Cookworks IM2104-GS Manual

Issue 1 28/7/2021 1
Ice Maker
Model No. IM2104-GS
Care & Instruction Manual
For household and indoor use only
Please read these instructions before use and retain for
future reference

Issue 1 28/7/2021 2
ELECTRICAL SAFETY
You should only plug the appliance into a 220V‐240V AC,
50Hz supply. Connecting it to other power sources may
damage the appliance and will invalidate the guarantee.
Switch off and unplug when not in use and before cleaning
the appliance.
It is recommended that the appliance and its cord is kept
out of reach of children less than 8 years.
Do not allow children to use the appliance without
supervision.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision. Children aged from 3 to 8
years are allowed to load and unload refrigerating
appliances.
Keep cable, plug and outside of appliance dry and away
from areas where it is likely to get splashed. Never immerse
in water.
Do not pull on the cable to disconnect from mains supply.
Do not operate the appliance if damaged or after it
malfunctions. In the event the supply cord is damaged, in
order to avoid a hazard it must only be replaced by a
qualified service engineer, with a suitably approved part.
This appliance must be plugged into an earthed socket
outlet.

Issue 1 28/7/2021 3
WARNING!
This appliance is intended exclusively for use in domestic
households. It is not suitable for commercial use.
Risk of fire / flammable materials. This product
contains a small amount of flammable
refrigerant. In the event of a refrigerant leak,
unplug the appliance, open the windows in the
area or move appliance outside away from
direct sunlight or sources of ignition.
WARNING: Keep ventilation openings, in the appliance
enclosure clear of obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Fill with fresh drinking water only. Never use
water from thawed ice cubes.
If moving the appliance, unplug, always transport in an
upright position and avoid mechanical damage.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or
portable power supplies at the rear of the appliance.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Only use for the intended purpose described in this manual
to make ice. Making ice cubes from drinking water.
Young children may not have the coordination or fully
understand the risks of water and electricity coming into
contact. Do not allow children under 8 years of age to fill
or refill the ice maker with water.

Issue 1 28/7/2021 4
PARTS
1. Housing
2. Lid
3. Viewing window
4. Control panel
5. Fixed cover
6. Air vents
7. Ice collection
basket
8. Ice scoop
9. Power cable
10. Ice shovel
11. Sensors
12. Filter
13. Water reservoir
14. Max water level
15. Drain plug
16. Foot
1
3
8
4
5
6
8
2
6
6
9
11
14
10
16
7
13
15
12

Issue 1 28/7/2021 5
CONTROL PANEL
17. On / OFF button
18. Small cube
indicator
19. Large cube
indicator
20. Clean indicator
21. Operational
mode (SELECT)
button
22. Ice full indicator
23. Add water
indicator
24. Power indicator
INDICATORS
Ice full
Activates when the ice basket is full. Production stops
automatically and will restart when ice is removed
from the ice basket.
Add water
Activates when the water reservoir is empty.
Production stops automatically and will restart
automatically after 20 minutes of adding water or
immediately after the ON/OFF button is pressed.
Clean
Activates when the ice maker needs to be cleaned or
the water pipes require flushing. See cleaning section.
20
23
21
17
19
18
22
24

Issue 1 28/7/2021 6
FITTING THE ICE COLLECTION BASKET
Fig. 1
BEFORE FIRST USE
1. Unpack the appliance and dispose of all packaging safely.
2. Check all parts are present and become familiar with the parts of
the ice maker and how to fit and lift out the ice collection basket
(fig.1).
3. Clean appliance and all detachable parts in accordance with the
cleaning section of these instructions.
4. Check that the drain on the underside of appliance is fully
closed.
5. Place the ice maker on a stable, flat surface that will be
undamaged by heat and water, that is within easy reach of a plug
socket and away from heat sources.
6. Ensure that there is 15cm clearance for adequate airflow around
all sides.
7. Allow the appliance to settle for 2 hours before using. Using
the appliance immediately can seriously damage the icemaker.
The resting time allows the oil in the compressor to flow back
into position and for the gas to settle.

Issue 1 28/7/2021 7
ICE MAKER USE
1. Place the ice maker in the desired location and ensure the oil
and gas have had chance to settle if the appliance has been
moved.
2. Lift the lid, remove the ice collection basket (if fitted).
3. Using a jug, fill the water reservoir with drinking water at or
below room temperature. Do not exceed the MAX level mark and
never use warm or hot water as this will damage the appliance.
4. Refit the ice collection basket and close the lid.
5. Fully unwind the cable and plug in, the POWER indicator will
illuminate and flash. For safety do not allow the cable to dangle
over the edge of units.
6. Press the ON/OFF button. The POWER indicator will stop
flashing.
7. Press the SELECT button until the indicator of choice is
illuminated.
‘S’ indicator illuminated = Small cubes
‘L’ indicator illuminated = large cubes
8. Ice making will start automatically and it will take 7 –15 minutes
to produce the first batch of ice. The time taken depends on the
ambient temperature and the temperature of the drinking water
added. Cooler room temperatures and drinking water will result
in ice being formed in a faster time. The sequence is as follows -
Water is pumped into the tray below the evaporator (metal
tube).
Ice begins to form around the evaporator.
When ice reaches the size selected (Small or Large), the
water tray under the evaporator tilts and the remaining
water drains back into the reservoir.
Ice drops from the evaporator and is pushed forward into
the ice collection basket by the ice shovel.
The water tray will return to the position under the
evaporator and the sequence will begin again.
9. When sufficient ice has been produced press the ON/OFF button
to switch off the appliance and transfer the ice to the freezer or
ice bucket
10. Unplug the appliance, allow it to warm up to room temperature
and drain the water from the reservoir if the appliance is not
going to be used again soon.

Issue 1 28/7/2021 8
REFILLING THE WATER RESERVOIR
If the ADD WATER indicator activates the water reservoir requires to
be refilled and the ice maker will pause automatically.
1. Open the lid and lift out the ice collection basket.
2. Using a jug, fill the water reservoir with cool drinking water. Do
not exceed the MAX level mark.
3. Refit the ice collection basket and close the lid.
4. Press the ON/OFF button to restart operation. If the ON/OFF
button is not pressed after refilling, operation will restart
automatically after 30 minutes.
CLEANING & MAINTENANCE
Rinsing the ice maker
After 24 hours of inactivity the water reservoir and pipework need
to be flushed for hygiene reasons.
1. Switch off and unplug the appliance.
2. Lift the lid and remove the ice collection basket.
3. Move the ice maker forward so that drain plug clears the worktop
by 6cm (fig. 2) and position a large bowl (e.g. washing up bowl)
to collect the residual water in the reservoir.
4. Open the drain plug (fig. 3) and empty the water.
5. Refit the drain plug and fill the water reservoir with fresh drinking
water.
6. Plug in and switch on the appliance and then press the SELECT
button until the ‘clean’ indicator starts to flash.
7. Press the ON/OFF button. The ‘clean’ indicator will stop flashing
and the pump will circulate water through the icemaker for 5
minutes and automatically stop.
Drain plug
Worktop
Drain plug
Fig. 3
Fig. 4
Fig. 2

Issue 1 28/7/2021 9
8. Once the water has been circulated, switch off the appliance,
open the drain plug and empty the water again.
9. Refit the drain plug (fig 4), reposition the ice maker, fill the water
reservoir with fresh drinking water and use as normal.
Cleaning the ice maker
Clean the icemaker once per week if in regular use, when the CLEAN
indicator activates, before and after prolonged storage.
1. Switch off and unplug the appliance and allow it to warm up to
room temperature.
2. Lift the lid and remove the ice collection basket.
3. If residual water can be seen in the water tray under the
evaporator, push the tray gently backwards so that all the water
drains back into the reservoir.
4. Move the ice maker forward so that drain plug clears the worktop
by 6cm (fig. 2) and position a large bowl (e.g. washing up bowl)
to collect the residual water in the reservoir.
5. Open the drain plug and empty the water (fig. 3).
6. Grip the filter and pull straight upwards to remove.
7. Wipe internal surfaces with a soft cloth soaked in warm water and
vinegar, rinse with clean water and then wipe dry.
8. Wipe external surfaces of the ice maker with a soft damp cloth
and dry surfaces with a soft dry cloth.
9. Wash loose parts (filter, ice scoop and ice collection basket) in
hot water with a little washing up liquid. Rinse and dry
thoroughly. Not suitable for the dishwasher.
10. Do not use boiling water, strong detergents or abrasives, as these
may dull or scratch the surface. Do not immerse in water. Do
not use a steam cleaner.
11.Ensure all parts are dry before refitting the drain plug (fig. 4),
loose parts and storing.
12. If the ice maker is left empty for long periods, switch off, defrost,
clean, dry, and leave the door open to prevent mould developing
within the appliance.

Issue 1 28/7/2021 10
TROUBLESHOOTING
Observation
Potential cause / solution
ADD WATER
indicator
illuminates
Low water level. Refill water reservoir and restart
icemaker.
Filter at bottom of water reservoir is blocked.
Clean the ice maker and filter
Pump malfunction. Call helpline 0345 640 3030
ICE FULL
indicator
illuminates
The ice basket is full. Remove ice from the
basket.
Diode sensor malfunction. Wipe sensors above
the ice collection basket to remove any foreign
objects and restart the ice maker. If indicator
still illuminated call helpline 0345 640 3030
ADD WATER &
ICE FULL
indicators
BOTH
illuminate
Water tray under the evaporator bar not in the
correct position. Unplug the appliance and
check if tray is being blocked
Sunlight falling on the diodes is interfering with
signal and means that ICE FULL sensor is
inoperative. Unplug ice maker and move it to a
more shaded position.
Ice sticks
together during
cycle
Ice production cycle too long. Switch off and
allow ice too melt before restarting..
Water temperature too low. Refill reservoir with
water between 8 - 25C
Ice making
cycle seems
normal but no
ice produced
Ambient or water temperature too high
Refrigerant system has leaked. Call helpline
0345 640 3030
Refrigerant system blocked. Call helpline 0345
640 3030
Poor ice
making
Poor heat dissipation. Ensure there is a
clearance of 15cm around all sides of the ice
maker.
Water temperature too high. Water reservoir
should be refilled will water between 8 - 25C
Ambient temperature too high. Operate ice
maker in room with temperature between 10 -
43C

Issue 1 28/7/2021 11
TECHNICAL SPECIFICATION
Cookworks Ice Cube Maker
Model
IM2104-GS
Rated Voltage & Frequency
220 - 240V ~ 50Hz
Rated Power Input
150W
Class rating
1 (earthed)
BS 1362 fuse
10A
Refrigerant
Type
R600a
Weight
24g
Climate class
ST / SN/ N /T
Insulating material
Expanded Polystyrene
Water reservoir capacity
1.75litres
Ice production capacity
9 pieces per cycle
10kg in 24 hours approx.
Ice storage capacity
0.5kg approx.
Product dimensions (external)
330 x 227 x 292 mm
Product weight (net)
7.55 kg approx.
RECYCLING ELECTRICAL PRODUCTS
You should now recycle your waste electrical goods and in
doing so help the environment.
This symbol means an electrical product should not be
disposed of with normal household waste. Please ensure it
is taken to a suitable facility for disposal when finished
with.
Visit www.recycle-more.co.uk, click on “bank locator” and
enter your postcode to find your nearest recycling site.

Issue 1 28/7/2021 12
PLUG / WIRING ADVICE
The wires in this mains lead are coloured in accordance with the
following UK electrical code: BLUE = NEUTRAL
BROWN = LIVE
GREEN + YELLOW = EARTH
Non-rewireable plug
This appliance may be fitted with a “non‐rewireable” plug. If you
need to change the fuse in a “non‐rewireable” plug, the fuse cover
must be refitted. If the fuse cover is lost or damaged, the appliance
must not be used.
Rewireable plug
The colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in a
rewireable plug. Rewireable plugs should only be replaced by a
suitably competent person. If in doubt, consult a qualified
electrician.
The BLUE wire must be connected to the
terminal marked with the letter N
The BROWN wire must be connected to the
terminal marked with the letter L
The GREEN & YELLOW wire must be
connecting to the terminal marked with the
letter E or the earth symbol .
Produced in China.
Argos Limited, 489-499 Avebury Boulevard,
Milton Keynes, MK9 2NW.
Argos (N.I.) Ltd, Forestside Shopping Centre,
Upper Galwally, Belfast, United Kingdom, BT8
6FX.
Argos Distributors (Ireland) Limited, Unit 7,
Ashbourne Retail Park, Ballybin Road,
Ashbourne, County Meath, Ireland
www.argos.co.uk/cookworks
Tel: [phone]

Issue 1 28/7/2021 13
