COOLSTUFF KitchPro User manual

1
Ice crusher
Instruction manual

2
Read the instruction carefully before using your appliance for the first time.
Specifications
Name
Ice crusher
Rated time
1 minute
Size
100x130x285MM
(including base)
Weight
about 0.8kg
Voltage
AC 220-240V
Power
30W
Rated frequency
50Hz/60Hz
Safety instruction
1. Before using the appliance, please read this Safety Instruction carefully.
2. Comply with the safety precautions.
3. Please save this instructional manual after the first application.
4. Appliances can be used by persons with reduced physical, sensitive or mental capabilities or lack of
experience and knowledge, if they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
5. Children shall not play with the appliance.
6. Switch off the appliance and disconnect it from power supply before changing accessories or
approaching moving parts in use.
7. Always disconnect the appliance form the power supply if it is left unattended and before
assembling, disassembling, or cleaning.
8. This appliance shall not be used by children. Keep the appliance and its cord out of reach of
children.
9. Misuse of this appliance may lead to potential injury
10. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similar qualified person to avoid a hazard.
11. Care shall be taken when handling the sharp cutting blades, emptying the bowl and cleaning the
appliance.
12. Be careful if hot liquid is poured into the appliance, as it can be ejected out of the appliance due
to sudden steaming.

3
1) power cord
2) power plug
3) ON/OFF switch button
4) Main body
5) ice press plate
6) spike
7) ice box
8) inner ring
(The ice amount can not exceed the height of
the inner ring)
9) ice position
10) outlet
11) base
(1)
(2)
(4)
(3)
(5)
(6)
(7)
(8)
(9)
(10)
(11)

4
Correct Usage
⚫Do not use it on the dining table or similar
places.
⚫Prevent the child from using this appliance,
and keep it away from the children’s reach.
⚫Do not connect the plug before inserting the
main body into the ice box.
1. Take the main body out from the ice box.
◆Please put the product on flat surface
hold the ice box firmly with one hand, and rotate the
main body clockwise with another hand, to coincide with mark and ▲.
2. Put the ice cubes into the ice box.
◆Put the ice cubes from the ice making device on the market
into the ice box, and make sure the ice cubes are under the maximum
line of ice box.
⚫Make sure the top surface of ice cubes are
flat, then connect ice box with main body. If
the amount of ice cubes is over the maximum
line or the top surface of the ice cube is not
flat, it can’t be closed.
⚫Do not use the rock ice sold in the
supermarkets or convenience stores.
3. Connect the ice box with the main body.
◆First of all, make sure that the ice box is assembled on the base
completely.
◆As shown in the right picture: hold the ice box tightly by one hand,
then press the main body hardly with another hand and make sure the
mark ▲fit with coincidentally, rotate the main body
counterclockwise to the position of mark , until hearing the
sound of “click”, and it means it is installed in place.
ice box
ice position

5
※If the amount of ice cubes is over the maximum position or the top surface of
ice cubes is not flat, it can’t be closed.
※Do not be blocked by the inner reinforcing rib when
assembling the main body with ice box.
4. Please insert the plug into the socket.
5. Shave ice
◆Hold the main body and ice box tightly with two hands,
slowly lift it and press the switch button during lifting.
※The base is not needed when lifting the appliance for using.
◆The appliance will not work without pressing the switch button.
※Even if there is no ice cube in the ice box, the appliance will not
stop working when you press the switch button, so do not forget
to release the switch button when there is no ice cube in ice box.
Possible phenomena during shaving
◆When the ice is stuck, you will hear a locking sound.
Please stop working. This is a normal phenomenon,
which is not fault.
◆With the reduction of ice cubes, the side of ice cubes touching
the blade will become smooth, and the shaving amount will decrease.
Solutions:
No matter what has happened, please turn off the switch and
start it again. If the problem still can’t be solved,
please take the ice box away from the main body, shake the
ice box, reduce the amount of ice cubes, and then
switch on after re-assembly.
⚫It is dangerous to touch plug with wet hand,
and make sure that your hands are dry before
touching the plug.
inner
reinforcingrib
ON/OFFswitch

6
6. Remove the main body, throw the ice cube way.
※Because of the structure, it is a normal phenomenon that there might be residual ice cubes in
the box, which is not fault.
Make sure to throw the residual ice cubes away for the next application.
If there are residual ice cubes in the ice box, and you continue adding ice cubes, it will cause idling.
⚫Please pull out the plug after using.
⚫Sometimes, the water attaching to the main body will fall,
please put the main body on the cloth to absorb the moisture.
⚫Do not reverse the main body.
⚫During continuous shaving of ice, please make sure a minimum
interval of 30 seconds.
Cleaning and storage
1. Make sure to pull out the plug.
2. Put the appliance on the bottom base.
3. Remove the main body from the ice box.
◆Put the appliance on a flat surface, hold the ice box tightly with one hand, and rotate the main
body clockwise with another hand.

7
◆Wipe the main body, ice press plate and spikes with dry cloth. Pour the neutral lotion onto the
cloth, dry it gently, and wipe the hard dirt.
◆Please store the appliance in dry condition.
4. Invert the ice box after cleaning, until moisture is dry. Make sure to keep the blade dry.
5. Don’t touch the spikes and blades with hands during cleaning.
6. Don’t soak the appliance into the water or pour water on it, it may cause electric shock.
7. It may rust or mildew if the appliance is not used for a long time, and you could smear edible oil
on the blade and store it after complete drying.
Environment
Meaning of crossed –out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater and get into the
food chain, damaging your health and well-being. When replacing old appliances
with new ones, the retailer is legally obligated to take back your old appliance for
disposals at least free of charge.
