COP Security 15-VP04-HDD2 User manual

15-VP04-HDD2
&
15-VP04-CDRW
VER 5.53
04 Channel Video Processor
Safety & Security

1
Table of Contents
Chapter 1 . Product package
Chapter 2. Installation procedure
1-1. The contents of package 3
1-2. Name and function of each button (front panel) 4
1-3. Name and function of each button (Rear panel) 5
2-1. Camera connection 6
2-2. Monitor connection (Composite monitor) 6
2-3. Monitor connection (S-VHS) 6
2-4. Sensor connection 7
2-5. Network connection 7
2-6. HDD connection 8
2-7. Power connection 8
Chapter 3. Operation
3-1. Basic Display 9
3-2. Playback 12
14
3-3. SYSTEM Log-in
15
3-4. System Set-up
15
16
17
18
19
22
22
23
Chap 4. Specification and Configuration
4-1. Specifications 25
4-2. Configuration 26
3-1-1. MODE
3-1-2. FRZ
3-1-3. SEQ
3-1-4. ZOOM
3-1-5. PIP
3-1-6. P/T
9
9
10
10
11
11
3-4-1. BASIC OPERATION
3-4-3. CAMERA SETUP
3-4-5. ALARM / MOTION SETUP
3-4-4. TIME/DATE Setup
3-4-6. RECORD SETUP
3-4-8. MISCELLANEOUS SETUP
3-4-7. TCP/IP SETUP
3-4-2. DISPLAY SETUP

2
1. This document is intended for both the administrator and users of Video Processor model.
2. This manual contains information for configuring, managing and using Video Processor model.
4. To prevent fire or electrical shock, do not expose the product to heat or moisture.
3. Be sure to read through this manual before using this Video Processor model.
5. Check electricity at the place you want to install the unit if it is stable and meets our electricity requirements. Unstable
electricity will cause malfunction of the unit or give critical damage to the unit.
6. Several chips on the main board of the unit and hard disk drive inside the unit generate heat, and it must be
properly discharged.
Do not put any objects just beside exhaust port(fan) on the left side of the unit and do not close up an opening
(fresh air in-take) on the right side of the unit.
7. Put the unit at well-ventilated place and do not put heat-generating objects on the unit.
When it is installed inside 19 inch mounting rack together with other devices, please check built- in ventilation fan of
the rack is properly running.
Before installing Video Processor, be sure to thoroughly review and follow the instructions in this User’s Manual.
Pay particular attention to the parts those are marked NOTICE.
Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.
8. For questions and technical assistance of this product, contact your local dealer.
About this manual
Before reading this manual
Install hard disk drive
1) HDD should be up to 7200rpm. Capacity of HDD is Max. 300GB. (Tested with maxtor HDD)
We recommend Maxtor HDD.
2) Please make sure that jumper setting of HDD must be MASTER.
3) After install HDD, start . First, set the date and time.
Set at Factory Default in SETUP Menu and please clear HDD.
4) Go into Menu HDD Management HDD information and Verify that the second drive detected CD-Recorder.
15-VP04-HDD2 & 15-VP04-CDRW

3
Chapter 1 . Product Package
1. Product package 15-VP04-HDD2 & 15-VP04-CDRW
1-1. The contents of package
1. 4 ch stand-alone unit
5. Accessories (Rack mount brackets, tapes and bolts )
Mounting bracket and bolts necessary for fixing unit into 19 inch rack, and batteries for remote controller.
4. DC power adapter and power cable
Converts AC 110V or AC 220V into DC 12V to supply unit.
3. Remote controller
IR remote controller enables full operation unit.
2. User manual
15-VP04-HDD2
&
15-VP04-CDRW
The most stable and reliable real stand-alone Digital Video Recorder
User Manual
VER 2.0
Safety & Security
04 Channel Dig ital Video Recorder

ALL ABOUT IMAGE RECOGNITION & PROCESSING
4
1. Product package 15-VP04-HDD2 & 15-VP04-CDRW
8. MODE : Changes to quarterly split screen or Full display screen.
4. MENU : Used to change menu in SYSTEM SETUP
2. ENTER : Used as selection key in SYSTEM SETUP mode or changes contents displayed in live display mode.
9. P/T : Enter into or exit from PAN/TILT CONTROL mode
5. Camera No : Represents camera numbers. Used with MODE button or to enter numbers.
10. PIP (MARK) : In full screen, this button assigns PIP( Picture In Picture ) .
7. FRZ : On-off switch to freeze pictures in live mode
6. SEQ : In full screen, this button shows pictures in rotation.
11. ZOOM : In full screen, this button enlarges pictures two times ( Possible to fix area to be enlarged using direction buttons.)
18. IR receiver : If blocked up by any object, remote controller does not work.
3. Direction key : Used to move in SETUP menu(Up/Down/Right/Left), or to change values
Notice : If several keys are pressed at the same time, or improper sequence in pressing buttons may cause
malfunction of unit.
1. LED : Indicates the status of system (OVERWRITE / RECORD / PLAY / SETUP)
19. CD-RW or Mobile Rack : Back-up / Recording device
1-2. Name and function of buttons
[ Front Panel ]
13. Record ( ): Records picture data on hard disk drive
14. Stop ( ): Stops recording or playback
17. Fast backward ( ) : High speed playback in reverse direction in playback mode, or moving to the start of recorded data
when it is in stop mode
16. Playback ( ) : Start or exit playback.
15. Fast Forward ( ): High speed playback in forward direction in playback mode, or moving to the last of recorded
data when it is in stop mode.
12. Pause ( ): Pauses when it is in palyback mode
21 34
Enter
Menu
MODE
ZOOM
SEQ
P/T
FRZ
PIP
Se tup
Play
Record
Overwrite

5
15-VP04-HDD2 & 15-VP04-CDRW
1. VIDEO INPUT : Connect cameras up to 4
2. VIDEO LOOP : Loop out from each camera from 1 to 4
NOTICE : When connecting with other applications, be sure to turn off the system.
3. MONITOR 1 : First Connect to composite monitor
4. MONITOR 2 : Additional Monitor output
8. S-VHS : Connect to S-VHS monitor for better quality of display
6. ALARM / RELAY : Connect to alarm input and relay output
7. RS-485 : Connect to external device of RS-485 protocol (PTZ camera control)
5. ETHERNET : Connect to Ethernet port for TCP/IP
9. D/C 12V : Port for DC 12V, 5A.
10. POWER SWITCH WITH LED : DC Power Switch With LED
Generally speaking, cutting power to system may cause trouble in system or damage to HDD when
HDD is in writing process, and we ask you to press [MENU] button first to protect HDD from being
damaged or system failure before you press DC power switch off in practical operation.
[ Rear Panel ]
1-2. Name and function of each button
D
1
C
O
M
D
+
D
-
N
CD 2
D
4D 3
N
O
G
N
D
RELAYRS-485 ALARM
ETHERNET
LOOP
CH1 CH2 CH3 CH4
VIDEO INPUT
MONITOR1
MONITOR2 DC 12V
S-VHS
POWER
1. Product package

6
2. Installation 15-VP04-HDD2 & 15-VP04-CDRW
1) Camera Connection
Connect the camera to the CAMERA INPUT on the Rear Panel of the system.
2) Monitor Connection (Composite Connection Method)
Connect the monitor to the MONITOR OUT on the Rear Panel of the system
VIDEO
LENS VIDEO
DC
AC24V/DC12
V.P
DC
LEVEL
Rear part of CAMERA
VIDEO A
IN OUT
VIDEO C
IN OUT
VIDEO B
IN OUT
CH1 CH2 CH3 CH4
LOOP
MONITOR 1
MONITOR 2 S-VHS
Notice : This system accepts camera with both PAL system or NTSC system automatically.
Connect camera and monitor while DC power switch on the front panel is off.
CH1 CH2 CH3 CH4
LOOP
MONITOR 1
MONITOR 2 S-VHS
CH1 CH2 CH3 CH4
LOOP
3) Monitor (S-VHS) Connection
Connect S-VIDEO Monitor to MONITOR OUT(S-VHS) on the Rear Panel of the system.
VIDEO
A
IN OUT
VIDEO
C
IN OUT
VIDEO
B
IN OUT
MONITOR 1
MONITOR 2 S-VHS
Chapter 2 . Installation Procedure

7
2. Installation 15-VP04-HDD2 & 15-VP04-CDRW
ETHERNET
G
N
D
D
4D
3D 2
C
O
M
N
CN
OD
1
ALARM
RELAY
D
-- D
+
RS485
4) Sensor Connection
Connect the Sensor to the SENSOR INPUT/OUTPUT on the Rear Panel of the system
5) Network Connection
NOTICE : Sensor input is RECOGNIZED as LOW when alarm signal is on a level with GND,
and it is recognized as HIGH when alarm signal is FLOATING or 5V. Following is internal circuit.
Internal Circuit D1
5
V
Thus, there is a danger of damage, when the sensor input goes to a Negative level or
voltage higher than 5V.
Terminal block
Pin 1 Alarm1
Pin 2 Alarm2
Pin 3 Alarm3
Pin 4 Alarm4
Pin 5 GND
Pin 6 NO( Normal Open )
Pin 7 NC( Normal Close)
Pin 8 COM
Relay output : COM+NC, COM+NO OR COM+NC+NO
Alarm input : Short-circuit between Alarm1, Alarm2, Alarm3 or Alarm4 and GND is recognized as alarm.
RS 485 : Connect to PTZ camera
RJ-45 (ETHERNET) : Connect to LAN, WAN or Internet
PTZ
CAMERA
G
N
D
D
4D
3D 2
C
O
M
N
CN
OD
1
ALARM
RELAY
D
-- D
+
COM NC NO GND D4 D3 D2 D1
RS-485

8
15-VP04-HDD2 & 15-VP04-CDRW
7) Power Connection
Connect the power to the POWER CONNECTION on the Rear Panel of the system, and turn on the switch.
DC 12V
6) HDD connection
MAIN BOARD
HDD
Mobile
Rack
or
CD-RW
Connect main board and HDD using IDE HDD cable and power cable
included in the package.The jumper setting of HDD must be on Mater,
as specified by HDD manufacturer. The jumper setting must be done
properly as specified by HDD manufacturer. Fix HDD on the bottom of
case using screws included in the package. Screws must be inserted
from outside of the bottom.
And jumper setting of CD-RW DRIVE must be on Slave.
Mobile Rack must be on MASTER, the other HDD on Slave.
Notice : To turn off DC power switch on the Rear panel of case, be sure to press [MENU] button first.
If you press [MENU] button, system stops recording, and you can cut power to unit while HDD head is not in
writing mode. It is necessary to press [MENU] button first and turn DC power switch off to protect HDD head from being
damaged and eliminate possibility of mal-function of unit.
2. Installation

9
15-VP04-HDD2 & 15-VP04-CDRW
3. Operation
1. MODE
When button is pressed, the full screen
of each channel and quarterly split screen is played
MODE
With button, select
full screen of each camera.
1234
2002 / APR / 01 PM 01:00:00
50FPS REC
CAM1 CAM2
CAM3 CAM4
Display of Recording Mode
by turns.
Indicates recording speed
50FPS : 50 Fields/sec
MOTION : records when motion
is detected Indicates recording mode
REC : represents recording in
Field Switch Mode
Nothing displayed in Quad Mode
Indicates recording conditions
ALARM : records when alarm
condition is detected
Indicates
camera channel
1.
2. FRZ
1. Live full screen pauses when button is pressed.
2. To pause quarterly split screen,
FRZ
FRZ 1234
press button, and with button
select channel. On the right of the camera name, “FRZ”
message appears and the LIVE screen of that channel
will pause. When pressed once more, it will come back to
NOTICE : When selected,
button or button do not work.
FRZ
1234MODE
To move to full screen of each camera, press button once more to end Freeze mode.
FRZ
LIVE screen.
CAM1
FRZ CAM2
CAM3 CAM4
2002 / APR / 01 PM 01:00:00
60FPS REC FRZ
Indicates if “FRZ”
button selection.
When #1 camera is
paused in QUAD screen
Pause Screen
Chapter 3 . Operation
Basic Display

10
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
3. SEQ
1.In LIVE full screen, press button to make picture from each channel rotate.
SEQ
CAM1 CAM2
CAM3 CAM4
2002 / APR / 01 PM 01:00:00
60FPS REC
Display of 4-split (Quad) screen
2. It does not operate in quarterly split screen.
3. During automatic rotation, press button to stop automatic rotation.
SEQ
MODE
2002 / APR / 01 PM 01:00:00
60FPS REC SEQ
Automatic rotation of the Full Screen
AB
CD D
C
B
A
Full screen
automatically rotates
by the value of
SEQUENCE
INTERVAL in
A/B/C/D/A/B/C..
4.During automatic rotation, press button to stop automatic rotation and move to quarterly split screen.
PAGE.16. It is possible to select between 1 second to 99 seconds.
To change the time interval of the automatic rotation, change the value of SEQUENCE INTERVAL as per procedure
4. ZOOM
2004/NOV/15
REC
ZOOM in live view
LR
T
B
PM03:36:08
ZOOM
1.In full screen in live mode or in playback mode, press [ZOOM] button to see 2 times enlarged picture.
2. Vertical bar and horizontal bar on the bottom and on the right respectively show which are of picture is enlarged, and you can change
area to be enlarged by pressing [LEFT], [RIGHT], [UP], and [DOWN] button.
3. Because it is enlarged 2 times digitally, picture quality is a little poor than picture you see in normal playback mode.
4. To exit ZOOM mode, just press [ZOOM] button again.

11
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
6. P/T
1. Press button.
P/T
ENTER
P/T
3. Use [LEFT]/[RIGHT] button to select the command
2.Use [UP]/[DOWN] button to choose the ADDRESS
of the P/T camera.
4. With button, select ON/OFF.
5. Press button to come back to recording
for P/T camera you want to transmit.
2002 / APR / 01 PM 01:00:00
60FPS REC
CAM1 CAM2
CAM3 CAM4
P/T CH1 FOCUS FAR
EXIT : PRESS [P/T]
1. Indicates address of camera
0~255 2. Select
Command
FOCUS FAR
FOCUS NEAR
FOCUS AUTO
PAN RIGHT
PAN LEFT
TILT UP
TILT DOWN
ZOOM IN
ZOOM OUT
AUTO PAN
LIGHT CMD
WIPER CMD
PUMP CMD
POWER CMD
FUNTION 1
FUNTION 2
FUNTION3
3. Set ON/OFF
for selected
command
Display of PAN/TILT Control
screen
In most of cases, while you press button, it
is ON, and OFF while not pressed.ENTER
5. PICTURE IN PICTURE (PIP)
1234
PIP
SEQ
1. Use button to select a camera
and set a full screen.
2. Press button.
3. With [UP]/[DOWN] or button, select the
NOTICE : PIP is not available in quarterly split screen.
camera channel in full screen, and with [LEFT]/[RIGHT]
button select the channel of smaller screen.
4. Press button to make the image in smaller
screen rotate.
To change the location of smaller screen, press button and use direction button to move to desired
FRZ
location.
1234
2002/APR/1 PM 09:22:06
60FPS REC PIP FL
PIP WINDOWS MOVE : OFF
MOVE ON/OFF : PRESS PRZ
CAM1
Indicates if “SEQ”button
selection. Indicates “FRZ”
key selection.
Display of PICTURE IN PICTURE
7. NOTICE
1) Recording is stopped during SYSTEM SETUP.
2) Recording is stopped during playback, or search in playback mode.
3) Recording is not possible if no camera is connected.

12
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
2) After pressing , press or and button and use [LEFT]/[RIGHT] button to advance single frame to the right
1. Playback setup
1) Press button to begin playback.
PLAY
2) Display screen as shown on the right will appear
3) Press button again to start playback from
START picture.
ENTER
2. GOTO time setting
1) At , use [LEFT]/[RIGHT] button to choose the date or time of GO TO.
2) Use [UP]/[DOWN] button, set desired time.
(To start from a specific time, first set the
GO TO time before press button.)
3) Press button to replay from the GO TO time.
NOTICE : During playback or setting GO TO time, recording is stopped
3. Pausing and single frame advanced
1) During playback, press button to pause. (Will replay when pressed once more)
SEQ
NOTICE : When value that is out of the range of start and end is entered, it starts from START time
4) To come back to recording mode.
press or button.
NOTICE : When value is in the range of START and END, but there is no recorded pictures at the set time,
it moves to the closest time of the recorded pictures.
START : 2002/APR/12 AM 07:40:38
END : 2002/APR/20 PM 02:11:56
GOTO : 2002/APR/15 AM 00:00:00
Time recording
started.
Time recording
ended.
Indicate time to be
played.
Display of Search(GOTO) mode
2
3
3
1
Playback
2.
or left.
ENTER
ENTER
Playback

13
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
6. MARK IMAGE (Internal backup) SETUP
5. Display Enlargement.
2) Press button, during Playback or PAUSE mode.
ZOOM
3) The display will enlarge by 200%
4) Use direction button to move the area enlarged.
5) Press to go back to Playback or FRZ mode.
ZOOM
1) Choose camera by pressing button.
1234
4. Playback Speed Setup
1) During playback , press or and button.
SEQ
2) Display screen will appear as on the right.
3) On SEQ mode, use [LEFT]/[RIGHT] button to move forward (FF) or
4) Use [UP]/[DOWN] button to select the speed rate.
(High speed up to x60 and slow speed up to 1field/60sec is possible.)
Refer to MISCELLANEOUS SETUP : MARK IMAGE SETUP in PAGE.28 for details.
During Playback, press button and choose pictures using [LEFT]/[RIGHT] button to protect selected
PIP
2002/APR/12 AM 07:40:38
1X PLAY SPEED
CAM1 CAM2
CAM3 CAM4
We recommend you to install 7200rpm EIDE hard disk drive.
5400rpm EIDE hard disk drive is not good enough to retrieve recorded data
in high speed and slow speed playback mode.
ZOOM Press(X2 Enlargement)
Press
Chosen
1X PLAY SPEED
2X PLAY SPEED
4X PLAY SPEED
8X PLAY SPEED
16X PLAY SPEED
32X PLAY SPEED
60X PLAY SPEED
Chosen
1X PLAY SPEED
1/2 PLAYSPEED
1/4 PLAYSPEED
1/8 PLAYSPEED
1/16 PLAYSPEED
1/32 PLAYSPEED
1/60 PLAYSPEED
Playback speed
Display of PLAYBACK SPEED SETUP
backward (REW).
pictures from being overwritten when hard disk is full
During playback at 60x speed, blue screen comes into view instantaneously
once in a while and you could not see some pictures at that moment even
though all they were recorded correctly, due to limitation in speed of reading
data on a hard drive, and it is not a critical error in operation of unit.
To see pictures you could not see, just go back for some seconds and
replay at a little lower speed than before.

14
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
NOTICE : We recommend you to enter your own password as per procedure in page.23 to change the password.
5) After entering the password, press button to go back to the system menu.
MENU
If password entered matches previously set number, “ADMIN GRADE LOGIN OK”message appears.
If password entered does not match previously set number “CURENT PW INPUT ERROR”message
appears.
LOGIN SYSTEM
PASSWORD ( )
1,2,3,4 : INPUT PASSWOR
PIP(MARK) : ERASE PASSWORD
MENU : ENTER OR EXIT
Enter the password
default P/W : 1
NOTICE : Be sure to memorize the changed password.
Display of Login SYSTEM
Log-in
Log-in
3.
NOTICE : To protect hard drive from damaged, turn off the power switch of unit after you first press [MENU] button.
If you press [MENU] button, unit stops recording, and HDD head is not in the process of writing.
Factory default password is 1.

15
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
1. Basic Operation
1) Press button.
MENU
2) Use [UP]/[DOWN] button to select setup item.
3) Press button to enter sub-menu of selected SETUP.
4) Press sub-menu item with [UP]/[DOWN] button, and change the value with [LEFT]/[RIGHT] button.
5) Press button to forward button to go backward.
MENU
6) To go back to the very first SETUP condition recommended by manufacturer, set at FACTORY DEFAULT.
SYSTEM SETUP
DISPLAY SETUP
TCP/IP SETUP
RECORD SETUP
ALARM/MOTION SETUP
CAMERA TITLE
TIME/DATE SETUP
MISCELLANEOUS
FACTORY DEFAULT
SELECT UP/DOWN , ENTER
Display of SYSTEM SETUP
2) Log into the system by entering the password with button and press button
Items remain unchanged when FACTORY DEFAULT is selected.
1. value of TIME/DATE SETUP 2. Date stored on HDD
3. Marked image (Internal backup) 4. ADMIN password
5. ALARM LIST SETUP
1234MENU
to enter SETUP MENU.
button enables to enter and button to go back.
MENU
We recommend users to set at FACTORY DEFAULT in the first operation, or after you replaced HDD.
System Setup
System Setup
4.
You can set at FACTORY DEFAULT all in one (as a whole) or group by group. When cursor is at ALL SETUP, you can set at ON
or OFF by pressing [ENTER] button. If you set ALL SETUP at ON, all groups of settings are SET as per FACTORY DEFAULT
recommended by manufacturer. If you set ALL SETUP at OFF, then you are requested to set each group of settings separately
one by one, ON or OFF, and groups of settings set at ON shall be reset whenever you set at FACTORY DEFAULT.
To reset, you have to select ALL SET or each group of settings (ON or OFF), and then move to RESET NOW and press [ENTER].
ENTER
ENTER
ENTER

16
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
2. DISPLAY SETUP
PB TIME/DATE : On Playback screen, Date and Time is indicated.
DISPLAY SETUP
TIME/DATE
CAMERA TITLE
PB TIME/DATE
PB CAMERA TITLE
DVR STATUS
BORDER SET
SEQUENCE INTERVAL
DISPLAY TYPE
SELECT , PRESS
: ON
: ON
: ON
: ON
: ON
: WHITE
: 01
: COMPO
1
2
3
4
5
6
7
This is about the contents displayed on the display screen.
2002/ARP12 AM 07:40:38
60FPS REC
CAM1 CAM2
CAM3 CAM4
1
2
TIME/DATE : Date and time is indicated on LIVE screen.
CAMERA TITLE : Camera TITLE is indicated on LIVE screen.
PB CAMERA TITLE : Camera TITLE is indicated on the Replay SCREEN.
DVR STATUS : indicates status of operation, such as REC/REPLAY.
BORDER SET : Changes the color of the border - WHITE/ BLACK
SEQUENCE INTERVAL : Sets rotating time interval of pictures . In full screen in live mode or playback mode, pictures are rotating in a
certain time interval, when you press button, and SEQUENCE INTERVAL is for it.
( Time interval from 1 second to 99 seconds)
7
6
5
4
3
A
B
C
D
E
F
Display of DISPLAY SETUP
A C
E
B
D
F
SEQ
8

17
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
3. CAMERA SETUP
1
2
COLOR SETUP : Adjust Camera Image
TITLE SETUP : Input TITLE of each camera
CH NUMBER
BRIGHTNESS
CONTRAST
SATURATION
HUE
GAIN
(-31~ +32)
(-31~ +32)
(-20~ +32)
(-31~ +32)
(-31~ +32)
: Select camera
: Adjust screen brightness
: Adjust color contrast
: Adjust color saturation
: Adjust color hue
: Adjust image signal level
1) Use [LEFT]/[RIGHT] button to select CHANNEL and press button
2) Go into CHANNEL content and use [LEFT]/[RIGHT] button to move to item to be
changed and use [UP]/[DOWN] button to change the letters.
MENU
CAMERA SETUP
COLOR SETUP
TITLE SETUP
ACTIVE CH SETUP
SCREEN POSITION SETUP
COLOR BAR TEST
SELECT , PRESS
1
2
3
4
Display of Camera Setup
5
CAMERA COLOR SETUP
CH NUMBER
BRIGHTNESS
CONTRAST
SATURATION
HUE
GAIN
SELECT , PRESS
Display of CAMERA COLOR SETUP
1
+2
-2
-8
+0
+0
When modification is finished, press button to come back to the MAIN MENU.
Display of CAMERA TITLE SETUP
CAMERA TITLE SETUP
SELECT , PRESS ENTER
0 1 2 3 4 5 6 7 8 9 . , < > ( ) - = A B C D
E F G H I J K L M N O P Q R S T U V W X Y Z a b
c d e f g h I j k l m n o p q r s t u v w x y z
CH1
CH2
CH3
CH4
(CAM 1 )
(CAM 2 )
(CAM 3 )
(CAM 4 )
Right adjustment of each element in COLOR setup will increase picture quarterly displayed.
We recommend you to adjust each element of COLOR SETUP for cameras and monitor to be connected
to the unit, for better appearance.
▶
▲
ENTER
3. CAMERA SETUP

18
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
1
2
SET TIME/DATE : Can set year/month/time/minute/second.
SET the notation of TIME/DATE :
Use [UP]/[DOWN] button to assign Year/Month/Time/Minute/Second and use [LEFT]/[RIGHT] button to change the value.
1. HOUR DISPLAY :
2. DATE DISPLAY :
3. MONTH DISPLAY :
SET TIME/DATE
YEAR
MONTH
DAY
HOUR
MINUTE
SECOND
SELECT , PRESS
2002/APR/15
PM 09:23:17
TIME/DATE SETUP
SET TIME/DATE
SET TIME/DATE TYPE
SELECT , PRESS
1
2
Changes to AM/PM or 24hour time indication
Converts into Asian type/American type/European type
Month indication is changed to English or Numeric
TIME/DATE TYPE SETUP
HOUR DISPLAY
DATE DISPLAY
MONTH DISPLAY
SELECT , PRESS
: AM/PM
: ASIAN
: ENGLISH
Display of Time/Date TYPE
Display of TIME/DATE SETUP
ACTIVE CH SETUP :
COLOR BAR TEST : COLOR BAR CHART is generated.
5
3
Used for adjusting the monitor
CAMERA ACTIVE SETUP
CHs
CH1
CH2
CH3
CH4
SELECT , PRESS ENTER
Display of CAMERA ACTIVE Setup
LIVE
ON
ON
ON
ON
STATUS
ACTIVE
ACTIVE
ACTIVE
ACTIVE
REC
ON
ON
ON
ON
: SCREEN POSITION
ADJUSTMENT
ENTER : DEFAULT POSITION
CAM1 CAM2
CAM3 CAM4
Display of Screen Position Adjustment
2. LIVE : Decides whether to show LIVE screen image or not.
With direction button, move to item to be changed, and press button to select ON/OFF.
1. STATUS : In normal cable condition it is indicated as ACTIVE, and when the cable is disconnected or has problem, it is indicated as LOSS.
3. REC : Decides whether to record relevant channel or not.
SCREEN POSITION SETUP
4Use direction button to move the full screen according to the user’s needs.
ENTER
4. TIME/DATE SETUP

19
3. Operation 15-VP04-HDD2 & 15-VP04-CDRW
5. ALARM/MOTION SETUP
1ALARM SETUP : Sets type of alarm sensors connected to unit.
OFF : No alarm sensor is connected.
NC : Normal Closed alarm sensor. When an event happens, Contact is opened.
NO : Normal Open alarm sensor. When an event happens, Contact is closed.
ALARM DURATION : Duration of recording, when an ALARM is activated.
ALARM/MOTION SETUP
ALARM SETUP
ALARM LIST SETUP
MOTION SETUP
MOTION MASK SETUP
SELECT , PRESS
1
2
3
4
2ALARM LIST SETUP : Shows list of alarms up to 400. If total alarm exceeds 400, it overwrites from the beginning.
Alarm list is very helpful to manage system.
1. With [LEFT]/[RIGHT] button, select SORT, DELETE or GO TO.
ALARM LIST SETUP
NO DATE TIME TYPE
CALM
………………………………………………………
001 02/04/01 21 : 14 :11 3_H_
. . . .
. . . .
. . . .
. . . .
. . . .
SORT : TIME DELETE GOTO
SELECT , ENTER OR MODE Move to play screen of relate
appropriate time.
1 2 3 Sort
method
CH
SORT TIME
TYPE DELETE MARK
PAGE
ALL
2. SORT
Press button to select submenu of SORT ,that are CH ,TIME and TYPE.
1) CH : Sort by CHANNEL 2) TIME : Sort by TIME 3) TYPE : Sort by TYPE
3. DELETE
Press button when DELETE is highlighted, and select MARK, PAGE or ALL using [LEFT]/
[RIGHT] button and press button.
1) MARK : Deletes marked item in the list.
C: CAMERA
A : ALARM
L : LOSS
M :MOTION
ALARM POP-UP : When an alarm is activated, display screen is switch to full screen of image from relevant
channel, and a color of camera number is changed to red.
If an alarm is activated from 2 channels, display screen is changed to quarterly split screen
(Quad screen), and a color of camera number of relevant channel is change to red.
Display of ALARM/MOTION SETUP
SELECT LIST TYPE : Select type of event to be enlisted in the event list. “A” indicates Alarm, “L” indicates Loss,
and “M” indicates Motion. You can select NONE if you do not want to have event list, and
ALM if you want all of Alarm, Loss and Motion are enlisted in event list, by pressing
[LEFT] and [RIGHT] button.
ENTER
ENTER
ENTER
