Craftsman 917.252530 User manual

cRoFTX
MODEL NUMBER 917.252530
•Assembly
° Operation
°Customer Responsibilities
•Service and Adjustments
°Repair Parts
OWNER'S MANUAL
TM
CAUTION: Read and follow all safety rules and instructions before operating this equipment.

SAFETY RULES &
Safe Operation Practices for Ride-On Mowers
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS.
•Only allow responsible adults, who are familiar with the
instructions to operate the machine.
-Clear the area of objects such as rocks, toys, wire, etc.,
which could be picked up and thrownby the blade,
•Besure the area isclearofother people before mowing. Stop
machine if anyone enters the area.
°Never carry passengers. _ : ::::
•Do not mow in reverse unless absolutely necessary, Always
look down and behind before and while backing.
•Be aware of the mower discharge direction and do not point
it at anyone. Do not operate the mower without either the
entire grass catcher or the guard in place.
•Slow down before turning.
•Never leave a running machine unattended. Always turn off
blades, set parking brake, stop engine, and remove keys
before dismounting.
• Turn off blades when not mowing.
°Stop engine before removing grass catcher or unclogging
chute.
° Mow only in daylight or good artificial light,
•Do not operate the machine while under the influence of
alcohol or drugs ...... : ,
and the mowing activity. Never assume that children will remain
where you last saw them .... .....
• Keep children out of the mowing area and under the watchful
care of another responsible adult.
• Be alert and turn machine off if children enter the area.
°Before and when backing, look behind and down for small
children,
•Never carry children. They may fall off andbe seriously
injured or interfere with safe machine operation.
°Never allow children to operate the machine,
• Use extra care when approaching blind corners, shrubs,
trees, or other objects that may obscure vision.
IV. SERVICE : :
•Use extra care in handling gasoline and other fuels, They are
flammable and vapors are explosive,
- Use only an approved container,
- Never remove gas cap or add fuel with the engine
running. Allow engine to cool before refueling, Do not
smoke. : ....
,Never refuel the machine indoors.:
-Never store the machine or fuel :container inside where
° Watch for traffic when operating near or crossing roadways. : there is an open flame, :such as a water heater.
°Use extra care when loading or unloading the machine into " :Never run a machine ins!dea _!osed area.
a trailer or truck. _i:i: :_:::= :: ::: , :Keep nuts and bolts especially blade attachment bolts tight
...... :: :i and keep equipm_nt]rt g00d €ondition.
II. SLOPE OPERATION : :::: : : ::::i(:i:: ::ii:: : i_i i: _Never tamper with :'safety deviceS.: 'Check their proper
Slopes are a major factor reiated to loss-of-control andtipover := _i=:i _ Operationregularlyl :i: =::i:
accidents, which can All st0pes : Keeomachine free0f arass leaves or other debris build-up.
require extra caution, ifyou cannot back up the slope erif you feel ::: :c ea.n:0 or rue spi _ge: Alow 'roach ne to cool befo;'e
uneasy on it, do not mow it. I .:: : :: JiLl:i :storingii:::i :i: ::;:::::: : : :
DO: i: ::= :; ::_ : i: :, i::iStop :and inspect the:equipment :if you strike an object.
• Mow up and down slopes n0i across.::: : :: Repair!
• : : : : : : •Never make adjustments or repairs with the engine running
Remove obstacles such as rocks tree hmbs etc. :: : _ : ......
......... ,_ : .... , :,:_ :L..,_, ,::Grasscatchercomponentsaresubjecttowear, damage, and
•watcn for hOleS ruts or Dumps., uneven terral{i coulu : : _. .. :_. ,_ ....
°Use slow speed. Ch0ose a Iow gear sothat you will not have
to stop or shift while on the slope.
°Follow the manufacturer's recommendations for wheel
weights or counterweights to improve stability.
°Use extra care with grass catchers or other attachments.
These can change the stability of the machine.
• Keep all movement on the slopes slowand gradual. Do not
make sudden changes in speed or direction.
°Avoid starting or stopping on a slope. If tires lose traction,
disengage the blades and proceed slowly straight down the
slope.... i :i
DO NOT: .................
: O =::Donotturnonslopesunlessnecessary, andthen, turnlslowly
and gradually downhill, if possible ................
::Do not mow near dr0p:-0ff& ditches, or embankments. The : :ii::
•mower could suddenly turnover if a wheel is over the edge
: Ofa c!iff or ditc h,:or if an edge cayes in: _:: : : _::ii :: :
..... ' Do nOt mow onwet :grassl Reduced tracti0n could Cause
o
replace with manufacturer's recommended parts, when nec-
essary.
Mower blades are sharp and can cut. Wrap the blade(s) or
wear gloves, and use extra caution when servicing them.
Check brake operation frequently. Adjust and service as
required.
Look for this symbol to point out impor-
tant safety precautions. It means
CAUTION!!! BECOME ALERT!!! YOUR
SAFETY IS INVOLVED. ......
_.:iii::Ii:: i := CAUTIONi ::Always idisconnect Spark: ;" i
plug wire and place wire where it cannot
icontact spark plug in order to ;prevent
accidental starting when Setting :up,
;:::sliding" ::i :ii::i:: :::::::::_:: ;: : :_ : : i: _ :::: :transporting, adjusting or: making
:.... Donottrytostabi zethemachinebyputtingyourfootonthel : :: repairs: : : .: : :' :; :: ::
: : :; :D0 not use:graSs catcheron steep SlopeS: .... ::::2 : ;:::i : :::::::i :: :::::

CONGRATULATIONS on your purchase of a Sears
Tractor. It has been designed, engineered and manufac-
tured to give you the best possible dependability and
performance.
Should you experience any problem you cannot easily
remedy, please contact your nearest Sears Authorized
Service Center!Department. We have competent, well-
trained technicians and the proper tools to service or repa r
this tractor. , : ....
Please read and retain this manual, The instructions writ
enable you to assemble and maintain your unit properly.
Always observe the "SAFETY RULES".
MODEL
NUMBER 917.252530
SERIAL
NUMBER
DATEOFPURCHASE
THE MODEL AND SERIAL NUMBERS WILL BE FOUN D
ON A PLATE UNDER THESEAT.
YOU SHOULD REcoRD BOTH SERIAL NUMBER AND
DATE OF PURCHASE AND KEEP IN A SAFE PLACE
FOR FUTURE REFERENCE,
MAINTENANCE AGREEMENT
A Sears Maintenance Agreement is available on this prod-
uct, Contact your nearest Sears store for details.
CUSTOMER RESPONSIBILITIES
•Read and observe the safety ru]es.
• Follow a regular schedule in maintaining, caring for and
using your tractor.
• Follow the instructions under "Customer Responsibili-
ties" and "Storage" sections of this owner's manual.
PRODUCT SPECIFICATIONS
HORSEPOWER: 15.0
GASOLINE CAPACITY 5 QUARTS
AND TYPE: UNLEADED REGULAR
OIL TYPE (API-SF/SG): SAE 30 (above 32°F) _:
SAE 5W-30 (below 32°F)
OiL CAPACITY: 3.0 PINTS
SPARK PLUG: CHAMPION RJ-19LM
(GAP: .030") STD361458
VALVE CLEARANCE: INTAKE: .005" - .007" '
EXHAUST: .009" - .011"
GROUND SPEED (MPH): FORWARD: 5.5
REVERSE: 2.5
TiRE PRESSURE: FRONT: 14 PS!
REAR: 10 PSi
CHARGING SYSTEM: 3 AMPS BATTERY
5 AMPS HEADLIGHTS
BLADE BOLT TORQUE: 30-35 FT. LBS.
WARNING: This tractor is equipped with an internal
combustion engine and should not be used on or near any
unimproved forest-covered, brush-covered or grass-cov-
ered land unless the engine's exhaust system isequipped
with a spark arrester meeting applicable local or state laws
(if any). If a spark arrester isused, it should be maintained
in effective working order by the operator.
In the state of California the above is required by law
(Section 4442 of the California Public Rosources Code).
Other states may have similar laws. Federal iaws apply on
federal lands. A spark arrester for the muffler is available
through your nearest Sears Authorized Service Center/
Department (See REPAIR PARTS section ofthis manual).
LIMITED TWO YEAR WARRANTY ON ELECTRIC START RIDING EQUIPMENT
For two (2) years from the date of purchase, if this riding equipment is maintained, lubricated and tuned up according to the
instructions in the owner's manual, Sears wiil repair or repiace, free of charge, any parts found to be defective in material or
workmanship.
This Warranty does not cover:
•Expendable items which become worn during normal use, such as blades, spark plugs, air cleaners and belts.
•Tire replacement or repair caused by punctures from outside objects, suc h as nails, thorns, stumps, or glass.
• Repairs necessary because of operator abuse, negligence, improperstorage or accident or the failure to maintain the
equipment according to the instructions contained in the owner's manual.
• Riding equipment used for commercial or rental purposes.
LIMITED 90 DAY WARRANTY ON BATTERY ....
For ninety (90) days from date of purchase, if any battery included with this riding equipment proves defective in material or
.workmanship and our testing determines the battery will not hold a charge, Sears will replace the battery at no charge.
WARRANTY SERVICE IS AVAILABLE BY RETURNING THE RIDING EQUIPMENT TO THE NEAREST SEARS SERVICE
CENTER/DEPARTMENT iNTHE UNITED STATES.
This Warranty gives you specific tega!rights, and you may also have other rights which may vary from state to state.
SEARS, ROEBUCK AND CO., D/817 WA, HOFFMAN ESTATES, ILLINOIS 60179
