Craftsman 917.98636 User manual

LAWN TRACTOR
24 HP,*42" Mower
Electric Start
Automatic Transmission
Model No.
917.98636
Operator's Manual
This product has a low emission engine which operates
differently from previously built engines. Before you start the
engine, read and understand this manual.
IMPORTANT:
Read and follow all Safety
Rules and Instructions before
operating this equipment.
For answers to your questions
about this product, Call:
1-800-659-5917
SEARS Craftsman Help Line
5 am - 5 pm, Mon - Sat
* The power rating as declared by the engine manufacturer is the
average gross power output at the specified RPM of a typical
production engine for the engine model measured using SAE
Standards for engine gross power. Please refer to the engine
manufacturer for details
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
Visit our Craftsman website:www.sears.com/craftsman
586027826

2
TABLE OF CONTENTS
WARRANTY
Warranty................................................2
Safety Rules..........................................3
Product Specifications...........................6
Assembly/Pre-Operation .......................7
Operation.............................................10
Maintenance Schedule........................17
Maintenance........................................17
Service and Adjustments.....................22
Storage................................................28
Troubleshooting...................................29
CRAFTSMAN FULL WARRANTY
TWO YEARS ON RIDING EQUIPMENT
When operated and maintained according to all supplied instructions, Warranty will also
cover defects in material and workmanship of the Frame and Front Axle for five years from
the date of purchase
This warranty covers ONLY defects in material and workmanship. Sears will NOT
pay for:
• Expendable items that become worn during normal use, including but not limited to
blades, spark plugs, air cleaners, belts, and oil filters.
• Standard maintenance servicing, oil changes, or tune-ups.
• Tire replacement or repair caused by punctures from outside objects, such as nails,
thorns, stumps, or glass.
• Tire or wheel replacement or repair resulting from normal wear, accident, or improper
operation or maintenance.
• Repairs necessary because of operator abuse, including but not limited to damage
caused by towing objects beyond the capability of the riding equipment, impacting
objects that bend the frame or crankshaft, or over-speeding the engine.
• Repairsnecessarybecauseofoperatornegligence,includingbutnotlimitedto,electrical
and mechanical damage caused by improper storage, failure to use the proper grade
andamountof engineoil,failure tokeepthe deckclearof flammabledebris,or failureto
maintain the riding equipment according to the instructions contained in the operator’s
manual.
• Engine(fuel system) cleaning orrepairs caused by fueldetermined to becontaminated
or oxidized (stale). In general, fuel should be used within 30 days of its purchase date.
• Normal deterioration and wear of the exterior finishes, or product label replacement.
All riding equipment and battery warranty coverage is void if this product is ever used for
commercial or rental purposes.
This warranty applies only while this product is within the United States.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179

3
I. GENERAL OPERATION
• Read,understand,andfollowallinstruc-
tions on the machine and in the manual
before starting.
• Do not put hands or feet near rotating
parts or under the machine. Keep clear
of the discharge opening at all times.
• Only allow responsible adults, who are
familiar with the instructions, to operate
the machine.
• Clearthe area of objectssuch as rocks,
toys, wire, etc., which could be picked
up and thrown by the blades.
• Be sure the area is clear of bystanders
beforeoperating. Stopmachineifanyone
enters the area.
• Never carry passengers.
• Donotmowinreverseunlessabsolutely
necessary. Alwayslookdownandbehind
before and while backing.
• Neverdirectdischargedmaterialtoward
anyone. Avoid discharging material
against a wall or obstruction. Material
may ricochet back toward the operator.
Stop the blades when crossing gravel
surfaces.
• Do not operate machine without the en-
tire grass catcher, discharge chute, or
othersafetydevicesinplaceandworking.
• Slow down before turning.
• Never leave a running machine unat-
tended. Always turn off blades, set
parking brake, stop engine, and remove
keys before dismounting.
• Disengage blades when not mowing.
Shut off engine and wait for all parts to
cometoacompletestopbeforecleaning
themachine,removingthegrasscatcher,
or unclogging the discharge chute.
• Operatemachineonlyindaylightorgood
artificial light.
• Donot operate themachine whileunder
the influence of alcohol or drugs.
• Watch for traffic when operating near or
crossing roadways.
• Useextracarewhenloadingorunloading
the machine into a trailer or truck.
• Alwaysweareyeprotectionwhenoperat-
ing machine.
• Data indicates that operators, age 60
years and above, are involved in a large
percentageofridingmower-relatedinju-
ries. These operators should evaluate
their ability to operate the riding mower
safelyenoughtoprotectthemselvesand
others from serious injury.
• Followthemanufacturer’srecommenda-
tionforwheelweightsorcounterweights.
• Keep machine free of grass , leaves or
otherdebrisbuild-upwhichcantouchhot
exhaust / engine parts and burn. Do not
allow the mower to plow leaves or other
debris which can cause build-up to oc-
cur. Clean any oil or fuel spillage before
operating or storing the machine. Allow
machine to cool before storage.
DANGER: This cutting machine is capable of amputating hands and feet and
throwing objects. Failure to observe the following safety instructions could result
in serious injury or death.
WARNING: Inordertopreventacciden-
tal starting when setting up, transporting,
adjusting or making repairs, always discon-
nect spark plug wire and place wire where
it cannot contact spark plug.
WARNING: Do not coast down a hill in
neutral, you may lose control of the tractor.
WARNING: Tow only the attachments
that are recommended by and comply with
specifications of the manufacturer of your
tractor. Use common sense when towing.
Operate only at the lowest possible speed
whenona slope. Tooheavyof aload,while
on a slope, is dangerous. Tires can lose
traction with the ground and cause you to
lose control of your tractor.
WARNING: Engine exhaust, some of
its constituents, and certain vehicle compo-
nents contain or emit chemicals known to
the State of California to cause cancer and
birth defects or other reproductive harm.
WARNING:Batteryposts,terminalsand
related accessories contain lead and lead
compounds,chemicalsknowntotheStateof
Californiato causecancer and birthdefects
or other reproductive harm. Wash hands
after handling.
SAFETY RULES

4
II. SLOPE OPERATION
Slopes are a major factor related to loss of
control and tip-over accidents, which can
result in severe injury or death. Operation
on all slopes requires extra caution. If you
cannotbackuptheslopeorifyoufeeluneasy
on it, do not mow it.
• Mow up and down slopes, not across.
• Watch for holes, ruts, bumps, rocks, or
other hidden objects. Uneven terrain
could overturn the machine. Tall grass
can hide obstacles.
• Choose a low ground speed so that you
will not have to stop or shift while on the
slope.
• Donotmowonwetgrass.Tiresmaylose
traction.
Always keep the machine in gear when
goingdownslopes.Donotshifttoneutral
and coast downhill.
• Avoid starting, stopping, or turning on a
slope. Ifthetireslosetraction, disengage
the blades and proceed slowly straight
down the slope.
• Keep all movement on the slopes slow
and gradual. Do not make sudden
changes in speed or direction, which
could cause the machine to roll over.
• Use extra care while operating machine
withgrasscatchersorotherattachments;
they can affect the stability of the ma-
chine. Do no use on steep slopes.
• Do not try to stabilize the machine by
putting your foot on the ground.
• Do not mow near drop-offs, ditches,
or embankments. The machine could
suddenly roll over if a wheel is over the
edge or if the edge caves in.
III. CHILDREN
WARNING: CHILDREN CAN BE INJURED
BY THIS EQUIPMENT. The American Acade-
my of Pediatrics recommends that children
be a minimum of 12 year of age before op-
erating a pedestrian controlled lawn mower
and a minimum of 16 years of age before
operating a riding lawn mower.
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the machine
and the mowing activity. Never assume
that children will remain where you last
saw them.
• Keep children out of the mowing area
andinthewatchfulcareofaresponsible
adult other than the operator.
• Be alert and turn machine off if a child
enters the area.
• Before and while backing, look behind
and down for small children.
• Nevercarrychildren,evenwiththeblades
shutoff. Theymayfalloffandbeseriously
injured or interfere with safe machine
operation.Childrenwhohavebeengiven
ridesinthepastmaysuddenlyappearin
themowing area foranother ride andbe
runoverorbackedoverbythemachine.
• Never allow children to operate the ma-
chine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may block your view of a child.
IV. TOWING
• Towonly with amachine that hasa hitch
designedfortowing.Donotattachtowed
equipment except at the hitch point.
• Followthemanufacturer’srecommenda-
tionforweightlimitsfortowedequipment
and towing on slopes.
• Never allow children or others in or on
towed equipment.
• Onslopes,theweightofthetowedequip-
mentmaycauselossoftractionandloss
of control.
• Travelslowly andallowextradistance to
stop.
V. SERVICE
SAFE HANDLING OF GASOLINE
To avoid personal injury or property dam-
age,useextremecareinhandlinggasoline.
Gasoline is extremely flammable and the
vapors are explosive.
• Extinguish all cigarettes, cigars, pipes,
and other sources of ignition.
• Use only approved gasoline container.
• Never remove gas cap or add fuel with
theengine running.Allow engine tocool
before refueling.
• Never fuel the machine indoors.
• Neverstorethemachineorfuelcontainer
where there is an open flame, spark, or
pilot light such as on a water heater or
other appliances.
• Never fill containers inside a vehicle or
on a truck or trailer bed with plastic liner.
Always place containers on the ground
away from your vehicle when filling.
SAFETY RULES

5
• Remove gas-powered equipment from
the truck or trailer and refuel it on the
ground.Ifthisisnotpossible,thenrefuel
suchequipmentwithaportablecontainer,
rather than from a gasoline dispenser
nozzle.
• Keep the nozzle in contact with the rim
of the fuel tank or container opening at
alltimesuntil fuelingiscomplete. Donot
use a nozzle lock-open device.
• Iffuelisspilledonclothing,changecloth-
ing immediately.
• Neveroverfillfueltank.Replacegascap
and tighten securely.
GENERAL SERVICE
• Neveroperatemachineinaclosedarea.
• Keepallnutsandboltstighttobesurethe
equipment is in safe working condition.
• Maintainorreplacesafetyandinstruction
labels, as necessary.
• Be sure the area is clear of bystanders
beforeoperating. Stopmachineifanyone
enters the area.
• Never carry passengers.
• Donotmowinreverseunlessabsolutely
necessary.Alwayslookdownandbehind
before and while backing.
• Never carry children, even with the
blades shut off. They may fall off and
beseriouslyinjuredorinterferewithsafe
machine operation. Children who have
beengivenridesinthepastmaysuddenly
appear in the mowing area for another
ride and be run over or backed over by
the machine.
• Keep children out of the mowing area
andinthewatchfulcareofaresponsible
adult other than the operator.
• Nevertamperwithsafetydevices.Check
their proper operation regularly.
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel
spillageandremoveanyfuel-soakedde-
bris. Allowmachinetocoolbeforestoring.
• If you strike a foreign object, stop and
inspectthemachine.Repair,ifnecessary,
before restarting.
• Never make any adjustments or repairs
with the engine running.
• Checkgrasscatchercomponentsandthe
discharge chute frequently and replace
withmanufacturer’srecommendedparts,
when necessary.
• Mowerbladesaresharp. Wraptheblade
or wear gloves, and use extra caution
when servicing them.
• Checkbrakeoperationfrequently. Adjust
and service as required.
• Be alert and turn machine off if a child
enters the area.
• Before and while backing, look behind
and down for small children.
• Mowupand downslopes(15° Max),not
across.
• Choose a low ground speed so that you
will not have to stop or shift while on the
slope.
• Avoid starting, stopping, or turning on a
slope. Ifthetireslosetraction, disengage
the blades and proceed slowly straight
down the slope.
• If machine stops while going uphill,
disengageblades, shiftintoreverse and
back down slowly.
• Donot turn onslopes unless necessary,
and then, turn slowly and gradually
downhill, if possible.
• Whenloadingorunloadingthismachine,
do not exceed the maximum recom-
mended operation angle of 15°.
SAFETY RULES

6
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Follow a regular schedule in maintaining,
caring for and using your tractor.
• Follow instructions under “Maintenance”
and “Storage” sections of this manual.
• Wear proper Personal Protective Equip-
ment(PPE)whileoperatingthismachine,
including(ata minimum)sturdyfootwear,
eye protection, and hearing protection.
Do not mow in shorts and/or open toed
footwear.
• Alwaysletsomeoneknowyouareoutside
mowing.
WARNING: Thistractorisequippedwith
an internal combustion engine and should
not be used on or near any unimproved
forest-covered, brush-covered or grass-
covered land unless the engine’s exhaust
system is equipped with a spark arrester
meeting applicable local or state laws (if
any). If a spark arrester is used, it should
be maintained in effective working order by
the operator.
InthestateofCaliforniatheaboveisrequired
bylaw(Section4442oftheCaliforniaPublic
Resources Code). Other states may have
similar laws. Federal laws apply on federal
lands. A spark arrester for the muffler is
availablethroughyournearestSearsservice
center (See REPAIR PARTS manual).
CONGRATULATIONS onyourpurchaseof
a new tractor. It has been designed, engi-
neeredandmanufacturedtogiveyouthebest
possible dependability and performance.
Shouldyouexperienceanyproblemyoucan-
noteasilyremedy,pleasecontactaSearsor
otherqualifiedservicecenter. Wehavecom-
petent,well-trainedrepresentativesandthe
proper tools to service or repair this tractor.
Please read and retain this manual. The
instructions will enable you to assemble
and maintain your tractor properly. Always
observe the “SAFETY RULES”.
PRODUCT SPECIFICATIONS
Gasoline Capacity
and type: 2.5 Gallons/9,46 L Regular Unleaded†
Power Rating*: 17,9 KW @ 3600 RPM
Oil Type:
(API: SG-SL) SAE 30 (above 32°F/0°C) SAE 5W30 (below 32°F/0°C)
Oil Capacity: W/ Filter: 64 Oz./1,96L
W/out Filter: 60 Oz./1,77 L
Spark Plug: XC12YC
(Gap: .030" / 0,76 mm)
Charging System: 16 amps @ 3600 RPM
Battery: Amp/Hr: 28
Min. CCA: 230
Case size: U1R
Blade Bolt Torque: 45-55 Ft. Lbs./62-75 Nm
* The power rating as declared by the engine manufac-
tureristheaveragegrosspoweroutputatthespecified
RPMofatypicalproductionenginefortheenginemodel
measuredusingSAEStandardsforenginegrosspower.
Please refer to the engine manufacturer for details.
†Gasoline containing up to 10% ethanol (E10) is
acceptable for use in this machine. The use of
any gasoline exceeding 10% ethanol (E10) will
void the product warranty.

7
Key(s)
Slope Sheet BatteryKeys
(2) Hex Bolts
(2) Nut Keps
UNASSEMBLED PARTS
ASSEMBLY/PRE-OPERATION
Your new tractor has been assembled at the factory with exception of those parts left
unassembled for shipping purposes.
TOOLS REQUIRED FOR ASSEMBLY
A socket wrench set will make assembly
easier. Standard wrench sizes are listed.
(1) 1/2" wrench Tire pressure gauge
(2) 7/16" wrenches Utility knife
Pliers
When right or left hand is mentioned in this
manual,itmeanswhenyouareintheoperating
position(seatedbehindthesteeringwheel).
TO REMOVE TRACTOR FROM
CARTON
UNPACK CARTON
• Remove all accessible loose parts and
parts cartons from carton .
• Cut along dotted lines on all four pan-
els of carton. Remove end panels and
lay side panels flat.
• Check for any additional loose parts or
cartons and remove.
TO CHECK BATTERY
1. Lift seat to raised position.
NOTE:If this battery isput into service after
month and year indicated on label (label is
located between terminals) charge battery
forminimumofonehourat6-10amps.(See
"BATTERY" in Maintenance section of this
manual for charging instructions).
• Forbatteryandbatterycableinstallation
see "REPLACING BATTERY" in the
"Service and Adjustments" section in
this manual.
Label
BEFORE REMOVING TRACTOR
FROM SKID
A
TO ADJUST SEAT
• Sit in seat.
• Liftupadjustmentlever(A)andslideseat
until a comfortable position is reached
which allows you to press clutch/brake
pedal all the way down.
• Release lever to lock seat in position.

8
CHECK TIRE PRESSURE
Thetiresonyourtractorwereoverinflatedat
the factory for shipping purposes. Correct
tire pressure is important for best cutting
performance.
• Reduce tire pressure to PSI shown on
tires.
CHECK DECK LEVELNESS
For best cutting results, mower housing
shouldbeproperlyleveled. See“TOLEVEL
MOWER” in the Service and Adjustments
section of this manual.
✓CHECKLIST
Before you operate your new tractor, we
wish to assure that you receive the best
performance and satisfaction from this
Quality Product.
Please review the following checklist:
✓Allassemblyinstructionshavebeencom-
pleted.
✓No remaining loose parts in carton.
✓Battery is properly prepared and
charged.
✓Seatisadjustedcomfortablyandtightened
securely.
✓All tires are properly inflated. (For ship-
pingpurposes,the tireswereoverinflated
at the factory).
✓Be sure mower deck is properly leveled
side-to-side/front-to-rear for best cutting
results. (Tires must be properly inflated
for leveling).
✓Check mower and drive belts. Be sure
they are routed properly around pulleys
and inside all belt keepers.
✓Check wiring. See that all connections
are still secure and wires are properly
clamped.
✓Before driving tractor, be sure freewheel
control is in “transmission engaged”
position (see “TO TRANSPORT” in the
Operation section of this manual).
Whilelearninghowtouseyourtractor,payex-
traattentiontothefollowingimportantitems:
✓Engine oil is at proper level.
✓Fueltankisfilledwithfresh,clean,regular
unleaded gasoline.
✓Become familiar with all controls, their lo-
cationandfunction. Operatethembefore
you start the engine.
✓Be sure brake system is in safe operating
condition.
✓ Be sure Operator Presence System and
Reverse Operation System (ROS) are
working properly (See the Operation and
Maintenance sections in this manual).
✓Itisimportanttopurgethetransmissionbefore
operating your tractor for the first time. Fol-
lowproperstartingandtransmissionpurging
instructions(See“TOSTARTENGINE”and
“PURGETRANSMISSION”intheOperation
section of this manual).
CHECK FOR PROPER POSITION OF
ALL BELTS
See the figures that are shown for replacing
motion and mower blade drive belts in the
ServiceandAdjustmentssectionofthisman-
ual. Verifythatthebeltsareroutedcorrectly.
CHECK BRAKE SYSTEM
After you learn how to operate your tractor,
checktoseethatthebrakeisoperatingprop-
erly. See“TOCHECKBRAKE”intheService
and Adjustments section of this manual.
NOTE: Youmaynow roll yourtractor off the
skid. Continue using the instructions that
follow to remove the tractor from the skid.
WARNING: Before starting, read, un-
derstand and follow all instructions in the
Operation section of this manual. Be sure
tractor is in a well-ventilated area. Be sure
the area in front of tractor is clear of other
people and objects.
TO ROLL TRACTOR OFF SKID (See
Operation section for location and
function of controls)
1. Raise attachment lift lever to its highest
position.
2. Release parking brake by depressing
clutch/brake pedal.
3. Placefreewheelcontrolin"transmission
disengagedposition"(See“TOTRANS-
PORT” in the Operation section of this
manual).
4. Roll tractor forward off skid.
5. Remove banding holding the deflector
shield up against tractor.
Continue with the instructions that follow.

9
OPERATION
These symbols may appear on your tractor or in literature supplied with the product.
Learn and understand their meaning.
DANGER, KEEP HANDS
AND FEET AWAY
FREE WHEEL
(Automatic Models only)
KEEP AREA CLEAR SLOPE HAZARDS
15
15
(SEE SAFETY RULES SECTION)
BATTERY REVERSE FORWARD
FAST SLOW
ENGINE ON
ENGINE OFF
FUEL
CHOKE
MOWER HEIGHT
REVERSE NEUTRAL HIGH LOW
ATTACHMENT
CLUTCH ENGAGED
PARKING BRAKE
IGNITION SWITCH
ATTACHMENT
CLUTCH DISENGAGED
ENGINE START MOWER LIFT
Failure to follow instructions
could result in serious injury or
death. The safety alert symbol
is used to identify safety inform-
ation about hazards which can
result in death, serious injury
and/or property damage.
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION when used without the alert symbol,
indicates a situation that could result in damage
to the tractor and/or engine.
FIRE indicates a hazard which, if not avoided,
could result in death, serious injury and/or
property damage.
HOT SURFACES indicates a hazard which,
if not avoided, could result in death, serious injury
and/or property damage.
REVERSE
OPERATION
SYSTEM (ROS)
LIGHTS ON CLUTCH/BRAKE
PEDAL
CRUISE CONTROL

10
KNOW YOUR TRACTOR
READ THIS MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR
Compare the illustrations with your tractor to familiarize yourself with the locations of
various controls and adjustments. Save this manual for future reference.
Our tractors conform to the applicable safety standards of the
American National Standards Institute.
(A) ATTACHMENT LIFT LEVER - Used to
raise and lower the mower or other attach-
ments mounted to your tractor.
(B) BRAKE PEDAL - Used for braking the
tractor and starting the engine.
(C) PARKING BRAKE - Locks clutch/
brake pedal into the brake position.
(D) THROTTLE/CHOKE CONTROL -
Used for starting and controlling engine
speed.
(E) ATTACHMENT CLUTCH SWITCH -
Used to engage the mower blades or other at-
tachments mounted to your tractor.
(F) IGNITION SWITCH - Used for starting
and stopping the engine.
(G) REVERSE OPERATION SYSTEM
(ROS) "ON" POSITION - Allows operation
of mower or other powered attachment
while in reverse.
(H) LIGHT SWITCH - Turns the headlights
on and off.
(J) CRUISE CONTROL LEVER - Used to
set forward movement of tractor at desired
speed without holding the forward drive
pedal.
(K) FORWARD DRIVE PEDAL - Used for
forward movement of tractor.
(L) REVERSE DRIVE PEDAL - Used for
reverse movement of tractor.
(M) FREEWHEEL CONTROL - Disen-
gages transmission for pushing or slowly
towing the tractor with the engine off.
(P) SERVICE REMINDER/HOUR METER
- Indicates when service is required for the
engine and mower.
P
J
M
D
G
H
E
K
L
C
F
B
A

11
The operation of any tractor can result in foreign objects thrown into
the eyes, which can result in severe eye damage. Always wear safety
glasses or eye shields while operating your tractor or performing any
adjustments or repairs. We recommend standard safety glasses or a
wide vision safety mask worn over spectacles.
HOW TO USE YOUR TRACTOR
TO SET PARKING BRAKE
Your tractor is equipped with an operator
presence sensing switch. When engine is
running,anyattemptbytheoperatortoleave
theseatwithoutfirstsettingtheparkingbrake
will shut off the engine.
1. Depressbrakepedal(B)allthewaydown
and hold.
2. Pullparking brakelever (C)up andhold,
release pressure from brake pedal (B),
then release parking brake lever. Pedal
should remain in brake position. Make
sureparkingbrakewillholdtractorsecure.
STOPPING
MOWER BLADES -
• To stop mower blades, move attachment
clutchcontroltodisengagedposition( ).
GROUND DRIVE -
• Tostopgrounddrive,depressbrakepedal
all the way down.
IMPORTANT: Forward and reverse drive
pedals return to neutral position when not
depressed.
ENGINE -
• Move throttle control (D) to slow position.
() Attachment
Clutch Control
“Disengaged”
( ) Attachment
Clutch Control
“Engaged”
NOTE: Failuretomovethrottlecontroltoslow
position and allowing engine to idle before
stopping may cause engine to “backfire”.
• Turn ignition key (F) to “STOP” position
andremovekey. Alwaysremovekeywhen
leavingtractortopreventunauthorizeduse.
• Never use choke to stop engine.
IMPORTANT: Leaving the ignition switch in
anypositionotherthan"STOP"willcausethe
battery to discharge and go dead.
NOTE:Undercertainconditionswhentractor
is standing idle with the engine running, hot
engine exhaust gases may cause “brown-
ing” of grass. To eliminate this possibility,
always stop engine when stopping tractor
on grass areas.
CAUTION: Always stop tractor com-
pletely, as described above, before leaving
the operator's position.
D
F
TO MOVE FORWARD AND BACKWARD
The direction and speed of movement
is controlled by the forward and reverse
drive pedals.
1. Start tractor and release parking brake.
2. Slowlydepressforward(K)orreverse(L)
drive pedal to begin movement. Ground
speed increases the further down the
pedal is depressed.
B
C
TO USE THROTTLE CONTROL (D)
Always operate engine at full speed (fast).
• Operating engine at less than full speed
(fast) reduces engine's operating effi-
ciency.
• Full speed (fast) offers the best mower
performance.

12
TO USE CRUISE CONTROL
The cruise control feature can be used for
forward travel only.
SYSTEM CHARACTERISTICS
The cruise control should only be used
while mowing or transporting on relatively
smooth, straight surfaces. Other conditions
suchastrimmingatslowspeedsmaycause
the cruise control to disengage. Do not use
the cruise control on slopes, rough terrian
or while trimmimg or turning.
• Withforwarddrivepedal(K)depressedto
desiredspeed,pullcruisecontrollever(J)
up and hold while lifting your foot off the
pedal, then release the lever.
Todisengagethecruisecontrol,depressthe
brake pedal or tap on forward drive pedal.
JL
K
A
TO ADJUST MOWER CUTTING HEIGHT
The position of the attachment lift lever (A)
determines the cutting height.
• Putattachmentlift leverindesiredcutting
height slot.
The cutting height range is approximately 1
to 4" (25,4 to 101,6 mm). The heights are
measured from the ground to the blade tip
with the engine not running. These heights
are approximate and may vary depending
upon soil conditions, height of grass and
types of grass being mowed.
• Theaveragelawnshouldbecuttoapproxi-
mately 2-1/2" (63,5 mm) during the cool
season and to over 3" (76,2 mm) during
hotmonths.Forhealthierandbetterlook-
ing lawns, mow often and after moderate
growth.
• For best cutting performance, grass over
6"(152,4mm)inheightshouldbe mowed
twice.Makethefirstcutrelativelyhigh;the
second to desired height.
TO ADJUST GAUGE WHEELS
Gauge wheels are properly adjusted when
theyareslightlyoffthe groundwhenmower
is at the desired cutting height in operating
position. Gauge wheels then keep the deck
in proper position to help prevent scalping
in most terrain conditions.
NOTE: Adjust gauge wheels with tractor on
a flat level surface.
1. Adjust mower to desired cutting height
(See “TO ADJUST MOWER CUTTING
HEIGHT” in this section of manual).
2. Withmowerindesiredheightofcutposi-
tion,gaugewheelsshouldbeassembled
sotheyareslightlyofftheground.Install
gaugewheelinappropriatehole.Tighten
securely.
3. Repeat for all, installing gauge wheel in
same adjustment hole.
3/4”
9/16”
TO OPERATE MOWER
Your tractor is equipped with an operator
presence sensing switch. Any attempt
by the operator to leave the seat with the
engine running and the attachment clutch
engaged will shut off the engine. You must
remain fully and centrally positioned in the
seattopreventtheenginefromhesitatingor
cutting off when operating your equipment
on rough, rolling terrain or hills.
1. Select desired height of cut with attach-
ment lift lever.
2. Startmower bladesby engagingattach-
ment clutch control.

13
0
2
8
2
8
ROS "ON" Position Engine "ON" Position
(Normal Operating)
REVERSE OPERATION SYSTEM (ROS)
Your tractor is equipped with a Reverse
Operation System (ROS). Any attempt by
theoperatortotravelinthereversedirection
withtheattachmentclutchengagedwillshut
off the engine unless ignition key is placed
in the ROS "ON" position.
WARNING: Backing up with the at-
tachment clutch engaged while mowing is
stronglydiscouraged.TurningtheROS"ON",
to allow reverse operation with the attach-
ment clutch engaged, should only be done
whentheoperatordecidesitisnecessaryto
reposition the machine with the attachment
engaged. Do not mow in reverse unless
absolutely necessary.
USING THE REVERSE OPERATION
SYSTEM -
Only use if you are certain no children or
otherbystanderswillenterthemowingarea.
1. Depress brake pedal all the way down.
2. With engine running, turn ignition key
counterclockwiseto ROS "ON"position.
3. Look down and behind before and while
backing.
4. Slowly depress reverse drive pedal to
start movement.
5. WhenuseoftheROSisnolongerneeded,
turn the ignition key clockwise to engine
"ON" position.
TO OPERATE ON HILLS
WARNING: Do not drive up or down
hills with slopes greater than 15° and do not
drive across any slope. Use the slope guide
provided at the back of this manual.
• Choose the slowest speed before start-
ing up or down hills.
• Avoidstoppingorchangingspeedonhills.
• If stopping is absolutely necessary, push
brake pedal quickly to brake position and
engage parking brake.
• Torestartmovement,slowlyreleasepark-
ing brake and brake pedal.
• Slowlydepressappropriatedrivepedalto
slowest setting.
• Make all turns slowly.
TOWING CARTS AND OTHER ATTACH-
MENTS
Tow only the attachments that are recom-
mended by and comply with specifications
of the manufacturer of your tractor. Use
common sense when towing. Too heavy of
aload,while onaslope, isdangerous.Tires
can lose traction with the ground and cause
you to lose control of your tractor.
TO STOP MOWER BLADES
Disengage attachment clutch control.
CAUTION: Do not operate the mower
without either the entire grass catcher, on
mowersso equipped,orthe deflectorshield
in place.
TO TRANSPORT
When pushing or towing your tractor, be
sure to disengage transmission by placing
freewheel control in freewheeling position.
Free wheel control is located at the rear
drawbar of tractor.
1.Raise attachment lift to highest position
with attachment lift control.
2.Pullfreewheelcontroloutandintotheslot
andreleasesoitisheldinthedisengaged
position.
• Do not push or tow tractor at more than
two (2) mph (3,2 km/h).
• Toreengagetransmission,reverseabove
procedure.
Transmission Engaged
Transmission Disengaged
NOTE: Toprotect hoodfrom damagewhen
transportingyourtractoronatruckoratrailer,
besurehoodisclosedandsecuredtotractor.
Use an appropriate means of tying hood to
tractor (rope, cord, etc.).

14
SERVICE REMINDER/HOUR METER
Serviceremindershowsthe totalnumberof
hourstheenginehasrunandindicateswhen
the engine or mower needs servicing. After
every 50 hours of operation the oil can icon
willstayonfor2hoursoruntilamanualreset
occurs. To reset the display manually turn
the ignition switch to the on position, then
the off position five times (1 second on, 1
second off). To service engine and mower,
seetheMaintenancesectionofthismanual.
NOTE: Service reminder runs when the
ignition key is in any position but “STOP”.
For accurate reading, be sure key remains
in the “STOP” position when engine is not
running.
BEFORE STARTING THE ENGINE
CHECK ENGINE OIL LEVEL
Theengineinyourtractor hasbeenshipped
from the factory already filled with summer
weight oil.
1. Check engine oil with tractor on level
ground.
2. Remove oil fill cap/dipstick and wipe
clean,reinsertthedipstickandscrewcap
tight,waitforafewseconds,removeand
read oil level. If necessary, add oil until
“FULL” mark on dipstick is reached. Do
not overfill.
• For cold weather operation you should
change oil for easier starting (See the oil
viscositychartintheMaintenancesection
of this manual).
• Tochangeengineoil,seetheMaintenance
section in this manual.
ADD GASOLINE
• Fill fuel tank to bottom of filler neck. Do
not overfill. Use fresh, clean, regular
gasoline with a minimum of 87 octane.
Do not mix oil with gasoline. Purchase
fuel in quantities that can be used within
30 days to ensure fuel freshness.
CAUTION:Wipeoffanyspilledoilorfuel.
Do not store, spill or use gasoline near an
open flame.
IMPORTANT: When operating in tempera-
tures below 32°F (0°C), use fresh, clean
winter grade gasoline to help ensure good
cold weather starting.
CAUTION: Alcohol blended fuels (called
gasohol or using ethanol or methanol) can
attract moisture which leads to separation
andformationofacidsduringstorage. Acidic
gascandamagethefuelsystemofanengine
whileinstorage. Toavoid engineproblems,
the fuel system should be emptied before
storage of 30 days or longer. Drain the gas
tank, start the engine and let it run until the
fuel lines and carburetor are empty. Use
freshfuelnextseason. SeeStorageInstruc-
tions for additional information. Never use
engineorcarburetorcleanerproductsinthe
fuel tank or permanent damage may occur.
Fuelstabilizerisanacceptablealternativein
minimizingtheformationoffuelgumdeposits
duringstorage. Add stabilizerto gasolinein
fueltankorstoragecontainer. Alwaysfollow
the mix ratio found on stabilizer container.
Run engine at least 10 minutes after adding
stabilizer to allow the stabilizer to reach the
carburetor. Do not empty the gas tank and
carburetor if using fuel stabilizer.
TO START ENGINE
Whenstartingtheengine forthefirsttimeor
if the engine has run out of fuel, it will take
extra cranking time to move fuel from the
tank to the engine.
1. Ensure freewheel control is in the trans-
mission engaged position.
2. Sitonseatinoperatingposition,depress
brake pedal and set parking brake.
3. Move attachment clutch to disengaged
position.
4. Move throttle control to choke position.
NOTE: Before starting, read the warm and
cold starting procedures below.
5. Insert key into ignition and turn key
clockwise to start position and release
keyas soonas enginestarts. Donotrun
startercontinuouslyformorethanfifteen
seconds per minute. If the engine does
not start after several attempts, move
throttle control to fast position, wait a
few minutes and try again. If engine still
does not start, move the throttle control
back to the choke position and retry.

15
WARM WEATHER STARTING
(50°F (10°C) and above)
6. When engine starts, move the throttle
control to the fast position.
• The attachments and ground drive
can now be used. If the engine does
notaccept the load, restartthe engine
and allow it to warm up for one minute
using the choke as described above.
COLD WEATHER STARTING
(50°F (10°C) and below)
6. Whenenginestarts,leavethrottlecontrol
in choke position until engine warms up
and begins to run roughly. Once rough
running begins, immediately move the
throttlecontroltothefastposition.Engine
warm-upmaytakefromseveralseconds
to several minutes (the colder the tem-
perature, the longer the warm-up).
AUTOMATIC TRANSMISSION WARM UP
Before driving the unit in cold weather, the
transmission should be warmed up as fol-
lows:
1. Ensure the tractor is on level ground.
2. Release the parking brake and let the
brakeslowlyreturntooperatingposition.
3. Allowoneminutefortransmissiontowarm
up. This can be done during the engine
warm up period.
• The attachments can also be used
duringtheenginewarm-upperiodafter
thetransmissionhasbeenwarmedup.
PURGE TRANSMISSION
CAUTION: Neverengage ordisengage
freewheel lever while the engine is running.
Toensureproperoperationandperformance,
it is recommended that the transmission be
purged before operating tractor for the first
time.Thisprocedurewillremoveanytrapped
air inside the transmission which may have
developed during shipping of your tractor.
IMPORTANT: Should your transmission
require removal for service or replacement,
itshouldbepurgedafterreinstallationbefore
operating the tractor.
1. Place tractor safely on a level surface -
that is clear of objects and open - with
engine off and parking brake set.
2. Disengage transmission by placing
freewheelcontrolindisengagedposition
(See “TO TRANSPORT” in this section
of manual).
3. Sitting in the tractor seat, start engine.
Aftertheengineisrunning,movethrottle
controltoslowposition.Disengagepark-
ing brake.
CAUTION: At any time, during step 4,
theremaybemovementofthedrivewheels.
4. Depressforwarddrivepedaltofullforward
positionandholdforfive(5)secondsand
release pedal. Depress reverse drive
pedal to full reverse position and hold
for five (5) seconds and release pedal.
Repeat this procedure three (3) times.
5. Shutoff engine and set parking brake.
6. Engagetransmissionbyplacingfreewheel
control in engaged position (See “TO
TRANSPORT”inthissectionofmanual).
7. Sitting in the tractor seat, start engine.
Aftertheengineisrunning,movethrottle
control to half (1/2) speed. Disengage
parking brake.
8. Drive tractor forward for approximately
five (5) feet (1,5 m) then backwards for
five (5) feet (1,5 m). Repeat this driving
procedure three times.
Your transmission is now purged and now
ready for normal operation.

16
MOWING TIPS
• DO NOT use tire chains when the mower
housing is attached to tractor.
• Mowershouldbeproperlyleveledforbest
mowing performance. See “TO LEVEL
MOWER HOUSING” in the Service and
Adjustments section of this manual.
• The left hand side of mower should be
used for trimming.
• Drivesothatclippingsaredischargedonto
the area that has already been cut. Have
thecutareatotherightofthetractor. This
will result in a more even distribution of
clippings and more uniform cutting.
• Whenmowinglargeareas,startbyturning
totherightso thatclippingswilldischarge
away from shrubs, fences, driveways,
etc. After one or two rounds, mow in the
opposite direction making left hand turns
until finished .
• If grass is extremely tall, it should be
mowedtwice to reduce loadand possible
fire hazard from dried clippings. Make
first cut relatively high; the second to the
desired height.
• Do not mow grass when it is wet. Wet
grass will plug mower and leave undesir-
able clumps. Allow grass to dry before
mowing.
• Always operate engine at full throttle
when mowing to assure better mow-
ing performance and proper discharge
of material. Regulate ground speed by
selecting a low enough gear to give the
mowercuttingperformanceaswellasthe
quality of cut desired.
• When operating attachments, select a
ground speed that will suit the terrain and
give best performance of the attachment
being used.

17
LUBRICATION CHART
GENERAL RECOMMENDATIONS
The warranty on this tractor does not cover
items that have been subjected to operator
abuse or negligence. To receive full value
from the warranty, operator must maintain
tractor as instructed in this manual.
Some adjustments will need to be made
periodicallytoproperlymaintainyourtractor.
At least once a season, check to see if
you should make any of the adjustments
described in the Service and Adjustments
section of this manual.
• At least once a year you should replace
the spark plug, clean or replace air filter,
and check blades and belts for wear. A
new spark plug and clean air filter assure
proper air-fuel mixture and help your en-
gine run better and last longer.
BEFORE EACH USE
1. Check engine oil level.
2. Check brake operation.
3. Check tire pressure.
4. Check operator presence and
ROS systems for proper operation.
5. Check for loose fasteners.
IMPORTANT: Donot oilorgrease thepivot
points which have special nylon bearings.
Viscous lubricants will attract dust and dirt
thatwillshortenthelifeoftheself-lubricating
bearings. Ifyoufeeltheymustbelubricated,
use only a dry, powdered graphite type
lubricant sparingly.
T
R
A
C
T
0
R
1 - Change more often when operatingunder a heavy load or in high ambient temperatures
2 - Service more often when operatingin dirty or dusty conditions.
E
N
G
I
N
E
3
2
2
2
2
3 - Replace blades more often when mowingin sandy soil.
4 - Not required if equipped with maintenance-free battery.
5 - See Cleaningin Maintenance Section.
1 ,
1,2
2
4
5
1,2
BEFORE
EACH
USE
EVERY
8
HOURS
EVERY
25
HOURS
EVERY
50
HOURS
EVERY
100
HOURS
EVERY
SEASON
BEFORE
STORAGE
Inspect Muffler/Spark Arrester
Clean Air Filter
Change Engine Oil (models with oil filter)
Replace Air Filter Paper Cartridge
Replace Spark Plug
Check Engine Oil Level
Clean Engine CoolingFins
Clean Air Screen
Replace Oil Filter (If equipped)
Replace Fuel Filter
Change Engine Oil ( models without oil filter)
Lubrication Chart
Check Brake Operation
Check Battery Level
Check Tire Pressure
Clean Battery and Terminals
MAINTENANCE
SCHEDULE
Check for Loose Fasteners
Check/Replace Mower Blades
Che
Clean Debris Off SteeringPlate
ck Transaxle Cooling
Che
Check Operator Presence & ROS Systems
ck V-Belts
Check Mower Levelness
MAINTENANCE
➀General Purpose Grease
➁RefertoMaintenance“ENGINE”Section.
02501
➁ Engine
➀ Front
Wheel
Bearing
Zerk
➀ Spindle
Zerk ➀ Spindle
Zerk
➀ Front Wheel
Bearing Zerk
➀ Steering
Sector
Gear
Teeth ➁ Mandrel
Zerks

18
BLADE REMOVAL
1. Raisemowertohighestpositiontoallow
access to blades.
NOTE: Protectyour hands withgloves and/
or wrap blade with heavy cloth.
2. Remove blade bolt by turning counter-
clockwise.
3. Installnewbladewithstamped"GRASS
SIDE" facing the ground.
IMPORTANT: To ensure proper assembly,
center hole in blade must align with star on
mandrel assembly.
4. Install and tighten blade bolt securely
(45-55 Ft. Lbs./62-75 Nm).
IMPORTANT: Special blade bolt is heat
treated.
TRACTOR
Always observe safety rules when perform-
ing any maintenance.
BRAKE OPERATION
If tractor requires more than 5 feet (1,5 m)
to stop at highest speed in highest gear on
a level, dry concrete or paved surface, then
brake must be serviced. (See “TO CHECK
BRAKE” in the Service and Adjustments
section of this manual).
TIRES
• Maintain proper air pressure in all tires
(See the side of tires for proper PSI.)
• Keep tires free of gasoline, oil, or insect
control chemicals which can harm rubber.
• Avoid stumps, stones, deep ruts, sharp
objectsandotherhazardsthatmaycause
tire damage.
NOTE: To seal tire punctures and prevent
flat tires due to slow leaks, tire sealant may
be purchased from your local parts dealer.
Tire sealant also prevents tire dry rot and
corrosion.
OPERATOR PRESENCE SYSTEM AND
REVERSE OPERATION SYSTEM (ROS)
Be sure operator presence and reverse
operation systems are working properly. If
your tractor does not function as described,
repair the problem immediately.
• The engine should not start unless the
brake pedal is fully depressed, and the
attachment clutch control is in the disen-
gaged position.
CHECKOPERATORPRESENCESYSTEM
• When the engine is running, any attempt
by the operator to leave the seat without
firstsetting theparking brake shouldshut
off the engine.
• When the engine is running and the at-
tachment clutch is engaged, any attempt
by the operator to leave the seat should
shut off the engine.
• Theattachmentclutchshouldneveroper-
ate unless the operator is in the seat.
CHECK REVERSE OPERATION (ROS)
SYSTEM
• Whentheengineisrunningwiththeignition
switchintheengine"ON"positionandthe
attachment clutch engaged, any attempt
by the operator to drive in reverse should
shut off the engine.
• Whentheengineisrunningwiththeignition
switch in the ROS "ON" position and the
attachment clutch engaged, any attempt
by the operator to drive in reverse should
NOT shut off the engine.
BLADE CARE
Forbestresultsmowerbladesmustbesharp.
Replace worn, bent or damaged blades.
CAUTION:Useonlyareplacementblade
approvedbythemanufacturerofyourtractor.
Using a blade not approved by the manu-
facturer of your tractor is hazardous, could
damageyourtractorandvoidyourwarranty.
Ros "On"
Position Engine "On" Position (Normal Operating)
Blade
Blade Bolt
(Special)
Center Hole Star
Mandrel
Assembly
BATTERY
Your tractor has a battery charging system
whichis sufficientfor normal use. However,
periodic charging of the battery with an au-
tomotive charger will extend its life.
• Keep battery and terminals clean.
• Keep battery bolts tight.
• Keep small vent holes open.
• Recharge at 6-10 amperes for 1 hour.
NOTE: The original equipment battery on
your tractor is maintenance free. Do not
attempt to open or remove caps or covers.
Adding or checking level of electrolyte is
not necessary.

19
V-BELTS
CheckV-beltsfordeteriorationandwearafter
100hoursofoperationandreplaceifneces-
sary. The belts are not adjustable. Replace
belts if they begin to slip from wear.
TRANSAXLE COOLING
Thetransmissionfanandcoolingfinsshould
be kept clean to assure proper cooling.
Do not attempt to clean fan or transmission
while engine is running or while the trans-
mission is hot. To prevent possible damage
to seals, do not use high pressure water or
steam to clean transaxle.
• Inspect cooling fan to be sure fan blades
are intact and clean.
• Inspectcoolingfinsfordirt,grassclippings
andothermaterials. Topreventdamageto
seals, do not use compressed air or high
pressure sprayer to clean cooling fins.
TRANSAXLE PUMP FLUID
The transaxle was sealed at the factory and
fluid maintenance is not required for the life
of the transaxle. Should the transaxle ever
leak or require servicing, contact your near-
est Sears or other qualified service center.
TO CLEAN BATTERY AND TERMINALS
Corrosionanddirtonthebatteryandterminals
can cause the battery to “leak” power.
1. Remove terminal guard.
2. Disconnect BLACK battery cable first
then RED battery cable and remove
battery from tractor.
3. Rinse the battery with plain water and
dry.
4. Clean terminals and battery cable ends
with wire brush until bright.
5. Coatterminalswithgreaseorpetroleum
jelly.
6. Reinstall battery (See “REPLACING
BATTERY" in the Service and Adjust-
ments section of this manual).
TEMPERATURE RANGE ANTICIPATED BEFORE NEXT OIL CHANGE
SAE VISCOSITY GRADES
-20 0 30 40 80 100
-30 -20 0 20 30 40
F
C
32
-10 10
60
5W-30
SAE 30
ENGINE
LUBRICATION
Onlyusehighqualitydetergentoilratedwith
APIserviceclassificationSG-SL. Selectthe
oil’s SAE viscosity grade according to your
expected operating temperature.
NOTE: Although multi-viscosity oils (5W30,
10W30etc.)improvestartingincoldweather,
they will result in increased oil consumption
when used above 32°F/0°C. Check your
engine oil level more frequently to avoid
possible engine damage from running low
on oil.
Change the oil after every 50 hours of
operationoratleastonceayearifthetractor
is not used for 50 hours in one year.
Checkthecrankcaseoillevelbeforestarting
the engine and after each eight (8) hours
of operation. Tighten oil fill cap/dipstick
securely each time you check the oil level.
02463
CAP
DOCKING
POSITION
OIL DRAIN
EXTENSION
TO CHANGE ENGINE OIL
Determine temperature range expected
before oil change. All oil must meet API
service classification SG-SL.
• Ensure tractor is on level surface.
• Oil will drain more freely when warm.
• Catch oil in a suitable container.
1. Remove oil fill cap/dipstick. Be careful
nottoallowdirttoentertheenginewhen
changing oil.
2. Slideoildrainextensionfromthedocking
position on the engine blower housing
and extend outward from engine.
3. To open, twist cap counter-clockwise
4. After oil is drained completely, replace
cap and twist clockwise until it stops.
5. Re-attach oil drain extension to engine
blower housing.
6. Refill engine with oil through oil fill dip-
stick tube. Pour slowly. Do not overfill.
For approximate capacity see “PROD-
UCT SPECIFICATIONS” section of this
manual.
7. Use gauge on oil fill cap/dipstick for
checking level. For accurate reading,
tighten dipstick cap securely onto the
tube before removing dipstick. Keep oil
at “FULL” line on dipstick. Tighten cap
onto the tube securely when finished.

20
ENGINE OIL FILTER
Replacetheengine oilfiltereveryseasonor
every other oil change if the tractor is used
more than 100 hours in one year.
AIR FILTER
Your engine will not run properly using a
dirty air filter. Service air cleaner more often
under dusty conditions.
ENGINE COOLING SYSTEM
To ensure proper cooling, make sure the
grass screen, cooling fins, and other exter-
nal surfaces of the engine are kept clean
at all times.
Every 100 hours of operation (more often
under extremely dusty, dirty conditions),
removetheblowerhousingandothercooling
shrouds.Cleanthecoolingfinsandexternal
surfaces as necessary. Ensure the cooling
shrouds are reinstalled.
NOTE:Operatingtheengine withablocked
grass screen, dirty or plugged cooling fins,
and/or cooling shrouds removed will cause
engine damage due to overheating.
MUFFLER
Inspect and replace corroded muffler and
sparkarrester(ifequipped)asitcouldcreate
a fire hazard and/or damage.
00667
Fuel Filter
Clamp
Clamp
IN-LINE FUEL FILTER
Thefuelfiltershouldbereplacedonceeach
season. If fuel filter becomes clogged, ob-
structingfuelflowtocarburetor,replacement
is required.
1. With engine cool, remove filter and plug
fuel line sections.
2. Placenewfuelfilterinpositioninfuelline
with arrow pointing towards carburetor.
SPARK PLUG(S)
Replace spark plugs at the beginning of
each mowing season or after every 100
hours of operation, whichever occurs first.
Spark plug type and gap setting are shown
in “PRODUCT SPECIFICATIONS” section
of this manual.
3. Be sure there are no fuel line leaks and
clamps are properly positioned.
4. Immediatelywipeupanyspilledgasoline.
CLEAN AIR SCREEN
The air screen is over the air intake blower
located on top of engine. The air screen
mustbekeptfreeof dirtandchafftoprevent
enginedamagefromoverheating. Cleanwith
a wire brush or compressed air to remove
dirt and stubborn dried gum fibers.
CLEANING
• Clean engine, battery, seat, finish, etc.
of all foreign matter.
• Cleandebrisfromsteeringplate. Debris
canrestrictclutch/brakepedalshaftmove-
ment, causing belt slip and loss of drive.
CAUTION: Avoid all pinch points and
movable parts
• Keep finished surfaces and wheels free
of all gasoline, oil, etc.
• Protectpaintedsurfaceswithautomotive
type wax.
Except for the washout port (if equipped),
we do not recommend using a garden hose
or pressure washer to clean the outside of
yourtractorunlesstheengineandtransmis-
sion are covered to keep water out. Water
in engine or transmission will shorten the
useful life of your tractor. Use compressed
air or a leaf blower to remove grass, leaves
and trash from outside tractor and mower.
Steering System, Dash, Fender
and Mower Not Shown
Clutch/brake pedal
Steering
Plate
Clean
top side
