Cosa EX9-5B/56 User manual

Ceiling Fan
EX9-5B/56
EX9-5B/40
Instruction
Manual
Version: 2023 V1

Warning
Installation and maintenance work shall only be performed by qualified persons, familiar with local
code and regulation, and experienced with this type of appliance.
All field wiring must be installed in accordance with the national wiring regulation.
Ensure that the rated voltage of the unit corresponds to that of the name plate before commencing
wiring work according to the wiring diagram.
The appliance must be permanently connected to the electricity supply through a double pole switch
having a contact separation of at least 3mm in all poles
The unit must be GROUNDED to prevent possible hazard due to insulation failure.
The earth wire is approximately 60mm longer than safety wire. This is to ensure at the event whereby
the suspension system fails, the (L) and (N) wire will break leaving the fan remain earthed to prevent
electrocution.
Tighten the blade firmly using a screw driver.
Blades that are detached from the unit during operation will cause serious injuries and property
damages.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliances.
Confirm that the power supply has been switched OFF before installing or servicing the unit. Ensure
that the blade is fully static before doing any maintenance work.
Item Page No.
1. Safety Precautions ................................................................................................ 1 - 2
2. Parts & Accessories .............................................................................................. 3
3. Installation Instruction ............................................................................................ 4 - 8
4. Transmitter Learning Process ................................................................................ 9
5. Transmitter Assembly & Operation ........................................................................ 10
5. Power Supply Connection ...................................................................................... 10 - 11
6. Circuit Diagram ...................................................................................................... 11
7. Maintenance .......................................................................................................... 12
8. Technical Specifications ........................................................................................ 12 - 13
9. Customer Service Centre ...................................................................................... 13
Table of Contents
Safety Precaution
1

STOP using the ceiling fan when any abnormality or failure occurs.
If unusual oscillating movement is observed, immediately stop using the ceiling fan and contact the
manufacturer, its service agent or suitably qualified persons.
CAUTION
Please take note of the following important points when installing.
The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan.
The mounting of the suspension system shall be performed by the manufacturer, its service agent or
suitably qualified persons.
The fan is to be installed so that the blades are more than 2.5m above the floor.
Safety cord should not be longer than the earthing conductor.
Should failure of the suspension system occur, the supporting of the fan must not rely on the earthing
conductor. The earthing terminal in the fan assembly should be such that should any part of the
suspension system fall off, the body of the fan assembly shall effectively earthed.
Ensure that the unit’s panel is closed after service or installation.
Unsecured panels will cause the unit to operate noisily.
Sharp edges and coil surfaces are potential locations which may cause injury hazards. Avoid
from being in contact with these places.
Before turning off the power supply set the remote controller’s ON/OFF switch to the “OFF”
position.
If this is not done, the unit’s fans will start turning automatically when power resumes, posing a
hazard to service personnel or the user.
Do not operate any heating apparatus too close to the ceiling fan unit or use in room where mineral
oil, oil vapour or oil steam exist, this may cause plastic part to melt or deform as a result of excessive
heat or chemical reaction.
Avoid the ceiling fan unit from exposing to direct sunlight, this may cause degradation of plastic
material as a result of excessive heat and UV radiation.
Ensure the colour of wires of the outdoor unit and the terminal markings are same to the indoors
respectively.
Do not use joined and twisted wires for incoming power supply.
Do not place any object in the path of the blades. Avoid raising objects or your arms near the ceiling
fan.
The fan suspension system and blade screw tightening shall be examined yearly.
Replacement of parts of the safety suspension system device shall be performed by the manufactur-
er, its service agent or suitably qualified persons.
Torque value for screw/bolts for securing primary suspension system for motor is 2Nm.
Safety Precaution
2
AAA
AAA
Battery x 2
Wall Screw x 2
Transmitter &
Holder x 1
Receiver x 1
Parts & Accessories
3
Transmitter Kit
Bolt x 2
Blade Screw &
Washer x 11
Rubber Pulley
Assembly x 1
Canopy
Motor Assembly
Coupling Cover
Blade x 5
Motor
Bracket Downrod

Step 2
a. Assemble the Canopy and Coupling Cover through the Downrod.
b. Fix the Rubber Pulley Assembly to the Downrod with Bolt, Washer, Nut and tighten them firmly,
then insert the Clevis Pin.
45
Installation Instruction Installation Instruction
Step 3 - Remove the Bolt, Clevis Pin, Nut, Washer and Rubber Pulley from the Downrod.
Place the Rubber Pulley onto the ceiling hook and fix back the Bolt, Clevis Pin, Nut and
Washer.
IMPORTANT : Clevis Pin MUST be inserted to prevent Nut from loosening.
Step 4 - Remove the Safety Wire screw from the Downrod.
IMPORTANT : Clevis pin MUST be inserted to prevent Nut from loosening.
IMPORTANT : SWITCH OFF THE ELECTRICAL MAINS AT THE CIRCUIT BREAKER
FUSE BOX.
Step 1
a. Route all the wires from the Motor through the Motor Bracket.
b. Route all the wires through the Downrod.
c. Fix the Motor Bracket and Downrod to the Motor Assembly with Bolt, Washer, Nut and
tighten them firmly then insert the Clevis Pin.
IMPORTANT : Clevis Pin MUST be inserted to prevent Nut from loosening.
Washer & Nut
Clevis Pin
c.
a.
Motor
Shaft
Motor Bracket
a. b. Rubber Pulley
Assembly
Bolt Washer, Nut &
Celvis Pin
Canopy
Coupling
Cover
Rubber
Pulley
Clevis Pin
Nut
Safety Wire
Washer
b.
Downrod

Installation Instruction Installation Instruction
76
Below shows a complete installation diagram.
Step 7 - Install the Blades on Motor with Blade Screw and Washer.
IMPORTANT : Assemble the Fan Blades only after the ceiling fan is mounted on
the hook.
Step 6 - Connect the Connectors from Fan and Receiver. Connect the wires from the
receiver to House’s Supply Wire. Connect Earth Wire to House Supply Earth Terminal.
Step 5 - Tie the Safety Wire across the hook as shown.
In the case of “J”Hook
is being used.
Green/Yellow(E)
Brown(L)
Blue(N)
Green/Yellow(E)
Brown(L)
Blue(N)
Green/Yellow(E)
White
Yellow
Grey
House Supply Wires
White
Yellow
Grey

9
8
The receiver & transmitter is pre-programmed in factory. If you wish to control 2 or more
fans using 1 transmitter, the below steps are required.
DO NOT PRESS ANY OTHER BUTTON DURING THIS PROCESS
Step 1
a) Insert the 2 pcs of batteries (provided) into transmitter.
b) Turn on the power supply (wall switch) to the fan.
c) Within 30 sec., press and hold the “OFF” button for 3 sec. Once the receiver has
detected the frequency, transmitter will “Beep Beep” twice. Programming process is
completed and fan is ready to use.
If the fan is not responding to the transmitter, repeat Step 1b.
Transmitter Learning Process
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
REGULATOR OR DIMMER SWITCH.
Function of Transmitter
The transmitter & receiver is incorporated with last memory function. This function stores
your last setting in memory and the next time you turn on the fan, fan will operate as the
last setting.
Transmitter Assembly & Operation
IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
REGULATOR OR DIMMER SWITCH.
Mount the remote control
holder on the wall with the
screws provided.
- Turn off fan
- Fan speed lowest to highest
- Natural wind, creating gentle sea-
breeze effect
- Forward/Reverse, turn anti-clockwise
or clockwise rotation.
- Timer off - fan turns on after 1hr
- Timer off - fan turns on after 3hr
- Timer off - fan turns on after 6hr
Function of Forward & Reverse
Fan must be turned on and rotating.
Press Forward/Reverse button and fan will slow down and then change direction
(approx. 15 sec). When the fan is slowing down to change direction, the Fan Speed
function is disabled until direction has been changed.
Forward
Fan rotates anti-clockwise blowing
the air downwards creating the
wind chill effect. Suitable for hot
weather condition.
Reverse
Fan rotates clockwise drawing the air
towards the ceiling circulating the warm
air downwards. This function works best
at low speed. Suitable for air-conditioned
condition.
Press and hold
for 3 sec
-
-
Natural wind, creating gentle sea-breeze
effect.
Fan speed will decrease gradually
every 30 minutes until reach to speed 1

IMPORTANT : DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO
REGULATOR OR DIMMER SWITCH.
Regulator Dimmer Switch
Circuit Diagram
10 11
Double Pole
Switch
Single Pole
Switch
Power
Supply
Power Supply Connection
DC
Motor
ANT
W
N
Blue
Grey
Yellow
White
Neutral (Blue)
Live (Brown)
Earth (Green/Yellow)
Earth (Green/Yellow)
Brown
Green/Yellow
MAIN PCB
L
E
V
U
Power Supply
220-240V~ 50Hz

Due to the fan’s natural movement, connections may get loose after period of usage. To
ensure a proper and safety usage, it is highly recommended to inspect and tighten all
connections every 6 months.
Cleaning
Cleaning your fan periodically will prolong its new appearance. Basic cleaning procedures
are as follows :
1. Use only water and mild soap. Do not use solvents, corrosive or acidic solution.
2. Damp the cloth lightly. Use only soft or lint-free cloth to clean the fan. Rough fabric will
scratch the surface.
3. Do not bent the blades while cleaning. At the event where blades are bent or damage,
order new set of blades from service center or dealer shop.
4. There is no need to oil the fan.
Maintenance
Technical Specifications
Model
No. of Blades
Fan Width
Motor RPM
Voltage
Motor Wattage
Nett Weight
Gross Weight
EX9-5B/56
5
1420mm (56”)
75 - 203
220-240V~ 50Hz
4W - 45W
4.7kg
5.4kg
EX9-5B/40
5
1015mm (40”)
84 - 226
220-240V~ 50Hz
4W - 40W
4.5kg
5.2kg
If you need any technical assistance or faulty report, please contact our customer service
centre at :
Alpha Home Appliances Sdn. Bhd. (390258-H)
Head Office : 6, Jalan Sungai Kayu Ara 32/37, Berjaya Park, Section 32,
40460 Shah Alam, Selangor.
Tel : [phone] Fax : [phone]
Website : www.alphamalaysia.com Email : [email protected]
Johor Bahru : 71, Jalan Molek 3/10, Taman Molek, 81100 Johor Bahru.
Tel : [phone] / 4933 Fax : [phone]
Melaka : 19, 19-1 & 19-2, Jalan KSB 11, Taman Kota Syahbandar, 75200 Melaka.
Tel : [phone] / 6293 Fax : [phone]
Ipoh : 11, Laluan Tasek Timur 5, Taman Tasek Indra, 31400 Ipoh, Perak.
Tel : [phone] Fax : [phone]
Penang : 28, Jalan Icon City, Icon City, 14000 Bukit Mentajam, Penang.
Tel : [phone] / 2066 / 2566 Fax : [phone]
Pahang : A131, TK1, Jalan Wang Ah Jang, Taman Liza, 25100 Kuantan, Pahang.
Tel : [phone] Fax : [phone]
Technical Specifications
Customer Service Centre
More than 2.5m (8’ 2”)
More than
1000mm
342mm (13.5”)
273mm (10.7”)
EX9-5B/56 1420mm (4’ 8”)
EX9-5B/40 1015mm (3’ 4”)
12 13
