Connect Tech Titan/cPCI User manual

Titan/cPCI
CompactPCI Serial Communications
User Manual
Connect Tech Inc
42 Arrow Road
Guelph, Ontario
N1K 1S6
Tel: [phone]
Toll: 800-426-8979 (North America only)
Fax: [phone]
Email: [email protected]
[e-mail]
URL: www.connecttech.com
CTIM-00009, Revision 1.01 February 2006

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 ii
Limited Lifetime Warranty
Connect Tech Inc. provides a Lifetime Warranty for all Connect Tech Inc. products. Should this
product, in Connect Tech Inc.'s opinion, fail to be in good working order during the warranty
period, Connect Tech Inc. will, at its option, repair or replace this product at no charge, provided
that the product has not been subjected to abuse, misuse, accident, disaster or non Connect Tech
Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc.
business partner or to Connect Tech Inc. along with proof of purchase. Product returned to
Connect Tech Inc. must be pre-authorized by Connect Tech Inc. with an RMA (Return Material
Authorization) number marked on the outside of the package and sent prepaid, insured and
packaged for safe shipment. Connect Tech Inc. will return this product by prepaid ground
shipment service.
The Connect Tech Inc. Lifetime Warranty is defined as the serviceable life of the product. This
is defined as the period during which all components are available. Should the product prove to
be irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if
available or to retract Life Time Warranty if no replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no
circumstances will Connect Tech Inc. be liable in any way for any damages, including any lost
profits, lost savings or other incidental or consequential damages arising out of the use of, or
inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech
Inc. shall not be liable for errors contained herein or for incidental consequential damages in
connection with the furnishing, performance, or use of this material. This document contains
proprietary information that is protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated to another language without the prior
written consent of Connect Tech, Inc.
Copyright ©1997 - 2006 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights
referred to in this document as the property of their respective owners.
Not listing all possible trademarks or copyright acknowledgments does not constitute a lack of
acknowledgment to the rightful owners of the trademarks and copyrights mentioned in this
document.

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 iii
Certification Statements
Class A Computing Device
Titan/cPCI; Titan/cPCI Rear I/O; Titan/cPCI Rear I/O Opto*
FCC
This equipment complies with the requirements in Part 15 of FCC Rules for a Class A computing device.
Operation of this equipment in a residential area may cause unacceptable interference to radio and TV
reception requiring the operator to take whatever steps are necessary to correct the interference.
DOC/IC
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Connect Tech Inc. declares that the product(s) covered by the contents of this manual have been tested and
found compliant with the below listed standards as required by the Electromagnetic Compatibility (EMC)
Directive for General Immunity Compliance, EN 50 0082.1:1997
EN 55022 Conducted and Radiated emissions, Class A
EN 61000-4-2 Electrostatic Discharge
EN 61000-4-3 Radiated Immunity
EN 61000-4-4 Electrical Fast Transients
EN 61000-4-6 Conducted Immunity Test, Level 2
Connect Tech Inc. declares that the product(s) covered by the contents of this manual have been
tested and found compliant with the below listed standards as required by the Electromagnetic
Compatibility (EMC) Directive for General Immunity Compliance, EN 50 0082.1:1997
*Note: Models TN004 and TN003 are not FCC or CE certified.

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 iv
Table of Contents
Limited Lifetime Warranty................................................................................................................. ii
Copyright Notice............................................................................................................................... ii
Trademark Acknowledgment.............................................................................................................. ii
Certification Statements .................................................................................................................... iii
Titan/cPCI; Titan/cPCI Rear I/O; Titan/cPCI Rear I/O Opto ................................................................. iii
FCC ...................................................................................................................... iii
DOC/IC ................................................................................................................. iii
Table of Contents ..............................................................................................................................iv
Introduction .......................................................................................................................................1
Features: ..................................................................................................................1
Customer Support Overview ......................................................................................2
Contact Information ..................................................................................................2
Titan/cPCI Installation Overview .........................................................................................................3
Hardware Installation..........................................................................................................................3
Connecting the Titan/cPCI to your System ..................................................................3
Titan/cPCI Software..................................................................................................8
Installing the Titan/cPCI adapter in your system ..........................................................9
Titan/cPCI and Rear I/O adapters.......................................................................9
Configuring the Titan/cPCI......................................................................................10
Baud Rate Selection .......................................................................................10
RS-422/485 Line Interface ..............................................................................10
Line Termination ...........................................................................................11
Software Installation.........................................................................................................................11
Introduction ...........................................................................................................11
Appendix A: Specifications .............................................................................................................12
Operating Environment ...........................................................................................12
Power Requirements ...............................................................................................12
CompactPCI Bus Interface.......................................................................................12
Communications.....................................................................................................12
Control Signals.......................................................................................................12
Surge Suppression ..................................................................................................13
Optical Isolation .....................................................................................................13
Dimensions ............................................................................................................13
Connectors/Interface ...............................................................................................13
Appendix B: Connectors/Pinouts.....................................................................................................14
Connector Pinouts...................................................................................................14
Appendix C: Factory Settings .........................................................................................................17
Titan/cPCI Adapters................................................................................................17
Titan/cPCI Rear I/O adapters ...................................................................................17
Titan/cPCI Rear I/O Opto adapters ...........................................................................18
Appendix D: RS-422/485 Line Interface ..........................................................................................19
Titan/cPCI adapters Electrical Interface Selection ......................................................19
Full Duplex Mode (4 wire) .............................................................................20
Half Duplex RS-422/485 (2 wire) ....................................................................20
Multi-drop Slave Mode (4 wire) ......................................................................20
Line Termination ....................................................................................................21
Titan/cPCI Rear I/O Opto 2 and 4 port adapters .........................................................23
Titan/cPCI Rear I/O Opto Electrical Interface Selection .....................................25
Line Termination ...........................................................................................26
RS-422/485 Cable Wiring .................................................................................................................29

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 v
List of Tables
Table 1: DB-9 cable connector pinouts..........................................................................................................14
Table 2: DB-37 cable connector pinouts........................................................................................................15
Table 3: RJ-45 pinouts – Titan/cPCI Rear I/O Opto ......................................................................................16
Table 4: Titan/cPCI Rear I/O Opto jumper descriptions................................................................................23
List of Figures
Figure 1: Titan/cPCI two and four port adapters .......................................................................................... 4
Figure 2: Titan/cPCI Model TN004 for compatibility with 64 bit systems..................................................... 5
Figure 3: Titan/cPCI TN003 Adapter with LEDs........................................................................................... 5
Figure 4: Titan/cPCI Rear I/O two and four port adapters .......................................................................... 6
Figure 5: Titan/cPCI Rear I/O Opto two and four port adapters. ................................................................. 7
Figure 6: 10-port configuration using Front and Rear I/O........................................................................... 8
Figure 7: RS-422/485 Partial Schematic ..................................................................................................... 21
Figure 8: RS-422/485 partial schematic for Rear I/O Opto......................................................................... 27
Figure 9: RS-422/485 wiring diagram (4 wire)............................................................................................ 29
Figure 10: RS-422/485 wiring diagram (2 wire).......................................................................................... 30

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 1
Introduction
Connect Tech’s Titan/cPCI and Titan/cPCI Rear I/O adapters are high performance multi-port
serial adapters that allow you to connect up to 4 serial devices through one expansion slot.
Titan/cPCI adapters provide the high-speed interfaces between a host computer’s CompactPCI
bus and multiple external serial devices.
You must have the corresponding number of Titan/cPCI serial ports installed in the front I/O in
order to use a Titan/cPCI Rear I/O or Titan/cPCI Rear I/O Opto adapter in your system.
Titan/cPCI Rear I/O and Rear I/O Opto adapters provide the high-speed interfaces between a
host computer’s rear I/O CompactPCI bus and multiple external serial devices. Please note that
when you have a Titan/cPCI Rear I/O adapter installed the corresponding number of ports
in the front I/O section are not available.
Features:
●Two or four asynchronous serial ports from one slot
●RS-232 and RS-422/485 interfaces
●Full RS-422/485 support in the following modes:
Full Duplex Mode
Half Duplex Mode
Multi-drop Slave Mode
●16C950 UARTs
●Independent baud rate selection per port offering baud rates from 50 bps to 1.8342 Mbps
(RS-422/485) or 230.4 Kbps (RS-232), with 5, 6, 7 or 8 data bits and 1, 1.5, 2 stop bits, odd,
even, mark and space parity
●TransGuard Transient Voltage Suppression (surge suppression – IEC 1000-4 compatible),
able to withstand multiple strikes on every signal of every port (not available on the Rear
I/O Opto model)
●CompactPCI rear I/O capability (Please contact your Connect Tech Sales representative for
further information concerning the available rear I/O options for your Titan/cPCI adapter)
●Jumper selectable +5 V DC or +12 V DC output on pin 6 of the DB-9 connector (available
on Titan/cPCI Rear I/O adapters only)
●Each port is independently optically isolated to 3.0kV AC peak to peak (Titan/cPCI Rear
I/O Opto models only)
●Ability to install any number of Titan/cPCI adapters that your system can accommodate(For
Rear/IO, you can install up to the same number of Titan/cPCI Rear I/O and Rear I/O Opto
serial ports as Titan/cPCI serial ports already installed in your system.)

Titan/cPCI User’s Manual, Connect Tech Inc.
2 Revision 1.01
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the
Connect Tech reseller from which you purchased the product. In most cases the reseller can help
you with product installation and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff
can assist you. Our support section is available 24 hours a day, 7 days a week on our website at:
www.connecttech.com/sub/support/support.asp.See the contact information section below for
more information on how to contact us directly. Our technical support is always free.
Contact Information
We offer three ways for you to contact us:
Mail/Courier
You may contact us by letter at:
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
You may contact us through the Internet. Our email and URL addresses on the Internet are:
[email protected]m
[e-mail]
www.connecttech.com
Note:
Please go to the Download Zone or the Knowledge Database in the
Support Center on the Connect Tech website for product
manuals, installation guides, device driver software and
technical tips.
Submit your technical support questions to our customer
support engineers via the Support Center on the Connect Tech
website.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from
8:30 a.m. to 5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Telephone: [phone] (North America only)
Telephone: [phone] (Live assistance available 8:30 a.m. to 5:00 p.m. EST, Monday to
Friday)
Facsimile: 519-836-4878 (on-line 24 hours)

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 3
Titan/cPCI Installation Overview
There are two main stages in the installation process for your Titan/cPCI product:
1. Hardware Installation
This involves the physical connection of the Titan/cPCI hardware to your system.
2. Software Installation and Configuration of Titan/cPCI
This step installs and configures the Titan/cPCI drivers and allows you to set parameters
specific to your serial requirements.
Hardware Installation
Connecting the Titan/cPCI to your System
Before you begin, take a minute to ensure that your package includes the required components
that should have shipped with your Titan/cPCI:
•Titan/cPCI adapter and/or Titan/cPCI Rear I/O adapter (if applicable)
•Cable harness (optional with four-port models only)
•Titan/cPCI device drivers
•One CD containing software and documentation
If any of these components is missing, contact Connect Tech (See Contact Details) or your
reseller.
Please read before you install your Titan/cPCI
Some Titan/cPCI cards are designed with rear I/O capabilities.
These are 32-bit cards. The Titan/cPCI cards with rear I/O
capabilities are NOT designed for use in 64-bit backplanes. Using
these Titan/cPCI cards in a 64-bit backplane may damage the card
and/or your equipment.
If you are uncertain whether the cPCI slots in your backplane
support 32 or 64-bit cards, please consult your equipment manual
or manufacturer.
Non-rear I/O versions of the Titan/cPCI cards are available (TN004
and TN007 for example). Please contact [email protected]
for more details or [e-mail] if you have any
questions.

Titan/cPCI User’s Manual, Connect Tech Inc.
4 Revision 1.01
Titan/cPCI Adapter
2 port model
Rear I/O
Connector
CompactPCI
Bus Connector
PCI 954
Quad UART
DB-9
Connector
Port 2
Ejector
Handle
Line Termination/Bias
Jumper blocks JC, JD ½ Duplex Control
Jumper Block JA
RS-232 Select
Jumper Block JB
DB-9
Connector
Port 1
Titan/cPCI Adapter
4 port model
Rear I/O
Connector
CompactPCI
Bus Connector
PCI 954
Quad UART
DB-37
Connector
Ejector
Handle
Jumper blocks
JC, JD, JE, JF ½ Duplex Control
Jumper Block JA
RS-232 Select
Jumper Block JB
Figure 1: Titan/cPCI two and four port adapters

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 5
Figure 2: Titan/cPCI Model TN004 for compatibility with 64 bit systems
Titan/cPCI TN003
A
dapter
(front panel LEDs)
Rear I/O
Connector
CompactPCI
Bus Connector
PCI 954
Quad UART
Tx/Rx LEDs
Ejector
Handle
Jumper blocks
JC, JD, JE, JF ½ Duplex Control
Jumper Block JA
RS-232 Select
Jumper Block JB
Figure 3: Titan/cPCI TN003 Adapter with LEDs
Titan/cPCI Adapter Model TN004
(Compatible with 64 bit systems)
CompactPCI
Bus Connector
PCI 954
Quad UART
DB-37
Connector
Ejector
Handle
Jumper blocks
JC, JD, JE, JF ½ Duplex Control
Jumper Block JA
RS-232 Select
Jumper Block JB

Titan/cPCI User’s Manual, Connect Tech Inc.
6 Revision 1.01
Figure 4: Titan/cPCI Rear I/O two and four port adapters
J1
J2
J4
Titan/cPCI Rear I/O
2
p
ort model
J1
J2
J3
Ejector
Handle
DB-37
Connector
Ejector
Handle
Rear I/O
Connector
Rear I/O
Connector
DB-9
Connector
Port 2
DB-9
Connector
Port 1
Titan/cPCI Rear I/O
4 port model
Jumper J1
+5/+12V Select
Jumper J2
DSR/Power Select (Ports 1 & 2)
Jumper J3
DSR/Power Select (Ports 3 & 4)
Jumper J4
Direct GND
J4
Jumper J1
+5/+12V Select
Jumper J2
DSR/Power Select (Ports 1 & 2)
Jumper J4
Direct GND

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 7
Figure 5: Titan/cPCI Rear I/O Opto two and four port adapters.
Ejector
Handle
Ejector
Handle
Rear I/O
Connector
Rear I/O
Connector
Titan/cPCI Rear I/O Opto
2 port model
Titan/cPCI Rear I/O Opto
4 port model
RJ-45 Connector
Port 2
RJ-45 Connector
Port 1
RJ-45 Connector
Port 2
RJ-45 Connector
Port 1
RJ-45 Connector
Port 3
RJ-45 Connector
Port 4
Jumpers JA, JB, JC, JD
RS-232/RS-422/485 Select
RS-422/485 Mode Control
TxD, RxD, CTS, RTS
termination & bias
Jumpers JA, JB
RS-232/RS-422/485 Select
RS-422/485 Mode Control
TxD, RxD, CTS, RTS
termination & bias

Titan/cPCI User’s Manual, Connect Tech Inc.
8 Revision 1.01
You can combine different Titan/cPCI and Titan/cPCI Rear I/O adapters in a single computer to
accommodate both small and large multi-channel applications. The figure below represents a
sample configuration for a system requiring 10 ports.
Host Computer
Printer Modem Terminals
Titan/cPCI
4 port model
Titan/cPCI
2 port model
Printer Modem
Printer Modem Terminals
Titan/cPCI Rear I/0 Opto
2 port model
Titan/cPCI
4 port model
Figure 6: 10-port configuration using Front and Rear I/O
Note:
When you have a Titan/cPCI Rear I/O adapter installed the
corresponding number of Titan/cPCI ports in the front I/O section are
not available.
Titan/cPCI Software
To install your Titan/cPCI adapter under different operating systems see Software Installation.

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 9
Installing the Titan/cPCI adapter in your system
Titan/cPCI and Rear I/O adapters
To install your Titan/cPCI or Rear I/O adapter in your computer follow these steps:
1. Turn off the power to your computer.
2. Remove the Titan from its packaging, and remove the protective rubber from the alignment
pins on the Titan’s front panel.
3. Insert your Titan/cPCI into an available front 3U slot or insert your Titan/cPCI Rear I/O
adapter into an available rear 3U slot. The black handle on the front panel should be on the
bottom, in the lowered position.
4. Push the Titan into the cPCI slot until the handle mates with the card cage. Lift the handle to
lock the Titan into place.
5. With a screwdriver, fasten the screw on the top of the panel into the card cage for added
mechanical security.
Your Titan/cPCI and Rear I/O adapters are very sensitive to static
electricity. Make sure you wear an anti-static wristband before you
remove the card from the anti-static shipping bag. When you remove
the board from the anti-static bag, handle it only by the edges and
place it on the anti-static bag or an anti-static mat.

Titan/cPCI User’s Manual, Connect Tech Inc.
10 Revision 1.01
Configuring the Titan/cPCI
Compact Peripheral Component Interconnect (cPCI) bus architecture offers a feature called Plug
and Play (sometimes referred to as PnP). This feature automatically identifies and configures
installed devices each time the system boots.
In most CompactPCI compliant computers, the system BIOS will automatically detect and
configure the Titan/cPCI adapter. However in some cases a system BIOS cannot resolve all of
the requests for resources in the system. This often occurs with the assignment of system
interrupts, since this is usually the scarcest resource.
If this occurs, the driver will signal that a given resource has not been assigned, which requires
the user to assign system resources manually. After reboot, determine with the BIOS setup
utility what resources have been assigned to the cPCI devices and then do manual assignments
of free resources to your cPCI device. Reboot your system. If the BIOS cannot find a suitable
configuration please contact Connect Tech Technical Support.
Important Configuration Note:
The Titan/cPCI and the Titan/cPCI with front LEDs must be configured
for RS-485 to operate with the Titan Rear I/O Opto. This is configured
via jumper blocks on the Rear I/O Opto. You must remove ALL
jumpers on the front I/O Titan/cPCI when you are using the Rear
I/O Opto.
Baud Rate Selection
Titan/cPCI adapters offer ideal solutions for applications requiring serial communications up to
1.8432 Mbps. Baud rates are software selectable; please refer to Software Installation for
configuring the baud rates under certain operating systems.
RS-422/485 Line Interface
The Titan/cPCI adapters and Rear I/O Opto adapters come with a jumper selectable RS-422/485
electrical line interface for each port. The RS-422/485 electrical interface is a reliable high-
speed serial link that offers superior noise immunity and multi-drop network connectivity. The
RS-485 electrical interface is also a superset of the RS-422 electrical interface. Titan/cPCI and
Titan/cPCI Rear I/O Opto adapters offer full RS-422/485 support in hardware. The following
modes are supported:
Full Duplex Mode
In this mode, TxD & RxD are active all the time. This mode is typically used in point to point
situations much like RS-232. Please refer to Appendix D: RS-422/485 Line Interface for the
jumper settings associated with this function.
Half Duplex Mode
In this mode the TxD line driver is enabled only when data is transmitted and RxD is disabled
when data is being transmitted. This mode is typically used in either point to point "2 wire"
connections OR in multi-drop "2 wire" bussed connections. Please refer to Appendix D:
RS-422/485 Line Interface for the jumper settings associated with this function.

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 11
Multi-drop Slave Mode
In this mode the TxD line driver is enabled only when data is transmitted and RxD is enabled all
the time. This mode is typically used in multi-drop "4 wire" connections. Please refer to
Appendix D: RS-422/485 Line Interface for the jumper settings associated with this function.
Line Termination
You can terminate and bias TxD +/-, RxD +/-, RTS +/-, and CTS +/- on the individual
RS-422/485 ports through jumper selectable 150 Ω fixed resistors. Please refer to Appendix D:
RS-422/485 Line Interface for the jumper settings associated with this function.
Software Installation
Introduction
Titan/cPCI boards are standard multi-port serial adapters that utilize 16C950 UARTs. In many
cases, users have software that will interface directly to the Titan/cPCI boards. Many operating
systems come with handlers to control access to multiple 8250 style UARTs. Titan/cPCI
adapters currently ship with device drivers for the following operating systems:
QNX 4
QNX 6
Windows NT
Linux
Before installing the Titan/cPCI software device driver, verify and note jumper settings
described in Appendix D: RS-485/422 Line Interface for:
Jumper block JA – Full duplex, half duplex and multi-drop slave control
Jumper block JB – RS-232, RS-485/422 select
Jumper blocks JC, JD, JE and JF – line bias/termination.
If you require further information please contact Connect Tech Technical Support.
Technical Tips:
Your Titan/cPCI adapter may ship with diskettes that include howto.txt
or readme.txt files. Please examine these files for technical tips or
release notes concerning installation and configuration of various
device drivers and software utilities.
If you did not receive a driver diskette for your operating system or you
require additional information, please go to the Download Zone of the
Support Center on the Connect Tech website for product manuals,
installation guides, diagnostic utilities and device driver software.

Titan/cPCI User’s Manual, Connect Tech Inc.
12 Revision 1.01
Appendix A: Specifications
Operating Environment
Storage temperature: -65°C to 150°C
Operating temperature: 5°C to 70°C
Relative humidity: 5 - 95% non-condensing
Air movement: no requirement
Altitude: 15,000 feet (5000 meters)
Power Requirements
Titan/cPCI, Titan/cPCI Rear I/O (2 port models):
+5 VDC +/-5% @ 350 mA typical
Titan/cPCI, Titan/cPCI Rear I/O (4 port models):
+5 VDC +/-5% @ 550 mA typical
Titan/cPCI Rear I/O Opto (2 port model):
+5 VDC +/-5% @ 425 mA typical
Titan/cPCI Rear I/O Opto (4 port model):
+5 VDC +/-5% @ 900 mA typical
CompactPCI Bus Interface
Titan/cPCI: One 3U cPCI slot
Titan/cPCI Rear I/O: One 3U cPCI rear I/O slot
Communications
UARTs
•16C950 UARTs with 128 byte TxD/RxD FIFO buffers
RS-232
•Programmable baud rate generator: up to 230.4 Kbps on all ports
RS-422/485
•Programmable baud rate generator: up to 1,843.2 Kbps on all ports
Control Signals
Titan/cPCI
RS-232:RTS; DTR; TxD; DCD; CTS; RxD, DSR, RI
RS-422/485: RTS+/-; TxD+/-; CTS+/-; RxD+/-
Titan/cPCI Rear I/O
RS-232: RTS; DTR; TxD; DCD; CTS; RxD, DSR or +5V or +12V, RI
RS-422/485: RTS+/-; TxD+/-; CTS+/-; RxD+/-

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 13
Surge Suppression
TransGuard Transient Voltage Suppression, able to withstand multiple strikes on every signal
of every port.
Transient Energy dissipation 0.1 joules on every signal of every port
Transient peak current dissipation 40A on every signal of every port
EN61000-4-2/3/4 compatible
Optical Isolation
Titan/cPCI Rear I/O Opto (2 & 4 port models):
3.0kV AC peak to peak on every signal of every port.
Dimensions
3U cPCI compliant
Connectors/Interface
Titan/cPCI & Titan/cPCI Rear I/O (2 port model):
Male DB-9
Titan/cPCI & Titan/cPCI Rear I/O (4 port model):
Optional cable harness with DB-37 to four male DB-9 connectors
Titan/cPCI Rear I/O Opto (2 & 4 port models):
RJ-45
Other connection options are available upon request. Contact Connect Tech for details.

Titan/cPCI User’s Manual, Connect Tech Inc.
14 Revision 1.01
Appendix B: Connectors/Pinouts
Connector Pinouts
Tables 1 and 2 outline the pinouts for the Titan/cPCI and Titan/cPCI Rear I/O connectors or
cable connectors.
Technical Tip:
Please ensure that you terminate signals if your application does not
use them. Failure to do so may result in a loss of a performance on
your Titan/cPCI adapter.
Table 1: DB-9 cable connector pinouts
Pin
No. RS-232 Signal Direction RS-422/485 Signal Direction
1 DCD input RxD (+) input
2 RxD input RxD (-) input
3 TxD output TxD (+) output
4 DTR output TxD (-) output
5 SG signal ground SR signal reference
6 DSR
or +5V **
or +12V **
input CTS (-) input
7 RTS output RTS (+) output
8 CTS input CTS (+) input
9 RI input RTS (-) output
** This option is jumper selectable on
the Titan/cPCI Rear I/O adapter
only.
Male DB-9 Connector
15
69
Cable Part Number: CAB04DX
Technical Tip:
Please ensure that you terminate the DCD or CTS signals if your
application does not use them. The common way to do this is to
connect DCD to DTR and/or to connect CTS to RTS. Failure to do so
may result in a loss of performance.

Titan/cPCI User’s Manual, Connect Tech Inc.
Revision 1.01 15
Table 2: DB-37 cable connector pinouts
Pin
No.
Port
No.
RS-232
Signal Direction
RS-422/485
Signal Direction
1 1 SG signal gnd SR signal ref
2 1 DTR output TxD- output
3 1 TxD output TxD+ output
4 1 RxD input RxD- input
5 1 DCD input RxD+ input
6 unused unused
7 3 RI input RTS- output
8 3 CTS input CTS+ input
9 3 RTS output RTS+ output
10 3 DSR
or +5V or +12V **
input CTS- input
11 4 RI input RTS- output
12 4 CTS input CTS+ input
13 4 RTS output RTS+ output
14 4 DSR
or +5V or +12V **
input CTS- input
15 2 SG signal gnd SR signal ref
16 2 DTR output TxD- output
17 2 TxD output TxD+ output
18 2 RxD input RxD- input
19 2 DCD input RxD+ input
20 1 RI input RTS- output
21 1 CTS input CTS+ input
22 1 RTS output RTS+ output
23 1 DSR
or +5V or +12V **
input CTS- input
24 3 SG signal gnd SR signal ref
25 3 DTR output TxD- output
26 3 TxD output TxD+ output
27 3 RxD input RxD- input
28 3 DCD input RxD+ input
29 4 SG signal gnd SR signal ref
30 4 DTR output TxD- output
31 4 TxD output TxD+ output
32 4 RxD input RxD- input
33 4 DCD input RxD+ input
34 2 RI input RTS- output
35 2 CTS input CTS+ input
36 2 RTS output RTS+ output
37 2 DSR
or +5V or +12V **
input CTS- input
** This option is jumper selectable on the
Titan/cPCI Rear I/O adapters only.
Cable Part Number: CAB04DX
