Country Clipper jazee SR210 User manual

Safety Instructions & Operators Manual
®
Zero Turn Radius Mower
™
™
Congratulations for buying a Country Clipper product. our Country Clipper Zero Turning Radius
Riding Mower was designed and built to provide long and trouble free service. Keep in mind that it, like
any other mechanical device, can be potentially dangerous if used improperly, and hazard control and
accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the equipment. Study this
manual and pay special attention to the important Safety Precautions on pages 4-6. Following these
instructions will help you continue to enjoy the trouble-free performance expected of the Country Clipper
product.
P-12485 (8/08)

2
TABLE OF CONTENTS
SAFETY ......................................................................................................................................... 3
ACCIDENT PATTERNS TO AVOID ...............................................................................................................3
SAFETY INSTRUCTIONS AND RECOMMENDATIONS ...........................................................................3
SAFETY INTERLOCK SYSTEM .....................................................................................................................5
START UP AND OPERATION .................................................................................................... 6
CHECKLIST BEFORE OPERATION .............................................................................................................6
CONTROL LOCATIONS JOYSTICK MODELS...........................................................................................6
OPERATION JOYSTICK MODELS...............................................................................................................7
CONTROL LOCATIONS TWINSTICK MODELS ........................................................................................8
OPERATION TWINSTICK MODELS............................................................................................................8
MOWING RECOMMENDATIONS ...............................................................................................................10
MAINTENANCE ......................................................................................................................... 11
MAINTENANCE SCHEDULE ........................................................................................................................11
MAINTENANCE INSTRUCTIONS................................................................................................................12
PROCEDURE FOR RAISING AND LOWERING THE DECK FOR SERVICING .................................17
LEVELING THE DECK ..................................................................................................................................19
ADJUSTING THE LATCH PLATE................................................................................................................20
TROUBLE SHOOTING CHECK LIST ..................................................................................... 21
BELT ROUTINGS....................................................................................................................... 23
WIRING SCHEMATIC FOR BRIGGS JOYSTICK (E-64 5) ................................................. 24
WIRING SCHEMATIC FOR KOHLER JOYSTICK (E-6415) ................................................ 25
WIRING SCHEMATIC FOR BRIGGS JOYSTICK (E-6415 PLUS E-6417 ADAPTER)……26
WIRING SCHEMATIC FOR KOHLER TWINSTICK (E-6416) ............................................. 27
WIRING SCHEMATIC FOR KAWASAKI TWINSTICK (E-6416 PLUS E-6417 ADAP). .... 28
WIRING SCHEMATIC FOR BRIGGS TWINSTICK (E-6416 PLUS E-6436
ADAPTER).…29
NOTES / SERVICE RECORDS: ................................................................................................ 3

3
SAFETY
ACCIDENT PATTERNS TO AVOID
I. CONTACT WITH THE ROTATING
BLADE -- This accident usually happens
when the operator is clearing the
discharge chute of grass, (especially
when the grass is wet), or when the
operator adjusts the machine without
turning it off and waiting for the blades to
completely stop.
II. PROPELLED OBJECTS -- Sticks,
rocks, wires, and other objects can be
propelled out through the discharge
chute or from under the mower housing.
Bystanders are particularly vulnerable.
III. GRASS CATCHER OR GUARD -- The
mower shall not be operated without
either the entire grass catcher or guard
in place.
IV. OVERTURNING -- This happens when
riding mowers are used on steep slopes,
embankments or hills. The operator in
these cases can come in contact with
the blades or sustain injuries during a
fall.
V. MOWER RUNNING OVER THE VICTIM
-- This usually happens when a riding
mower is driven in reverse. The
accident victims are most often young
children whom, unseen by the operator
of the mower, were in the area being
mowed.
AT COUNTRY CLIPPER, WE SHARE OUR
DESIRE TO PROTECT OURSELF, OUR
FAMIL , OUR FRIENDS AND OUR
NEIGHBORS FROM ACCIDENTAL INJUR .
OBSERVING AND ENFORCING THE
FOLLOWING GUIDELINES WILL HELP TO
INSURE THE SAFET OF EVER ONE.
PLEASE BE CAREFUL!
SAFETY INSTRUCTIONS AND
RECOMMENDATIONS
1. PEOPLE WHO OPERATE SERVICE
OR ARE OTHERWISE ASSOCIATED
with the Country Clipper Zero Turning
Radius Mower should be trained in its
proper use and warned of its dangers.
Before operating, adjusting, or servicing
the Country Clipper Zero Turning
Radius Mower they should read and
understand this entire manual and the
engine owner’s manual.
2. AVOID CONTACT WITH MOVING
PARTS. Keep hands and feet from
under mowing deck and away from
blades at all times. Turn engine (motor)
off if you must unclog the chute.
3. AVOID HILLS AND SLOPES. Use
extreme caution when mowing up or
down slopes. NEVER mow across the
face of a slope. If a slope must be
ascended, back up the slope; drive
forward when descending. Reduce
speed and use caution to start, stop and
maneuver. To prevent loss of control on
a slope avoid sharp turns, sudden
changes in direction, and sudden stops
and starts.
4. DISENGAGE POWER TO MOWER
BEFORE BACKING UP. Do not mow in
reverse unless ABSOLUTEL
necessary and then only after turning
around and observing the entire area
behind the mower. Go slowly. Most
“running over victim” accidents occur in
reverse.
5. BEGINNING OPERATORS SHOULD
LEARN HOW TO STEER the Country
Clipper Zero Turning Radius Mower
before attempting to mow. Start with
slow engine speed and drive without the
blades engaged in an open area until
comfortable with the machine.
6. KNOW HOW TO STOP QUICKLY.
Know the location and operation of every
control, especially how to brake and how
to disengage the mower blades.

4
7. DO NOT MOVE CONTROL LEVER(S)
from forward position to reverse position
rapidly. The speed and/or direction of
travel is affected instantly by movement
of the Control Lever(s).
8. DO NOT ALLOW CHILDREN TO
OPERATE MOWER. Do not allow
others who have not had instruction to
operate mower.
9. ALWAYS TURN ENGINE OFF AND
REMOVE KEY before leaving the
mower to prevent children and
inexperienced operators from starting
the engine. Never leave the mower
unattended with engine running. Always
wait for all moving parts and all sounds
to stop before leaving operator’s seat.
10. WEAR STURDY ROUGH-SOLED
WORK SHOES AND CLOSE-FITTING
SLACKS AND SHIRTS. Never operate
mower in bare feet, sandals or
sneakers.
11. KNOW THE AREA YOU ARE TO
MOW. Watch for hidden danger such
as rocks, roots, sticks, holes, bumps,
and drop-offs, etc. Before mowing, pick
up all debris in area to be mowed.
Sharp and hard objects can be propelled
at a high speed and can act like
shrapnel. Walk through tall grass
BEFORE MOWING to make sure there
are no hidden dangers. Mow higher
than desired in tall grass to expose any
hidden objects and/or obstacles, clean
the area, and then mow to the desired
height.
12. NEVER REFUEL A MOWER
INDOORS. Allow the engine time to
cool before refueling. Unseen vapors
may be ignited by a spark. Always clean
up spilled gasoline. Never run the
engine indoors in a garage or any other
closed building. Allow engine to cool
before storing in any enclosure. The
engine exhaust and gasoline fumes are
dangerous.
13. DISENGAGE BLADES BEFORE
DRIVING ACROSS WALKS or
projecting objects.
14. NEVER REMOVE THE FUEL CAP or
add gasoline to a running or hot engine
that has not been allowed to cool for
several minutes after running. Always
make sure the gas cap is in place.
15. NEVER CARRY PASSENGERS.
16. DO NOT SMOKE AROUND THE
MOWER or the gasoline storage
container. Gasoline fumes can easily
ignite.
17. KEEP GASOLINE IN A WELL-
VENTILATED AREA away from your
living quarters and in tightly-capped
safety cans. Never store mower with
gasoline in the tank inside a building
where fumes may reach open flame or
spark.
18. DISENGAGE BLADES STOP ENGINE
AND REMOVE IGNITION KEY before
any servicing. Be sure all moving parts
and all sounds have stopped. Let
engine cool and disconnect the spark
plugs so the engine cannot start by
accident. A SLIGHT ROTATION OF
THE BLADES COULD START THE
ENGINE.
19. KEEP ALL NUTS BOLTS AND
SCREWS TIGHT to be sure equipment
is in safe working condition, especially
blade mounting bolts.
20. VEHICLE SHOULD BE STOPPED AND
INSPECTED FOR DAMAGE after
striking a foreign object and the damage
should be repaired before restarting and
operating the equipment. Stop
immediately and check for damage or
loose parts if mower should start
vibrating.
21 KEEP SAFETY DEVICES AND
GUARDS IN PLACE. If any of the
safety switches become inoperable,
have them repaired immediately.
22. DO NOT STEP OR STAND ON THE
MOWER HOUSING. Step or stand only
on the foot deck.
23. WATCH OUT FOR TRAFFIC near
roadways and when crossing roads.
24. DO NOT USE MOWER WHEN GRASS
IS WET OR SLIPPERY.
25. MOW ONLY DURING DAYLIGHT.

5
26. THIS MACHINE IS NOT MEANT FOR
HIGHWAY OR STREET USE. It is not a
recreational vehicle and it should not be
operated as such.
27. ALWAYS DISENGAGE THE MOWER
BLADE CLUTCH when transporting.
28. KEEP ALL SAFETY LABELS IN
LEGIBLE CONDITION. Remove
grease, dirt, grass, etc. that may cover
safety labels. Replace any safety label
that is missing or damaged.
29. WEAR PERSONAL PROTECTIVE
EQUIPMENT. Eye, ear, feet and head
protection is recommended.
30. ONLY USE COUNTRY CLIPPER
APPROVED ACCESSORIES.
31. DO NOT CHANGE THE ENGINE
GOVERNOR SETTING or over speed
the engine.
32. BEWARE OF MOWER DISCHARGE
DIRECTION and do not point it at
anyone.
33. DO NOT OPERATE THE MOWER
UNDER THE INFLUENCE OF
ALCOHOL OR DRUGS.
34. USE CARE WHEN LOADIING OR
UNLOADING MACHINE INTO A
TRAILER OR TRUCK.
35. USE CARE WHEN APPROACHING
BLIND CORNERS shrubs, trees, or
other objects that may obscure vision.
36. CLEAN ALL GRASS AND DEBRIS
FROM MACHINE TO PREVENT
FIRES. Remove spilled oil or gasoline.
37. KEEP HANDS AND FEET AWAY
FROM MOVING PARTS. If possible do
not make adjustments with the engine
running.
38. NEVER MOW WHEN OTHER PEOPLE
OR PETS ARE IN THE AREA.
39. CAREFULLY RELEASE PRESSURE
FROM COMPONENTS WITH STORED
ENERGY.
40. USE CARE WHEN REPLACING
BLADES. Wrap the blade(s) or wear
gloves, and use caution when servicing
them. Only replace blade(s). Never
straighten or weld blade(s).
41. USE JACKSTANDS TO SUPPORT
COMPONENTS when required.
SAFETY INTERLOCK SYSTEM
our Country Clipper Zero Turning Radius
Mower is equipped with switches interlocked for
your safety.
ON JOYSTICK MODELS GROUND DRIVE
NEUTRAL IS WHEN THE JO STICK (CONTROL
LEVER) IS IN THE “DOWN” POSITION.
ON TWINSTICK MODELS GROUND DRIVE
NEUTRAL IS WHEN BOTH CONTROL LEVERS
ARE IN THE “OUT” POSITION.
1. The mower blades must be disengaged
before engine will start.
2. The Control Lever(s) must be in the
neutral position before the engine will
start.
3. The engine will stop if the mower blade
clutch is engaged when the operator
leaves the driver’s seat.
4. The engine will stop if the Control
Lever(s) are not in the neutral position
when the operator leaves the driver’s
seat.
5. The engine will stop if the brake is
“SET” and the Control Lever(s) are not
in the neutral position.
6. The engine will stop if the brake is “SET”
and the mower blade clutch is engaged.
DO NOT OPERATE MOWER IF SAFETY
SWITCHES AND GUARDS ARE NOT
OPERATING PROPERLY

6
START UP AND OPERATION
CHECKLIST BEFORE OPERATION
1. Make sure fuel tank is full. Use regular
unleaded gasoline (see engine owner’s
manual for more details).
WARNING
HANDLE GASOLINE WITH CARE -- IT IS
HIGHLY FLAMMABLE. DO NOT SMOKE.
ENGINE SHOULD BE OFF AND COOL. USE
APPROVED GAS CONTAINER. NEVER FILL
TANK INDOORS. WIPE UP ANY SPILLS.
REPLACE CAP TIGHTLY.
2. Make sure dirt and foreign matter is kept
out of gas tank. Use a clean funnel and
gas can.
3. Do not mix oil with gasoline.
4. Do not use white, high test or premium
gasoline. Do not use de-icers,
carburetor cleaners, or other such
additives.
5. Check the crankcase oil level. Make
sure the engine is off. The mower
should be parked on a level area. Do
not overfill. (See your engine manual for
more detailed instruction.)
6. Check battery fluid level.
7. Inspect V-belts.
8. Check tire pressure:
9. Make sure underside of mower deck is
free of grass.
10. Make sure mower blades are sharp and
secured tightly.
11. Clean the air intake screen on the
engine if necessary.
12. Perform any other maintenance as it
becomes necessary. (See the
“Maintenance” section of this manual.)
IMPORTANT: Before cutting grass, clutch must
be broken-in as follows: With engine at
full RPM engage deck until blades come
to full speed and then disengage until
blades come to a complete stop.
Repeat 10 times to “break-in” the clutch
properly.
CONTROL LOCATIONS
JOYSTICK MODELS
Joystick Control
Lever
Blade Clutch Switch
Ignition Key
Choke Throttle
Cut Height Stop
Pin
Parking Brake Lever
Cut Height
Adjustment Lever
Cut Height Foot
Assist Lever

7
WARNING
AVOID INHALING EXHAUST FUMES --
CARBON MONOXIDE GAS IS COLORLESS
AND ODORLESS AND CAN CAUSE
UNCONSCIOUSNESS AND IS POTENTIALLY
LETHAL. DO NOT RUN LAWN MOWER IN
GARAGE OR OTHER CONFINED AREA.
OPERATION
JOYSTICK MODELS
1. MOVE JO STICK CONTROL LEVER to
neutral “DOWN” position.
2. SET PARKING BRAKE. Pull up to set.
3. DISENGAGE MOWER BLADE
CLUTCH by moving clutch switch to
“OFF” position.
4. PULL ENGINE CHOKE CONTROL to
full position for cold starts.
5. SET ENGINE THROTTLE TO 1/2
THROTTLE.
6. TURN IGNITION KE to “START”
position and release to “RUN” as soon
as engine starts. NOTE: Prolonged
cranking will damage starter motor and
shorten the battery life
7. ADJUST ENGINE THROTTLE AND
CHOKE for desired engine smoothness
and speed. NOTE: When mowing,
always run engine at full throttle.
8. RELEASE PARKING BRAKE. Push
brake lever down to release.
IMPORTANT: Until the operator is familiar with
the Country Clipper Zero Turning
Radius Mower, he/she should follow
these recommendations: Disengage the
mower blades. Go very slowly until
thoroughly familiar with the machine.
Keep away from fences, buildings, and
other obstructions. Move the Joystick
Control Lever smoothly and slowly.
Practice until operation is smooth and
efficient.
9. TO DRIVE:
A. Move the Joystick Control Lever to the
“UP” position.
B. Move the Joystick Control Lever
forward to move forward. Increasing
forward movement of the Joystick
Control Lever will increase the speed
of travel.
C. To reverse the direction, pull the
Joystick Control Lever slightly back.
D. To turn, move the Joystick Control
Lever toward the direction you want to
turn.
E. To turn on a zero radius axis, go
slowly and move the Joystick Control
Lever to the side you wish to turn and
slightly to the rear at the same time.
CAUTION
FOR SMOOTH SAFE OPERATION MOVE
THE JOYSTICK CONTROL LEVER IN A
GENTLE SLOW MOTION. NEVER PULL OR
PUSH THE JOYSTICK CONTROL LEVER
RAPIDLY ESPECIALLY ON GRADES.
10. BRAKING: To brake mower, gently
move the Joystick Control Lever in the
direction opposite to travel. If the
parking brake is engaged with the
Joystick Control Lever in the “UP”
position the engine will stop.
11. CUTTING HEIGHT ADJUSTMENT: With
the Cut Height Adjustment Lever latched
into the top cut height latch. Insert Cut
Height Stop Pin to desired cutting height.
Pull Cut Height Adjustment Lever
rearward and then to the left to clear top
cut height latch. Lower Cut Height
Adjustment Lever until it rests on Cut
Height Stop Pin. NOTE: Pushing on the
Cut Height Foot Assist Lever will make
the Cut Height Adjustment Lever easier
to operate.
12. ENGAGE MOWER BLADE CLUTCH: Set
the Blade Clutch Switch to the “ON”
position. The engine will not start if the
blade clutch is engaged. If the operator is
not in the seat, the engine will stop if the
clutch is engaged

8
Cut Height Foot
Assist Lever
Parking Brake
Lever
CAUTION
AVOID HILL AND SLOPES. USE EXTREME
CAUTION WHEN MOWING UP OR DOWN
SLOPES. NEVER MOW ACROSS THE FACE
OF A SLOPE. IF A SLOPE MUST BE
ASCENDED BACK UP THE SLOPE; DRIVE
FORWARD WHEN DESCENDING.
13. TO STOP:
A. Move Joystick Control Lever to neutral
position and then to the “DOWN”
position.
B. Disengage the mower blade clutch by
moving the clutch to the “OFF”
position.
C. Set the parking brake.
D. Slow engine speed with throttle to
slowest position.
E. Turn ignition key to “OFF” position.
F. Remove the key and wait for all
movement and all sound to cease
before dismounting.
G.
CONTROL LOCATIONS
TWINSTICK MODELS
WARNING
AVOID INHALING EXHAUST FUMES --
CARBON MONOXIDE GAS IS COLORLESS
AND ODORLESS AND CAN CAUSE
UNCONSCIOUSNESS AND IS POTENTIALLY
LETHAL. DO NOT RUN LAWN MOWER IN
GARAGE OR OTHER CONFINED AREA.
OPERATION
TWINSTICK MODELS
1. MOVE STEERING CONTROL LEVERS TO
neutral “OUT” position.
2. SET PARKING BRAKE. Pull up to set.
3. DISENGAGE MOWER BLADE CLUTCH by
moving clutch switch to “OFF” position.
4. PULL ENGINE CHOKE CONTROL to full
position for cold starts.
5. SET ENGINE THROTTLE TO 1/2
THROTTLE.
6. TURN IGNITION KE to “START” position
and release to “RUN” as soon as engine
starts. NOTE: Prolonged cranking will
damage starter motor and shorten the
battery life.
7. ADJUST ENGINE THROTTLE AND CHOKE
for desired engine smoothness and speed.
Right Hand Steering
Control Lever
Blade Clutch Switch
Ignition Key
Choke
Throttle
Cut Height
Adjustment Lever
Cut Height Stop
Pin
Left Hand Steering
Control Lever

9
NOTE: When mowing, always run engine at
full throttle.
8. RELEASE PARKING BRAKE. Push brake
lever down to release.
IMPORTANT: Until the operator is familiar with
the Zero Turning Radius Mower, he/she
should follow these recommendations.
Disengage the mower blades. Go very
slowly until thoroughly familiar with the
machine. Keep away from fences,
buildings, and other obstructions. Move
the Steering Control Levers smoothly
and slowly. Practice until operation is
smooth and efficient.
9. TO DRIVE:
A. Move the Steering Control Levers to the
“IN” position.
B. Move the Steering Control Levers
forward to move forward. Increasing
forward movement of the Steering
Control Levers will increase the speed of
travel.
C. To reverse the direction, pull the
Steering Control Levers slightly back.
D. To turn, move one Steering Control
Lever slightly ahead of the other.
E. To turn on a zero radius axis, go slowly
and move one Steering Control Lever
forward and one Steering Control Lever
rearward. (For a right hand turn the left
hand Steering Control Lever will be
ahead of the right hand Steering Control.
For a left hand turn the right hand
Steering control will be ahead of the left
hand Steering Control.)
CAUTION
FOR SMOOTH SAFE OPERATION MOVE
THE STEERING CONTROL LEVER(S) IN A
GENTLE SLOW MOTION. NEVER PULL OR
PUSH THE STEERING CONTROL LEVER(S)
RAPIDLY ESPECIALLY ON GRADES.
10. BRAKING: To brake mower, gently move
the Steering Control Levers in the direction
opposite to travel. If the parking brake is
engaged with the Steering Control Lever(s)
in the “IN” position the engine will stop.
11. CUTTING HEIGHT ADJUSTMENT: With the
Cut Height Adjustment Lever latched into the
top cut height latch. Insert Cut Height Stop
Pin to desired cutting height. Pull Cut Height
Adjustment Lever rearward and then to the
left to clear top cut height latch. Lower Cut
Height Adjustment Lever until it rests on Cut
Height Stop Pin. NOTE: Pushing on the Cut
Height Foot Assist Lever will make the Cut
Height Adjustment Lever easier to operate.
12. ENGAGE MOWER BLADE CLUTCH: Set
the Blade Clutch Switch to the “ON” position.
The engine will not start if the blade clutch is
engaged. If the operator is not in the seat,
the engine will stop if the clutch is engaged.
CAUTION
AVOID HILL AND SLOPES. USE EXTREME
CAUTION WHEN MOWING UP OR DOWN
SLOPES. NEVER MOW ACROSS THE FACE
OF A SLOPE. IF A SLOPE MUST BE
ASCENDED BACK UP THE SLOPE; DRIVE
FORWARD WHEN DESCENDING.
13. TO STOP:
A. Move Steering Control Levers to neutral
position and then to the “OUT” position.
B. Disengage the mower blade clutch by
moving the clutch to the “OFF” position.
C. Set the parking brake.
D. Slow engine speed with throttle to
slowest position.
E. Turn ignition key to “OFF” position.
F. Remove the key and wait for all
movement and all sound to cease
before dismounting.
CAUTION
WHEN LEAVING THE MOWER
UNATTENDED ALWAYS REMOVE THE KEY
AND SET THE PARKING BRAKE EVEN IF
JUST FOR A FEW MOMENTS. HELP
PROTECT CHILDREN AND OTHER
UNAUTHORIZED PERSONS FROM
ACCIDENTS.

10
14. TO FREE WHEEL MACHINE: UNLOCK
TRANSMISSION: Pull the Transmission
Release Chains out away from the
Hydrostatic Drive Axle and then down
into the retaining slot (each side must
individually be pulled out and down into
the retaining slot). To re-engage the
transmissions push the Transmission
Release Chains out of the retaining slot.
On Jazee mowers the Transmission
Release Chains are located on the front
side of the Hydrostatic Drive Axles and
below the Engine Mounting Plate. On
Jazee Pro mowers the Transmission
Release Chains are located on the rear
side of the Hydrostatic Drive Axles and
below the Engine Mounting Plate.
NOTE: The tractor should never be pulled at
more than 2 miles per hour or for any
appreciable distance.
MOWING RECOMMENDATIONS
1. Keep mower blades sharp.
2. Make sure deck and discharge are
clean.
CAUTION
POWER MUST BE OFF TO CLEAN
DISCHARGE CHUTE. TURN ENGINE OFF
AND WAIT FOR ALL MOVING PARTS TO
STOP.
3. When mowing tall grass, make two
passes, mowing off 1/2 of the desired
cut on the first pass, and then the
desired height the second pass. Check
for hidden dangers first.
4. Go slowly for trimming.
5. Always cut grass with the engine at full
throttle speed. This “ENGINE” speed
allows the cutting blades to operate at
optimum cutting speed. Control
“GROUND” speed with the Control
Lever(s).
6. Vary ground speed to suit conditions (i.e.
go slower in tall thick grass, on hills, wet
conditions, etc.).
Transmission
Release Chain
Retaining Slot

11
MAINTENANCE
CAUTION
BEFORE PERFORMING ANY MAINTENANCE TURN OFF ENGINE
REMOVE KEY AND DISCONNECT SPARK PLUGS. USE EXTREME CARE WHEN WORKING ON
MACHINERY. DO NOT WEAR WATCHES OR JEWELRY. DO NOT WEAR LOOSE FITTING
CLOTHES AND OBSERVE ALL COMMON SAFETY PRACTICES WITH TOOLS.
MAINTENANCE SCHEDULE
SERVICE WHEN
Check crankcase oil level --------------------------------------------------------------------- before each use
Clean grass from Hydrostatic Transmission fins and cooling fans ------------------ before each use
Check air intake screen --------------------------------------------------------------------------- after each use
Clean grass under deck -------------------------------------------------------------------------- after each use
Check tire pressure ------------------------------------------------------------------------------- every 10 hours
Check battery fluid -------------------------------------------------------------------------------- every 10 hours
Sharpen mower blades -------------------------------------------------------------------------- every 10 hours
Clean air filter pre-cleaner element ----------------------------------------------------------- every 25 hours
Check drive belts ---------------------------------------------------------------------------------- every 50 hours
(20 hours break-in)
Service Air Cleaner Filter Element ---------------------------------------------------------- every 100 hours
Change engine crankcase oil ------------------------------------------------------------------------- 100 hours
oil filter -------------------------------------------------------------------------- 200 hours
Change Hydrostatic Transmission crankcase oil ------------------------------------------------- 200 hours
oil filter --------------------------------Clean every 200 hours (replace if damaged)
Replace air filter element --------------------------------------------------------------- annually or 500 hours
Check spark plugs ------------------------------------------------------------------------ annually or 500 hours
Service battery ---------------------------------------------------------------------------- annually or 500 hours
--------------------------------------------------------------------------------------------------------------------------------
Replace decals when illegible. Write factory for free replacement.

12
MAINTENANCE INSTRUCTIONS
1. ENGINE:
For complete maintenance and
operating information for your engine,
please refer to your engine operating
and maintenance instructions furnished
by the engine manufacturer and
included in your Country Clipper Zero
Turning Radius Mower information
packet.
NOTE: Air intake screen must be kept
clean. If plugged, engine may be
seriously damaged by over heating.
2. BATTERY:
CAUTION
BATTERY ELECTROLYTE IS A POISONOUS
AND CORROSIVE SULFURIC ACID
SOLUTION. AVOID SPILLING ON SKIN
EYES AND CLOTHING.
Keep the electrolyte level above the
plates in each cell by adding distilled
water as it becomes necessary. Add
water just before operating the mower to
mix the water with the solution. Be
careful not to overfill the battery -- the
electrolyte solution is corrosive and can
cause damage to surrounding metal
parts if it should spill. When taking the
battery out of the mower for servicing,
make sure to connect the cables to the
battery exactly as they were prior to
removal. Always disconnect the ground
( - ) wire first and always reconnect the
ground ( - ) wire last.
Keep the battery clean. Remove the
corrosion around the battery terminals
by applying a solution of one part baking
soda to four parts water. Coat all
exposed terminal surfaces with a light
layer of grease or petroleum jelly to
prevent corrosion.
NOTE: At temperatures below 32 degrees F (0
degrees C) the full charge state must be
maintained to prevent cell electrolyte
from freezing and causing permanent
battery damage.
3. TIRES:
Correct tire pressure is essential for
efficient operation of the mower. Check
tire pressure as requested in the
maintenance schedule. Inflate tires to
the pressures listed below:
Lug nuts should be torqued to 75 ft/lbs
and checked regularly for tightness.
4. MOWER BLADES:
Check sharpness of mower blades after
every 10 hours of operation. To sharpen
blades proceed as follows:
CAUTION
STOP ENGINE REMOVE IGNITION KEY AND
SPARK PLUGS FOR SAFETY.
A. Remove bolt, lock washer, and cup
washer mounting blade on shaft.
Remove blade.
B. Blades should be discarded when worn
excessively.
C. Sharpen blades with a hand file, electric
grinder or blade sharpener. Wear
gloves and eye protection when
sharpening. Grind blade at original 25
degree bevel.
D. Check balance of blade by positioning
the blade on a nail or blade balance
pedestal. Grind the blade on the end
that is heavier until both sides balance.
E. Install blade, cup washer, lock washer,
and bolt. Make sure to tighten bolt to 60
ft-lbs.
Model Front tires Rear tires
All
Models
12 psi 12 psi
New Blade
25 degrees When notch
starts discard
blade
DANGEROUS!
DO NOT USE
BLADE IN THIS
CONDITION

13
5. V-BELTS:
All belts should be checked every 50
hours. Replace any belts found to be in
poor condition. All belts are equipped
with spring loaded belt tighteners and do
not require tightening adjustments.
6. LUBRICATION:
A. Engine: Follow engine manufacturer’s
recommendation.
B. Deck Spindles: Lubricate with 3 “shots”
only, every 100 hours.
7. PARKING BRAKE ADJUSTMENT FOR
JAZEE (SR210) MOWERS:
A. Move Parking Brake Lever to the “OFF”
position.
B. Tighten the Brake Adjustment Nut until
the Brake Adjustment Spring just begins
to collapse on the Brake Linkage
Assembly.
C. Repeat for the other side
NOTE: With the Brake Lever in the
“OFF” position the teeth of the brake
disk mechanism should not be engaged.
8. PARKING BRAKE ADJUSTMENT FOR
JAZEE PRO (SR360) MOWERS
A. Move Parking Brake Lever to the “OFF”
position.
B. Adjust the top 2 Adjustment Nuts down
or up so that the Brake Rod Arm is fully
extended downward.
C. Move Parking Brake Lever to the “ON”
position.
D. Adjust the Bottom Adjustment Nut so
that the compression spring is
compressed to 5/8”.
E. Repeat for the other side
Brake Linkage Assembly
Brake Adjustment Nut Brake Adjustment
Spring
Brake Linkage
Assembly
Brake Rod Arm
Top Brake
Adjustment Nuts
Bottom Brake
Adjustment Nut

14
JOYSTICK CONTROL LEVER
NEUTRAL ADJUSTMENT:
With the engine running, if the machine
travels in either direction when the
Joystick Control Lever is in the neutral
“DOWN” position, stop the engine,
elevate the rear wheels clear of the
ground and adjust as follows:
A. Remove the right hand fender skirt
exposing the Joystick Control Lever
Assembly.
B. Start the engine.
C. Run engine at fast idle with Joystick
Control Lever in the “DOWN” position.
D. Loosen the locknuts tightened against
the rod end ball joints on the Upper
Linkage Rod Assembly that corresponds
to the wheel that is turning. Note: One of
these is a left hand nut and will have to
be turned backwards.
E. Adjust the Neutral Position by turning the
rod in the Upper Linkage Rod Assembly
until the wheel stops turning.
F. Retighten the locknuts on Upper Linkage
Rod Assembly and check to make sure
the drive wheel is still not turning.
G. Repeat steps B through F for other side.
H. Shut off engine before removing from
blocks. Replace fender skirt.
11. JOYSTICK CONTROL LEVER
SENSITIVITY ADJUSTMENT
To change the sideways turning
response adjust as follows:
A. Remove the right hand fender skirt
exposing the Joystick Control Lever
assembly.
B. Remove the cross bolt, nut, and
spacers
C. Reassemble the spacers as desired.
(2) spacers between the rod end ball
joints and the joystick pivot shaft will
quicken the side to side response, (1)
spacer slows the response.
NOTE: It is important that there is at least one
spacer on each side of the rod end ball
joints to prevent damage. Also the small
diameter of the spacer must point
towards the rod end ball joint.
Spacers (3)
per side
Cross Bolt
Joystick
Pivot Shaft
Lock Nut
Right Hand
Upper Linkage
Rod Assembly
Left Hand Upper
Linkage Rod
Assembly
Lock Nut

15
12. JOYSTICK CONTROL LEVER
DETENT ADJUSTMENT:
If the Joystick Control Lever does not
lock in the “UP” position, turn the detent
adjustment screw clockwise until a
desirable locking action is obtained. If
the Joystick Control Lever is hard to
slide up and down, turn the detent
adjustment screw counter-clockwise
until a desirable sliding action is
obtained.
13. TWINSTICK CONTROL LEVER
NEUTRAL ADJUSTMENT:
A. Remove the fender skirts from each side
of the machine.
B. Block up the unit so that the Drive
Wheels are off the ground.
C. Start the engine and run at a fast idle
with the Steering control levers in the
“out” position.
D. Loosen the locknuts tightened against
the rod end ball joints in the Upper
Linkage Assembly. (Note: One of these
is a left hand nut and will have to be
turned backwards.)
E. Adjust the Neutral Position by turning the
rod in the upper linkage until the wheel
stops turning.
F. Retighten the nuts on the Upper Linkage
Assembly and check to see that the
drive wheel is still not turning.
G. Repeat steps B-F for the other side.
H. Shut off engine before removing the
blocks.
14. To Adjust “IN” Position of the
Twinstick Steering Control Levers:
A. Remove the Front Bolts, Nuts and
Washers which hold the Fender Cap in
place.
B. Pull the boot from the hole in the fender
cap, exposing the cast iron lever.
C. Using a 5/32” Allen Wrench, turn the
setscrew to adjust the stop.
D. Replace the Boot into the hole in the
Fender Cap.
E. Replace the Front Bolts, Nuts, and
Washers.
15. To Align Twinstick Control Lever
Handles Forward / Reverse:
A. Sit on the seat and push the control
levers full forward and full backward. If
the ends do not match the handles
maybe adjusted as follows:
B. Locate Setscrew stops in the Steering
Control Lever Base which stop the lever
in each direction. (Note: The one at the
rear is the stop for FWD and the one in
the front is the stop for REV.)
C. Adjust setscrew stops so that handles
line-up together when shifted full forward
and full reverse.
Detent
Adjustment
Joystick
Assembly
Lock Nut
Lock Nut
Upper Linkage
Rod Assembly

16
Note: To prevent damage to Control Linkages
the Control Lever must always hit on the
Stop Screws. Never adjust Stops out so
that the Control Lever “bottoms” out on
other parts of the linkage.
16. ADJUSTING FOR STRAIGHT
FORWARD TRACKING:
In a large open area, actuate the Control
lever(s) into the full forward position. If
the mower veers in either direction left or
right some adjustment is necessary. If
the mower veers to the right, then the
right hydrostat needs to be sped up. If
the mower veers to the left, then the left
hydrostat needs to be sped up.
A. Stop the machine and shut off the
engine.
B. Slightly loosen the bolt at the lower end
of the upper linkage assembly on the
side that is slower. Using a 1/8” hex
wrench turn the setscrew ¼ turn in. It
may take several test drives to get the
mower to track straight forward.
C. Once the tracking is to the operators
liking, completely tighten the bolt on the
control linkage assembly that was
loosened earlier.
D. Recheck to make sure neutral adjust
has not been effected. Readjust neutral
if necessary.
17. HYDROSTATIC TRANSMISSIONS:
Before each use, check to be sure that
the cooling fins of the hydrostatic
transmissions are clean. Excessive
accumulation of oil, dirt, or trash may
cause the transmissions to overheat.
18. HYDROSTATIC TRANSMISSIONS
FLUID CHANGE (JAZEE PRO):
A SAE 20W-50 engine oil has been
selected for use by factory and is
recommended for normal operating
temperatures. Each transmission holds
a maximum of 74 oz of oil. Refer to page
17 on how to check fluid level.
Hydrostatic
Transmission
Vent Hose
(One Each Side)
Access Hole to
Control Lever
“Forward” Stop
Access Hole to
Control Lever
“Outward” Stop
Control Lever
“Reverse” Stop
Setscrew to
adjust forward
tracking
Upper Linkage Assembly
Loosen Nut

17
It is essential that the unit exterior be
free of debris prior to fluid maintenance.
Remove the oil drain plug to facilitate oil
change. When reinstalling drain plug
torque to 180-240 in-lbs.
Remove filter from Transmission, clean
all debris from screens, and check for
any damage to filter. Replace filter if
plastic is cracked or screens are loose.
Use Part # H-2256 when reordering from
Country Clipper. When tightening filter
insure proper torque value 20-50 in-lbs
is applied. Filter is plastic. Excessive
torque will damage filter.
19. PURGING PROCEDURES:
Oil Hydrostatic Transmission
The following procedures should be
performed with the vehicle drive wheels
off the ground then repeated under
normal operating conditions.
A. With the transmission unlocked (see
page 10 for details) and engine running,
slowly move the directional control in
both forward and reverse directions 5 to
6 times, as air is purged from the unit,
the oil level will drop.
B. With the transmission locked and the
engine running, slowly move the
directional control in both forward and
reverse directions (5 to 6 times). Check
the oil level, and add oil as required after
stopping engine.
C. It may be necessary to repeat Steps 1
and 2 until all air is completely purged
from the system. When the transaxle
moves forward and reverse at normal
speed purging is complete.
Due to effects air has on efficiency in
hydrostatic drive applications, it is critical
that it be purged from the system.
These purge procedures should be
implemented any time a hydrostatic
system has been opened to facilitate
maintenance or any additional oil has
been added to the system.
The resulting symptoms in hydrostatic
systems may be:
1. Noisy operation.
2. Lack of power or drive after short
term operation.
3. High operation temperature and
excessive expansion of oil. Before
starting, make sure the transmission
is at the proper oil level. If it is not,
fill to specifications.
PROCEDURE FOR RAISING AND
LOWERING THE DECK FOR
SERVICING
1. RAISING THE DECK:
A. Remove cut height adjustment pin and
completely lower the cut height
adjustment lever. Re-insert the cut
height adjustment pin into the 3-1/2” cut
height position (this will lock the cut
height adjustment lever into the lowest
position).
B. Flip up the foot deck to allow access to
the engine to deck drive belt. Roll the
engine to deck drive belt off the center
spindle. Remove the engine to deck
drive belt from the clutch on the engine.
Flip up the Front Step on units so
equipped.
On models equipped with Deck Belt
Tension Latch carefully rotate the
Latch to release tension from the
Deck Belt.
Fluid Level

18
C. On the right side of the mower, lift and
hold up on the hook keeper. Lift up on
the release handle to disconnect the
back of the deck. The latch plate
should catch and hold the release
handle rod in place. (To adjust the latch
plate, see Page 20.)
D. Position the front caster wheels so they
are away from the deck (such as the
tractor would be traveling in reverse).
E. Lift the nose of the deck until the deck
is standing vertical (lifting can be made
easier if someone stands on the rear
bumper of the tractor). IMPORTANT
NOTE: MAKE SURE THAT THE
DECK IS LIFTED FAR ENOUGH TO
GO COMPLETELY “OVER-CENTER”.
This will prevent the deck from falling
down when servicing the underside of
the mower deck.
2. LOWERING THE DECK:
A. Push the bottom (back) of the deck
towards the rear of the tractor. Lower
the deck until it rests on the ground.
B. Lift up on the latch plate to release the
release handle rod. Push down on the
release handle until deck hooks lock into
place.
C. Install the engine to deck belt onto the
clutch on the engine.
D. Roll the engine to deck drive belt back
onto the center spindle. Insure that the
engine to deck drive belt is installed onto
all of the pulleys and idlers in the drive
train.
On models equipped with Deck Belt
Tension Latch carefully rotate the
Latch to re-tension the Deck Belt
E. Lower the foot deck down into the
operation position. On units so
equipped, lower the front step.
MOWER SHOWN IN OPERATION
POSITION.
Front Caster Wheels
positioned out of the way.
Deck Hook
Hook
Keeper
Latch
Plate
Foot Deck
Cut Height
Adjustment
Center Deck Spindle
Cut Height Adjustment Lever
Flip Front Step Up

19
Deck hanger bolt
Part # F-1936
1/2" Jam nut
Part # F-1189
6" Scale
LEVELING THE DECK
1. Move the tractor to a hard surface (i.e. concrete or blacktop)
2. Set the tire pressure on each of the four tires to 12 psi
3. Set the deck cutting height to the highest position and rotate the two outside blades by hand until one end
of each outside blade points forward (toward the front of tractor)
4. Measure from the ground to the front blade tip of each outside blade. These measurements should be
Within 1/8” of each other. (NOTE: To simplify this measuring, an optional Blade Measuring tool, part
Number 629-374A is available from your local “Country Clipper” Dealer)
5. If necessary loosen the jam nut(s) of the Deck Hanger Bolt(s) and adjust the Deck Hanger
Bolt(s) up or down accordingly. It may be necessary to adjust both the front and rear Deck
Hanger Bolts for a given side.
MOWER SHOWN IN SERVICING
POSITION.
Engine to Deck Belt removed
from Center spindle & Clutch
Deck Raised
“OVER –CENTER”
Note: If you run out of threads during
the adjustment process, remount the
deck mounting in this upper hole.
IF ATTEMPTING TO ADJUST DECK
HIGHER THAN DESIGN
SPECIFICATIONS, DECK DRIVE
FAILURE CAN OCCUR.

20
6. Once the side to side cut height is within tolerance, measure from the ground to the blade tip
At the rear of each outside blade. This measurement should be between 1/8” and ¼” higher
from the ground than the front of the blade from the ground on the corresponding side of the
deck. Adjust rear and/or the front deck hangers accordingly to obtain the proper measurement.
Re-measure the side to side cutting height to confirm that they are still within 1/8” of each other
at the front of the blade.
7. Confirm that the deck is hanging firmly on ALL four deck hanger bolts. Readjust any loose
Deck Hanger Bolts accordingly.
8. Once all of the above measurements are confirmed, tighten ALL jam nuts on the Deck Hanger
Bolts. Failure to tighten can result in an un-level cutting deck and/or lost Deck Hanger
Components.
ADJUSTING THE LATCH PLATE
1. Level the deck before proceeding to adjust the latch plate. (Follow instructions on previous page.) Pin
the deck in the lowest position before proceeding to adjust the latch plate.
2. Lift up on the hook keeper, while pulling up on the release handle. This will disconnect the rear of the
deck.
3. Loosen nuts on the adjustment of the latch plate using a 7/16 wrench. Pull up on the release handle as
far as it will allow. Slide adjustment back or forward to where the latch plate will catch the release handle
rod at its highest location. Tighten nuts back.
4. Lift up on latch plate and push down on the release handle to lock deck hooks in place.
5. Double check the latch plate adjustment by releasing the deck hangers and pulling up on the release
handle. If the latch plate catches the release handle rod, no further adjustment needs to be made. If it
does not, follow steps 3-5, as needed.
UP
(RELEASE)
DOWN
(LOCK)
HOOK
KEEPER
DECK
HOOK
LATCH
PLATE
RELEASE
HANDLE ROD
RELEASE
HANDLE
LATCH PLATE
ADJUSTMENT
