KitchenAid KUIC15P - 15 in. ARCHITECT Series II Ice... User manual

CABINET LINER AND DOOR PARTS
1
ICE CUBE
For Models: KUIC15PLXS0
(Stainless−Pump Model)
10−10 Litho In U.S.A. (mjb)(bay) Part No. W10334498 Rev.A
ICE CUBE
MAKER

CABINET LINER AND DOOR PARTS
2
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10206423 Use & Care Guide
W10206442 Service &
Wiring Sheet
2 3400886 Screw 8−18 x 1 1/4
3 2185742 Bin, Door
4 2185678 Spacer
5 2217394 Cover, Wiring
6 489442 Screw
7
W10320412 Door
8 2185695 Cam, Door
9 2217393 Assembly,
Magnetic Catch
10 2151652 Plug, Hole
12 2313816 Wrap, Door
13 2217367 Gasket, Bottom
15 2217294 Gasket, Door
16 2185640 Sleeve, Hinge
17
W10243391 Nameplate
18 2185710 Hinge, Top
19 2185709 Shim, Hinge
20 9872207S Handle, Door
21 8281186 Screw
22
W10136199 Assembly,
Unit Cover
23 8281184 Screw
24 Filler, Endcap
2185655B Left Side
2185656B Right Side
25 2185756 Pad, Foam
26 2185691 Channel, Wiring
27 2185964 Grommet,
Edge Guard (2)
28 3400240 Nut,
Leg Leveler
29 585158 Scoop
30 3400884 Screw 8−18 x 5/8
31 3400037 Screw 10−32 x 3/8
33 2185711 Hinge, Bottom
34 2185712 Pin, Hinge
35 489048 Screw, Ground
8−32 x 1/2
36 2208367 Clamp
37 8281265 Screw
38 348689 Screw 8−18 x 3/4
39 489423 Screw
40 2185927 Holder, Scoop
41 8281228 Thumbscrew
42 3374849 Leg, Leveler(4)
43 2217467 Tube, Air Vent
44
W10320111 Top
45 2185690 Shield, Electrical
46 2217293 Gasket, Top Panel
47 2185571B Grill, Front
48 489474 Screw 8−18 x 1
49 Cabinet & Liner
(NOT SERVICED)
50 489505 Clamp
51 2155774 Strap

3
EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498

EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
4
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION
1 W10163596 Valve, Complete
Water
2 2217286 Tube, Plastic
3 488208 Screw
4 2185523 Dispenser, Water
5
W10218037 Evaporator
6 2313705 Pump Reservoir
Drain
7 2313851 Tube, Reservoir
Pump
8
W10122016 Tube, Water Fill
9 488660 Nut, Speed
10 836667 Spacer
11 2208539 Fastener,
Pushnut
12 489443 Screw
13 2185625 Reservoir,
Water Slide
14 2185626 Tube
15 2313890 Hose, Overflow
16 2313604 Guide−Ice Grid
17 2313603 Bracket, Front
W10136175 Rear
18 2313602 Bracket, Side
Left and Right
19 2185681 Harness, Grid
20
W10217922 Tube
21 2310169 Wire Assembly
Valve
26 3400886 Screw 8−18 x 1 1/4
28 2313637 Grid Assembly
(Complete)
29 2174754 Wire, Grid Cutter
30 2185570 Cover, Grid
31 8281228 Thumbscrew
32 2324334 Reservoir, Water
33 3400884 Screw 8−18 x 5/8
34 2185696 Cap, Drain
35 3400909 Nut, Push−In

PUMP PARTS
5
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION
1 2313628 Pump Recirculating
2 3400884 Screw 8−18 x 5/8
3 2185677 Cover, Pump
4 2313844 Bracket, Connector
Assembly
5 2313627 Bracket−Pump
6 2313643 Sensor−Motor
8 2310092 Wiring Harness
Main To Pump
9 2313702 Pump Assembly

6
CONTROL PANEL PARTS
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION
1 2185738 Box, Control
2 2310139 Transformer
3
W10282116 Assembly, Switch
(ALSO ORDER #4)
4
W10282108 Overlay
5
W10226156 Control Board
6 2149705 Switch, Plunger
Grid/Light
7 2187585 Wire Assy
9 745362 Bulb
12 2313633 Thermostat, Bin
13 2185825 Clamp
15 3400884 Screw 8−18 x 5/8
18 3400850 Screw 8−16 x 3/8
20 2313635 Thermister,
Ice Control

UNIT PARTS
7
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498

UNIT PARTS
8
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2185532 Bracket, Fan Mtg.
2 2185675 Pad, Foam
3 2188935 Blade, Fan
4 2315558 Motor & Mounting
Plate Assembly
5
W10193296 Wiring Harness,
Complete Unit
(Includes
Power Cord)
6 304392 Screw 8−18 x 1/2
7
W10136195 Compressor
(Includes
Illus. 11,18,
20,21 & 23)
8 3405028 Clip, Mounting
9 A201441 Shim (4)
10 2185960 Clamp (Power Cord)
11 Grommet (4)
2217318 Production
4387558 Service
12 2208415 Tube, Process
13 489423 Screw
14 489472 Screw
15
W10206473 Coil, Solenoid
16 2313806 Hot Gas Valve
17 2187629 Wiring Harness,
Condenser Fan
18
W10136197 Combo Device
19 488500 Screw
22 2208534 Pump, Drain
23 Drier
W10183199 Production
4387019 Service
24 2313624 Condenser
25 2319835 Grommet−Cond.(1)
26 2208432 Tube, Drainage
27 2217397 Pad, Foam (2)
28 1115375 Clip−Wiring
29 8281197 Screw
30 2217445 Base, Unit
31 8281196 Screw
32 W1005420 Clamp−Nylon
33 3400884 Screw
34 851095 Wire Tie
35 2185672 Tube, Drain
36 489503 Clamp
37
W10282061 Shield
38 759113 Solenoid Valve
39 2301979 Plate
40 2188891 Motor
REFRIGERANT CHARGE
6.5 OZ. (R134A)

OPTIONAL PARTS (NOT INCLUDED)
9
For Models: KUIC15PLXS0
(Stainless−Pump Model)
W10334498
Illus. Part
No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
503695 Sealer, Cork
(1/4 Pound)
797403 Cement, Insulation
(1 Oz.)
505587 Sealer, Mastic
(1 Qt.)
212643 Sealer, Gum
(22 Pcs. 3/16" x 7")
479976 Kit, Insulation
(5 Pcs. 3" x 24"
x 48")
8537055 Cleaner,
Stainless Steel
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
ACCESSORIES
Previous Architect
Series Handle Kit
2217442S Stainless Steel
