
parameters, waveforms, and alarming information provided by the monitor, bed marks, clocks,
monitor status and other reminder information.
The main screen is divided into 4 sub-areas, i.e., Information Area , Waveform Area ,①②
Parameter Area and Menu Area (As shown in Figure 0③④ -2)

5
Figure 1-2 Main screen display
Information Area ( ):①
Prompt message in the information area appears and disappears together with the reported state. In
accordance with the content, it is divided into:
1. Network setup: Cursor stops in sign, press to enter system setup.
Network Bed No.: refer to IP address for monitor, The IP is 200.200.200.X,（Xis
Network Bed No.:, from 1 to 100）
Caution
Connection state of CMS (central monitoring system) : when displaying , no
connection; when displaying , connection.
Network Bed No. should not conflict with other monitors, or there will be unnecessary problems
for the monitor.
If any problem happens because of confliction, unplug network wire, restart the monitor, reset the
Network Bed No. and connect the network wire again.
2. Patient Information: press to enter the Patient Information menu when cursor is in bed No.,
name or patient group area.
“Bed No.”: Refer to the bed number of the patient being monitored, this area will be
blank if there is no input.
Name: Patient name, this area will be blank if there is no input.
Information Area
Parameter
Area
Waveform
Area
Menu Area

6
Sex: Male and Female.
Weight(kg): patient’s weight
Patient Type: neonatal, pediatric, adult
Update patient: Replaced with new patients, once the update, delete the monitoring data
on a patient
3. Time setup: set up local time
time: display system time
4. Technical alarm: display technical alarm, such as ECG lead off.
5. Physical alarm: display physical alarm, such as T2 too low.
6. Battery: display capacity of batter.
Full capacity
Not full capacity
Low capacity
Very low capacity, need to charge soon.
7. Volume setup: setup alarm volume, heart beat volume, key volume.
Alarm volume: there are five Alarm Vol levels, 1, 2, 3, 4 and OFF, where "OFF" level
means the alarm sound is closed.
Alarm volume on, alarm level 4
Alarm volume off
Caution
Visual alarm and alarm status
Alarm light winks or shines when there is an alarm. The colour of light means the alarm
level. Refer to alarm function chapter for details.
Waveform Area ( )②
There are four waveforms in the waveform area, which are respectively from up to down:
two-channel ECG waveform, SpO2 volume graphic waveform and respiratory waveform
(possibly from ECG module).
The name of selected waveform is displayed on the upper left part. For details, please refer to
chapter of ECG Monitoring. Each ECG waveform still shows the gain of this channel and the
filtering method of ECG waveform. A 1-mv rod is on the left of ECG waveform.
When you choose/touch each waveform, submenu of waveform will be pop up, which always
occupies most of space of waveform area, so that some waveforms are invisible. The original
image will come back after the menu exit.
Waveforms are refreshed at the set speed. For adjustment on waveform refresh speed, refer to the

7
chapter of each Parameter Setting.
ParameterArea( )③：
Parameters can display at the fixed position (as shown in ~①○12of the following picture), which
are separately:
Figure 1-3 Main Screen
ECG
—Heart Rate or Pulse Rate（,unit①：bpm）
—pacer detection ( PACE)②
—ST-segment of channel 1 and channel 2 ( , unit: mv)③
— PVCs times ( Unit: times/minute)④
NIBP
— None-Invisive Blood Pressure
(From left to right) Systolic, Diastolic, Mean ( , Unit: mmHg or kPa)⑤
SpO2
—SpO2（⑥,unit：%）
②
③
④
⑤
⑥
⑦
①
○
8
○
9
○
10 ○
11

8
—Pulse Rate（unit：bpm）
IBP (optional)
— Invisive Blood Pressure
(From left to right) Systolic, Diastolic, Mean (⑦, Unit: mmHg or kPa)
TEMP
—TEMP
—Temperature（⑧,unit: or℃℉）
CO2 (optional)
—end-tidal CO2 (⑨, Unit: mmHg or kPa)
—inspiratory CO2 (⑩, Unit: mmHg or kPa)
—Air Way Respiration Rate (AWRR)（○
11 ,unit：bpm）
RESP
—Respiration Rate（,unit：bpm）
The above monitored results will show in the parameter area.
The parameters are refreshed once per second, but NIBP value, once per measurement.
Users can select the monitoring parameters and the main screen will display the relative content.
Menu Area(④)
1. PATIENT: patient information configuration. Refer to chapter of Patient Informatio for details.
2. ALARM SETUP: set up alarm type
ALARM RECORD TIME: in case of physiological alarm, the system can record the
information before and after the alarm time. The system can give three kinds of time, i.e., 8
seconds, 16 seconds. The seconds in the options are the sum of seconds before and after the
alarm time. For example, 8 seconds mean the information within 4 seconds before the alarm
time and within 4 seconds after such a time.
ALM PAUSE TIME (Alarm pause time)：“1 minute”, “2 minutes” or “3 minutes”
ALAM LIMIT (Display alarm limits)：”ON” and”OFF”
ALM LATER :Disabled ,5s,10s,15s,20s. Select "Disable", when an alarm occurs, the
instrument that occurs immediately alarm; When Select "five seconds", alarm occurs only
when the parameters continue to exceed the the alarm upper or lower limit of 5 seconds
instrument, other settings and so on. The purpose of this feature is to reduce the instant false
alarms, allow doctors to more accurately grasp the situation
3. SURVEY SETUP: ECG, RESP, SpO2, NIBP and TEMP setup, refer to each chapter for details
4. SCREEN CHANGE: STANDARD, LIST FACE, TREND SCREEN, oxyCRG SCREEN, BIG
FONT, AND 7CH MULTI-LEADS DISPLAY. For details,please refer to chapters for each

9
parameter.
5. NIBP STARTt: press this button to start/stop NIBP measurement.
6. FROZEN: the screen freezes when press this button, turn the knob to review all the waveform
stored for the last 4 minutes.
7. TREND GRAPH, TREND TABLE (TREND Figure), NIBP RECALL: refer to chapter 3 for
details.
8. PRINT: press this button to record waveforms and patient information.
9. SCR LOCK: In order to avoid non-operators misuse Monitor, the instrument has a touch
screen lock function. Click on the "lock screen" button to lock the touch screen in the main
interface. For To unlock the the continuous point lived unlock the screen "option for three seconds,
you can unlock the screen is locked
1.4 External Socket
1.4.1 Left Panel
Recorder is optional
1. Open the recorder door.
2. Take away the no-paper rod
3. Fix the new paper correctly, tip of paper out from the
head of printer.
4. 3mm paper must out of recorder door, close the door.
5. Press PRINT to check if the paper fixed well or not.
If no printing, prease re-fix the paper.
Fig 1-4 Recorder
1.4.2 Right Panel
On the right side of the monitor are sockets for each transducer

10
① ECG1
② NELLCORSPO2
③ ECG2
④ IBP1 （optional）
⑤ Hidden NIBP
⑥ TEMP1
⑦ TEMP2
⑧ CO2（optional）
⑨ IBP2（optional）
⑩ ICG or Anesthesia Gas（optional）Fig 1-5
This symbol means “be careful”; refer to this manual for details.
This symbol means this application part is of CF type, designed with special protection
from electric shock (especially provided with F-type floating insulation apparatus for permissible
leakage current) and suitable for the defibrillation process.
Other symbols will be introduced in the Patient Safety chapter.
this symbol means: BF type
means the equipotential grounding terminal.
A.C. indicator
work indicator
Power-up
Switch-on/off
1.4.3 Rear Panel
There are the following soclets in the rear panel:
①
②
③
④
⑤
○
6
○
7
○
8
○
9
○
10

11
Fig 1-7 rear panel socket
Fig1-6 RearPanel
Handle 2.Fan 3.rear panel socket（Fig 1-7 ○1Fuse-holder,○2Power socket,○3 Equipotential
socket,○4Nurse call socket,○5Network socket,○6Channel socket,○7VGA socket,4.Speaker
Warning
This network port can only be connected with CARL NOVEL’s central monitoring
system.
Warning
All the simulated or digital equipments connected with this monitor must be certified
under the designated IEC standards (such as IEC 60950 Data Processing Equipment
Standard and IEC 60601-1 Medical Equipment Standard). And all configurations must
comply with effective versions of IEC 60601-1-1 system standards. Persons in charge of
connecting additional equipments with the input/ output signal terminals should
configure the medical system and be responsible for compliance of the system to IEC
60601-1-1 standard. For any enquiries, please contact the supplier.
Warning
Patient cable interface, network interface and other interfaces connected to different
equipments, the leakage current should not exceed the limit.
1.5 Built-in charge battery
The multi-parameter monitor has a built-in charge battery. When connected with AC power, the
battery will charge automatically until it is full. On the right side of the screen, there is a “ ”, it
means charging state. Its yellow part means the quantity of the battery. If this monitor has no
built-in battery, the battery state will display “ ”, it means no battery or defective battery.
②
①
③
④
○
1○ 2○ 3○ 4○ 5○ 6○ 7
