Comer AS650 Operating instructions

mod. AS650
NORM - CARB - EPA
Manuale d’Uso e Manutenzione
Operating and Maintenance manual
Betriebs- und Wartungsanleitung
Manuel d’Utilisation et d’Entretien
Manual de Uso y Mantenimiento
®
S.p.A.

SERIAL NUMBER AND YEAR OF MANUFACTURE
TABLE OF CONTENTS
Page
3 ....... - Warnings
3 ....... 1 - Warranty terms
4 ....... 2 - TECHNICAL DATA
4 ....... 2.1 - components
6 ....... 2.2 - technical specications
6 ....... 2.3 - noise and vibrations
6 ....... 2.4 - equipment supplied
7 ....... 4 - SYMBOLS AND
PICTOGRAMS
8 ....... 5 - PREPARING the machine
8 ....... 5.1 - fuelling
9 ....... 5.2 - starting
9 ....... 5.3 - stopping the engine
Page
10 ....... 6 - USE IN SAFE
CONDITIONS
11 ....... 6.1 - use, techniques and
precautions
12 ....... 6.2 - principal safety regulations
13 ....... 7 - CARBURETTOR
13 ....... 7.1 - adjusting the carburettor
14 ....... 8 - MAINTENANCE AND
WARRANTY
14 ....... 9 - SHORT AND LONG IDLE
PERIODS
15 ....... 10 TROUBLESHOOTING

Do not keep the engine
running out of the water for
more than 10 seconds.
Do not allow water to enter
through the snorkel or in the
fuel tank.
Take care when refuelling.
Water may be present.

3
WARNINGS.
Our sincerest congratulations on becoming the Owner of this
FANTASTIC AQUASCOOTER.
- The Aquascooter is a unique product, designed and built with the great-
est attention to the user’s health and safety, and protection of the environment.
- No other machine is so complete. It is ideal for a number of recreational uses.
- It is a simple 2-stroke engine that will give you many hours of enjoyment if used and serv-
iced correctly. It is designed for your leisure time and not as an instrument of work.
Failure to comply with the operation and maintenance procedures will void the war-
ranty. Read this manual carefully before using your Aquascooter: in this way you can
prevent damage to the engine and avoid costly repairs.
- The manual, the declarations of conformity and power engine are integral parts of the ma-
chine. It must be kept in a safe place and delivered with the machine if it is sold to a new user.
- The information in this manual may change without prior notice, without prejudice to the
safety-related technical characteristics.
This danger symbol in the manual draws your attention to important in-
structions concerning safety. Failure to comply with such instructions can
cause serious injuries to persons.
- Any jobs or repairs the customer feels he is unable to do himself should be carried out by
authorised service centres, with the fuel tank empty.
1 - WARRANTY TERMS
- The warranty is valid for 24 months from the date of delivery, so long as the certicate
is lled out correctly and forwarded within 8 days from the purchase date. During
this warranty period, COMER S.p.A. undertakes, after having carried out the due techni-
cal assessments, to repair and/or replace the defective parts for which the manufacturer is
responsible.
WARNING! Tampering voids the warranty.
- The costs of any labour, forwarding expenses and sending spare parts are always at
the purchaser’s complete charge.
WARNING! for Service Centres
- Parts replaced under warranty must be returned to the manufacturer with a
copy of the warranty within 20 days at most, or the warranty will become void.
IN ANY CASE THE MANUFACTURER DECLINES ALL LIABILITY FOR:
- Modications made without the manufacturer’s approval.
- Use of accessories not contemplated by the manufacturer.
- Improper use of equipment with snap-hooks, cords around the fuel tank, collisions with
rocks, etc.
- Failure to comply with the instructions in this manual.
- Failure to comply with the safety regulations and recommendations in this manual.
- When the engine has blocked owing to the entrance of water.
- Failure to comply with the general and basic rules of caution and prudence.
- COMER S.p.A. declines all liability for damage to persons, things or the machine itself
caused by incorrect or improper use of the same.
All disputes are the competence of the Court of Reggio Emilia.

4
2 - TECHNICAL DATA
2.1 - COMPONENTS
1 - AIR TANK
2 - AIR TANK PLUG FOR SNORKEL CONNECTION
3 - FUEL TANK PLUG
4 - FUEL TANK
5 - FUEL VALVE
6 - EXHAUST GAS OUTLET
7 - FUEL PIPE
8 - STARTER HANDLE
9 - STEERING HANDLE
10 - THROTTLE LEVER

5
11 - “AVVIAMENTO - START - STOP” POSITIONS
12 - CARBURETTOR TO CARB - EPA STANDARDS
13 - “START AND RUN” LEVER
14 - “RUN/MARCIA” POSITIONS
15 - PROTECTIVE GRILLE
16 - FUEL TANK BREATHER PIPE
17 - PROPELLER GUARD AND WATER DEFLECTOR
18 - CARRY HANDLE
19 - SPARK PLUG
20 - AIR INTAKE TUBE (SNORKEL)
21 - SNORKEL EXTENSION
22 - RUBBER BUMPER

6
2.2 - TECHNICAL SPECIFICATIONS 650
2-stroke, direct drive engine
Power output at 5000 rpm 2 HP - 1.47 KW
Swept volume 49 c.c.
Thrust 22 kg
Ignition Electronic C.D.I.
Spark plug Bosch WR 10 BC
Fuel tank capacity 2 l. (no reserve)
Fuel mixture with synthetic oil (biodegradable) 1,5%(100:1,5) rst 5 hours
Autonomy of operation (approx.) 2 hours
Weight 7.00 kg
Dimensions 530 X 300 X 195 cm
2.3 - AIRBORNE NOISE AND VIBRATIONS
Sound Pressure Level: continuous equivalent sound pressure measured at
the ear of the user, measured conventionally at a height of 20 cm and at the
centre of the tank, with the engine supplying 1.2 kW at 4000 rpm.: LAeq = 75
dBA
Vibrations: weighted mean square value in frequency to which the upper limbs
are subjected, with engine at 85% of top speed, in accordance with ISO stand-
ards = 10m/s2.
2.4 - EQUIPMENT SUPPLIED:
Spark plug wrench, spark plug, funnel, starter rope,
biodegradable oil.
Warranty - Declaration of conformity and engine power,
use and maintenance manual.
AQUA MAT
Boat Bracket
Carrier Bag
OPTIONAL ACCESSORIES:
- Carrier bag
- “AQUA MAT” mattress
SYNTHETIC
oil mixture
30 ml.
150 ml.

7
4 - SYMBOLS AND PICTOGRAMS
- The following pictograms are afxed to the tank (see page 4 - 5). Always pay
particular attention to them and bear in mind what they mean:
It is obligatory to read
the whole manual
carefully before us-
ing the machine.
Turn off the engine
before proceeding
with any mainte-
nance or repairs.
Do not lubricate,
clean or perform
maintenance on the
machine while it is
running.
Do not smoke near
the machine.
DANGER of elec-
tric shock; do not let
any part of your body
touch the electrical
parts of the machine.
DANGER of amputa-
tion due to the pres-
ence of the propeller.
It is forbidden to re-
move the protective
covers when the ma-
chine is running.
It is obligatory to put
on a lifejacket before
getting into the wa-
ter.

8
5 - PREPARING THE MACHINE
- The machines are equipped with handy carrying points.
- They are shipped from the factory in specic packaging.
- The machines are tested before delivery. Prior to using the machine and with
the engine off, always make sure the protective covers have not been tampered
with and that there is no evident damage.
5.1 FUELLING
Fuel: use unleaded petrol.
Oil: special synthetic oil at 1,5% (100 parts pet-
rol to 1,5 parts oil), which guarantees excellent
lubrication.
How to prepare the mixture: pour one litre of
petrol into the tank through the rear inlet marked
with the symbol . Add the oil and then pour in
the remaining litre of fuel.
WARNING. Do not ll the tank right up to the
brim. Leave a small amount of air above the level of the fuel. Screw on the plug
and shake for 5 seconds, then unscrew the tank plug to relieve any overpressure
before screwing it back on again.
BEFORE USE:
1 - Unscrew the air tank plug and t the snor-
kel in its place.
WARNING. Make sure the snorkel is fully
tightened.
WARNING!!
Do not fully empty the can used for fuelling as
it may contain water.
Do not refuell while the machine is in the wa-
ter: even only a few drops of water in the fuel
tank can damage the carburettor and the en-
gine.

9
5.3 - STOPPING THE MOTOR
1- For short stops: block the opening of the snorkel with a nger, leaving the
fuel tap and the carburettor lever in the “run” positions. It will be easier to start
the engine the next time, because you just have to pull the starter cord with the
accelerator always at maximum.
2 - For longer stops (when the engine has cooled down):
stop the engine with the carburettor lever in the “AVVIAMENTO-START-STOP”
position.
Now immediately move the lever back to the “RUN/MARCIA” position. It will be
easier to stat the engine again, with the accelerator always at maximum.
NOTE: If the Aquascooter does not start in the water, follow the cold start
procedure by moving the carburettor lever to the ”AVVIAMENTO-START-STOP”
position and pull the starter cord once only. Then move the lever back to the
”RUN/MARCIA” position and start again.
5.2. STARTING
1 - Open the fuel valve by moving the yellow lever to the
horizontal “APERTO-OPEN” position.
2 - Turn the red lever of the carburettor anticlockwise
to the “AVVIAMENTO-START-STOP” position for a cold
start and after a LONG IDLE PERIOD only.
3 - Grip the steering handle with one hand, while moving
the throttle lever to full throttle position.
4 - Pull the starter handle up to three times with your other hand. When you hear
the engine re, move the carburettor lever immediately back to the “RUN/MAR-
CIA” position by turning it clockwise.
Pull the starter cord again until the engine starts.
When the engine has started, accelerate up to 2-3 times before getting into the
water.
WARNING. Do not allow the engine to run for more than
10 seconds out of the water or the piston will begin to
deform through overheating.
NOTE: Follow the procedure described in points 1-2-3-
4 with a new machine and for cold starts. Just pull the
starter cord with the carburettor lever still in the “RUN/
MARCIA” position if you are starting with the engine still
hot either on the beach or in the water.

10
6 - USE IN SAFE CONDITIONS
- Only carry the Aquascooter by its handle. Do not let it fall sideways into the
water because water will enter the snorkel and block the engine.
- Hold the steering handle and hold down the throttle with your thumbs.
- Do not use the engine at top rate for the rst 10 hours.
- Use the Aquascooter with your arms outstretched. Keep your body and legs in
a relaxed horizontal position to reach top speed.
- Keep the snorkel well out of the water and use the extension.
- Make sure you do not accidentally touch the red carburettor lever during use, as
this will stop the motor immediately.
- Avoid zones with banks of algae, shallow water and rocks (these can damage
the propeller).
- If you let go of the Aquascooter when it is running, it will perform a slow turn
around you and can be easily recovered.
Avoid this operation when there are bathers present, in rough seas, where
there are strong currents, or if the carburettor has not been properly adjusted to
allow the engine to idle (you could lose the Aquascooter).
- You can stop the Aquascooter and start it again in the water. In the case of
brief stops, to start again just pull the starter with one hand, while using the other
to hold the steering handle with the accelerator at maximum.
For longer stops, use the cold start procedure to start again.
IMPORTANT - The Aquascooter is only a surface craft for one person. In
order to run, the engine needs air to come in through snorkel, but if water
should get in through the snorkel, it can cause serious problems with the
internal parts of the motor.
a) Always use the snorkel with the extension, especially in rough seas.
b) Fully tighten the ring nut on the snorkel and the fuel tank plug. Check to make
sure that the gaskets are not damaged.
c) Absolutely avoid situations that could let water get into the snorkel (rough sea,
user acrobatics under the water, throwing the machine into the water, overturning,
etc.).

11
6.1 - USE, TECHNIQUES AND PRECAUTIONS
- If just a few splashes of water get in, this water will remain in the bottom hollows
inside the air tank without causing damage. However, it is advisable to empty
out any water as soon as you get back to the beach.
- It’s an entirely different matter if a large amount of water ows quickly
into the snorkel. This happens in particular if the end of the snorkel becomes
submerged, causing a mass of water to suddenly ow in and stop the engine
immediately. The water must be emptied out as soon as possible, or the
engine will be irreparably damaged.
SOLUTION !
Drain any water out of the tank immediately. Then drain the machine
completely in the following way.
1) Shut off the fuel valve (OFF - CLOSED - CHIUSO).
2) Unscrew the snorkel and the spark plug.
3) Turn the aquascooter upside down and pull the starter repeatedly (as many
as 8 times) until all the water has been drained out of the engine. This is the only
way to avoid the damage to the internal parts of the engine through rust. After
this,replace the spark plug and open the fuel valve again (APERTO -OPEN - ON).
4) Now attempt to start the engine according to the normal procedure; if the
machine fails to start, clean or replace the spark plug. Start the motor again using
the cold start procedure. It is important to get the engine started and to then
get into the water and use the aquascooter for at least 10 minutes.
WARNING - If the engine has stopped because water has got into the snorkel,
and after repeatedly draining the engine and attempted starts you cannot
get it to re-start, it is advisable to unscrew the spark plug, ll the cylinder
with the oil used in the mixture (20 ml) and to pull on the starter cord slowly
2-3 times. Then contact your nearest Aquascooter Service Centre within 48
hours.
Starter rope and spring replacement.

12
6.2 - PRINCIPAL SAFETY REGULATIONS.
- Aquascooter is designed for use by good swimmers. A lifejacket must be
worn at all times.
- Keep at a safe distance from the beach (do not go out farther than you can
swim back).
- The Aquascooter is not a buoyancy aid and is not designed to support the
weight of a person in the water.
- Long hair, ribbons, cords, necklaces, etc. must be kept away from the
propeller. If you have long hair, wear a bathing cap (long hair can be caught
up by the propeller).
- Children should only use the Aquascooter under adult supervision.
- Beware of obstacles under water or on the surface.
- Always avoid getting too close to other bathers or craft in the water.
- Never leave the Aquascooter running and unattended in zones where
there are other people.
- Do not put anything into the water intake deector (propeller guard).
- Do not smoke while refuelling, emptying or preparing the fuel mixture.
- Only start out with a full fuel tank (roughly 2 hours of run time). There is
no reserve.
- Do not start the engine in closed environments (the exhaust gases are
toxic).
- Empty the fuel out of the Aquascooter before transporting it on any type of
vehicle. Use metal containers for the fuel that comply with the law.
- The Aquascooter is not for diving. Keep the intake of the snorkel well
above the surface of the water and check frequently for any traces of water
in the air tank: if there is any water, empty it out.
- If necessary, the Aquascooter can be turned off quickly by blocking the
snorkel with a nger, or with the START-STOP lever.
- Do not tamper with the controls and never remove the safety systems and
guards of the machine, even momentarily.
- Do not inhale the exhaust gas.

13
7 - CARBURETTOR
- The Aquascooter has a carburettor with two membranes. The rst membrane
acts as a pump, drawing the fuel from the tank and into the engine as required.
Faults involving this pump-membrane are extremely rare.
- The second membrane, located in the bottom part, regulates the ow of fuel and
needs to be connected to the external atmospheric pressure so as to regulate
the fuel to suit the engine’s needs. In normal engines that do not run in the water,
this is done with a simple hole in the cover of the membrane. The Aquascooter’s
carburettor has to run in the water, so this system cannot be used. There is
therefore a rubber tube connecting the carburettor to the atmospheric pressure in
the air tank (5, g.7).
7.1- ADJUSTMENTS.
1 - Idling/Medium rate adjuster screw (
L
)
2 turns
2 - Full throttle (H) rpm adjuster screw 1
and 3/4 turns
3 - Idling adjuster screw
4 - “Start and Run” lever
5 - Membrane pressure compensation tube
6 - Spark plug
7 - Air tank
8 - Rubber stopper for closing the carburetor
screws
9 - Adjusting key
- This engine has been designed and built in accordance with CARB-EPA
Exhaust Emission Standards.
- The Exhaust Emission Control System includes the fuel system, the intake system
and, more importantly, the carburettor: designed to allow only adjustments of
screws
L
and H in a preset range established by the manufacturer that
cannot be modied by the user.
You can only adjust the throttle valve “idling” adjuster screw (3, g. 7) to regulate
the engine in the water if it stops when idling.
7.2 - WARNING: With the Aquascooter out of the water and the accelerator at full
throttle, the engine must always be abundantly supplied with fuel, otherwise you
will not obtain maximum power in the water.
If faults or fuel problems occur, contact your nearest dealer who can adjust the
relevant screws
L
and H by 1/8 of a turn with a special wrench, to nd the optimal
setting and allow the engine to function without stopping in the water.
g.7

14
8 - MAINTENANCE
Before servicing the Aquascooter in any way, turn the off the engine
and take care of any hot parts that could scorch the skin.
After use, even when stopping for only a few hours, comply with the
”Short stops” procedure to prevent the internal parts of the engine from rusting or
the engine from seizing (which would require costly repairs).
NOTE: Traces of corrosion in the engine are due to the user’s failure to
comply with the procedures described in this manual. This situation, testi-
ed by the corrosion inside the engine, is regarded as negligence and voids
the warranty.
9 - SHORT STOPS
At the end of each day of use and even for brief periods of effective use of the
machine:
1 - Unscrew the snorkel and turn the Aquascooter upside down to empty all traces
of water out of the air tank.
Slowly turn the Aquascooter so the water can gradually ow out of the air
tank intake. Turning the machine over suddenly may allow water to ow
into the carburettor.
2 - Start the Aquascooter out of the water and run it only for 10 seconds, inclined
at 30°, at different speeds, using various positions of the accelerator. This warms
the engine up sufciently to eliminate any water that may have entered or con-
densed in the combustion chamber, engine block or silencer.
WARNING: To avoid overheating the engine, never allow it to run out of
the water for more than 10 seconds and never at full throttle speed. After
10 seconds the piston begins to overheat and can become deformed with
possible seizure.
3 - After running the engine out of the water, turn it off by blocking the snorkel or,
even better, with the START-STOP lever.

15
10 - TROUBLESHOOTING
- Most problems can be solved simply with a little patience, by systematically
checking the initial procedure for ”Preparing the machine” (page 8) and the start-
ing procedure (page 9).
- For example, if the engine fails to start, make sure there is fuel mixture in the
tank and that the fuel valve is open. Have you installed the snorkel in place of the
plug on the air tank? Have you changed the spark plug? You might have ooded
the engine.
- If you cannot nd the problem after having followed this procedure, take your
Aquascooter to the nearest Service Centre, as you would for any other machine.
Any judgement as to the performance of the Aquascooter must be made in nor-
mal conditions of use in the water. This procedure presumes that the fuel mixture
used is in the correct proportions and that the machine has not been modied (for
example, tted with an unsuitable spark plug, lled with the wrong oil, tampering
with the carburettor screws and fuel lines, tampering with the intake connector,
clamps and screws, assembly of cords and snap hooks).
A) THE MACHINE FAILS TO START OR IS DIFFICULT TO START:
- Are you following the correct starting procedure? (page 9)
- Make sure that the red carburettor lever is in the correct position.
- Is the spark plug wet? Clean, dry, or replace if necessary (in some cases, this
operation must be repeated). Try starting again with the red carburettor lever in
“RUN/MARCIA” position.
LONG STOPS (e.g.: at the end of the season)
1 - If it has been used in salt water, wash the outside of the Aquascooter
with fresh water.
2 - Unscrew the SNORKEL and turn the Aquascooter upside down to eliminate
any water from the tank.
3 - Allow the Aquascooter to operate with a fuel mixture at 6% for not more than
12 seconds at different speeds, then stop it by moving the carburettor lever to the
“STOP” position with the engine at top rate.
4 - Close the air tank with its plug.
5 - Empty the fuel mixture from the tank to eliminate any drops of water.
6 - Turn off the fuel valve.
7 - Store the Aquascooter in a dry, sheltered place.
WARNING: If you cannot test the Aquascooter, remove the spark plug and pour
20 ml of fuel mixture oil into the cylinder. Slowly pull the starter cord 2-3 times so
the oil lubricates all the parts. Screw the spark plug back on.

16
- Water in the fuel tank: empty the entire contents of the tank, and replace with
new fuel. Check the carburettor: may contain drops of water.
- Check the plug: it may not have been closed properly, or the plug seal may be
damaged and water may have entered the carburettor (which must be replaced).
- Check that the fuel draw pipe is correctly positioned on the bottom of the tank.
Make sure that the tubes are not broken and that the draw
pipe is not clogged.
- Idling adjustment wrong: follow the procedure (page 13, g.
7).
B) THE ENGINE STOPS WHEN THE MACHINE IS PLACED IN THE WATER:
1 - If the engine stops when the water reaches the spark plug, a solution is to ll
the inside of the spark plug cap with grease or Vaseline.
Install a new, original spark plug cap as soon as possible.
2 - The throttle valve idling adjuster screw is not adjusted properly: turn clock-
wise.
3 - The engine slows in the water when cruising at full power: is poor power from
the carburettor, turn the H screw anticlockwise for 1/8 of a turn (page13, g. 7).
OTHERWISE
4 - Light blue breather tube (D, g. 8) blocked
or full of fuel. Remove from the tank and clean.
5 - Intake elbow clamps loose.
6 - The engine fails to tick over in the water?
7 - Piston worn due to water entering from the
snorkel, the intake union, the exhaust valve or
the fuel tank.
8 - Tank breather. The rubber valve is in the
small internal tube in the fuel tank inlet: check
that it is there and move the internal part with
a pin (C, g. 8) to allow a small amount of air
to pass through.
- Make sure that the exhaust gas valve is not deformed or at. If it is, dismantle it
with a screwdriver, start the engine, and then reassemble it or replace it (A, g. 8).
- Replace the exhaust valve at least twice a year to prevent water from enter-
ing the engine.
Warning: It is absolutely essential to empty the fuel tank if you send your
Aquascooter away for repairs.
g.8

POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT
PREZZO UNITARIO
UNIT PRICE €
1 Rubinetto completo Fuel shut-off cock, compI. 7000 2033 1
12,00
1a Vite rubinetto Shut-off cock screw 70001066 1
4,00
2 Set adesivi Decal set 7000 1013 1
8,00
4 Pesca carburante Fuel pick-up 7000 1061 1
6,00
5 Valvola sato Valve 7000 1039 1
3,50
6 Serbatoio Tank 7000 2010 1
70,00
7 Tappo Cap 7000 2005 2
5,00
8 Manico trasporto Carry handle 7000 1017 1
5,00
9 Clip Ø 6 Clamp Ø 6 7000 1068 3
0,30
10 Tubo compensazione cm.20 Pressure relief hose cm.20 7000 0003 1
2,00
11 Tubo carburante cm.30 Fuel hose cm.30 7000 0003 1
2,00
12 Raccordo aspirazione Intake elbow 7000 1055 1
8 , 0 0
13 Fascetta Clamp 7000 1056 1
4,00
14 Tubo sato Pressure relief hose 7000 1054 1
3,00
15 Rondella Washer 7000 1037 2
0,30
16 Vite laterale Screw, lateral 7000 1024 2
4,00
17 Molla candela Spark plug spring 7000 1095 1
0,60
18 Cappuccio e molla Cap and spring 7000 1093 1
4,00
19 Candela Bosch. Spark plug Bosch 7000 1133 1
5,00
20 Vite frontale 5x25 Screw, cruise handle 5x25 7000 1038 1
1,00
21 Rondella Washer 7000 1021 1
0,30
22 Snorkel Snorkel 7000 2001 1
12,00
23 Prolunga snorkel Snorkel extension 7000 2002 1
10,00
24 Busta attrezzi Tool kit 7000 1010 1
15,00
25 Conf. olio mix 150 ml. Oil mix bottle 150 ml. 7500 9001 1
6,75
25D Conf. olio mix 30 ml. Oil mix bottle 30 ml. 7500 9002 1
2,00
26 Raccordo a 90° Elbow 90° 7000 1069 1
2,20
27 Clip Ø 8 Clamp Ø 8 7000 1072 2
0,30
28 Boccola serbatoio Tank bush 7000 1063 1
4,00
29 Paracolpi in gomma Rubber bumper 7000 2046 1
10,00
POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT
PREZZO UNITARIO
UNIT PRICE €
1 Inserto puleggia Starter pulley axle 7000 1047 1
12,00
2 Molla avviamento Starter spring 7000 1051 1
10,00
3 Scat. avv. c/paraolio Starter housing w/oil seal 7000 2040 1
18,00
4 Anello di tenuta Water seal 7000 1050 1
3,50
5 Puleggia avviamento Starter pulley 7000 1046 1
10,00
6 Funicella avviamento Starter rape 7000 2009 1
2,00
7 Vite conica 4x16 Conical screw 4x16 7000 1049 1
1,00
8 Calotta Nosepiece 7000 1045 1
3,00
9 Impugnatura avviamento Starter handle 7000 1052 1
4,00
10 Avviamento completo Starter compI. 7000 2007 1
38,00
11 Vite scatola 5x25 Screw, starter housing 5x25 7000 1022 4
1,00
12 Rondella Washer 7000 1018 4
0,30
13 O.R. perno puleggia O ring, starter axle 7000 1062 1
0,50
14 Boccola x fune Bush for rape 7000 1044 1
0,50
Fig.1 SERBATOIO / TANK
Fig.2 AVVIAMENTO/STARTER SYSTEM
POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT
PREZZO UNITARIO
UNIT PRICE €
1 Dado autobloccante elica Nut, propeller 7000 1020 1
2,00
2 Elica Propeller 7000 2004 1
14,00
3 Disco di protezione Protection sleeve 7000 1086 1
0,80
4 Anello di tenuta elica Water seal 7000 1091 2
3,50
5 Kit gabbia e boccola Needle bearing kit 7000 2037 1
10,00
6 Coppia basamenti Crankase assy 7000 2020 1
75,00
7 Distanziale Sleeve 7000 1125 1
2,00
8 Cuscinetto elica Propeller bearing 7000 1089 1
5,00
9 Anello tenuta alb.Witon Witon oil seal 7000 1092 2
5,00
10 Cuscinetto Iato volano Bearing, ywheel side 7000 1090 1
5,00
11 Albero motore Ø 40 Crankshaft+needle bearing 7000 2032 1
90,00
Albero motore Ø 41 SM Crankshaft+needle bearing SM 7000 1140 1
90,00
12 Astuccio a rulli Upper needle bearing C050-048 1
5,00
12a Gabbia a rulli slabile Sliding needle bearing 7000 1131 1
5,00
13 Rondella Washer 7000 1018 4
0,30
14 Vite cilindro 5x20 Screw, cylinder 5x20 7000 1081 4
1,00
16 O.R. tenuta volano O ring, ywheel side 7000 1088 1
2,50
19 Rondella Washer 7000 1018 6
0,30
20 Vite basamenti 5x40 Screw 5x40 7000 1032 6
1,00
21 Spinotto Piston pin 7000 1118 1
4,00
22 Anello di fermo Piston pin clip 7000 1116 2
0,30
23 Guarnizione cilindro Cylinder gasket 7000 1028 1
1 , 0 0
24 Pistone completo Ø 40 Piston complete Ø 40 7000 1120 1
40,00
Pistone completo Ø 41 SM Piston complete Ø 41 SM 7000 1142 1
40,00
25 Segmenti Ø 40 Piston rings Ø 40 7000 1119 2
4,50
Segmenti Ø 41 SM Piston rings Ø 41 SM 7000 1144 2
4,50
26 Kit cilindro / pistone Ø 40 Cylinder / piston kit Ø 40 7000 2035 1
95,00
Kit cilindro / pistone Ø 41 SM Cylinder / piston kit Ø 41 SM 7000 2044 1
95,00
27 Cufa cilindro Cylinder head 7000 1071 1
4,00
28 Griglia protezione CE Safety-Grid CE 7000 1025 1
5,00
29 Set guarnizioni + O.R. Set gasket + O ring 7000 2030 1
10,00
31 Vite protezione 4x10 Safety screw 4x10 70001036 5
0,50
32 Blocco motore assemblato Engine assy assembly 7000 1078 1
280,00
33 Estrattore elica Propeller puller 7000 2036 1
50,00
34 Tampone paraolio Oil seal buffer 7000 1000 1
10,00
35 Tampone paraolio elica Propeller oil seal buffer 7000 1000 1
10,00
36 Boccola chius. basamento CranKase lock bush 7000 1139 1
100,00
37 Biella completa Connetting rod 7000 1110 1
50,00
38 Perno ferma pistone Piston check pin KACC-126 1
4,00
Fig.3 BLOCCO MOTORE / ENGINE BLOCK

POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT PREZZO UNITARIO
UNIT PRICE €
1 Convogliatore acqua Propeller guard 7000 1014 1 10,00
2 Vite marmitta 5x90 Screw, mufer 5x90 7000 1023 2 3,50
3 Rondella in rame Copper washer 7000 1080 2 0,70
4 Marmitta Mufer 7000 2026 1 55,00
5 O.R. di tenuta grande O. Ring (Iarge) 7000 1103 1 2,50
6 O.R. di tenuta medio O. Ring (medium) 7000 1104 1 2,50
7 Vite convogliat. 4x16 Screw, guard 4x16 7000 1082 2 1,00
8 Rondella Washer 7000 1031 2 0,30
9 Kit valvola di scarico Exhaust valve kit 7000 2034 1 8,00
10 Estrattore marmitta Mufer extractor 7000 2031 1 60,00
11 Tampone scarico Mufer buffer 7000 2041 1 10,00
Fig.4 MARMITTA / MUFFLER
Fig.5 ACCENSIONE ELETTRONICA
ELECTRONIC IGNITION
POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT PREZZO UNITARIO
UNIT PRICE €
1 Accensione elettronica C.D.I. ignition 7000 1132 1 110,00
2 Chiavetta Woodruft key 7000 1070 1 0,80
3 Rondella Washer 7000 1031 2 0,30
4 Grover ø 4 Grover ø 4 7000 1085 2 0,30
5 Vite statore 4x16 Screw electric system 4x16 7000 1082 2 1,00
6 Gommino passacavo Grommet, stop cord 7000 2019 1 2,00
7 Grover ø 8 Grover ø 8 7000 1084 1 0,30
8 Dado ssaggio volano Nut ywheel 7000 1040 1 0,50
12 Molla arpioncino Starter pawl spring 7000 1108 2 1,50
13 Arpioncino Starter pawl 7000 1109 2 3,00
14 Perno ssaggio arpioncino Pin starter pawl 7000 1107 2 3,00
15 Cavo con cappuccio Hose with cap 7000 1136 1 12,00
16 Estrattore volano Flywheel puller 7000 1130 1 18,00
POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT PREZZO UNITARIO
UNIT PRICE €
1 Guarnizione angia Flange gasket 7000 1074 1 1,00
2 Flangia per Walbro Walbro ange 7000 2015 1 10,00
3 Rondella Washer 7000 1018 1 0,30
4 Vite angia 5x20 Screw, ange 5x20 7000 1081 1 1,00
5 Guarnizione carburatore Carburetor gasket 7000 1076 1 1,00
6 Carburatore Walbro Walbro carburetor 7000 1128 1 65,00
7 Guarniz. collettore Intake ange gasket 7000 1077 1 1,00
8 Collettore aspirazione Intake ange 7000 2017 1 7,00
9 Fascetta Clamp, intake elbow 7000 1034 1 4,00
10 Rondella in rame Washer 7000 1080 2 0,70
11 Vite carburatore 5x67 Screw, carburetor 5x67 7000 1073 2 2,00
12 Set membrane Walbro Walbro diaphragm set 7000 1122 1 16,00
13 Prova carburatore Carburetor tester KACC 140 1 33,00
14 Chiave carburazione Carburetor wrench 7000 1124 1 4,00
15 Set guarnizioni 1/5/7/23 Set gasket 1/5/7/23 7000 1137 1 4,00
16 Tappino in gomma Small rubber cap 7000 1145 1 1,00
Fig.6 CARBURATORE WALBRO
WALBRO CARBURETOR
POS DESCRIZIONE DESCRIPTION N. CODICE-PART N. QT PREZZO UNITARIO
UNIT PRICE €
2 Leva acceleratore Throttle lever 7000 2006 1 12,00
3 Impugnatura Cruise handle 7000 1016 1 18,00
4 Rondella Washer 7000 1021 2 0,30
5 Vite impugnatura 5x20 Screw, cruise handle 5x20 7000 1081 2 1,00
6 Rondella Washer 7000 1021 1 0,30
7 Dado ss. impugnatura Nut, cruise handle 7000 1019 1 0,30
Scatola Aquascooter Aquascooter box 7000 1012 1 5,00
Imballo neutro Packing 1 3,00
Fig. 7 IMPUGNATURA / CRUISE HANDLE
*Rondelle e viti inox *Stanley steel washers and screws
*Guarnizioni speciali *High quality gaskets
*Anelli O-ring speciali *High quality O-rings

DICHIARAZIONE di POTENZA
Engine Power Declaration
(Art.28 Decreto Legislativo 18 luglio 2005,n° 171)
Costruttore del motore Legale Rappresentante Rivenditore Autorizzato (*)
Engine Manufacturer/legal representative/authorized seller
COMER SPA – VIA STORCHI, 8 –42011 BAGNOLO IN PIANO (RE)
Modello AQUASCOOTER AS 650 CE Numero di serie
Engine Model Serial Number
Tipo di motore PROPULSORE X HOBBY Combustibile impiegato MISCELA 1%
Engine Type Specication of reccomended fuel
Potenza dichiarata 2 HP Kw a 1,47 Giri/min 5.000
Declared Rated Power Kw a rp0
All’albero portaelica All’albero motore
Declared propeller shaft power Declared crankshaft power
Consumo orario Massimo 1 l/h Ora A/h
Hourly max consumpion Ampere ora
Ciclo QUATTRO Tempi 2 T Iniezione a carburatore Cilindrata totale 49 cm³
Cycle Stroke Carburettor injection Total swept volume
Numero e disposizione cilindri 1 in linea Alesaggio 40 mm Corsa 39 mm
Number of cylinder Cylinder Bore Piston Stroke
Massa [kg] 7
Weight [kg]
Sistema di aspirazione ASPIRAZIONE NATURALE
Induction System
Raffreddamento aria di sovralimentazione NO Massima contropressione allo scarico 0,00 kPa
Charge air cooling Maximum premissible exhaust backpressure
Timbro e rma del costruttore, del legale rappresentante
o del rivenditore autorizzato nel territorio UE
Stamp and signature of engine manufacturer, legal representative
or authorized seller in EU
(*)Marcare la voce corretta COMER S.p.A.
Tickthe item which is applicable Vanessa Santini
La falsità della dichiarazione e/o l’utilizzo di dichiarazione falsa concretizzano le fattispecie di cui agli articoli 483 o.p. (falsità ideologica commes-
sa dal privato in atto pubblico) e 489 c.p. (uso di atto falso).
Comer S.p.A. – Loc. S. Tomaso – 42011 BAGNOLO IN PIANO (RE) – Ufci: Via Storchi, 8 – Magazzino: Via Rabitti, 9
Tel. +39 (0) 522 – 955045 / FAX +39 (0) 522 – 955040
Cap Soc. i.v. € 817.438,96 – R.E.A. di RE 108113 – N. Mecc. RE 005160 – Registro Imprese di RE/cod. Fisc. – P. I.
00130020357 – Cod. Identicativo C.E.E. IT 0013002
x
