Coopers of Stortford G228 User manual

Rotary Wet Dry Shaver G228 Instructions for Use
Please read and retain these instructions for future reference v002: 29/07/20
INSTRUCTIONS FOR USE:
Notes
Before using the product, please carefully read the operating instructions and keep them for future
reference.
1. Only use the charger provided.
2. The charger can transform 240V-230V ac to a safe low voltage of 5Vdc.
3. The charger includes a transformer which should not be removed and replaced with another
plug.
4. If the charger is damaged, it should be replaced with an identical one.
5. The temperature charging and storing the product should not be below 5 °C or exceed 35 °C.
6. Keep the charger in a cool dry environment and away from moisture.
7. Unplug the charger before cleaning the shaver with running water. When using hot water check
the water is not too hot.
8. The shaver head is waterproof grade IPX4 and can be washed. The body should not be soaked in
water.
9. Always dry thoroughly if washed in water before use.
10. Switch off the shaver before charging. When charging the charge indicator light will be on.
11. Always ensure to put the protective cover on the shaver head to protect the shaver head.
Power Details:
Shaver: 2.4VDC; 3Watts, IPX7
Power Supply:
Input: 220-240VAC; 50/60Hz; IP20
Output: 3VDC; 150mA
Battery:
2x1.2VDC AA Ni.MH rechargeable
batteries
Accessories:
Charger, brush.

Rotary Wet Dry Shaver G228 Instructions for Use
Please read and retain these instructions for future reference v002: 29/07/20
Charge:
Make sure the product is switched off before charging.
The charge lasts about 5 hours.
Do not leave the product connected to the power supply
for more than 24 hours.
1. Insert the product charger into the shaver (Fig 1).
2. Plug in the charger.
3. The charge indicator lights up (Fig. 2).
4. After the shaver is fully charged, unplug the charger
and also pull out the plug.
Attaching shaver head/nose trimmer/hair clipper/face cleansing brush
There are 2 grooves on the shaver itself.
All the attachments have 2 outer grooves. Line up grooves on the shaver and the outer grooves and push
together. To take the attachments off, pull apart. (Note: it is a tight fit)
Hair Clipper
Clip attachments for 7, 5 or 3mm in place as shown.
Then line up grooves on hair clipper and main unit and push into place.

Rotary Wet Dry Shaver G228 Instructions for Use
Please read and retain these instructions for future reference v002: 29/07/20
How to use the product
Shaving:
1. Press the ON/OFF button to start the shaver.
2. Move the shaver head quickly on the skin in straight
lines and circles (Fig 3).
3. Cover the shaver’s head with the protective cover
after each use to avoid damage (Fig 4).
4. The shaver can run for ten days after a full charge.
Trimming:
Used for trimming temple and moustache.
1. Push the side face upwards to open the hair trimmer. Press the ON/OFF
button to start the hair trimmer (Fig 5).
Cleaning & Maintenance:
To ensure best performance, the shaver must be
cleaned regularly.
It is recommended to replace the blades once a year.
The easiest and most hygienic way to clean the
product is to wash the shaver head part and the hair
chamber with water each time after using it.
When using remember to check the water is not too
hot to avoid scalding your hands.
1. Turn off the shaver.
2. Pull away the four shaver heads to the side one by one and then rotate
and pull out the middle head in the direction of the arrow indicated on it
(Fig 6).
3. Hold the five shaver head part and the hair chamber under hot running
water for cleaning (Fig 7).
Make sure the inside of the shaver head parts and the hair chamber have
been cleaned thoroughly.
4. Wash the product’s surface (Fig 8).
5. Close the shaver head part and shake off excess water.
Do not wipe the shaver head part with a towel or paper tissues, which may cause damages to the
shaver head.

Rotary Wet Dry Shaver G228 Instructions for Use
Please read and retain these instructions for future reference v002: 29/07/20
6. Open the shaver head part again and leave it open to let the product dry
completely (Fig 9).
You can also use the brush included to clean the hair chamber.
Do not wet the brush.
Trimmer:
Clean the trimmer each time after use.
1. Switch off the shaver, then unplug the charger and
also unplug the product’s plug from the shaver.
2. Clean the trimmer with the brush included (Fig 11).
3. Lubricate the trimmer teeth with a drop of sewing
machine oil once every six months (Fig 10).
Cleaning the nose trimmer and face cleansing brush
Nose trimmer
Pull apart the 2 sections and the nose trimmer comes apart
for cleaning.
Face cleansing brush
The 2 sections can be pulled apart.
PLUG WIRING (UK & IRELAND)
This appliance is supplied with a mains adaptor/charger with BS1363 plug pins.
DO NOT use If the socket outlets in your home or office are not suitable for this product’s mains
adaptor/ charger plug pins. Attempts to insert the mains adaptor/charger into the wrong socket is
likely to cause electric hazard or damage.
DO NOT use with any other mains transformer/charger than the one that is supplied with this
product.
BATTERIES
•Keep batteries away from children and pets.
•Do not mix used and new batteries.
•Install batteries in accordance with its polarity symbols.
•Remove the batteries if left for long periods.
•Never dispose of batteries in a fire.
•Battery disposal, spent or expired batteries must be properly disposed of and recycled in
compliance with local regulations. For detailed information, contact your local authority.
•Follow the battery manufacturer’s safety, usage, and disposal instructions.

Rotary Wet Dry Shaver G228 Instructions for Use
Please read and retain these instructions for future reference v002: 29/07/20
DISPOSAL
•Dispose of all packaging, paper, cartons, plastic and plastic bags in
accordance with your local recycling regulations.
•At the end of the product’s lifespan please dispose of it at an
authorised household WEEE waste recycling centre.
