The CONA V2-N series amplifiers are remote controlled using UTP (CAT-5E)
Standard Ethernet cabling via TCP/IP Network protocol. Designed to be compact in
appearance the V2-N series ampliers deliver high power output with high eciency,
low power consumption and low heat dissipation.
High-output power amplier with network control
1. V2-N Series Features
2. V2-N Series Control S/W G.U.I
3. V2-N Series Applications
4. V2-N Series Specication
V2-1000N · V2-2000N · V2-3000N · V2-4000N

Eco-Friendly
50Hz HPF selection
Wired or wireless network control
Excellent response characteristics and S / N ratio
Software control
Clip Limiter
Remote PC control of volume level and power on/off as well as monitoring
of amplier power and operating conditions reduces power consumption
for an Eco-friendly environment.
A 50Hz High Pass Filter removes unnecessary base protecting speakers
preventing loss of phase.
Remote control is as simple as connecting a UTP (CAT-5E) Standard
Ethernet cable to TCP/IP network. The dedicated GUI software easily nds
and connects to the amplier.
The V2-N has a damping factor of better than 400, a THD of less than
0.05% THD, and a S/N ratio greater than 105dB giving it great tone and
high-resolution sound.
V2-N control software can remotely Power the amplifier On and Off set
volume and monitor amplier output voltage as well as current status.
A Clip Limiter can be set on or off to prevent output distortion and protects
against equipment damage.
Class H 2 tier linear design ensures ruler-at response, transparency and
detail while minimizing loss.
Class-H Technology
Features
1. V2-N Series
Total harmonic distortion stands. The lower THD means that the equipment
produces a more accurate reproduction by reducing harmonics added by
electronics and audio media.
Stands for Signal to Noise Ratio expressed in dB. It is a measurement that
compares the level of a desired signal to the level of background noise. It is
dened as the ratio of signal power to the noise power. The higher the ratio
indicates more signal than noise.
※T H D :
※S/N Ratio :
04 CONA Professional

Professional networking power amplifier
V2-1000N · V2-2000N · V2-3000N · V2-4000N
Easy to removeand clean dust filter
Circuit Protection
SMPS - Switch mode power supply provides high
efciency and low weigh
Input Gain Sensitivity
Forced air cooled, from front to back with easy access removable dust filter offer easy
maintenance and improving performance, efciency and extending product life.
Designed to operate under extreme conditions, a variety of protection circuitry is built into the
V2-N series ampliers such as DC Protection, over-temperature protection, and short-circuit.
This ensures stability of the equipment.
SMPS - Switch mode power supply provides high efficiency and low weigh. Among their
advantages is their reduced physical size, only 2 RU and lower heat dissipation. SMPS offer
greater than 90% power efciency and reduced power consumption over traditional ampliers.
A 3 position input gain sensitivity selector allows for matching of amplier input to a variety of
sources.
Technical Specication and features
CONA V2-N series :
Power, Pristine Audio Quality and Reliability
V2-N series ampliers are compact, lightweight, high-eciency, two-channel, high
power ampliers delivering quality reliable audio performance with sonic perfection.
The latest technology in amplier design is delivering ultimate power output while protecting
the entire system. High-performance and high-quality with clean and precise power makes
this amplifier ideal for voice and all styles of music. Perfect for portable live sound and
installed sound applications, including outdoor events, stadiums and arenas, casinos,
nightclubs, restaurants, hotels, houses of worship, corporate campuses and convention
centers.
05

Amplier Network Control And Setup Software
The software will display
equipment operating mode
and monitor system status.
Equipment vcan display
equipment by name, group or
system wide.
06 CONA Professional
2. V2-N Series
Control S/W G.U.I
Auto scan feature
The V2-N network amplifier can
be remotely controlled via TCP/IP
network using the included GUI
Software. Easy Set-Up allows for
automatic SCAN and detection
of amplifiers on the network.
Manual loading of amplifiers is
also possible.
The Software is
compatible with
all inter-M network
ampliers.
The information
displayed will
vary according to
amplier models.

Operating mode
A user-friendly GUI facilitates setting amplier modes, controlling and monitoring of the amplier with a
simple button click.
07
The Software will display Information such as Equipment model number, IP address, Power Status (including
online status, HPF filter on and clip protection), Volume levels, and amplifier mode. Amplifier operating
conditions including Amplier output voltage level, output current level and amplier’s internal temperature can
also be monitored.
General Information Amplier features and information are displayed and congurable.
1) Device model information
2) Power status
3) Volume information
4) Amplier status ▶ ONLINE ▶ HPF ▶ CLIP/PROT
5) Amp mode ▶ MODE ▶ GAIN
6) Operating Status ▶ Voltage ▶ Curren ▶ Temp
Professional networking power amplifier
V2-1000N · V2-2000N · V2-3000N · V2-4000N

Control S/W G.U.I
2. V2-N Series
Equipment detail View Additional equipment information is available by a simple click of a button. The
information screen will display details such as amplier model number, channel
name, and rmware version number. A graphical representation of the amplier
history is also displayed showing changes in output wattage, output voltage
output current and temperature.
Amplifier LOG information is stored and updated for operator reference and
maintenance purposes.
1) Details
2) History view
This view will display, the channel name, amplier rmware version, Remarks.
Graphical representation of changes in amplier operation.
Graphical representation of variation in Temperature, output wattage, output current, and output voltage (level).
Simple single button click allow to the user to view the amplier log le.
LOG Information
08 CONA Professional

Applications
3. V2-N Series
09
Multi-story
complex
Stadium
application
PC
Gym
Auditorium
Seminar Room
Seminar Room
Seminar Room
Meeting Room
Meeting Room
Control Room
Auditorium
Seminar Room
Seminar Room
Meeting Room
Meeting Room
Cafeteria
8F
7F
6F
5F
4F
3F
2F
1F
B1F
Amp Room
FOH - Main control Room
Network

Specification
4. V2-N Series
V2-N Series
V2-1000N · V2-2000N
V2-3000N · V2-4000N
V2-1000N V2-2000N V2-3000N V2-4000N
STEREO 8Ω (1kHz, THD 1%)
STEREO 4Ω (1kHz, THD 1%)
STEREO 2Ω (1kHz, THD 1%)
BRIDGED 8Ω (1kHz, THD 1%)
BRIDGED 4Ω (1kHz, THD 1%)
DAMPING FACTOR
POWER SOURCE
S/N (@8Ω)
WEIGHT (SET)
DIMENSIONS (SET)
·Amplier status such as Output voltage, protection
circuit, internal temperature and current conditions
can be remotely monitored using the Network
Control Software.
·Network Remote control of the amplier functions
such power on, Mute, volume level and other is
made possible using the Network Control Software.
·Amplier IP address can be set via three rotary DIP
Switches.
·TCP/IP Network remote control using Standard
UTP Cable and RJ45 Terminal.
·Included Network remote control Software.
(Windows 7 Compatible)
REMOTE CONTROL
170W
300W
550W
650W
1100W
≥380
10.7kg / 23.6 Ib
280W
500W
850W
1000W
1700W
≥400
10.9kg / 24 Ib
500W
900W
1500W
1800W
3000W
≥400
12kg / 26.4 Ib
700W
1200W
1900W
2400W
3800W
≥400
12.1kg / 26.7 Ib
AC CORDGAIN
SELECT SWITCH
INPUT
CONNECTORS
CLIP
LIMITER
HPF
SELECT SWITCH
SPEAKER OUTPUT CONNECTORS
440
482
88 369 39
MODE SELECT SWITCH
AC 110V / AC 220V, 60Hz
106dB
7A 4A 6A 7A
POWER CONSUMPTION
(1/8 power @4Ω)
Standard Ethernet TCP / IP
(10/100 Base TX), RJ-45 Port
482(W) x 88(H) x 407(D)mm / 19(W) x 3.5(H) x 16(D)in
10 CONA Professional

Professional networking power amplifier
V2-1000N · V2-2000N · V2-3000N · V2-4000N
1. Front Hanldes or Grip (removable)
2. Dust Filter replacement access
3. Volume Control
1
1 2 43 5 6 7 8 9
2 3 4 5 76
1. AC Cord
2. Speaker output connector
3. IP Adress Setup switch
4. Signal level LED indicator
5. Clip / Protection LED Indicator
6. Power LED Indicator
7. Power Switch
4. Ethernet Port
5. Euroblock input connector
6. 1/4 TRS / XLR-F Combination Jack
7. 3 position Input Gain Selector switch
8. Bridge/stereo/Parallel mode selector switch
9. 50Hz High Pass Filter selector switch
Front panel controls
Rear panel controls
11

V2-1000N
V2-2000N
V2-3000N
V2-4000N
