Owner's Manual
ICRRFTSMRW I
6.75 HORSEPOWER
21" MULTI-CUT
POWER PROPELLED
ROTARY LAWN MOWER
Model No.
917.377811
•Safety
•Assembly
•Operation
• Maintenance
•Espa_ol
•Repair Parts
CAUTION:
Read and follow all
Safety Rules and Instructions
beforeoperatingthis equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Visit our Craftsman website: www.sears.com/craftsman

Warranty ................................................. 2
Safety Rules ........................................ 2-4
Assembly ................................................ 5
Operation ........................................... 6-10
Maintenance Schedule ........................ 11
Maintenance., .................................. 11-14
Product Specifications .......................... 12
Service and Adjustments ...................... 15
Storage ............................................ 16-17
Troubleshooting .............................. 17-18
Repair PaRs ..................................... 36-43
Parts Ordering ........................ Back Cover
LIMITED TWO YEAR WARRANTY ON CRAFTSMAN POWER MOWER
For two years from date of purchase, when this Craftsman Lawn Mower is maintained,
lubricated, and tuned up according to the operating and maintenance instructions in
the owner's manual, Sears will repair free of charge any defect in material or workman-
ship.
If this Craftsman Lawn Mower is used for commercial or rental purposes, this warranty
applies for only 90 days from the date of purchase.
This Warranty does not cover:
•Expendable items which become worn during normal use, such as rotary mower
blades, blade adapters, belts, air cleaners and spark plug.
• Repairs necessary because of operator abuse or negligence, including bent
crankshafts and the failure to maintain the equipment according to the instructions
contained in the owner's manual.
Warranty service is available by returning the Craftsman power mower to the nearest
Sears Service Center/Department in the United States. This warranty applies only
while this product is in use in the United States.
This Warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
SEARS, ROEBUCKAND CO., £)/817 WA, HOFFMAN ESTATES, ILLINOIS 60179
IMPORTANT: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructions could result in
serious injury or death.
I. GENERAL OPERATION
• Read, understand, and follow all
instructions on the machine and in the
manual(s) before starting. Be thor-
oughly familiar with the controls and the
proper use of the machine before
starting.
• Do not put hands or feet near or under
rotating parts. Keep clear of the
discharge opening at all times.
• Only allow responsible individuals, who
are familiar with the instructions, to
operate the machine.
• Clear the area of objects such as rocks,
toys, wire, bones, sticks, etc., which
could be picked up and thrown by the
blade. 2
•Be sure the area is clear of other
people before mowing. Stop machine if
anyone enters the area.
• Do not operate the mower when
barefoot or wearing open sandals.
Always wear substantial foot wear.
•Do not pull mower backwards unless
absolutely necessary. Always look
down and behind before and while
moving backwards.
• Do not operate the mower without
proper guards, plates, grass catcher or
other safety protective devices in
place.
• See manufacturer's instructions for
proper operation and installation of
accessories. Only use accessories
approved by the manufacturer.

• Stop the blade(s) when crossing gravel
drives, walks, or roads.
•Stop the engine (motor) whenever you
leave the equipment, before cleaning
the mower or unclogging the chute.
•Shut the engine (motor) off and wait
until the blade comes to complete stop
before removing grass catcher.
•Mow only in daylight or good artificial
light.
• Do not operate the machine while
under the influence of alcohol or drugs.
•Never operate machine in wet grass.
Always be sure of your footing: keep a
firm hold on the handle and walk; never
run.
• Disengage the self-propelled mecha-
nism or drive clutch on mowers so
equipped before starting the engine
(motor).
• If the equipment should start to vibrate
abnormally, stop the engine (motor)
and check immediately for the cause.
Vibration is generally a warning of
trouble.
• Always wear safety goggles or safety
glasses with side shields when
operating mower.
II. SLOPE OPERATION
Slopes are a major factor related to slip
and fall accidents which can result in
severe injury. All slopes require extra
caution, if you feel uneasy on a slope, do
not mow it.
DO"
• Mow across the face of slopes: never
up and down. Exercise extreme caution
when changing direction on slopes.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Tall
grass can hide obstacles.
DO NOT:
•Do not trim near drop-offs, ditches or
embankments. The operator could lose
footing or balance.
•Do not trim excessively steep slopes.
• Do not mow on wet grass. Reduced
footing could cause slipping.
III. CHILDREN
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the
machine and the mowing activity. Never
assume that children will remain where
you last saw them.
•Keep children out of the trimming area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
•Before and while walking backwards,
look behind and down for small
children.
• Never allow children to operate the
machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
IV. SERVICE
• Use extra care in handling gasoline
and other fuels. They are flammable
and vapors are explosive.
-Use only an approved container.
-Never remove gas cap or add fuel
with the engine running. Allow
engine to cool before refueling. Do
not smoke.
-Never refuel the machine indoors.
-Never store the machine or fuel
container inside where there is an
open flame, such as a water heater.
• Never run a machine inside a closed
area.
• Never make adjustments or repairs with
the engine (motor) running. Disconnect
the spark plug wire, and keep the wire
away from the plug to prevent acciden-
tal starting.
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep
equipment in good condition.
•Never tamper with safety devices.
Check their proper operation regularly.
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel
spillage. Allow machine to cool before
storing.
• Stop and inspect the equipment if you
strike an object. Repair, if necessary,
before restarting.
• Never attempt to make wheel height
adjustments while the engine (motor) is
running.
3

•Grass catcher components are subject
to wear, damage, and deterioration,
which could expose moving parts or
allow objects to be thrown. Frequently
check components and replace with
manufacturer's recommended parts,
when necessary.
•Mower blades are sharp and can cut.
Wrap the blade(s) or wear gloves, and
use extra caution when servicing them.
•Do not change the engine governor
setting or overspeed the engine.
&Look for this symbol to point out
important safety precautions. It means
CAUTION!!! BECOMEALERT!!! YOUR
SAFETY IS INVOLVED.
_, WARNING: In order to prevent acci-
dental starting when setting up, transport-
ing, adjusting or making repairs, always
disconnect spark plug wire and place wire
where it cannot contact spark plug.
_,WARNING: Engine exhaust, some of its
constituents, and certain vehicle compo-
nents contain or emit chemicals known to
the State of California to cause cancer
and birth defects or other reproductive
harm.
_,WARNING: Battery posts, terminals and
related accessories contain lead and lead
compounds, chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm. Wash
hands after handling.
ACAUTION: Muffler and other engine
parts become extremely hot during
operation and remain hot after engine has
stopped. To avoid severe burns on
contact, stay away from these areas.
These accessories were available when this lawn mower was produced. They are not
shipped with your mower. They are also available at most Sears retail ouUets and service
centers. Most Sears stores can also order repair parts for you, when you provide the model
number of your lawn mower. Some of these accessories may not apply to your lawn mower.
LAWN MOWER PERFORMANCE
CLIPPING DEFLECTOR
FOR REAR DISCHARGE LAWN MOWERS
GRASS CATCHERS
FOR
REAR DISCHARGE
LAWN MOWERS
J
MULCHER KITS
_/1 GRASS CATCHERS
FOR
_I SIDE DISCHARGE
LAWN MOWERS
STABILIZER
GAS CANS
LAWN MOWER MAINTENANCE
MUFFLERS AIR FILTERS SPARK PLUGS
BELTS BLADES BLADE ADAPTERS WHEELS ENGINE OIL
4

Read these instructions and this manual
in its entirety before you attempt to
assemble or operate your new lawn
mower.
IMPORTANT: This lawn mower is
shipped WITHOUT OIL OR GASOLINE in
the engine.
Your new lawn mower has been as-
sembled at the factory with the exception
of those parts left unassembled for
shipping purposes. All parts such as nuts,
washers, bolts, etc., necessary to com-
plete the assembly have been placed in
the parts bag. To ensure safe and proper
operation of your lawn mower, all parts
and hardware you assemble must be
tightened securely. Use the correct tools
as necessary to ensure proper tightness.
TO REMOVE LAWN MOWER FROM
CARTON
1. Remove loose parts included with
mower.
2. Cut down two end comers of carton
and lay end panel down flat.
3. Remove all packing materials except
padding between upper and lower
handle and padding holding operator
presence control bar to upper handle.
4. Roll lawn mower out of carton and
check carton thorougly for additional
loose parts.
HOW TO SET UP YOUR LAWN
MOWER
TO UNFOLD HANDLE
IMPORTANT: Unfold handle carefully so
as not to pinch or damage control cables.
1. Raise lower handle section to
operating position and squeeze the
bottom ends of lower handle towards
each other until the pin in handle can
be inserted into one of the three
height adjustment holes.
2. Remove protective padding, raise
upper handle section into place on
lower handle and tighten both handle
knobs.
3. Remove any packing material from
around control bar.
Your handles may be adjusted for your
mowing comfort. Refer to Service and
Adjustments section of this manual.
Operator I:
control bar
Lift
Mowing
position
Lower handle
sq
3-Position
handle
adj
bracket
pin
TO INSTALL A'I-FACHMENTS
Your lawn mower was shipped ready to
be used as a mulcher. To convert to
bagging or discharging, see "TO CON-
VERT MOWER" in the Operation section
of this manual.
5

KNOWYOUR LAWN MOWER
READ THIS OWNER'S MANUALAND SAFETY RULES BEFORE OPERATING YOUR LAWN
MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the
location of various controls ancl adjustments. Save this manual for future reference.
These symbols may appear on your lawn mower or in literature supplied with the product.
Learn and understand their meaning.
CAUTION ENGINE ENGINE FAST SLOW CHOKE FUEL OIL DANGER, KEEP HANDS
OR WARNING ON OFF AND FEET AWAY
Drive control b_
Handle knob
presence control bar
Drive speed control lever
Engine zone control cable
Drive cover
Grass
Single point height adjuster handle.,
Gasoline filler cap
Air filter
Engine oil cap
Mulcher plug Mulcher doc
IMPORTANT: This lawn mower is shipped
without oil or gasoline in the engine. ousing
MEETS CPSC SAFETY REQUIREMENTS
Sears rotary walk-behind power lawn mowers conform to the safety standards of the
Amedcan National Standards Institute and the U.S. Consumer Product Safety Commis-
sion. The blade turns when the engine is running.
Operator presence control bar -must
be held down to the handle to start the
engine. Release to stop the engine.
Primer -pumps additional fuel from the
carburetor to the cylinder for use when
starting a cold engine.
Starter handle -used for starting the
engine.
Drive control bar - used to engage
power-propelled foward motion of lawn
mower.
Drive speed control lever - used to
engage power-propelled forward motion
lawn mower.
Single point height adjuster- used to
adjust cutting height of lawn mower.
Mulcher door - allows conversion to
discharging or bagging operation.
Mulcher plug -Located at the rear
discharge opening must be removed
when converting to bagging operation.
6

The operationof any lawn
mowercan result in foreign
objects thrown into the
eyes, which can result in
severe eye damage.
Always wear safety glasses or eye
shields while operating your lawn mower
or performing any adjustments or repairs.
We recommend a wide vision safety mask
over spectacles or standard safety
glasses.
HOWTO USEYOUR LAWN MOWER
ENGINE SPEED
The engine speed was set at the factory for
optimum performance. Speed is not
adjustable.
ENGINE ZONE CONTROL
_,CAUTION: Feel.eral requlations reguire an
engine control to De installed on mislawn
mower in order to minimize the risk of blade
contact injury. Do not under any
circumstances attempt to defeat the function
of the operator control. The blade turns when
the engine is running.
•Your lawn mower is equipped with an
operator presence control bar which
requires the operator to be pos_oned
behind the lawn mower handle to start and
operate the lawn mower.
GROUND DRIVE SPEEDS
Your lawn mower provides multiple
speeds to let you select the speed that
suits you best.
• Lower speeds are for heavy/thick grass
cutting or trimming.
• Medium speeds are for normal grass
cutting or trimming.
• High speeds are for light cutting and for
ground transport.
NOTE: Do not move speed control lever
unless the engine is running
Drive speed
control lever_
TO OPERATE DRIVE SYSTEM
•With engine running, select ground
speed by moving drive speed control
lever to desired position.
•To start forward motion, pull drive
control bar back against handle.
•To stop forward motion, release drive
control bar.
IMPORTANT: Always keep drive control
fully engaged against handle when in
use. Operator nce control bar
\
Drive control
;led _ disengaged
TO ADJUST CUTTING HEIGHT
All four wheels are adjusted by a single
lever.
•Pull adjuster lever toward wheel, To
raise mower, move lever forward to
desired position. To lower mower,
move the lever toward the rear.
Lower Wheels
,\
for High Cut_ J
Single point
height adjuster
lever
Raise Wheels
for Low Cut
TO ATTACH GRASS CATCHER
1. Lift the rear door of the lawn mower
and place the grass catcher frame
hooks into the slots of the rear door.
2. The grass catcher is secured to the
lawn mower housing when the rear
door is lowered onto the grass catcher
frame.
• iLCAUTION: Do not run your lawn mower
without clipping deflector or approved
grass catcher in place. Never attempt to
operate the lawn mower with the rear
door removed or propped open.
7

Rear door slots Grass
catcher
Catcher frame hook
TO EMPTY GRASS CATCHER
1. Lift up on grass catcher using the
frame handle.
2. Remove grass catcher with clippings
from under lawn mower handle.
3. Empty clippings from bag using both
frame handle and bag handle.
NOTE: Do not drag the bag when
emptying; it will cause unnecessary wear.
(Grass
Bag frame
handle handle
TO CONVERT MOWER
Your lawn mower was shipped ready to
be used as a mulcher. To convert to
bagging or discharging:
REAR BAGGING
• Open rear door and remove mulcher
plug. Store mulcher plug in a safe
place.
• You can now install the grass catcher.
• To convert to mulching or discharging
operation, install mulcher plug into rear
discharge opening of mower.
Mulcher plug
SIDE DISCHARGING
•Mulcher plug must be installed into rear
discharge opening of mower.
•Open mulcher door and install dis-
charge deflector under guard as shown.
•Mower is now ready for discharging
operation.
•To convert to mulching or bagging
operation, discharge deflector must be
removed and discharge guard must be
closed.
:her door
Open mulcher door
Discharge
deflector

SIMPLE STEPS TO REMEMBER WHEN
CONVERTING YOUR LAWN MOWER
FOR MULCHING -
1. Rear mulcher plug installed.
2. Mulcher door closed.
FOR REAR BAGGING -
1. Rear mulcher plug removed.
2. Grass catcher installed.
3. Mulcher door closed.
FOR SIDE DISCHARGING -
1. Rear mulcher plug installed.
2. Side discharge deflector installed.
• I,CAUTION: Do not run your lawn mower
without rear mulcher plug in place or
approved grass catcher in place.
Never attempt to operate the lawn mower
with the rear door removed or propped
open.
BEFORE STARTING ENGINE
ADD OIL
Your lawnmower is shipped without oil in
the engine. Engine holds 20 oz. of oil.
For type and grade of oil to use, see
"ENGINE" in Maintenance section of this
manual.
1. Be sure lawnmower is level and area
around oil fill is clean.
2. Remove engine oil cap and fill to the
full line on the dipstick. Pour oil slowly.
Do not over fill.
NOTE: Allow oil to settle down into engine
for accurate reading. To read proper level,
tighten engine oil cap, then remove it to
read the dipstick.
3. Reinstall engine oil cap and tighten.
• Check oil level before each use. Add
oil if needed. Fill to full line on dipstick.
• Change the oil after every 25 hours of
operation or each season. You may
need to change the oil more often
under dusty, dirty conditions.
ADD GASOLINE
• Fill fuel tank. Use fresh, clean, regular
unleaded gasoline with a minimum of
87 octane. Do not mix oil with gasoline.
Purchase fuel in quantities that can be
used within 30 days to assure fuel
freshness.
_WARNING: Experience indicates that
alcohol blended fuels (called gasohol or
using ethanol or methanol) can attract
moisture which leads to separation and
formation of acids during storage. Acidic
gas can damage the fuel system of an
engine while in storage. To avoid engine
problems, the fuel system should be
emptied before storage of 30 days or
longer. Drain the gas tank, start the
engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel
next season. See Storage Instructionsfor
additional information. Never use engine
or carburetor cleaner products in the fuel
tank or permanent damage may occur.
ACAUTION: Fillto bottom of gas tank
filler neck. Do not overfill. Wipe oft any
spilled oil or fuel. Do not store, spill or use
gasoline near an open flame.
- Gasoline
filler cap
Engine oil cap
9

TO START ENGINE
NOTE: Due to protective coatings on the
engine, a small amount of smoke may be
present during the initial use of the
product and should be considered
normal.
1. To start a cold engine, push primer
three (3) times before trying to start.
Use a firm push. This step is not
usually necessary when starting an
engine which has already run for a few
minutes.
2. Hold operator presence control bar
down to the handle and pull starter
handle quickly. Do not allow starter
rope to snap back.
TO STOP ENGINE
• To stop engine, release operator
presence control bar.
NOTE: In cooler weather it may be
necessary to repeat priming steps. In
warmer weather over priming may cause
flooding and engine will not start. If you do
flood engine, wait a few minutes before
attempting to start and do not repeat
priming steps.
MOWINGTIPS
• Under certain conditions, such as very
tall grass, it may be necessary to raise
the height of cut to reduce pushing
effort and to keep from overloading the
engine and leaving clumps of grass
clippings. It may also be necessary to
reduce ground speed and/or run the
lawn mower over the area a second
time.
•For extremely heavy cutting, reduce the
width of cut by overlapping previously
cut path and mow slowly.
• For better grass bagging and most
cutting conditions, the engine speed
should be set in the fast position.
•Pores in cloth grass catchers can
become filled with dirt and dust with use
and catchers will collect less grass. To
prevent this, regularly hose catcher off
with water and let dry before using.
• Keep top of engine around starter clear
and clean of grass clippings and chaff.
This will help engine air flow and
extend engine life.
MULCHING MOW1NG TIPS
IMPORTANT: Forbestperformance,keep
mower housingfree of built-upgrass and
trash.See "CLEANING"in the Maintenance
sectionofthis manual.
• The special mulching blade will recut the
grass clippings many times and reduce
them in size so that as they fall onto the
lawn they will disperse into the grass and
not be noticed. Also, the mulched grass
will biodegrade quickly to provide nutrients
for the lawn. Always mulch with your
highest engine (blade) speed as this will
provide the best recutting action of the
blades.
• Avoid cutting your lawn when it is wet. Wet
grass tends to form clumps and interferes
with the mulching action. The best time to
mow your lawn is the early aftemoon. At
this time the grass has dried and the newly
cut area will not be exposed to the direct
sun.
• For best results, adjust the lawn mower
cutting height so that the lawn mower cuts
off only the top one-third of the grass
blades. If the lawn is overgrown it will be
necessary to raise the height of cut to
reduce pushing effort and to keep from
overloading the engine and leaving
clumps of mulched grass. For extremely
heavy mulching, reduce your width of cut
by overlapping previously cut path and
mow slowly.
• Certain types of grass and grass conditions
may require that an area be mulched a
second time to completely hide the
clippings. When doing a second cut, mow
across or perpendicular to the first cut path.
• Change your cutting pattem from week to
week. Mow north to south one week then
change to east to west the next week. This
will help prevent matting and graining of
the lawn.
Max 1/3
10

AS YOU COMPLETE ..,#_l_.?,_._.l_,,_
Check for Loose Fasteners _/ 1/
Clean/Inspect Grass Catcher
(If Equipped) t,/ _
a Clean Lawn Mower
Clean Under Drive Cover
W (Power-PropeEledMowers) i,/
Check drive belt]pulleys
(Power-Propelled Mowers) If
RCheck/Sharpen/Replace Blade I/'3
LubricationChart I_
Clean Battery/Recharge
tElectric Start Mowers I I_ 1_4
NE Check Engine Oil Level !/
Change EngineOil Vwt.2
G Clean Air Filter _,_ 2
Inspect Muffler
N Clean or Replace Spark Plug
Replace Air Filter Paper Cartridge 11_2
_ERVICE DATES
1 - Change more often when operating under a heavy load or in high ambient temperatures.
2- Service more often when operating in dirty or dusty conditions.
3- Replace blades more often when mowing in sandy soil. LUBRICATION CHART
4 - Charge 48 hours at end of season.
GENERAL RECOMMENDATIONS (_) Engine oil
The warrantyon this lawn mower does not
cover items that have been subjected to
operator abuse or negligence. To receive full
value from the warranty, operator must
maintain mower as instructed in this manual.
Some adjustments will need to be made
periodically to properly maintain your unit.
All adjustments in the Service and Adjust-
ments se_on of this manual should be
checked at least once each season.
•Once a year, replace the spark plug,
replace air filter element and check blade
for wear. A new spark plug and clean/new
air filter element assure proper air-fuel
mixture and help your engine runbetter
and last longer.
• Follow the maintenance schedule in this
manual.
BEFORE EACH USE
1. Check engine oil level.
2. Check for loose fasteners.
LUBRICATION
Keep unit well lubricated (See "LUBRICA-
TION CHART').
(_) Brake spring
bracket
Mulcher
door hinge pin
Rear
door hinge
(_) Handle bracket mounting pins
(_) Spray lubricant
_) See "ENGINE" in Maintenance section.
11
IMPORTANT: Do not oil or grease
plastic wheel bearings. Viscous
lubricants will attract dust and dirt that
will shorten the life of the self-lubricat-
ing bearings. If you feel they must be
lubricated, use only a dry, powdered
graphite type lubricant sparingly.

PRODUCT SPECIFICATIONS
;ERIAL NUMBER:
DATE OF PURCHASE:
GASOLINE CAPACITY/TYPE: 1.5 QUARTS (UNLEADED REGULAR)
)ILTYPE (API-SF-SJ): SAE 30 (ABOVE 32°F); SAE 5W-30 (BELOW 32°F
OIL CAPACITY: 20 OUNCES
SPARK PLUG (GAP: .045") CHAMPION RJ19LM4
BLADE BOLT TORQUE: 35-40 FT. LBS.
The model and serial numbers will be found on a decal attached to the rear of the
lawn mower housing. Record both serial number and date of purchase in the space
provided above.
LAWN MOWISR TO REPLACE BLADE
Always observe safety rules when performing
any maintenance.
TIRES
•Keep tiresfree of gasoline, oil,or insect
controlchemicals whichcan harm rubber.
• Avoid stumps,stones,deep ruts,sharp
objectsand other hazardsthat may cause
tire damage.
BLADE CARE
For best results, mower blade must be
kept sharp. Replace bent or damaged
blades.
TO REMOVE BLADE
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Turn lawn mower on its side. Make
sure air filter and carburetor are up.
3. Use a wood block between blade and
mower housing to prevent blade from
turning when removing blade bolt.
NOTE: Protect your hands with gloves
and/or wrap blade with heavy cloth.
4. Remove blade bolt by turning counter-
clockwise.
5. Remove blade and attaching hard-
ware (bolt, lock washer and hardened
washer).
NOTE: Remove the blade adapter and
check the key inside hub of blade adapter.
The key must be in good condition to work
properly. Replace adapter if damaged.
1. Position the blade adapter on the
engine crankshaft. Be sure key in
adapter and crankshaft keyway are
aligned.
2. Position blade on the blade adapter
aligning the two (2) holes in the blade
with the raised lugs on the adapter.
3. Be sure the trailing edge of blade
(opposite sharp edge) is up toward the
engine.
4. Install the blade bolt with the lock
washer and hardened washer into
blade adapter and crankshaft.
5. Use block of wood between blade and
lawn mower housing and tighten the
blade bolt, turning clockwise.
• The recommended tightening torque is
35-40 ft. Ibs.
IMPORTANT: Blade bolt is grade 8 heat
treated.
Blade adaptel Crankshaft
Ke keyway
Blade
Blade
bolt Hardene --_ _ shaft
washer Trailing edge Blade adapter
12

TO SHARPEN BLADE
NOTE: We do not recommend sharpening
blade - but if you do, be sure the blade is
balanced.
Care should be taken to keep the blade
balanced. An unbalanced blade will cause
eventual damage to lawn mower or
engine.
• The blade can be sharpened with a file
or on a grinding wheel. Do not attempt
to sharpen while on the mower.
•To check blade balance, drive a nail
into a beam or wall. Leave about one
inch of the straight nail exposed. Place
center hole of blade over the head of
the nail. If blade is balanced, it should
remain in a horizontal position. If either
end of the blade moves downward,
sharpen the heavy end untilthe blade is
balanced.
GRASS CATCHER Hubca
• The grass catcher may be hosed with /
water, but must be dry when used.
• Check your grass catcher often for
damage or deterioration. Through _
normal use it will wear. If catcher needs
replacing, replace only with a manufac-
turer approved replacement catcher.
Give the lawn mower model number
when ordering.
DRIVE WHEELS
Check rear drive wheels each time you
mow to be sure they move freely. The
wheels not turning freely means trash,
grass cuttings, etc., may be inside the
drive wheel and dust cover area and must
be cleaned out to free drive wheels.
If necessary to clean the drive wheels,
check both rear wheels.
1. Remove hubcaps and Iocknuts.
2. Remove wheels from wheel adjuster
axles.
3. Remove any trash or grass cuttings
from inside the dust cover, pinion and/
or drive wheel gear teeth.
4. If you remove the drive pinions, wipe
clean with dry cloth. Reassemble dry.
Do not lubricate. Do not use oil or
grease.
NOTE: The pinion gears, on both sides of
the mower, are the same, however, they
must be installed correctly. If installed
incorrectly, the drive system will not work.
5. There are arrows embossed on both
sides of the pinion gear. With the
arrow at the top of the pinion, the
arrow must point towards the front of
the mower. If the arrow points to the
rear of the mower, turn the pinion
around, then assemble to mower.
6. Place wheels back on adjuster axles.
7. Replace Iocknuts and hubcaps.
Correct Incorrect
Wave
,Washer
Pinion
'Locknut
Dust
cover
Washers
ENGINE
LUBRICATION
Use only high quality detergent oil rated with
API service classification SF-SJ. Selectthe
oil's SAE viscosity grade according to your
expected operating temperature.
SAE VISCOSITY GRADES
-20 0 30 32 40 60 80 100
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
NOTE: Although multi-viscosity oils (5W30,
10W30 etc.) improve staring in cold weather,
these multi-viscesity oils will result in
increased oil consumption when used above
32°F. Check your engine oil level more
frequently to avoid possible engine damage
from running low on oil.
Change the oil after every 25 hours of
operation or at least once a year if the lawn
mower is not used for 25 hours in one year.
Check the crankcase oil level before starting
the engine and after each five (5) hours of
continuous use. "13ghten oil plug securely
each time you check the oil level.
13

TO CHANGE ENGINE OIL
NOTE: Before tipping lawn mower to
drain oil, drain fuel tank by running
engine untilfuel tank is empty.
1. Disconnect spark plug wire from spark
plug and place wire where it cannot
come in contact with spark plug.
2. Remove engine oil cap; lay aside on a
clean surface.
3. Tip _awn mower on its side as shown
and drain oil into a suitable container.
Rock lawn mower back and forth to
remove any oil trapped inside of
engine.
4. Wipe off any spilled oil from lawn
mower or side of engine.
5. Fill engine with oil. (See "ADD OIL" in
the Operation section of this manual).
6. Reconnect spark plug wire to spark
plug.
Container
AIR FILTER
Your engine will not run properly and may
be damaged by using adirty air filter.
Replace the air filter every 100 hours of
operation or every season, whichever
occurs first. Service air cleaner more
often under dusty conditions. Do not
wash air filter.
TO CHANGE AIR FILTER
1. Remove the air filter by turning
clockwise to the stop and pull away
from collar.
2. Remove filter from inside of cover.
3. Clean the inside of the cover and the
collar to remove any dirt accumula-
tion.
4. Insert new filter into cover.
5. Put air filter cover and filter into collar
aligning the tab with the slot.
6. Push in on cover and turn counter-
clockwise to tighten.
Collar
Clip
\\
rum
clockwise to
remove
Slot /
/
Air filter Tab /Turn
/counter-
Air filter cover clockwise to tighten
MUFFLER
Inspect and replace corroded muffler as it
could create a fire hazard and/or damage,
SPARK PLUG
Replace spark plugs at the beginning of
each mowing season or after every 100
hours of operation, whichever occurs first.
Spark plug type and gap setting are
shown in "PRODUCT SPECIFICATIONS"
in Maintenance section ot this manual.
CLEANING
IMPORTAN'E For best performance, keep
mower housing free of built-up grass and
trash. Clean underside of mower housing
after each use.
ACAUTION'. Disconnect spark plug wire
from spark plug and place wire where it
cannot come in contact with the spark
plug.
•Clean the underside of your lawn
mower by scraping to remove build-up
of grass and trash.
• Clean engine often to keep trash from
accumulating. A clogged engine runs
hotter and shortens engine life.
• Keep finished surfaces and wheels free
of all gasoline, oil, etc.
• We do not recommend using a garden
hose to clean lawn mower unless the
electrical system, muffler, air filter and
carburetor are covered to keep water
out. Water in engine can result in
shortened engine life.
14

ACAUTION: Before performing any
service or adjustments:
1. Release control bar and stop eng!ne.
2. Make sure the blade and all moving
parts have completely stopped.
3. Disconnect spark plug wire from spark
plug and place where it cannot come
in contact with plug.
LAWN MOWER
TO ADJUST CU'I-FING HEIGHT
See "TO ADJUST CUTTING HEIGHT" in
the Operation section of this manual.
REAR DEFLECTOR
The rear deflector, attached between the
rear wheels of your mower, is provided to
minimize the possibility that objects will
be thrown out of the rear of the mower
into the operator mowing position. If the
deflector becomes damaged, it should be
replaced.
TO ADJUST HANDLE
The handle on your lawn mower has
three (3) height positions - adjust to
height that suits you.
• Squeeze the bottom ends of lower
handle towards each other until the pin
in handle can be inserted into one of
the three height adjustment holes.
ndle pin 3-position
handle
Sql bracket
TO ASSEMBLE GRASS CATCHER
1. Put grass catcher frame into grass bag
with rigid part of bag on the bottom.
Make sure the frame handle is outside
of the bag top.
2. Slip vinyl bindings over frame.
NOTE: If vinyl bindings are too stiff, hold
them in warm water for a few minutes. If
bag gets wet, let it dry before using.
ACAUTION: Do not run your lawn mower
without clipping deflector or approved
grass catcher in place. Never attempt to
operate the lawn mower with the rear
door removed or propped open.
Catcher
frame
handle
Frame
ENGINE opening
ENGINE SPEED
Your engine speed has been factory set. Do
not attempt to increase engine speed or it
may result in personal injury. If you believe
that the engine is running too fast or too slow,
take your lawn mower to a Sears or other
qualified service center for repair and
adjustment.
CARBURETOR
Your carburetor has a non-adjustable fixed
main jet for mixture control. If your engine
does not operate properly due to suspected
carburetor problems, take your lawn mower
to a Sears or other qualified service center for
repair and adjustment.
IMPORTANT: Never tamper with the engine
govemor, which is factory set for proper
engine speed. Overspeeding the engine
above the factory high speed setting can be
dangerous. If you think the engine-govemed
high speed needs adjusting, contact your
nearest Sears or other qualified service
center, which has proper equipment and
experience to make any necessary
adjustments.
15

Immediately prepare your lawn mower for
storage at the end of the season or if the
unit will not be used for 30 days or more.
LAWN MOWER
When lawn mower is to be stored for a
period of time, clean it thoroughly, remove
all dirt, grease, leaves, etc. Store in a
clean, dry area.
1. Clean entire lawn mower (See
"CLEANING" in the Maintenance
section of this _nanual).
2. Lubricate as shown in the Mainte-
nance section of this manual.
3. Be sure that all nuts, bolts, screws, and
pins are securely fastened. Inspect
moving parts for damage, breakage
and wear. Replace if necessary.
4. Touch up all rusted or chipped paint
surfaces; sand lightly before painting.
HANDLE
You can fold your lawn mower handle for
storage.
1. Loosen the two (2) handle knobs on
sides of the upper handle and allow
handle to fold down to the rear.
2. Squeeze the bottom ends of lower
handle toward each other until pins in
handle clear the brackets and pivot
entire handle assembly forward and
allow it to rest on mower.
• When setting up your handle from the
storage position, the lower handle will
require manually locking into the
mowing position.
IMPORTANT: When folding the handle
for storage or transportation, be sure to
fold the handle as shown or you may
damage the control cables.
Operator I
control bar Fold
Lower
han_
Fold
backward
Mowing
position
sq pin
J3-Position
handle
adjustment
bracket
ENGINE
FUELSYSTEM
IMPORTANT: It is important to prevent
gum deposits from forming in essential
fuel system parts such as carburetor, fuel
filter, fuel hose, or tank during storage.
Also, experience indicates that alcohol
blended fuels (called gasohol or using
ethanol or methanol) can attract moisture
which leads to separation and formation
of acids during storage. Acidic gas can
damage the fuel system of an engine
while in storage.
1. Drain the fuel tank.
2. Start the engine and let it run until the
fuel lines and carburetor are empty.
• Never use engine or carburetor cleaner
products in the fuel tank or permanent
damage may occur.
• Use fresh fuel next season.
NOTE; Fuel stabilizer is an acceptable
alternative in minimizing the formation of
fuel gum deposits during storage. Add
stabilizer to gasoline in fuel tank or
storage container. Always follow the mix
ratio found on stabilizer container. Run
engine at least 10 minutes after adding
stabilizer to allow the stabilizer to reach
the carburetor. Do not drain the gas tank
and carburetor if using fuel stabilizer.
ENGINEOIL
Drain oil (with engine warm) and replace
with clean engine oil. (See "ENGINE" in
the Maintenance section of this manual).
CYLINDER
1. Remove spark plug.
2. Pour one ounce (29 ml) of oil through
spark plug hole into cylinder.
3. Pull starter handle slowly a few times
to distribute oil.
164 . Replace with new spark plug.

OTHER
•Do not store gasoline from one season
to another.
• Replace your gasoline can if your can
starts to rust. Rust and/or dirt in your
gasoline will cause problems.
•If possible, store your unit indoors and
cover itto give protection from dust and
dirt.
• Cover your unit with asuitable protec-
tive cover that does not retain moisture.
Do not use plastic. Plastic cannot
breathe, which allows condensation to
form and will cause your unit to rust.
IMPORTANT: Never cover mower while
engone and exhaust areas are still warm.
ACAUTION:Never store the lawn mower
with gasoline in the tank inside a building
where fumes may reach an open flame or
spark. Allow the engine to cool before
storing in any enclosure.
TROUBLESHOOTINGCHART
PROBLEM CAUSE
Doesnotsta_ 1. Di_ airfilte_
Loss of power
Poor cut -
uneven
2. Out of fuel.
3. Stale fuel.
4. Water in fuel.
5. Spark plug wire is
disconnected.
6. Bad spark plug.
7. Loose blade or broken
blade adapter.
8. Control bar in released
position.
9. Control bar defective.
1. Rear of lawn mower
housing or cutting blade
dragging in heavy grass.
2. Cutting too much grass.
3. Dirty air filter.
4. Buildup of grass, leaves,
and trash under mower.
5. Too much oil in engine.
6. Walking speed too fast.
1. Worn, bent or loose blade.
2. Wheel heights uneven.
3. Buildup of grass, leaves
and trash under mower.
CORRECTION
1. Clean/replace air filter.
2. Fill fuel tank.
3. Drain tank and refill with
fresh, clean fuel.
4. Drain fuel tank and
carburetor and refill tank
with fresh gasoline.
5. Connect wire to plug.
6. Replace spark plug.
7. Tighten blade bolt or
replace blade adapter.
8. Depress control bar to
handle.
9. Replace control bar.
1. Set to "Higher Cut"
position.
2. Set to "Higher Cut"
position.
3. Clean/replace air filter.
4. Clean underside of mower
housing.
5. Check oil level.
6. Cut at slower walking
speed.
1. Replace blade. Tighten
blade bolt.
2. Set all wheels at same
height.
3. Clean underside of
mower housing.
17

TROUBLESHOOTING CHART
PROBLEM CAUSE CORRECTION
Excessive 1. Worn, bent or loose blade. 1. Replace blade. "tighten
vibration blade bolt.
2. Bent engine crankshaft. 2. Contact a Sears or other
qualified service center.
Starter rope
hard to pull 1. Engine flywheel brake
is on when control bar
is released.
2. Bent engine crankshaft.
3. Blade adapter broken.
4. Blade dragging in grass.
1. Depress control bar to
upper handle before
pulling starter rope.
2. Contact a Sears or other
qualified service center.
3. Replace blade adapter.
4. Move lawn mower to cut
grass or to hard surface.
Grass catcher 1. Cutting height too low. 1. Raise cutting height.
notfilling 2. Lift on blade worn off. 2. Replace blade.
(Ifsoequipped) 3. Catcher not venting air. 3. Clean grass catcher.
Hard to push 1. Raise cutting height.1. Grass is too high or wheel
height is too low.
2. Rear of lawn mower
housing or cutting blade
dragging in grass.
3. Grass catcher too full.
4. Handle height position not
right for you.
1. Belt wear.
2. Belt off of pulley.
3. Drive cable worn or broken.
4. Dirt in drive pinions.
Loss of drive
2. Raise rear of lawn mower
housing one (1)setting
higher.
3. Empty grass catcher.
4. Adjust handle height to suit.
1. Check/replace drive belt.
2. Check/reinstall drive belt.
3. Replace drive cable.
4. Clean drive pinions.
18

Garantfa ......................................................... 19
Reglas de Seguridad ................................ 19-21
Montaje ........................................................... 22
Operaci6n ................................................. 23-27
Mantenimiento .......................................... 28-31
Programa de Mantenimiento .......................... 29
Especificaciones del Producto ...................... 29
Servicio y Adjustes ........................................ 32
Almacenamiento ......._............................... 33-34
Identificaci6n de problemas ..................... 34-35
Partes de repuesto ..................... Vea el manual
ingl6s del duefio
Orden de Partes ............................. Contratapa
GARANT[A LIMITADA DE DOS AI9OS PARA LA SEGADORAA MOTOR CRAFTSMAN
Por dos (2) aSos, a partirde la fecha de compra,cuando esta Segadora Craftsman se mantenga,
lubriquey afinesegSnlasinstrucciones para la operaci6ny elmantanimiantoen el manual del duefio,
Sears reparar_gratistododefectoen el materialy la mano de obra.
Sila SegadoraCraltsman se usa para fines comercialeso de arriendo,esta garantias61ose aplicapor
noventa(90) dfas a partirde lafesha de compra.
Esta Garantia no cubre:
•Artfculosque se desgastanduranteel uso normaltales como lascuchillassegadoras rotatorias,los
adeptadoresde lacuchilla,las correas,losfiltros de aira y lasbujfas.
• Reparacionesnesesariasdebidoal abusoo ala nogligencia deloperador,incluy_ndosealos
cigOehalosdoblades y a lafalta de mantenimiento del equiposeg6n lasinstruccionesque se induyan
enel manualdel duefio.
EL SERVIClO DE GARANrlA ESTA DISPONIBLE al devolver la segadoraa motor Craftsman alcentro/
departmanto de servicio Sears mas cercano en los Estados Unidos. Esta garantfa se aplica solamente
mientras el producto este an uso en los Estados Unidos.
Esta Garantfa le otorga derechos legales especlficos, y puede que tambi6n tenga otros derechos que
varfan de estado a estado.
Sears, Roebuck and Co., Di817WA, Hoffrnan Estates, IL 60179 USA
IMPORTANTE: Esta maquina cortadaora es capaz de amputar las manos y los manos y los
pies y de lanzar objetos. Si no se observan las instruccionesde seguridad siguientes se pueden
producir lesiones graves o la muerte.
I. OPERACION
• Antes de empezar, debe familiarizarse
completamente con los controles y el uso
correcto de la maquina. Para esto, debe leer
y comprender todas las instrucciones que
aparecen en la maquina yen los manuales
de operaci6n.
• No ponga las manos olos pies cerca o
debajo de las partes rotatorias. Mant6ngase
siempre lejos de la abertura de la descarga.
• Permita que solamente las personas
responsables que est_n familiarizadas con
las instrucciones operen la maquina.
• Despeje el _.rea de objetos tales como
piedras, juguetes, alambres, huesos, palos,
etc. que pueden ser recogidos y lanzados
por las cuchillas.
• Asegerese que el &rea no se hallan
personas, antes de segar. Pare la m&quina
si alguien entra en el _.rea.
• No opere la maquina sin zapatos o con
sandalias abiertas. P6ngase siempre
zapatos s61idos.
• NO tire de la segadora hacia atr&s a menos
que sea absolutamente necesado. Mire
siempre hacia abajo y hacia detr&s antes y
mientras que se mueve hacia atr_.s.
• No opera la segadora sin los respectivos
resguardos, las placas, el recogedor de
c_sped u otros aditamentos dise ados para
su protecci6n y seguridad.
• Refi_rase a las instrucciones del fabricante
para el funcionamiento e instalaci6n de
accesorios. Use 6nicamente accesorios
aprobados por el fabricante.
• Detenga la cuchilla o las cuchillas cuando
cruce pot calzadas, calles o caminos de
grava.
• Parar el motor cada vez que se abandona
el aparato, antes de limpiar la segadora o de
remover residuos del tubo.
• Apagar el motor y esperar hasta que las
cuchillas est_n completamente paradas
antes de remover el receptor de hierba.
• Segar solamente con luz del dia o con una
19 buena luz artificial.

•No opere la mdquina bajo la influencia del
alcohol o de las drogas.
•Nunca opere la maquina cuando la hierba
est6 mojada. Asegdrese siempre de tener
buena tracci6n en sus pies; mantenga el
mango firmemente y camine; nunca corra.
•Desconectar el mecanismo de propulsi6n
aut6noma o el embrague de transmisi6n en
las segadoras que Io tienen antes de poner
en marcha el motor.
•Si el equipo empezara a vibrar de una
manera anormal, pare el motor y revise de
inmediato para averiguar la causa.
Generalmente la vibraci6n suele indicar que
existe alguna averfa.
•Siempre use gafas de seguridad o anteojos
con pmtecci6n lateral cuando opere la
segadora.
II. OPERACION SOBRE LAS
CUESTAS
Los accidentes ocurren con m_.s frecuencia
en las cuestas. Estos accidentes ocurren
debido a resbaladas o caidas, las cuales
pueden resultar en graves lesiones. Operar la
recortadora en cuestas requiem mayor
concentraci6n. Si se siente inseguro en una
cuesta, no la recorte.
HACER:
•Nunca permita que los niSos operen la
mdquina.
•Tenga un cuidado extra cuando se acerque
a esquinas donde no hay visibilidad, a los
arbustos, drboles u otros objetos que
pueden interferir con su Ifnea de visi6n.
IV.SERVIClO
•Puede recortar a trav_s de la superficie de •
la cuesta, nunca hacia arriba y hacia abajo.
Proceda con extrema precauci6n cuando
cambie de direcci6n en las cuestas.
• Renueva todos los objetos extra£_os, tales •
como guijarros, ramas, etc.
•Debe prestar atenci6n a hoyos, baches o
protuberancias. Recuerde que la hierba alta •
puede esconder obst&culos.
NO HACER"
•No recorte cerca de pendientes, zanjas o
terraplenes. El operador puede perder la
tracci6n en los pies o el equilibrio.
• No recorte cuestas demasiado inclinadas.
• No recorte en hierba mojada. La reduccibn
en la tracci6n de la pisada puede causar
resbalones.
III.NII_OS
Se pueden producir accidentes tr&gicossi el
operador no presta atenci6n ala presencia de
los niSos. A menudo, los niSos se sienten
atraidos por la maquina y por la actividad de la
siega. Nunca suponga que los niSos van a
permanecer en el mismo lugar donde los vio
por 01tima vez. •
•Mantenga a los nii_osalejados del area de la
siega y bajo el cuidado estricto de otra
persona adulta responsable,
•Est6 alerta y apague la mdquina si hay nii_os
que entran al drea.
• Antes y cuando este retrocediendo, mire
hacia atr_.s y hacia abajo para verificar si
hay nihos pequeSos. 20
Tenga cuidado extra al manejar la gasolina
y los dem_.s combustibles. Son inflamables
y los gases son explosivos.
-Use solamente un envase aprobado.
- Nunca remueva la tapa del dep6sito de
gasolina o agregue combustible con el
motor funcionando. Permita que el motor
se enfrfe antes de voIver a pone
combustible. No fume.
- Nunca vuelva a poner combustible en fa
mdquina en recintos cerrados.
- Nunca almacene la mg=quinaoel envase
del combustible dentro de algen lugar en
donde haya una llama expuesta, tal como
la del calentador de agua.
Nunca haga funcionar una m_iquina dentro
de un area cerrada.
Nunca haga ajustes o reparaciones
mientras el motor estd en marcha.
Desconecte el cable de la bujfa, y
mantdngalo a cierta distancia de 6sta para
prevenir un arranque accidental.
Mantenga las tuercas y los pernos,
especialmente los pemos del accesorio de
la cuchilla, apretados y mantenga el equipo
en buenas condiciones.
Nunca manipule de forma indebida los
dispositivos de seguridad. Controle
regularmente su funcionamiento correcto.
Mantenga la mdquina libre de hierba, hojas
uotras acumulaciones de desperdicio.
Limpie los derrames de aceite o combus-
tible. Permita que la mdquina se enfrfe antes
de almacenada.
Pare e inspeccione el equipo si le pega a un
objeto. Repdrelo, si es necesario, antes de
hacerlo arrancar.
En ning6n caso hay que regular la altura de
las ruedas mientras el motor est_ en
marcha.
Los componentes del receptor de la hierba
van sujetos a desgaste, daSos y deterioro,
que pueden exponer las partes en
movimiento o permitir que objetos sean
disparados. Controlar frecuentemente y
cuando sea necesario sustituir con partes
aconsejadas por el fabricante.
Las cuchillas de la segadora estdn afiladas
y pueden cortar. Cubrir las hojas o Ilevar
guantes, y utilizar precauciones especiales
cuando se efect6a mantenimiento sobre las
mismas.
No cambie el ajuste del regulador del motor
ni exceda su velocidad.
