The ConMed Linvatec 26” LCD Medical Monitor
Instruction Manual (VP4726 and VP4726F)
E
Manuel d'instruction du moniteur médical LCD
ConMed Linvatec 66 cm (VP4726 et VP4726F)
F
ConMed Linvatec 26-Zoll-LCD-Monitor
Bedienungsanleitung (VP4726 und VP4726F)
G
Monitor medicale LCD 26" ConMed Linvatec
Manuale di istruzioni (VP4726 e VP4726F)
I
Manual de instrucciones del monitor LCD médico
ConMed Linvatec de 26 pulgadas (VP4726 y VP4726F)
S
W41-147-004AA.book Page 1 Wednesday, February 18, 2009 2:47 PM

Proprietary Information
This manual contains information deemed proprietary to Linvatec Corporation. The
information contained herein, including all of the designs and related materials, is the sole
property of ConMed Linvatec and/or its licensors. ConMed Linvatec and/or its licensors
reserve all patent, copyright and other proprietary rights to this document, including all
design, manufacturing methodology and reproduction.
This document, and any related materials, is confidential and is protected by copyright laws
and shall not be duplicated, transmitted, transcribed, stored in a retrieval system, or
translated into any human or computer language in any form or by any means, electronic,
mechanical, magnetic, manual or otherwise, or disclosed to third parties, in whole or in part,
without the prior express written consent of ConMed Linvatec.
ConMed Linvatec reserves the right to revise this publication and to make changes from time
to time in the contents hereof without obligation to notify any person of such revision or
changes, unless otherwise required by law.
Linvatec is a trademark or registered trademark of ConMed Linvatec
Linvatec Corporation 2009. All Rights Reserved. Printed in USA
Record the Model and Serial Numbers of the VP4726 and/or VP4726F LCD Monitor(s)
and date received. Retain for future reference.
Monitor Model No. Serial No Date
Monitor Model No. Serial No Date
Monitor Model No. Serial No Date
E
W41-147-004AA.book Page 2 Wednesday, February 18, 2009 2:47 PM

Table of Contents Page
E-i
E
1.0 INTRODUCTION
1.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1
1.2 Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1
1.2.1 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1
1.2.2 Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-3
1.3 Environmental Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-4
1.4 Symbol Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-5
1.5 Unpacking and Inspecting the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-6
1.6 Returning the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-6
1.7 System Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-7
1.7.1 Front Panel On-Screen Display (OSD) Button Functionality . . . . . . . . . . . E-7
1.7.2 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-8
1.8 Monitor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-9
1.9 On-Screen Display Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-10
1.9.1 DSUB ANALOG/RGBS Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . E-10
1.9.2 DVI OPTICAL / DVI DIGITAL Input Source . . . . . . . . . . . . . . . . . . . . . E-13
1.9.3 YPbPr Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-15
1.9.4 SVIDEO / CVIDEO Input Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-18
1.9.5 SDI Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-21
1.10 OSD System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-24
1.11 Standard Signal Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-30
1.12 SDI Video Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31
1.13 VGA (15 Pin D-Sub) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31
1.14 DVI In, Out (24 DVI-D). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32
1.15 C-Video (BNC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32
1.16 S-Video (BNC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33
1.17 RS232C (D-SUB 9 Pin) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33
1.18 SDI (BNC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33
1.19 RGBHV / RGBS / YPbPr (BNC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-34
1.20 OPTICAL (available on VP4726F Monitor Only). . . . . . . . . . . . . . . . . . . . . . . . . E-34
W41-147-004AA.book Page i Wednesday, February 18, 2009 2:47 PM

E-ii
Table of Contents Page
E2.0 MAINTENANCE
2.1 Life Expectancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-35
2.2 Periodic Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-35
2.3 Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-35
2.4 Recommended Annual Monitor Maintenance Requirements . . . . . . . . . . . . . . . . E-36
2.5 Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-38
2.6 Detailed EMC Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41
2.7 Obtaining Parts and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-47
2.8 Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
2.8.1 Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
2.8.2 Repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-48
W41-147-004AA.book Page ii Wednesday, February 18, 2009 2:47 PM

E-1
E
1.0 INTRODUCTION
t is recommended that personnel study this
manual before attempting to connect,
operate, adjust and/or clean the ConMed
Linvatec VP4726 and VP4726F Medical LCD
26” Monitors. The safe and effective use of this
equipment requires the understanding of and
compliance with all warnings, precautionary
notices, and instructions marked on the product,
and included in this manual.
The VP4726F Monitor is identical to the
VP4726 Monitor except it is equipped with
Optical input connectors. See “1.20 OPTICAL
(available on VP4726F Monitor Only)” on
page E-34 for connector information.
1.1 Intended Use
The VP4726 and VP4726F Medical LCD 26”
Monitors are used to display live and recorded
images captured with a medical grade camera
system or previously recorded using various
recording devices.
1.2 Warnings and Precautions
The words WARNING, PRECAUTION, and
NOTE carry special meanings and they should
be read carefully.
WARNING: The safety and/or health
of the patient, user, or a third party is at
risk. Comply with this warning to avoid
injury to the patient, user, or third party.
PRECAUTION: This contains
information concerning the intended use
of the device or accessory. Damage to
the equipment is possible if these instructions
are not followed.
NOTE: A note is added to provide additional,
focused, information.
1.2.1 Warnings
1. This equipment is designed for use
by medical professionals completely familiar
with the required techniques and instructions
for use of the equipment. Prior to using the
device, read and follow all warning and
precautionary notices and instructions
marked on the product and included in
this manual.
2. Do not attempt to open or service
the monitor, as this may void your
warranty. There are no user-
serviceable parts inside. Removing
the cover may introduce an electric
shock hazard by exposing you to dangerous
high voltages or other risks. If the system
malfunctions, return it for service
immediately.
I
W41-147-004AA.book Page 1 Wednesday, February 18, 2009 2:47 PM

E-2
E3. Dangerous voltages are present
inside the monitor. The unit should
be used only in rooms that comply
with recommendations concerning
electrical safety when used for medical
purposes (as stated in IEC 60601 Series and
UL 60601-1).
4. Never insert anything metallic into
the cabinet openings of the monitor.
Doing so may cause electric shock.
5. System installation shall be in accordance
with the requirements of IEC 60601-1-1,
The Standard for Safety Requirements of
Medical Electrical Systems.
6. This equipment is not suitable for
use in the presence of flammable
anesthetic mixture with air,
oxygen, or nitrous oxide.
7. Some disinfectants and cleaning agents
vaporize to form explosive mixtures and, if
such agents are used, the vapor must be
allowed to disperse before the monitor is
put to use.
8. Before connecting the AC power cord to
the DC adapter outlet make sure the voltage
designation of the DC adapter corresponds
to the local electrical supply.
9. Disconnect monitor prior to applying
cardiac defibrillation to patient.
10. This monitor should not share an electrical
outlet or grounding with life supporting or
life sustaining equipment.
11. This monitor may not be used in connection
with life support equipment.
12. Equipment grounding is vital for safe
operation. Plug power cord into a properly
earthed mains supply outlet whose voltage
and frequency characteristics are
compatible with those listed on the monitor
or in this manual. Do not use plug adapters
or extension cords; such devices defeat the
safety ground and could cause injury.
13. Grounding reliability is achieved only when
the monitor is connected to a “hospital
only” or “hospital grade” receptacle.
Inspect routinely and do not use if damage
is discovered.
14. If one or more mains powered units are
connected simultaneously to one socket by
the means of a distribution box, the sum of
the individual leakage currents may exceed
the tolerated limits.
15. Be sure to hold the plug, not the
cord, when disconnecting the
monitor from an electric socket.
Doing so may cause electric shock.
16. Do not touch signal input, signal output or
other connectors, and the patient
simultaneously.
17. If your monitor does not operate normally,
in particular, if there are any unusual
sounds or smells coming from it, unplug it
immediately and return for service.
18. For the protection of service personnel, and
for safety during transportation, all devices
and accessories that are returned for repair
must be prepared for shipment as described
in “1.6 Returning the Monitor” on page
E-6 of this manual. The manufacturer has
the right to refuse to carry out repairs if the
product is contaminated.
W41-147-004AA.book Page 2 Wednesday, February 18, 2009 2:47 PM

E-3
E
1.2.2 Precautions
1. United States Federal law
restricts sale of this device to or
on the order of a physician.
2. The monitor should only be used in
compliance with its intended use.
3. Do not use the monitor with incompatible
equipment not authorized by ConMed
Linvatec. Doing so may void certifications
and/or warranties.
4. The warranty becomes void and the
manufacturer is not liable for direct or
resulting damage if:
• The monitor or the accessories are
improperly used, prepared or maintained;
• The instructions in the manual are not
adhered to;
• Non-authorized persons open and / or
perform repairs, adjustments or
alterations to the monitor;
NOTE: Receipt of technical documentation
from the manufacturer does not authorize
individuals to perform repairs, adjustments,
or alterations to the monitor or accessories.
Only authorized service personnel may
perform repairs, adjustments or alterations on
the monitor and accessories. Any violation will
void the manufacturer’s warranty. Authorized
service technicians are trained and certified
only by the manufacturer.
5. Prior to each use the monitor and all
associated equipment must be inspected for
proper operation.
6. Do not expose the monitor to moisture,
operate in wet areas, or place liquids on or
above unit.
7. Electrical cords and attaching cables used
with the monitor must be appropriate for the
rated voltage and current, and in compliance
with all international, national, and local
electrical codes and regulations pertaining to
the use of medical devices.
8. Ensure that the available mains voltage
matches the mains voltage data on the rear
of the monitor which is located near the
appliance inlet module.
9. Do not excessively bend or kink the
instrument power cord.
10. Handle all equipment carefully. If the
monitor is dropped or otherwise damaged,
return it immediately for service.
11. Openings in the monitor cabinet are
provided for ventilation. To prevent
overheating, these openings should not be
blocked or covered.
12. Thoroughly clean the monitor as needed
(reference “2.3 Cleaning Instructions” on
page E-35).
Rx ONLY
W41-147-004AA.book Page 3 Wednesday, February 18, 2009 2:47 PM

E-4
E13. External equipment that will be connected to
signal input and signal output ports or other
connectors shall comply with relevant IEC
standard (i.e., IEC 60950 for IT equipment
and IEC 60601 series for medical electrical
equipment). In addition, all such
combinations / systems - shall comply with
the standard IEC 60601-1-1 (Safety
requirements for medical electrical systems).
Any person who connects external
equipment to signal input and signal output
ports or other connectors has formed a
system and is therefore responsible for the
system to comply with the requirements of
IEC 60601-1-1. If in doubt, contact a
qualified technician or your local
representative.
(a) Reorient or relocate the receiving
device.
(b) Increase the separation between the
equipment.
(c) Connect the equipment into an outlet
on a circuit different from that to which
the other devices are connected.
(d) Consult the manufacturer or field
service technician for assistance.
1.3 Environmental Directives
WEEE Directive [2002/96/EC] on
Waste Electrical and Electronic
Equipment
The Directive on Waste Electrical and
Electronic Equipment obliges manufacturers,
importers, and/or distributors of electronic
equipment to provide for recycling of the
electronic equipment at the end of its useful life.
Do not dispose of WEEE in unsorted municipal
waste.
The WEEE symbol on the product or its
packaging indicates that this product must not
be disposed of with other waste. Instead, it is
your responsibility to dispose of your waste
equipment by handing it over to a designated
collection point for the recycling of Waste
Electrical and Electronic Equipment. The
separate collection and recycling of your waste
equipment at the time of disposal will help
conserve natural resources and ensure that it is
recycled in a manner that protects human health
and the environment. For more information
about where you can drop off your medical
equipment at the end of its useful life for
recycling, please contact ConMed Linvatec.
W41-147-004AA.book Page 4 Wednesday, February 18, 2009 2:47 PM

E-5
E
1.4 Symbol Definitions
Power Standby / ON
Follow instructions for use.
Precaution or warning notice
Electrical hazard. Dangerous
voltages are present within the
cabinet. Never attempt to repair
the equipment. Only trained
service personnel may remove
the cover, or obtain access to the
system components.
Alternating Current.
Direct Current
Protective Earth (ground).
Warning - For continued
protection against risk of fire,
replace only with same type and
rating fuse.
Waste Electronics and Electrical
Equipment (WEEE) Symbol.
Regarding European Union end-
of-life of product.
RF Symbol. Non-ionizing
Electromagnetic Radiation
Caution: Federal Law restricts
this device to sale by or on the
order of a physician.
~
Rx ONLY
Flammable Anesthetics - Risk of
explosion if used in the presence of
flammable anesthetics
Fragile
This side up
Maximum Stacking
Keep Dry
Temperature limits for storage and
transport
Humidity limits for storage and
transport
Pressure limits for storage and
transport
GPIO General Purpose Input / Output
PACS Picture Archive Communications
System
PIP Picture in Picture
PBP Picture By Picture (side by side
images)
IPX1 Indicates that the device is
protected against the effects of
vertically falling water.
3
W41-147-004AA.book Page 5 Wednesday, February 18, 2009 2:47 PM

E-6
E1.5 Unpacking and Inspecting the
Monitor
Upon receipt, carefully unpack the monitor and
accessories. Ensure contents are complete and
are free from damage. If any damage is noted
contact your ConMed Linvatec Customer
Service Representative. Save ALL packaging
materials; they may be needed to verify any
claims of damage by the shipper.
VP4726 / VP4726F LCD 26” Monitor:
• 1 - DVI Cable, 6 ft. (IM9021)
• 1 - BNC Cable (8175-06)
• 1 - AC Adapter (023933)
• 2 - DC Cable Terminal male / female
(Optional)
• 4 - Screws FH M4x12 (Screws for Vesa
mount - Optional)
• 2 - Ferrite Core,
ZCAT2035-0930A-M-K (Optional)
• 1 - Instruction Manual
The power cord is sold separately and is
packaged in a separate box.
• C7104 Power Cord — 115VAC
• C7105 Power Cord — 230VAC
1.6 Returning the Monitor
If it becomes necessary to return the monitor,
always use the original packaging. The
manufacturer does not take responsibility for
damage that has occurred during transportation
if the damage was caused by inadequate
transport packaging.
Contact ConMed Linvatec Customer Service for
Return Authorization PRIOR to shipping your
monitor for service.
Please make sure that all required information
has been supplied.
• Owner’s Name
• Owner’s Address
• Owner’s Daytime Telephone Number
• Device type and model.
• Serial Number
• Detailed explanation of the damage.
W41-147-004AA.book Page 6 Wednesday, February 18, 2009 2:47 PM

E-7
E
1.7 System Indicators
1.7.1 Front Panel On-Screen Display
(OSD) Button Functionality
❶“POWER” Button - Press to set the
monitor to Normal Mode or Stand-by Mode.
❷Power Status Indicator - Indicator is off
when monitor is in stand-by mode, and is
illuminated green when the monitor is
activated.
❸Up Arrow - With the OSD deactivated, press
this area to increase the brightness of the
monitor. With the OSD activated, press this
area to move the cursor upward in a menu.
❹Left Arrow - With the OSD deactivated,
press this area to decrease the contrast of
the monitor. With the OSD activated, press
this area to enter a sub-menu and decrease
the adjustment of the selected function.
➎MENU Button - With the OSD deactivated,
pressing this button activates the OSD menu.
With OSD activated, pressing this button
exits the main menu or sub-menu.
➏Down Arrow - With the OSD deactivated,
press this area to decrease the brightness of
the monitor. With the OSD activated, press
this area to move the cursor downward.
❼Right Arrow - With the OSD deactivated,
press this area to increase the contrast of the
monitor. With the OSD activated, press this
area to enter a sub-menu and increase the
adjustment of the selected function.
❽INPUT Button - Used to change the
monitor’s signal source; select DVI
OPTICAL / DVI DIGITAL / DSUB
ANALOG / SDI YPbPR / RGBS / SVIDEO
/ CVIDEO. With OSD deactivated, press
this button to switch signal inputs.
➒PIP Button - Pressing this button enables
the Picture-In-Picture function. Select PIP,
PBP1, PBP2.
❶
❸❹ ❺
❻❼❽ ❾
❷
W41-147-004AA.book Page 7 Wednesday, February 18, 2009 2:47 PM

E-8
E
1.7.2 Rear Panel
❶AC / DC IN Jack
❷ON / OFF Switch
❸OPTICAL IN (OPTIONAL) Connector
(Available only on the VP4726F Model)
❹DVI IN Connector
➎DVI OUT Connector
➏VGA IN Connector
❼GPIO Connector
❽RS232C Connector
➒HD SDI IN Connector
➓HD SDI OUT Connector
RED / Pr Connector
GREEN / Y Connector
BLUE / Pb Connector
C-SYNC / H-SYNC Connector
VS (V-SYNC) Connector
S-VIDEO / Y Connector
S-VIDEO / C Connector
Composite (C) VIDEO Connector
11
12
13
14
15
16
17
18
❶❷❸ ❹❺ ❻❼❽
❾
10 11
12
13 14 15
17
18
16
W41-147-004AA.book Page 8 Wednesday, February 18, 2009 2:47 PM

E-9
E
1.8 Monitor Operation
1. Connect the DC input jack to the DC IN
connector on the back of the monitor.
2. Plug the female end of the AC Power Cord
into the AC Inlet of the DC Adapter.
3. Plug the AC Power Cord into a Hospital
Grade outlet.
4. Connect the appropriate video source to the
monitor.
5. Apply power to all connected peripheral
devices.
6. Turn the monitor on by pressing the power
switch on the back of the monitor.
7. Set your preferred settings using the On-
Screen Menus listed on the following
pages.
W41-147-004AA.book Page 9 Wednesday, February 18, 2009 2:47 PM

E-10
E1.9 On-Screen Display Menus
1.9.1 DSUB ANALOG/RGBS Input Source
Adjust Menu
❶BRIGHTNESS - Increase or decrease the
brightness (Range: 0~100).
❷CONTRAST - Increase or decrease the contrast
(Range: 0~100).
❸CLOCK - Increase or decrease the sampling
frequency (Range: 0~100).
❹PHASE - Increase or decrease the phase level
(Range: 0~100).
➎BACK LIGHT - Increase or decrease the back
light dimming level (Range: 0~100).
➏AUTO ADJUST - Fit to the most appropriate
screen on the D-SUB Analog signal.
Color Temp Menu
❶MODE - Change the color temperature mode:
6500K, 5600K, USER. When USER is selected, a
sub-menu displays allowing the user to adjust the
RED, GREEN or BLUE balance.
❷RED - Red balance- Only works with USER mode
(Range: 0~100).
❸GREEN - Green balance- Only works with USER
mode (Range: 0~100).
❹BLUE - Blue balance- Only works with USER
mode (Range: 0~100).
W41-147-004AA.book Page 10 Wednesday, February 18, 2009 2:47 PM

E-11
E
Image Menu
❶IMAGE SIZE - Change the image size (Scaling
mode) (Full; Fill aspect, 1:1; Normal; Video;
Zoom; Video only).
❷H POSITION - Adjust the horizontal (left or right)
position of the displayed source image
(Range: 0~100).
❸V POSITION - Adjust the vertical (up or down)
position of the displayed source image
(Range: 0~100).
❹GAMMA - Adjust GAMMA value (VIDEO,
BYPASS, 1.8, 2.0, 2.2, 2.4, 2.6, PACS).
➎FILTER - Set the sharpness of the image (Softest,
Soft, Normal, Sharp, Sharpest).
➏OVER SCAN - Adjust the displayed size ( 0~8)
❼IMAGE SETTING - Allow selection of one of
five user defined image presets.
Setup Menu
❶LANGUAGE - Change the OSD language
(8 languages - Korean, English, French, Spanish,
German, Chinese, Japanese, Italian).
❷OSD POSITION - Change the OSD position.
❸DURATION - Adjust time until the OSD Menu
will disappear after adjusting the duration
(5, 10, 20, 30, 60, 90, 120, 180, 240 seconds).
❹RESET SETTINGS - Changes all the OSD values
to factory out-going status.
➎AUTO SOURCE SELECT - Disable or enable
auto source select. (ON: Searches through all
possible input sources until an active video source
is found. OFF: Video input is manually selected.)
➏USER NAME ENTRY - Change the name of a
Preset to the Users Name, etc.
W41-147-004AA.book Page 11 Wednesday, February 18, 2009 2:47 PM

E-12
EPIP Menu
❶LAYOUT - Changes the OSD layout (Single, PIP,
PBP1, PBP2).
For each LAYOUT selection, the following Sub-menus
are available:
❷SOURCE - Changes the secondary source.
❸SIZE - Changes the PIP size (Small, Medium,
Large).
❹POSITION - Changes the PIP location.
➎SWAP - Swaps the position and size of the Primary
and Secondary image.
W41-147-004AA.book Page 12 Wednesday, February 18, 2009 2:47 PM

E-13
E
1.9.2 DVI OPTICAL / DVI DIGITAL Input
Source
Adjust Menu
❶BRIGHTNESS - Increase or decrease the
brightness (Range: 0~100).
❷CONTRAST - Increase or decrease the contrast
(Range: 0~100).
❸BACK LIGHT - Adjust the back light dimming
level (Range: 0~100).
Color Temp Menu
❶MODE - Change the color temperature mode:
6500K, 5600K, USER. When USER is selected, a
sub-menu displays allowing the user to adjust the
RED, GREEN or BLUE balance.
❷RED - Red balance- Only works with USER mode
(Range: 0~100).
❸GREEN - Green balance- Only works with USER
mode (Range: 0~100).
❹BLUE - Blue balance- Only works with USER
mode (Range: 0~100).
W41-147-004AA.book Page 13 Wednesday, February 18, 2009 2:47 PM

E-14
EImage Menu
❶IMAGE SIZE - Change the image size
(Scaling mode) (Full; Fill aspect, 1:1; Normal).
❷GAMMA - Adjust GAMMA value (VIDEO,
BYPASS, 1.8, 2.0, 2.2, 2.4, 2.6, PACS).
❸FILTER - Set the sharpness of the image (Softest,
Soft, Normal, Sharp, Sharpest).
❹OVER SCAN - Adjust the displayed size ( 0~8).
➎IMAGE SETTING - Change the image setting
(PRESET 1, PRESET 2, USER 1, USER 2, USER 3).
➏ZOOM / PAN - Enlarge the image.
❼FREEZE FRAME - Freezes the image.
Setup Menu
❶LANGUAGE - Change the OSD language
(8 languages - Korean, English, French, Spanish,
German, Chinese, Japanese, Italian).
❷OSD POSITION - Change the OSD position
(9 Positions).
❸DURATION - Adjust time until the OSD Menu
will disappear after adjusting the duration
(5, 10, 20, 30, 60, 90, 120, 180, 240 seconds).
❹RESET SETTINGS - Changes all the OSD values
to factory out-going status.
➎AUTO SOURCE SELECT - Disable or enable
auto source select. (ON: Searches through all
possible input sources until an active video source
is found. OFF: Video input is manually selected.)
➏USER NAME ENTRY - Change the name of a
Preset to the Users Name, etc.
W41-147-004AA.book Page 14 Wednesday, February 18, 2009 2:47 PM

E-15
E
PIP Menu
❶LAYOUT - Changes the OSD layout (Single, PIP,
PBP1, PBP2).
For each LAYOUT selection, the following Sub-menus
are available:
❷SOURCE - Changes the secondary source.
❸SIZE - Changes the PIP size (Small, Medium,
Large).
❹POSITION - Changes the PIP location.
➎SWAP - Swaps the position and size of the Primary
and Secondary image.
1.9.3 YPbPr Input Source
Adjust Menu
❶BRIGHTNESS - Increase or decrease the
brightness (Range: 0~100).
❷CONTRAST - Increase or decrease the contrast
(Range: 0~100).
❸SHARPNESS - Adjust the sharpness of the video
image (Range: 0~100).
❹SATURATION - Changes the tone of the color
(Range: 0~100).
➎COLOR - Changes the richness of the color
(Range: Green 0~50, Red 0~50).
➏BACK LIGHT - Increase or decrease the back
light dimming level (Range: 0~100).
❼PHASE - Increase or decrease the phase level
(Range: 0~100).
W41-147-004AA.book Page 15 Wednesday, February 18, 2009 2:47 PM

E-16
EColor Temp Menu
❶MODE - Change the color temperature mode:
6500K, 5600K, USER. When USER is selected, a
sub-menu displays allowing the user to adjust the
RED, GREEN or BLUE balance.
❷RED - Red balance- Only works with USER mode
(Range: 0~100).
❸GREEN - Green balance- Only works with USER
mode (Range: 0~100).
❹BLUE - Blue balance- Only works with USER
mode (Range: 0~100).
Image Menu
❶IMAGE SIZE - Change the image size
(Scaling mode) (Full; Fill aspect, 1:1; Normal).
❷H POSITION - Adjust the horizontal (left or right)
position of the displayed source image
(Range: 0~100).
❸V POSITION - Adjust the vertical (up or down)
position of the displayed source image
(Range: 0~100).
❹GAMMA - Adjust GAMMA value (VIDEO,
BYPASS, 1.8, 2.0, 2.2, 2.4, 2.6, PACS).
➎FILTER - Set the sharpness of the image (Softest,
Soft, Normal, Sharp, Sharpest).
➏OVER SCAN - Adjust the displayed size ( 0~8)
❼IMAGE SETTING - Change the image setting
(PRESET 1, PRESET 2, USER 1, USER 2, USER 3).
W41-147-004AA.book Page 16 Wednesday, February 18, 2009 2:47 PM
