Conbrov DV089 User manual

MINI PIR SECURITY CAMERAUSER MANUALPlease ensure that you read the complete user manual carefully before using any part of the product.- Keep this copy safe for future reference in case of operational difficulties.- MODEL NO: DV089

This manual is specifically meant for this product and covers tutorials for the Mini High-Performance Security Camera that comes alongside with this manual. The camera has High Definition (HD) sensor with PIR feature for accurate motion detection and video recording ability. Additionally, it has a maximum of 1 week battery stand-by when fully charged. This gives the ability to capture long hours of any motion accurately round the clock. Connecting it to an external separate power bank enables it to record for months without going off. The small size of the camera enables the user to place it in any favorable locations and positions as it is not limited to specified places.Main features - Has the ability to record people movement perfectly without distractions- It is small in size providing flexibility when in use- It has easy to use features. Use single press to access the Motion Detection Mode and record instant accurate videos- It has a maximum stand-by time of about 7 days when fully charged.General overview2

Please read the following instructions before using the camera:- Ensure that the camera is tested for the first time use and confirm that it suits the intended purpose. - We are not responsible for any missing video information due to wrong operation,Micro-SD malfunctioning or camera angle limit etc.- The camera should be used for legal purpose only. Check and follow the laws provided in your country regarding the use of camera and other video recording devices.By following the above safety instructions, we hope that it will be enjoyable to own and use this product!Safety Instructions3

MINI PIR CAMERAUser Manual-Ple ase rea d the use r manua l caref ully be fore usin g the pro duct.-Ple ase kee p the use r manua l well for f uture checking.MOD EL NO: DV0 89
It is important to note that:If there is anything missing in your product package and it is not included in the above list of accessories, contact us as soon as possible at: [e-mail] accessoriesCamerabracket 1bracket 3USB cableManualbracket 24

Product structureLensPower on button PIR motion sensorUSB PortReset Micro-SD slotMode button (switch motion detection on/off)Micro phoneRecord/StopStatus indicator5

Detection abilityImportant Notice:- While using the camera, it should be placed in a perpendicular direction to those objective people passing by- Avoid using the camera in hot or extreme temperatures that will interfere with the motion-accuracy detection- Once the camera is set to motion-detection mode, it takes about 1 minute to switch to surveillance function.Motion detectin angle: 90 degreesFavorable detection distance: within 8 meters / 24 feet
Detectiondistance
Detectionangle690
8 meters

Charging informationThe camera is chargeable by the use of provided USB cable.- During charging, both Red and Blue light indicators are ON. The Red light goes OFF once fully charged.- It's usually take 5 hours for a fully charge. (5v 1A)- Important notice:- Ensure that the camera is switched OFF during charging.- Before using the camera for the fist time, it is recommended to fully charge it using a computer.7

How to insert and take out Micro-SD card
Important notice:- The camera has the ability to record video only when Micro-SD is inserted.- Please avoid by all means to insert or remove Micro-SD when the camera is either powered ON or connected to the computer. This can possibly cause damage to Micro-SD or the entire camera.- Please ensure that minimal effort is applied to the Micro-SD when inserting it in or out of the camera. Use of force can easily damage the Micro-SD or the product parts.- Before using the product for the first time, ensure that the Micro-SD is formatted. Please check for any saved data in the Micro-SD to avoid unexpected loss.We are not liable or responsible for malfunctions that result from failure to follow the above guidelines.Take Micro-SD outInsert Micro-SD card8

It is not compulsory to set time or date unless when necessary for personal purposes. The user can choose to set or ignore depending on their target of product use.How to set time and dateStep 1: Use the provided USB cable to connect the camera to the computer and open the camera control panel available from the computer options. The new window will show a tag.txt file. Time and date setting9Step 2: Open the tag.txt file and only change the date and time figures without altering any other data. Save the file and close it. Step 3: Disconnect the camera from the computer and power it on. It should be ready to function normally with an updated time and date details.TAG. TXTfile Edit Format View HelpFile nameYear/Month/DayHour/Minute/Second [date] 2015/03/2323:15:12 NewOpenSaveSave asPage settingsPrintExitfileEdit Format View Help12TAG. TXT

1. Motion detection procedure: - The camera should be fully charged and Micro-SD inserted. - Press on Mode button and the camera will automatically switch to Motion Detection Mode. This enables the camera to record any motion detected within its environment as specified above - While in Motion Detection Mode, there is a yellow indicator at the bottom that will remain ON to show record duration.2. Video recording procedure: - Press the power function button to switch ON. - Hold the Record button for 3 seconds to enable video record feature. - Press the record button again will stop the camera from recording and automatically savethe already recorded video.Operating the motion detection record feature10Yellow indicatorMode button

Installation position and camera angle settingsPoint APoint BFrom the diagram, it is clear that point A is not favorable as the camera's angle is limited and the position is directly straight to the door. Point B happens to be the best position. Point APoint BHowever, it would be an advantage when using two or more motion cameras to cover the entire room and avoid possible limitations that may occur due to distance and angle covered by a single camera.11

Detailed parametersIndicator Status and their meanings12Parameter22mm x 16mm x 57mmAVIM-JPEG720x480 Windows Media Player or other available alternativesComputer Operating Systems supported Mini 5 PinMicro-SDHigh capacity Li-battery90 degrees8 meters / 24 feet72 degreesWindows Camera size Video file format Video file code Camera resolution Video player supported USB type Camera memory storage Battery type Camera PIR angle Supported PIR distance Camera view angle ItemStand-by Save file Charging Fully charged Motion detection ONNo Micro-SD insertedRecord modeBlue indicator is ONBlue indicator is ONBoth Red and Blue indicators are ONRed indicator goes OFF,Red indicator is ONYellow indicator is ON at the bottomBlue indicator flashesand goes OFFBlue indicator flashes for 3 times and goes OFF
