COSY K9CM Operating instructions
3 DIGIT3 DIGIT
TM
Product Information & Operating Instructions
Multicounter Token Number Display
Model : K9CM
Upto 10 counters can be connected .
COSY Token Display System are ideal for Serving Counters in Offices, Banks,
Airports, Doctors- Clinics, Restaurants and other such places where people have
to wait in line for their turn. These systems allow customers to wait without
having to stand in line, once their number is displayed then only they have to
come to the counter for their turn.
Multi Counter systems are recommended for applications where all counters are
providing same services so that customers can be attended by any counter.
Applications:
Features :
* Simple operation and easy to install.
* Large sized 4 inches high LED Displays, visible from 100 feet distance.
* utomatic UP /DOWN counting with pleasant musical chime.
* Solid state high efficiency circuit with 8 bit micro controller.
A
* Feather touch heavy duty key board.
* Robust design. Lightweight ABS Plastic moulded control cabinets & lightweight LED displays.
Specifications:
Power Supply : 220 Volts AC + 10% ( Optional 12 V 7.5AH Battery for Backup ) system has built-in battery charger.
Dimensions & Weight : Display Units: 17 inches X 7 inches X 1 inches
7Control Unit: inches X 6.5inches X 2.5 inches
Connecting cable between control and display : 4 core cable with 9 pin D connectors.
Standard cable length shipped is 10 meters. Maximum recommended cable length 25 meters.
Installation :
1. Connect the Display with main control unit by connector cable provided with system.
2. Connect counter switches with main control terminal strip using any 2 core telephone cable.
3. Connect Mains cable of control to 220 VAC . ( Also Recommended 12 Volt Battery or
UPS for back-up ). Switch ON the system by RED Power ON/OFF switch provided at side.
( select the required bell duration by simultaneously keeping pressed a number key and Key before
switching ON the system. e.g. ( B
1 +B makes bell sound for 1 sec.) ( 3 +B for 3sec.) )
Press any required starting number up to 3 digits in Manual mode. Select Auto UP or Down
counting Mode using the small slide switch in the control .
Change the switch on the top to Auto Mode .
Now when any of the number key 0 to 9 is pressed , the display will show the incremented
next token number along with the pressed counter number.Calling Counter number will be the
same number as the key pressed 0 to 9 .
(Automatic bell also sounds with every change of number).
Connection to all number keys are provided in parallel on an external terminal strip where switches
from diffrent counters can be connected .Any Bell push switch can be connected using a single pair
cable . Do not provide any electrical pulse at this terminal strip.
Caution :
Do not remove the cable of display while the system is ON.
In case 12 V battery is connected Switch OFF the system from side of control unit only .
Keep the mains supply to control unit from Mains power outlet ON to enable battery charging
when system is not in use.
Manufactured by:
COSY COMMUNICATIONS ,1, Indraprastha, Sewla, Majra, Dehradun - 248 171
