Concorde RG-42 User manual

CONCORDE BATTERY CORPORATION
2009 San Bernardino Road | West Covina, CA 91790 USA
626-813-1234 | Fax [phone] | www.ConcordeBattery.com
ISO 9001 + AS9100 | Crafted for Quality in the U.S.A.
RG-42 (17 Ah)
Auxiliary
0219
ATR 42 Series & ATR 72 Series
Certified Sealed Lead Acid
Battery Installations
FAA STC ST03930AT
EASA ESTC 10038867
TCCA Acceptance
ANAC Brazil 2012S10-07
Main Battery Upgrade –
Existing Nickel Cadmium battery is replaced
with Concorde Battery RG-380E/44 (24V/42Ah).
Auxiliary Battery Upgrade –
Existing Nickel Cadmium battery is replaced
with Concorde Battery RG-42 (24V/17Ah).
•Drop In Replacement
•Lower cost of acquisition
•Reduced cost per flight hour
•No memory effect, cycling requirements or
thermal runaway
•Ship Hazmat Exempt
•Lead Acid Batteries are 100% Recyclable
Made in the U.S.A.
This STC provides for the
installation of Concorde RG-
380E/44 main ship & RG-42
auxiliary lead acid batteries
in place of the existing Nickel
Cadmium batteries in the
ATR-42/72 Avions de Transport
Regionale Aircraft Series. Please
note this STC replaces Nickel
Cadmium batteries in both
positions. Remove existing battery
from aircraft in accordance with
ATR-42/72 Maintenance Manual.
1. Install a dummy plug (7945) on
each aircraft side temperature
sensor connector. Stow the
temp sensor connector from
each battery.
2. Install placards (6716) on battery
temperature alarms indicating
that they are not operational.
3. Install Concorde RG-380E/44
IAW ATR 42/72 Maintenance
Manual Instructions for
installing the main Nickel
Cadmium. Omit that portion
of the instruction pertaining to
connection of the temperature
sensor connector.
4. Install Concorde RG-42 IAW
ATR 42/72 Maintenance Manual
Instructions for installing the
auxiliary Nickel Cadmium. Omit
that portion of the instruction
pertaining to connection of the
temperature sensor connector.
5. Perform the battery operational
tests IAW ATR-42/72
Maintenance Manual.
6. Weigh the batteries being
removed & update the weight &
balance for the installed battery.
RG-380E/44 (42 Ah)
Main

CONCORDE BATTERY CORPORATION
2009 San Bernardino Road | West Covina, CA 91790 USA
626-813-1234 | Fax [phone] | www.ConcordeBattery.com
ISO 9001 + AS9100 | Crafted for Quality in the U.S.A.
0219
MS3509
RECEPTACLE
2X LIFTING HANDLES
9.84
(249.9 MM)
9.60
(243.8 MM)
11.87
(301.5 MM)
10.26
(260.5 MM)
10.28
(261.0 MM)
2X VENT TUBES
MS3509
RECEPTACLE
FLEXIBLE
HANDLE
2X 8.03
(203.8 MM)
6.40
(162.6 MM)
6.63
(168.4 MM)
7.15
(181.6 MM)
5.06
(128.6 MM)
11.06
(280.9 MM)
10.69
(271.5 MM)
FAA STC ST03930AT
EASA ESTC 10038867
TCCA Acceptance
ANAC Brazil 2012S10-07
Main Battery
RG-380E/44 (24V/42Ah)
Part Rated Capacity IPP IPR IPP IPR IPP IPR Maximum
Number C1 in Ah 23°C / 74°F -18°C / 0°F -30°C / -22°F Weight
RG-380E/44 42 Ah 1350 1000 875 750 750 600 86 LB/39.0 KG
Part Rated Capacity IPP IPR IPP IPR IPP IPR Maximum
Number C1 in Ah 23°C / 74°F -18°C / 0°F -30°C / -22°F Weight
RG-42 17 Ah 900 625 600 425 450 300 43 LB/19.5 KG
Auxiliary Battery
RG-42 (24V/17Ah)
Miscellaneous
7945 – Dummy Temperature Sensor
This sensor disables the battery temperature warning system which is not required for lead acid
batteries.
6716 – Placard
To be installed on battery temperature alarm indicating that they are not operational.
