Comfort Zone CZ16W Series User manual

Save These Instructions
www.comfortzoneproducts.com
CZ16W Series
Features:
• 3 Speed Settings
• Adjustable Vertical Tilt
• Rotary Dial Speed
• Pull-String Speed Control
• Pull-String Oscillation Control
• All Metal Safety Grilles
• 120V A.C. / 60 Hz.
Wall Mount Oscillating Fan

2
2
www.comfortzoneproducts.com
INTENDED USE:
This product is intended for indoor residential and ofce use only,
not for industrial or other commercial applications. Use only with
electrical wiring that is in good working order and that meets
applicable codes and ordinances. If you have any questions
whether your wiring is adequate, consult a qualied electrician.
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word “WARNING” to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
IMPORTANT INSTRUCTIONS
As with all electrical appliances, basic safety precautions should
always be followed to reduce the risk of electric shock, re, or
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
re or injury to persons.
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non-combustible, level surface.
• Always unplug fan when not in use, when moving from place
to place, when assembling or disassembling parts, and before
cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non-window models).
• Do not operate the fan with blade guards or any safety device
removed.
• Avoid the use of extension cords due to risk of re. If an
extension cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from trafc
area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the
fan. Doing so may cause electric shock and/or re hazard.
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
READ & SAVE THESE
INSTRUCTIONS
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
ooded basements.
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
combustible materials or ammable gases or sources of heat.
Do not use in areas where gasoline, paint or ammable materials
are used or stored. To prevent a possible re, do not block air
intakes or exhaust in any manner. Do not insert or allow foreign
objects to enter any ventilation or exhaust opening as this may
cause an electric shock, re, or damage the fan.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code.
CAUTION: TO PREVENT ELECTRIC SHOCK
This product has a polarized two prong plug (one blade is wider
than the other) that must be fully inserted in to a matching
properly grounded outlet. This plug is designed to t a polarized
outlet only one way. If the plug does not t fully into the outlet,
reverse the plug. If the plug still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use this product with any solid-state speed control
device.
Do not operate any fan with a damaged cord or plug or after fan
malfunctions, has been dropped or damaged in any manner. Do
not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact World and Main Customer Service by telephone
or mail for information and assistance.
Do not run power cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from trafc
area where it will not be tripped over. Avoid the use of extension
cords due to risk of re. If an extension cord must be used, the
cord must be minimum 14 AWG and rated not less then 1875
watts. Do not use an extension cord unless the plug can be
completely inserted into its receptacle. Unplug the fan when not
in use. Do not operate fan with its ventilation obstructed.

3
3
www.comfortzoneproducts.com
USAGE:
FAN OPERATION: Always operate the fan in the upright
position following all instructions and recommendations listed
in this manual. FAN LOCATION: Place the fan in the area of the
room that will provide proper fan cooling. FAN CONNECTION:
Plug fan directly into 120 Volt A.C., 60Hz wall outlet. Be sure plug
ts tightly in outlet. A loose connection may cause overheating
and damage to the plug or fan. NOTE: To prevent overloading
a circuit, do not plug the fan into a circuit that is servicing other
electrical needs.
TURNING FAN ON: With fan mounted to a stable wall surface,
plug fan into properly functioning outlet. To start the fan, rotate
the dial from the OFF position to the desired fan speed (1 - LOW,
2 - MEDIUM, or 3 - HIGH). This fan is equipped with additional
pull-string control for easy reach. Pull the right side pull-string
to turn unit ON and adjust fan speed.
TURNING FAN OFF: To turn the fan off, rotate the switch from
its current fan speed setting to the OFF position. This fan is
equipped with additional pull-string control for easy reach. Pull
the right side pull-string to cycle past fan speeds and turn unit
OFF. Remove plug from outlet.
OSCILLATION: To start fan oscillation, pull left side pull-string
while operating at any fan speed. To stop oscillation function
simply pull oscillation pull-string again to discontinue oscillation
while operating the fan at any speed.
ADJUSTING FAN TILT: To adjust the tilt angle simply tilt the fan
to desired position. Ratcheting effect should hold the fan at the
desired angle.
ASSEMBLY INSTRUCTIONS:
Images may vary slightly from actual product.
ASSEMBLY INSTRUCTIONS: (cont.)
Mount
Securely
to Wall
Control Panel
Power /
Fan Speed
Rotary Dial
Oscillation
Pull-String
Power /
Fan Speed
Pull-String
STEP 2:
Assemble Rear Grille onto
Motor Housing. Rear Grille
should t into pins on fan
motor housing as shown.
STEP 3:
Thread Locknut onto Motor
Housing to lock Rear Grille
in place.
STEP 4:
Remove any protective
covering over shaft before Fan
Blade installation. Place Fan
Blade onto Motor Shaft. Notice
the pin on Motor Shaft should
t into slots of Fan Blade.
STEP 5:
Thread Blade Cap onto
threaded end of Motor Shaft.
NOTE: Threads are reversed.
Tighten = Counter-clockwise.
STEP 6:
Attach Front Grille to Rear
Grille with Hook Clip centered
on the top above Wire Handle.
STEP 7:
Press remaining Grille Clips
onto Rear Grille to securely
attach Front Grille. Do not
operate fan without Grille in
place.
STEP 8:
Secure Wall Bracket to the wall
in the desired location. Use
proper anchors for the wall
material selected, following the
manufacturers instructions.
Mounting bracket to wall studs
is recommended.
STEP 9:
Hang fan on wall bracket.
Place Bracket Screw through
fan and thread screw onto
bracket.
STEP 1:
Remove the Blade Cap by
twisting it CLOCKWISE while
holding the metal shaft tightly.
NOTE: Threads are reversed.
Unscrew = Clockwise.
Pin
Pin
Pin
Slot
Hook Clip
Grille
Clip
Bracket
Screw
Loosen
Blade Cap
Tighten
Locknut

4
4
www.comfortzoneproducts.com
LIMITED WARRANTY
This unit is guaranteed to the original retail purchaser against
defects in quality or workmanship for a period of one year
from the date of original purchase. If this unit fails because of
a manufacturing defect within 30 days of purchase, return the
unit, with your receipt, to the retailer. After 30 days, but within the
warranty period, if the unit was purchased within the continental
United States, return it, freight prepaid, to World and Main for
repair or replacement. If the unit was purchased outside the
continental United States, return the unit to the place of
purchase. This warranty does not cover damage caused by
misuse, abuse, overheating or alteration. Repairs made by
anyone other than World and Main are not covered in this
warranty. World and Main will not be held liable for any losses
due to neglectful operation. All implied warranties, including
the warranties of merchantability and of tness of purpose, if
applicable, are hereby limited in duration to the period of one
year from the date of original retail purchase. Some states do
not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you. Incidental or
consequential damages arising from a breach of either express
or implied warranties are hereby disclaimed and excluded. Some
states do not allow the exclusion of limitation of incidental or
consequential damages, so this limitation or exclusion may not
apply to you. Upon the expiration of this warranty all such liability
will terminate. No other warranties are expressed or implied.
This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state. No informal
dispute settlement mechanisms are available. This limited
warranty is given in lieu of all other warranties.
Manufactured for:
World and Main (Cranbury), LLC
324A Half Acre Rd.
Cranbury, NJ 08512 USA
800-221-6895
www.comfortzoneproducts.com
Rev. 09/2021
CARE AND MAINTENANCE:
CLEANING: CAUTION – Before cleaning the fan be sure to
disconnect power cord from the plug. Clean the grille surface
with a clean damp cloth. Do not use harsh chemical or
abrasive cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES
IN WATER. Allow fan to dry completely before use. Periodic grille
cleaning with a vacuum will prevent dust build up. The motor is
sealed and does not require any interior maintenance, cleaning
or lubrication.
MAINTENANCE: The internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
REPAIR: DO NOT USE THE FAN IF IT HAS MALFUNCTIONED
OR BECOME DAMAGED IN ANY WAY.
STORAGE: Keep original carton for storage of the heater.
Coil and tie the power cord to avoid damage during storage.
FUSE REPLACEMENT:
This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the
user servicing instructions (follow product marking for proper
fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for
examination and/or repair.
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on top of
attachment plug towards blades (see Fig. 2).
3. Remove fuse carefully. Use a small tool to pry the end of the
fuse from holder cavity. Be careful not to break glass window.
4. Replace fuse. WARNING: Risk of re. Replace fuse only with
identical 2.5 or 5.0 Amp, 125 Volt fuse (3.6 mm x 10 mm). Be
sure fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
Slide Cover to Open
Figure 1 Figure 3Figure 2
Slide Cover to Open
