Cottinch SP6143 User manual

Assembly Instructions
IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep
this manual for future reference.
03.Three-sided Electric Fireplace
Professional fireplace manufacturer
MODEL # SP6143
www.echamphome.com

2
Table of ContentsImportant Safety Instructions
Important Safety Instructions
Assembly
Cleaning and Maintenance
Warranty
Table of Contents
Parts List
Operating Instructions
Troubleshooting Guide
2
6
10
13
2
5
8
12
Warning! To reduce the risk of serious injury, read the following safety instructions before
assembling and operating this fireplace.
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. The equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on. The user is encouraged to try and
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
equipment.
This Class B digital apparatus complies with Canadian ICES-003.

3Model No. SP6143
Important Safety Instructions
electric shock and injury to persons, including the following:
Use this appliance only as described in the manual. Any other use is NOT recommended by the manufacturer
WARNING: This appliance is hot when in use. To avoid burns, DO NOT let bare skin touch hot
surfaces. Keep combustible material, such as furniture, pillows, bedding, papers, clothes and
curtains, at least 3’ (1 m) from the front of the heater and keep them away from the side and rear.
DANGER:
result causing property damage, personal injury or loss of life.
WARNING: Extreme caution is necessary when any heater is used by or near children or
WARNING: DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners, or
WARNING: Do NOT insert or allow foreign objects to enter any ventilation or exhaust opening as
WARNING: This appliance has hot and arcing or sparking parts inside. DO NOT use it in areas
be used as a drying rack for clothing. Christmas stockings or decorations should not be hung in the
area of it.
CAUTION!
If possible, ALWAYS unplug this appliance when not in use.
DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions.
DO NOT operate any heater if it has been dropped or damaged in any manner. Disconnect power at service panel and
have heater inspected by a reputable electrician before reusing.
DO NOT use outdoors.
This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. NEVER place heater where it
may fall into a bathtub or other water container.
To disconnect this appliance, turn controls to the off position, then remove plug from outlet.
ONLY connect to properly grounded outlets.
This appliance, when installed, must be electrically grounded in accordance with local codes, with the current CSA C22.1
Canadian Electrical Code or follow the National Electrical Code, ANSI/NFPA NO.70.
where opening may become blocked.
The heaters MUST NOT be located immediately below a wall outlet/receptacle.
ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an extension cord or re-locatable power tap
(outlet/power strip).

4
Important Safety Instructions
C
A
D
B
Grounding Pin
Grounding Pin
Grounding Means
Adaptor
Metal Screw
Cover of
Grounding Box
SAVE THESE INSTRUCTIONS
Electric Connection
circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow when the heater
exceed the current rating of the current tap. ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with
an extension cord or re-locatable power tap (outlet/power strip).
This heater is for use on a120 V outlet. The cord has a plug as shown below. See illustration for grounding instruction. An
adaptor as shown in Fig. C is available for connecting three-blade grounding type plugs to two-slot receptacles. The
green grounding plug extending from the adaptor must be connected to a permanent ground such as a properly grounded
outlet box. The adaptor should not be used if a three-slot grounded receptacle is available .
Voltage 120 V AC, 60 Hz
Amps 11.7 A
Watts 1400 W
There is a thermostat device provide inside of the unit. If the inner temperature overheats or abnormal heating occurs, the
This heater may include a visual alarm to warn that parts of the heater are getting excessively hot. If the E1 is displayed
on control panel with a beep sound, immediately turn the heater off and inspect for any object on or adjacent to the heater
that may cause high temperatures. DO NOT OPERATE THE HEATER WITH THE ALARM FLASHING.
DO NOT slide insert on top of wood to avoid scratching wood surface.

5Model No. SP6143
Parts List
A
Electric Stove - 1
B
Legs - 4
C
Remote - 1
AA
Screw - 12 + (1)

6
Assembly
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
If you have questions regarding your product, require warranty assistance, or have damaged or
missing parts, please call our customer service toll-free helpline. Contact us for assistance, we’re
here to help .
IMPORTANT: Please read and understand this manual before any assembly. Before beginning assembly of product,
make sure all parts are present. Compare parts with packaging contents list. If any part is missing, or if you have
any questions, contact the service centre at
Place all parts from the box in a cleared area and position them on thefloor in front of you. Remove all packing
materials and place them back into the box. Do not dispose of the packing materials until assembly is complete.
Read each step carefully before beginning any assembly and make sure you understand each step. If you are
missing a part, please call our toll-free number for assistance SER[email protected]
.
Needed for assembly:
Phillips Screwdriver 2 People
Hex Key
[email protected]
[email protected]

7Model No. SP6143
Assembly
Step 1
Requires A, B, AA
Insert the legs B into the holes in the base of the body A . Attach each leg with three screws AA .
Not actual size
AA
AA
B
A

8
Operating Instructions
Power Button
Pressing the power button will turn the unit ON or OFF.
When the unit is in ON mode, the power icon indicator light will glow green.
When the unit is in OFF mode, the power icon indicator light will glow red. If the heater is working when the unit is
powered OFF, the fan will continue to run for another 20 seconds to ensure heat will not be trapped inside the unit.
Note: Each time the unit is plugged in, the fan and heater will turn on for few seconds as a programmed internal check.
Note: Unless the main power is interrupted, the unit will remember the last heating level and flame brightness settings.
Remote Control
Note: This function is only available if using the control panel.
Mode Button
Press the mode button to cycle through the different functions. Each time the mode button is pressed, the mode will
rotate through temperature, timer orflame brightness modes.
Temperature Setting
The temperature mode controls the heater’s thermostat setting.
Press the up arrow button or down arrow button to scroll through the pre-set temperature range from 15 to 30°C (59
to 86°F).
When the ambient temperature is higher than the set temperature, heater will turn off automatically.
Hold the mode button for 3 seconds. This allows the unit to change from °C to °F or °F to °C. The unit default is °F.
Note: The remote control may be used on the unit with the door closed, however for best visibility of the
thermostat and timer settings, adjust on the control panel directly.

9Model No. SP6143
Timer Setting
The timer mode should be used to set the countdown for the unit’s main power.
Press the up arrow button or down arrow button to adjust the timer setting from 0 hour (OFF) to 9 hours with
30 minute intervals.
Flame Brightness Setting
The flame brightness mode is used to set the flame brightness.
Use the up arrow button or down arrow button to scroll through the flame brightness settings: F0 (flame off, lowest
brightness of ember bed), F1, F2, F3, F4, F5 (brightest).
Up Arrow Button
Use up arrow button to increase the setting of the selected function.
Down Arrow Button
Use down arrow button to decrease the setting of the selected function.
Operating Instructions
Child Lock
Activate Child Lock
When the unit is ON, hold the POWER button for 10 seconds to activate the child lock function. E3 will be displayed
and the unit will beep 3 times indicating that the child lock function is activated. All function keys are locked. When
any button is pressed, E3 will show on the display indicating that the child lock function is activated.
Deactivate Child Lock
To deactivate the child lock function, hold the POWER button for 10 seconds.
Note: The child lock function is only available if using the control panel.

10
Make sure the unit is turned OFF, unplugged and the heating elements of heater are cool whenever you are cleaning
the heater.
Clean the metal trim using a water-dampened soft, clean cloth. DO NOT use brass polish or household cleaners as
these products will damage the metal trim.
The motors used on the fan and the ame generator assembly are pre-lubricated for extended bearing life and
require no further lubrication. However, periodic cleaning/vacuuming of the fan/heater and air intake/ output vents is
recommended.
Any other servicing should be performed by an authorized service representative.
When the heater is not in use, the heater should be stored in a dry location, away from possible damage. The power
cord should be stored properly to avoid contact with hot or sharp objects.
Cleaning and Maintenance
Warning! Make sure the power is turned off before proceeding. Any electrical repairs
or rewiring of this unit should be carried out by a licensed electrician in accordance with
national and local codes. If repairing or replacing any electrical component or wiring, the
original wire routing, colour coding and securing locations must be followed.
Warning! Do not use this fireplace if any part of it has been under water. Immediately call
a qualified service technician to inspect the fireplace and replace any part of the electrical
system.
Warning! During any service of this appliance, the power to the unit must be turned off.
First turn the main power switch to the “OFF” position. Then remove the electrical plug from
the wall outlet.
Warning! Electrical outlet wiring must comply with local building codes and other
applicable regulations to reduce the risk of fire, electric shock and injury to persons.
Warning! Disconnect power before attempting any maintenance or cleaning to reduce the
risk of fire, electric shock or personal injury.

11 Model No. SP6143
Note: The battery should be removed if the product is to be left unused for a long time.
Disposal of Used Battery
A battery may contain hazardous substances that could be dangerous to the environment and human
health.
This symbol marked on the battery and/or packaging indicates that the used battery shall not be treated
as municipal waste. Instead it shall be left at the appropriate collection point for recycling.
By ensuring the used battery is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health. The recycling of materials will help to conserve
natural resources.
For more information about collection and recycling of used batteries, please contact your local
municipality, your waste disposal service or the point of sale where you purchased this item.
Cleaning and Maintenance
Caution!
Non-rechargeable batteries must not be recharged. Exhausted battery is to be removed from
the product.
Replacing the Remote Control Battery
When the remote control stops operating or its range seems reduced, it is time to replace the battery.
Step 1
The battery compartment is located on the back end of the remote control.
Step 2
Press the small tab inward as you slide the battery door open and remove the exhausted battery.
Step 3
Insert a new CR2025 lithium battery (not included), ensuring the polarities of the battery match the inside of
the battery compartment.
Step 4
Re-insert the battery door.

12
Troubleshooting Guide
PROBLEM POSSIBLE CAUSE SOLUTION
No power. Logs
do not glow.
The unit does not have
power.
Check that unit is plugged into a standard 120 V
outlet. Then make sure power is set at “ON” position.
E1 displayed on
control panel with
beep sound.
The overheat sensor has
been engaged.
Unplug unit, wait 5-10 minutes, then the sensor will
reset itself. Plug the unit back in and turn on the
heater. If the problem persists, call customer service.
E2 displayed on
control panel.
The ambient temperature
sensor is broken or not
working correctly.
Unplug unit, wait 5-10 minutes, then the sensor will
reset itself. Plug the unit back in and turn on the
heater. If the problem persists, call customer service.
E3 displayed on
control panel.
Child lock function is
active.
To inactivate the child lock function, holding the
POWER button for 10 seconds.
Fan motor
continues to
blow after unit is
powered off.
Normal operation.
This is a standard feature; the blower runs for an
additional 20 seconds to ensure heat will not be
trapped inside the unit.
Power cord gets
warm to the
touch.
Normal operation.
This is normal for a heater appliance as it requires
more current to operate. Check the connections of
the appliance cord and the outlet. Make sure the
plug ts tightly into the outlet. During use, check the
plug and outlet frequently to determine if it is HOT;
if so, discontinue use of the appliance and consult
with a quali ed electrician to check or change the
overheating outlet(s).

13 Model No. SP6143
Warranty
This product carries a one (1) year warranty against defects in workmanship and materials.
We agrees to replace the defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear
or breakage due to misuse and/or abuse.
www.echamphome.com
