COOK 4 LIFE GASONOVA BRAAI User manual

USER GUIDE
GASONOVA
BRAAI
USER GUIDE

HEAD OFFICE:
Cook4Life Office Park
26 & 27 Waitara Road
Pompagalana A/H
Tzaneen, 0850
Limpopo Province, South Africa
CALL CENTRE:
[phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.cook4life.co.za

CONTENTS
WELCOME TO COOK4LIFE ............................... PAGE 4
COOK4LIFE WARRANTY ................................. PAGE 4 - 5
INSTRUCTION MANUAL ................................. PAGE 6 - 13

4
WELCOME
TO THE
COOK4LIFE
FAMILY!
Congratulations on your purchase from
Cook4life. At Cook4Life we care about
you. We inform, educate and empower our
customers to live a happy, nutritional and
healthy lifestyle that lets you spend so much
more time with your friends and family
By purchasing your Cook4Life product,
you automatically became part of the most
trusted network marketing brand in South
Africa. Cook4life customers all over the
country have experienced the benets of a
healthier lifestyle using Cook4Life products.
Your Cook4Life product will not only Save
you time and money but also allow you to
prepare healthier and more delicious meals
for you and your family.
To get the most value out of your Cook4life
product, please read through this guide
which will tell you more about how to use
and care for your investment.
COOK4LIFE
WARRANTY
ELECTRICAL APPLIANCES & NON ELECTRICAL
PRODUCTS
Cook4Life warrants to the original purchaser of
this product (“the client”) that this products will be
free of defects in quality and workmanship under
normal personal, family or household use for a
period of 1 (one) year from the date of purchase
(“warranty period”).
Where the client has purchased the product and
it breaks, is defective or does not work properly or
for the intended purpose, the client must notify
Cook4Life thereof with the warranty period. Any
claim in terms of this warranty must be supported
by a proof of purchase. If proof of purchase in
not available, then repair, and/or service charges
maybe be payable by the client to Cook4Life. All
repair, and/or service charges are payable up front
upon receipt of a Proforma Invoice from Cook4Life.
The faulty product must be taken to Cook4Life’s
nearest regional office to exercise the warranty.
The product must be in good working condition,
with your original proof of purchase, name,
address, telephone number, and a description
of the claimed defect. Returned goods must be
complete with all the accessories included in the
original purchase. You will be required to offer
us an explanation for the return and offer us the
opportunity to address any problems. Cook4Life
will provide the client with a charge for transport
and handling.
Cook4Life will repair or exchange the product
in terms of this warranty subject to legislative
requirements. This warranty shall be valid only
where the client has not broken the product
himself, or used the product for something that it
is not supposed to be used for. The warranty does
not include and will not be construed to cover
products damaged as a result of disaster, misuse,
tamper, abuse or any unauthorised modication or
repair of the product. Every possible precautionary
measure to prevent damage to the product has
been taken.

5
If the client requests that Cook4Life repairs the product
and the product breaks or fails to work properly within 3
(three) months of the repair and not as a result of misuse,
tampering or modication by or on behalf of the client,
then Cook4Life may replace the product.
The client may be responsible for certain costs where
products returned are not in the original packaging,
or if the packaging is damaged or if all the accessories
included in the original purchase, are not included.
WHAT IF THE GOODS ARE DEFECTIVE?
If within 6 months from date of purchase the goods are
found to be defective due to a manufacturing or material
defect, and not due to abuse, misuse or tampering, then
Cook4life will repair or replace the goods.
If after the initial 6 months from date of purchase, the
goods are found to be defective due to a manufacturing
or material defect, and not due to abuse, misuse or
tampering, then Cook4life will send the goods to the
manufacturer for assessment and the manufacturer will
decide whether you have a valid claim, and if so repair or
replace the goods.
If the goods become defective after the 12 months from
date of purchase Cook4life can arrange to have the
goods repaired at a cost. No repairs will be done without
the approval of a quotation rst, as well as payment
received from the client.
WHEN WILL THE WARRANTY FROM COOK4LIFE NOT
APPLY?
The 1 year warranty from Cook4life will only apply to
manufacturing defects of goods, and will not apply in
the following instances:
• Damage caused by accident to the goods
• Damage caused by tampering, abuse or misuse of
the goods
• If the goods are used for any other purpose other
than which they were manufactured for
• If the goods are not cared for or used according to
their instruction manuals

6
INSTRUCTION MANUAL
THIS INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE
PROPER ASSEMBLY AND SAFE USE OF THE GASONOVA GRILL. FOLLOW ALL WARNINGS
AND INSTRUCTIONS. FAILURE TO FOLLOW SAFETY INSTRUCTIONS MAY RESULT IN SERIOUS
BODILY INJURY OR DEATH, OR MAY RESULT IN A FIRE OR AN EXPLOSION CAUSING DAMAGE
TO PROPERTY.
IMPORTANT SAFTEY INSTRUCTIONS
IF YOU SMELL GAS:
1. Shut off gas to the appliance immediately.
2. Extinguish any open ame.
3. Open lid.
4. Do not ignite any ame in, near or around the vicinity of the appliance until the smell of
gas has disappeared.
DANGER
1. Do not store or use gasoline or other ammable liquids or vapours in the vicinity of this
or any other appliance.
2. An LPG gas cylinder not connected for use shall not be stored in the vicinity of this or
any other appliance.
WARNING
1. This appliance is for OUTDOOR USE ONLY.
Under no circumstances is it to be used
indoors.
2. Read all operating instructions and familiarize
yourself with the appliance before operating.
3. Do not perform any servicing on this
appliance yourself. Servicing must only
be conducted by a suitably qualied and
authorized technician.
4. Always check for leaks when the cylinder is
replaced or reconnected.
5. Do not store chemicals or ammable
materials on or near this appliance.
6. Children should not be left unsupervised
near the appliance warming up, during use or
while it is cooling down.
7. Flammable clothing should not be worn near
the appliance when it is operating.
8. Do not leave food unattended on the
appliance.
9. If a fat re occurs, immediately turn off the
gas cylinder.
10. Hot fat can cause serious burns. Care must be
taken when removing the grease tray.
11. This appliance must not be positioned under
any overhead combustible construction,
and the advised minimum distances from
combustible materials must be maintained at
all times. Minimum clearance to combustibles
is 3 metres including structures.
12. Never operate the Gasonova Grill within 10
metres of ammable liquid.
13. When not in use, ensure all gas valves
including the cylinder are turned off.
14. Never leave the burners on“High”for more
than 10 minutes unless actually cooking. If

7
GENERAL INFORMATION
the burner makes a ‘hissing’sound during use,
the ame may have ashed back inside the
burner. If this occurs turn the burner off, allow
it to cool and relight it.
15. Do not allow unburnt gas to build up. Always
provide sufficient ventilation. The hose
assembly connects to the appliance with a
¼ BSP Male compression tting. It must be
tightened using a suitable spanner (such as
an adjustable wrench) to obtain a gas tight
seal. The joint must be tested for leaks using
a soapy water solution after each connection.
If a leak is detected the joint must be sealed
before the appliance is used.
• Minimum LPG cylinder size ‐ 2Kg, certied
and marked to be compliant.
• Strong winds and low ambient temperatures
will affect the heating performance of the
appliance. You should consider these factors
during use; it is part of cooking outdoors.
• Never use your appliance in a garage, porch,
breezeway or any other similar enclosed area.
• Air ow is vital for this appliance’s safe
operation; do not obstruct the ow of
ventilation in or around this appliance.
• This appliance is not intended to be installed
in recreational vehicles or marine vessels.
• Gas owing through your regulator can cause
a humming sound; this is normal and not a
cause for concern. Purging the gas system
of air can assist in reducing this noise and
should be done each time a gas cylinder is
connected to the appliance.
• Ensure all transit material has been removed
prior to assembly and use.
• Lay out all components prior to assembly,
then check all components are included.
• The installation must conform with local
regulations

INSTRUCTION MANUAL
8

9
SAVE THIS MANUAL FOR FUTURE REFERENCE
ASSEMBLY INSTRUCTIONS
Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly.
Once the grill is fully assembled, go back and check to make certain all the bolts are secure. Tighten again only
if necessary.
Step 1:
Unpack the box, and take out the body. Open the legs as the diagram.
Step 2:
1 Attach the left side wing on the body with M6x4PCS (15mm).
2 Attach the right side wing same as left side.
Step 3:
Before attaching the right side wing, insert the valve outlet into the burner tube. Attach the spark electrode wire
onto the gas valve.

10
INSTRUCTION MANUAL
Step 4:
1 Open the lid and put the cooking grid and cooking plate into the body.
2 Attach the handle on the lid with M6 washer, M6 split washer and M6 nut.
Step 5:
Put the side shelves on the both wing side.
Step 6:
Attach the oil box on the bottom of the body.
Step 7:
Gas connection. Connect the POL regulator to the LPG cylinder. Conduct a thorough leakage test as described in
the following section. DO NOT USE UNLESS ALL CONNECTIONS ARE GAS TIGHT.

LEAK TESTING GAS CONNECTIONS
All gas connections must be tested for leaks before each use using a soapy water solution. With the gas
cylinder turned on and the appliance controls off, drip sponge soapy water onto the gas inlet connection,
hose and cylinder connection, then look for a stream of bubbles. A stream of bubbles indicates a leak which
must be sealed before the appliance is used. NEVER use a naked ame to test for gas leaks.
Pre Lighting Checks
1. After testing for leaks and being sure that all connections are gas tight, ensure the appliance controls
and gas cylinder are turned off.
2. Find a at and stable surface to place the Gasonova Grill.
3. Make sure there is sufficient gas in the gas cylinder.
4. Ensure the burner is correctly located on the gas control.
5. Open the lid.
Lighting the Appliance
1. Open the lid. Note: Attempting to light the burner with the lid closed may cause an explosion.
2. The valve must be in the“OFF”position.
3. Turn gas supply at the cylinder “ON”
4. Push in the control knob completely (3 to 4 seconds) and rotate slowly 1/4 turn counter clockwise
until a click is heard. The burner should light. Observe the burner ame and make sure all burner ports
are alight. A blue/yellow ame should appear from the burner. If the burner does not light, turn the
control knob to “OFF” position immediately, wait 5 minutes then repeat the lighting procedure. When
the burner is alight, adjust the valve knob to the desired cooking temperature.
Manual Lighting Method
1. Insert a long lit BBQ match through the cooking grid slots, next to the rst burner port. The rst burner
port is located next to the spark electrode.
2. Push and turn control knob to “HIGH” setting. After lighting observe the burner ame, make sure
all burner ports are alight. If ignition does not take place, turn the burner control knob to the “OFF”
position. Wait ve minutes with lid open for the gas to clear before repeating the lighting procedure.
Shutting o the burner:
1. Turn the valve knob clockwise all the way to the “LOCK OFF’’ position.
2. Immediately close the LPG Cylinder valve.
11

12
INSTRUCTION MANUAL
CURING THE CAST IRON
During manufacture the cast iron cooking surfaces were coated with a non‐toxic paint to protect them from
corrosion during storage and transport. This coating will come completely off in time. However the cooking
surface must be cured to assist with food not sticking to it. To do this, coat the cooking surface in a light
coating of inexpensive cooking oil. Turn burner to “Low” and maintain this for 20 minutes (some paint may
start to come off during this process). Turn the appliance off and allow it to cool. Clean the cooking surfaces
and the curing process is complete. This needs only to be once when the appliance is new but it may be
repeated at a later date to maintain the non‐stick properties of the cast iron surface.
CONTROLLING THE TEMPERATURE
The temperature of the appliance is set by adjusting the control knob between high and low ame setting.
The maximum setting for closed hood roasting is the low ame setting.
COOKING TIPS
The appliance must be warmed up before use, light the burner and allow it to operate on high for 3 – 5
minutes. When cooking meat, resist the urge to continually turn it over. For moist juicy meat, turn it once only
during cooking. Juices rise to the top of meat during cooking and then settle.
Each time meat is turned, juices are lost and the meat becomes drier. Flames sometimes occur when fat
drippings fall onto the hot surfaces in the rebox and ignite. Some aming is normal and desirable as it helps
impart the unique avours associated with grilled foods. Controlling the intensity of the ames is necessary
in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental re. Always
monitor the grill closely when cooking and turn the ame level down LOW or OFF if ames intensify.
AFTER COOKING
Turn the valve knob clockwise to the “LOCK OFF’’ position to turn off the burner, then
close the LPG Cylinder valve. While the hotplate and grill are still hot, using a long handled brush and scraper,
remove any remaining food residue and wipe any excess fat from the cooking surfaces, then coat with fresh
cooking oil for continued protection against corrosion.
CLEANING
The appliance will look better and last longer if it is kept clean. You should check the burner periodically
for any sort of blockage. Look for any blockages of the ame ports and inside the burner. If any ame ports
are blocked, use a wire brush to unblock them. If there is a blockage inside the burner, use a stiff wire or pipe
cleaner to unblock it.
A sign that there is a blockage inside the burner is if the burner is ashing back regularly. If this is occurring,
remove the burner and inspect it for a blockage. Ensure the mesh at the burner air inlet is clean and clear
of blockages such as dust, grime, spider webs, etc. This mesh must be clean to ensure safe operation of the
burner. Grease can build up inside the appliance and this can be cleaned with a hot soapy water solution.
Do not use a caustic cleaner as it will irreparably damage the appliance’s coating. The grease tray should be

emptied regularly. Never touch the grease tray when hot, always allow it to cool completely before handling.
The hotplate, grill and grease tray can be placed in the dishwasher for convenient cleaning.
STORAGE
• Do not store the appliance until it has completely cooled.
• Storage of the appliance indoors is permissible only if the LPG gas cylinder has been disconnected,
removed from the appliance and remains outdoors.
• Store the appliance in a cool dry location.
• Always disconnect the gas cylinder and store it in a safe suitable location away from naked ames and
sources of ignition.The gas cylinder must be stored vertically, never lay it on its side. Store cylinder away
from children’s reach.
• If storing the appliance outdoors it is recommended to cover it with a heavy duty cover that will protect
it from the elements.
• Keep the cooking area free from combustible materials such as fuel, ammable vapours and liquids.
ABNORMAL OPERATION
• Due to unforeseen circumstances the appliance may not operate as designed. Indications of this are
ashing back in the burner, large soft yellow ames, ames lifting extensively away from the burner and
the appliance not igniting or remaining alight. If any of these conditions occur, you should rstly check
your gas supply to ensure there is sufficient gas, no leaks and the valves are opened sufficiently for use.
If this is the case and the problem/s still persists, you will need to contact a suitably qualied authorized
person to service your appliance.
CARE AND MAINTENANCE
• In addition to the regular cleaning of your appliance, there is some other minor maintenance that can
be performed to ensure its longevity. Before conducting any maintenance, ensure the gas cylinder is
turned off and disconnected.
• If there are any rubber seals as part of the gas connection, check them regularly for wear or cracking
and replace as necessary.
• It is recommended that a suitably authorized and qualied person should perform a thorough
examination of the appliance at least every 5 years.
• You should ensure that any LPG cylinder you use with this appliance is within its service life.
13

HEAD OFFICE:
Cook4Life Office Park
26 & 27 Waitara Road
Pompagalana A/H
Tzaneen, 0850
Limpopo Province, South Africa
CALL CENTRE:
[phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.cook4life.co.za
Cares about you
