Convotherm CONVOVent min Manual

CONVOVent mini /
CONVOVent mini 2in1
ENG Operating, Installation,
and Service Manual
Translation of the original


Table of Contents
CONVOVent mini / mini 2in1 2
Table of Contents
1General information 4
►EC Declaration of Conformity in compliance with Directive 2006/42/EC, Annex II A 5
►Environmental protection 6
►Identifying your condensation hood 7
►About this operating, installation, and service manual 8
2Design and function 10
►Intended purpose 11
►Design and function of the condensation hood 12
►Technical data 13
3For your safety 15
►Basic safety code 16
►Warnings on the condensation hood 17
►Summary of hazards 18
►Hazards and safety precautions 20
►Safety devices 22
►Requirement to be met by personnel, working positions 23
►Personal protection equipment 24
4Operation 25
►Basic operating sequence 26
5Cleaning and Maintenance 27
►Cleaning and maintenance schedule 28
6How to do it correctly 30
►Opening the appliance door safely on the combi steamer fitted with hood 31
►Removing and fitting the front panel 32
7Moving and setting up the appliance 33
►Requirements for the installation location 34
►Taking to the installation location 34
►Unpacking 35
►Installing the CONVOVent mini 35
►Installing the CONVOVent mini 2in1 38
8Connecting up the appliance 40
►Electrical installation 41
►Design and function of the condensation hood for the installation engineer 42
9Preparing for first-time use, taking out of service and
disposal 46
►Safe working 47
►Procedure for preparing the appliance for first-time use 48
►Taking out of service and disposal 49

Table of Contents
CONVOVent mini / mini 2in1 3
10 Service and Repairs 50
►Troubleshooting 51
►Service manual 52
►Spare parts list and circuit diagram 56

General information
CONVOVent mini / mini 2in1 4
1 General information
Purpose of this chapter
This chapter shows you how to identify your appliance and provides guidance on using this manual.
Contents
This chapter includes the following topics
Page
EC Declaration of Conformity in compliance with
Directive 2006/42/EC, Annex II A 5
Environmental protection 6
Identifying your condensation hood 7
About this operating, installation, and service manual 8

General information
CONVOVent mini / mini 2in1 5
►EC Declaration of Conformity in compliance with Directive
2006/42/EC, Annex II A
Manufacturer
CONVOTHERM Elektrogeräte GmbH
Talstraße 35
82436 Eglfing
Germany
Condition when placed on market
This declaration applies only to the machine in the condition in which it was placed on the market. It
does not cover any subsequent modifications and/or parts fitted later by the end user This declaration
is invalidated if the product is converted or modified without approval.
Appliances
This Declaration of Conformity applies to the following condensation hoods:
CONVOVent mini
CONVOVent mini 2in1
Declaration of Conformity with directives
The manufacturer declares that its condensation hoods, as listed above, comply with European Di-
rective 2006/42/EC (Machinery Directive, Official Journal of the European Union L 157/24 dated
9.6.2006) and with the following directives.
The safety objectives of European Directive 2006/95/EC (Low Voltage Directive, Official Journal of the
European Union L 374/10 dated 27.12.2006) have been met in accordance with Annex I, Section 1.5.1
of the Machinery Directive.
Compliance with other Directives
The condensation hoods comply with the following European directives:
2004/108/EC, Official Journal of the European Union L
390/24 dated 31.12.2004
RoHS 2002/95/EC, Official Journal of the European
Union L 37/19 dated 13.2.2003
Type examinations carried out
The following type examinations have been carried out:
Notified body for EMC testing:
mikes-testingpartners gmbh, Ohmstr. 2-4, 94342 Strasskirchen, Germany
Report no. E33312-00-00HP
Reference no. BNetzA-bs EMV-07/61-07
Notified body for Electrical safety:
TÜV Süd Management Service GmbH, Ridlerstr. 65, 80339 Munich, Germany
Report no. 028-71343738-000
Certificate registration no. Z1A 10 02 18434 033

General information
CONVOVent mini / mini 2in1 6
Quality and environmental management
CONVOTHERM Elektrogeräte GmbH employs a certified quality management system in accordance
with ISO 9001:2008 and a certified environmental management system in accordance with
ISO 14001:2004.
Notified body for quality management system and environmental management system:
TÜV Süd Management Service GmbH, Ridlerstr. 65, 80339 Munich, Germany
Süd report no. 70007041
Certificate registration no. 12100/104 14754 TMS
Authorized representative
The following person is authorized to compile the technical documentation in accordance with Annex II
A Section 2 of Directive 2006/42/EC
CONVOTHERM Elektrogeräte GmbH, Gisela Rosenkranz, Abteilung technische Redaktion, Talstraße
35, 82436 Eglfing, Germany
Eglfing, dated 29.12.2009
ppa. Lutz Riefenstein
Bereichsleiter Technik / General Manager Engineering
►Environmental protection
Statement of principles
Our customers' expectations, the legal regulations and standards and our company's own reputation
set the quality and service for all our products.
We have an environmental management policy that not only ensures compliance with all environmen-
tal regulations and laws, but also commits us to continuous improvement of our green credentials.
We have developed a quality and environmental-management system in order to guarantee the con-
tinued manufacture of high-quality products, and to be sure of meeting our environmental targets.
This system satisfies the requirements of ISO 9001:2008 and ISO 14001:2004.
Environmental protection procedures
We observe the following procedures:
Use of residue-free compostable wadding materials
Use of RoHS-compliant products
Multiple re-use of cardboard packaging
Recommendation and use of bio-degradable cleaning agents
Recycling of electronic waste
Environmentally friendly disposal of old appliances via the manufacturer
Join us in a commitment to environmental protection.

General information
CONVOVent mini / mini 2in1 7
►Identifying your condensation hood
Position and layout of the type plate
You can use the type plate to identify your hood. The type plate is located on the left-hand side of the
hood.
The type plate has the following layout:
Key
The following table lists the relevant items on the type plate:
Item number Meaning
1 trade name
2 Part number
3 serial number
The code making up the trade name (1) in the type plate identifies your appliance:
Elements of the trade
name
Meaning
Letters / Numbers
C CONVO
V Vent
EL electric
mini suitable for the mini range of
combi steamers (table-top
appliances)
mini 2in1 suitable for the mini range of
combi steamers (floor-
standing appliances)

General information
CONVOVent mini / mini 2in1 8
List of matching CONVOTHERM combi steamers
Use the table below to identify your condensation hood and the matching combi steamer from the
trade name on the type plate:
Model
Condensation hood
For combi steamer model
3424725 Table-top appliances
OES 6.06 mini
OES 6.10 mini
OES 10.10 mini
3425012 Floor-standing appliances
OES 6.06 mini 2in1
OES 6.10 mini 2in1
►About this operating, installation, and service manual
Purpose
This manual provides answers to the following questions:
How can I use the hood?
How do I install the hood?
How do I service and repair the hood?
Who should read this manual
These operating instructions and the installation and service manuals are aimed at the following target
groups:
Chef
User
Installation engineer
The target groups must have the qualifications listed in "Requirements to be met by personnel on page
23".

General information
CONVOVent mini / mini 2in1 9
Layout of the operating instructions
The table below lists the chapters in this user manual and summarizes their content, purpose, and
target groups:
Chapter/section Purpose
General information Shows you how to identify your hood
Explains how to use these operating, installation and service instructions
Design and function Specifies the intended use of the hood
Explains the functions of the hood and shows the position of its components
Summarizes the technical data
For your safety Describes the hazards posed by the hood and suitable preventive actions
You should read this chapter carefully in particular.
Operation Contains instructions for the operating procedures used with the hood
Cleaning and Maintenance Contains the cleaning schedule
Contains the maintenance schedule where relevant to the user
Contains cleaning instructions
How to do it correctly Contains instructions for regularly used operating procedures for the hood
Moving and setting up the
appliance
Specifies the basic appliance dimensions
Specifies requirements for the installation location
Provides information on conveying the appliance to the installation location,
unpacking and setting up
Connecting up the appli-
ance
Provides information on the electrical installation
Explains the functions of selected components in the hood and shows their
position
Preparing for first-time use,
taking out of service and
disposal
Explains the procedure for preparing the appliance for first-time use
Explains the procedure for taking out of service
Contains disposal instructions
Service and Repairs Provides troubleshooting recommendations
Contains an exploded assembly drawing, a spare parts list, and the circuit diagram
Contains instructions for regularly used operating procedures for repairing the
hood
Symbols used for safety instructions
Safety instructions are categorized according to the following hazard levels:
Hazard level Consequences Likelihood
Death / serious injury (irreversible) Immediate risk
Death / serious injury (irreversible) Potential risk
Minor injury (reversible) Potential risk
Caution Damage to property Potential risk

Design and function
CONVOVent mini / mini 2in1 10
2 Design and function
Purpose of this chapter
This chapter specifies the intended use of the appliance and explains its functions.
Contents
This chapter includes the following topics:
Page
Intended purpose 11
Design and function of the condensation hood 12
Technical data 13

Design and function
CONVOVent mini / mini 2in1 11
►Intended purpose
Intended use
The hood must only be used for the purposes specified below:
The hood is designed solely for condensing the steam and vapor from the air vent of the combi
steamer.
The hood is designed for combi steamers from the following model series: OES 6.06 mini, OES
6.10 mini, OES 10.10 mini, OES 6.06 mini 2in1 and OES 6.10 mini 2in1.
The hood is intended solely for professional, commercial use.
The ambient temperature must lie between 4°C and 35°C.
The hood does not need to be connected directly to an extraction system as the exhaust air from
the combi steamer is condensed by a condensation unit.
In addition, the hood is only being used as intended when the following conditions are met:
To avoid accidents and any damage to the hood, the owner must train staff on a regular basis.
The hood must be operated only by trained staff.
The manufacturer regulations for operation and maintenance of the hood must be observed.
Restrictions on use
The following restriction on use must be observed:
The hood improves the environment in the kitchen but is no substitute for an air conditioning sys-
tem.
The hood must only be operated when all safety devices are fitted and in working order.
Requirements to be met by personnel
The following requirements must be met by personnel:
The hood must only be operated by trained personnel only.
Requirements relating to the operating condition of the condensation hood
The following requirements relating to the operating condition of the hood must be met:
The hood must only be operated when all safety devices are working correctly.
The hood must only be operated when all covers are fitted correctly.
The hood must only be operated when the front panel is fitted correctly.
Requirements relating to the operating environment of the condensation hood
The following requirements relating to the operating environment of the hood must be met:
The hood must not be operated if the national and local regulations regarding ventilation and dis-
charge, or the specific requirements for the relevant cooking equipment, are not complied with.
The hood must not be operated in the vicinity of flammable gases or liquids.
The hood must not be operated in toxic or potentially explosive atmospheres.
Cleaning requirements
The following requirements must be met during cleaning:
The combi steamer and the hood must be disconnected from the power supply in order to clean the
hood.
It is only permitted to use the following materials:
- Common household, non-alkaline detergent that is gentle on the skin and is pH-neutral
Do not let the fans come into contact with cleaning agents.
High-pressure cleaners, sprinklers or water jets must not be used for cleaning.
The hood must not be treated with acids or exposed to acid fumes.

Design and function
CONVOVent mini / mini 2in1 12
►Design and function of the condensation hood
Layout
The following diagram shows how the hood is positioned on a combi steamer:
OES 6.06 mini
1234
OES 6.06 mini 2in1
1234
2
Parts and their function
The parts shown have the following function:
No. Name
Function
1
Switches the hood on and off
2 Dehumidifier valve (ventilati-
on port)
External air intake for removing the moisture from the oven compartment.
3 Air outlet Allows air to exit
4 Front panel with filter Prevents fans from soiling
Basic principle of operation
The hood is designed solely for condensing the steam and vapor emitted from the air vent of a combi
steamer.

Design and function
CONVOVent mini / mini 2in1 13
►Technical data
Dimensions and weights
The following table shows appliance dimensions and weights:
CONVOVent mini CONVOVent mini 2in1
Width (mm)
including packaging 570 570
excluding packaging 515 515
Depth (mm)
including packaging 680 680
excluding packaging 564 589
Height (mm)
including packaging 210 250
excluding packaging 135 175
Weight (kg)
including packaging 19 21
excluding packaging 15 17
Safety distances (mm)
Rear 50 50
scroll right 50 50
scroll left 100 100
Above 500 for ventilation 500 for ventilation
Material
Stainless steel
Electrical connected load ratings
The following table shows the electrical installed load ratings:
CONVOVent mini CONVOVent mini 2in1
Rated power consump-
tion (kW)
1N~ 230V 50/60Hz 0,06 0,06
Rated current (A)
1N~ 230V 50/60Hz 0,26 0,26
Fuse protection (A)
1N~ 230V 50/60Hz 16 16

Design and function
CONVOVent mini / mini 2in1 14
Heat output
The following table shows the heat output of the combi steamer fitted with the hood:
6.06 mini 6.10 mini 10.10 mini 6.06 mini 2in1 6.10 mini 2in1
Heat output (kJ/h)
latent heat 200 266 370 400 740
sensible heat 1580 2088 2918 2760 4146
Appliance technical standards
The following table shows the technical standards for the appliance:
CONVOVent mini CONVOVent mini 2in1
Degree of protection IPX4 IPX4
Approval mark TÜV / GS, DIN GOST TÜV / GS, DIN GOST
Noise emission [dB (A)] < 60 < 60

For your safety
CONVOVent mini / mini 2in1 15
3 For your safety
Purpose of this chapter
This chapter provides you with all the information you need in order to use the appliance safely without
putting yourself or others at risk.
You should read this chapter carefully in particular.
Contents
This chapter includes the following topics:
Page
Basic safety code 16
Warnings on the condensation hood 17
Summary of hazards 18
Hazards and safety precautions 20
Safety devices 22
Requirement to be met by personnel, working positions 23
Personal protection equipment 24

For your safety
CONVOVent mini / mini 2in1 16
►Basic safety code
Object of this safety code
This safety code aims to ensure that all persons using the appliance have a thorough knowledge of
the hazards and safety precautions and that they follow the safety directions given in the operating
instructions and on the appliance. If you do not follow this safety code, you risk potentially fatal injury
and property damage.
Working with the operating instructions
Follow the instructions below:
Read in full the Safety chapter and chapters that relate to your work.
Always keep the operating instructions to hand for reference.
Pass on the operating instructions with the appliance if it changes owners.
Working with the appliance
Follow the instructions below:
Only people who satisfy the requirements set forth in these operating instructions are allowed to use
the appliance.
People (including children) who, because of their physical, sensory or intellectual capabilities, or
because of their lack of experience or knowledge, are incapable of using the appliance safely,
should not use this equipment without the supervision or guidance of a responsible person.
Use the appliance only for its specified use. Never, under any circumstances, use the appliance for
any other purposes that might seem self-evident.
Take all the safety precautions specified in these operating instructions and on the appliance. In
particular, use the prescribed personal protection equipment.
Only stand in the working positions specified.
Do not make any changes to the appliance, e.g. do not remove parts or install non-approved parts.
In particular, you must not disable any safety devices.
Secure appliances with wheels in order to ensure that they don't move accidentally.

For your safety
CONVOVent mini / mini 2in1 17
►Warnings on the condensation hood
Where are the warning signs fitted?
The warning signs are located in the following positions on the hood:
1
Warning on the inside
The following warning is affixed inside on the electrical box cover (1):
Warning sign Description
Warning of electric shock
There is a risk of electric shock from live parts if the appliance cover is opened.

For your safety
CONVOVent mini / mini 2in1 18
►Summary of hazards
General rules for dealing with hazards and safety precautions
The appliance is designed so to protect the user from all hazards that can reasonably be avoided by
design measures.
The actual purpose of the appliance, however, means that there are still residual risks; you must there-
fore take precautions to avoid them. A safety device can provide you with a certain degree of protec-
tion against some of these hazards. You must ensure, however, that these safety devices are in place
and in working order.
The nature of these residual risks and what effect they have are described below.
Hazard points
The following diagram shows the hazard points when the front panel has been removed from the air
inlet (representative of all appliance sizes):
123
No. Description
1 Appliance cover
2 Grill over air outlet
3 Grill over air intake (in front of fans)
Damaged power cable
The appliance's power cable may become damaged during transit. This poses:
A risk of electric shock from damaged power cable.
Live components
The appliance contains live parts. This poses:
A risk of electric shock if covers are not in place.
Risk of electric shock caused by a short-circuit when spraying water on the appliance.
Missing equipotential bonding
No equipotential bonding installed. This poses:
A risk of electric shock when the hood is not incorporated into the equipotential bonding of the
combi steamer.

For your safety
CONVOVent mini / mini 2in1 19
Hot steam / vapor
The combi steamer generates hot steam and vapor that escape when the appliance door is opened.
This poses:
A risk of scalding from hot steam when the appliance door is opened. You are protected from hot
steam by the appliance door itself.
Hot vented air
The combi steamer generates hot steam / vapor that is removed through the air vent on top of the
combi steamer into the hood. This poses:
A risk of scalding at the air outlet.
Hot components
If the hood is not switched on while the combi steamer is running, this poses:
Risk of burns from hot hood components.
Hot components (air vent)
The combi steamer generates hot steam / vapor that is removed through the air vent on top of the
combi steamer into the hood. This poses:
A risk of burns at the air-outlet grill.
Risk of burns on the left side of the hood housing.
Moldy and bacterially contaminated water
If the hood is not used for a long time, this poses:
Risk of contamination from moldy and bacterially contaminated water.
Condensation collection
The hood is not turned on when using the combi steamer. This poses:
A risk of mold formation from condensation collecting inside the appliance.
Overstressing your body
If a single person tries to lift the appliance by himself/herself, the appliance's weight may lead to:
A risk of injury, especially in the area of the torso, from incorrect lifting.
Contact with cleaning agents
Cleaning agents can come into direct contact with your skin and eyes. This poses:
Risk of skin and eye irritation or chemical burns.
Hood falling down
If the hood is not fastened to the combi steamer correctly, the hood may slip and fall down. This poses:
Risk of crushing various parts of the body from the hood falling down.
Combined units falling over
Mounting the hood on top of the combi steamer increases the risk of the units toppling over. This
poses:
Risk of crushing various parts of the body from the combined units falling over.

For your safety
CONVOVent mini / mini 2in1 20
Rotating fan
The appliance contains a fan. This poses:
A risk of hand injuries or hair or loose clothing being caught by the rotating fan wheel if the cover is
not fitted properly.
►Hazards and safety precautions
Moving and setting up the appliance
When moving and setting up the appliance, be aware of the following hazards and take the specified
preventive actions:
Hazard Where or in what situation
does the hazard arise?
Preventive actions Safety device
Risk of injury from over-
stressing your body
When setting up and moving the
hood
Only with enough people or
appropriate tools
None
Risk of crushing from hood
falling down
When the hood is not secured on
the combi steamer
Screw-fix to the combi steamer Securing with
fixing screws
Risk of crushing from the
combined units falling over
When fitting a hood to a combi
steamer
Check that the combined units
cannot tip over
Ensure that they are fitted on
a horizontal and flat surface
None
A risk of electric shock from
damaged power cable
On the back of the appliance Check the power cable None
Operation
When operating the appliance, be aware of the following hazards and take the specified preventive
actions:
Hazard Where or in what situations
does the hazard arise?
Preventive action Safety device
Risk of scalding from hot
steam
In front of the appliance door Check safety device
use safety device
On-latch posi-
tion of appliance
door
Risk of electric shock from
live parts
Under the cover Check safety device Cover
Risk of contamination from
moldy and bacterially
contaminated water.
Inside the hood Clean before leaving out of use
for extended periods
None
A risk of burns from hot
components
At the air outlet Do not touch the air-outlet grill Safety grill
Outside the hood Always switch on the hood
during combi steamer opera-
tion
None
Risk of injuries from
rotating fan
Inside the holding chamber Check safety device Safety grill
Panel
