Connect One II-EVB-361MW User manual

International:
Connect One Ltd.
20 Atir Yeda Street
Kfar Saba 44643, Israel
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
http://www.connectone.com
Connect One Semiconductors, Inc.
560 S. Winchester Blvd.
Suite 500
San Jose, CA 95128
Tel: [phone]
Fax: [phone]
Pub. No. 23-3620-13, Copyright © Connect One, March 2008
Instant Internet
Evaluation Board
II-EVB-361MW
User Manual
Version 1.3

II-EVB-361-MW User’s Manual ii
Information provided by Connect One Ltd. is believed to be accurate and reliable.
However, Connect One assumes no responsibility for its use, nor any infringement of
patents or other rights of third parties, which may result from its use. No license is
granted by implication or otherwise under any patent rights of Connect One other than
for circuitry embodied in Connect One’s products. Connect One reserves the right to
change circuitry at any time without notice. This document is subject to change
without notice.
The software described in this document is furnished under a license agreement and
may be used or copied only in accordance with the terms of such a license agreement.
It is forbidden by law to copy the software on any medium except as specifically
allowed in the license agreement. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including but not
limited to photocopying, recording, transmitting via fax and/or modem devices,
scanning, and/or information storage and retrieval systems for any purpose without
the express written consent of Connect One.
iChip, Secure Socket iWiFi, Internet Controller, SerialNET, AT+i, and Connect One
are trademarks of Connect One Ltd.
Copyright 2008 Connect One Ltd. All rights reserved.

International:
Connect One Ltd.
20 Atir Yeda Street
Kfar Saba 44643, Israel
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
http://www.connectone.com
Connect One Semiconductors, Inc.
560 S. Winchester Blvd.
Suite 500
San Jose, CA 95128
Tel: [phone]
Fax: [phone]
Pub. No. 23-3620-13, Copyright © Connect One, March 2008
TABLE OF CONTENTS
Introduction....................................................................................................................4
Unpacking......................................................................................................................4
Connections....................................................................................................................4
Testing the Secure Socket iWiFi Wireless LAN Connection....................................4
Installing the II-EVB-361MW Utility and Evaluation Program....................................5
Connectors and Switch Positions...................................................................................6
LED Positions................................................................................................................7
Bill of Materials.............................................................................................................8
Appendix 1: II-EVB-361MW Schematic ......................................................................8
Appendix 2: Secure Socket iWiFi Mechanical Views.................................................10
Appendix 3: WiFi Configuration Notes.......................................................................11
Introduction..............................................................................................................11
iChip Wireless LAN Environment Configuration Parameters ................................12
Wireless LAN Configuration Web Site Page ..........................................................13
Wireless LAN Status Report....................................................................................13
iChip Wireless LAN Test Mode..............................................................................15
Placement and Range Guidelines.............................................................................15
Wireless LAN Data Privacy/Security Considerations .............................................15

II-EVB-361-MW User’s Manual
4
Introduction
This manual is intended to familiarize prospective customers with Connect One’s
Instant Internet Evaluation Board II-EVB-361MW. The II-EVB-361MW is an
evaluation platform for the Secure Socket iWiFi™Internet Controller. Secure Socket
iWiFi is a secure serial-to-Wireless LAN device server module that also acts as a
bridge to connect serial devices to 802.11b/g wireless LANs. Secure Socket iWiFi fits
into a socket form-factor and utilizes Connect One’s iChip CO2128SEC Internet
communications coprocessor and the AT+i™command set, a powerful set of Internet
protocol commands developed by Connect One to manage Internet connectivity
through a wireless LAN connection.
Secure Socket iWiFi enables sending and receiving textual and binary data, MIME-
encoded email messages; downloading HTML pages or files from a Web server, or
items from within a page; Web serving, as well as managing TCP or UDP socket
communications (with or without SSL3) over the Internet. It also includes an FTP
client and a Telnet client.
Secure Socket iWiFi supports numerous security protocols like SSL3/TLS1, 64/128-
bit WEP encryption, AES-CCM and TKIP encryption, WPA (including AES) and
WPA2.
Unpacking
Take the II-EVB-361MW out of its box. Included in the box are:
The II-EVB- 361MW motherboard including Secure Socket iWiFi
(iW-SM2128MW)
A serial cable with two DB-9 connectors
Antenna
Power supply adaptor (110V/220V)
Connections
1. Connect one end of the RS232 cable to the serial port on the II-EVB-361MW
(J1) and connect the other DB-9 connector to the COM1 or COM2 serial port
on your PC, or to the serial port of your embedded device.
2. Connect the II-EVB- 361MW to the power supply.
Testing the Secure Socket iWiFi Wireless LAN Connection
To test the wireless LAN connection, you need to configure the Secure Socket iWiFi
to connect to an Access Point:
1. Make sure the Access Point is connected and configured properly.
2. Invoke the iChip Config Utility on your PC.
3. In the main window of the utility, click the Dumb Terminal icon.
4. In the Dumb Terminal window, enter the AT+i command to verify that the
iChip is communicating with your PC. You should receive an I/OK in
response.

II-EVB-361-MW User’s Manual
5
5. Enter the AT+iRP11 command to obtain a report of all the Access Points
available in your area.
6. Enter AT+iWLSI=<ssid>. ssid is the ID of the Access Point you connect to.
Note that ssid is a case-sensitive string.
7. If you want to enable WEP encryption, configure the following parameters:
AT+iWLWM=<n> where n=0 means no security, n=1 means 64-bit
key, and n=2 means 128-bit key
AT+iWLKI=<n> where nis the WEP key index (n=1..4)
AT+iWLK<n>=<keyString> where nis an index between 1 and 4, and
keyString is the WEP key string in the nth position.
8. If you want to enable WPA encryption, configure the following parameter:
AT+iWLPP=<passphrase> where passphrase is the pass-phrase to
be used in generating the WPA1-PSK encryption key
At this stage a connection to the Access Point is established. To test the
connection, use the iChip Config Utility to perform any activity that requires
network connection such as retrieving a web page, sending an email, or
opening a socket.
Installing the II-EVB-361MW Utility
and Evaluation Program
II-EVB-361MW enables you to evaluate the Secure Socket iWiFi without changing
anything in your current development environment. Using a simple terminal program
on a PC, you can issue AT+i commands to the iChip and get responses.
AT+i commands are used to configure parameter values into iChip’s flash memory
and activate Internet tasks such as email send, sockets, FTP sessions, configuration,
and more.
A full description of the AT+i protocol can be found in the AT+i Programmer’s
Manual on the Connect One website in the Documentation section at
http://www.connectone.com.
To help you evaluate the iChip, Connect One supplies the iChip Config Utility. This
is a Windows-based GUI program that contains intuitive dialog boxes to fully
configure iChip. It doesn’t require any knowledge of AT+i commands. It also
contains local firmware upgrade functionality.
The iChip Config Utility also allows you to perform specific Internet communication
tasks such as sending and receiving emails, activating iChip’s websites, entering
SerialNET mode, and more.
The latest iChip Config Utility version and user manual can be found on the
Connect One website at http://www.connectone.com in the Support section.
For more information on the iChip Config Utility and its usage, see the iChip Config
Utility User’s Manual.

II-EVB-361-MW User’s Manual
6
Connectors and Switch Positions
RS232
Host Interface
Mode
Select
Button
Reset
Button
Extension
Connector
On/Off
Switch
ANTENA
HOLDER
II-EVB-361MW
DC Jack

II-EVB-361-MW User’s Manual
7
LED Positions
Link/Act LED
Full/Col LED
Power LED
RXDH
TXDH

II-EVB-361-MW User’s Manual
8
Bill of Materials
#
Qty
Reference
Description
Manufacturer
1
6
C1,C2,C8,C9,C11,C13
100NF
Any
2
4
C3,C4,C5,C6
470NF
Any
3
2
C7,C10
1000UF/25V
Any
4
1
C12
10UF/16V
Any
5
1
C14
1NF/2KVPF
Any
6
1
D1
LLN4148
Any
7
1
D2
1N4001
Any
8
1
D3
R.LED
Any
9
5
D4,D5,D7,D8,D9
G.LED
Any
10
1
D6
MUR115
Any
11
4
3.3V,46,47,GND
TP
Any
12
1
J1
DB9 FEM
Any
13
1
J2
DC-JACK-MALE
Any
14
1
J3
RJ45
Any
15
1
J4
HEADER 4x2
Any
16
1
L1
68UH/1A
Any
17
1
R1
10k
Any
18
3
R2,R3,R4
470
Any
19
1
R5
0
Any
20
2
R6,R7
75
Any
21
1
SW1
TACK_SW
Any
22
1
SW2
PB SW
Any
23
1
SW3
SWITCH
Any
24
1
U1
Secure Socket iWiFi
Connect One
25
1
U2
SP3238ECA
Any
26
1
U3
LM2591HVS-3.3
Any
27
1
U4
SP708TCN
Any
Appendix 1: II-EVB-361MW Schematic

8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
-RES
GND
MSEL
TXDH -RTSH -DTRH RXDH -CTSH
RESET
-RES
-RTSH232 TXDH232 -CTSH232 RXDH232
TXDH232 -RTSH232 -CTSH232 RXDH232
RXDH -CTSH -RTSH TXDH
-DTRH232
-DTRH232
-DTRH
CHASSIS
-CDH
-CDH
-CDH232
-CDH232
MSEL RESET
-CDH
GND
VDD
GND
GND
VIN
GND GND
VDD
VDD
GND
GND
VDD
GND
GND
GND
GND
VDD
GND
GND GND
GND
GND
VDD
VDD
GND
VDD
VDD
GND
VDD
GND
VDD
VDDVDD
GND GND
Title Size Document Number Rev Date: Sheet of
254 1.0
IIEVB_361MW
Connect-ONE Ltd.
B
1 1Monday, June 18, 2007
Title Size Document Number Rev Date: Sheet of
254 1.0
IIEVB_361M
Connect-ONE Ltd. B
1 1Monday, June 18, 2007
Title Size Document Number Rev Date: Sheet of
254 1.0
IIEVB_361M
Connect-ONE Ltd. B
1 1Monday, June 18, 2007
RS232 TO HOST
C14
1NF/2KVPF
C14
1NF/2KVPF
D2
1N4001
D2
1N4001
2 1
+
C10
1000UF/25V
+
C10
1000UF/25V
SW2
PB SW
SW2
PB SW
LLN4148
D1
LLN4148
D1
C11
100NF
C11
100NF
R6 75 R6 75
C13 100NF C13 100NF
R4 470 R4 470
C3
470NF
C3
470NF
D7 G.LED D7 G.LED
21
SW1
TACK_SW
SW1
TACK_SW
C4 470NF C4 470NF
J4
HEADER 4x2
J4
HEADER 4x2
1 2 3 4 5 6 7 8
R1
10k
R1
10k
R5 0 R5 0
3.3V TP 3.3V TP
1
GND TP GND TP
1
U1
Socket iWIFI
U1
Socket iWIFI
N.C
2GND 63
VDD 61
CTSH 33
TXDH 34
RXDH 35
VDD 36
DTRH 37
RTSH 38
CDH 39
N.C 40
GND 41
GND
26
RES
24
TX+
4
TX-
5
RX+
6
RX-
7Link/Act/RF 58
N.C
25
N.C
28
N.C
30
N.C
32 N.C 31
N.C
29
MSEL
27
N.C
1
Full/Col 56
N.C 57 N.C 59
Speed 60
N.C 62 N.C 64
J3
RJ45
J3
RJ45
1 2 3 4 5 6 7 8 SHILD
HOLE3
SHILD
HOLE4
U3
LM2591HVS-3.3
U3
LM2591HVS-3.3
VIN
1FEEDBACK 4
ON/OFF
5
OTPUT 2
SGND
6
PGND
3
C6 470NF C6 470NF
U4
SP708TCN
U4
SP708TCN
MR
1
PFI
4
RESET 8 RESET 7
PFO 5
VCC 2
GND
3
NC 6
C1
100NF
C1
100NF
R7 75R7 75
+
C12 10UF/16V
+
C12 10UF/16V
C8 100NF C8 100NF
D3
R.LED
D3
R.LED
21
D9
G.LED
D9
G.LED
21
J1
DB9 FEM
J1
DB9 FEM
5 9 4 8 3 7 2 6 1
10 11
C9 100NF C9 100NF
+
C7
1000UF/25V
+
C7
1000UF/25V
D6
MUR115
D6
MUR115
2 1
R2 470 R2 470
D4 G.LED D4 G.LED
21
D8 G.LED D8 G.LED
21
47 TP 47 TP
1
U2 SP3238ECA U2 SP3238ECA
RIN1 8 RIN2 9 RIN3 11
TOUT1 5 TOUT2 6 TOUT3 7 TOUT4 10 TOUT5 12
ROUT1
21
ROUT2
20
ROUT3
18
TIN1
24
TIN2
23
TIN3
22
TIN4
19
TIN5
17
FORCEOFF
14
FORCEON
13
VCC 26
GND
2
C1+
28
C1-
25
C2+
1
C2-
3
V+ 27
V- 4
INVALID 15
ROUTB1
16
C2 100NF C2 100NF
J2 DC-JACK-MALE J2 DC-JACK-MALE
L1
68UH/1A
L1
68UH/1A
1
2
46 TP 46 TP
1
SW3
SWITCH
SW3
SWITCH
1 2
D5 G.LED D5 G.LED
21
R3 470 R3 470
C5
470NF
C5
470NF

II-EVB-361-MW User’s Manual
10
Appendix 2: Secure Socket iWiFi Mechanical Views

II-EVB-361-MW User’s Manual
11
Appendix 3: WiFi Configuration Notes
Introduction
Wireless LAN stations operate in one of two modes: Infrastructure or Ad-Hoc.
In Infrastructure mode, wireless LAN stations connect to a wireless LAN Access
Point (AP), which acts as a hub. Wireless LAN stations may connect to each other
through the AP. If the AP is connected to LAN, it allows wireless LAN stations to
connect to other stations on the LAN. When a gateway is in place, it enables wireless
LAN stations to connect to systems across the gateway, as well.
In Ad-Hoc mode, two or more wireless LAN stations communicate directly with each
other.
The Secure Socket iWiFi supports the 802.11b/g wireless LAN communication
platform. It uses the iChip™ CO2128 communication controller chip and Marvell
88W8686 WiFi chipset. It incorporates several dedicated AT+i configuration
parameters to support the wireless LAN environment. See the table below for a
detailed list of WiFi configuration parameters.
AT+i Parameter Name
Description
WLCH
Wireless LAN Communication Channel
WLSI
Wireless LAN System-Set ID
WLWM
Wireless LAN WEP Mode
WLKI
Wireless LAN Transmission WEP Key Index
WLKn
Wireless LAN WEP Key Array
WLPS
Wireless LAN Power Save
WLPP
Personal Shared Key Pass Phrase
WLRS
Wireless LAN Rescan Interval
Table 1: AT+i Wireless LAN Configuration Parameters
The Secure Socket iWiFi may also be configured to exploit WEP security. iChip
supports configuration of both 64-bit or 128-bit WEP keys.
In Infrastructure mode, Power Save mode is supported. When activated, Power Save
shuts down the station for a limited period of time, during which the Access Point
buffers incoming packets destined for the deactivated WiFi station. The station
periodically wakes up to retrieve all the buffered packets stored in the Access Point.
In this mode, total power consumption is lowered at the expense of higher response
latency. The Secure Socket iWiFi may be configured to put the WiFi chipset in Power
Save mode in conjunction with iChip’s inherent Power Save mode.

II-EVB-361-MW User’s Manual
12
iChip Wireless LAN Environment Configuration Parameters
WLCH (Factory Default: 0)
In Infrastructure mode, the WLCH parameter must be set to 0. Other available values
(1..13) designate the preferred communication channel while in Ad-Hoc mode.
WLSI (Factory Default: Empty)
This parameter must be assigned with the System-Set-ID string (SSID), which is
identical to that configured in the Access Point(s) through which the WiFi station
needs to connect. An exception to this is the “Any SSID” configuration, which is
configured by simply leaving this parameter empty (or setting to NULL string with
AT+iWLSI=””). In the “Any SSID” configuration, the WiFi station will connect to
any available Access Point. If more than one Access Point is active, it will choose the
one with the stronger radio signal.
WLWM (Factory Default: 0)
Configure this parameter to designate WEP security usage mode. If WEP is disabled,
the WLKI and WLKnparameter settings are irrelevant. Note that WEP settings (with
the exception of WLKI) must be identical to those configured in the Access Point
device. Possible settings are:
WLWM Setting
WEP Security
0
Disabled
1
Enabled, using 64 bit keys
2
Enabled, using 128 bit keys
Table 2: WEP Security Mode Settings
WLKI (Factory Default: 1)
If WEP is enabled, this parameter defines the key index of the WEP key to be used
when encoding outgoing WiFi packets. Since WEP includes configuration for an
array of four possible keys, WLKI can receive a value in the range [1..4]. The value of
this parameter need not be the same as that configured in the Access Point.
WLKn (Factory Default: All Empty)
These are four consecutive parameters (with nranging from 1 to 4). The parameters
define an array of 4 WEP security keys, which are used to encode outgoing WiFi
packets (using the key defined by WLKI) and decode incoming packets according to
the key issued by the Access Point device. Key size is 64- or 128-bits, according to
the WLWM setting. The parameter values are used only if WEP security is enabled
(WLWM > 0). The key values must be identical to those configured in the Access
Point device.
WLPS (Factory Default: 0)
This parameter defines the chipset Power Save mode. When configured for Power
Save mode, iChip links its own internal Power-Save mode with that of the Marvell
chipset. When iChip’s Power Save mode is activated (AT+iPSE=1), and when WLPS
is greater than 0, iChip will force the chipset into Power Save mode. The value stored
in WLPS defines the maximum length of time (in milliseconds) during which the
Marvell chipset will snooze, before waking up to download any available packets that
may have been buffered for it in the Access Point. WLPS may be set in the range:

II-EVB-361-MW User’s Manual
13
[0..3600]. When WLPS is set to 0, the Marvell chipset Power Save is disabled, even if
iChip enters Power Save mode.
WLPP (Factory Default: Empty)
This parameter sets the wireless LAN WPA1-PSK pass-phrase to be used in
generating the WPA1-PSK encryption key. When empty, WPA security is disabled. If
WLSI (SSID) is not empty, WPA1-PSK security is enabled for WiFi connections and
WLPP is used in generating the WPA1-PSK encryption key. The allowed value for
WLPP is an ASCII string containing 8-63 characters.
WLRS (Factory Default: 0)
This parameter sets the interval between consecutive scans that iChip performs in
search for nearby ad-hoc networks. Scan duration is two beacon periods (200 ms).
WLRS may be set in the range: 0-65535 milliseconds.
Wireless LAN Configuration Web Site Page
iChip’s configuration website includes two views that support configuration and
status retrieval of related Wireless LAN parameters. The configuration view displays
the configurable Wireless LAN AT+i parameters (WLCH, WLSI, WLWM, and
WLKI). New values may be defined and submitted to iChip from the browser.
Figure 1: Wireless LAN Web Configuration
Wireless LAN Status Report
The Wireless LAN AT+i Report (AT+iRP10) returns pertinent status information
regarding the active 802.11b/g Wireless LAN link. In response to issuing the report
command, iChip will reply with the following syntax:
I/(<port stat>, <xfer rate>, <sig level>, <lnk qual>)
Where,
port stat -- Port Status:
0: Wireless LAN adapter not present
1: Wireless LAN adapter Disabled
2: Searching for initial connection
4: Connected
5: Out of range
xfer rate -- Transfer Rate, in the range 1..4
(1 =>1 Mbps; 2 =>2 Mbps; 3 =>5.5 Mbps; 4 =>11 Mbps)

II-EVB-361-MW User’s Manual
14
sig lvl -- Signal Level [%], in the range 0..100
lnk qual -- Link Quality [%], in the range 0..100
The Configuration website contains a live status page with this and some additional
status information:
Figure 2: Wireless LAN Web Status Display

II-EVB-361-MW User’s Manual
15
iChip Wireless LAN Test Mode
WLTR
This command limits the wireless LAN transmission rate according to the specified
command parameter. The table below details the possible parameter values:
Maximum
Transmission Rate
Detail
0
Maximum possible transmission rate for the current chipset.
1
1 Mbps
2
2 Mbps
3
5.5 Mbps
4
11 Mbps
Table 3: Maximum Transmission Rate Command Parameter
When AT+i WLTR is issued, transmission rate is limited for the duration of the
session until another AT+iWLTR command is issued, or iChip is power-cycled.
Placement and Range Guidelines
802.11b/g wireless LAN devices connect to wireless LAN Access Points over a
maximum range of 300 feet. Actual transmission rate and service quality may vary
significantly as a result of environmental obstacles and physical placement of the
Access Point and station devices.
For best results, refer to the following guidelines:
1. Locate the wireless LAN equipment away from sources of interference, such
as PCs, large metal surfaces, microwaves, and cordless phones.
2. Position the wireless LAN access point at an elevated position and as close as
possible to the center of the area in which the wireless LAN devices will
operate.
Wireless LAN Data Privacy/Security Considerations
The fact that wireless LAN devices transmit data over a radio link makes them
vulnerable to electronic eavesdropping, tampering, and information theft. There are
several means by which you may strengthen your wireless LAN access security:
Change the factory default SSID setting of the wireless LAN Access Point and
station devices. Enable WEP or WPA encryption of the wireless LAN data
communications. If you use WEP, it is recommended that you use 128-bit
WEP keys.
Restrict 802.11b/g wireless LAN access based on MAC address. This is
configurable in most Access Point devices.
Place the 802.11b/g Wireless Access Point in a location where it cannot be
physically tampered with.
Store printed SSID and WEP or WPA key settings in a safe place.
