CO04D Digital Radio
Quick Start Guide
COTRE

1
To Users
Thank you for purchasing our product! This Manual (contains both
analog and digital radios) is designed to make you quickly grasp the
use of the device. In order to avoid physical injury or property loss due
to improper operation, please read this Manual carefully before using
the device.
Notice
The device meets the requirements of FCC PART 90, PART 97 and
PART 15. Local laws and regulations shall be complied with when
setting up or using the equipment, and corresponding qualifications
and relevant procedures shall be obtained if necessary. Consulting the
relevant authorities is suggested.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications.However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o󰀨 and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
·Reorient or relocate the receiving antenna.
·Increase the separation between the equipment and receiver.
·Connect the equipment into an outlet on a circuit di󰀨erent from that
to which the receiver is connected.
·Consult the dealer or an experienced radio/TV technician for help.
Using Tips

2
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. this device may not cause harmful interference, and.
2. this device must accept any interference received, including
interference that may cause undesired operation.
ISEDC RSS warning
This product meets the applicable Industry Canada technical
specifications. / Le présent matériel est conforme aux specifications
techniques applicables d’Industrie Canada.
Safety Information
In order to use the radio safely and e󰀩ciently, please read the following
safety information:
·The radio can only be maintained by professional technicians. Do not
disassemble the radio without permission.
·Only the batteries and chargers specied by our company can be
used.
·To avoid problems caused by electromagnetic interference and
electromagnetic compatibility, please turn o󰀨 the radio in places
where the "Please turn o󰀨 the radio" sign is displayed, such as
hospitals and other health care places. When taking the ight, please
turn o󰀨 the radio if the crew requests to do so.
·In vehicles with airbags, do not place the radio in the area where
airbag deployment may be involved.
·Please turn o󰀨 the radio before entering ammable or explosive
environment.
·Do not replace or charge the battery in a ammable or explosive
environment.
·Please turn o󰀨 the radio before approaching the blasting area and
the detonator area.
·Do not use the radio with damaged antenna. A damaged antenna
Using Tips Using Tips

3
Using Tips Using Tips
may cause minor burns when it comes into contact with the skin.
·Do not expose the radio to direct sunlight for a long time or place it
near the heating Radio.
·If you wear a portable radio, make sure the antenna is at least 2.5
cm away from your body when the radio is transmitting.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
CAUTION:
Use the approved charger to charge the battery. The remaining
lithium-ion battery is limited to 30% pursuant to the new lithium battery
shipment regulation approved by International Air Transport Association
(IATA). Before use, charge the battery. It is recommended that the radio
remain powered o󰀨 during charging.
Use of battery not recommend or replaced with incorrect type of battery
may result in a risk of re and explosion or personal injury.
Maximum ambient temperature around the power supply equipment
including charger must not exceed 40℃(104ºF) and device operating
temperature not exceed 55℃(131ºF).
RF Exposure Compliance and Control Guidelines and
Operating Instructions
To control your exposure and ensure compliance with the occupational/
controlled environment
exposure limits always adhere to the following procedures.
Guidelines:
• Do not remove the RF Exposure Label from the device.
• User awareness instructions should accompany device when
transferred to other users.
• Do not use this device if the operational requirements described
herein are not met.
Operating Instructions:
• Transmit no more than the rated duty factor of 50% of the time.

4
To transmit (talk), push the Push-To-Talk (PTT) button. To receive
calls, release the PTT button. Transmitting 50 % of the time, or
less, is important because this radio generates measurable RF
energy exposure only when transmitting (in terms of measuring for
standards compliance).
• Hold the radio in a vertical position in front of face with the
microphone (and the other parts of the radio, including the antenna)
at least one inch (2.5 cm) away from the nose. Keeping the radio at
the proper distance is important because RF exposures decrease with
distance from the antenna. Antenna should be kept away from eyes.
• When worn on the body, always place the radio in approved clip,
holder, holster, case, or body harness for this product. Use of non-
approved accessories may result in exposure levels, which exceed
the occupational/controlled environment RF exposure limits.
• Use only manufacturer’s approved supplied or replacement
antennas, batteries, and accessories. Use of non-manufacturer-
name approved antennas, batteries, and accessories may exceed
the FCC and IC RF exposure guidelines.
• For a list approved accessories please consult your local dealer for
information.
EU Regulatory Conformance
As certied by the qualied laboratory, the product is in compliance
with the essential requirements and other relevant provisions of the
following directives: 2014/53/EU, 2011/65/EU, and 2012/19/EU. Please
note that the above information is applicable to EU countries only.
European Union (EU) Waste of Electrical and Electronic
Equipment (WEEE) directive：
The European Union's WEEE directive requires that products
sold into EU countries must have the crossed out trash bin
label on the product (or the package in some cases). As
dened by the WEEE directive, this cross-out trash bin label
means that customers and end-users in EU countries.
Using Tips Using Tips

5
RF Radiation Information
1. This product is limited to occupational applications that can meet RF
energy radiation requirements. The user must be fully aware of the
RF radiation hazards and can take corresponding measures to meet
the RF radiation limitation requirements.
2. Radio frequency (RF) refers to the electromagnetic frequency that
can be radiated into space. It is a widely used technology in the
elds of communication, medical treatment, and food processing. It
will generate certain RF radiation during use.
EXPOSURE RF compliance et Lignes de
contrôle et Instructions opérationnelles
contrôle et Instructions opérationnelles
Pour contrôler votre exposition et garantir le respect des limites
d'exposition dans un environnement professionnel / contrôlé, suivez
toujours les procédures suivantes.
Des lignes directrices:
• Ne retirez pas l'étiquette d'exposition RF de l'appareil.
• Les instructions de sensibilisation des utilisateurs doivent
accompagner l'appareil lors de leur transfert à d'autres utilisateurs.
• N'utilisez pas cet appareil si les exigences opérationnelles décrites ici
ne sont pas remplies.
Mode d'emploi:
• Ne transmet pas plus que le facteur de marche nominal de 50%
du temps. Pour transmettre (parler), appuyez sur le bouton Push-
To-Talk (PTT). Pour recevoir des appels, relâchez le bouton PTT.
La transmission 50% du temps, ou moins, est importante car cette
radio génère une exposition mesurable à l'énergie RF uniquement
lors de la transmission (en termes de mesure pour la conformité aux
normes).
Using Tips Using Tips

6
• Tenez la radio en position verticale devant le visage avec le microphone
(et les autres parties de la radio, y compris l'antenne) à au moins 2,5
cm du nez. Garder la radio à la bonne distance est important car les
expositions RF diminuent avec la distance de l'antenne. L'antenne doit
être tenue à l'écart des yeux.
• Lorsqu'elle est portée sur le corps, placez toujours la radio dans un clip,
un support, un étui, un étui ou un harnais de sécurité approuvés pour
ce produit. L'utilisation d'accessoires non approuvés peut entraîner des
niveaux d'exposition qui dépassent les limites d'exposition aux RF de
l'environnement professionnel / contrôlé.
Using Tips Using Tips

7
Using Tips Using Tips
Max. SAR Level(s) Reported Limit (W/Kg)
0.85 W/kg 1g Head SAR
1.26 W/kg 1g Body SAR 8.0
INFORMATION CONCERNING SAR FOR FCC

8
Know the Radio
Programmable key
Product Control
Antenna
LED Indicator
PTT key
Up key
Down key
Menu key
Charging Contacts
Speaker
Microphone
Charging Port
Accessory Port
Power key
Display
Know the Radio

9
Know the Radio Know the Radio
Radio LED Indicators
Display Guide
Radio Status
Standby
Low Battery
Transmit (TX)
Receive (RX)
Programming Mode (Read from Radio)
Programming Mode (Write to Radio)
Scanning
Call hang time mode
CTCSS Code icon
Digital mode
Scan icon
VOX icon
Battery Level icon
Channel display
Signal strength
DCS Code icon
Analog mode
Channel indication
Volume icon
LED Indication
Blinking Green
Blinking Red
Solid Red
Solid Green
Fast Blinking Red
Fast Blinking Green
Slow Blinking Orange
Solid Orange

10
熟悉本机
Battery Installation
1. Use nger tip to pull the latch as shown in picture below to remove
battery cover.
2. Put the battery pack into the battery compartment, close the battery
cover with snap t all latches. Ensure the battery cover is fully x to radio.
3. Install the belt clip holder using a coin or screwdriver as shown in the
picture.
Note: To remove the
battery pack, please turn
o󰀨 the radio rst.
Know the Radio
熟悉本机
Know the Radio

11
熟悉本机
Know the Radio
熟悉本机
Belt Clip Installation
1. Align the guide groove of the belt clip to the belt clip holder on the
battery cover and install it appropriately.
Accessory Installation
Step 1: Open the accessory
connector cover.
Step 2: Align the plug of the
accessory (matching headset
or programming cable) with the
accessory connector.
Step 3: Insert the accessory
properly into the accessory
connector.
2.Take out the belt clip to the following angle with belt clip bottom face
up, and remove it toward the top.
Note: The belt clip can
be installed from any
direction, clip on the belt,
and the radio can rotate
180 degrees.
Figure 1 Figure 2
Know the Radio

12
熟悉本机
Charing the Radio
This product allows direct charging and Micro-USB charging with
charger.
The battery meter bar will blinking when the battery is charging. When
fully charged, the battery bar appears full charge.
DEVICE CHARGING USB CHARGING
Charging precautions:
·Please use the matching charging base of the model for charging.
·When charging the device, it is recommended to turn off the radio
rst.
·To obtain the best battery performance, please charge for at least 5
hours for the rst time.
·Do not charge the battery pack for a long time, otherwise it will
shorten the battery pack life. When the battery is fully charged,
please stop charging in time.
·The charger can only be used to charge the battery pack of the
product. Do not use it to charge other battery packs, otherwise the
charger and battery pack may be damaged.
·The battery pack should be stored in a cool and dry place after being
Know the Radio
功能介绍
Know the Radio

13
熟悉本机
Know the Radio
功能介绍
Power On/O󰀨
Press and hold [Power] key to power on the radio. Repeat the step to
power o󰀨 the radio.
Check Channel and
Battery Level status
In standby mode, briey press the power button to check Channel and
battery Level status.
Volume Control
Press [+] to increase the volume. Press [-] to decrease the volume.
Note: When press [+] again under the maximum radio volume, the
speaker of radio will prompt an error sound. When the volume is
adjusted to the minimum by pressing [-] key, the radio is muted.
Transmitting/Receiving
1. To talk, press and hold the [PTT] button. When transmitting, the red
LED indicator is on. Release the PTT button when you are nished
talking. Do not use the radios closer than ve feet apart.
2. When receiving, green LED indicator is on.
fully charged. Do not expose the battery pack near the re or to the
sun, otherwise there are safety risks.
·During charging, it is not recommended to transmit the radio.
·The battery pack may slightly heat up during charging, which is a
normal phenomenon.
Know the Radio

14
功能介绍
Precautions for Radio Operation
·When the radio is transmitting, keep the radio in a vertical position,
and keep the microphone 2.5-5 cm away from the mouth. When transmitting,
the radio should be at least 2.5 cm away from the head or body.
·Do not turn on/o󰀨 the radio repeatedly during use, and adjust the
volume to a level suitable for your hearing.
·Before using the radio for communication, please set the transmitter
and receiver to the same frequency point.
·For the analog channel that requires intercom, please set the
transmitter and receiver to the same sub-audio frequency.
·For digital channel.
1. If encryption is enabled for the digital channel that requires intercom,
please set the transmitter and receiver to the same password.
2. For the digital channel that requires intercom, please set the
transmitter and receiver to the same color code.
Menu Selection
1. The [Menu] key were set to (i) Switch channel, (ii)Turn on/o󰀨
scanning , and (iii) Set high/low power.
2. If the radio is not operated for 3 seconds or [PTT] key is pressed, it
will exit the menu mode.
Channel Selection
In the standby state, press the [Menu] key once to enter the channel
selection menu, and then press the [+] or [-] key to select the channel.
The current channel number will be voice prompted every time you
select. If the radio is not operated for 3 seconds or [PTT] key is
pressed, it will exit the menu mode.
Features
功能介绍
Features

15
功能介绍
Features
功能介绍
Channel Scanning
Press the [Menu] key twice to enter the channel scanning menu, press
the [+] or [-] key to start/stop channel scanning, and the speaker will
give a voice prompt "Scan on" or "Scan o󰀨".During scanning, the digital
radio scans the channels in the list and the current main channel.
When any channel in the scan list is transmitting a signal, it will stay
on that channel after scanning the signal. If press the [+] key again will
skip the current channel and continue scanning. When scanning stop,
if the radio is not operated for 3 seconds or [PTT] key is pressed, it will
exit the menu mode.
Setting High/Low Power
Press the [Menu] key thrice to enter high/low power setting, and press
[+] or [-] key again to switch high/low power. If the radio is not operated
for 3 seconds or [PTT] key is pressed, it will exit the menu mode.
·When transmitting at high power, the screen will display 5 grids of
signal, as shown in gure:
·When transmitting at low power, the screen will display 3 grids of
signal, as shown in gure:
TOT (Time out Timer) Function
In order to prevent some users from occupying the same channel for a
long time, users can set to enable the TOT function. When the user's
continuous transmission time on the current channel reaches the TOT
duration, the radio will stop transmitting and the speaker will give a
time-limit prompt tone. You can set the time out timer via programming
software. By default is 60 seconds. When OFF is selected, user can
transmit continuously.
Features

16
功能介绍
Voice Control Function
1. Preset the [Program] key to [VOX On/O󰀨] key through programming
software.
2. Press the [VOX On/O󰀨] key to turn on/o󰀨 the voice control function.
VOX levels can be preset through programming software: Level 1,
Level 2, and Level 3, where Level 3 is the most sensitive. When the
radio VOX function is on, the preset VOX level is used.
Monitor
Monitor feature is pre programmed on 'Program' button. Press and hold
for 3s to enter monitor mode. Release the button to exit.
Power Saving Function
The power saving function can be enabled/disabled by programming
software.
Low Battery Alert
When the radio rst entered low battery range, the radio chirps
periodically or after releasing the PTT button. When the radio battery
level becomes empty, transmit mode is disabled. Please charge the
radio immediately.
Features
功能介绍
Features

17
功能介绍
Features
功能介绍
Program Button
User can congure program button functions via programming
software. Corresponding features as below:
- None
- Monitor
- High/Low Power
- Emergency Call
- One Touch Call
- VOX On/O󰀨
Setting Privacy Code
User can congure privacy code via programming software. Default is
OFF.
Setting/Changing Frequency
1. In direct mode (DM) mode, you can talk only when the transmitting
frequency and receiving frequency are the same.
2. Digital radio: In DMR relay mode, the transmitting frequency and receiving
frequency are di󰀨erent, but it needs to be used together with repeater.
Squelch Step (SQ)
1. SQ is only valid for analog channels.
2. SQ can be congured through programming software only.
Radio Name Conguration
and Modication
1. Enter the basic setting interface of programming software to
congure or modify the Radio name.
Features

18
功能介绍
2. Radio name can support: Letters, numbers, Chinese, special
characters, etc.
Radio ID
1. The Radio ID is related to the private call contact, and the ID range
is 1-16776415.
2. When using a private call contact to call the other party, enter the
Radio ID of the other party and then call.
Setting new Read/Write password
To further enhance privacy and security, user can congure password
through programming software interface.
1. Set new read/write 8-digits password.
2. To change password, rst input old password, press to conrm in
order to unlock and input new password.
3. To remove password, leave it blank and press conrm.
Digital Encryption
1. Add key through programming software, which only supports basic
encryption, maximum 8 characters.
2. Supported characters include: numbers, uppercase letters,
lowercase letters.
3. The same encryption template must be congured for transmitter
and receiver for normal intercom, otherwise the speech content
cannot be heard clearly.
4. The main purpose is to prevent the content of the speech from
being monitored by other people at the same frequency.
Features
功能介绍
Features

19
功能介绍
Features
功能介绍
Color Code
1. For digital channels, the color code must be same to call.
2. The color code range of this product can be set: 0-15.
Contacts
1. Contacts are only valid for digital channels.
2. There are three kinds of contacts: private call, group call and all call,
which need to be congured through the programming software.
3. Di󰀨erent contacts congured on the same channel cannot
communicate with each other.
Emergency Call
In the event of an emergency, you can use this function to ask your
partners or control center for help. The alarm system works only when
the user has congured the “emergency alarm system” (such as the
number of emergency calls) of the current channel, and the contact of
reply channel of emergency alarm system is group call.
· Operation Method of Emergency in Digital mode
(1) Preset the [Program] button to [Emergency Call] Button through
programming software.
(2) Press and hold the [Emergency Call] Button to enter alarm mode.
(3) When digital channel triggers emergence call, an emergency
call alarm command will be sent. Wait for acknowledge or after
remaining emergency call alarm command cycle to zero, emergency
alarm will be trigger 2 times. After the alarm is stop, you can send
an emergency call through PTT button or press the key to exit the
alarm.
· Operation Method of Emergency in Analog mode
(1) Preset the [Program] button to [Emergency Call] Button through
programming software.
Features
