OWNER’S MANUAL
Quick Install Sump Pump
MANUAL DEL USUARIO
Bomba para sumidero de
instalación rápida
CLRP50
©2016 CL884 (Rev. 09/26/16)
Installation/Operation/Parts
For further operating, installation, or
maintenance assistance:
Call 800-535-4950
English.................Pages 2-8
Instalación/Operación/Piezas
Para mayor información sobre
el funcionamiento, instalación o
mantenimiento de la bomba:
Llame al 800-535-4950
Español ............. Páginas 9-15
For emergency flooding situations, see instructions, page 4.
Para situaciones de emergencia en caso de inundación,
consulte las instrucciones en la página 11.
293 Wright Street, Delavan, WI 53115
Phone: [phone]
Fax: [phone]
www.tractorsupply.com

Safety 2
Important Safety
Instructions
SAVE THESE INSTRUCTIONS - This manual
contains important instructions that should be
followed during installation, operation, and
maintenance of the product. This is the
safety alert symbol. When you see this symbol
on your pump or in this manual, look for one
of the following signal words and be alert to the
potential for personal injury!
indicates a hazard which, if not
avoided, will result in death or serious injury.
indicates a hazard which, if not
avoided, could result in death or serious injury.
indicates a hazard which, if not
avoided, could result in minor or moderate injury.
NOTICE addresses practices not related to
personalinjury.
Carefully read and follow all safety instructions
in this manual and on pump.
Keep safety labels in good condition. Replace
missing or damaged safety labels.
California Proposition 65 Warning
This product and related
accessories contain chemicals known to the
State of California to cause cancer, birth defects
or other reproductive harm.
Specifications
Power supply required.................................. 115V, 60 HZ.
Liquid Temp. Range......................... 32°F to 70°F(0°-21°C)
Individual Branch Circuit Required (min.) ............15 Amps
Motor Full Load:..................................................5.5 Amps
Discharge:
Check Valve ................................1-1/4” slip / 1-1/2” slip
Hose .....................................................................1-1/4”
NOTICE Do not reduce size of discharge pipe or
hose below 1-1/4” diameter. If discharge is too
small, pump will overheat and fail prematurely.
NOTICE This unit is not designed as a waterfall
or fountain pump, or for applications involving
salt water or brine! Use with waterfalls,
fountains, salt water or brine will void warranty.
Pump water only with this pump.
Do not use where water recirculates.
Not designed for use as a swimming
pooldrainer.
NOTICE Read this Owner’s Manual for
installation, operation, and safety information.
Performance
GPH (LPH) at Total feet (m) of lift
5’
(1.5m)
10’
(3m)
15’
(4.6m)
20’
(6.1m)
No flow
at height
shown
below
Capacity Gallons(L)/Hour
3200
(12 113) 2700 (10 220) 2000 (7 571) 1200 (4 542) 24’ (7.3m)
1. Know the pump application, limitations, and
potential hazards.
2. Do not use in water with fish present. If any oil
leaks out of the motor it can kill fish.
3. Disconnect power before servicing.
4. Release all pressure within system before
servicing any component.
5. Drain all water from system before servicing.
6. Secure discharge line before starting pump.
An unsecured discharge line will whip,
possibly causing personal injury and/or
propertydamage.
7. Check hoses for weak or worn condition
before each use, making certain that all
connections are secure.
8. Periodically inspect sump, pump and system
components. Keep free of debris and foreign
objects. Perform routine maintenance
asrequired.
9. Provide means of pressure relief for pumps
whose discharge line can be shut-off
orobstructed.

Warranty 3
Retain Original Receipt For Warranty Eligibility
Limited Warranty
This Limited Warranty is effective January 1, 2013 and replaces all undated warranties and warranties dated before
January 1, 2013.
CountyLine warrants to the original consumer purchaser (“Purchaser” or “You”) that its products are free from defects in
material and workmanship for a period of twelve (12) months from the date of the original consumer purchase. If, within
twelve (12) months from the original consumer purchase, any such product shall prove to be defective, it shall be repaired or
replaced at CountyLine’s option, subject to the terms and conditions set forth herein. Note that this limited warranty applies
to manufacturing defects only and not to ordinary wear and tear. All mechanical devices need periodic parts and service to
perform well. This limited warranty does not cover repair when normal use has exhausted the life of a part or the equipment.
The original purchase receipt and product warranty information label are required to determine warranty eligibility. Eligibility
is based on purchase date of original product – not the date of replacement under warranty. The warranty is limited to repair
or replacement of original purchased product only, not replacement product (i.e. one warranty replacement allowed per
purchase). Purchaser pays all removal, installation, labor, shipping, and incidental charges.
For parts or troubleshooting assistance, DO NOT return product to your retail store. Contact CountyLine Customer Service
at 800-535-4950.
Claims made under this warranty shall be made by returning the product (except sewage pumps, see below) to the retail outlet
where it was purchased immediately after the discovery of any alleged defect. CountyLine will subsequently take corrective
action as promptly as reasonably possible. No requests for service will be accepted if received more than 30 days after the
warranty expires. Warranty is not transferable and does not apply to products used in commercial/rentalapplications.
Sewage Pumps
DO NOT return a sewage pump (that has been installed) to your retail store. Contact CountyLine Customer Service. Sewage
pumps that have seen service and been removed carry a contamination hazard with them.
If your sewage pump has failed:
• Wear rubber gloves when handling the pump;
• For warranty purposes, return the pump’s cord tag and original receipt of purchase to the retail store;
• Dispose of the pump according to local disposal ordinances.
Exceptions to the Twelve (12) Month Limited Warranty
Product Warranty Period
CL106, CL108 90 days
CLTS33P, CLSU14 2 Years
4” Submersible Well Pumps 3 Years
CLVS50C, CLW750, Pressure Tanks 5 Years
General Terms and Conditions; Limitation of Remedies
You must pay all labor and shipping charges necessary to replace product covered by this warranty. This warranty does not
apply to the following: (1) acts of God; (2) products which, in CountyLine’s sole judgement, have been subject to negligence,
abuse, accident, misapplication, tampering, or alteration; (3) failures due to improper installation, operation, maintenance or
storage; (4) atypical or unapproved application, use or service; (5)failures caused by corrosion, rust or other foreign materials in
the system, or operation at pressures in excess of recommended maximums.
This warranty sets forth CountyLine’s sole obligation and purchaser’s exclusive remedy for defective products.
COUNTYLINE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE FOREGOING WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION PROVIDEDHEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an
implied warranty lasts, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal
rights and You may also have other rights which vary from state to state.
CountyLine • 293 Wright Street • Delavan, WI U.S.A. 53115
Phone: [phone] • Fax: [phone] • www.tractorsupply.com

10. Personal Safety:
a. Do not plug in or otherwise handle with
wet hands or when standing on wet or
damp surface, or in water.
b. Wear safety glasses at all times when
working with pumps.
c. Keep work area clean, uncluttered and
properly lighted – replace all unused tools
and equipment.
d. Keep visitors at a safe distance from
workarea.
e. Make workshop child-proof – with
padlocks, master switches, and by
removing starter keys.
11. When wiring an electrically driven pump,
follow all electrical and safety codes
thatapply.
12. Risk of electric shock. Can
shock, burn or kill. This equipment is only for
use on 115 volt (single phase) and is equipped
with an approved 3-conductor cord and
3-prong, grounding-type plug.
• To reduce risk of electric shock, pull plug
before servicing. This pump has not been
investigated for use in swimming pool areas.
Pump is supplied with a grounding conductor
and grounding-type attachment plug. Be sure
it is connected only to a properly grounded
grounding-type receptacle.
• Where a 2-prong wall receptacle is
encountered, it must be replaced with properly
grounded 3-prong receptacle installed in
accordance with codes and ordinances
thatapply.
13. All wiring should be performed by a
qualifiedelectrician.
14. Make certain power source conforms to
requirements of your equipment.
15. Protect electrical cord from sharp objects, hot
surfaces, oil, and chemicals. Avoid kinking
cord. Replace or repair damaged or worn
cords immediately.
16. Risk of burns. Do not touch
an operating motor. Motors can operate at
hightemperatures.
17. Do not handle pump or pump motor with
wet hands or when standing on wet or damp
surface, or in water.
Risk of electric shock. Can
shock, burn or kill. If your basement has
water or moisture on floor, do not walk on
wet area until all power has been turned off.
If shut-off box is in basement, call electric
company or hydro authority to shut-off service
to house, or call your local fire department
for instructions. Remove pump and repair or
replace. Failure to follow this warning can
result in fatal electricalshock.
18. Do not lift pump by power cord.
For Emergency Flooding
Situations
Risk of electric shock. Can
shock, burn or kill. If your basement has
water or moisture on floor, do not walk on
wet area until all power has been turned off.
If shut-off box is in basement, call electric
company or hydro authority to shut-off service
to house, or call your local fire department
for instructions. Remove pump and repair or
replace. Failure to follow this warning can result
in fatal electricalshock. Do not lift pump by
powercord.
1. Install the adapter and hose barb in the pump’s
check valve. Install the hose on the adapter
and clamp it.
2. Lift the cord and tape it to the pump’s
discharge pipe. Plug the pump and switch into
a UL and/or CSA approved type SJTW water
resistant 3-prong grounding-type extension
cord. The cord must be at least #14 AWG
and not more than 100 feet long. Plugs and
extension cord must be kept out of the water.
3. Remove the old pump from the sump and set
itaside.
4. Lower the pump into the sump. Make sure the
power cord is long enough that the plug is out
of the water when the pump is running.
5. Run the hose out of the flooded area to an
adequate drain area.
Safety • Emergency Use 4

Installation 5
6. Risk of electric shock. Can
shock, burn or kill.
Go to a dry area, remove wet shoes and
change wet clothing. WHEN YOU ARE DRY,
plug the extension cord into a grounded
electrical outlet (with a GFCI, if possible).
DO NOT STAND IN WATER TO PLUG IN
THEPUMP.
7. National Electrical Code (NEC) and Canadian
Electrical Code (CEC) requirements prohibit the
use of an extension cord with this pump in a
permanent installation.
As soon as possible, remove the extension
cord and reinstall the pump as a permanent
replacement pump whose power cord
connects directly into a properly grounded
grounding-type receptacle. Install the pump
in accordance with the instructions, and in
accordance with all codes and ordinances
thatapply.
8. Monitor the pump’s operation. The pump will
automatically stop when the water level has
receded to the OFF point of the switch.
NOTICE CSA has not approved the use of an
extension cord with this pump.
Installation
1. Install pump in sump pit with minimum
diameter of 10” (254mm). Sump depth should
be 10” (254mm). Construct sump pit of tile,
concrete, steel or plastic. Check local codes for
approved materials and for proper installation.
2. Install pump in pit so that switch operating
mechanism has maximum possible clearance.
Switch Setting in inches (mm)
On Off
8” (203) 3.5” (89)
3. Pump should not be installed on clay, earth or
sand surfaces. Clean sump pit of small stones
and gravel which could clog pump. Keep
pump inlet screen clear.
NOTICE Do not use ordinary pipe joint
compound on plastic pipe. Pipe joint
compound can attack plastics.
Risk of flooding. Can cause
personal injury and/or property damage.
If a flexible discharge hose is used, make
sure pump is secured in sump to prevent
movement. Failure to secure pump may allow
pump movement, switch interference and
prevent pump from starting or stopping.
4. Power Supply: Pump is designed for 115 V.,
60 Hz., operation and requires a minimum
15amp individual branch circuit. Both pump
and switch are supplied with 3-wire cord sets
with grounding-type plugs. Switch plug is
inserted directly into outlet and pump plug
inserts into opposite end of switch plug.
Risk of electric shock. Can
shock, burn or kill. Pump should always be
electrically grounded to a suitable electrical
ground such as a grounded water pipe or a
properly grounded metallic raceway, or ground
wire system. Do not cut off round ground pin.
5. If pump discharge line is exposed to outside
sub-freezing atmosphere, portion of line
exposed must be installed so any water
remaining in pipe will drain to the outfall
by gravity. Failure to do this can cause water
trapped in discharge to freeze which could
result in damage to pump.
6. After piping, check valve and float switch have
been installed, the unit is ready for operation.
7. Check the pump operation by filling sump with
water and observing pump operation through
one complete cycle.
Risk of flooding. Can cause
personal injury and/or property damage.
Failure to make this operational check may
lead to improper operation, premature failure,
and flooding.
