Operator's Manual
CReFT. Me.oI
AWN TRACTO'R
21.0 HP,* 46" Mower
Electric Start
Automatic Transmission
Model No.
917.28852
• Espa_ol, p. 33
I _ This product has a tow emission engine which operates
differently from previously built engines, Before you start the
engine, read and understand this Operator's Manual.
IMPORTANT:
Read and follow all Safety
Rules and Instructions before
operating this equipment.
For answers to your questions
about this product, Call:
1-800-659-5917
SEARS Craftsman Help Line
5 am - 5 pro, Mon - Sat
Gasoline containing up to 10% ethanol (El0) is acceptable for use in this machine,
The use of any gasoline exceeding 10% ethanol (El0) will void the product warrant':/,
Esta mdquina puede uUlizar gasolina con un contenido de hasta el 10% de etanol (El0).
Eluso de una gasolina que supere el 10% de etanol (El0) anutard la garantla del producto,
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U,S,A.
Visit our Craftsman website:www,sears.comicraftsman *_ rated by the engine manufacturer
584158096 Rev. 2

Warranty .................................................. 2
Safety Rules ............................................ 3
Product Specifications ............................. 6
Assembly/Pro-Operation ......................... 7
Operation ................................................. 9
Maintenance Schedule .......................... 16
Maintenance .......................................... 16
Service and Adjustments ....................... 21
Storage .................................................. 27
Troubleshooting ..................................... 28
Sears Service ......................... Back Cover
Craftsman Riding Equipment Warranty
CRAFTSMAN FULL WARRANTY
FOR TWO YEARS from the date of purchase, all non-expendable partsof this riding equipment are
warranted against any defects in material or workmanship. A defective non-expendable part will
receive free in-home repair or replacement if repair is impossible.
FOR FIVE YEARS from the date of purchase, the frame and front axle of this riding equipment are
warranted against any defects in material orworkmanship, A defective frame or front axle wilt receive
free in-home repair or replacement if repair is impossible.
FOR 90 DAYS from the date of purchase, the battery (an expendable part) of this riding equipment
is warranted against any defects in material or workmanship (our testing provesthat it will not hold a
charge). A defective battery will receive free in-home replacement.
ADDITIONAL LIFETIME LIMITED WARRANTY on CAST IRON FRONT AXLE (if equipped)
FOR AS LONG AS IT 1SUSED by the originalowner after the fifth yearfrom the date of purchase,the
cast ironfront axle (ifequipped) of thisriding equipmentiswarranted against any defects in material or
workmanship. With proof ofpurchase, adefective castfront axle willreceivefree in-home replacement.
WARRANTY SERVICE
For warranty coverage details to obtain free repair or replacement, ca!l 1-800-659-5917 or visitthe
web site: www.craftsrnan.corn
In a?lcases above, if part repair or replacement is impossible, the riding equipment will be replaced
free of charge with the same or an equivalent model.
All of the above warranty coverage is void if this dding equipment is ever used while providing
commercial services or if rented to another person.
This warranty covers ONLY defects in material and workmanship. Warranty coverage does NOT
include:
• Expendable parts (except battery) that can wear out from normal use within the warranty period,
including but not limited to blades, spark plugs, air cleaners, belts, and oilfilters.
• Standard maintenance servicing, oilchanges, or tune-ups.
• Tire replacement or repair caused by punctures from outside objects, such as nails, thorns,
stumps, or glass.
•Tire orwheel replacement or repair resulting from normal wear, accident, or improper operation or
maintenance.
• Repairs necessary because of operator abuse, including but not limited to damage caused by
towing objects beyond the capability of the riding equipment, impacting objects that bend the
frame, axle assembly or crankshaft, or ever-speeding the engine.
• Repairs necessary because of operator negligence, including but not limited to, electnca] and
mechanical damage caused by improper storage, failure to use the proper grade and amount
of engine oil, failure to keep the deck clear of flammable debris, or failure to maintain the riding
equipment according to the instructions contained in the operator's manual.
• Engine (fuel system) cleaning or repairs caused by fuel determined to be contaminated or oxidized
(stale). In general, fuel should be used within 30 days of its purchase date.
• Normal deterioration and wear of the exterior finishes, or productlabel replacement.
This warranty gives you specific legal rights, and you may afso have other rights which vary from
state to state,
Sears Brands Management Corporation, Hoffman Estates, IL 60179
2

_DANGER: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructions could result
in serious injury or death.
_WARNING: Inorderto preventacciden-
tal starting when setting up, transporting,
adjusting or making repairs, always discon-
nect spark plug wire and place wire where
it cannot contact spark plug.
_kWARNING: Do not coast down a hill in
neutral, you may lose control ofthe tractor.
_kWARNING: Tow only the attachments
that are recommended by and comply with
specifications of the manufacturer of your
tractor. Use common sense when towing.
Operate only at the lowest possible speed
when onaslope. Tooheavy ofa load, while
on a slope, is dangerous. Tires can lose
traction with the ground and cause you to
lose control of your tractor.
__WARNING: Engine exhaust, some of
itsconstituents, and certain vehicle compo-
nents contain or emit chemicals known to
the State of California to cause cancer and
birth defects or other reproductive harm.
_kWARNING: Battery posts,terminals and
related accessories contain lead and lead
compounds, chemicals knownto the Stateof
California to cause cancer and birthdefects
or other reproductive harm. Wash hands
after handling.
I, GENERAL OPERATION
•Read,understand, and follow allinstruc-
tions on the machine and in the manual
before starting.
• Do not put hands or feet near rotating
parts or under the machine. Keep clear
of the discharge opening at all times,
• Only allow responsible adults, who are
familiar with the instructions, to operate
the machine.
• Clear the area of objects such as rocks,
toys, wire, etc., which could be picked
up and thrown by the blades.
•Be sure the area is clear of bystanders
beforeoperating. Stop machineifanyone
enters the area,
• Never carry passengers.
•Do not mow in reverse unless absolutely
necessary. Always lookdown and behind
before and while backing.
w
Never direct discharged material toward
anyone. Avoid discharging material
against a wall or obstruction. Material
may ricochet back toward the operator.
Stop the blades when crossing gravel
surfaces,
Do not operate machine without the en-
tire grass catcher, discharge chute, or
othersafety devices in place andworking.
Slow down before turning.
Never leave a running machine unat-
tended. Always turn off blades, set
parking brake, stop engine, and remove
keys before dismounting.
Disengage blades when not mowing,
Shut off engine and wait for all parts to
come toa complete stop before cleaning
the machine, removingthe grass catcher,
or unclogging the discharge chute.
Operate machine onfy indaylight or good
artificial light.
Do not operate the machine while under
the influence of alcohol or drugs.
Watch for trafficwhen operating near or
crossing roadways.
Use extracarewhen loading or unloading
the machine into a trailer or truck.
Alwayswear eyeprotection when operat-
ing machine.
Data indicates that operators, age 60
years and above, are involved ina large
percentage of riding mower-related inju-
ries. These operators should evaluate
their ability to operate the riding mower
safely enough to protectthemselves and
others from serious injury.
Fol]owthe manufacturer's recommenda-
tionforwheel weights orcounterweights,
Keep machine free of grass, leaves or
other debris build-up which cantouch hot
exhaust/engine parts and burn. Do not
allow the mower to plow leaves or other
debris which can cause build-up to oc-
cur. Clean any oil or fuel spillage before
operating or storing the machine. Allow
machine to cool before storage.
3

II, SLOPE OPERATION
Slopes are a major factor related to Lossof
control and tip-over accidents, which can
result in severe injury or death. Operation
on al!slopes requires extra caution, Ifyou
cannot back upthe slope orifyou feeluneasy
on it, do not mow it,
•Mow up and down slopes, not across.
•Watch for holes, ruts, bumps, rocks, or
other hidden objects. Uneven terrain
could overturn the machine. Tall grass
can hide obstacles.
• Choose a [ow ground speed sothat you
will not have to stop or shift while on the
slope.
• Do not mow onwet grass. Tires may lose
traction.
Always keep the machine in gear when
going down slopes, Do not shiftto neutral
and coast downhill.
• Avoid starting, stopping, or turning on a
slope. Ifthetireslosetraction, disengage
the blades and proceed slowly straight
down the slope.
• Keep all movement on the slopes slow
and gradual. Do not make sudden
changes in speed or direction, which
could cause the machine to roll over.
• Use extra care while operating machine
with grasscatchers orother attachments;
they can affect the stability of the ma-
chine. Do no use on steep slopes.
• Do not try to stabilize the machine by
putting your foot on the ground.
• Do not mow near drop-offs, ditches,
or embankments. The machine could
suddenly roll over if a wheel is over the
edge or if the edge caves in.
II1.CHILDREN
_iLWARNING: CHILDRENCANBEINJURED
BYTHIS EQUIPMENT.The American Acade-
my of Pediatrics recommends that children
be a minimum of 12 year of age before op-
erating a pedestrian controlled lawn mower
and a minimum of 16 years of age before
operating a riding lawn mower.
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the machine
and the mowing activity. Never assume
that children will remain where you last
saw them.
•Keep children out of the mowing area
and in the watchful care ofa responsible
adult other than the operator.
.Be alert and turn machine off if a child
enters the area.
• Before and while backing, look behind
and down for small children.
• Nevercarrychildren, evenwiththe blades
shutoff. They mayfalloffand beseriously
injured or interfere with safe machine
operation. Children who havebeen given
rides in the past may suddenly appear in
the mowing area for another rideand be
runover or backed over by the machine.
• Never a]!ow children to operate the ma-
chine,
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may block your view of a child.
IV. TOWING
• Tow only with amachine that has ahitch
designed fortowing. Donot attach towed
equipment except at the hitch point,
• Followthe manufacturer's recommenda-
tion for weight limits for towed equipment
and towing on slopes.
• Never allow children or others in or on
towed equipment.
• On slopes,theweightofthetowedequip-
ment may cause loss oftraction and toss
of control.
•Travel slowly andallowextra distance to
stop.
V. SERVICE
SAFE HANDLING OF GASOLINE
To avoid personal injury or property dam-
age, use extreme care in handling gasoline.
Gasoline is extremely flammable and the
vapors are explosive,
• Extinguish all cigarettes, cigars, pipes,
and other sources of ignition.
• Use only approved gasoline container.
- Never remove gas cap or add fuel with
the engine running, Allow engine to cool
before refueling.
- Never fuelthe machine indoors,
• Never store the machine orfuel container
where there is an open flame, spark, or
pilot light such as on a water heater or
other appliances.
•Never fill containers inside a vehicle or
on atruck ortrailer bed with plastic liner.
Always place containers on the ground
away from your vehicle when filling.

° Removegas-poweredequipmentfrom
thetruckortrailerandrefuelitonthe
ground.Ifthisisnotpossible,thenrefuel
suchequipmentwithapor_biecontainer,
ratherthanfromagasolinedispenser
nozzle.
• Keepthenozzleincontactwiththerim
ofthefueltankorcontaineropeningat
alltimes untilfueling is complete. Do not
use a nozzle lock-open device.
• Iffuel isspilled onclothing, change cloth-
ing immediately,
° Never overfill fuel tank. Replace gas cap
and tighten securely.
GENERAL SERVICE
°Neveroperate machine in aclosed area.
•Keepallnuts andboltstightto besurethe
equipment is in safe working condition,
• Nevertamperwithsafetydevices. Check
their proper operation regularly,
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel
spillage and remove any fuel-soaked de-
bris. Allow machineto cool beforestoring.
• tf you strike a foreign object, stop and
inspectthe machine, Repair,ifnecessary,
before restarting.
•Never make any adjustments or repairs
with the engine running.
• Checkgrass catchercomponents andthe
discharge chute frequently and replace
with manufacturer's recommended parts,
when necessary.
• Mower blades aresharp. Wrap the blade
or wear gloves, and use extra caution
when servicing them.
• Check brake operationfrequently. Adjust
and service as required.
•Maintain orreplace safety and instruction
labels, as necessary,
• Be sure the area is clear of bystanders
beforeoperating. Stop machine ifanyone
enters the area.
• Never carry passengers,
, Do not mow in reverse unless absolutely
necessary.Always lookdown andbehind
before and while backing,
• Never carry children, even with the
blades shut off. They may fall off and
beseriously injured or interfere with safe
machine operation. Children who have
beengiven rides inthe past may suddenly
appear in the mowing area for another
ride and be run over or backed over by
the machine.
• Keep children out of the mowing area
and in the watchful care ofa responsible
adult other than the operator,
° Be alert and turn machine off if a child
enters the area.
Before and while backing, look behind
and down for small children.
• Mow up and down slopes (15° Max), not
across.
•Choose alow ground speed so that you
will not have to stop or shift while on the
slope.
o Avoid starting, stopping, or turning on a
slope, lfthetires Iosetraction, disengage
the blades and proceed slowly straight
down the slope.
. If machine stops while going uphill,
disengage blades, shift into reverse and
back down slowly.
• Do not turn on slopes unless necessary,
and then, turn slowly and gradually
downhill, if possible.
• When loading orun]oadingthis machine,
do not exceed the maximum recom-
mended operation angle of 15°.

PRODUCT SPECIFICATIONS
Gasoline Capacity 2.5 Gallons/9,46 L
and type: ............ Regular Un!eaded
Oii Type: SAE30 (above32° F!'0°C
(API: SG-SL) SAE SW30 (below ;32°F/0°C
Oil Capacity: W/Filter: 56 Oz.I1,65 L
W/out Filter: 48 Oz./1,4 L
Spark Plug: Champion RCt 2YC
(Gap: .030"/0,76 turn)
Charging 3 Amps Battery
System: 5 Amps Headlights
Battery: Amp/Hr: 28
Min. CCA: 230
Case size: UIR
Blade Belt Torque: 45-55 Ft. Lbs.i62-75 Nm
CONGRATULATIONS on your purchase of
a new tractor. It has been designed, engi-
neeredand manufacturedto giveyouthe best
possible dependability and performance.
Shouldyou experience anyproblemyou cam
noteastly remedy, please contact aSears or
other qualified service center. Wehave com-
petent, well-trained representatives andthe
proper tools to service or repair this tractor.
Please read and retain this manual. The
instructions wilt enable you to assemble
and maintain,your tractor properly. Always
observe the SAFETY RULES.
CUSTOMER RESPONSIBILITIES
•Read and observe the safety rules.
• Follow a regular schedule inmaintaining,
caring for and using your tractor,
• Follow instructions under "Maintenance"
and "Storage" sections ofthis manual.
•Wear proper Personal Protective Equip-
ment (PPE)while operating this machine,
including (ata minimum) sturdy footwear,
eye protection, and hearing protection.
Do not mow in shorts and/or open toed
footwear.
• Always let someone knowyou areoutside
mow=rig.
_WARNING: This tractor is equipped with
an internal combustion engine and should
not be used on or near any unimproved
forest-covered, brush-covered or grass-
covered land unless the engine's exhaust
system is equipped with a spark arrester
meeting applicable local or state laws (if
any). If a spark arrester is used, it should
be maintained in effective working order by
the operator.
Inthe state ofCaliforniathe above isrequired
bylaw (Section 4442 ofthe California Public
Resources Code). Other states may have
similar laws, Federal laws apply on federal
lands. A spark arrestor for the muffler is
availablethroughyour nearestSearsservice
center (See REPAIR PARTS manual).
REPAIR PROTECTION AGREEMENTS
Congratutatk_ns on making a smart pur-
chase, Your new Craftsman® product is
designed and manufactured for years of
dependable operation. But like all products,
it may require repairfromtimetotime. That's
when having aRepair Protection Agreement
can save you money and aggravation.
Purchase a Repair Protection Agreement
now and protect yourself from unexpected
hassle and expense.
Here's what's included inthe Agreement;
• Expertservice byour 12,000professional
repair specialists.
•Unlimited serviceand nochargefor parts
and labor on all covered repairs.
• Product replacement if your covered
product can't be fixed.
•Discount of 10% from regular price of
service and service-related parts not
covered bythe agreement; also, 10% off
regular price of preventive maintenance
check.
• Fast help by phone -phone support
from aSears representative on products
requiring in-home repair,plusconvenient
repair scheduling,
Once you purchase the Agreement, a simple
phone call isall that ittakes for you tosched-
uleservice. Youcan callanytime day or night,
or schedule a service appointment online.
Sears has over 12,000 professional repair
specialists, who have access to over 4,5
million quality parts and accessories. That's
the kind ofprofessionalism you can counton
to help prolong the life ofyour new purchase
for years to come, Purchase your Repair
Protection Agreement today!
Some limitations and exclusions apply.
Forpricesand additional information call
1-800-827-6655.
SEARS INSTALLATION SERVICE
For Sears professional installation of home
appliances, garage door openers, water
heaters, and other major home items, in the
U,S.A. call 1-800-4-MY-HOME®

Keys
Connect
Slope Sheet
Your new tractor has been assembled at the factory with the exception of those parts left
unassembled for shipping purposes.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly
easier. Standard wrench sizes are listed.
(1) 1/2" wrench Tire pressure gauge
(2) 7/16" wrenches UtUityknife
Pliers
When right or left hand is mentioned in this
manual,itmeanswhenyouareintheoperating
position (seated behind the steering wheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACK CARTON
•Remove all accessible loose parts and
parts cartons from carton.
• Cut along dotted lines on aJ]four pan-
els of carton. Remove end panels and
lay side panels flat.
• Check for any additional loose parts or
cartons and remove.
BEFORE REMOVING TRACTOR
FROM SKID
TO CHECK BATTERY
1. Lift seat to raised position,
NOTE: Ifthis batteryis put intoservice after
month and year indicated on label (label is
located between terminals) charge battery
forminimum ofone hour at6-10 amps. (See
"BAKERY" in Maintenance section ofthis
manual for charging instructions).
For battery and battery cable installation
see "REPLACING BATTERY" in the
"Service andAdjustments" section inthis
manual.
Label
ADJUST SEAT
1. Sit in seat,
2, Liftupadjustment lever(A)and sfide seat
until a comfortable position is reached
which allows you to press clutch/brake
pedal all the way down.
3. Release lever to lock seat in position,
7

NOTE:Youmaynowrollyourtractoroffthe
skid,Continueusingtheinstructionsthat
followtoremovethetractorfromtheskid,
A WARNING:Beforestarting,read,un-
derstandandfollowallinstructionsinthe
Operationsectionofthismanual,Besure
tractorisinawell-ventilatedarea.Besure
theareainfrontoftractorisclearofother
peopleandobjects.
TO ROLL TRACTOR OFF SKID (See
Operation section for location and
function of controls)
1. Raise attachment lift lever to its highest
position.
2. Release parking brake by depressing
clutch/brake pedal.
3. Place freewheel control in "transmission
disengaged position" (See "TO TRANS-
PORT" in the Operation section of this
manual).
4, Roll tractor forward off skid,
5. Remove banding holding the deflector
shield up against tractor,
Continue with the instructions that follow.
CHECK TIRE PRESSURE
The tires on yourtractor were overinflatedat
the factory for shipping purposes. Correct
tire pressure Is important for best cutting
performance,
, Reduce tire pressure to PSI shown on
tires,
CHECK DECK LEVELNESS
For best cutting results, mower housing
should beproperly leveled. See TO LEVEL
MOWER" in the Service and Adjustments
section ofthis manual.
CHECK FOR PROPER POSITION OF
ALL BELTS
See the figures that are shown for replacing
motion and mower blade drive belts in the
Serviceand Adjustments section ofthisman-
ual.Verify that the belts are routed correctly.
CHECK BRAKE SYSTEM
After you learn how to operate your tractor,
check to see that the brake is operating
properly. See "TO CHECK BRAKE" in the
Service and Adjustments section of this
manual.
,/O.FCK',S
Before you operate your new tractor, we
wish to assure that you receive the best
performance and satisfaction from this
Quality Product.
Please review the following checklist:
J Al! assembly instructions have been-
completed.
t/" No remaining looseparts in carton.
J" Batteryis propedy prepared andcharged.
t/" Seat is adjusted comfortably and tight-
ened securely.
Vf All tires are properly inflated. (For ship-
pingpurposes, the tires were overinflated
at the factory).
VI Be sure mower deck is properly leveled
side-to-sideifront-to-rear for best cutting
results. (Tires must be properly inflated
for leveling).
v/' Check mower and drive belts. Be sure
they are routed properly around pulleys
and insideall belt keepers,
t/" Check wiring. See that all connections
are still secure and wires are properly
clamped.
vzBefore driving tractor, be sure freewheel
control is in transmission engaged"
position (see "TO TRANSPORT" in the
Operation section of this manual),
While learninghowto useyourtractor,payex-
traattention tothe following important items:
_ Engine oil is at proper level.
Fueltank isfilled with fresh, clean, regular
unleaded gasoline.
v/" Become familiar with all controls, their
location and function. Operate them
before you start the engine.
VfBesurebrake system isin safe operating
condition,
V_ Be sure Operator Presence System and
Reverse Operation System (ROS) are
working properly (See theOperation and
Maintenance sections in this manual).
v/' It isimportant to purge the transmission
before operating your tractor for the
first time. Follow proper starting and
transmission purging instructions (See
"TO START ENGINE and 'PURGE
TRANSMISSION" in the Operation sec-
tion of this manual),
8

Thesesymbolsmayappearonyourtractororinliteraturesuppliedwiththeproduct.Learn
andunderstandtheirmeaning.
R N H L I',,!
REVERSE NEUTRAL HIGH LOW CHOKE FAST SLOW
ENGINE OFF REVERSE ENGINE ON ENGINE START PARKING BRAKE MOWER HNGHT
OPERATION
SYSTEM (RO_
UGhTS ON FUEL BA'ri'ERY
ATTACHMENT ATTACHMENT
CLUTCH DISENGAGED CLUTCH ENGAGED
FREE WHI_EL
(Automatic Models onLy)
Failure to follow instructions
could result in serious injury or
death. The safety alert symbol
is used to identify safety inform-
ation about hazards which can
result in death, serious injury
and/or property damage.
IGNITION SWITCH
MOWER UFT
÷
REVERSE FORWARD
DANGER_ KEEP HANDS
AND FEST AWAY
_D_D•_(_o
CRUISE cowrROL CLUTGWBRAKE
PEDAL
KEEP AREA CLEAR SLOPE HAZARDS
(SEE SAFETY RULES SECTION)
DANGER indicates ahazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious Injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION when used without the alert symbol,
indicates a situation that could result in damage
to the tractor and!or engine.
HOT SURFACES indicates ahazard which,
if not avoided, could result in death, serious injury
and/or property damage.
j_ IRE indicates _,hazard which, if not avoided, ;
could result in death, serious injury and/or
property damage.

KNOW YOU R TRACTOR
READ THIS MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR
Compare the illustrations with your tractor to familiarize yourself withthe locations of
various controls and adjustments. Save this manual for future reference,
Our tractors conform to the applicable safety standards of the
American National Standards Institute.
(A) ATTACHMENT LIFT LEVER - Used to
raise and lower the mower or other attach-
merits mounted to your tractor.
(B) CLUTCH/BRAKE PEDAL - Used for
declutching and braking the tractor and
starting the engine.
(C) PARKING BRAKE- Locks clutch/brake
pedal into the brake position.
(D) THROTTLE/CHOKE CONTROL- Used
for starting and controlling engine speed.
(E) ATTACHMENTCLUTCH LEVER-Used
to engage the mower blades, orother attach-
merits mounted to your tractor.
(F) IGNITION SWITCH - Used for starting
and stopping the engine.
(G) REVERSE OPERATION SYSTEM
(ROS) "ON" POSITION - Allows operation
of mower or other powered attachment while
in reverse,
(H) LIGHT SWITCH - Turns the headlights
on and off.
(J) MOTION CONTROL LEVER - Selects
the speed and direction of tractor,
(M) FREEWHEEL CONTROL- Disengages
transmission for pushing or slowfytowing the
tractor with the engine off.
10

The operation of any tractor can result in foreign objects thrown into t
the eyes, which can result in severe eye damage. Always wear safety I
glasses or eye shields while operating your tractor or performing any I
adjustments or repairs. We recommend standard safety glasses or a I
wide vision safety mask worn over spectacles. I
HOW TO USE YOUR TRACTOR
TO SET PARKING BRAKE
Your tractor is equipped with an operator
presence sensing switch, When engine is
running, any attempt bythe operator toleave
theseat without first settingthe parking brake
wilt shut off the engine,
1. Depress clutch/brake pedal (B) all the
way down and hold,
2, Pullparkingbrake lever (C) up and hold,
release pressure from clutch/brake pedal
(B),thenrelease parking brakelever.Ped-
alshould remainin brakeposition. Ensure
parking brake will hold tractor secure.
STOPPING
MOWER BLADES -
•Tostop mower blades, move attachment
clutchcontrolto disengaged position (_'_).
ENGINE -'
• Move throttle control (D) to fast position.
NOTE: Failureto movethrottle control tofast
position before stopping may cause engine
to "backfire",
•"SJrnignition key (F) to "STOP" position
andremove key.Always remove keywhen
leavingtractorto preventunauthorized use.
• Never use choke to stop engine.
IMPORTANT: Leaving the ignitionswitch in
anyposition otherthan "STOP"will causethe
battery to discharge and go dead,
NOTE: Undercertain conditions whentractor
isstanding idlewith the engine running, hot
engine exhaust gases may cause "brown-
ing"of grass. To eliminate this possibility,
always stop engine when stopping tractor
on grass areas,
CAUTION: Always stop tractor com-
pletely, as described above, before leaving
the operator's position.
TO USE THROTTLE CONTROL (D)
Always operate engine at full speed (fast).
•Operating engine at less than full speed
(fast)reducesengine'soperatingefficiency.
• Full speed (fast) offers the best mower
performance.
(I_1) Attachment (1'_) Attachment
Clutch Control Clutch COntrol
"Engaged .... Disengaged"
GROUND DRIVE -
• To stop ground drive, depress brake pedal
all the way down.
• Move motion control lever to neutral
position.
11

TO MOVE FORWARD AND
BACKWARD
The direction and speed of movement is
controlled bythe motion control lever. (J)
1. Start tractor with motion control lever in
neutral position,
2. Release parking brake.
3. Slowly move motion control lever to
desired position.
TO ADJUST MOWER CUTTING HEIGHT
The position of the attachment lift lever (A)
determines the cutting height.
• Put attachment lift lever in desired cutting
height slot.
• Slidepointertab (T)todesired cuttingheight
as a reminder for next time you mow.
The cutting height range is approximately 1
to 4" (25,4 to 101,6 mm). The heights are
measured from the ground to the blade tip
with the engine not running, These heights
are approximate and may vary depending
upon soil conditions, height of grass and
types of grass being mowed.
• The averagelawn should becutto approxi-
mately 2-1/2" (63,5 mm) during the cool
season and to over 3" (76,2 mm) during
hot months. For healthier and better look-
ing lawns, mow often and after moderate
growth,
• For best cutting performance, grass over
6" (152,4 mm) in height should be mowed
twice. Make the first cutrelatively high; the
second to desired height.
TO ADJUST GAUGE WHEELS
Gauge wheels are properly adjusted when
they areslightly offthe ground when mower
is at the desired cutting height in operating
position. Gauge wheels then keep the deck
in proper position to help prevent scalping
in most terrain conditions.
NOTE: Adjust gauge wheels with tractor on
aflat level surface.
1. Adjust mower to desired cutting height
(See "TO ADJUST MOWER CUI-rlNG
HEIGHT" in this section of manual).
2. With mower indesired height ofcut posi-
tion, gauge wheels should beassembled
sothey areslightly off the ground. Install
gauge wheel in appropriate hole.Tighten
securely.
3. Repeat for all, installing gauge wheel in
same adjustment hole,
TO OPERATE MOWER
Your tractor is equipped with an operator
presence sensing switch. Any attempt
by the operator to leave the seat with the
engine running and the attachment clutch
engaged will shut off the engine, You must
remain fully and centrally positioned in the
seat to prevent the engine from hesitating or
cutting off when operating your equipment
on rough, rolling terrain or hills,
1. Select desired height of cut with attach-
ment liftlever.
2. Start mower blades byengaging attach-
ment clutch control.
TO STOP MOWER BLADES
Disengage attachment clutch control.
_I_CAUTION: Do not operate the mower
without either the entire grass catcher, on
mowers soequipped, orthe deflector shield
in place.
12

REVERSE OPERATION SYSTEM (ROS)
Your tractor is equipped with a Reverse
Operation System (ROS). Any attempt by
the operator totravel inthe reverse direction
withthe attachment clutch engaged will shut
off the engine unless ignition key is placed
inthe ROS "ON" position.
_kWARNING: Backing up with the at-
tachment clutch engaged while mowing is
stronglydiscouraged. Turningthe ROS "ON",
to allow reverse operation with the attach-
ment clutch engaged, should only be done
when the operator decides it isnecessary to
reposition the machine with the attachment
engaged, Do not mow in reverse unless
absolutely necessary.
USING THE REVERSE OPERATION
SYSTEM -
Ontyuseifyouarecertain nochildren orother
bystanders wilt enter the mowing area.
1. Move motion control lever to neutral
position.
2. With engine running, turn ignition key
counterclockwise to ROS "ON" posi-
tion.
3. Lookdown and behind before and while
backing.
4. Slowly move motion control lever to
reverse (R) position to start movement.
5. When useofthe ROSis noIongerneeded,
turn the ignitionkey clockwise to engine
"ON" position.
ROS "ON" Position Engine "ON" Position
(Normal Operating)
TO OPERATE ON HILLS
_kWARNING: Do not drive up or down
hillswith slopes greater than 15° and do not
drive across any slope. Use the slope guide
provided at the back of this manual.
• Choose the slowestspeed beforestarting
up or down hills.
• Avoid stopping or changing speed on
hills.
•Ifstopping is absolutely necessary, push
clutch/brake pedalquicklytobrake position
and engage parking brake.
• Move motion control lever to neutral posi-
tion.
IMPORTANT: The motion control lever does
not return toneutral position when the clutch/
brake pedal is depressed.
• Torestart movement, slowly release park-
ing brake and clutch/brake pedal.
• Slowly move motion control lever toslow-
est setting.
• Make all turns slowly.
TO TRANSPORT
When pushing or towing your tractor, be
sure to disengage transmission by placing
freewheel control in freewheeling position.
Free wheel control is located at the rear
drawbar of tractor.
• Raise attachment lift to highest position
with attachment lift control.
• Pull freewheel control out and intothe slot
andrelease so it is held inthe disengaged
position.
• Do not push or tow tractor at more than
two (2) mph (3,2 kmih)o
• Toreengage transmission, reverse above
procedure.
TRANSMISSION ENGAGED
TRANSMISSION DISENGAGED
NOTE: To protect hood from damage when
transporting yourtractor on atruck oratrailer,
besure hoodisclosed and secured totractor,
Use an appropriate means of tying hood to
tractor (rope, cord, etc.),
TOWING CARTS AND OTHER ATTACH-
MENTS
Tow only the attachments that are recom-
mended by and comply with specifications
of the manufacturer of your tractor. Use
common sense when towing. Too heavy of
aload,while on a slope, isdangerous. Tires
can lose traction with the ground and cause
you to lose control of your tractor.
13

BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
The engine inyour tractor hasbeen shipped
from the factory already filled with summer
weight oi!,
1. Check engine oil with tractor on level
ground.
2. Remove oil fill cap!dipstick and wipe
clean,reinsertthe dipstick and screw cap
tight, wait for afew seconds, remove and
read oil level. If necessary, add oil until
"FULE' mark on dipstick is reached. Do
not overfill.
•For cold weather operation you should
change oil for easier starting (See the oil
viscosity chart inthe Maintenance section
ofthis manual).
• Tochange engine oil, seethe Maintenance
section in this manual.
ADD GASOLINE
• Fill fuel tank to bottom of filler neck. Do
not overfill. Use fresh, clean, regular
gasoline with a minimum of 87 octane.
Do not mix oil with gasoline. Purchase
fuel in quantities that can be used within
0 days to ensure fuel freshness.
CAUTION:Wipe oftanyspilled oilorfuel.
Do not store, spill or use gasoline near an
open flame.
IMPORTANT: When operating in tempera-
tures below 32°F (0°C), use fresh, clean
winter grade gasoline to help ensure good
cold weather starting.
CAUTION: Alcohol blended fuels (called
gasohol or using ethanol or methanol) can
attract moisture which leads to separation
and formation ofacids during storage. Acidic
gas candamage thefuel system ofanengine
while in storage. To avoid engine problems,
the fuel system shou/d be emptied before
storage of 30 days or longer, Drain the gas
tank, start the engine and let it run until the
fuel lines and carburetor are empty. Use
freshfuel nextseason. SeeStorage Instruc-
tions for additional information. Never use
engine or carburetor cleaner productsin the
fuel tank or permanentdamage may occur.
Fuelstabilizer isan acceptable alternative in
minimizing the formationoffuel gumdeposits
during storage. Add stabilizer to gasoline in
fuel tank orstorage container. Always follow
the mix ratio found on stabilizer container.
Runengine at least 10 minutes after adding
stabilizer to allow the stabilizer to reach the
carburetor. Do not empty the gas tank and
carburetor if using fuel stabilizer.
14
TO START ENGINE
When starting the engine for the first time or
if the engine has run out of fuel, it will take
extra cranking time to move fuel from the
tank to the engine.
1. Sit onseat in operating position, depress
clutch/brake pedaland setparking brake.
2. Ptace gear shift leverin neutral position.
3. Move attachment clutch to disengaged
position.
4. Move throttle control to choke position,
NOTE: Before starting, read the warm and
cold starting procedures below,
5. Insert key into ignition and turn key
clockwise to start position and release
keyas soon as engine starts. Do not run
starter continuously for more than fifteen
seconds per minute. If the engine does
not start after several attempts, move
throttle control to fast position, wait a
few minutes andtry again, tf engine still
does not start, move the throttle control
back to the choke position and retry.
WARM WEATHER STARTING
(50°F (10°C) and above)
6. When engine starts, move the throttle
control to the fast position.
*The attachments and ground drive
can now be used, Ifthe engine does
not accept the load, restart the engine
andallow it to warm upfor one minute
using the choke as described above.
COLD WEATHER STARTING
(50°F (10°C) and below)
6, When engine starts, leavethrottle control
in choke position until engine warms up
and begins to run roughly. Once rough
running begins, immediately move the
throttlecontroltothe fast position, Engine
warm-up maytake from several seconds
to several minutes (the colder the tem-
perature, the longer the warm-up).
, The attachments can also be used
during the engine warm-up period.

PURGE TRANSMISSIO N
_kCAUTION: Never engage or disengage
freewheel lever while the engine isrunning.
Toensureproperoperationand performance,
it is recommended that the transmission be
purged before operating tractor for the first
time.This procedurewill removeanytrapped
air inside the transmission which may have
developed during shipping of your tractor.
IMPORTANT: Should your transmission
require removal for service or replacement,
itshould bepurged after reinstallation before
operating the tractor.
1. Place tractor safely on a level surface -
that is clear of objects and open - with
engine off and parking brake set.
2. Disengage transmission by placing
freewheel control indisengaged position
(See "TO TRANSPORT" in this section
of manual).
3. Sitting in the tractor seat, start engine,
After the engine is running, movethrottle
control to slow position. With motion
control lever in neutral position, slowly
disengage clutch/brake pedal.
_I_CAUTtON: At any time, during step 4,
there may bemovement of the drive wheels.
4. Move motion control lever to full forward
position and hold for five (5) seconds.
Move lever to full reverse position and
hold for five (5) seconds. Repeat this
procedure three (3) times.
5. Movemotion control leverto neutral posi-
tion. Shutoifengine andset parkingbrake.
6. Engage transmission by placing free-
wheel control in engaged position (See
"TO TRANSPORT" in this section of
manual).
7, Sitting in the tractor seat, start engine.
Afterthe engine is running, movethrottle
control to haft (1/2) speed. With motion
control lever in neutral position, slowly
disengage clutch/brake pedal.
8, Slowlymove motioncontrol leverforward,
after the tractor moves approximately
five (5)feet (1,5 m), slowly move motion
control lever to reverse position. After
the tractor moves approximately five
(5)feet (1,5 m)return the motion control
leverto the neutral position. Repeat this
procedure with the motion control lever
three (3) times.
Your transmission is now purged and now
ready for normal operation,
MOWING TIPS
. DO NOT use tire chains when the mower
housing is attached to tractor.
•Mowershould be properly leveled for best
mowing performance. See "TO LEVEL
MOWER HOUSING" in the Service and
Adjustments section of this manual,
- The left hand side of mower should be
used for trimming.
•Drive sothat clippings are discharged onto
the area that has already been cut, Have
the cut areato the rightof the tractor. This
will result in a more even distribution of
clippings and more uniform cutting.
oWhen mowing large areas, start byturning
tothe right so that clippings will discharge
away from shrubs, fences, driveways,
etc, After one ortwo rounds, mow in the
opposite direction making left hand turns
untilfinished.
f
• If grass is extremely tall, it should be
mowed twice to reduce load and possible
fire hazard from dried clippings. Make
first cut relatively high; the second to the
desired height.
. Do not mow grass when it is wet. Wet
grass will plug mower and leave undesir-
able clumps. Allow grass to dry before
mowing.
• Always operate engine at full throttle
when mowing to assure better mow-
ing performance and proper discharge
of material. Regulate ground speed by
selecting a low enough gear to give the
mower cutting performance aswel! asthe
quality of cut desired.
-When operating attachments, select a
ground speed that willsuit the terrain and
give best performance ofthe attachment
being used.
15

MAIN'rEN_NcE
SCHEDULE
Check BraXe Ol_erat_on
IT Pcess_re .............
Check Ttre
RCheckOperator Presence& ROSSysteme
Check for LOOSe FasIeners
_! ChecPJReplace Mower B,adgs
TLU brie_ien Chart
0Check Battery Level
RCleaneatery_dT,rmi.ai',
Clean Debt;s,Olf Steer_ PIate
Check Trensaxle Cooling
Check Mower Levelnes s
Check V-Belts
Check En!qineOil Level ...........
Change Engine Oii (models with oil filter}
E Change EnOine Oil (models without el| filter)
NiCleanAirF_lter
,Clean Air Screen
|:Inspect MuffledSpark Attester I
NIRepEece OiI Filter (If equipped)
Elcio_ E.gt.oCooling Rns
Replace Spark PIu_l ................
Repla_e A_r Filler Paper Cartridge
............Replace FtJe! F!#tar ...........
'"B'EFORE "EVERY
EACH 8
USE ROUR_
............._v_ V
I/ v'
V'
V'
_5 50 100
HOUR_ HOURS HOUR_
v'
EVERY BEFOre
_SON STORAGE
v'
I,
v"
v'
v' v-
_' I
GENERAL RECOMMENDATIONS
The warranty on this tractor does not cover
items that have been subjected to operator
abuse or negligence. To receive full value
from the warranty, operator must maintain
tractor as instructed in this manual.
Some adjustments will need to be made
periodicallyto properly maintain your tractor,
At least once a season, check to see if
you should make any of the adjustments
described in the Service and Adjustments
section of this manual.
•At least once a year you should replace
the spark plug, clean or replace air filter,
and check blades and belts for wear. A
new spark plug and clean air filter assure
proper air4uel mixture and help your en-
gine run better and last longer,
LUBRICATIONCHART
_Steering PivotBoits
Spindle---1_1_- 10)Spindle
zor, zo,.
(_FrontIf u'-_ _, -. t[.,a _ "
Whee _ _ 1%._\. t_-_ _dD Front
Bead! _;_. _:L_,_.X j_ Wheel
. ng /A_ ..... _X._..,. Bearing
z_erK _-\\"_ Zerk
(DSteering" _ _ ',_.X
Sector i i I ;i: I I I \
•oeth
(_General Purpose Grease
@Refer to Maintenance "ENGINE" Section
BEFORE EACH USE
t, Check engine oil level.
2, Check brake operation.
3. Check tire pressure,
4, Check operator presence and
ROS systems for proper operation.
5. Check for loose fasteners,
IMPORTANT: Do not oit or grease the pivot
points which have special nylon bearings,
Viscous lubricants will attract dust and dirt
that wiltshorten the lifeofthe self-lubricating
bearings, lfyou feel they must belubricated,
use only a dry, powdered graphite type
lubricant spadngfy,
16

TRACTOR
Alwaysobservesafetyruleswhenperform-
inganymaintenance.
BRAKEOPERATION
Iftractorrequiresmorethan5feet(1,5m)
tostopathighestspeedinhighestgearon
alevel,dryconcreteor paved surface, then
brake must be serviced. (See "TO CHECK
BRAKE" in the Service and Adjustments
section of this manual).
TIRES
• Maintain proper air pressure in all tires
(See the side of tires for proper PSI.)
• Keep tires free of gasoline, oil, or insect
control chemicals which can harm rubber.
• Avoid stumps, stones, deep ruts, sharp
objects and other hazards that may cause
tire damage.
NOTE: To seal tire punctures and prevent
flat tires due to slow leaks, tire sealant may
be purchased from your local parts dealer.
Tire sealant also prevents tire dry rot and
corrosion.
OPERATOR PRESENCE SYSTEM AND
REVERSE OPERATION SYSTEM (ROS)
Be sure operator presence and reverse
operation systems are working properly. If
your tractor does not function as described,
repair the problem immediately.
. The engine should not start unless the
brake pedal is fully depressed, and the
attachment clutch control is in the disen-
gaged position.
CHECK OPERATOR PRESENCE SYSTEM
• When the engine is running, any attempt
by the operator to leave the seat without
first settingthe parking brake should shut
off the engine.
• When the engine is running and the at-
tachment clutch is engaged, any attempt
by the eperator to leave the seat should
shut off the engine.
• The attachment clutch should never oper-
ate unless the operator is in the seat,
CHECK REVERSE OPERATION (ROS)
SYSTEM
• Whenthe engine isrunningwiththe ignition
switch inthe engine "ON"position andthe
attachment clutch engaged, any attempt
by the operator to drive in reverse should
shut off the engine.
• Whenthe engineis runningwiththe ignition
switch in the ROS "ON" position and the
attachment clutch engaged, any attempt
bythe operator todrive in reverse should
NOT shut off the engine.
Ros "On" Engine "On" Position
Position (Normal Operating)
BLADE CARE
Forbest resultsmower blades must besharp.
Replace worn, bent or damaged blades.
_L_CAUTION:Use onlyareplacement blade
approved bythe manufacturer ofyour tractor.
Using a blade not approved by the manu=
facturer of your tractor is hazardous, could
damage yourtractor andvoid your warrants/.
BLADE REMOVAL
1. Raise mower to highest position to a!low
access to blades.
NOTE: Protect your hands with gloves and/
or wrap blade with heavy cloth.
2. Remove blade bolt by turning counter-
clockwise.
3. Install new blade with stamped "GRASS
SIDE" facing the ground.
IMPORTANT: To ensure proper assembly,
center hole in blade must align with star on
mandrel assembly.
4. Install and tighten blade bolt securely
(45-55 Ft. Lbs./62-75 Nm).
IMPORTANT: Special blade bolt is heat
treated.
MandrelAssembl
Blade
\_" Blade Bolt
(Special)
17

TOCLEANBATTERYANDTERMINALS
Corrosionanddirtonthebatteryandterminals
cancausethebatteryto"leak"power.
1.Removeterminalguard.
2.DisconnectBLACKbatterycablefirst
thenREDbatterycableandremove
batteryfromtractor.
3.Rinsethebatterywithplainwaterand
dry.
4. Clean terminals and battery cable ends
with wire brush until bright.
5. Coat terminals with grease or petroleum
jelly.
6, Reinstall battery (See "REPLACING
BATTERY" in the Service and Adjust-
ments section of this manual).
V-BELTS
CheckV-betts fordeterioration andwear after
100hours ofoperation and replace if neces-
sary. The belts are not adjustable. Replace
belts if they begin to slip from wear.
TRANSAXLE COOLING
Thetransmission fan andcoolingfins should
be kept clean to ensure proper cooling,
Do not attempt to clean fan or transmission
while engine is running or while the trans-
mission is hot. Toprevent possible damage
to seals, do not use high pressure water or
steam to clean transaxle.
• Inspect cooling fan to ensure fan blades
are intact and clean.
• Inspect cooling fins fordirt,grass clippings
and other materials. To prevent damageto
seals, do not use compressed air or high
pressure sprayer to clean cooling fins.
TRANSAXLE PUMP FLUID
The transaxle was sealed at the factory and
fluid maintenance is not required for the life
of the transaxle. Should the transaxle ever
leak or require servicing, contact your near-
est Sears or other qualified service center.
ENGINE
LUBRICATION
Only usehighqualitydetergent oilrated with
API service classificationSG-SL Sefectthe
oil'sSAE viscositygrade according to your
expected operatingtemperature.
SAE VISCOSITY GRADES
loo
TEMP:Ep, ATU RE RA_E ANTICI PAIT_D BEFORE NEXT OIL C_G.E
NOTE: Although multi-viscosity oils (5W30,
10W30etc.)improvestarting incold weather,
they wiUresult in increased oil consumption
when used above 32°F/0°C. Check your
engine oil level more frequentlyto avoid pos-
sibleengine damage from running low onoil,
Changethe oi!after every50 hours ofopera-
tion or at least once a year ffthe tractor is
not used for 50 hours in one year,
Check the crankcase oil level before starting
the engine and after each eight (8) hours
of operation. Tighten oil fill cap/dipstick
securely each time you check the oil level.
TO CHANGE ENGINE OIL
Determine temperature range expected
before oil change. All oil must meet API
service classification SG-SL.
-Be sure tractor is on level surface,
• Oil will drain more freely when warm,
• Catch oit in a suitable container.
1, Remove oit fill cap!dipstick. Be careful
not to altow dirt to enter the engine when
changing oil,
2. Slide oildrain extension fromthe docking
position on the engine blower housing
and extend outward from engine.
_oOCking
sition OilDrain
3. Toopen, twist cap counter-clockwise
4. After oil is drained completely, replace
cap and twist clockwise until it stops.
5, Re-attach oil drain extension to engine
blower housing.
6. Refillengine withoil through oil filldipstick
tube. Pour slowly. Do not overfill. For ap-
proximatecapacity see "PRODUCT SP-
ECIF1CATIONS"section of this manual.
7. Use gauge on oil fill cap/dipstick for
checking level, For accurate reading,
tighten dipstick cap securely onto the
tube before removing dipstick. Keep oil
at "FULE' tine on dipstick. Tighten cap
onto the tube securely when finished.
18

ENGINE OIL FILTER
Replacethe engine oilfilter every season or
every other oil change if the tractor is used
more than 100 hours in one year.
AIR FILTER
Your engine wilt not run properly using a
dirty airfilter, Service paper cartridge every'
100 hours of operation or every season,
whicheveroccurs first.
Service air cleaner more oftenunder dusty
conditions,
1. Remove cover,
2. Carefully remove air filter cartridge and
pre-cleaner from base.
3. Clean base carefully to prevent debris
from falling into carburetor.
NOTE: If very dirty or damaged, replace
cartridge.
4. Place new pro-cleaner and cartridge
firmly in base.
5. Replace cover.
IMPORTANT: Petroleum solvents, such as
kerosene, are not to be used to clean the
cartridge. They may cause deterioration of
the cartridge. Do not oil cartridge. Do not
use pressurized air to clean cartridge,
CLEAN AIR SCREEN
The air screen is over the air intake blower
located on top of engine. The air screen
must be keptfree of dirt and chaffto prevent
enginedamage fromoverheating. Clean with
a wire brush or compressed air to remove
dirt and stubborn dried gum fibers,
ENGINE COOLING SYSTEM
Debris may clog the engine's air cooling
system. Remove blower housing and dean
area shown to prevent overheating and
engine damage.
AirScree Cleanout chaff
r_ anddebris
IN-LINE FUEL FILTER
The fuel filtershouldbe replacedonceeach
season. If fuel filter becomes clogged, ob-
structing fuel flowto carburetor, replacement
is required.
1. With engine cool, remove filter and plug
fuel line sections.
2. Place newfuel filter in position in fuel line
with arrow pointing towards carburetor.
3. Be sure there are no fuel line leaks and
clamps are properly positioned.
4. Immediatelywipe upanyspiUedgasoline.
Clamp
Fuel Filt_
MUFFLER
Inspect and replace corroded muffler and
sparkarrester(ifequipped) asit couldcreate
afire hazard and/ordamage.
SPARK PLUG(S)
Replacespark plug(s)atthe beginning ofeach
mowing season or after every 100 hours of
operation, whicheveroccursfirst. Sparkplug
type andgapsetting areshown in"PRODUCT
SPECIFICATIONS" section of this manual.
19

CLEANING
•Clean engine, battery, seat, finish, etc.
of all foreign matter.
• Clean debris from steering plate. Debris
can restrict clutch]brake pedal shaft move-
ment, causing belt slip and loss of drive.
ACAUTION: Avoid all pinch points and
movable parts
Clean /' '_YS_=_. X
Plate_S_
Steering System, Dash, Fender
and Mower Not Shown
• Keep finished surfaces and wheels free
of al! gasoline, oil, etc.
• Protect painted surfaces with automotive
type wax,
Except for the washout port (if equipped),
we do not recommend using a garden hose
or pressure washer to clean the outside of
your tractor unless the engine and transmis-
sion are covered to keep water out. Water
in engine or transmission will shorten the
useful life of your tractor. Use compressed
air or a leaf blower to remove grass, leaves
and trash from outside tractor and mower.
DECK WASHOUT PORT
Your tractor's deck is equipped with a washout
port as part of its deck wash system. It should
be utilized after each use.
1. Drive the tractor to a level, clear spot on
your lawn, near enough to a water spigot
for your garden hose to reach.
IMPORTANT: Make certain the tractor's
discharge chute is directed AWAY from your
house, garage, parked cars, etc. Remove bag-
ger chute or mulch cover if attached.
Hose _.-1P_ WashoutPort
Nozz[e....---'C--" / /(_ t
._Adapter _ _c
2. Make sure the attachment clutch control
is in the "DISENGAGED" position, set
the parking brake, and stop the engine.
3. Thread the nozzle adapter (packaged with
your tractor's Operator's Manual) ontothe
end of your garden hose.
4. Pull back the lock collar of the nozzle
adapter and push the adapter onto the
deck washout port at the left end of the
mower deck. Release the lock collar to
lock the adapter on the nozzle.
IMPORTANT: Tug hose ensuring connection
is secure.
5, Turn the water on.
6. While sitting in the operator's position on
the tractor, re-start the engine and place
the throttle lever in the Fast "_" position.
IMPORTANT: Recheck the area to ensure the
area is clear. Ensure no children are in the:
area while cleaning the deck.
7. Move the tractor's attachment clutch con-
trol to the "ENGAGED" position. Remain
in the operator's position withthe cutting
deck engaged until the deck is cleaned,
8. Movethetractor's attachment clutch con-
trol to the "DISENGAGED" position. Turn
the ignition keyto the STOP position totum
the tractor's engine off. Turn the water off.
9. Pull back the lock collar of the nozzle
adapter to disconnect the adapter from
the nozzle washout port.
10. Move the tractor to adry area, preferably
a concrete or paved area. Piece the at-
tachment clutch contro!inthe"ENGAGED"
position to remove excess water and to
help dry before putting the tractor away.
_IbWARNING: A broken or missing washout
fitting could expose you or others to thrown
objects from contact with the blade.
* Replace broken or missing washout fitting
immediately, prior to using mower again.
, Plug any holes in mower with bolts and
Iocknuts,
2O
