PET RAMP
INSTRUCTION MANUAL

1-800-672-4399
Available exclusively at
OVERVIEW
This pet ramp includes panels you’ll need to connect together using braces of various shapes, plus a support ladder that
keeps it upright. Follow these steps and once you’re done putting it together, your pets will think you’re a genius!
ASSEMBLY INSTRUCTIONS FOR ITEM #156784
GEAR UP
You’ll need a Phillips head screwdriver (not included), a set of pliers (not included) and an allen key (included).
IT TAKES TWO
We recommend that assembly be a two-person project.
PARTS INCLUDED
Prior to assembly, please be sure to identify and sort all parts shown below.
1 Short Panel (#4)1 Long Panel Curved
Bottom Edge (#1) 1 Long Panel Straight
Bottom Edge (#2) 1 Support Ladder (#6)
2 Support Feet (#9)
2 Bent Braces (#5)
2 Short Braces (#8)
2 Angled Braces (#7)
4 Nuts (G)
28 Washers (F)
2 Long Braces (#3)
1 Allen Key (E)
4 Screws, M6 x 30mm (A)
22 Screws, M6 x 50mm (B)
4 Screws, M6 x 65mm (C)
2 Screws, M6 x 72mm (D)

1-800-672-4399
Available exclusively at
PART 2 - CONNECT SHORT PANEL TO LONG PANELS
PART 1 - CONNECT LONG PANELS
STEP 2 Place a bent brace (#5) on either
side of the inside edge of the short panel
(#4), lining the screw holes on the bent brace
with the threaded holes on the short and
long panels. Hint—the bent braces also angle
toward you, just like the short panel.
STEP 2 We all need a little support, so
put the long braces (#3) in place. Place one
on the inside edge where the 2 long panels
overlap, lining up the screw holes on the long
brace with the threaded holes on the long
panel. Do the same with the second long
brace, on the other side.
STEP 3 Place in 3 screws (B) with washers
in the holes on the bent brace (#5), but
skip the second to last hole (you’ll need
it for part 3b). Tighten screws loosely with
included allen key (E).
STEP 3 Put in screws (B) with washers (F)
into the 4 screw holes to attach the 2 long
support braces (#3) on either side. Tighten
screws loosely with included allen key (E).
STEP 1 Place the 1 short panel (#4)
(it’s the runt of the pack) next to the now
connected 2 long panels. You’ll want to
place it next to the end of the long panel
that has the threaded holes (#2).
STEP 1 Place the 2 long panels (#1) and
(#2) on a flat surface, with the ends with
the 2 threaded holes touching. Hint—these
threaded holes will be used to attach the
long panels to one another.
2
21
3
3
1
PART 3 - CONNECT SUPPORT LADDER AND ANGLED BRACES
STEP 3 Repeat Step 2 for the second
angled brace (#7) on the other side, and
TIGHTEN ALL HARDWARE using the
included allen key.
3
STEP 2 The 2 angled braces (#7) act
as support beams to secure the support
ladder (#6), so have them handy. Align
angled brace with the threaded hole on the
inside middle of the support ladder and
the threaded hole on the inside middle of
the bent brace. HINT—This is the hole we
left open in part 2. Insert screws (D) and
washers (F), but DON’T TIGHTEN YET.
2
STEP 1 Place the support ladder (#6) on
the short panel (#4), lining up the 2 screw
holes on the support ladder with the 2
threaded holes on the free end of the short
panel. Insert screws (C) and washers (F) on
each side, then tighten screws with nuts
(G) using the included allen key (E). Use
pliers if needed.
1

1-800-672-4399
Available exclusively at
• Grab a friend—it’s recommended that two people assemble this product.
• Assembly should be completed on a clean, level surface.
• Power tools are not recommended for assembly.
• Intended for pet use only. Do not use a ramp for people.
WARNINGS AND CAUTIONS
Please read all warnings and instructions thoroughly before assembling.
CALL OUR FRIENDLY CUSTOMER SERVICE TEAM ANYTIME.
WE’RE HERE 24/7! 1-800-67-CHEWY (672-4399)
QUESTIONS?
CLEANING INSTRUCTIONS
If small nicks or scratches occur, the finish can be restored using the recommended pet-friendly, furniture polish.
Spot clean with a damp cloth as needed.
PART 4 - ADDING THE SUPPORT FEET
STEP 2 Locate the 2 support feet (#9)
to connect to the support ladder. Align the
holes on the support feet with the holes
on the bottom of the support ladder. Insert
screw (A) and tighten fully.
2
NICE AND TIGHT? ALRIGHT!
Make sure all screws are tightened fully before standing the ramp upright, then let your pet climb on!
STEP 1 Find your remaining 2 short
braces (#8) and line up with the threaded
holes where the long panel and short
panel meet. Place screws (B) and washers
(F) in the holes and tighten fully.
1
