Installing an External Cache Battery (ECB)
The HSZ70, the HSG80, and the HSZ80 all use the same ECB. This document contains instructions to replace an ECB in an HSZ70
HSOF Version 7.x Array Controller, the HSG80 ACS Version8.x Array Controller, and the HSZ80 ACSVersion 8.x Array Controller. See
the appropriate
HSZ70 Array Controller HSOF Version7.x Service Manual , HSG80 Array Controller ACS Version 8.x User’s Guide ,
HSZ80 Array Controller ACS Version 8.x User’s Guide , HSG80 Array Controller ACS Version 8.3 Maintenance and Service Guide, or
HSZ80 ACS Version 8.3 Maintenance and ServiceGuide
for instructions on upgrading a single-controller configuration to a
dual-redundant controller configuration.
Replacing an External Cache Battery Storage
Building Block
Use this procedure for the following configurations:
HSZ70 HSOF Version 7.x Dual-Redundant Controller
HSG80 ACS Version 8.0 Dual-Redundant Controller
HSZ80 ACS Version 8.1 Dual-Redundant Controller
Use the following steps to replace an external cache battery
(ECB) storage building block (SBB) (see Figure 1):
Figure 1. ECB for Dual-Redundant Controller Configurations
CAUTION: Do not disconnect the old ECB until the batteries in
the new ECB are fully charged.
NOTE: This procedure assumes that a single ECB SBB with a
dual battery is installed and an empty slotis available for the
replacement ECB SBB. If an empty slot is not available, place
the new ECBSBBonthetopofthe enclosure.After theold ECB
SBB has been removed, carefully insert the new ECB SBB into
the empty slot.
1. Connect a PC or terminal to the controller with the
operational ECB. The controller to which you’re connected
is “this controller”; the controller whose ECB you’re
replacing is the “other controller.”
2. Disable failover with the following command:
SET NOFAILOVER
3. [HSZ70 and HSZ80] Start FRUTIL with the following
command:
RUN FRUTIL
4. [HSZ70] Enter option 3, Replace other cache module
battery, from the FRUTIL Main menu:
FRUTIL Main Menu:
1. Replace or remove a controller or cache module
2. Install a controller or cache module
3. Replace other cache module battery
4. Replace a PVA module
5. Replace an I/O module
6. Exit
Enter choice: 1, 2, 3, 4, 5, or 6 -> 3
5. [HSZ80] Enter option 3, Replace other cache module
battery, from the FRUTIL Main menu:
FRUTIL Main Menu:
1. Replace or remove a controller or cache module
2. Install a controller or cache module
3. Replace other cache module battery
4. Replace a PVA module
5. Replace an I/O module
6. Set battery life to new
7. Exit
Enter choice: 1, 2, 3, 4, 5, 6, or 7 -> 3
1 Shut off button
2 Status LED
3ECBYcable
4 Faceplate and controls for second
battery
CACHE
POWER
STATUS
SHUT OFF
CACHE
POWER
STATUS
SHUT OFF
3
~
4
2
1

2
6. [HSZ70 and HSZ80] Confirm that you have a new dual-
battery replacement ECB SBB. FRUTIL displays the
following:
Do you have a NEW replacement battery? Y/N
7. [HSZ70 and HSZ80] Enter Y(es) and press return.
NOTE: If an empty slot is not available, place the new ECB SBB
on the top of the enclosure.
8. [HSZ70 and HSZ80] Confirm that you want to install a
replacement ECB SBB. FRUTIL displays the following:
Replace the battery for the cache module in slot A
[
or B ]? Y/N
9. [HSZ70 and HSZ80] Enter Y(es) and press return.
10. [HSG80] Shut down the controllers. First shut down the
“other controller,” then shut down “this controller” with the
following commands:
SHUTDOWN OTHER_CONTROLLER
SHUTDOWN THIS_CONTROLLER
When the controllers shut down, their reset buttons and first
three LEDs are lit continuously.
11. [HSG80] Turn off the power to the subsystem.
12. Insert the new ECB SBB into an empty slot.
CAUTION: The ECB cable has a 12-volt and a 5-volt pin.
Improper handling or misalignment when connecting or
disconnecting could cause these pins to contact ground,
resulting in cache module damage.
13. [HSG80] Restore power to the subsystem. The controllers
automatically restart.
14. Connect the open end of the ECB Y cable to the new ECB.
CAUTION: Do not disconnect the old ECB until the batteries in
the new ECB are fully charged. The new ECB’s status light will
be lit continuously to indicate that its batteries are fully charged.
A blinking status light indicates that its batteries are charging.
You may operate the subsystem regardless of the old ECB’s
status.
15. Wait until the new ECB’s status light is on continuously,
then disconnect the ECB cable from the old ECB.
[HSZ80] FRUTIL displays the following:
Setting battery A [ or B ] state to new.
Testing battery attached to cache module A [
or B ].
Test complete. Battery is good.
16. [HSZ80] Wait for FRUTIL to terminate.
17. Enable failover, and re-establish the dual-redundant
configuration with the following command:
SET FAILOVER COPY=THIS_CONTROLLER
This command copies the subsystem’s configuration from
“this controller” to the “other controller.”
18. Disconnect the PC or terminal from the controller.
19. To connect the other cache module to the new ECB SBB,
repeat the appropriate steps for the remaining controller and
its cache module.
20. Remove the old ECB SBB.
NOTE: If an empty slot was not available, and the new ECB SBB
was placed on the topof the enclosure, carefully insert it now
into the empty slot.

3EK–80ECB–IN. C01/388622-001
Replacing an External Cache Battery Storage
Building Block
Use this procedure for the following configurations:
HSZ70 HSOF Version 7.x Single Controller
HSG80 ACS Version 8.0 Single Controller
HSZ80 ACS Version 8.1 Single Controller
Use the following steps to remove and replace an ECB SBB (see
Figure 2):
Figure 2. ECB for Single-Controller Configurations
CAUTION: Do not disconnect the old ECB until the batteries in
the new ECB are fully charged.
1. If the controller and cache module are not operating, go to
step 4. Otherwise, go to the next step.
2. Connect a PC or terminal to the controller’s maintenance
port.
3. Shut down the controller the following command:
SHUTDOWN THIS_CONTROLLER
When the controller shuts down, its reset button and first
three LEDs are lit continuously.
4. Turn off the power to the subsystem.
5. Insert the new ECB SBB into its slot.
CAUTION: The ECB cable has a 12-volt and a 5-volt pin.
Improper handling or misalignment when connecting or
disconnecting could cause these pins to contact ground,
resulting in cache module damage.
6. Connect the open end of the ECB Y cable to the new ECB.
7. Restore power to the subsystem. The controller
automatically restarts.
CAUTION: Do not disconnect the old ECB until the batteries in
the new ECB are fully charged. The new ECB’s status light will
be lit continuously to indicate that its batteries are fully charged.
A blinking status light indicates that its batteries are charging.
You may operate the subsystem regardless of the old ECB’s
battery status, but do not disconnect the old ECB until the
batteries in the new ECB are fully charged.
8. Wait until the new ECB’s status light is on continuously,
then disconnect the ECB cable from the old ECB.
9. [HSZ80] Start FRUTIL with the following command:
RUN FRUTIL
10. [HSZ80] An internal clock monitors the life of the battery.
When replacing a battery this clock must be reset. Choose
option 6, Set battery life to new, from the FRUTIL Main
menu to reset the internal clock.
FRUTIL Main Menu:
1. Replace or remove a controller or cache module
2. Install a controller or cache module
3. Replace other cache module battery
4. Replace a PVA module
5. Replace an I/O module
6. Set battery life to new
7. Exit
Enter choice: 1, 2, 3, 4, 5, 6, or 7 -> 6
11. [HSZ80] Choose option 1, Battery attached to cache module
A, from the Battery Replacement menu:
Which battery was replaced while powered off?
1. Battery attached to cache module A
2. Battery attached to cache module B
3. Both batteries
4. Exit
Enter choice: 1, 2, 3, or 4 -> 1
FRUTIL displays the following:
Setting battery A state to new.
Testing battery attached to cache module A.
Test complete. Battery is good.
12. [HSZ80] Wait for FRUTIL to terminate.
13. Remove the old ECB SBB.
1 Shut off button
2 Status LED
3ECBYcable
CACHE
POWER
STATUS
SHUT OFF
1
3
~
2

4
Replacing an External Cache Battery Storage
Building Block
Use this procedure for the following configurations:
HSG80 ACS Version 8.2 Single Controller
HSG80 ACS Version 8.2 Dual-Redundant Controller
HSG80 ACS Version 8.3 Single Controller
HSG80 ACS Version 8.3 Dual-Redundant Controller
HSZ80 ACS Version 8.2 Single Controller
HSZ80 ACS Version 8.2 Dual-Redundant Controller
HSZ80 ACS Version 8.3 Single Controller
HSZ80 ACS Version 8.3 Dual-Redundant Controller
The ECB SBB can be replaced with cabinet power on or off. A
single-battery ECB SBB is shown in Figure 2 and a dual-battery
ECB SBB is shown in Figure 1.
Replacing an External Cache Battery Storage Building Block with
Cabinet Power On
Use the following steps to replace the ECB SBB with the cabinet
powered on:
NOTE: The procedure for a dual-redundant controller
configuration assumes that a single ECB SBB with a dual battery
is installed and an empty slot is available for the replacement
ECBSBB. If an empty slot is not available, place the new ECB
SBB on the top of the enclosure. After the old ECB SBB has been
removed, carefully insert the new ECB SBB into the empty slot.
1. Connect a PC or terminal to the controller with the ECB
SBB that you intend to replaced. The controller to which
you’re connected is “this controller.”
2. Start FRUTIL with the following command:
RUN FRUTIL
FRUTIL displays the following:
Do you intend to replace this controller’s cache
battery? Y/N
3. Enter Y(es). FRUTIL displays the following:
If the batteries were replaced while the cabinet was
powered down, press return.
Otherwise follow this procedure:
WARNING:Ensure that at least one battery is
connected to the Y cable at all times
during this procedure.
1.Connect the new battery to the unused end
of the 'Y' cable attached to cache A [
or B ].
2.Disconnect the old battery. Do not wait for the
new battery's status light to turn solid green.
3.Press return.
CAUTION: The ECB cable has a 12-volt and a 5-volt pin.
Improper handling or misalignment when connecting or
disconnecting could cause these pins to contact ground,
resulting in cache module damage.
4. Insert the new ECB SBB into the empty battery slot.
NOTE: If an empty slot is not available, placethe new ECB SBB
on the top ofthe enclosure.
5. Connect the new battery to the unused end of the Y cable
attached to the cache module.
6. Disconnect the old battery. Do not wait for the new battery’s
status light to turn solid green.
7. Press return.
FRUTIL displays the following:
Updating this battery's expiration date and deep
discharge history.
Field Replacement Utility terminated.
8. Disconnect the PC or terminal from the controller’s
maintenance port.
9. If this is a dual-redundant controller configuration and you
installed a dual-battery ECB SBB and you want to connect
the othercache module to the new ECB SBB, connect the PC
or terminal to the other controller’s maintenance port. The
controller to which you’re now connected is “this controller.”
10. Repeat steps 2 through 8.
11. Remove the old ECB SBB.
NOTE: If an empty slot was not available, and the new ECB SBB
was placed on the topof the enclosure, carefully insert it now
into the empty slot.
Replacing an External Cache Battery Storage Building Block with
Cabinet Power Off
Use the following steps to replace the ECB SBB with the cabinet
powered off:
1. If the controller and cache module are not operating, go to
step 4. Otherwise, go to the next step.
2. Connect a PC or terminal to the controller’s maintenance
port. The controller to which you’re connected is “this
controller.”
3. Shut down the controllers. In single controller
configurations, shut down “this controller.” In dual-
redundant controller configurations, shut down the “other
controller” first, then shut down “this controller” with the
following commands:
SHUTDOWN OTHER_CONTROLLER
SHUTDOWN THIS_CONTROLLER
When the controllers shut down, their reset buttons and their
first three LEDs are lit continuously. This may take several
minutes, depending on the amount of data that needs to be
flushed from the cache modules.
4. Turn off the power to the subsystem.
5. Insert the new ECB SBB into its slot.

5EK–80ECB–IN. C01/388622-001
CAUTION: The ECB cable has a 12-volt and a 5-volt pin.
Improper handling or misalignment when connecting or
disconnecting could cause these pins to contact ground,
resulting in cache module damage.
6. Connect the open end of the ECB Y cable to the new ECB.
7. Restore power to the subsystem. The controller
automatically restarts.
8. Disconnect the ECB cable from the old ECB.
9. Start FRUTIL with the following command:
RUN FRUTIL
FRUTIL displays the following:
Do you intend to replace this controller’s cache
battery? Y/N
10. Enter Y(es). FRUTIL displays the following:
If the batteries were replaced while the cabinet was
powered down, press return.
Otherwise follow this procedure:
WARNING:Ensure that at least one battery is
connected to the Y cable at all times
during this procedure.
1.Connect the new battery to the unused end
of the 'Y' cable attached to cache A [
or B ].
2.Disconnect the old battery. Do not wait for the
new battery's status light to turn solid green.
3.Press return.
11. Press return.
FRUTIL displays the following:
Updating this battery's expiration date and deep
discharge history.
Field Replacement Utility terminated.
12. Disconnect the PC or terminal from the controller’s
maintenance port.
13. In a dual-redundant controller configuration and if the ECB
was replaced for both cache modules, connect the PC or
terminal to the other controller’s maintenance port. The
controller to which you’re now connected is “this controller.”
14. Repeat steps 9 through 12.
15. Remove the old ECB SBB.
