COMPANION 315.101811 User manual

Operator’s Manual
Model Nos.
315.101811 – 9.6 Volt
315.101821 – 12 Volt
3/8 in. CORDLESS DRILL-DRIVER
Variable Speed / Reversible
WARNING: To reduce the risk of
injury, the user must read and understand
the operator’s manual before using this
product.
Customer Help Line: 1-800-932-3188
Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.sears.com/craftsman
983000-492
4-04
3
R
Save this manual for future reference

2 3
nWarranty.......................................................................................................................................................................... 2
nIntroduction..................................................................................................................................................................... 2
nGeneral Safety Rules ...................................................................................................................................................3-4
nSpecific Safety Rules...................................................................................................................................................... 4
nSafety Rules for Charger................................................................................................................................................. 5
nSymbols .......................................................................................................................................................................6-7
nFeatures .......................................................................................................................................................................8-9
nAssembly ...................................................................................................................................................................... 10
nOperation .................................................................................................................................................................11-16
nMaintenance ............................................................................................................................................................17-18
nExploded View and Repair Parts List............................................................................................................................ 19
nParts Ordering / Service ............................................................................................................................................... 20
TABLE OF CONTENTS
INTRODUCTION
ONE YEAR FULL WARRANTY ON COMPANION TOOL
If this Companion tool fails due to a defect in material or workmanship within one year from the date of purchase,
RETURN IT TO THE NEAREST SEARS STORE IN THE UNITED STATES, and Sears will replace it, free of charge.
This warranty is void if this tool is used for commercial or rental purposes.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179
WARRANTY
This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.

2 3
WARNING! READ AND UNDERSTAND ALL
INSTRUCTIONS. Failure to follow all instructions
listed below, may result in electric shock, fire and/or
serious personal injury.
SAVE THESE INSTRUCTIONS
WORK AREA
n Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
n Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
n Keep bystanders, children, and visitors away while
operating a power tool. Distractions can cause you to
lose control.
ELECTRICAL SAFETY
n A battery operated tool with integral batteries or a
separate battery pack must be recharged only with
the specified charger for the battery. A charger that
may be suitable for one type of battery may create a
risk of fire when used with another battery.
n Use battery operated tool only with specifically
designated battery pack. Use of any other batteries
may create a risk of fire.
n Use battery only with charger listed.
MODEL BATTERY PACK CHARGER
315.101811 130122043 140209025
315.101821 130122044 140209026
n Do not abuse the cord. Never use the cord to carry
the charger. Keep cord away from heat, oil, sharp
edges, or moving parts. Replace damaged cords
immediately. Damaged cords may create a fire.
PERSONAL SAFETY
n Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use tool while tired or under the influence of
drugs, alcohol, or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
n Dress properly. Do not wear loose clothing or
jewelry. Contain long hair. Keep your hair, clothing,
and gloves away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
n Avoid accidental starting. Be sure switch is in the
locked or off position before inserting battery pack.
Carrying tools with your finger on the switch or insert-
ing the battery pack into a tool with the switch on
invites accidents.
n Remove adjusting keys or wrenches before turning
the tool on. A wrench or a key that is left attached to a
rotating part of the tool may result in personal injury.
n Do not overreach. Keep proper footing and balance
at all times. Proper footing and balance enable better
control of the tool in unexpected situations.
n Use safety equipment. Always wear eye protection.
Dust mask, non-skid safety shoes, hard hat, or hearing
protection must be used for appropriate conditions.
n Do not wear loose clothing or jewelry. Contain long
hair. Loose clothes, jewelry, or long hair can be drawn
into air vents.
n Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
tool in unexpected situations.
TOOL USE AND CARE
n Use clamps or other practical way to secure and
support the workpiece to a stable platform. Holding
the work by hand or against your body is unstable and
may lead to loss of control.
n Do not force tool. Use the correct tool for your
application. The correct tool will do the job better and
safer at the rate for which it is designed.
n Do not use tool if switch does not turn it on or off. A
tool that cannot be controlled with the switch is
dangerous and must be repaired.
n Disconnect battery pack from tool or place the
switch in the locked or off position before making
any adjustments, changing accessories, or storing
the tool. Such preventive safety measures reduce the
risk of starting the tool accidentally.
n Store idle tools out of reach of children and other
untrained persons. Tools are dangerous in the hands
of untrained users.
n When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys,
nails, screws, or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
sparks, burns, or a fire.
n Maintain tools with care. Keep cutting tools sharp
and clean. Properly maintained tools with sharp
cutting edges are less likely to bind and are easier to
control.
n Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that
may affect the tool’s operation. If damaged, have
the tool serviced before using. Many accidents are
caused by poorly maintained tools.
n Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one tool may create a risk of injury when
used on another tool.
n Keep the tool and its handle dry, clean and free
from oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline, petroleum-
based products, or any strong solvents to clean your
tool. Following this rule will reduce the risk of loss of
control and deterioration of the enclosure plastic.
GENERAL SAFETY RULES

4 5
GENERAL SAFETY RULES
n Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring. Contact with a “live” wire will
also make exposed metal parts of the tool “live” and
shock the operator.
n Know your power tool. Read operator’s manual
carefully. Learn its applications and limitations, as
well as the specific potential hazards related to this
tool. Following this rule will reduce the risk of electric
shock, fire, or serious injury.
n Always wear safety glasses with side shields.
Everyday glasses have only impact resistant lenses.
They are NOT safety glasses. Following this rule will
reduce the risk of eye injury.
n Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the
risk of serious personal injury.
n Protect your hearing. Wear hearing protection dur-
ing extended periods of operation. Following this rule
will reduce the risk of serious personal injury.
n Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery tool or when changing
accessories. Following this rule will reduce the risk of
electric shock, fire, or serious personal injury.
SERVICE
n Tool service must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified personnel may result in a risk of injury.
n Do not place battery tools or their batteries near
fire or heat. This will reduce the risk of explosion and
possibly injury.
n Never use a battery that has been dropped or
received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or dam-
aged battery immediately.
n Batteries vent hydrogen gas and can explode in
the presence of a source of ignition, such as a pilot
light. To reduce the risk of serious personal injury,
never use any cordless product in the presence of
open flame. An exploded battery can propel debris and
chemicals. If exposed, flush with water immediately.
n Do not charge battery tool in a damp or wet
location. Following this rule will reduce the risk of
electric shock.
n For best results, your battery tool should be
charged in a location where the temperature is
more than 50°F but less than 100°F. Do not store
outside or in vehicles.
n Under extreme usage or temperature condi-
tions, battery leakage may occur. If liquid comes
in contact with your skin, wash immediately with
soap and water, then neutralize with lemon juice
or vinegar. If liquid gets into your eyes, flush them
with clean water for at least 10 minutes, then seek
immediate medical attention. Following this rule will
reduce the risk of serious personal injury.
n When servicing a tool, use only identical replace-
ment parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or
failure to follow Maintenance Instructions may create a
risk of shock or injury.
SPECIFIC SAFETY RULES

4 5
WARNING! READ AND UNDERSTAND ALL
INSTRUCTIONS. Failure to follow all instructions
listed below, may result in electric shock, fire
and/or serious personal injury.
n Before using battery charger, read all instructions
and cautionary markings in this manual, on battery
charger, battery, and product using battery to prevent
misuse of the products and possible injury or damage.
CAUTION: To reduce the risk of electric shock or
damage to the charger and battery, charge only
nickel-cadmium rechargeable batteries as specifi-
cally designated on your charger. Other types of
batteries may burst, causing personal injury or
damage.
n Do not use charger outdoors or expose to wet or
damp conditions. Water entering charger will increase
the risk of electric shock.
n Use of an attachment not recommended or sold
by the battery charger manufacturer may result in
a risk of fire, electric shock, or injury to persons.
Following this rule will reduce the risk of electric shock,
fire, or serious personal injury.
n Do not abuse cord or charger. Never use the cord to
carry the charger. Do not pull the charger cord rather
than the plug when disconnecting from receptacle.
Damage to the cord or charger could occur and create
an electric shock hazard. Replace damaged cords im-
mediately.
n Make sure cord is located so that it will not be
stepped on, tripped over, come in contact with
sharp edges or moving parts or otherwise subject-
ed to damage or stress. This will reduce the risk of
accidental falls, which could cause injury, and damage
to the cord, which could result in electric shock.
n Keep cord and charger from heat to prevent
damage to housing or internal parts.
n Do not let gasoline, oils, petroleum-based products,
etc. come in contact with plastic parts. They contain
chemicals that can damage, weaken, or destroy plastic.
n An extension cord should not be used unless
absolutely necessary. Use of improper extension cord
could result in a risk of fire and electric shock. If
extension cord must be used, make sure:
a. That pins on plug of extension cord are the
same number, size and shape as those of
plug on charger.
b. That extension cord is properly wired and in
good electrical condition; and
c. That wire size is large enough for AC ampere
rating of charger as specified below:
Cord Length (Feet) 25’ 50’ 100’
Cord Size (AWG) 16 16 16
NOTE: AWG = American Wire Gauge
n Do not operate charger with a damaged cord or
plug, which could cause shorting and electric shock. If
damaged, have the charger replaced by an authorized
serviceman.
n Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in any
way. Take it to an authorized serviceman for electrical
check to determine if the charger is in good working
order.
n Do not disassemble charger. Take it to an authorized
serviceman when service or repair is required. Incor-
rect reassembly may result in a risk of electric shock or
fire.
n Unplug charger from outlet before attempting any
maintenance or cleaning to reduce the risk of
electric shock.
n Disconnect charger from the power supply when
not in use. This will reduce the risk of electric shock
or damage to the charger if metal items should fall into
the opening. It also will help prevent damage to the
charger during a power surge.
n Risk of electric shock. Do not touch uninsulated
portion of output connector or uninsulated battery
terminal.
n Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If
you loan someone this tool, loan them these instruc-
tions also to prevent misuse of the product and
possible injury.
WARNING: Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure
to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust
masks that are specially designed to filter out microscopic particles.
SAFETY RULES FOR CHARGER

6 7
SYMBOLS
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the tool better and safer.
Read The Operator’s Manual
Safety Alert
No Hands Symbol
No Hands Symbol
No Hands Symbol
No Hands Symbol
SYMBOL NAME DESIGNATION/EXPLANATION
Voltage
Current
Frequency (cycles per second)
Power
Time
Type of current
Type or a characteristic of current
Rotational speed, at no load
Double-insulated construction
Revolutions, strokes, surface speed, orbits etc., per minute
Do not expose to rain or use in damp locations.
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye Protection Always wear safety goggles or safety glasses with side
shields and a full face shield when operating this product.
Precautions that involve your safety.
Failure to keep your hands away from the blade will result in
serious personal injury.
Failure to keep your hands away from the blade will result in
serious personal injury.
Failure to keep your hands away from the blade will result in
serious personal injury.
Failure to keep your hands away from the blade will result in
serious personal injury.
Wet Conditions Alert
.../min Per Minute
Class II Construction
n
o
No Load Speed
Direct Current
Alternating Current
min Minutes
W Watt
Hz Hertz
A Amperes
V Volts
Hot Surface To reduce the risk of injury or damage, avoid contact with
any hot surface.

6 7
SYMBOLS
SERVICE
Servicing requires extreme care and knowledge and
should be performed only by a qualified service tech-
nician. For service we suggest you return the product to
your nearest AUTHORIZED SERVICE CENTER for
repair. When servicing, use only identical replacement
parts.
WARNING: To avoid serious personal injury,
do not attempt to use this product until you read
thoroughly and understand completely the
operator’s manual. Save this operator’s manual
and review frequently for continuing safe opera-
tion and instructing others who may use this
product.
The operation of any power tool can result in foreign objects being thrown into your eyes, which
can result in severe eye damage. Before beginning power tool operation, always wear safety
goggles or safety glasses with side shields and a full face shield when needed. We
recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side
shields. Always use eye protection which is marked to comply with ANSI Z87.1.
WARNING:
SAVE THESE INSTRUCTIONS
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
The following signal words and meanings are intended to explain the levels of risk associated with this product.

8 9
FEATURES
MODEL NO. 315.101811
Chuck ............................................ 3/8 in. (10 mm) Keyless
Motor................................................................ 9.6 Volt DC
Switch......................................................... Variable Speed
Gear Train .............................................................. 1 Speed
No Load Speed ................................................. 0-550/min.
Clutch ................................................................4 Positions
Charger Input ...................................120 V, 60 Hz, AC only
Charge Rate ........................................................3-6 Hours
Torque.................................................... Maximum 70 in.lb.
MODEL NO. 315.101821
Chuck ............................................ 3/8 in. (10 mm) Keyless
Motor................................................................. 12 Volt DC
Switch......................................................... Variable Speed
Gear Train .............................................................. 1 Speed
No Load Speed ................................................. 0-550/min.
Clutch ................................................................4 Positions
Charger Input ...................................120 V, 60 Hz, AC only
Charge Rate ........................................................3-6 Hours
Torque.................................................... Maximum 80 in.lb.
3
Fig. 1
SWITCH
TRIGGER
BIT
STORAGE
CHARGER
ASSEMBLY
KEYLESS
CHUCK
TORQUE
ADJUSTMENT RING
DIRECTION OF
ROTATION SELECTOR
(FORWARD / REVERSE)
BATTERY PACK

8 9
FEATURES
KNOW YOUR DRILL-DRIVER
See Figure 1.
Before attempting to use this product, familiarize
yourself with all operating features and safety
rules.
KEYLESS CHUCK
The drill-driver has a keyless chuck that allows you to
hand tighten or release drill bit in the chuck jaws.
SWITCH
To turn the drill-driver ON, depress the switch trigger.
Release switch trigger to turn the drill-driver OFF.
SWITCH LOCK
The switch trigger can be locked in the OFF position. This
feature helps reduce the possibility of accidental starting
when not in use.
VARIABLE SPEED
This tool has a variable speed switch that delivers higher
speed with increased trigger pressure. Speed is controlled
by the amount of switch trigger depression.
FORWARD/REVERSE SELECTOR
(DIRECTION OF ROTATION SELECTOR)
The drill-driver has a forward/reverse selector located
above the switch trigger.
BIT STORAGE
When not in use, bits provided with the drill-driver can be
placed in the storage area located on the top of the motor
housing.

10 11
UNPACKING
This product has been shipped completely assembled.
n Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list
are included.
n Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
n Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.
n If any parts are damaged or missing, please call
1-800-932-3188 for assistance.
PACKING LIST
3/8 in. (10 mm) Drill-Driver
Double-ended Bits (2)
Charging Assembly
Battery Pack
Case
Operator’s Manual
ASSEMBLY
WARNING: If any parts are missing do not operate
this tool until the missing parts are replaced. Failure
to do so could result in possible serious personal
injury.
WARNING: Do not attempt to modify this tool
or create accessories not recommended for use
with this tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING: To prevent accidental starting that
could cause serious personal injury, always remove
the battery pack from the tool when assembling
parts.

10 11
OPERATION
WARNING: Do not allow familiarity with tools to
make you careless. Remember that a careless
fraction of a second is sufficient to inflict serious
injury.
WARNING: Always wear safety goggles or safety
glasses with side shields when operating tools.
Failure to do so could result in objects being thrown
into your eyes, resulting in possible serious injury.
WARNING: Do not use any attachments or acces-
sories not recommended by the manufacturer of
this tool. The use of attachments or accessories not
recommended can result in serious personal injury.
APPLICATIONS
You may use this tool for the following purposes:
n Drilling in wood
n Drilling in ceramics, plastics, fiberglass, and laminates
n Drilling in both hard and soft metals
n Using driving accessories, such as driving screws with
screwdriver bits
n Mixing paints
CAUTION: To prevent damage to the battery pack,
remove the battery pack from the charger immedi-
ately if no LED comes on. Return the battery pack
and charger to your nearest service center for check-
ing or replacing. Also, if you are removing the battery
pack from the charger and no LEDs are on, return
both the battery pack and the charger to your near-
est service center. Do not insert another battery pack
into the charger. A damaged charger may damage a
battery pack.
CHARGING THE BATTERY PACK
See Figure 2.
The battery pack for this tool has been shipped in a low
charge condition to prevent possible problems. Therefore,
you should charge overnight prior to use.
NOTE: Batteries will not reach full charge the first time
they are charged. Allow several cycles (operation followed
by recharging) for them to become fully charged.
n Charge battery pack only with the charging assembly
provided.
n Make sure power supply is normal household voltage,
120 volts, 60 Hz, AC only.
n Connect charger to power supply.
n Place battery pack in charging stand. Align raised rib
on battery pack with groove in charging stand.
n Press down on battery pack to be sure contacts on
battery pack engage properly with contacts in charging
stand.
n The charge indicator light (LED), located on the charg-
ing stand, will light up red and glow when the charger
is properly connected to power supply. This light
indicates the charger is operating properly. It will
remain on until battery pack is removed from charging
stand or charger is disconnected from power supply.
NOTE: If charger does not charge battery pack, return
battery pack and charging assembly to your nearest
Sears Repair Center for electrical check.
n After normal usage, 3 hours or less of charging time is
required to fully recharge battery pack.
NOTE: If battery pack is completely discharged,
6 hours or longer of charging time is required to fully
recharge battery pack.
n The battery pack will become slightly warm to the
touch while charging. This is normal and does not
indicate a problem.
n Do not place charger in an area of extreme heat or
cold. It will work best at normal room temperature.
n When batteries become fully charged, unplug charger
from power supply and remove the battery pack.
CHARGING A HOT BATTERY PACK
When using the tool continuously, the batteries in your
battery pack will become hot. You should let a hot battery
pack cool down for approximately 30 minutes before
attempting to recharge.
NOTE: This situation only occurs when continuous use of
the drill causes the batteries to become hot. It does not
occur under normal circumstances. Refer to “CHARGING
THE BATTERY PACK” for normal recharging of batteries.
If the charging assembly does not charge your battery
pack under normal circumstances, return both the battery
pack and charging assembly to your nearest Sears Repair
Center for electrical check.
Fig. 2
CHARGING
ASSEMBLY
BATTERY
PACK
CHARGE
INDICATOR
LIGHT (LED)

12 13
OPERATION
TO INSTALL BATTERY PACK
See Figures 3 - 4.
n Lock switch trigger on the drill by placing the direction
of rotation selector in center position.
n Place the battery pack in the drill. Align raised rib on
battery pack with groove in drill's battery port.
n Make sure the latches on each side of the battery pack
snap in place and that battery pack is secured in drill
before beginning operation.
CAUTION: When placing battery pack in the tool,
be sure raised rib on battery pack aligns with the
bottom of the drill and latches into place properly.
Improper installation of the battery pack can cause
damage to internal components.
TO REMOVE BATTERY PACK
See Figures 3 - 4.
n Lock switch trigger on the drill by placing the direction
of rotation selector in center position.
n Locate latches on side of battery pack and depress both
sides to release battery pack from the drill.
n Remove battery pack from the drill.
3
Fig. 3
SWITCH TRIGGER
Fig. 4
DEPRESS LATCHES TO RELEASE
BATTERY PACK
LATCHES
BATTERY PACK
BATTERY PORT
DIRECTION OF ROTATION SELECTOR
(FORWARD / REVERSE / CENTER LOCK)

12 13
RELEASE
(UNLOCK)
3
3
OPERATION
WARNING: Battery tools are always in operating
condition. Therefore, switch should always be locked
when not in use or when carrying at your side.
SWITCH
See Figure 5.
The drill starts and stops by depressing and releasing the
switch trigger. Release the switch trigger to turn drill OFF.
VARIABLE SPEED
See Figure 5.
The drill has a variable speed feature in the switch. The
switch delivers higher speed and torque with increased
trigger pressure. Speed is controlled by the amount of
switch trigger depression.
SWITCH LOCK
See Figure 5.
The switch trigger can be locked in the OFF position. This
feature helps reduce the possibility of accidental starting
when not in use. To lock the switch trigger, place the
direction of rotation selector in the center position.
REVERSIBLE
See Figure 5.
This tool is reversible. The direction of rotation is con-
trolled by a selector located above the switch trigger. With
the drill held in normal operating position, the direction
of rotation selector should be positioned to the left of the
switch for drilling. The drilling direction is reversed when
the selector is to the right of the switch. When the selector
is in center position, the switch trigger is locked.
CAUTION: To prevent gear damage, always allow
chuck to come to a complete stop before changing
the direction of rotation.
To stop, release switch trigger and allow the chuck to
come to a complete stop.
SWITCH TRIGGER
FORWARD
Fig. 5
Fig. 6
GRIP
(TIGHTEN)
CHUCK BODY
KEYLESS CHUCK
See Figure 6.
A keyless chuck has been provided with the drill to allow
for easy installation and removal of bits. As the name
implies, you can hand tighten or release drill bits in the
chuck jaws. Grasp and hold the collar of the chuck with
one hand. Rotate the chuck body with your other hand.
The arrows on the chuck indicate which direction to rotate
the chuck body in order to GRIP (tighten) or RELEASE
(unlock) the drill bit.
WARNING: Do not hold the chuck body with one
hand and use the power of the drill to tighten chuck
jaws on drill bits. Chuck body could slip in your
hand or your hand could slip and come in contact
with rotating drill bit. This could cause an accident
resulting in serious personal injury.
REVERSE
DIRECTION OF ROTATION SELECTOR
(FORWARD / REVERSE / CENTER LOCK)
BIT
CHUCK COLLAR

14 15
OPERATION
Fig. 8
INSTALLING BITS
See Figures 7 - 8.
WARNING: Make sure to insert the drill bit straight
into the chuck jaws. Do not insert the drill bit into
the chuck jaws at an angle then tighten, as shown in
figure 8. This could cause the drill bit to be thrown
from the drill, resulting in possible serious personal
injury or damage to the chuck.
n Place the direction of rotation selector in center posi-
tion. This will turn off the power to the drill.
3
n Open or close the chuck jaws to a point where the
opening is slightly larger than the bit size you intend to
use. Also, raise the front of the drill slightly to keep the
bit from falling out of the chuck jaws.
n Insert the drill bit into the chuck the full length of the
jaws.
n Tighten the chuck jaws on the drill bit. To tighten, grasp
and hold the collar of the chuck with one hand, while
rotating the chuck body with your other hand.
NOTE: Rotate the chuck body in the direction of the
arrow marked GRIP to tighten the chuck jaws. DO
NOT use a wrench to tighten or loosen the chuck jaws.
RELEASE
(UNLOCK)
3
Fig. 7
GRIP
(TIGHTEN)
CHUCK BODY
CHUCK COLLAR
BIT
REMOVING BITS
See Figure 7.
n Place the direction of rotation selector in center
position. This will turn off the power to the drill.
n Loosen the chuck jaws from drill bit by grasping
and holding the collar of the chuck with one hand,
while rotating chuck body with your other hand.
NOTE: Rotate chuck body in the direction of the arrow
marked RELEASE to loosen chuck jaws.
n DO NOT use a wrench to tighten or loosen the chuck
jaws.
n Remove drill bit from chuck jaws.
WRONG

14 15
3
OPERATION
SCREWDRIVING TORQUE ADJUSTMENT
(Driving power of the drill-driver)
See Figure 9.
When using the drill-driver for various driving applications,
it becomes necessary to increase or decrease the torque
in order to help prevent the possibility of damaging screw
heads, threads, workpiece, etc. In general, torque should
correspond to the intensity of the screw diameter. If the
torque is too high or the screws too small, the screws may
be damaged or broken.
The torque is adjusted by rotating the torque adjustment
ring. The torque is greater when the torque adjustment
ring is set on a higher setting. The torque is less when the
torque adjustment ring is set on a lower setting.
The proper setting depends on the type of material and
the size of screw you are using.
TO ADJUST TORQUE
See Figure 9.
n Identify the four torque indicator settings located on
the front of the drill.
n Rotate adjustment ring to the desired setting.
• Position 1: For driving small screws
• Position 2: For driving screws into soft material
• Position 3: For driving screws into hard wood
• For heavy drilling
Fig. 10
BIT
STORAGE
AREA
SCREWDRIVER
BITS
3
Fig. 9
TO DECREASE
TORQUE
TO INCREASE
TORQUE
TORQUE
ADJUSTMENT RING
BIT STORAGE
See Figure 10.
When not in use, bits provided with the drill can be placed
in the storage area located on the top of the drill as shown
in figure 10.
BIT
STORAGE
AREA

16 17
3
OPERATION
DRILLING
See Figure 11.
When drilling hard, smooth surfaces, use a center punch
to mark the desired hole location. This will prevent the drill
bit from slipping off center as the hole is started. However,
the lower speed feature allows starting holes without cen-
ter punching if desired. To accomplish this, simply operate
the drill at lower speed until the hole is started.
The material to be drilled should be secured in a vise or
with clamps to keep it from turning as the drill bit rotates.
Hold tool firmly and place the bit at the point to be drilled.
Depress the switch trigger to start tool.
Move the drill bit into the workpiece, applying only
enough pressure to keep the bit cutting. Do not force or
apply side pressure to elongate a hole.
WARNING: Be prepared for binding at bit
breakthrough. When these situations occur, the drill
has a tendency to grab and kick opposite to the
direction of rotation and could cause loss of control
when breaking through material. If you are not
prepared, this loss of control can result in possible
serious injury.
When drilling metals, use a light oil on the drill bit to keep
it from overheating. The oil will prolong the life of the bit
and increase the drilling action.
If the bit jams in workpiece or if the drill stalls, release
switch trigger immediately. Remove the bit from the work-
piece and determine the reason for jamming. Fig. 11

16 17
3
MAINTENANCE
Fig. 13
CHUCK REMOVAL
See Figures 12 - 14.
n Lock the switch trigger by placing the direction of
rotation selector in center position.
n Insert a 5/16 in. or larger hex key into the chuck of the
drill and tighten the chuck jaws securely.
n Tap the hex key sharply with a mallet in a clockwise
direction. This will loosen the screw in the chuck for
easy removal.
n Open chuck jaws and remove hex key. Remove the
chuck screw by turning it in a clockwise direction.
NOTE: The screw has left hand threads.
n Insert hex key in chuck and tighten chuck
jaws securely. Tap sharply with a mallet in a
counterclockwise direction. This will loosen chuck on
the spindle. It can now be unscrewed by hand.
MALLET
KEYLESS
CHUCK
CHUCK JAWS
HEX KEY
Fig. 12
3
SCREWDRIVER
WARNING: When servicing, use only identical
Sears replacement parts. Use of any other part may
create a hazard or cause product damage.
WARNING: Always wear safety goggles or safety
glasses with side shields when using compressed air
to clean tools. If the operation is dusty, also wear a
dust mask.
WARNING: To avoid serious personal injury, always
remove the battery pack from the tool when cleaning
or performing any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids,
gasoline, petroleum-based products, penetrating
oils, etc. come in contact with plastic parts. Chemi-
cals can damage, weaken or destroy plastic which
may result in serious personal injury.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts
should be replaced at a Sears Service Center.

18 19
MAINTENANCE
BATTERIES
The battery pack for this tool is equipped with nickel-
cadmium rechargeable batteries. Length of service from
each charging will depend on the type of work you are
doing.
The batteries in this tool have been designed to provide
maximum trouble-free life. However, like all batteries, they
will eventually wear out. Do not disassemble battery pack
and attempt to replace the batteries. Handling of these
batteries, especially when wearing rings and jewelry, could
result in a serious burn.
To obtain the longest possible battery life, we suggest the
following:
n Remove the battery pack from the charger once it is
fully charged and ready for use.
For battery pack storage longer than 30 days:
n Store the battery pack where the temperature is below
80°F.
BATTERY PACK REMOVAL AND
PREPARATION FOR RECYCLING
To preserve natural resources, please
recycle or dispose of batteries
properly.
This product contains nickel-cadmium
batteries. Local, state or federal
laws may prohibit disposal of nickel-
cadmium batteries in ordinary trash.
Consult your local waste authority for information
regarding available recycling and/or disposal options.
WARNING: Upon removal, cover the battery pack’s
terminals with heavy-duty adhesive tape. Do not
attempt to destroy or disassemble battery pack or
remove any of its components. Nickel-cadmium
batteries must be recycled or disposed of properly.
Also, never touch both terminals with metal objects
and/or body parts as short circuit may result. Keep
away from children. Failure to comply with these
warnings could result in fire and/or serious injury.
Fig. 14
TO RETIGHTEN A LOOSE CHUCK
See Figure 12.
The chuck may become loose on spindle and develop a
wobble. Periodically check the chuck screw for tightness.
To tighten:
n Lock the switch trigger by placing the direction of
rotation selector in center position.
n Open the chuck jaws.
n Insert hex key into chuck and tighten chuck jaws
securely. Tap hex key sharply with a mallet in a
clockwise direction. This will tighten chuck on the
spindle.
n Open the chuck jaws and remove hex key.
n Tighten the chuck screw.
NOTE: The chuck screw has left hand threads.
3
MALLET
KEYLESS CHUCK
CHUCK JAWS
HEX KEY

18 19
COMPANION 9.6 AND 12 VOLT CORDLESS DRILL
MODEL NOS. 315.101811 AND 315.101821
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your CORDLESS DRILL-DRIVER or when ordering repair parts.
PARTS LIST
Key Part
No. Number Description Qty.
1 660120003 Screw....................................................................................................... 1
2 690033036 Chuck ...................................................................................................... 1
3 130122043 Battery pack (315.101811) ...................................................................... 1
130122044 Battery pack (315.101821) ...................................................................... 1
4 140209025 Charger (315.101811) .............................................................................. 1
140209026 Charger (315.101821) ............................................................................. 1
580013020 Carrying Case (not shown) ...................................................................... 1
983000-492 Operator’s Manual
