Craftsman 320.27990 User manual

Operator's Manual
II:RAFTSMAN°I
8A Impact Wrench
Model No. 320.27990
WARNING:To reduce the risk of
injury, the user must read and
understand the Operator's manual
before using this product.
!-_ C_US
• WARRANTY
• SAFETY
• UNPACKING
• DESCRIPTION
•OPERATION
•MAINTENANCE
•TROUBLESHOOTING
•ESPANOL
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
www.craftsman.com

iII_ =[e_[_e__]
Warranty page 2
Safety Symbols page 3
Safety Instructions page 5-8
Unpacking page 9
Description page 10-11
Operation page 12-14
Maintenance page 15
Troubleshooting page 16
Exploded View and Part List page 17-20
Sears Repair Parts Phone Number Back Cover
CRAFTSMAN ONE YEAR LIMITED WARRANTY
FOR ONE YEAR from the date of purchase, this product is warranted
against any defects in material or workmanship. With proof of
purchase, defective product will be replaced free of charge.
For warranty coverage details to obtain free replacement, visit the
web site: www.craftsman.com
This warranty is void if this product is ever used while providing
commercial services or if rented to another person.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179
AWARNING: Some dust created by using power tools contains chemicals
known to the state of California to cause cancer and birth defects or other re-
productive harm.
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!
This Impact Wrench has many features for making its use more pleasant and
enjoyable. Safety, performance, and dependability have been given top priority
in the design of this product, making it easy to maintain and operate.
27990 ManuaLRevised_lO ±202 Page 2

The purpose of safety symbols is to attract your attention to possible dangers.
The safety symbols and the explanations with them deserve your careful
attention and understanding. The warnings do not, by themselves, eliminate any
danger. The instructions and warnings they give are no substitutes for proper
accident prevention measures.
A_, WARNING: Be sure to read and understand all safety instructions in this
manual, including all safety alert symbols such as "DANGER," "WARNING,"
and "CAUTION," before using this Impact Wrench. Failure to follow all
instructions listed in this manual may result in electric shock, fire, and/or serious
personal injury.
SYMBOL MEANNING
_, SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
DANGER: Failure to obey this safety warning will result in death or serious
injury to you or to others. Always follow the safety precautions to reduce the risk
of fire, electric shock, and personal injury.
A_, WARNING: Failure to obey this safety warning can result in death or serious
injury to you or to others. Always follow the safety precautions to reduce the risk
of fire, electric shock, and personal injury.
_, CAUTION: Failure to obey this safety warning may result in death or serious
injury to you or to others. Always follow the safety precautions to reduce the risk
of fire, electric shock, and personal injury.
_, WARNING: To ensure safety and reliability, all repairs should be performed
at a Sears Parts & Repair Service Center.
DAMAGE PREVENTION AND INFORMATION MESSAGES
These messages inform the user of important information and/or instructions
that could lead to equipment or other property damage if they are not followed.
Each message is preceded by the word "NOTE" as in the example below.
NOTE: Equipment and/or property damage may result if these instructions
are not followed.
_, WARNING: The operation of any power tool can result in foreign objects
being thrown into your eyes, which can result in severe eye
damage. Before beginning power tool operation, always
wear safety goggles or safety glasses with side shields and a
full-face shield when needed. We recommend a Wide Vision
Safety Mask for use over eyeglasses or standard safety
glasses with side shields. Always use eye protection which is
marked to comply with ANSI Z87.1
27990 ManuaLRevised_10 1202 Page 3

Some of these following symbols may be used on this tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to
operate the tool better and more safely.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
rain Minutes Time
Alternating Current Type of current
---== Direct Current Type or a characteristic of current
n o No Load Speed Rotational speed, at no load
] Class II Construction Double-insulated construction
.../rain Per Minute Revolutions, strokes, surface speed,
orbits, etc., per minute
Do not expose to rain or use in damp
Wet Conditions Alert locations.
To reduce the risk of injury, user must
Read The Operator's Manual read and understand operator's manual
before using this product.
O Always wear safety goggles or safety
Eye Protection glasses with side shields and a full face
shield when operating this product.
_lb Alert Precautions that involve
Safety your safety,
Failure to keep your hands away from the
No Hands Symbol blade will result in serious personal injury.
No Hands Failure to keep your hands away from the
Symbol blade will result in serious personal injury.
Failure to keep your hands away from the
No Hands Symbol blade will result in serious personal injury.
Failure to keep your hands away from the
No Hands Symbol blade will result in serious personal injury.
Hot Surface To reduce the risk of injury or damage,avoid contact with any hot surface.
27990 ManuaLRevised_lO 1202 Page 4

A_, WARNING: Be sure to read and understand all instructions in this manual
before using the Impact Wrench. Failure to follow all instructions listed below
may result in electric shock, fire, and/or serious personal injury.
_, WARNING: Do not attempt to operate this tool until you have thoroughly
read all instructions, safety rules, and warnings. Failure to comply with them can
result in fire, electric shock, or serious personal injury. Save the manual and refer
to it frequently.
GENERAL SAFETY PRECAUTIONS
_, WARNING: Read all safety warnings and instructions. Failureto follow
the warnings and instructions may result in electric shock, fire and/or serious
personal injury.
Save all warnings and instructions for future reference.
The term "power tool" in all of warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
•Keep your work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive environments, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks,
which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions may cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will reduce the risk of electric shock.
Avoid body contact with grounded surfaces, such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling, or
unplugging the power tool. Keep the cord away from heat, oil, sharp
edges, or moving parts. Damaged or entangled cords increase the risk of
electric shock.
27990 ManuaLRevised_lO 1202 Page 5

•When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
•If operating a power tool in a damp location is unavoidable, use a
ground fault circuit interrupter (GFCI) protected power supply. Use of a
GFCI reduces the risk of electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use the power tool while tired or under
the influence of drugs, alcohol, or medication. A moment of inattention
while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment, such as dust mask, non-skid safety shoes, hard hat,
or hearing protection, used for appropriate conditions will reduce personal
injuries.
Prevent unintentional starting. Ensure that the switch is in the OFF
position before connecting to a power source and/or battery, picking
up, or carrying the tool. Carrying power tools with your finger on the switch
or energizing power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and
collection facilities, ensure that these are connected and properly used.
Use of these devices can reduce dust-related hazards.
POWER TOOL USE AND CARE
•Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and more safely at
the rate for which it was designated.
•Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
•Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories,
or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
27990 ManuaLRevised_lO 1202 Page 6

•Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool's operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
•Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
Use the power tool, accessories, blades, etc. in accordance with these
instructions and in the manner intended for the particular type of
power tool, taking into account the working conditions and the work
to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
_, WARNING: When using power tools, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and personal injury.
_, WARNING: The operation of any tool can result in foreign objects being
propelled into your eyes, resulting in severe eye damage. When operating a
power tool, always wear safety goggles or safety glasses with side shields and a
full face shield when needed.
A_, WARNING: If any parts are missing, do not operate the tool until the missing
parts have been replaced. Doing so could result in serious personal injury.
SERVICE SAFETY
•Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
If any part of this Impact Wrench is missing or should break, bend, or fail
in any way, or should any electrical component fail to perform properly: shut
off the power switch and remove the Impact Wrench plug from the power
source and have the missing, damaged, or failed parts replaced before
resuming operation.
Tool service must be performed only at a Sears Parts & Repair Service
Center. Service or maintenance performed by unqualified personnel could
result in a risk of injury.
Use only identical replacement parts when servicing a tool. Follow
the instructions in the Maintenance section of this manual. Use of
unauthorized parts or failure to follow maintenance instructions may create a
risk of electric shock or injury.
27990 ManuaLRevised_lO 1202 Page 7

SPECIFIC SAFETY RULES FOR IMPACT WRENCH
Hold power tools by the insulated gripping surfaces when performing an
operation where the cutting tool may contact hidden wiring or its own
cord. Contact with a "live" wire will make exposed metal parts of the tool live
and shock the operator.
Do not use the power tool with a damaged cord. Do not touch the
damaged cord; turn off the tool and pull the plug from the outlet if the
cord is damaged while working. Damaged cords increase the risk of an
electric shock.
Secure the workpiece. A workpiece clamped with clamping devices or in a
vice is held more securely than it is by hand.
Always wait until the power tool has come to a complete stop before
placing it down. The tool insert can jam and lead to loss of control over the
power tool.
Check the socket carefully for wear, cracks or damage before installation
on the hammer drill.
• Hold the tool firmly with both hands.
•Always be sure that you have a firm footing. Be sure that no one is below
you when using the tool in high locations.
•Check the torque with a torque wrench. The proper fastening torque may
differ depending on the type of size of the bolt.
•Use thick, cushioned gloves and limit the exposure time by taking
frequent rest periods. Vibration caused by hammer-drill or Impact wrench
action may be harmful to your hands and arms.
•Do not use this tool as a drill. Tools equipped with shut-off clutches are not
designed for drilling applications. The output drive can shut off automatically
and without warning.
•Be careful when driving long screws. There is a risk of the tool sliding
off the fastener head, depending on type of socket or bit used. First test
the fastening time of a fastener and pay attention during the screw-driving
process to ensure you do not injure yourself if the tool bit or socket slides off
of the fastener.
_. WARNING: Bits, sockets, and tools get hot during operation. Wear gloves
when touching them.
_1_ WARNING: Wear ear protection. Exposure to noise can cause
hearing loss.
A_, WARNING: To avoid injury, hold the tool by the insulated
gripping surfaces only. If the tool contacts hidden wiring or its
own cord, exposed metal parts of the tool could shock the operator and cause
serious injury. Make sure that hidden electrical wiring, water pipes, or other
hazards are not in the cutting path.
27990 ManuaLRevised_lO 1202 Page 8

A_, WARNING: Your Impact Wrench should never be connected to the power
source when you are assembling parts, making adjustments, installing or
removing bits, cleaning, or when it is not in use. Disconnecting the Impact
Wrench will prevent accidental starting, which could cause serious personal
injury.
When unpacking the box, do not discard any packing materials until all of the
contents are accounted for.
1. Carefully lift the Impact wrench out of the carton and place on a stable, flat
surface.
2. Open the box to locate the following:
•Impact wrench
• Manual
• Soft case
3. Inspect the items carefully to make sure that no breakage or damage has
occurred during shipping. If any of the items mentioned is missing, return
the Impact Wrench with your sales receipt to your nearest Craftsman retail
outled to have the Impact Wrench replaced.
_, WARNING: If any part is broken or missing, do not attempt to assemble
the Impact Wrench, plug in the power cord, or operate the Impact Wrench until
the broken or missing part is replaced. Failure to do so could result in possible
serious injury.
27990 Manual_Revised_lO 1202 Page 9

ID]_]_II]_IIIEe]_]
KNOW YOUR IMPACT WRENCH (Fig.l)
The machine is intended for driving and loosening screws and bolts as well as
for tightening and loosening nuts within the range of the Product Specifications.
Fig. 1
1/2-in. Square Externally
Drive Accessible
Carbon Brushes
Forward/
Reverse Switch
Live Tool Indicator
LED Work Light
_i, WARNING: Do not allow familiarity with the impact wrench to cause a lack of
alertness. A fraction of a second of carelessness is enough to cause severe injury.
PRODUCT SPECIFICATIONS
Motor 120Volt 60Hz AC only
No Load Speed 2100 RPM
Impacts Per Minute 2700 BPM
Torque 350 ft-lbs
Capacity Standard bolt M 18 - M22 (11/16" - 7/8")
Capacity High tensile bolt M16 - M20 (5/8" - 13/16")
Wrench Weight 7.71 Ibs (3.5kg)
27990 Manual_Revised_lO 1202 Page 10

_, WARNING: The safe use of this product requires an understanding of the
information on the tool and in this operator's manual, as well as knowledge of
the project you are attempting. Before use of this product, familiarize yourself
with all operating features and safety rules.
LED WORK LIGHT
Pressing the trigger switch illuminates the LED worklight located on the base of
the Impact Wrench. This feature provides extra light for increased visibility.
LIVE TOOL INDICATOR
The LED indicator shines green when the tool is plugged into a power source.
EXTERNALLY ACCESSIBLE CARBON BRUSHES
Externally accessible brushes permit replacement of the brushes to extend the
life of the impact wrench.
27990 Manual_Revised_lO 1202 Page 11

SELECTING THE CORRECT SOCKET (SOCKETS AVAILABLE SEPARATELY)
_, CAUTION: Always verifythat the tool isswitched off and unplugged before
installing any accessories on the tool.
Always use the correct size socket for bolts and nuts. An incorrect socket will
result in inaccurate and inconsistent fastening torque and/or damage to the bolt
or nut.
INSTALLINGAND REMOVING THE SOCKET (Fig.2)
1. To install the socket, push it onto the
output drive of the tool until it locks into
place.
2. To remove the socket, simply pull it off.
TURNING THE IMPACT WRENCH ON (Fig, 3)
1.
Fig. 2 _r_------_j /
Socket
Output
Drive
Connect the power cord of your impact
wrench to a standard household power
outlet. Fig. 3
2. Press the part of the switch marked _F_,
to run the tool in the forward direction
(clockwise rotation). Use this direction for
tightening bolts or nuts. Switch
3. Press the part of the switch marked _-R_
to reverse the motor direction (counter-
clockwise rotation). Use this direction for
loosening bolts or nuts.
4. Release the switch to stop the tool.
5. Keep the switch pressed for continuous operation.
_, CAUTION: Do not allow familiarity with your impact wrench to make you
careless. Remember that a careless fraction of a second is sufficient to cause
severe injury.
27990 ManuaLRevised_lO ±202 Page 12

INSTALLING FASTENERS
NOTE: Always keep the Impact Wrench at a right angle to the fastener to avoid
damaging the fastener head.
To fasten:
1. Start threading the fastener by hand onto or into its threaded counterpart
(e.g. nut onto bolt, or bolt into nut or threaded hole).
2. With the proper impact socket securely mounted to the wrench, slide the
impact socket onto the nut or bolt head.
3 Hold the tool securely with both hands and depress the switch at '_j.
The impact socket will turn the fastener and impacting will begin once the
fastener encounters resistance.
A_, WARNING: Do not over-tighten, as the force of the Impact Wrench can
break the fastener.
To loosen:
1.
2
3.
With the proper impact socket securely mounted to the wrench, slide the
impact socket onto the bolt head.
Hold the tool securely with both hands and depress the switch at _.. The
tool will start to impact immediately.
Once the fastener has "broken loose," it will start to unthread. Be careful that
you do not allow a fastener to spin freely once it is no longer engaged with
its threaded counterpart, as it may be thrown out of the socket.
IMPACTING TECHNIQUES
The proper fastening torque may differ depending on the type or size of the bolt,
the material of the workpiece to be fastened, etc.
NOTE: Hold the tool straight along the axis of the bolt or nut.
NOTE: Excessive fastening torque may damage the bolt/nut or socket. Before
starting your job, always perform a test operation to determine the proper
fastening time for your bolt or nut.
Practice with various fasteners, noting the length of time required to reach the
desired torque. Check the tightness with a hand-torque wrench. If the fasteners
are too tight, reduce the impacting time. If they are not tight enough, increase
the impacting time.
Hold the tool firmly, and place the socket over the bolt or nut. Turn the tool on,
and fasten the bolt or nut to the proper torque.
The torque that is required to loosen a fastener averages 75% to 80% of the
tightening torque, depending on the condition of the contacting surfaces.
However, if rust or corrosion causes seizing, more torque may be required.
27990 ManuaLRevised_lO 1202 Page 13

After fastening, always check the torque with a torque wrench. The fastening
torque is affected by a wide variety of factors, including the following:
• Voltage
o A voltage reduction will cause a reduction in the fastening torque.
• Socket
o Failure to use the correct size socket will cause a reduction in the fastening
torque.
o A worn socket (wear on the hex end or square end) will cause a reduction
in the fastening torque.
Bolt
o Although the torque coefficient and the class of bolt may be the same, the
proper fastening torque will differ according to the diameter of the bolt.
o Even if the diameters of bolts are the same, the proper fastening torque
will differ according to the torque coefficient, the class of bolt and the bolt
length.
The use of a universal joint or an extension bar (both available separately) will
reduce the fastening force of the impact wrench somewhat. Compensate by
fastening for a longer period of time.
The manner of holding the tool or the material to be fastened will affect the
torque.
27990 ManuaLRevised_10 1202 Page 14

_1, WARNING: To avoid serious personal injury, always disconnect the tool plug
from the power source before cleaning or performing any maintenance.
_1, WARNING: When servicing, use only identical Craftsman replacement parts.
Use of any other parts may create a hazard or cause product damage.
A_, WARNING: It is not recommended to use compressed dry air as a cleaning
method for the Impact Wrench. If cleaning with compressed air must be used,
always wear safety goggles or safety glasses with side shields. If the operation is
dusty, also wear a dust mask.
BRUSH REPLACEMENT (Fig. 4)
The impact wrench is equipped with externally
accessible brushes.
Replacement brush sets are available through
a Sears Parts & Repair Service Center.
To replace:
1.
2.
3.
4.
Unplug the tool.
Loosen the brush caps with a slotted
screwdriver and remove them from the
tool.
Fig. 4 Brush Brush
Assembly Cap
_ Brush
Brush _ Assembly
Cap :_
Remove the brush assemblies. L_
Check for wear. Replace both brush
assemblies when the carbon brush on either is less than 1/4 in. long.
NOTE: Do not replace the brush on one side without replacing the other.
5. Reassemble using new brush assemblies. Make sure that the curvature of
the brush matches the curvature of the motor and that the brush moves
freely in the brush tube, being certain to fit the two metal "ears" into the
brush tube.
6. Tighten all brush caps securely. Do not over-tighten. The tool should be
allowed to "RUN IN" (run at no-load without a bit) for 5 minutes before use to
seat the new brushes properly.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible
to damage from various types of commercial solvents and may be damaged by
their use. Use clean cloths to remove dirt, dust, oil, grease, etc.
A_, WARNING: Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc. to come in contact with plastic parts. Chemicals
can damage, weaken or destroy plastic which may result in serious personal injury.
,_, WARNING: When servicing, use only identical Craftsman replacement parts.
Use of any other parts may create a hazard or cause product damage. To ensure
safety and reliability, all repairs should be performed by a qualified service
technician at a Sears Service Center.
27990 ManuaLRevised_lO i202 Page 15

PROBLEM CAUSE SOLUTION
The Impact Wrench is Plug the wrench into
The Impact Wrench not plugged into a power an appropriate power
does not work source source
Socket cannot be
installed Improper socket selection Use a suitable socket
Clean and clear vents.
Cooling vents are
Motor overheating obstructed Do not cover vents with
hand during operation
27990 ManuaLRevised_iO 1202 Page i6

m_
o
.C
C
o
C
E
_ E
.I..o
_° C
_.z_
o. o
E
J

8A IMPACT WRENCH MODEL NUMBER 320.27990
The Model Number will be found on the Nameplate. Always mention the Model
Number when ordering parts for this tool.
1 5610100000 Tapping Screw 4
2 3125492000 Decorate Cover 1
3 3421138000 Front Gear Housing 1
4 5690208000 O Ring 1
5 5650351000 Washer 1
6 2822873000 Spindle 1
201 2822725000 Impact Block ASSY 1
7 5700217000 Steel Ball 2
8 3551371000 Impact Block 1
9 5700045000 Steel Ball 29
10 5650312000 Washer 2
11 3660413000 Spring 1
12 3551440000 Gear 1
13 3551372000 Spindle 1
14 5650187000 Washer 2
15 5700028000 Needle Bearing 2
16 3551470000 Gear 1
17 3704670000 Gasket 1
202 2822944000 Rear Gear Housing ASSY 1
18 5670258000 Pin 1
19 5700211000 Oil Impreging Bearing 1
20 3421139000 Rear Gear Housing 1
21 5690213000 Rubber Ring 1
22 5700014000 Ball Bearing 1
23 2750905000 Rotor 1
24 5700008000 Ball Bearing 1
27990 ManuaLRevised_lO 1202 Page 18

25 3123738000 Bearing Holder 1
26 3125486000 Fan Baffle 1
27 5610048000 Tapping Screw 2
28 5650007000 Spring Washer 2
29 5650005000 Plain Washer 2
30 2740283000 Stator 1
31 3321078000 Hosuing 1
32 4930041000 Receptacle 2
33 4930008000 Sleeve 2
34 5620017000 Hexagon Socket Screw 2
35 4930057000 Terminal 2
36 3321080000 Rear Cover 1
37 5610042000 Tapping Screw 6
38 3121028000 Cord Guard 1
39 3125935000 Brush Cover 2
40 2800005000 Brush Holder Assy 2
41 4960019000 Carbon Brush Assy 2
42 4930432000 Connecter 1
43 3700314000 Cord Anchorage 1
44 5610093000 Tapping Screw 2
45 4890462000 PCB Assembly 1
46 4540017000 Power Supply Indicator 1
47 5610010000 Tapping Screw 2
48 3125488000 Indicator Cover 1
49 3125491000 Right Bracket 1
50 3125490000 Left Bracket 1
51 4360225000 LED 1
52 3125493000 Protecting Cap 1
53 3125487000 LED Cover 1
54 4930047000 Ring Terminal 4
27990 ManuaLRevised_lO 1202 Page 19

55 4870453000 Rocker Switch 1
56 3321079000 Handle 1
57 4810002000 Power Cord & Plug 1
58 4860004000 Inner Wire 2
59 4930449000 Terminal 2
60 4930030000 Receptacle 4
