DATENBLATT
RRY-4(FIT)GY

Ver.1.01
RRY-4(FIT)GY 1
F&eIT Series
Reed Relay junction Output Module
RRY-4(FIT)GY
* Specifications, color and design of the products are subject to change
without notice.
This product is an expansion module (device module) to add a reed relay
contact output interface to a variety of controllers. Congratulations on
your recent purchase of an Isolated Analog Input Module.
The RRY-4(FIT)GY can be connected to the F&eIT series of controller
modules (such as the
CPU-CAxx(FIT)GY and CPU-SBxx(FIT)GY) to construct a system.
The RRY-4(FIT)GY can perform a maximum of 4 points of relay output
per module.
*1 This module is available in different product models. "x" in each model number represents a blank or one
alphanumeric character. This is applicable to the rest of this document.
Features
Capable of providing up to four independent channels of common
reed relay contact output
High-capacity output rating designed to be a maximum of 125
VAC/30 VDC, 2 A per channel
A rotary switch allows you to set device IDs, making it easy to keep
track of device numbers.
Like other F&eIT series products, the module has a 35mm DIN rail
mounting mechanism as standard. A connection to a controller
module can be effected on a lateral, stack basis in a unique
configuration, which permits a simple, smart system configuration
without the need for a backplane board.
Packing List
Module [RRY-4(FIT)GY] …1
First Step Guide … 1
Disk *1 [F&eIT Series Setup Disk] …1
Interface connector plug …1
Warranty Certificate …1
Serial number Label …1
*1 The bundled disk contains various software and User’s Manual.
Specifications
Specifications
Item Specifications
Output section
Number of output signal points
4 points
Output format
Reed relay contact (1 make output) output
Relay contact
specifications
Maximum allowable
voltage
125VAC, 30VDC (Max.)
Maximum switching
current
2A (Max.)
Contact resistance
30mΩor less
Response time
7msec or less
Mechanical life
20 million times or more (switching frequency: 180 times/minute)
Electrical life
100,000 times or more (switching frequency: 20 times/minute)
Relays used
PA1a-5V
Common section
Internal power consumption
5VDC (±5%) 150mA (Max.) *1
Allowable distance of signal
extension
Approx. 50m (depending on wiring environment)
Physical dimensions (mm)
25.2(W) x 64.7(D) x 94.0(H) (exclusive of protrusions)
Weight (module itself)
100g
Module connection method
Stack connection by means of a connection mechanism standard with
the system.
Module installation method
One-touch connection to 35mm DIN rails
(standard connection mechanism provided in the system)
Applicable wire
AWG 28 - 16
Applicable plug
FRONT-MC 1,5/12-STF-3,81 (made by Phoenix Contact Corp.)
Standard
VCCI Class A, FCC Class A,
CE Marking (EMC Directive Class A, RoHS Directive)
*1 The stack connector accepts currents of up to 3.0A (Max.).
Installation Environment Requirements
Parameter
Requirement description
Operating temperature
0 - 50°C
Storage temperature
-10 - 60°C
Operating humidity
10 - 90%RH (No condensation)
Floating dust particles
Not to be excessive
Corrosive gases
None
Line-Noise
resistance
Line-noise *1
AC line/2kV, Signal line/1kV (IEC1000-4-4Level 3, EN61000-4-4Level 3)
Static electricity
resistance
Contact discharge/4kV (IEC1000-4-2Level 2, EN61000-4-2Level 2)
Atmospheric discharge/8kV (IEC1000-4-2Level 3, EN61000-4-2Level 3)
Vibration
resistance
Sweep resistance
10 - 57Hz/semi-amplitude 0.15mm, 57 - 150Hz/2.0G
80minutes each in X, Y, and Z directions
(JIS C0040-compliant, IEC68-2-6-compliant)
Impact resistance
15G, half-sine shock for 11ms in X, Y, and Z directions
(JIS C004-compliant, IEC68-2-27-compliant)
*1 In POW-AD22GY use.
When connecting one of the modules to a controller module, the internal power consumption should be
taken into account. If the total current exceeds the capacity of the power supply unit, the integrity of the
operation cannot be guaranteed. For further details, please see the Controller Module manual.
CAUTION

Ver.1.01
RRY-4(FIT)GY 2
Physical Dimensions
Functions and control method by controller
connected
The RRY-4(FIT)GY can be connected to a variety of controllers.
Supported controllers
Microcontroller Unit : CPU-SBxx(FIT)GY
I/O Controller Module : CPU-CAxx(FIT)GY
Monitoring & Control Server Unit : SVR-MMF2(FIT)
Check each controller to which the module can be connected as well as
the method of controlling the module when connected to that controller.
Connections to controllers
Control method by controller connected
* The API-SBP(W32) is included in the development kit [DTK-SBxx(FIT)GY]; the other drivers are bundled with
each controller.
Control using the I/O address map
When connected to the CPU-SBxx(FIT)GY, the RRY-4(FIT)GY can receive
I/O instructions directly from the controller module. For details, see
Chapter 4 “Using the I/O Address Map”.
Control using the memory address map
When connected to the CPU-CAxx(FIT)GY, the RRY-4(FIT)GY can be
accessed from the host computer over the network. The RRY-4(FIT)GY
is assigned with its device ID in the memory managed by the controller
module. The application running on the host computer controls the
module by reading/writing the memory managed by the controller
module. For details, see Chapter 5 “Using the Memory Address Map”.
Control via the Windows driver
For the functions and settings available when using the Windows driver,
refer to the reference manual and online help for each module.
Control over the web
You can monitor collected data and manage the log over the web. You
can use your familiar browser to easily make various settings. For
details, refer to the reference manual for the SVR-MMF2(FIT).
Interface Connector
How to Connect an Interface Connector
When connecting the Module to an external device, you can use the
supplied connector plug.
To wire each terminal, strip the wire about 9 - 10 mm from the end and
insert it into the opening. After inserting the wire, tighten the screw to
fasten it. Compatible wires are AWG 28 - 16. Tightening torque of
wires is 0.22Nm.
Removing the connector plug by grasping the cable can break the wire.
Signal Layout on the Interface Connector
The Module can be connected to an external device using a 12-pin
connector that is provided on the Module face.
(1.2)
25.2 64.7 4.0
3.5
(1.2)
[mm]
94.0
14.035.045.0
14.0 31.5
RRY-4
OUT3( - )
NC
OUT3(+)
OUT2( - )
NC
OUT2(+)
10 10 3
23 2
NC
OUT1( - )
NC
OUT1(+)
OUT0( - )
OUT0(+)
Device
ID
OUT
0
4
0
4
6
2
5
1
3
7
O: Permitted
×: Not permitted
CPU-SBxx(FIT)GY
CPU-CAxx(FIT)GY
SVR-MMF2(FIT)
SVR-MMF(FIT)GY
RRY-4(FIT)GY Ο Ο Ο ×
Device ID setting range 0 - 7 0 - 7 0 - 7 0 - 7
CPU-SBxx(FIT)GY
CPU-CAxx(FIT)GY
SVR-MMF2(FIT)
SVR-MMF(FIT)GY
Control using the I/O address map Ο
Control using the memory address map Ο
FIT Protocol Ο
API-CAP(W32) Ο
API-SBP(W32) Ο
Control over the web
(as set from within the browser)
Ο
Control via the Windows driver *
RRY- 4
OUT3( - )
NC
OUT3(+)
OUT2( - )
NC
OUT2(+)
10 10 32 32
NC
OUT1( - )
NC
OUT1(+)
OUT0( - )
OUT0(+)
Device
ID
OUT
0
4
0
4
6
2
5
1
3
7
Applicable plug (bundled):
Front screw type with connector stopper flange
FRONT-MC 1,5/12-STF-3,81 [made by Phoenix Contact Corp.]
Applicable wire: AWG28-16
Push this section to insert
the wire material.
9 - 10mm
CAUTION
OUT0(+)---
N.C.--- Unconnection
OUT1(+)---
OUT1(-)---
OUT2(+)---
N.C.--- Unconnection
OUT3(+)---
OUT3(-)---
N.C.--- Unconnection
OUT0(-)---
OUT2(-)---
N.C.--- Unconnection
Relay contact output 0ch [+
]
Relay contact output 0ch [-]
Relay contact output 1ch [+
]
Relay contact output 1ch [-]
Relay contact output 2ch [+
]
Relay contact output 2ch [-]
Relay contact output 3ch [+
]
Relay contact output 3ch [-]
