Convaid YoYo User manual

English
User’s Guide
YoYo
Hi-Lo Frame
SAVE THIS BOOK FOR FUTURE REFERENCE
READ INSTRUCTION BEFORE USING
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE

CONVAID USER’S GUIDE
2
Customer Service Support
Toll Free: 1-888-Convaid (266-8243)
Phone: [phone]
Fax: [phone]
Email: [email protected]
International Email: [email protected]
Website: www.convaid.com
Technical assistance or repair information hours are:
Monday-Friday, 6 a.m. to 4:30 p.m. PST
Before Calling:
Please ll in the following. Customer Service will be able to help you more
quickly if the information indicated below is readily available.
Serial number of frame:
Model of frame:
Date purchased:
Notice:
The information contained in this document is subject to change without notice.
No part of this document may be photocopied, reproduced, transmitted, transcribed,
stored in a retrieval system or translated to another language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise without the prior written consent of Convaid.
© Copyright 2016 by Convaid. All rights reserved.

3
Table of Contents
S e t t i n g U p t h e Y o Y o F r a m e
YoYo Frame
Accessories & Options
Maintenance, operating &
safety instructions......................................................... 38
Warranty ....................................................................... 43
Head support
TrekkerTM Seating Module
• Frame Standard Features Overview .................................................. 8
• Contents in the Box .......................................................................... 10
• To Remove Frame from Box ............................................................ 10
• Preparing the Frame for Use ........................................................... 10
• Foot Pedal Security Locks.................................................................11
• Caster Wheel Locks ..........................................................................11
• Frame Height Adjustment................................................................. 12
• Frame Height Adjustment with user ................................................. 13
• Curved Head Support....................................................................... 29
• Wing Head Support ......................................................................... 30
• Universal Head Support Mounting Plate .......................................... 30
• TrekkerTM Seat Bottom View ............................................................. 15
• TrekkerTM Seat Back View................................................................ 15
• Check Tilt Adjustment Lever Cables................................................. 16
• Specications ..................................................................................... 4
• Warnings ........................................................................................... 5
• TrekkerTM Seating Module Installation
on YoYo Hi-Lo Frame ....................................................................... 18
• Removing Trekker Seating Module from
YoYo Hi-Lo Frame ............................................................................ 19
• Tilt-in-Space Adjustment................................................................... 20
• Recline Adjustment........................................................................... 21
Operating Instruction
Laterals........................................................................... 31
Hip Guides....................................................................... 32
Medial Knee Abductor(Pommel) .......................................... 33
Legrest Extension ............................................................. 34
Utility Bag ....................................................................... 35
Shoe Holder..................................................................... 35
Extended Strap Vest(Buttery Harness)............................... 35
Upper Extremity Support Tray ............................................ 36
Calf Panel ........................................................................ 37
Seating Module Overview
Fitting Guide
• Back Height Adjustment ................................................................... 22
• Seat Depth Adjustment..................................................................... 23
• H-Harness with Padded Covers ....................................................... 24
• Extended Strap Vest (Buttery Harness).......................................... 24
• Depth Adjustment Crotch Strap........................................................ 25
• Foot Support Height Adjustment ...................................................... 26
• Foot Positioners ............................................................................... 27
• Two-Point Positioning Belt................................................................ 28
• Three-Point Positioning Belt............................................................. 28
• Four-Point Positioning Belt............................................................... 28

CONVAID USER’S GUIDE
4
Specications
Gas Struts Size Carrying Capacity*
Seat to Floor Height
Range
(with seat)
Seat to Floor Height
Range
(without seat)
650N 0 - 75 lbs. 11.8” - 24.8” 10.5” - 23.5”
800N 60 - 110 lbs. 14.8” - 25.3” 13.5” - 24”
Tilt-in-Space User Weight
Capacity Frame Length Frame Width Frame Weight
-10° to +30° up to 110 lbs. 28” 25.8” 27 lbs.
*Optimum user assist

5
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and functions of the
product before use and practice them. You must read and fully understand the contents of this
manual. Any caregiver who is going to operate this frame should read the manual in full.
You are responsible for the safety of the user. The safety of the user could be affected if you do not
follow the instructions in this manual. Nevertheless, not all possible circumstances and unpredictable
situations can be covered by this manual. Reason, care, and circumspection are not features of the
product; they are required of persons who use the product. If instructions are not clear and further
explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the frame or serious injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury or
death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are dened throughout this manual along with
operating instructions.
CHOOSE THE RIGHT FRAME AND SEAT & SAFETY OPTIONS
There are several options available to meet the needs of the frame and seat user. Make sure that
your (and your health care provider’s) choice of chair and other added options takes into account the
user’s comfort, positioning, physical limitations, and hazards that may be encountered during daily
use. Operating the frame and seat outside of the recommendations provided by the manufacturer can
lead to a dangerous situation.
Warnings
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
FIG.1
FIG.2

CONVAID USER’S GUIDE
6
WARNING: The operator/caregiver must read and understand
this manual prior to operating this equipment. If you are unable
to understand any part of the manual, contact your supplier for
assistance.
WARNING: The weight carried by the TrekkerTM seating module on the
YoYo frame must never exceed the total weight limit of the gas strut
(650N - 75lbs / 800N - 110lbs).
(Maximum occupant size plus any items carried.)
WARNING: To reduce the risk of an accident:
• ALWAYS carefully read the User Guide and get comfortable
operating the YoYo.
• ALWAYS watch for obstacles and avoid them as often as
possible.
• MAKE SURE that the YoYo operates properly. Repair any
problems before use.
• ALWAYS secure the user into the YoYo during use.
• ALWAYS use indoors on smooth and level surfaces.
• ALWAYS engage all four of the YoYo frame caster wheel
locks before transferring user into and out of the seat.
WARNING: The YoYo frame is not a transit model and should never be
used to transport the occupant in a motor vehicle or bus.
FRAME LABEL WARNING
WARNING: The YoYo frame is intended to be used indoors on smooth
and level surfaces.
WARNING: Do not move occupant in the YoYo frame over incline or
decline ramps.
WARNING: Engage all YoYo frames caster wheel locks when raising,
lowering, or transferring an occupant.
WARNING: Keep objects and obstructions away from the YoYo frame
when raising, lowering or moving the frame.
WARNING: When transferring occupant into or out of the seating
module on the YoYo frame and when moving the YoYo frame with an
occupant, the seating module should be tilted to the maximum tilt
range of 30 degrees to ensure balance and stability of the frame.
WARNING: Always lock the YoYo foot pedal when the desired seat
height is reached.
WARNING: The Trekker Seating Module only interfaces with the front
of the YoYo docking platform.
General Warnings
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE

7
WARNING: The Trekker Seating Module with after-market seating is not
compatible with the YoYo frame.
WARNING: Never leave the occupant unattended in the chair even when they
are strapped in and the caster locks are engaged.
WARNING: Changes & adjustments
• Adjustments made to the frame will change the balance and function
of the frame and may increase risk of tip over.
• Warranty will be voided if modications to the frame are made without
manufacturer’s authorization.
WARNING: Do not stand on the foot pedal when transferring the occupant into
or out of the chair.
WARNING: When the occupant reaches for objects in front, to the side, or
behind the YoYo frame, be sure that they do not lean out of the chair too far
since the shift in the center of gravity might cause the frame to tilt or tip over.
WARNING: Please keep packaging material away from children. Plastic
packaging presents the danger of suffocation.
WARNING: The chair is only intended to carry one occupant at a time.
WARNING: Whenever you change a setting on the seating module, make sure
that you rmly tighten any screws or knobs that have been loosened prior to
placing the occupant in the chair.
WARNING: Many of the screws, bolts, and nuts used on this chair are
specialized or high-strength fasteners and should only be purchased through
Convaid or a Convaid service dealer.
FIG.4
FIG.6
FIG.7
FIG.5
FIG.3
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
YoYo Hi-Lo Frame Labels

CONVAID USER’S GUIDE
8
Front View
Caster Lock
Serial Number Label
FIG.7
4” Wheels
Front Arms
Front Label FIG.4
Frame
Docking Platform
FIG.8
YoYo Frame Standard Features Overview
NOTE: TrekkerTM Seating
Module only interfaces with
the front of the Docking
Platform.

9
SETTING UP
Back View
YoYo Warning Label
FIG.3
Gas Strut Actuator Cable
Foot Pedal
Warning Label
FIG.6
Rear Arms
Gas Strut
(650N or 800N)
Foot Pedal
Security Lock Pin
Foot Padel Lock
Arrow Label FIG.5
Tilt Cable
FIG.9

CONVAID USER’S GUIDE
10
Contents in the Box
List of items included in the box
• YoYo frame
• Instruction Manual
• TrekkerTM Seating Module and Accessories-as ordered
To Remove Frame from Box:
1. Place box at on the oor.
2. Verify that package is in good shape and no damage has occurred during
shipping.
3. Pull frame out using both hands, with hand on each side of the frame.
4. Do not pull on any cables on the YoYo frame.
5. Secure cables from binding on any objects when transporting chair.
Preparing the Frame for Use
Once you have all components as ordered, the directions for use in this User Guide will
guide you through the process of preparing the YoYo frame for use.
Convaid recommends the initial tting, adjustments, and set-up take place with the help of
your Convaid Authorized Dealer. However, if the instructions contained in this manual are
followed carefully, a caregiver or attendant will be able to set up the YoYo frame.
Frame Set Up & Adjustment

11
SETTING UP
Foot Pedal Security Lock
For safety, the foot pedal on the YoYo frame can be
locked by engaging the pull pin, indicated by the red
arrow. FIG.5
To unlock
Pull the pin out and rotate 90 degrees to free the pin from
it’s locking position. the pedal can now move up and down
freely when operated by the foot. FIG.10
To lock
Rotate the locking pin until it retracts into the open slot
with pull pin to fully engaged into the foot pedal. FIG.11
NOTE: To reduce the risk of an accident: Always keep the
security lock pin engaged when the height of the seating
system is not being adjusted. This will ensure that the foot
pedal will not be activated accidentally.
Caster Wheel Locks
To unlock
Pull the caster lock tab up. FIG.12
To lock
Push the caster lock tab down. FIG.12
UNLOCK
LOCK
UNLOCK
LOCK
FIG.10
FIG.11
FIG.12
FIG.5

CONVAID USER’S GUIDE
12
Note: When lowering the YoYo without the occupant and/or the seating module, a signicant force may
be required to collapse the frame for storage. Use proper care and always ensure that all caster locks are
fully engaged when attempting this operation.
Frame Height Adjustment
The seat to oor height is adjustable by using the
foot pedal to raise or lower the occupant to the
desired height. The height can be adjusted with
or without a seating module. FIG.13
Before adjusting the seat to oor height of the
YoYo frame, always check that the foot pedal is
unlocked FIG.10, FIG.12 and the caster wheels
have been locked. (See Page 11)
By pressing on the foot pedal and the docking platform the frame lowers. FIG.14
By pressing on the foot pedal, the frame raises. FIG.15
Foot Pedal
FIG.13
FIG.14 FIG.15
LOWER RAISED

13
SETTING UP
The forces required to raise and lower the seating module with the user is dependent on the user’s
weight and the gas strut paired with the user (650N or 800N). Please see the weight assist chart for
optimal pull forces. FIG.19
Frame Height Adjustment with User
650N
Gas Strut
800N
Gas Strut
User Weight
Pull Force (lbs)
50 lbs.25 lbs.
10 lbs.
20 lbs.
30 lbs.
0 110 lbs.75 lbs.
Select Your Assist Based on User’s Weight
Forces required to raise the user vary depending on your gas strut selection.
1. Lock all caster wheels. FIG.12 (see page 11)
2. Unlock foot pedal lock. FIG.10 (see page 11)
3. Press the foot pedal. FIG.16 Place both
hands rmly on each side of the rear cross
tube of the seating module. FIG.17
4. Simultaneous press down (lower) or pull up
(raising) the rear cross tube while pressing
on the foot pedal. FIG.18
5. Once the desired height is reached, the foot
pedal should be released and locked to avoid
accidental actuation.
WARNING: Keep objects and obstructions away from the YoYo frame when raising, moving or lowering the frame.
WARNING: When moving an occupant in the YoYo frame, the seating module should be tilted to the maximum tilt
range of 30 degrees to ensure balance and stability of the frame.
WARNING: Before adjusting the seat to oor height of the YoYo frame, always check to ensure the foot pedal
security lock has been unlocked and the caster locks have been locked.
FIG.16 FIG.17
FIG.18
FIG.19
Rear
Cross
Tube

CONVAID USER’S GUIDE
14
Trekker Seating Module

15
Trekker Seat Bottom View
Trekker Seat Back View
Height
adjustable
knobs
Height
adjustable
knobs
Height
adjustable
knobs
Height
adjustable
Solid Back
System
Tilt Cable tie
downs
Seating Tilt
Cable
Tilt Cable
Safety Lock Lever Pommel Attachment Knob
Adjustment barrel
Adjustment barrel
Spring Inner Cable
Cable Clamp
Upper Propeller
Tilt adjustment lever
Recline adjustment
strap
Chrome Cable End
Push In
FIG.20
FIG.21

CONVAID USER’S GUIDE
16
Upper Propeller not
aligned at 90°
Before attaching the Seating Module to the frame
Check Tilt Adjustment Lever
To Adjust:
1. Plug the cable end into the adjustment barrel on the bottom of Seating Module. FIG.22
2. Make sure the chrome cable end is fully seated inside adjustment and that the Upper Propeller
is aligned at 90°. FIG.23
INCORRECT CORRECT
Push In
Tilt cable out of
position
Tilt cable Pushed In
Upper Propeller
aligned at 90°
90°
FIG.22
FIG.23

17
OPERATION
Check Tilt Adjustment Lever Cable
INCORRECT CORRECT
Tilt cable out of
position Push In
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
WARNING:Cable on the tilt
adjustment lever may be
pulled loose or dislodge
during transport and/or
initial assembly. FIG.24 To Adjust:
1. Plug the cable end into
the adjustment barrel.
FIG.25
2. Make sure the chrome
cable end is fully seated
inside adjustment barrel.
FIG.24 FIG.25

CONVAID USER’S GUIDE
18
Trekker Seating Module Installation
on YoYo Hi-Lo Frame
1. Look for the “front” label on the docking
platform to identify the front face of the frame.
FIG.26
2. Hold the seating module at a 45-degree
angle. FIG.27
3. Face the seating module forward and align
the seat docking hooks with the back tube of
the frame docking platform. FIG.28
4. Push the safety lock release lever and
engage seating module lock bar. FIG.29
FIG.27
FIG.28
FIG.29
FIG.26
Docking
Hooks
45°
Safety Lock
Operation

19
SETTING UP
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
Removing Trekker Seating Module from
YoYo Hi-Lo Frame
WARNING: Always remove the occupant from the chair before removing the seating module from the YoYo
frame. Removal of the seating module is only intended for facilitating, lifting and transportation of the
chair. The occupant should never be placed in the seating module if it is not properly attached to the YoYo
frame. The YoYo frame should not be used if the seating module assembly is not properly installed.
WARNING: The seating module can not be used as a car seat.
Removing seating module from frame:
1. Lock the casters. FIG.12
2. Remove occupant from seating module.
3. Adjust back to upright position. Seating Module
MUST be paraell to the oor.
4. Push Safety Lock release lever. FIG.30
5. Lift seating module release bar. FIG.31
6. Pull seating module forward to diengage the
Docking Hooks from docking platform. FIG.32
7. Lift seating module from the frame.
FIG.30
FIG.31 FIG.32
Safety Lock
Docking Hooks
Release Bar

CONVAID USER’S GUIDE
20
WARNING: In preparation to operate the tilt:
• Always verify that the arms of the user are
stable and within the frame.
• Always verify that the user’s legs are stable and
on the foot support.
• Never place hands, feet or foreign objects into
the tilt mechanism area.
• Never add accessories that are not specically
designed for the TrekkerTM Seating Module, as
they may interfere with the tilt mechanism.
• Never allow the user’s head to tilt/recline
beyond the horizontal plane to the oor.
• Never operate the tilt mechanism without
having a rm hold of the push handle.
• When tilting the chair, be aware that a change in
angle can create a sudden shift.
Tilt-in-Space Adjustment
The YoYo is equipped with a tilt-in-space mechanism.
The tilt-in-space range in the is -10º anterior to 30º posterior. FIG.33a
+30°
-10°
FIG.33a
FIG.33b
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
READ BEFORE USE
Read manual completely before use! Familiarize yourself with the handling and
functions of the product before use and practice them. You must read and fully
understand the contents of this manual. Any caregiver that is going to operate this
chair should also read the manual in full.
You are responsible for the safety of the user. The safety of the user could be
affected if you do not follow the instructions in this manual. Nevertheless, not all
possible circumstances and unpredictable situations can be covered by this
manual. Reason, care, and circumspection are not features of the product; they
are required of persons who use the product. If instructions are not clear and
further explanation is necessary, please contact your Convaid provider.
If you do not follow all instructions and warnings, damage to the chair or serious
injury may occur.
DEFINITION OF SYMBOLS
WARNING!
The word “WARNING” and/or the symbol shown above indicates
practices that are unsafe or dangerous and could result in serious injury
or death to the occupant of this chair or others.
WARNING! READ INSTRUCTION MANUAL!
Additional symbols are defined throughout this manual along with
operating instructions.
CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
There are several options available to meet the needs of the wheelchair user.
Make sure that your (and your health care provider’s) choice of chair and other
added options takes into account the user’s comfort, positioning, physical
limitations, and hazards that may be encountered during daily use. Operating the
manual wheelchair outside of the recommendations provided by the manufacturer
can lead to a dangerous situation.
!
CONVAID USER’S GUIDE
To Adjust the Tilt Angle:
1. Move the user to the desired tilt angle while holding the handle and the tilt lever.
2. With your left hand, hold onto the handle on the back of the seating module,to support the
weight of the occupant. FIG.33b
3. With your right hand, squeeze the tilt lever on the handle. FIG.33b
4. Release the lever to engage the tilt lock. FIG.33b
WARNING: When activating the tilt, gradually squeeze the lever to
allow the care giver to support the weight.
