Cooper & Hunter Himalaya Series User manual
Instruction manual
Модел/Model:
Electric
air purifier
CH-P25B3i
Outlook of devices, aslo colour scores can be revised without any special advance
notices.
Виробник ма
.
www.cooperandhunter.com
2
Dear customer!
Thank you for your good choice and purchase of
a Cooper&Hunter purifier. It will serve you for a long time!
The manufacturer reserves the right, without prior notification the buyer
to make changes in design, equipment or technology to manufacture
products with the aim of improving its properties.
The text and figures are given instruction may be a misprint.
If after reading the instructions you still have questions regarding the
operation of the unit and contact your dealer or authorized service facility
for clarification.
The product label is present, which are all necessary technical data and
other useful information about the instrument.
Use only for intended use as described in this manual. Air is designed to
clean air in residential areas.
Before the commissioning of the air purifier carefully read these instructions
for its use, and store it for later use.
When using the device, you must follow some precautions. Misuse of
power of ignoring safety precautions could cause harm the user and
others, as well as damage to their property.
The device is designed to work in a residential area in compliance with
these conditions. Use an air cleaner for other purposes may create a
situation dangerous to life and health.
1. IMPORTANT INFORMATION
2. SAFETY MEASURES
1. Important information
2. Safeguards
3. Specification
4. Product description
5. Complete set
6. Operation of the instrument
7. Device cleaning and maintenance
8. Troubleshooting
9. Utilization
10. Transportation and storage
CONTENTS
2
2
3
4
4
5
6
6
6
7
www.cooperandhunter.com
3
3. TECHNICAL CHARACTERISTICS
The appliance should be monitored during its operation, especially when
close to him are the children. The device is not intended for use by persons
(Including children) with reduced physical, sensory or mental capabilities,
having insufficient experience and knowledge, unless they are supervised
and do not receive instructions on how to use the device from the person
responsible for their safety. Make sure that the children do not play with
the device.
Do not use the device in order not provided for this manual.
Not allowed to operate the appliance if the power cord or plug are
damaged, and if air cleaner is defective, damaged in the fall or in other
circumstances.
The device should be used only in fully assembled form.
To avoid electrical hazards, damaged power cord must be changed only at
authorized service centers by qualified personnel.
To avoid electric shock, do not place the power cord near a heat source
and flammable or combustible substances.
To avoid personal injury and property damage, not try to repair the air
cleaner.
For repair of the air purifier, please contact the authorized service center of
the manufacturer. Its address can be obtained at
www.cooperandhunter.com.
Remove the plug from the outlet device in the following cases: before
cleaning and maintenance, before moving to another place.
Install the air cleaner on a flat dry surface.
For damages received due to improper location of the humidifier, a
manufacturer and seller are not liable.
When not in use, unplug the power supply.
Do not route power cord under a carpet or other items.
Avoid contact with air filter foreign objects.
Do not block air intake with foreign objects and the air outlet.
The minimum distance from any of the instrument to objects and surfaces,
30 cm.
Do not sit, or stand or place heavy objects on the air purifier.
For damage to the instrument, derived from the non-fulfillment of this
requirement, a manufacturer and seller are not liable.
When you disconnect the unit from the mains, do not pull the power cable
and do not touch it with wet hands.
5. Water tank 10. Power cord
11. Air outlet
Table 1
Specifications Unit of
measurement
-253i
Air flow m3/h 250
Power supply V/Hz 220~/50
Power consumption W 30
24.4-53.8
Water protection - IPX0
Electrical protection class - Сlass ll
Net weight kg 4,71
Device dimension mm 370x213x394
Noice level dB
The manufacturer reserves the right to change the
set-list of the device (including liquid and powder
components) for different supplies without prior
notice. The changes either in no way influence the
basic technical parameters of the device or may
improve them, and also not violate the legislation or
quality standards of the countries of manufacture,
transit and selling.
The changes in the set-list may result in changing
of the weight and dimensions of the device, but not
more than by ± 20% (depending on the product
category)
IMPORTANT!
Negative ions million / cm³3.0
www.cooperandhunter.com
4
4. DESCRIPTION OF THE UNIT FRONT PANEL
www.cooperandhunter.com
4
1. Front panel
2. Air filters (PP+CARBON+HEPA)
3. Base with back cover
4. Control panel
5. SCOPE OF DELIVERY
1. Air Purifier - 1 pc.
2. Filter – 1pc
3. Manual and warranty Card - 1 pc
4. Packing - 1 pc.
1. Power button
2. Fan Speed Button
3. Timmer button
4. CH-Ion filter button
5. Power indicator
6. Filter change indicator
7. Night /silent mode indicator
8. Low speed indicator
9. Average speed indicator
10. High speed indicator.
11. Timer indicator for 2hours
12. Timer indicator for 4hours
13. Timer indicator for 8hours
14. CH-Ion filter indicator
POWER: When the plug is connected, the buzzer will sound, and all
the indicators will be on, after one second, only the power indicator
will be on, and the machine will enter the standby mode.
Press the Power button to turn the machine on and working at speed
2, press this button again to turn off purifier.
SPEED: The machine is working in 2speed after start working, Press
the speed button and the machine will work at speed 3, Press again
and the machine switches to sleep mode. Touch again, machine will
be work in speed 1.
TIMER:Stops the device after the adjusted hours:
www.cooperandhunter.com 5
6. OPERATION OF THE UNIT
1. Open the front cover by
pulling the upper part of it.
2. Remove the plastic
packing of the filter.
3. Set the filter back.
Control of device
The product is for 220 V~, 50 Hz only.
Make sure to connect the power plug to a grounded
electric outlet (220 V~, 50 Hz) dedicated to the
product.
IMPORTANT!
MULTIPLE AIR PURIFICATION: 3stages filter system: Nano-silver PP filter to
kill bacteria, collect big dust particles and to prolong the lifetime of HEPA;
True 99.97% HEPA to filter the floating particles and pollen with little wind
resistance; Efficiency to filter dust is more than 99% within 1hour; Efficient
activated carbon filter to eliminate the strange odor, to filter the methanal and
TVOC.
1
3
2
4H 6H Timer o
2H
Disconnection at 2H: press the “off timer” button once. The LED 2H
lights up.
Disconnection at 4H: press the “off timer” button twice. The LED
4H lights up.
Disconnection at 6H: press the “off timer” button 3 times. The LED
2H +4H light up.
Disconnection at 8H: press the “off timer” button 4 times. The LED
8H lights up.
Disconnection at 10H: press the “off timer” button 5 times. The LED
2H +8H light up.
Disconnection at 10H: press the “off timer” button 5 times. The LED
2H +8H light up.
Disconnection at 14H: press the “off timer” button 6 times. The LED
2H +4H +8H light up.
Cancel the “off timer”:
Press the “off timer” button 7 times or then press the “off timer”
button for 2 seconds.
8H 10H 14H
www.cooperandhunter.com
6
7. CLEANING AND MAINTENANCE OF THE UNIT
IMPORTANT!
Make sure to start cleaning and filter
management after turning off power,
unplugging from power outlet and making
sure that the fan has stopped. There is
danger for electric shock or other accidents
if filter is changed during operation.
NOTE:
Negative Ions abound in our natural environments
such as forests, waterfalls, mountains and seaside.
Negative ions are useful for enhancing the
metabolism and homeostasis of the human body.
This air purifier is equipped with a negative ion
generator that can produce abundant negative ions
by means of electric simulation.
Before cleaning the device, make sure that it is unplugged. Otherwise, it may
lead to electrical shock.
Use damp and soft cloth to wipe the external surface of the device.
To avoid electrical shock, be careful not to scratch and damage the elements
during cleaning.
It is prohibited to use solvents, petroleum, xylene, hard brush, talcum powder
and other substances; only water is allowed.
The device shall be cleaned once or twice in a week.
Remove dust at the top of the e2f filter using a vacuum cleaner.
Store the device in premises with low humidity.
8. TROUBLESHOOTING
Table 2
Breakdown Reason Solution
Can Not Run
1. No power
2. Did not press the On/Off bottom on
control panel
3. Parts of the electricity broken
1. Plug the power and connect well
2. Press On/Off bottom on control
panel
3. Send to repair
Gentle air stream Cannot be off 1. Did not press the off bottom
2. Parts of the electricity broken
1.Press On/Off bottom on control panel
2. Send to repair
Abnormal Sound
1. Something inside
2. Wind wheel loose
3. Electrical machine damage
1. Remove the filter, and try again. If
cannot settle, send to repair.
2. Send to repair
3. Send to repair
Purify function not obvious 1.Need to change filter 1. Change filter
Term reliability is 5 years.
At the end of the life of the puripier should be subjected to disposal in
accordance the rules, regulations and methods, at the place of disposal.
9. UTILIZATION
In case of emergency contact information listed in the table 2 below. If you
can not solve problems independently, to a service center.
Change of Filter
Suggest you to change the filter once per 6 months.
Remove the cover of filter, take out the filter, then change new ones.
ANION: Touch the ANION, the Anion symbol light will be on, the
Anion start working. Re-touch ANION, the function stop working.
FILTER CHANGE
If the filter is very dirty or need to be changed, all the indicators
will be turned off, except the filter change indicator flashing ,to
remind the user need to be replaced the filter .
After replacing the filter, in standby mode, press the speed button
for 3times continuously, and press this button for 2seconds .
The indicator light for replacing the filter flashes quickly and the
power indicator light is on, indicating that the machine has been
replaced
www.cooperandhunter.com 7
10. TRANSPORTATION AND STORAGE
1. When transporting, any possible impacts and movements of the
package inside a vehicle must be avoided.
2. Handling symbols on the unit’s package must be strictly observed when
transporting and storing it.
3. Temperature
requirements*
Humidity
requirements*
Transportation and
storage
-30°C to +50°C
15% to 85%
(no condensate)
We are researching new technologies and constantly improving the quality
of our products. Specifications, design and scope of delivery may be
changed without any prior notice.
* Products must be stored in dry, ventilated storages at the temperature
not lower than -30°C.
!
Cooper & Hunter ,
,
. Cooper & Hunter
,
.
,
.
, . !
1. ВАЖЛИВА
www.cooperandhunter.com
8
1.
2.
3.
4.
5.
6.
7.
8.
9.
ЗМ
8
9
9
10
10
11
12
12
13
,
.
.
,
’.
,
.
,
.
10. 13
11. ’ 13
2. ЗАПОБ
www.cooperandhunter.com 9
.
,
.
’
, .
.
,
’ .
, , .
(
) ,
, ,
, .
, .
, , .
,
, ,
, .
.
,
.
,
.
.
, www.
cooperandhunter.com.
:
;
.
.
,
, .
,
.
.
.
.
-
30 .
,
.
, ,
.
.
3. ТЕХН
Таблиця1
. . -253i
м3/год 250
В/Гц 220~/50
Вт 30
Дб 24.4-53.8
-IPX0
-Сlass ll
кг 4,71
мм 370x213x394
/³3.0
4. ОПИС ПРИЛАДУ
www.cooperandhunter.com
10
ПРИМ
Виробник залиша за собою право для рзних
партй поставок без попереднього пов
мыняти комплектуючы частини виробу
(включаючи сипуч \т складов), не
впрливаючи при цьому на основтехн
параметривиробу або покращувати , а також
не порушуючи зам прийнятна территор
\транзиту\реалзац
стандарт норм законодавства.
Це може вплинути на зм
,но не б на +\- 5-20% (в
).
1.
2. (PP + CARBON + HEPA)
3.
4.
1.
2.
3.
4. CH-Ion
5.
6.
7. ()
8.
9.
10.
11. 2
12. 4
13. 8
14. CH-Ion
5. КОМПЛЕКТАЦ
1. - 1 .
2. – 1 .
3. - 1 .
4. - 1 .
5. - 3 .
www.cooperandhunter.com 11
6. ЕКСПЛУАТАЦ
1.
,
.
2.
3.
.
(3
:)
-Nano-silver PP ,
,
;
-True 99,97% HEPA
.
- ,
(TVOC).
220 , 50 .
,
(220 ~, 50 ),
.
УВАГА!
: , ,
,
,
.
,
2, ,
.
: 2
, ,
3, ,
“” ( ).
, 1.
:
14 ,
.
1
3
2
2 :
, “2”.
4 :
, “4”.
6 :
, “2” “4”.
8 :
, “8”.
10 :
, “2” “8”.
14 :
, “2” , “8” 4”.
www.cooperandhunter.com
12
: , Nano-
silver PP , HEPA .
(-on filter) ()
.
,
( ).
.
Nano-silver PP ,
,
.
HEPA (True 99,97% HEPA filter)
, 0,3 .
,
(, ,
).
7. СИСТЕМА ОЧИСТКИ ПОВ
Ф 4-6
(
).
:
, ,
, .
,
. ,
.
’ .
.
, , , ,
, .
.
.
8. ОЧИ
УВАГА!
УВАГА!
Перед очищенням завжди в
.
: ,
, CH-ION . CH-Ion
.
,
,
,
.
3 2 .
,
, , .
,
.
4H 6H
2H 8H 10H 14H
www.cooperandhunter.com 13
11. ГАРАНТ ’
,
’,
.
,
,
.
’
/ .
, /
.
’
, () .
- ,
- .
,
’
.
’
.
.
.
24 ( )
.
.
,
,
.
9. УСУНЕННЯ НЕСПРАВНОСТЕЙ
,
2.
, .
Таблиця2
1.
2. On/Off
1.
2. On/Off
1. Ненатиснута кнопка off
2.Несправноств прилад
1. n/Off
2.
1.
2.
3.
1.
2.
3.
1. 1.
П
, .
10. УТИЛ
:::
Cooper & Hunter International Corporation, Oregon, USA
www.cooperandhunter.com
E-mail: [email protected]
.
:
“-”
, 03127, . , , . 132
. +380 (44) 461-79-82, +380 (44) 461-78-93
This manual suits for next models
1
Table of contents
Languages:
Other Cooper & Hunter Air Cleaner manuals
