CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
PROJECT NAME: LT200 Smart Lighting Tower
STP FILE FOR ILUSTRATIONS: LINK
REGIONAL QSGs and LANGUAGES REQUIRED:
Versions: NA, EU/UK, AU/JP, CN
•NA - English, Canadian French, Latin Spanish, Brazil Portuguese
•Europe –English, French French, Spain Spanish, German, Italian, Portugal Portuguese, Russian,
Polish, Dutch, Arabic, Swedish, Norwegian, Danish, Finnish.
•AP –English, Traditional Chinese, Korean, Japanese
•CN - English, Simplified Chinese
REFERENCE IMAGE
COPY AND CONTENT REQUIREMENTS
1. Change line-art to 1 Lighting Tower.
2. Keep iCUE logo as it.
Product Name - LT200 Smart Lighting Tower
Sub Head –Wireless Smart Lighting Tower
LT200 Smart Lighting Tower

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
PACKAGE CONTENTS
SPECIFICATIONS
SET UP
PACKAGE CONTENTS -
1 x diffused RGB lighting tower with stand
ON/OFF
Lighting button
Aluminum Base
-
1 x USB-C to C Wall Adapter, 1800mm cable
1 x USB-C to A Receiver
1 x Wireless Receiver

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
SPECIFICATIONS:
Unit
Dimensions
422mmx95mmx95mm (TBD)
Power Inputs
(AC Adapter)
Wall Adapter, 5V 3A, 15W
Tower
White plastic housing, Aluminum base,
96 individually addressable LEDs
USB Cable
USB-C to USB-C cable, 1800mm
USB Connector
Adapter
USB-C to USB-A
Wireless
Receiver
USB-A receiver, range of up to 30 feet
Out of the Box Setup
1. Remove LT200 Smart Lighting Tower from box.
2. Connect the USB-C to C cable to the LT200 base and the wall adapter,
plug the adapter into an available wall outlet.
3. Power on the LT200 by pressing the ON/OFF switch on the side of the
base.
4. Press the lighting button to cycle through the preset lighting effects.
The lighting button is disabled when LT200 is connected to Corsair iCUE.
The list of effects:
• Super X (Combination of predetermined effects)
• Rainbow Wave
Color Shift
• Color Pulse
• Color Wave
• Static Color
• Sequential
• Marquee
• Rainbow
• Strobing
• Visor

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
Connecting LT200 to a PC via Corsair iCUE
1. Turn on the PC and plug the wireless receiver into an available USB-A
port. The LT200 Lighting Tower needs to be located within 30 feet of
the wireless receiver and no interference for data transmission.
2. Download CORSAIR iCUE software at www.corsair.com/downloads.
3. Internet connection is required to download the latest. Run the
installer program and follow instructions for installation.
4. A maximum of 4 LT200 Lighting Towers can be paired to a single
wireless receiver via Corsair iCUE software. (Additional tower is sold
separately.)
5. The LEDs can support 16.8M colors and update at rate of 25 times
per second with no flickering.
Pairing additional LT200 lighting tower(s) to a single wireless receiver
1. Power on additional LT200 lighting tower.
2. Initiate pairing by pressing and holding the lighting button for 10
seconds, the LT200 LEDs will pulse Blue.
3. On the system that has the wireless receiver, complete pairing in
Corsair iCUE software.
4. If pairing is successful, the LT200 LEDs will turn Green to confirm.
5. If pairing is unsuccessful, the LT200 LEDs will turn Red, repeat step 2
and try pairing again.
Corsair Memory, Inc. declares that this equipment is compliance with
Directive 2014/30/EU and 2011/65/EU. A copy of the original declaration
of the conformity can be obtained at “regulat[email protected].”

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
iCUE LT200
WEB: corsair.com
Phone: [phone]
Support: support.corsair.com
BlOG: corsair.com/blog
FORUM: forum.corsair.com
YOUTUBE: youtube.com/corsairhowto
2-year warranty
Corsair Memory Inc. All rights reserved. CORSAIR and the sails logoo are
registered trademarks in the United States and /or other countries. All
other trademarks are the property of their respective owners. Product
may vary slightly from other pictured.
NA version
FCC
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This product complies with the FCC portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual. The further RF exposure
reduction can be achieved if the product can be kept by 20cm from the user body or set the device to
lower output power if such function is available.
FCC ID: 2AAFMRDD0007
ISED
Canada (ISED Statement)
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and
compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102
et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur
l'exposition et la conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre
antenne ou émetteur. Cet équipement devrait être installé et actionné avec une distance minimum
de 20 centimètres entre le radiateur et votre corps.
IC: 10954A-RDD0007

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
EU Version
CE
ENGLISH
CORSAIR MEMORY, Inc. declares that this equipment is in
compliance with Directive 2014/53/EU, Directive 2011/65/EU,
and Directive 2009/125/EC. A copy of the original declaration of
conformity can be obtained at “corsair.com/documentation”.
The Authorized Representative in Europe
Corsair Memory, BV
Wormerweg 8, 1311 XB, Almere, Netherlands
Frequency Band: 2.400 –2.4835 GHz
Transmit Power EIRP: <20 dBm
Operating Temperature: 0°C ~ + 40°C
FRENCH
CORSAIR MEMORY, Inc. déclare que son équipement est
conforme aux directives 2014/53/UE, 2011/65/UE, et
2009/125/CE. Une copie de la déclaration de conformité originale
peut être obtenue en envoyant un courrier électronique à
l’adresse corsair.com/documentation.
La Représentant Agrée en Europe
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Bande de fréquences: 2.400 –2.4835 GHz
Puissance de transmission PIRE: <20 dBm
Température de fonctionnement: 0°C ~ + 40°C
GERMAN
CORSAIR MEMORY, Inc. erklärt, dass dieses Gerät den Richtlinien
2014/53/EU, 2011/65/EU und 2009/125/EU entspricht. Eine
Kopie der ursprnglichen Konformitätserklärung kann unter
corsair.com/documentation angefordert werden.
Die Autorisierten Vertreter in Europa
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Frequenzbereich: 2.400 –2.4835 GHz
EIRP-Sendeleistung: <20 dBm
Betriebstemperatur: 0°C ~ + 40°C

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
DUTCH
CORSAIR MEMORY, Inc. verklaart dat dit apparaat overeenstemt
met Europese Richtlijn 2014/53/EU, 2011/65/EU, en Europese
Richtlijn 2009/125/EU. Een kopie van de originele
conformiteitsverklaring kan worden verkregen via
corsair.com/documentation.
De Bevoegde Vertegenwoordiger in Europa
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Frequentieband: 2.400 –2.4835 GHz
Zendvermogen ERP: <20 dBm
Gebruikstemperatuur: 0°C ~ + 40°C
ITALIAN
CORSAIR MEMORY, Inc. dichiara che il presente apparecchio è
conforme
alla Direttiva 2014/53/UE, 2011/65/UE e 2009/125/CE. È possibile
richiedere una copia della dichiarazione originale di conformità
inviando un’email all’indirizzo “corsair.com/documentation”.
Il Rappresentante Autorizzato per L’europa
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Banda di frequenza: 2.400 –2.4835 GHz
Potenza di trasmissione EIRP: <20 dBm
Temperatura di funzionamento: 0°C ~ + 40°C
SPANISH
CORSAIR MEMORY, Inc. declara que este equipo cumple con las
directivas 2014/53/UE, 2011/65/UE y 2009/125/CE. Puede
obtener una copia de la declaración de conformidad original en
“corsair.com/documentation”.
El Representante Autorizado en Europa
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Banda de frecuencia: 2.400 –2.4835 GHz
Potencia de transmisión EIRP: <20 dBm
Temperatura de funcionamiento: 0°C ~ + 40°C
PORTUGUESE
A CORSAIR MEMORY, Inc. declara que este equipamento está em
conformidade com as Diretivas 2014/53/UE 2011/65/UE e
2009/125/CE. É possível obter uma cópia da declaração de
conformidade original através do endereço
“corsair.com/documentation”.
O Representante Autorizado na Europa
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Banda de frequência: 2.400 –2.4835 GHz
Energia de transmissão EIRP: <20 dBm
Temperatura de operação: 0°C ~ + 40°C

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
POLISH
Firma CORSAIR MEMORY, Inc. oświadcza, że to urządzenie jest
zgodne z dyrektywami 2014/53/UE 2011/65/UE i 2009/125/EC.
Kopię deklaracji zgodności można uzyskać pod adresem
corsair.com/documentation.
Autoryzowany Przedstawiciel w Europie
CORSAIR MEMORY, BV Wormerweg 8, 1311 XB,
Almere, Netherlands
Pasmo częstotliwości: 2.400 –2.4835 GHz
Moc nadawania EIRP: <20 dBm
Temperatura pracy: od 0°C do + 40°C
Swedish
Need Marcom help with translation!
Need Marcom help with translation!
Danish
Need Marcom help with translation!
Need Marcom help with translation!
Finnish
Need Marcom help with translation!
Need Marcom help with translation!
The Authorized Representative in Europe
Corsair Memory, BV
Wormerweg 8, 1311 XB, Almere, Netherlands
WEEE STATEMENT
EN (NA)
NOTE ON ENVIRONMENTAL PROTECTION
After the implementation of the European Directive 2012/19/EU in the national legal system,
the following applies:
>Electrical and electronic devices may not be disposed of with domestic waste.
>Consumers are obliged by law to return electrical and electronic devices at the end of their service lives to the public collecting points set up for this
purpose or point of sale. Details to this are defined by the national law of the respective country. This symbol on the product, the instruction manual
or the package indicates that a product is subject to these regulations. By recycling, reusing the materials or other forms of utilising old devices, you
are making an important contribution to protecting our environment.
FR
REMARQUES CONCERNANT LA PROTECTION DE L’ENVIRONNEMENT
Conformément à la directive européenne 2012/19/UE, et afin d’atteindre un certain nombre d’objectifs en matière de protection de l’environnement,
les règles suivantes doivent être appliquées:
>Elles concernent les déchets d’équipement électriques et électroniques. Le pictogramme “picto” présent sur le produit, son manuel d’utilisation ou
son emballage indique que le produit est soumis
àcette réglementation.
>Le consommateur doit retourner le produit usager aux points de collecte prévus àcet effet. Il peut aussi le remettre àun revendeur. En permettant
enfin le recyclage des produits, le consommateur contribuera à la protection de notre environnement. C’est un acte écologique.
DE
HINWEIS ZUM UMWELTSCHUTZ
Ab dem Zeitpunkt der Umsetzung der europäischen Richtlinie 2012/19/EU in nationales Recht gilt folgendes:
>Elektrische und elektronische Geräte dürfen nicht mit dem Hausmüll entsorgt werden.
>Der Verbraucher ist gesetzlich verpflichtet, elektrische und elektronische Geräte am Ende ihrer Lebensdauer an den dafür eingerichteten,
öffentlichen Sammelstellen oder an die Verkaufstelle zurückzugeben. Einzelheiten dazu regelt das jeweilige Landesrecht. Das Symbol auf dem
Produkt, der Gebrauchsanleitung oder der Verpackung weist auf diese Bestimmungen hin. Mit der Wiederverwertung, der stofflichen Verwertung
oder anderer Formen der Verwertung von Altgeräten leisten Sie einen wichtigen Beitrag zum Schutz unserer
Umwelt. In Deutschland gelten oben genannte Entsorgungsregeln, laut Batterieverordnung, für Batterien und Akkus entsprechend.

CORSAIR iCUE LT200 WIRELESS SMART LIGHTING TOWER - QSG BRIEF
NL
NOTITIE AANGAANDE DE BESCHERMING VAN HET MILIEU
Ten gevolge van de invoering van de Europese Richtlijn 2012/19/EU in het nationaal juridisch system, is het volgende van toepassing:
>Electrische en electronische toestellen mogen niet weggegooid worden tesamen met het huishoudelijk afval.
>Consumenten zijn wettelijk verplicht om electrische en elctronische apparaten op het einde van gebruik in te dienen bij openbare verzamelplaatsen
speciaal opgezet voor dit doeleinde of bij een verkooppunt. Verdere specificaties aangaande dit onderwerp zijn omschreven door de nationale wet
van het betreffende land. Dit symbool op het product, de gebruiksaanwijzing of de verpakking duidt erop dat het product onderworpen is aan deze
richtlijnen. Door te recycleren, hergebruiken van materialen of andere vormen van hergebruiken van oude toestellen, levert u een grote bijdrage aan
de bescherming van het mileu.
IT
INFORMAZIONI PER PROTEZIONE AMBIENTALE
Dopo l’implementazione della Direttiva Europea 2012/19/UE nel sistema legale nazionale, ci sono
le seguenti applicazioni:
>I dispositivi elettrici ed elettronici non devono essere considerati rifiuti domestici.
>I consumatori sono obbligati dalla legge a restituire I dispositivi elettrici ed elettronici alla fine della loro vita utile ai punti di raccolta pubblici preposti
per questo scopo o nei punti vendita. Dettagli di quanto riportato sono definiti dalle leggi nazionali di ogni stato. Questo simbolo sul prodotto, sul
manuale d’istruzioni o sull’imballo indicano che questo prodotto è soggetto a queste regole.
ES
NOTA SOBRE LA PROTECCIÓN MEDIOAMBIENTAL
Después de la puesta en marcha de la directiva Europea 2012/19/UE en el sistema legislativo nacional, Se aplicara lo siguiente:
> Los aparatos eléctricos y electrónicos, asícomo las pilas y las pilas recargables, no se deben evacuar en la basura doméstica.
> El usuario estálegalmente obligado a llevar los aparatos eléctricos y electrónicos, asícomo pilas y pilas recargables, al final de su vida útil a los
puntos de recogida comunales o a devolverlos al lugar donde los adquirió. Los detalles quedaran definidos por la ley de cada país. El símbolo en el
producto, en las instrucciones de uso o en el embalaje hace referencia a ello. Gracias al reciclaje, al reciclaje del material o a otras formas de
reciclaje de aparatos usados, contribuye Usted de forma importante a la protección de nuestro medio ambiente.
PT
NOTA EM PROTECÇÃO AMBIENTAL
Após a implementação da directiva comunitária 2012/19/UE no sistema legal nacional, o seguinte aplica-se:
>Todos os aparelhos eléctricos e electrónicos não podem ser despejados juntamente com o lixo doméstico.
>Consumidores estão obrigados por lei a colocar os aparelhos eléctricos e electrónicos sem uso em locais públicos específicos para esteefeito ou
no ponto de venda. Os detalhes para este processo são definidos por lei pelos respectivos países. Este símbolo no produto, o manual de
instruções ou a embalagem indicam que o produto estásujeito a estes regulamentos. Reciclando, reutilizando os materiais dos seus velhos
aparelhos, esta a fazer uma enorme contribuição para a protecção do ambiente.
PL
WSKAZÓWKI DOTYCZĄCE OCHRONY ŚRODOWISKA
Od czasu wprowadzenia europejskiej dyrektywy 2012/19/UE do prawa narodowego obowiązują
następujące ustalenia:
>Urzadzeń elektrycznych i elektronicznych nie należy wyrzucać wraz z innymi odpadami domowymi.
>Użytkownik zobowiązany jest, niepotrzebne lub zniszczone urządzenia elektryczne odnieść do punktu zbiórki lub do sprzedawcy. Szczegółowe
kwestie regulują przepisy prawne danego kraju. Informuje o tym symbol przekreślonego kosza umieszczony na opakowaniu. Segregując śmieci
pomagasz chronic środowisko naturalne.
FI
YMPÄRISTÖNSUOJELUA KOSKEVA OHJE
Siitälähtien, kun Euroopan unionin direktiivi 2012/19/EU otetaan käyttöön kansallisessa lainsäädännössä, pätevät seuraavat määräykset:
>Sähkö- ja elektroniikkalaitteita ei saa hävittäätalousjätteen mukana.
> Kuluttajalla on lain mukaan velvollisuus toimittaa sähkö- ja elektroniikkalaitteet niiden käyttöiän päätyttyäniille varattuihin julkisiin keräyspisteisiin
tai palauttaa ne myyntipaikkaan. Tähän liittyvistäyksityiskohdista säädetään kulloisenkin osavaltion laissa. Näistämääräyksistämainitaan myös
tuotteen symbolissa, käyttöohjeessa tai pakkauksessa. Uudelleenkäytöllä, materiaalien uudelleenkäytöllätai muilla vanhojen laitteiden
uudelleenkäyttötavoilla on tärkeävaikutus yhteisen ympäristömme suojelussa.
HU
KÖRNYEZETVÉDELMI TUDNIVALÓK
Az európai irányelvek 2012/19/EU ajánlása szerint, a megjelölt időponttól kezdve, minden EU-s tagállamban érvényesek a következők:
>A leselejtezett elektromos és elektronikus készulékeket nem szabad a háztartási szemétbe dobni.
> Az elhasznált és működésképtelen elektromos és elektronikus készulékek gyűjtésére törvényi előírás kötelez mindenkit, ezért azokat el kell
szállítani egy kijelölt gyűjtő helyre vagy visszavinni a vásárlás helyére. A termék csomagolásán feltuntetett szimbólum egyértelmű jelzést ad erre
vonatkozóan a felhasználónak. A régi készulékek begyűjtése, visszaváltása vagy bármilyen formában történő újra hasznosítása közös hozzájárulás
környezetunk védelméhez.
CZ (CS)
OCHRANA ŽIVOTNÍHO PROSTŘEDÍ
Evropská směrnice 2012/19/EU stanovuje:
>Elektrické a elektronické přístroje se nesmí vhazovat do domácího odpadu.
>Elektrické a elektronické přístroje musí bt zlikvidovány podle zákona na místech k tomu určench. Recyklacínebo jinm způsobem zpracování
vrazně přispíváte k ochraně našeho životního prostředí!
EL (GR)
ΥΠΌΔΕΙΞΗ ΣΧΕΤΙΚΆ ΜΕ ΤΗΝ ΠΡΟΣΤΑΣΊΑ ΠΕΡΙΒΆΛΛΟΝΤΟΣ
Απότη στιγμήπου ηΕυρωπαϊκή Οδηγία 2012/19/EE ενσωματώνεται στο εθνικό δίκαιο ισχύουν τα εξής:
>Οι ηλεκτρικές και ηλεκτρονικές συσκευές δεν επιτρέπεται να πετιούνται στα σκουπίδια.
>Οκαταναλωτής υποχρεούται δια νόμου να επιστρέφει τις ηλεκτρικές και ηλεκτρονικές συσκευές στο τέλος της ζωής τους πίσω στα ειδικά προβλεπόμενα
σημεία συγκέντρωσης ήστα καταστήματα αγοράς. Οι λεπτομέρειες ρυθμίζονται στη σχετική νομοθεσία. Το σύμβολο πάνω στο προϊόν, στο εγχειρίδιο
χρήσης ήστη συσκευασία παραπέμπει σε αυτές τις διατάξεις. Με την επαναχρησιμοποίηση, την ανακύκλωση των υλικών ήμεάλλους τρόπους
αξιοποίησης των παλαιών συσκευών συμμετέχετε ενεργά στην προστασία του περιβάλλοντός μας. Στη Γερμανία ισχύουν αντίστοιχα οι παραπάνω κανόνες
απόρριψης σύμφωνα μετον κανονισμόγια μπαταρίες και συσσωρευτές.
DA
ANVISNINGER TIL BESKYTTELSE AF MILJØET
Efter implementeringen af det europæiske direktiv 2012/19/EU i det nationale lovgivningssystem
gælder følgende:
>Elektriske og elektroniske apparater måikke bortskaffes med husholdningsaffaldet.
>Forbrugeren er ved afslutningen af elektriske og elektroniske apparaters levetid lovmæssigt forpligtet til at aflevere disse påde dertil indrettede
offentlige indsamlingssteder eller hos sælgeren. Enkeltheder vedrørende dette fastlægges af de respektive landes nationale lovgivning. Dette
symbol påproduktet, betjeningsvejledningen eller emballagen viser, at produktet er underlagt disse bestemmelser. Med genanvendelse,
genanvendelse af materialer eller andre former for genbrug af gamle apparater yder du et vigtigt bidrag til beskyttelse af vores miljø.
SV
