HOTO QWKPQ001 User manual

Manual of
HOTO Electric Wine Opener

Warning
1
Do not put this product into water or other liquids as this may cause damage
to the user and the product.
To avoid injuroes, do not touch the spiral hook with hands or other body
parts.
Children are not allowed to use this product.
Users are not allowed to disassemble the product as it can affect the
warranty.
Do not press the product against the bottle using brute force or try to speed
up the opening process. This product works best at its set speed.
Please do not use this product for any other purposes.
Do not use this product in the presence of flammable or explosive gases.
Misuse may cause hazard. Always disconnect the appliance from the supply if
it is left unattended and before assembling, disassembling or cleaning.
This appliance can be used by children aged from 8 years and above if they
have been given supervision or instruction concerning use of the appliance in
a safe way and if they understand the hazards involved. Cleaning and user
maintenance shall not be made by children unless they are aged from 8 years
and above and supervised. Keep the appliance and its cord out of reach of
children aged less than 8 years.

2
Appliances can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and if
they understand the hazards involved.
Children shall not play with the appliance.
Switch off the appliance and disconnect from supply before changing
accessories or approaching parts that move in use.
This appliance is intended to be used in household and similar applications
such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.

3
All products bearing this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be mixed
with unsorted household waste. Instead, you should protect human
health and the environment by handing over your waste equipment to a
designated collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities. Correct disposal
and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities
for more information about the location as well as terms and conditions of such
collection points.
Battery-operated appliances
- Four No. 5 batteries
- Press and hold the button on the back of the opener to open the battery
cover, and the battery cover will be cocked. Remove the battery cover, insert
four No. 5 dry cells (alkaline) according to the direction of the positive and
negative poles indicated in the battery compartment, and then close the
battery cover.
- non-rechargeable betteries are not to be recharged;
- different types of betteries or new and used batteries rae not to be mixed;
- betteries are to be inserted with the correct polarity;
- exhausted batteries are to be removed from the appliance and safely
disposed of;
- if the appliance is to be stored unused for a long period, the betteries should
be removed;
- the supply terminals are not to be short-circuited.

4
We Shanghai HOTO Technology Co., Ltd., hereby, declares that this
equipment is in compliance with the applicable Directives and
European Norms, and amendments.
We declare that the above mentioned device has been tested and found in
compliance with CFR 47 Part 15 Regulation.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Product: HOTO Electric Wine Opener
Model Number(s): QWKPQ001
Brand/Trade: HOTO
Federal Communications Commission Supplier’s
Declaration of Conformity

5
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Representative of Responsible Party for SDoC
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Company: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No.50 Moganshan Road, Shanghai, China
Country: China
Telephone No.: 400-021-8696

6
Cork release button
Uncork button
Battery cover button
Foil cutter
1
2
Battery cover
3
4
Viewing window
5
6
Product Overview
Read this manual carefully before use, and retain it for future reference.
Thanks for using HOTO Electric Wine Opener.
1
5
2
6
4
3

7
How to Use
Pinch the foil cutter and pull it out. Take
the cutter and place it around the mouth
of the bottle and turn your fingers slightly
from left to right to cut off the foil cap.
Bottle Opening
Press and hold the button on the back of the opener to
unlock the battery cover. Remove the battery cover and
insert four No.5 dry cells (alkaline) according to the direction
of the positive and negative poles indicated in the battery
compartment. Close the battery cover when finished.
Battery Installation
Hold the bottle firmly in one hand and the
opener in the other. Place the lower end
of the opener over the mouth of the wine
bottle, and try to keep the opener in
vertical position aligned with the bottle.
Press and hold the uncork button while
pressing down on the opener for about 8 to
10 seconds. The opener will automatically
remove the cork from the bottle. Once the
cork is completely removed, the opener will
automatically stop spinning, and the opener
may be released from the bottle.

8
This product is only suitable for corks with a diameter of 20 to 24mm and a
height of 38mm.
Tips:
This product is only suitable for mouth bottles with an outside diameter of up
to 35mm and an inside diameter of 17.5 to 23mm.
For a fast high-quality opening experience, it is recommended to use batteries
with guaranteed quality with a manufacturing day within the month.
Battery Replacement
Replace the battery if it is hard to uncork or the rotative speed is slow.
Press and hold the cork release button for about 5-8 seconds, and the cork
will gradually unscrew from the opener. Release the button after the cork
completely releases from the opener.

9
Avoid damages from accidental shocks.
Please wipe it up after use.
Remove the battery when it is not in use for a long time.
Maintenance

10
Troubleshooting
In the event that the opener breaks down during use, please follow the
following handling methods:
Possible Causes SolutionsIssues
The opener does not
respond or ceases to
work when
uncorking
Batteries are misplaced Please install the batteries
correctly
Please contact Custormer
Service
While pressing the uncork
button, slightly press down on
the opener
When cutting the foil, hold the
foil cutter firmly to ensure that
the blade is tightly clamped to
the bottle mouth
Hold the foil cutter firmly and
make several parallel turns
from left to right
Please replace the four No. 5
dry cells (alkaline)
Press the cork release button
until the opener fully detaches.
Reopen the bottle after
ensuring that the opener is
correctly aligned with the bottle
Low battery level
Opener faults
The tip of the spiral hook of
the opener does not drill
into the wine cork in time
The blade of the foil cutter
does not clamp tightly to
the mouth of the bottle
Parallel rotation from left
to right does not allow
more than half a circle
The opener was not
properly aligned with the
bottle during opening.
Tilted opening.
Takes too long to
uncork
The foil covering the
mouth of the bottle is
not completely
removed

Specifications
Model: QWKPQ001
Item Dimensions: 59.9×44.7×185.4mm (excluding the foil cutter)
Net Weight: About 250g
Rated Voltage: 6.0V
Rated Power: 15W
Working Temperature: 10℃~40℃
Storage Temperature: -10℃~50℃
Storage Humidity: ≤90%RH
Battery Type: AA Battery×4
Opener Material: Stainless steel, ABS
Foil Cutter Material: Stainless iron, ABS
11
Manufacturer: Shanghai HOTO Technology Co., Ltd.
Address: Building 45, No. 50 Moganshan Rd, Putuo District, Shanghai, PRC,
200060.

12
DECLARATION OF CONFORMITY
EU Declaration of Conformity
We
Shanghai HOTO Technology Co., Ltd.
Declare that the product:
HOTO Electric Wine Opener / QWKPQ001
References to the following harmonized standard were made:
EN 60335-1:2012 + A11:2014 + A13:2017 + A1:2019 + A14:2019 + A2:2019 + A15:2021
EN 60335-2-14:2006 + A1:2008 + A11:2012 + A12:2016 EN 62233:2008
EN 55014-1:2021
EN 55014-2:2021
2014/30/EU Electromagnetic Compatibility directive References to the following
harmonized standard were made:
2011/65/EU+ (EU) 2015/863 Restrictions of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Authorised signatory and technical file holder:
Shanghai HOTO Technology Co., Ltd.
Building 45, No.50 Moganshan Road, Shanghai, China
