Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins |
Product Description
Troubleshooting
Illustrated Parts
Removal & Replacement
Jumpers & Switches
Specifications
Connector Pins
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/ (1 of 2) [1/10/2002 11:55:24 AM]

Welcome to the Presario 5700 Series Maintenance and Service Guide. This online guide is designed to serve the needs of
those whose job it is to repair Compaq products. Many of the components of the hardcopy MSG are contained in this online
guide. The Notice contains the copyright and trademark information. The Preface shows symbol conventions, Technician Notes
and Serial Number locations on the unit.
Download a ZIP file of the complete MSG to local hard drive.
This MSG will be periodically maintained and updated as needed.
To report a technical problem, contact your Regional Support Center or IM Help Center.
For content comments or questions, contact the Editor.
Top
privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/ (2 of 2) [1/10/2002 11:55:24 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement
Jumpers & Switches | Specifications | Connector Pins | Power Cord Requirements
Symbols
The following words and symbols mark special messages throughout this guide.
WARNING: Text set off in this manner indicates that failure to follow directions in the warning could
result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions in the caution could result
in damage to equipment or loss of data.
IMPORTANT: Text set off in this manner presents clarifying information or
specific instructions.
NOTE: Text set off in this manner presents commentary, sidelights,
or interesting points of information.
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/preface.html (1 of 2) [1/10/2002 11:55:26 AM]

Technician Notes
WARNING: Only authorized technicians trained by Compaq should repair this equipment. All
troubleshooting and repair procedures are detailed to allow only subassembly/module level repair.
Because of the complexity of the individual boards and subassemblies, the user should not attempt to
make repairs at the component level or to make modifications to any printed circuit board. Improper
repairs can create a safety hazard. Any indications of component replacement or printed circuit board
modifications may void any warranty.
Serial Number
When requesting information or ordering spare parts, the computer serial number should be provided to Compaq. The
serial number can be found on the rear of the computer next to the fan grill and on the front bezel behind the drive
access door.
Locating Additional Information
The following documentation is available to support this product:
Compaq Presario documentation set● Introducing Windows 95 Guide● Service Training Guides● Compaq Service Advisories and Bulletins● Compaq QuickFind● Compaq Service Quick Reference Guide● Compaq Help Center●
privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/preface.html (2 of 2) [1/10/2002 11:55:26 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Models and Features
Controls and Lights Index
Power Management
Power Cord Requirements
Product Description
The Presario 5700 Series Internet PCs provide owners with the broadest array of choices
for high-speed access to the Internet. The new minitowers are equipped for the future
with an Industry-Standard Y2K Compliant design. Some models also provide Home
Phone line Networking that allows you to share simultaneous use of one Internet
account, printers, and more over your existing phone lines.
This section describes the model numbers and features of the Compaq Presario 5700
Series of personal computers.
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/pd.html (1 of 2) [1/10/2002 11:55:26 AM]

privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/pd.html (2 of 2) [1/10/2002 11:55:26 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Clearing CMOS
Power-On Self-Test (POST)
Diagnostic Error Codes
Troubleshooting Without Diagnostics
Troubleshooting
This section provides troubleshooting information for Compaq Presario
5700 Series Personal Computers. Power-On Self-Test (POST)
messages, diagnostic error codes, and memory error codes appear in
tables.
The message and code tables include a description of the error, the
probable cause, and the recommended action that should be taken to
resolve the error condition.
Adherence to the procedures and precautions described in this section
is essential for proper service.
privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/troubles1.html [1/10/2002 11:55:28 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Topics
System Unit
Mass Storage
Cables
Boards
Modems
Keyboards/Mouse
Monitors
Return Kits
Documentation
Illustrated Parts
This section provides illustrated parts and a reference for spare parts numbers
for Compaq Presario 5700 Series Personal Computers.
When requesting information or ordering spare parts, the computer serial
number should be provided to Compaq. The serial number is displayed on the
back of the chassis and behind the drive cover.
privacy and legal statement
Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/ipm.html [1/10/2002 11:55:29 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Disassembly
Sequence
Preparation for
Disassembly
Serial Number Location
Chassis
Mass Storage Devices
Button Board
Front I/O Cable
Creativity Action Center
Fan
Option Card Retainer
Graphics Board
Removal and Replacement
This chapter provides general service information for Compaq Presario 5700 Series Personal
Computers. Adherence to the procedures and precautions described in this chapter is
essential for proper service.
The topics discussed in this section include the following:
Electrostatic Discharge●
Generating Static●
Preventing Electrostatic Damage to Equipment●
Preventing Damage to Drives●
Grounding Methods●
Grounding Workstations●
Grounding Equipment●
Recommended Materials and Equipment●
Tool Requirements●
Screws●
Cables and Connectors●
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (1 of 7) [1/10/2002 11:55:29 AM]

Fax/Modem
Networking Interface Card
Memory
Processor
Processor Retention Clips
RTC Battery
System Board Cables
System Board
Parallel Port
Back I/O Panel
Power Supply
Electrostatic Discharge
A sudden discharge of static electricity from a finger or other conductor can destroy
static-sensitive devices or microcircuitry. Often the spark is neither felt nor heard, but
damage occurs. An electronic device exposed to electrostatic discharge (ESD) may not be
affected at all and will work perfectly throughout a normal cycle. Or it may function
normally for a while, then degrade in the internal layers, reducing its life expectancy.
Networks built into many integrated circuits provide some protection, but in many cases,
the discharge contains enough power to alter device parameters or melt silicon junctions.
Top
Generating Static
The accompanying table shows typical electrostatic voltages generated by different
activities.
Typical Electrostatic Voltages
Relative Humidity
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl floor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tubes 2,000 V 700 V 400 V
Removing DIPS from vinyl trays 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCBs 26,000 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
NOTE: 700 volts can degrade a product.
Top
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (2 of 7) [1/10/2002 11:55:29 AM]

Preventing Electrostatic Damage to Equipment
Many electronic components are sensitive to ESD. Circuitry design and structure determine
the degree of sensitivity. The following proper packaging and grounding precautions are
necessary to prevent damage:
Protect all electrostatic parts and assemblies with conductive or approved containers
or packaging.
●
Keep electrostatic sensitive parts in their containers until they arrive at static-free
stations.
●
Place items on a grounded surface before removing them from their
container.
●
Always be properly grounded when touching a sensitive component or assembly.● Place reusable electronic-sensitive parts from assemblies in protective packaging or
conductive foam.
●
Use transporters and conveyors made of antistatic belts and metal roller bushings.
Mechanized equipment used for moving materials must be wired to ground and
proper materials selected to avoid static charging. When grounding is not possible,
use an ionizer to dissipate electric charges.
●
The accompanying table shows typical static-shielding protection levels afforded by
different protective packaging materials.
Static-Shielding Protection Levels
Method Voltages
Antistatic Plastic 1,500
Carbon-Loaded Plastic 7,500
Metallized Laminate 15,000
Top
Preventing Damage to Drives
To prevent static damage to hard drives, use the following precautions:
Handle drives gently, using static-guarding techniques.● Store drives in the original shipping containers.● Avoid dropping drives from any height onto any surface.●
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (3 of 7) [1/10/2002 11:55:29 AM]

Handle drives on surfaces that have at least one inch of shock-proof foam.● Always place drives PCB assembly side down on the foam.●
Top
Grounding Methods
The method for grounding must include a wrist strap or a foot strap at a grounded
workstation. When seated, wear a wrist strap connected to a grounded system. When
standing, use footstraps and a grounded floor mat.
Top
Grounding Workstations
To prevent static damage at the workstation, use the following precautions:
Cover the workstation with approved static-dissipative material.● Provide a wrist strap connected to the work surface and properly grounded tools and
equipment.
●
Use static-dissipative mats, heel straps, or air ionizers to give added protection.● Handle electrostatic sensitive components, parts, and assemblies by the case or PCB
laminate. Handle them only at static-free workstations.
●
Avoid contact with pins, leads, or circuitry.● Turn off power and input signals before inserting and removing connectors or test
equipment.
●
Use fixtures made of static-safe materials when fixtures must directly contact
dissipative surfaces.
●
Keep work area free of nonconductive materials such as ordinary plastic assembly
aids and Styrofoam.
●
Use field service tools, such as cutters, screwdrivers, vacuums, that are conductive.● Use a portable field service kit with a static dissipative vinyl pouch that folds out of a
work mat. Also use a wrist strap and a ground cord for the work surface. Ground the
cord to the chassis of the equipment undergoing test or repair.
●
Top
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (4 of 7) [1/10/2002 11:55:29 AM]

Grounding Equipment
Use the following equipment to prevent static electricity damage to the equipment:
Wrist Straps are flexible straps with a minimum of 1 mega ohm +/- 10% resistance
to the ground cords. To provide proper ground, a strap must be worn snug against
the skin. On grounded mats without banana-plug connectors, connect a wrist strap
with alligator clips.
●
Heelstraps/Toestraps/Bootstraps can be used at standing workstations and are
compatible with most types of boots and shoes. On conductive floors or dissipative
floor mats, use them on both feet with a minimum of 1 mega ohm resistance between
operator and ground. To be effective, the conductive strips must be worn in contact
with the skin.
●
Top
Recommended Materials and Equipment
Other materials and equipment that are recommended for use in preventing static
electricity include:
Antistatic tape
● Antistatic smocks, aprons, or sleeve protectors● Conductive bins, and other assembly or soldering aids● Conductive foam● Conductive tabletop workstations with ground cord of 1 mega ohm
of resistance
●
Static dissipative table or floor mats with hard tie to ground● Field service kits● Static awareness labels● Wrist straps and footwear straps providing 1 mega ohm (+/- 10%) resistance● Material handling packages● Conductive plastic bags● Conductive plastic tubes● Conductive tote boxes● Metal tote boxes● Opaque shielding bags● Transparent metallized shielding bags●
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (5 of 7) [1/10/2002 11:55:29 AM]

Transparent shielding tubes●
Top
Tool Requirements
Torx T-8, T-10, and T-15 screwdrivers (included in kit number 130619-001)● Needle-nose pliers● Flat-bladed screwdriver● Diagnostics software●
Top
Screws
The screws used in these products are not interchangeable. If an incorrect screw is used
during the reassembly process, it could cause damage to the unit. Compaq strongly
recommends that all screws removed during the disassembly process be kept with the part
that was removed, then returned to their proper locations.
IMPORTANT: As each subassembly is removed from the computer, it should be
placed away from the work area to prevent damage
●
Top
Cables and Connectors
Most cables used throughout the unit are ribbon cables (Figures 4-1, 4-2, 4-3, 4-4, and
4-5). These cables must be handled with extreme care to avoid damage.
Apply only the tension required to seat or unseat the cables during insertion or removal
from the connector. Handle cables by the connector whenever possible. In all cases, avoid
bending, twisting, or tearing the cables, and ensure that cables are placed in such a way
that they cannot be caught or snagged by parts being removed or replaced.
The numbered cables show the recommended configuration for the ribbon cables. The
shaded lines indicate alternative configurations for additional optional hard drives, tape
drives, and diskette drives.
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (6 of 7) [1/10/2002 11:55:29 AM]

CAUTION: When servicing these computers, ensure that cables are
placed in their proper location during the reassembly process.
Improper cable placement can cause severe damage to the unit.
Top
privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/rr.html (7 of 7) [1/10/2002 11:55:29 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Click on a selection below for
jumper and switch
information.
Presario 5700 Models with
Celeron System Board
Presario 5700 Models with
AMD System Board
Presario 5700 Models with
Pentium III System Board
Mass Storage
3.5-inch Hard Drive
5.25-inch Hard Drive
DVD Drive
CD Drive
Jumper and Switch Information
This section contains jumper and switch information for system board jumpers, system
I/O board connectors, and Mass Storage drives.
privacy and legal statement
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/jumper.html [1/10/2002 11:55:29 AM]

United States
STORE | PRODUCTS | SERVICES | SUPPORT | CONTACT US | SEARCH
Maintenance & Service Guide
Presario 5700 Series Personal Computers
Models: 5710, 5711, 5712, 5714, 5715, 5716, 5717, 5718, 5721,
5722, 5724, 5726, 5728, 5733, 5735, 5736, 5738, 5745 and 5746
MSG Index | Home | Preface | Product Description | Troubleshooting | Illustrated Parts |
Removal & Replacement | Jumpers & Switches | Specifications | Connector Pins
Specifications
Compaq Presario 5700 Series Personal Computer specifications are listed in the following tables. Select the specification
you are interested in from the alphabetical list.
Mouse System Memory
Power Supply System Specifications
Diskette Drive System DMA Video Memory
IDE Hard Drives System I/O Zip Drive
Fax/Modem System Interrupts DVD Drive
System Specifications
U. S. Outside U. S.
Dimensions
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/spcific.html (1 of 5) [1/10/2002 11:55:30 AM]

Height 19.0 in 482.60 mm
Depth 20.9 in 530.86 mm
Width 8.38 in 212.73 mm
BTUs <178 BTUs/hour*
Weight 31 lb 14.09 kg
Shipping Weight
Gross 41 lb 18.64 kg
Average Net 31 lb 14.09 kg
Input Requirements
Nominal Line Voltage 100 to 120 VAC 220 to 240 VAC
Range Line Voltage 90 to 132 VAC 180 to 264 VAC
Line Frequency 47 to 63 Hz 47 to 63 Hz
Input Current 5.2 at 90 VAC 3.6 at 180 VAC
Power (watts)
Steady State 165 165
Environmental Requirements
Temperature
Operating 50° to 95° F 10° to 35° C
Shipping -4° to 140° F -20° to 60° C
Humidity (noncondensing)
Operating 8% to 90% 8% to 90%
Non-operating 5% to 95% 5% to 95%
Maximum Altitude
(unpressurized)
Operating 10,000 ft 3048 m
Nonoperating 30,000 ft 9144 m
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/spcific.html (2 of 5) [1/10/2002 11:55:30 AM]

Expansion Slots 2 16-bit
full-sized ISA
2 PCI
1 PCI/ISA
*This number will increase if more bay/slots are occupied.
Top
S3 Savage 4 Video Memory
Resolution Color Depth (bpp) Vertical Refresh (Hz)
640 × 480 8, 16, 32 60, 72, 75, 85, 160
800 × 600 8, 16, 32 60, 72, 75, 85, 160
1024 × 768 8, 16, 32 60, 72, 75, 85, 160
1152 × 864 8, 16, 32 75
1280 × 1024 8, 16 60, 75, 85, 100
1280 × 1024 32 60, 75, 85
1600 × 1200 8, 16 60, 75, 85
1600 × 1200 32 60
* The Compaq FP720 display supports a maximum resolution of 1024x768 and
only supports the 60 Hz refresh rate. The Compaq Presario MV520 Multimedia
Monitor supports a maximum resolution of 1024x768, which is displayed only at
the 60 Hz refresh rate. The Compaq Presario MV720 Multimedia Monitor
supports a maximum resolution of 1280x1024, which is displayed only at the 60
Hz refresh rate. The Compaq Presario MV920 Multimedia Monitor supports a
maximum resolution of 1600x1200, which is displayed at up to the 75 Hz refresh
rate.
Top
TNT Video Memory
Resolution Colors Vertical Refresh (Hz)
640 x 480 256, 65K, 16M 60,70,72,75,85,100,120,
140,144,150,170,200,240
800 × 600 256, 65K, 16M 60,70,72,75,85,100,120,
140,144,150,170,200,240
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/spcific.html (3 of 5) [1/10/2002 11:55:30 AM]

1024 × 768 256, 65K, 16M 60,70,72,75,85,100,120,
140,144,150,170,200
1152 × 864 256, 65K, 16M 60,70,72,75,85,100,120,
140,144,150,170
1280 × 1024 256, 65K, 16M 60,72,75,85,90,100,120
1280 × 1024 256, 65K, 16M 60,70,72,75,85,100,120,140
1600 × 1200 256, 65K, 16M 60,70,72,75,85,100
1920 × 1080 256, 65K, 16M 60,70,72,75,85
1920 × 1200 256, 65K, 16M 60,70,72,75,85
* The Compaq FP720 display supports a maximum resolution of 1024x768 and
only supports the 60 Hz refresh rate. The Compaq Presario MV520 Multimedia
Monitor supports a maximum resolution of 1024x768, which is displayed only at
the 60 Hz refresh rate. The Compaq Presario MV720 Multimedia Monitor
supports a maximum resolution of 1280x1024, which is displayed only at the 60
Hz refresh rate. The Compaq Presario MV920 Multimedia Monitor supports a
maximum resolution of 1600x1200, which is displayed at up to the 75 Hz refresh
rate.
System Interrupts
Hardware IRQ System Function
IRQ 0 Refresh Timer
IRQ 1 Keyboard
IRQ 2 Programmable Interrupt Controller
IRQ 3 Modem (COM 2) shared with modem audio*
IRQ 4 Communications Port (COM 1)
IRQ 5 USB, ACPI, Audio Drive
IRQ 6 Diskette Drive
IRQ 7 Parallel Port (LPT 1)
IRQ 8 Real-Time Clock, System CMOS
IRQ 9 SCI
IRQ 10 1394, ACPI
IRQ 11 Video Card, ACPI
IRQ 12 PS/2 Mouse
Compaq.com - Compaq Presario Maintenance and Service Guide - 5700 Series
http://www.compaq.com/athome/support/msgs/5700/spcific.html (4 of 5) [1/10/2002 11:55:30 AM]
