contoure RV-WD900W User manual

Digital Extra-Large Capacity
Ventless, Washer/Dryer Combo
OWNER’S MANUAL
Model RV-WD900W (White)
RV-WD900S (Titanium)
Read This Manual
Inside you will nd many helpful hints on how to use and maintain your washing machine
properly. Just a little preventative care on your part can save you a great deal of time and
money over the life of your washing machine. You’ll nd many answers to common problems
in the chart of troubleshooting tips. If you review the chart of Troubleshooting Tips rst, you may
not need to call for service.
Before using your washing machine,please read this manual carefully and keep
it for future reference.

Front Loading Combo Model No.: RV-WD900W (WHITE)
SAFETY AND PRECAUTIONS
Safety and precautions
This manual contains important information on the installation, use,
and care of your appliance. Please read this manual carefully
before installation and operation of this machine to prevent injury
and property damage.
What You Need To Know About Safety Instructions
Warnings and Important Safety Instructions in this manual DO NOT
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution and care when
installing, maintaining and operating your washer.
Important Safety Symbols And Precautions
WARNING
This indicates that hazards or unsafe practices may cause serious
personal injury or death. To reduce the risk of re, explosion, electric
shock, or personal injury when using your washer, these basic safety
precautions SHOULD be followed.
State of California Proposition 65 Warnings
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the State of California to cause cancer,
birth defects, or other reproductive harm, and requires
business to warn of potential exposure to such substances.
This product contains a chemical known to the State of
California to cause cancer, birth defects, or other reproductive
harm. This appliance can cause low-level exposure to some
of the substances listed, including benzene, formaldehyde,
and carbon monoxide.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
IMPORTANT SAFETY INSTRUCTIONS
WARNING - To reduce the risk of re, electric shock, or injury to
persons when using your appliance, follow basic
precautions, including the following:
- Read all instructions before using the appliance.
- Do not wash articles that have been previously cleaned in, washed
in, soaked in,or spotted with gasoline, dry-cleaning solvents, or
other ammable or explosive substances, as they give off vapours
that could ignite or explode.
- Do not add gasoline,dry-cleaning solvents, or other ammable or
explosive substances to the wash water. These substances give off
vapours that could ignite or explode.
- Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using a washing machine,
turn on all hot-water faucets and let the water ow from each
for several minutes. This will release any accumulated hydrogen
gas. As the gas is ammable, do not smoke or use an open ame
during this time.
- Always unplug the washing machine from the power supply
before attempting any service. Disconnect the power cord by
grasping the plug, not the cord.
- To reduce the risk of re, clothes, cleaning rags, mop heads and
the like which have traces of any ammable substance, such
as vegetable oil, cooking oil, petroleum based oils or distillates,
waxes, fats, ect., must not be placed in the washing machine.
These items may contain ammable substances which, even after
washing, may smoke or catch re.
- Never place items in the washer that have been dampened with
gasoline or any combustible or explosive substance. Do not wash
or dry anything that has been soaked in or spotted with any type
of oil(including cooking oils). Doing so can result in re , explosion,
or death.
- Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
- Pets and kids may climb into the machine. Check the machine
before every operation.
- Glass door or protector may be very hot during the operation. Keep
kids and pets far away from the machine during the operation.

Front Loading Combo Model No.: RV-WD900W (WHITE)
- This machine is not intended for use by persons (including kids)
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the machine by a
person responsible for their safety.
- Kids should be supervised to ensure that they do not play with the
machine.
- When children become old enough to operate the appliance, it is
legal responsibility of the parents or legal guardians to ensure that
they are instructed in safe practices by qualied persons.
- Do not machine wash berglass materials (such as curtains and
window coverings that use berglass materials.)Small particles may
remain in the washing machine and stick to fabrics in subsequent
wash loads causing skin irritation.
- Before the appliance is removed from service or discarded,
remove the door and cut off the power cord.
- Do not reach into the appliance if the tub or agitator is moving.
- Do not install or store this appliance where it will be exposed to
the weather.
- Do not tamper with controls.
- Do not repair or replace any part of the appliance or attempt
any servicing unless specically recommended in the user-
maintenance instructions or in published user-repair instructions
that you understand and have the skills to carry out.
- Never stop a tumble dryer before the end of the program and
spread out so that the heat is dissipated.
- Pull out its plug from the power socket before cleaning or
maintenance.
- Make sure that all pockets are emptied.
- Sharp and rigid items such as coin, brooch, nail, screw or stone
etc. may cause serious damages to this machine.
- Pull out its plug and cut off water supply after the operation.
- Please check whether the water inside the drum has been drained
before opening its door. Please do not open the door if there is
any water visible,
- Do not try to repair the machine by yourself. The machine may be
damaged or more troublesome repair work may be caused and
even dangerous operation may take place if it is repaired by any
inexperienced or unqualied staff.
- If the plug (power cord) is damaged, it shall be replaced by the
manufacturer or a service agent to avoid any danger.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
- Take care that power voltage and frequency shall be identical to
those of washing machine.
- Do not use any socket with rated current less than that of washing
machine. Never pull out power plug with wet hand.
- To ensure your safety, power cord plug must be inserted into an
earthed three pole socket. Check carefully and make sure that
your socket is properly and reliably earthed.
- This machine shall be repaired only by an authorized service
center and only authentic accessories can be used.
- An appliance shall be clearly and permanently marked with a
warning that the appliance is intended for use only with fabrics
that have been washed with water as a cleaning agent.
- To reduce the risk of re, do not dry articles containing foam
rubber or similarly textured rubber like materials.
- If connected to a circuit protected by fuses, use time-delay fuses
with this appliance.
- Do not dry articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents,or
other ammable or explosive substances, as they give off vapours
that could ignite or explode.
- Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or
product.
- Do not use heat to dry articles containing foam rubber or similarly
textured rubber-like materials. The interior of the appliance should
be cleaned periodically by qualied service personnel.
- Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch re.

Front Loading Combo Model No.: RV-WD900W (WHITE)
Grounding instructions
- This appliance must be grounded . In the event of a malfunction
or breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for the electric current. This
appliance is equipped with a cord that has an equipment
- gurounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING - Improper connection of the equipment grounding
conductor can result in electric shock. Connect to
individual branch Circuit. Check with a qualied
electrician or serviceman if you are in doubt as to
whether the washer is properly grounded.
DO NOT modify the plug provided with the appliance if it will not t
the outlet .
Please have a proper outlet installed by a proper outlet installed by
a qualied electrician.
Before ope r a ting this machine
- Packing materials may be dangerous to the kids. Please keep all
packing materials (plastic bags, foams etc) far away from the kids.
- Washing machine shall not be installed in bath room or very wet
rooms as well as in the rooms with explosive or caustic gases.
- Make sure that the water and electrical devices must be
connected by a qualied technician in accordance with the
manufacturer’s instructions and local safety regulations.
- Before operating this machine, all packages and transport bolts
must be removed. Otherwise,the washing machine may be
seriously damaged while washing the clothes.
- Before washing the clothes at rst time,the washing machine shall
be operated in cotton and hot water procedures without the
clothes inside .
- This washing machine is for indoor use only. Attention shall be paid
to protecting the machine
Attention shall be paid to protecting the machine
- Do not climb up and sit on top cover of the machine.
- Do not lean against machine door.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
- Please do not close the door with excessive forces. If it is found
difcult to close the door, please check if the excessive clothes
are put in or distributed well.
Cautions during Handling Machine
WARNING
- Transport bolts shall be reinstalled to the machine by a
specialized person.
- The accumulated water shall be drained out of the machine.
- Handle the machine carefully. Never hold each protruded part
on the machine while lifting.
Machine door can not be used as the handle during the
conveyance.
Cautions when washing clothes
- Cold city water shall be used and hot water may be also
connected according to the local situations.
- Your washing machine is only for home use and is only designed
for the textiles suitable for machine washing.
- Flammable and explosive or toxic solvents are forbidden. Gasoline
and alcohol etc. shall not be used as detergents. Please only
select the detergents suitable for machine washing, especially for
front loading.
- It is forbidden to wash carpets.
- Be careful of burning when washing machine drains hot washing
water.
- Never rell the water by hand during washing.
- After the program is completed, please open the door after the
bell or disconnect the power supply to the machine.
- Please remember to disconnect water and power supply
immediately after the clothes are washed.
- Always follow the fabric care instructions recommended by the
clothing manufacturer.
- Do not use the washing machine if it has a worn power cord or
loose plug. Contact an authorized service agent.
- Do not operate the washing machine if any guards, panels and
/or fasteners except transport xing bolts have been removed.
Check the ll hose connections on a regular basis to ensure that
they are tight and not leaking.

Front Loading Combo Model No.: RV-WD900W (WHITE)
- Do not operate the washing machine if parts are missing or broken.
- Do not touch the door if washing at high temperatures.
Note;
- The Important Safeguards and Warnings indicated in this manual
do not cover all possible conditions which may occur. Common
sense, caution and care must be exercised when installing,
maintaining or operating the washing machine.
- Always contact your dealer, distribute, service agent or the
manufacturer about any problems or conditions that you do not
understand.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
INSTALLATION REQUIREMENTS
Installation requirements
1. This machine must be earthed properly. If there is any short
circuit, earthing can reduce the danger of electrical shock.
This machine is equipped with power cord, which includes
plug, earthing wire at earthing terminal.
2. Washing machine shall be operated in a circuit separate
from other electrical appliances. Otherwise, power protector
may be tripped or fuse may be burned out.
WARNING – Risk of Fire
Clothes dryer installation must be performed by a qualied installer.
Install the clothes dryer according to the manufacturer’s instructions
and local codes.
These conditions will obstruct clothes dryer airow and increase the
risk of re.
To reduce the risk of severe injury or death, follow all installation
instructions. Save these instructions.
Failure to comply with these warnings could result in serious personal
injuries. Note: Environmental Protection
- If you plan to dispose this machine, please comply with the local
waste disposal regulations. Cut off the power cord so that it will
not be put into reuse.
Remove the door so that kids and animals will not be trapped in
the machine.
- Do not use excessive detergents.
- Decontaminant and bleacher can be used to pre-treat the stains
on the clothes only when very necessary.
Tools and parts
Gather the required tools and parts before starting installation. The
parts supplied are in the washer drum.
1/4 nut driver 3/8 socket with ratchet
3/8″ open end wrench
Adjustable wrench or 7/16″ socket with ratchet
Adjustable wrench or 9/16″ open- end wrench
Channel- lock adjustable pliers
Carpenter’s level
P.07 P.08
Gather the required tools and parts before starting installation. The parts supplied are in the
washer drum.
Installation Requirements
Transport Hole Plug
1/4 nut driver 3/8 socket with ratchet
3/8″ open end wrench
Adjustable wrench or 7/16″ socket with ratchet
Adjustable wrench or 9/16″ open-end wrench
Channel-lock adjustable pliers
Carpenter’s level
″ ″
-
Water Hoses(2)
Failure to comply with these warnings could result in serious
personal injuries.Note:Environmental Protection
- If you plan to dispose this machine, please comply with the local waste disposal
regulations. Cut off the power cord so that it will not be put into reuse.
Remove the door so that kids and animals will not be trapped in the machine.
- Do not use excessive detergents.
- Decontaminant and bleacher can be used to pre-treat the stains on the clothes
only when very necessary.
Safety And Precautions
WARNING – Risk of Fire
Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer’s instructions and local
codes.
These conditions will obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
Save these instructions.
1.This machine must be earthed properly. If there is any short circuit, earthing can
reduce the danger of electrical shock.
This machine is equipped with power cord, which includes plug, earthing wire at
earthing terminal.
2.Washing machine shall be operated in a circuit separate from other electrical
appliances. Otherwise, power protector may be tripped or fuse may be burned
out.
Installation requirements
WARNING
Tools and parts
Cautions when washing clothes
- Cold city water shall be used and hot water may be also connected according to
the local situations.
- Your washing machine is only for home use and is only designed for the textiles
suitable for machine washing.
- Flammable and explosive or toxic solvents are forbidden. Gasoline and alcohol
etc. shall not be used as detergents. Please only select the detergents suitable
for machine washing, especially for front loading .
- It is forbidden to wash carpets.
- Be careful of burning when washing machine drains hot washing water.
- Never refill the water by hand during washing.
- After the program is completed, please open the door after the bell or
disconnect the power supply to the machine.
- Please remember to disconnect water and power supply immediately after the
clothes are washed.
- Always follow the fabric care instructions recommended by the clothing
manufacturer.
- Do not use the washing machine if it has a worn power cord or loose plug.
Contact an authorized service agent.
- Do not operate the washing machine if any guards, panels and /or fasteners
except transport fixing bolts have been removed. Check the fill hose
connections on a regular basis to ensure that they are tight and not leaking.
- Do not operate the washing machine if parts are missing or broken.
- Do not touch the door if washing at high temperatures.
Note;
- The Important Safeguards and Warnings indicated in this manual do not cover
all possible conditions which may occur. Common sense, caution and care
must be exercised when installing, maintaining or operating the washing
machine.
- Always contact your dealer, distribute, service agent or the manufacturer
about any problems or conditions that you do not understand.
WARNING

Front Loading Combo Model No.: RV-WD900W (WHITE)
Location requirements
Selecting the proper location for your washer improves performance
and minimizes noise and possible washer “walk.”Your washer can
be installed under a custom counter,or in a basement, laundry
room, closet, or recessed area. See “Drain System.”Companion
appliance location requirements should also be considered. Proper
installation is your responsibility.
You will need
1. A water heater set to deliver 1 2 0°F ( 49°C) water to the washer.
2. A grounded electrical outlet located within 6 ft.( 1.8 m) of where
the power cord is attached to the back of the washer. See
“Electrical Requirements.”
3. Hot and cold water faucets located within 4 ft.( 1.2 m)of the hot
and cold water ll valves, and water pressure of 2 0 - 1 0 0 psi ( 1
3 7 . 9 - 6 8 9 . 6 kPa) .
4. A level oor with a maximum slope of 1” (25 mm)under entire
washer. Installing the washer on soft oor surfaces,such as carpets
or surfaces with foam backing. is not recommended.
5. A sturdy and solid oor to support the washer with a total weight
(water and load) of 200lbs.
6. Do not operate your washer in temperatures below 32°F ( 0°C).
Some water can remain in the washer and can cause damage
in low temperatures.
Installation clearances
1. The location must be large enough to allow the washer door to
be fully opened.
2. Additional spacing should be considered for ease of installation
and servicing. The door opens more than 90 ,and it is nor reversible.
3. Additional clearances might be required for wall ,door , and oor
moldings.
4. Additional spacing of 25mm on all sides of the washer is
recommended to reduce noise transfer.
5. Companion appliance spacing should also be considered.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
P.09 P.10
Installation Requirements Installation Requirements
1.A120v.60Hz,AConly,15-or 20amp,fused electrical supply is required. A time-delay fuse or
circuit serving only this appliance be provided .
2.This washer is equipped with a power supply cord having a 3 prong grounding plug.
3.To minimize possible shock hazard ,the cord must be plugged into a mating,3 prong,
grounding type outlet ,grounded in accordance with accordance with local codes and
ordinances. If a mating outlet is not available ,it is the personal responsibility and obligation
of the customerto have the properly grounded outlet installed by a qualified electrician.
4.If codes permit and a separate ground wire is used ,it is recommended that a qualified
electrician determine that the ground path is adequate.
5.Do not ground to a gas pipe .
6.Check with a qualified electrician if you are not sure the washer is properly grounded.
7.Do not have a fuse in the neutral or ground circuit.
8.Certain internal parts are intentionally not grounded and may present a risk of electric shock
only during servicing. Service Personnel – Do not contact the following parts while the appliance
is energized:Electrical value,Drain Pump,Door Lock,Dry Heater(Combo),Fan Motor(Combo).
Location requirements
Selecting the proper location for your washer improves performance and minimizes noise
and possible washer “walk.”Your washer can be installed under a custom counter,or in a
basement, laundry room, closet, or recessed area. See “Drain System.”Companion
appliance location requirements should also be considered. Proper installation is your
responsibility.
You will need
1. A water heater set to deliver 120°F ( 49°C) water to the washer.
2. A grounded electrical outlet located within 6 ft.(1.8 m) of where the power cord is
attached to the back of the washer.See “Electrical Requirements.”
3. Hot and cold water faucets located within 4 ft.(1.2 m)of the hot and cold water fill
valves,and water pressure of 20-100 psi (137.9-689.6 kPa).
4. A level floor with a maximum slope of 1" (25 mm)under entire washer.Installing the washer
on soft floor surfaces,such as carpets or surfaces with foam backing.is not recommended.
5. A sturdy and solid floor to support the washer with a total weight (water and load) of 200lbs.
6. Do not operate your washer in temperatures below 32°F (0°C).Some water can
remain in the washer and can cause damage in low temperatures.
Installation clearances
1.The location must be large enough to allow the washer door to be fully opened.
°
2. Additional spacing should be considered for ease of installation and servicing. The door
opens more than 90 ,and it is nor reversible.
3. Additional clearances might be required for wall ,door , and floor moldings.
4. Additional spacing of 25mm on all sides of the washer is recommended to reduce noise
transfer.
5. Companion appliance spacing should also be considered.
Electrical requirements
WARNING
Electrical Shock Harzard
Connect to grounded 3 prong outlet with an individual 12 amp
branch circuit protected by a 12 amp circuit breaker.
Connect to individual branch circuit.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in electrical
shock, fire, or death.
Electrical requirements
Washer dimensions
The dimensions shown are for the recommended spacing. Custom dercounter installation
23
"
( 595 mm)
1 "
(25 mm)
1 "
(25 mm)
2 " (50 mm)
" min.
(850 mm)
1/2
1
/ 2
1
/ 2
4
2"
(10 80 mm)
1/2
23
"
(595 mm)
33
33
"
(850mm)
Unpacking the washing machine
Unpack your washing machine and check if there is any damage during the transportation.
Also make sure that all the items (as shown in Page 5) in the attached bag arereceived.
If there is any damage to the washing machine during the transportation, or anyitem is
missing, please contact the local dealer immediately.
1/2
1
/ 2
23
"
(595 mm)
Electrical requirements
1. A120v.60Hz,AConly,15-or 20amp,fused electrical supply is
required. A time-delay fuse or circuit serving only this appliance
be provided .
2. This washer is equipped with a power supply cord having a 3
prong grounding plug.
3. To minimize possible shock hazard, the cord must be plugged
into a mating,3 prong, grounding type outlet ,grounded in
accordance with accordance with local codes and ordinances.
If a mating outlet is not available, it is the personal responsibility
and obligation of the customerto have the properly grounded
outlet installed by a qualied electrician.
4. If codes permit and a separate ground wire is used ,it is
recommended that a qualied electrician determine that the
ground path is adequate.
5. Do not ground to a gas pipe .
6. Check with a qualied electrician if you are not sure the washer
is properly grounded.
7. Do not have a fuse in the neutral or ground circuit.
8. Certain internal parts are intentionally not grounded and may
present a risk of electric shock only during servicing. Service
Personnel – Do not contact the following parts while the
appliance is energized: Electrical value, Drain Pump, Door Lock,
Dry Heater(Combo), Fan Motor(Combo).

Front Loading Combo Model No.: RV-WD900W (WHITE)
P.09 P.10
Installation Requirements Installation Requirements
1.A120v.60Hz,AConly,15-or 20amp,fused electrical supply is required. A time-delay fuse or
circuit serving only this appliance be provided .
2.This washer is equipped with a power supply cord having a 3 prong grounding plug.
3.To minimize possible shock hazard ,the cord must be plugged into a mating,3 prong,
grounding type outlet ,grounded in accordance with accordance with local codes and
ordinances. If a mating outlet is not available ,it is the personal responsibility and obligation
of the customerto have the properly grounded outlet installed by a qualified electrician.
4.If codes permit and a separate ground wire is used ,it is recommended that a qualified
electrician determine that the ground path is adequate.
5.Do not ground to a gas pipe .
6.Check with a qualified electrician if you are not sure the washer is properly grounded.
7.Do not have a fuse in the neutral or ground circuit.
8.Certain internal parts are intentionally not grounded and may present a risk of electric shock
only during servicing. Service Personnel – Do not contact the following parts while the appliance
is energized:Electrical value,Drain Pump,Door Lock,Dry Heater(Combo),Fan Motor(Combo).
Location requirements
Selecting the proper location for your washer improves performance and minimizes noise
and possible washer “walk.”Your washer can be installed under a custom counter,or in a
basement, laundry room, closet, or recessed area. See “Drain System.”Companion
appliance location requirements should also be considered. Proper installation is your
responsibility.
You will need
1. A water heater set to deliver 120°F ( 49°C) water to the washer.
2. A grounded electrical outlet located within 6 ft.(1.8 m) of where the power cord is
attached to the back of the washer.See “Electrical Requirements.”
3. Hot and cold water faucets located within 4 ft.(1.2 m)of the hot and cold water fill
valves,and water pressure of 20-100 psi (137.9-689.6 kPa).
4. A level floor with a maximum slope of 1" (25 mm)under entire washer.Installing the washer
on soft floor surfaces,such as carpets or surfaces with foam backing.is not recommended.
5. A sturdy and solid floor to support the washer with a total weight (water and load) of 200lbs.
6. Do not operate your washer in temperatures below 32°F (0°C).Some water can
remain in the washer and can cause damage in low temperatures.
Installation clearances
1.The location must be large enough to allow the washer door to be fully opened.
°
2. Additional spacing should be considered for ease of installation and servicing. The door
opens more than 90 ,and it is nor reversible.
3. Additional clearances might be required for wall ,door , and floor moldings.
4. Additional spacing of 25mm on all sides of the washer is recommended to reduce noise
transfer.
5. Companion appliance spacing should also be considered.
Electrical requirements
WARNING
Electrical Shock Harzard
Connect to grounded 3 prong outlet with an individual 12 amp
branch circuit protected by a 12 amp circuit breaker.
Connect to individual branch circuit.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in electrical
shock, fire, or death.
Electrical requirements
Washer dimensions
The dimensions shown are for the recommended spacing. Custom undercounter installation.
23
"
( 595 mm)
1 "
(25 mm)
1 "
(25 mm)
2 " (50 mm)
" min.
(850 mm)
1
/ 2
1
/ 2
1
/ 2
4
2"
(1080 mm)
1
/ 2
23
"
(595 mm)
33
33
"
(850mm)
Unpacking the washing machine
Unpack your washing machine and check if there is any damage during the transportation.
Also make sure that all the items (as shown in Page 5) in the attached bag arereceived.
If there is any damage to the washing machine during the transportation, or anyitem is
missing, please contact the local dealer immediately.
1
/ 2
1
/ 2
23
"
(595 mm)
Unpacking the washing machine
Unpack your washing machine and check if there is any damage
during the transportation. Also make sure that all the items (as shown
in Page 5) in the attached bag arereceived.
If there is any damage to the washing machine during the
transportation, or anyitem is missing, please contact the local dealer
immediately.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
INSTALLATION INSTRUCTIONS
Dispose the packing materials
The packing materials of this machine may be dangerous to kids.
Please dispose them properly and avoid easy touch by kids. Please
dispose the related packing materials according to the relevant
local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts must be removed
from the backside of this machine. Please take the following steps
to remove the bolts:
1. Loosen all bolts with spanner and
then remove them.
2. Cover the holes with transport hole
plugs.
3. Keep the transport bolts properly for
future use.
Make sure the small triangle foam is
removed with the bottom one together.
If not, lay the unit down with side surface,
then remove the small foam from the
unit bottom manually.
Select the location
Before installing the washing machine, the location characterized
as follows shall be selected:
- Rigid, dry, and level surface (if not level, please make it level with
reference to the following gure “Adjust Leg”)
- Avoid direct sunlight
- Sufcient ventilation
- Room temperature is above 0ºC
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet oor.
P.11 P.12
Installation Instructions
Install inlet pipe
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small triangle foam is removed with the
bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom
manually.
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0℃
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.
Drain system options
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires aminimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Installation Instructions

Front Loading Combo Model No.: RV-WD900W (WHITE)
P.11 P.12
Installation Instructions
Install inlet pipe
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small trianglefoamis removed with the
bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom
manually.
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0℃
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.
Drain system options
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires aminimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Installation Instructions
Connect inlet pipe
Connect the inlet pipe as indicated in the
gure.
For the model which has hot valve , please
connect the hot vale to hot water tap.
Install inlet pipe
1. Connect the elbow to tap and
fasten it clockwise.
2. Connect the other end of inlet pipe
to the inlet valve at the backside of
washing machine and fasten the
pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat
the steps to connect inlet pipe. The most common type of tap
shall be used to supply water. If tap is square or too big, then
standard tap shall be changed.
Drain system options
Standpipe drain system - wall or foor
(views A & B) The standpipe drain requires
a minimum diameter standpipe of 2” (50
mm). The minimum carry- away
Capacity can be no less than 17 gal. (64 L)
per minute. The top of the standpipe must
be at least 60cm high and no higher than
100cm from the bottom of the washer.
Laundry tub drain system (view C) The
laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must
be at least 60cm above the foor.
Floor drain system( view D) .The oor drain
system requires a siphon break that may be
purchased separately.
See“Tools and Parts”. The siphon break must
be a minimum of 28” ( 710 mm) from the
bottom of the washer. Additional hoses might
be needed.
P.11 P.12
Installation Instructions
Install inlet pipe
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small trianglefoamis removed with the
bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom
manually.
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0℃
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.
Drain system options
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires aminimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Installation Instructions
P.11 P.12
Installation Instructions
Install inlet pipe
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small trianglefoam is removed with the
bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom
manually.
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0℃
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.
Drain system options
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires aminimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Installation Instructions
P.11 P.12
Installation Instructions
Install inlet pipe
Dispose the packing materials
The packing materials of this machine may be dangerous to kids. Please dispose them
properly and avoid easy touch by kids. Please dispose the related packing materials
according to the relevant local regulations. Please do no throw the packing materials away
together with the other daily living rubbishes.
Remove transport bolts and foam
Before using this washing machine, transport bolts
must be removed from the backside of
this machine. Please take the following steps to
remove the bolts:
1.Loosen all bolts with spanner and then remove them.
2.Cover the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Make sure the small trianglefoam is removed with the
bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom
manually.
Select the location
Before installing the washing machine, the location characterized as follows shall be
selected:
- Rigid, dry, and level surface (if not level, please make it level with reference to the
following figure “Adjust Leg”)
- Avoid direct sunlight
- Sufficient ventilation
- Room temperature is above 0℃
- Keep far away from the heat resources such as coal or gas.
Make sure that the washing machine will not stand on power cord.
Do not install the washing machine on the carpet floor.
Connect inlet pipe
Connect the inlet pipe as indicated in the figure.
For the model which has hot valve , please connect
the hot vale to hot water tap.
HC
1.Connect the elbow to tap and fasten it
clockwise.
2.Connect the other end of inlet pipe to the inlet
valve at the backside of washing machine and
fasten the pipe tightly clockwise.
Note: after connection, if there is any leakage with hose, then repeat the steps to connect inlet
pipe. The most common type of tap shall be used to supply water. If tap is square or too big,
then standard tap shall be changed.
Drain system options
A
Capacity can be no less than 17 gal.(64 L)per minute.
The top of the standpipe must be at least 60cm high and
no higher than 100cm from the bottom of the washer.
Floor drain system(view D).The floor drain system requires
a siphon break that may be purchased separately.
See“Tools and Parts”.The siphon break must be a minimum
of 28" (710 mm)from the bottom of the washer.
Additional hoses might be needed.
Min 60
Max 100
B
Laundry tub drain system (view C)
The laundry tub needs a minimum 20 gal. (76 L)
capacity. The top of the laundry tub must be
at least 60cm above the foor.
Min.60cm
Max.100cm
C
28 " min.
(710 mm)
D
Standpipe drain system -wall or foor (views A & B)
The standpipe drain requires aminimum diameter
standpipe of 2"(50 mm).The minimum carry-away
Installation Instructions

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
Level the washer
1. When positioning the washing
machine, please rst check if the legs
are closely attachedto the cabinet. If
not, please turn them to their original
positions with hand or spanner
andtighten the nuts with spanner.
2. After positioning the washing machine,
press four corners on top cover of
washing machine in sequence. If
the washing machine is not stable
when being pressed, this leg shall be
adjusted.
3. Ensure the positioning status of washing
machine. Loosen the lock nut with
spanner and turn the leg with hand
until it closely contacts with the oor.
Press the leg with one hand and fasten the nut closely to the
cabinet with the other hand.
4. After being locked properly, press four corners again to make
sure that they has been adjusted properly. If it is still unstable, it
has to repeat Steps 2 and 3
5. Put a solid cylinder (e.g. pop cans) oppositely on the top cover
of the washing machine from in the left, right, front and back
directions. If the cylinder keeps stable, the washing machine
is positioned level. If it rolls, the washing machineis positioned
unlevel. The rolling direction is the direction of lower ground
surface. Then the two legs in this direction shall be raised at
the same time until the washing machine is level. Steps 1~3 are
repeated to make the bottom legs closely against the ground
and the nuts shall be locked tightly.
Electrical connection
- As the maximum current through the unit is 12A when you are
using its heating function, please make sure the power supply
system (current, power voltage and wire) at your home can meet
the normal loading requirements of the electrical appliances.
- Please connect the power to a socket which is correctly installed
and properly earthed.
- Make sure the power voltage at your place is same to that in the
machine’s rating label.
P.13 P.14
Operating Instructions
Installation Instructions
Level the washer
5.Put a solid cylinder (e.g. pop cans) oppositely on the
top cover of the washing machine from in the left, right,
front and back directions. If the cylinder keeps stable, the washing machine is
positioned level. If it rolls, the washing machineis positioned unlevel.The rolling direction is
the direction of lower ground surface.Then the two legs in this direction shall be raised at the
same time until the washing machine is level.Steps 1~3 are repeated to make the bottom legs
closely against the ground and the nuts shall be locked tightly. .
3.Ensure the positioning status of washing machine.
Loosen the lock nut with spanner and turn the leg
with hand until it closely contacts with the floor. Press
the leg with one hand and fasten the nut closely to the
cabinet with the other hand.
4.After being locked properly, press four corners again to
make sure that they has been adjusted properly. If it is
still unstable, it has to repeat Steps 2 and 3
1.When positioning the washing machine, please
first check if the legs are closely attachedto the
cabinet. If not, please turn them to their original
positions with hand or spanner andtighten the
nuts with spanner.
2.After positioning the washing machine, press
four corners on top cover of washing machine
in sequence. If the washing machine is not
stable when being pressed, this leg shall be adjusted.
Electrical connection
- As the maximum current through the unit is 12A when you are using its heating function,
please make sure the power supply system (current, power voltage and wire) at your
home can meet the normal loading requirements of the electrical appliances.
- Please connect the power to a socket which is correctly installed and properly earthed.
- Make sure the power voltage at your place is same to that in the machine's rating label.
- Power plug must match the socket and cabinet must be properly and effectively earthed.
- Do not use multi-purpose plug or socket as extension cord.
- Do not connect and pull out plug with wet hand.
- When connecting and pulling out the plug, hold the plug tightly and then pull it out. Do
not pull power cord forcibly.
- If power cord is damaged or has any sign of being broken, special power cord must be
selected or purchased from its manufacturer or service center for replacement.
WARNING
WARNING – To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
Operating instructions
Checklist and preparation before washing clothes
Please read this operation method carefully to avoid the troubles of washing machine and
damages of clothes.
Check if the first-washed clothes will bed decolorized.
After a white towel touched with liquid detergent is used to wash the invisible corners of the
clothes, check if the white towel is stained with
clothes' original color.
As for the scarves and those clothes that easily
get decolorized among imported clothes, please
wash them separately before washing.
As for the stains on sleeves, collars and pockets,
use the liquid detergent and wash it with brush
gently
. Finally put them into the washing machine
to achieve more ideal washing effects.
As for temperature-sensitive clothes, they shall
be washed as required in the labels. Otherwise,
it may cause color change or distortion.
Keep in Mind:
Never put the clothes to be washed in washing machine for a long period of time.
Otherwise it may get moldy and cause spots. Therefore, please wash the clothes in time.
The clothes also may get color changed or distorted if they are not washed according to
the stated washing temperature.
Clothes that can not be washed by washing machine
The clothes that may get distorted if being immersed in water:
Ties, waistcoats, western-style clothes, outer garments etc. may have obvious shrinkage
if being immersed in water; the decolorized clothes such as blended spinning clothes of
artificial fiber etc.

Front Loading Combo Model No.: RV-WD900W (WHITE)
- Power plug must match the socket and cabinet must be properly
and effectively earthed.
- Do not use multi-purpose plug or socket as extension cord.
- Do not connect and pull out plug with wet hand.
- When connecting and pulling out the plug, hold the plug tightly
and then pull it out. Do not pull power cord forcibly.
- If power cord is damaged or has any sign of being broken, special
power cord must be selected or purchased from its manufacturer
or service center for replacement

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
OPERATING INSTRUCTIONS
WARNING – To reduce the risk of re, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS
before operating this appliance. Operating instructions
Checklist and preparation before washing clothes
Please read this operation method carefully to avoid the troubles of
washing machine and damages of clothes.
Check if the rst-washed clothes will bed decolorized.
After a white towel touched with
liquid detergent is used to wash the
invisible corners of the clothes, check
if the white towel is stained with
clothes’ original color.
As for the scarves and those clothes
that easily get decolorized among
imported clothes, please wash them
separately before washing.
As for the stains on sleeves, collars
and pockets, use the liquid detergent
and wash it with brush gently. Finally put them into the washing
machine to achieve more ideal washing effects.
As for temperature-sensitive clothes, they shall be washed as
required in the labels. Otherwise, it may cause color change or
distortion.
Keep in Mind:
Never put the clothes to be washed in washing machine for a
long period of time. Otherwise it may get moldy and cause spots.
Therefore, please wash the clothes in time. The clothes also may get
color changed or distorted if they are not washed according to the
stated washing temperature.
Clothes that can not be washed by washing machine
The clothes that may get distorted if being immersed in water:
Ties, waistcoats, western-style clothes, outer garments etc. may
have obvious shrinkage if being immersed in water; the decolorized
clothes such as blended spinning clothes of articial ber etc.
Wrinkle-style clothes, embossed clothes, resin clothes etc. may get
distorted when being immersed in water. Among cotton and wool
P.13 P.14
Operating Instructions
Installation Instructions
Level the washer
5.Put a solid cylinder (e.g. pop cans) oppositely on the
top cover of the washing machine from in the left, right,
front and back directions. If the cylinder keeps stable, the washing machine is
positioned level. If it rolls, the washing machineis positioned unlevel.The rolling direction is
the direction of lower ground surface.Then the two legs in this direction shall be raised at the
same time until the washing machine is level.Steps 1~3 are repeated to make the bottom legs
closely against the ground and the nuts shall be locked tightly. .
3.Ensure the positioning status of washing machine.
Loosen the lock nut with spanner and turn the leg
with hand until it closely contacts with the floor. Press
the leg with one hand and fasten the nut closely to the
cabinet with the other hand.
4.After being locked properly, press four corners again to
make sure that they has been adjusted properly. If it is
still unstable, it has to repeat Steps 2 and 3
1.When positioning the washing machine, please
first check if the legs are closely attachedto the
cabinet. If not, please turn them to their original
positions with hand or spanner andtighten the
nuts with spanner.
2.After positioning the washing machine, press
four corners on top cover of washing machine
in sequence. If the washing machine is not
stable when being pressed, this leg shall be adjusted.
Electrical connection
- As the maximum current through the unit is 12A when you are using its heating function,
please make sure the power supply system (current, power voltage and wire) at your
home can meet the normal loading requirements of the electrical appliances.
- Please connect the power to a socket which is correctly installed and properly earthed.
- Make sure the power voltage at your place is same to that in the machine's rating label.
- Power plug must match the socket and cabinet must be properly and effectively earthed.
- Do not use multi-purpose plug or socket as extension cord.
- Do not connect and pull out plug with wet hand.
- When connecting and pulling out the plug, hold the plug tightly and then pull it out. Do
not pull power cord forcibly.
- If power cord is damaged or has any sign of being broken, special power cord must be
selected or purchased from its manufacturer or service center for replacement.
WARNING
WARNING – To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
Operating instructions
Checklist and preparation before washing clothes
Please read this operation method carefully to avoid the troubles of washing machine and
damages of clothes.
Check if the first-washed clothes will bed decolorized.
After a white towel touched with liquid detergent is used to wash the invisible corners of the
clothes, check if the white towel is stained with
clothes' original color.
As for the scarves and those clothes that easily
get decolorized among imported clothes, please
wash them separately before washing.
As for the stains on sleeves, collars and pockets,
use the liquid detergent and wash it with brush
gently
. Finally put them into the washing machine
to achieve more ideal washing effects.
As for temperature-sensitive clothes, they shall
be washed as required in the labels. Otherwise,
it may cause color change or distortion.
Keep in Mind:
Never put the clothes to be washed in washing machine for a long period of time.
Otherwise it may get moldy and cause spots. Therefore, please wash the clothes in time.
The clothes also may get color changed or distorted if they are not washed according to
the stated washing temperature.
Clothes that can not be washed by washing machine
The clothes that may get distorted if being immersed in water:
Ties, waistcoats, western-style clothes, outer garments etc. may have obvious shrinkage
if being immersed in water; the decolorized clothes such as blended spinning clothes of
artificial fiber etc.

Front Loading Combo Model No.: RV-WD900W (WHITE)
materials, the clothes that get easily distorted are wrinkle-style silk,
fur products and fur decorations;
Clothes with decoration, long dress and traditional clothes etc are
the products to get decolorized easily.
Please do not wash the clothes without material labels and washing
requirements.
Never wash the clothes stained with the chemicals such as gasoline,
petroleum, benzene, paint thinner and alcohol.
Please pay attention with regard to detergents
“Low bubble” detergent or washing powder or washing powder
special for drum washing machine shall be selected according to
ber types (cotton, synthetic ber, soft products and wool products),
colors, washing temperatures, dirty degrees and types. Otherwise,
excessive bubbles may be generated and overowed out of the
drawer so that accidents may take place.
Bleacher belongs to alkali type and can damage clothes, so it is
suggested to use as little as possible.
Powder detergents can easily leave the residues in the clothes so as
to generate the bad smell, so they shall be sufciently rinsed.
Detergent can not easily get dissolved completely if there is too
much detergent or water temperature is rather low. It can remain in
clothes, pipes and washing machines to pollute the clothes.
Washing shall follow the weight of clothes, dirty degrees, local
water hardness as well as the recommendations from the detergent
manufacturers. Please consult the water company if you are not
clear of water hardness.
Note:
Keep detergents and additives in safe and dry places out of touch
by kids.
Please take out the items out of the pockets.
Please check the pockets of the clothes to be washed, empty
the rigid items such as decorations and coins, otherwise washing
machine may be damaged or have abnormal troubles.
For the clothes to be washed, they are classied according to
the following characteristics:
The symbol types of care labels: the clothes to be washed are
classied into cotton, blended ber, synthetic ber, silk, wool and
articial ber.
Color: white and colorful colors shall be identied. All new colorful
articles shall be washed in a separate way.

Front Loading Combo Model No.: RV-WD900S (TITANIUM)
Size: the articles of different sizes are washed together to increase
the washing effects.
Sensitivity: soft articles shall be washed separately. As for new pure
wool textiles, curtains and silks, the soft washing procedure shall be
selected. Check the labels in all washing articles.
The clothes shall be sorted before being put into washing machine.
As for the curtains with hooks, the hooks shall be removed before
being washed.
The decorations on the clothes may damage the washing machine.
As for the clothes with buttons or embroideries, they shall be turned
over before being washed.
Clean up fasteners:
Zips shall be zipped close and buttons or hooks shall be xed. The
loose band or ribbon shall be bound together.
WARNING
It is suggested to put bras into the
pillow slip with zip or buttons sealed
to prevent the steel wire from
popping out of bras into the drum
and damaging the machine.
Especially delicate textiles such as
laced curtains, straightjackets, small
articles (tight socks, handkerchiefs,
ties etc.) shall be put into string bag
for washing.
When washing a single big and
heavy dress such as Turkish towels,
jeans, wadded jackets etc., it may
easily cause great eccentricity and
give alarm due to great unbalance.
Therefore it is suggested to add one
or two more clothes to be washed
together so that draining can be
done smoothly.
Clean away dusts, stains and pet hairs from the clothes.
The clothes may be damaged and disturb washing effects during
the friction between dusts, stains and clothes.
P.15 P.16
Wrinkle-style clothes, embossed clothes, resin clothes etc. may get distorted when being
immersed in water. Among cotton and wool materials, the clothes that get easily distorted
are wrinkle-style silk, fur products and fur decorations;
Clothes with decoration, long dress and traditional clothes etc are the products to get
decolorized easily.
Please do not wash the clothes without material labels and washing requirements.
Never wash the clothes stained with the chemicals such as gasoline, petroleum, benzene,
paint thinner and alcohol.
Please pay attention with regard to detergents
“Low bubble” detergent or washing powder or washing powder special for drum washing
machine shall be selected according to fiber types (cotton, synthetic fiber, soft products and
wool products), colors, washing temperatures, dirty degrees and types. Otherwise,
excessive bubbles may be generated and overflowed out of the drawer so that accidents
may take place.
Bleacher belongs to alkali type and can damage clothes, so it is suggested to use as little
as possible.
Powder detergents can easily leave the residues in the clothes so as to generate the bad
smell, so they shall be sufficiently rinsed.
Detergent can not easily get dissolved completely if there is too much detergent or water
temperature is rather low. It can remain in clothes, pipes and washing machines to
pollute the clothes.
Washing shall follow the weight of clothes, dirty degrees, local water hardness as well as
the recommendations from the detergent manufacturers. Please consult the water
company if you are not clear of water hardness.
Note:
Keep detergents and additives in safe and dry places out of touch by kids.
Please take out the items out of the pockets.
Please check the pockets of the clothes to be washed, empty the rigid items such as
decorations and coins, otherwise washing machine may be damaged or have abnormal
troubles.
For the clothes to be washed, they are classified according to the following
characteristics:
The symbol types of care labels: the clothes to be washed are classified into cotton, blended
fiber, synthetic fiber, silk, wool and artificial fiber.
Color: white and colorful colors shall be identified. All new colorful articles shall be washed
in a separate way.
Checklist and preparation before washing clothes
Operating Instructions Operating Instructions
Checklist and preparation before washing clothes
Size: the articles of different sizes are washed together to increase the washing effects.
Sensitivity: soft articles shall be washed separately. As for new pure wool textiles, curtains
and silks, the soft washing procedure shall be selected. Check the labels in all washing articles.
The clothes shall be sorted before being put into washing machine. As for the curtains with
hooks, the hooks shall be removed before being washed.
The decorations on the clothes may damage the washing machine. As for the clothes with
buttons or embroideries, they shall be turned over before being washed.
Clean up fasteners:
Zips shall be zipped close and buttons or hooks shall be fixed. The loose band or ribbon shall
be bound together.
It is suggested to put bras into the pillow slip
with zip or buttons sealed to prevent the steel
wire from popping out of bras into the drum and
damaging the machine.
Especially delicate textiles such as laced curtains,
straightjackets, small articles (tight socks,
handkerchiefs, ties etc.) shall be put into string
bag for washing.
When washing a single big and heavy dress such
as Turkish towels, jeans, wadded jackets etc.,
it may easily cause great eccentricity and give
alarm due to great unbalance. Therefore it is
suggested to add one or two more clothes to be
washed together so that draining can be done
smoothly.
Clean away dusts, stains and pet hairs from the clothes.
The clothes may be damaged and disturb washing effects during the friction between dusts,
stains and clothes.
To protect baby skin
Baby articles (baby clothes and towels) including napkins shall be washed separately.
If they are washed together with the adults' clothes, they may be infected. Rinsing times shall
be increased to ensure the thorough rinsing and cleaning without the detergent residues.
It is suggested that the parts that are easily stained such as white sockets, collars and
sleeves etc. shall be hand washed before being put into washing machine to achieve
more ideal washing effects.
Please use powder or liquid detergents. The residues of the soap could remain in the gaps of
the clothes if soap is used.
WARNING

Front Loading Combo Model No.: RV-WD900W (WHITE)
To protect baby skin
Baby articles (baby clothes and towels) including napkins shall be
washed separately. If they are washed together with the adults’
clothes, they may be infected. Rinsing times shall be increased to
ensure the thorough rinsing and cleaning without the detergent
residues.
It is suggested that the parts that are easily stained such as white
sockets, collars and sleeves etc. shall be hand washed before being
put into washing machine to achieve more ideal washing effects.
Please use powder or liquid detergents. The residues of the soap
could remain in the gaps of the clothes if soap is used.
The clothes which easily get fuzzed shall be turned over for
washing
The clothes which easily get fuzzed shall be washed separately;
otherwise the other articles can be stained with dust and thrum
etc. Preferably, black clothes and cotton clothes shall be washed
separately because they can easily get stained with the thrums of
other colors when being washed together.
Please check before washing.
Washing machine shall not wash water-proof materials (ski suits,
outside napkin pads, curtains).
As for the ber products that water can not get soaked easily into
such as water-proof cushions, and clothes, it is better not to wash.
Otherwise there will be water bursting out or abnormal vibration to
cause danger while rinsing and draining so that the clothes also may
be damaged. (Such as outside napkin pads, raincoats, umbrella, ski
suits, car covers, sleeping sacks etc.)
Cautions during Draining
Draining of normal clothes:
Moistures of washings are drained through drain hole.
Draining of water-proof clothes and ber products:
In the normal washing and draining status, moistures of water-
proof clothes and ber products can not be drained while water
is gathered in one direction so that the eccentricity of washing
machine is too great and vibration or moving is caused.
