Craftsman 12 VB2AQ Series Guide

778-16200A© 2018 12XVB2AQXXX CRAFTSMAN and the CRAFTSMAN logo are trademarks of Stanley Black & Decker, Inc. or an affiliate thereof and are used under license.
B. Pivot the handle into operating position. Be
careful not to crimp cables.
A. Place the EZ-Fold handle release levers to
the unlocked position.
A. Ensure the position indicator aligns
with one of three handle positions (a).
B. Place the EZ-Fold handle release levers
to the locked position.
B
A
A
(a)
A. Hold the blade control handle against
the upper handle.
B. Slowly pull starter rope handle from engine and
slip starter rope into the rope guide.
C. Tighten rope guide wing knob.
D. Use cable ties to secure cables to lower handle.
A
B
D
C
C. Insert the T-bolts
removed in Step 3A
through the handle
brackets to secure
the handle in place.
B
B. Pull upward on the
handle until the holes
in lower handle line
up with the holes in
the handle bracket.
A
A. Remove T-bolts from the handle brackets.
13
24
READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.
PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.
Fast Start Guide - Engine Start
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY
and FOLLOW THE important SAFE OPERATION PRACTICES BEFORE OPERATING.
Need Help?
www.CRAFTSMAN.com or Call 1-888-331-4569
Starter
Rope Handle
Blade Control
Drive Control
EZ-Fold
Handle release
Lever
EZ-Fold
Handle release
Lever

778-16200A© 2018 12XVB2AQXXX CRAFTSMAN and the CRAFTSMAN logo are trademarks of Stanley Black & Decker, Inc. or an affiliate thereof and are used under license.
Fill tank with fresh gas to within /-inch of top
of tank. Do not overfill. Do not use E85 or fuel
containing more than 10% Ethanol.
Pour the entire contents of the SAE 10W 30 oil
bottle (supplied) into the oil fill. Check the oil level
by inserting the dipstick (not threading it) into the
oil fill. (Refer to the Operator’s Manual)
Oil Fill
Gas Cap
Fuel Valve
Spark Plug
Boot
Rotate the fuel valve into the Open position.
While standing behind the machine, pivot the Blade
Control Handle against the upper handle.
Grasp the starter rope handle and pull with a quick,
full-arm stroke.
Make sure the spark plug boot is connected to
the spark plug before attempting to start.
1
4
3
2
5
READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.
PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.
Fast Start Guide - Engine Start
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY
and FOLLOW THE important SAFE OPERATION PRACTICES BEFORE OPERATING.
Need Help?
www.CRAFTSMAN.com or Call 1-888-331-4569
