Craftsman WEEDWACKER 358.745170 User manual

Instruction Manual
ICRRFTSlVlRN°I
5.5 Amp Motor
17 Inch Cutting Path/0.080 In. Line
ELECTRIC WEEDWACKER ®
Model No.
358.745170
•Safety
• Assembly
•Operation
•Maintenance
•Espa_ol
®
WARNING:
Read and follow all Safety Rules and Operating
Instructions before first use of this product.
_) For answers to your questions about this product:
Call 7 am-7 pm, Mon-Sat; Sun, 10 am-7 pm
•1-800-235-5878 <.ou,slistedare CentraI Time)
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
530088998 I/9/03

Limited Warranty Statement 2 Parts Available 8
Safety Rules 2 Storage 9
Assembly 4 Troubleshooting Table 9
Operation 5
Maintenance 7 Spanish 10
Service & Adjustments 8 Parts Ordering Back Cover
FULL ONE YEAR WARRANTY ON CRAFTSMAN ELECTRIC WEEDWACKER ®
LINE TRIMMER
If this Craftsman Electric Weedwacker ®Line Trimmer fails to perform properly
due to a defect in material or workmanship within (1) one year from the date of
purchase, Sears will replace it free of charge,
This warranty does not cover the nylon line,
WARRANTY SERVICE iS AVAILABLE BY RETURNING THE CRAFTSMAN ELECTRIC
WEEDWACKER¢">LINETRIMMER TO THE NEAREST SEARS STOREOR SERVICE CEN-
TER IN THE UNITED STATES,
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state,
Sears, Roebuck and Co., D/817WA, Hoffman Estates, IL 60179
_WARNING: When using elec-
tric gardening appliances, basic safe-
ty precautions should always be fol-
lowed to reduce the risk of fire,
electric shock, and serious injury.
Read and follow all instructions.
SAFETY INFORMATION
ON THE UNIT
This power unit can be dangerous! Op-
erator is responsible for following the
warnings and instructions in this manu-
al and on the unit. Read entire instruc-
tion manual before using unit! Be thor-
oughly familiar with the controls and
the proper use of the unit. Restrict the
use of this unit to persons who read,
understand, and follow unit and manual
instructions and warnings. Never allow
children to operate this unit. Close
attention is necessary when used near
children.
,_DANGER: Never use blades,
wire, or flailing devices. Unit is de-
signed for line trimmer use only. Use of
any other accessories or attachments
will increase the risk of injury.
2
@©0
_WARNING: Trimmer line
throws ob ects violently. You and oth-
ers can be b nded/njured. Wear
safety glasses, boots, and leg protec-
tion. Keep body parts clear of rotating
line.
Safety Glasses or similar eye protection
==4oots
Keep children, bystanders, and ani-
mals 50 feet (15 meters) away. If ap-
proached stop unit immediately.
If situations occur which are not
covered in this manual, use care and
good udgement. If you need
assistance, call 1-800-235-5878.
OPERATOR SAFETY
• Dress properly. Always wear safety
glasses or similar eye protection
when operating, or performing
maintenance on your unit. (Safety
glasses are available.) Always wear

faceordustmaskifoperationis
dusty.Alwayswearheavy,long
pants,longsleeves,boots,and
gloves.Donotgobarefootorwear
sandals.
• Securehairaboveshoulderlength.
Secureorremovelooseclothing
andjewelryorclothingwithloosely
hangingties,straps,tassels,etc.
Theycanbecaughtinmoving
parts.
• Beingfullycoveredalsohelpspro-
tectyoufromdebrisandpiecesof
toxicplantsthrownbyspinningline.
• StayAlert.Donotoperateunit
whenyouaretired,ill,upset,orun-
derinfluenceofalcohol,drugs,or
medication.Watchwhatyouaredo-
ing;usecommonsense.
• Avoidunintentionalstartingofthe
unit.Nevercarryunitwithyourfin-
gerontheswitch.Besurethe
switchisintheOFFpositionand
nevertouchtheswitchwhencon-
nectingextensioncord.
ELECTRICALSAFETY
_WARNING: Avoidadangerous
environment.Toreducetheriskof
electricalshock,donotuseinrain,in
damporwetlocations,oraround
swimmingpools,hottubs,etc.Do
notexposetosnow,rain,orwaterto
avoidthepossibilityofelectrical
shock.
*Use voltage supply as shown on unit.
* Avoid dangerous situations. Do not
use in the presence of flammable
liquids or gases to avoid creating a
fire or explosion and/or causing
damage to unit.
* To reduce the risk of electrical shock,
this appliance has a polarized plug
(one blade is wider than the other)
and will require the use of a polarized
extension cord. The appliance plug
will fit into a polarized extension cord
only one way. If the plug does not fit
fully into the extension cord, reverse
the plug. If the plug still does not fit,
obtain a correct polarized extension
cord. A polarized extension cord will
require the use of a polarized wall
outlet. This plug will fit into the polar-
ized wall outlet only one way. If plug
does not fit fully into the wall outlet,
reverse the plug. If the plug still does
not fit, contact a qualified electrician
to install the proper wall outlet. Do not
change the equipment plug, exten-
sion cord receptacle, or extension
cord plug in any way.
• To reduce risk of electrical shock,
use extension cords specifically
marked as suitable for outdoor ap-
pliances having electrical rating not
less than the rating of unit. Cord
must be marked with suffix "W-A"
(in Canada "W"). Make sure your
extension cord is in good condition.
inspect extension cord before use
and replace if damaged. Do not use
adamaged cord. Cord insulation
must be intact with no cracks or de-
terioration. Plug connectors must
be undamaged. An undersized ex-
tension cord will cause a drop in
line voltage resulting in loss of pow-
er and overheating. If in doubt, use
the next heavier gauge. The lower
the gauge number, the heavier the
cord (see SELECT AN EXTENSION
CORD). Do not use multiple cords.
• Do not abuse cord. Never carry the
unit by the extension cord or yank
extension cord to disconnect unit.
• Use cord retainer to prevent discon-
nection of extension cord from unit.
See ATTACH THE EXTENSION CORD
TO YOUR TRIMMER in the OPERA-
TION section.
• Do not use the unit if the switch
does not turn the unit on and off
properly. Repairs to the switch must
be made by your Sears Service
Center.
• Keep the extension cord clear of
operator and obstacles at all times.
Do not expose cords to heat, oil,
water, or sharp edges.
• To avoid the possibility of electric
shock, avoid body contact with any
_leroundedconductor, such as metal
nces or pipes.
• Ground Fault Circuit Interrupter
(GFCI) protection should be pro-
vided on circuit or outlet to be used.
Receptacles are available having
built-in GFCI protection and may be
used for this measure of safety.
UNIT SAFETY
• Inspect unit before use. Replace
damaged parts. Make sure all han-
dles, guards, and fasteners are in
place and securely fastened. Parts
that are damaged must be repaired
or replaced by aSears Service
Center. This includes head parts
that are cracked or chipped,
guards, and any other part that is
damaged.
• Do not repair unit yourself.
3

• Use only 0.080 inch (2 ram) diame-
ter recommended trimmer line (see
SERVICE AND ADJUSTMENTS). Nev-
er use wire, rope, string etc.
• Use specified trimmer spool. Make
sure spool is properly installed and
the cover is securely fastened.
• Use only Craftsman replacement
parts and accessories as recom-
mended.
CUTTING SAFETY
• Inspect area to be cut. Remove ob-
jects (rocks, broken glass, nails,
wire, string, etc.) which can be
thrown or become entangled in cut-
ting head.
• Do not overreach or stand on un-
stable support. Keep firm footing
and balance.
• Keep the cutting head below waist
level. Do not raise handles above
your waist. Cutting head can come
dangerously close to your body.
• Keep away from cutting head and
spinning line.
• Use unit properly. Use only for trim-
ming, scalping, mowing, and
sweeping. Do not force unit, it will
do the job better and with less risk
of injury at the rate for which it was
designed.
• Use only in daylight or in good artifi-
cial light.
MAINTENANCE SAFETY
_WARNING: Disconnect unit
from the power supply before per-
forming maintenance, or when
changing trimmer line.
• Maintain unit according to recom-
mended procedures. Keep cutting
line at proper length. Follow instruc-
tions for changing trimmer line.
• Have all service and maintenance
not explained in this manual per-
formed by aSears Service Center
to avoid creating a hazard.
• Never douse or squirt the unit with
water or any other liquid. Clean unit
and labels with adamp sponge.
Keep handles dry, clean, and free
from oil and grease.
• Keep the air vents clean and free of
debris to avoid overheating the mo-
tor. Clean after each use.
TRANSPORTING AND STORAGE
• Stop the unit and disconnect the
power source when not in use.
• Carry the unit with motor stopped.
• Store the unit so the line fimiter blade
(on underside of shield) cannot
cause injury.
• Store unit indoors in a high, dry
place out of the reach of children.
Store unit unplugged.
DOUBLE INSULATION
CONSTRUCTION
This unit is double insulated to help
protect against electric shock. Double
insulation construction consists of two
separate "layers" of electrical insula-
tion instead of grounding.
Tools built with this insulation system
are not intended to be grounded. No
grounding means is provided on this
unit, nor should a means of ground-
ing be added to this unit.
Safety precautions must be observed
when operating any electrical tool.
The double insulation system only
provides added protection against in-
jury resulting from an internal electri-
cal insulation failure.
WARNING: All electrical repairs
to this unit, including housing, switch,
motor, etc., must be diagnosed and re-
paired by qualified service personnel.
Replacement parts for adouble insu-
lated appliance must be recommended
by the manufacturer. A double insu-
lated appliance is marked with the
words "double insulation" or "double
insulated". The symbol (square within
a square) [] may also be marked on
the appliance. Failure to have the unit
repaired by qualified service personnel
can cause the double insulation
construction to become ineffective and
result in serious injury.
SAVE THESE INSTRUCTIONS
CARTON CONTENTS
Check carton contents against the
following list.
Model 358.745170
• Trimmer
• Shield
• Assist Handle
Examine parts for damage. Do not
use damaged parts.
NOTE: If you need assistance or find
that parts are missing or damaged,
call 1-800-235-5878.
4

ASSEMBLY
_ WARNING: If received as-
sembled, review all assembly steps
to ensure your unit is properly as-
sembled and all fasteners are secure.
ATTACHING THE ASSIST HANDLE
_WARNING: When attaching the
assist handle, be sure it remains be-
tween the trigger and the safety label.
1. Loosen and remove wing nut and
clamp from assist handle.
2. Attach handle to tube in an up-
right position between the trigger
and the safety label.
3. Insert tongue of clamp into slot on
assist handle. Re-install wing nut.
4. Tighten wing nut securely.
Assist Handle -
KNOW YOUR TRIMMER
ATTACHING THE SHIELD
_WARNING: The shield must be
properly installed. The shield pro-
vides partial protection from the risk
of thrown objects to the operator and
others. Your unit is equipped with a
line limiter blade, which cuts excess
line to the proper length while run-
ning. The line limiter blade (on under-
side of shield) is sharp and can cut
you.
• Assemble parts as shown.
• Tighten parts securely.
Siel d
NOTE: _iter
and use washerand \Blade
wing nut from this Wing Nut
bolt forassembling Washer
shield.
READ THIS INSTRUCTION MANUALAND SAFETY RULES BEFORE OPERATING YOUR
UNI]_ Compare the illustrations with your unit to familiarize yourself with the loca-
tion of the various controls and adjustments, Save this manual for future refer-
ence,
Trimmer Head with
0.080 inch Trimmer Line
Line Limiter Blade
Motor
Assist Handle Housing-,.
Trigger Switch l
Cord Retainer Ptgtail
Plug
PIGTAIL PLUG
The PIGTAIL PLUG is where you at-
tach your extension cord to the unit.
TRIGGER SWITCH
The TRIGGER SWITCH is used to turn
on the unit. Squeeze the trigger
switch to operate the unit. Release to
stop.
LINE LIMITER BLADE
The LINE LIMITER BLADE cuts the
cutting line to the proper cutting
length.
ASSIST HANDLE
The ASSIST HANDLE is used to help
hold and guide the unit.
TRIMMER HEAD
The TRIMMER HEAD holds cutting line
and rotates during operation.
5

OPERATING INSTRUCTIONS
Use only a voltage supply as speci-
fied on your unit.
SELECT AN EXTENSION CORD
Extension Cord Gauge Chart
Length of Cord Gauge
25 Ft. (7.5 m) 18 Gauge
50 Ft. (15 m) 16 Gauge
100 Ft. (30 m) 16 Gauge
Extension cords are available for this
unit at Sears.
ATTACH THE EXTENSION
CORD TO YOUR TRIMMER
Loop your extension cord through the
handle and around the hook. Ensure
the plug and cord are firmly and fully
engaged.
CORRECT OPERATING POSITION
Trimming
Cut only from right to left.
_ WARNING: Always wear eye
protection. Never lean over the trim-
mer head. Rocks or debris can rico-
chet or be thrown into eyes and face
and cause blindness or other serious
injury. Do not use trimmer for edging.
When operating unit, stand as shown
and check for the following:
• Wear eye protection and heavy
clothing.
• Hold trigger handle with right hand
and assist handle with left hand.
• Keep unit below waist level.
• Cut only from your right to your left to
ensure debris is thrown away from
you. Without bending over, keep line
near and parallel to the ground and
not crowded into material being cut.
ADVANCING THE CUTTING LINE
The cutting head advances line au-
tomatically. Do not tap head on the
ground to advance line. This may
break partsand cause cutting head to
malfunction.
Upon unit start up, the line will advance
automatically to the correct cutting path
length.
Always keep the shield in place when
the tool is being operated.
_WARNING: Use only 0.080
inch (2 mm) diameter round line.
Other sizes and shapes of line will
not advance properly and will result in
improper cutting head function or can
cause serious injury. Do not use other
materials such as wire, string, rope,
etc. Wire can break off during cutting
and become a dangerous missile that
can cause serious =njury.
CUTTING METHODS
TRIMMING - Hold the bottom of the
trimmer head about 3 inches (8 cm)
above the ground and at an angle. Al-
low only the tip of the line to make con-
tact. Do not force trimmer line into work
area.
Trimming
3 inches (8 cm)
above ground
SCALPING - The scalping technique
removes unwanted vegetation. Hold
the bottom of the trimmer head about
3 inches (8 cm) above the ground
and at an angle. Allow the tip of the
line to strike the ground around trees,
posts, monuments, etc. This tech-
nique increases line wear.
Scalping
6

MOWING - Your trimmer is ideal for
mowing in places conventional lawn
mowers cannot reach. In the mowing
position, keep the line parallel to the
ground. Avoid pressing the head into
the ground as this can scalp the
ground and damage the tool.
Mowing
SWEEPING - The fanning action of
the rotating line can be used for a
quick and easy clean up. Keep the line
parallel to and above the surfaces be-
ing swept and move the tool from side
to side.
Sweeping /___
CUSTOMER RESPONSIBILITIES
,_ WARNING: Disconnect power source before performing maintenance.
CARE & MAINTENANCE TASK
Check for loose fasteners and parts
Check for damaged or worn parts
Inspect and clean unit and labels
WHEN TO PERFORM
Before each use
Before each use
After each use
GENERAL RECOMMENDATIONS
The warranty on this unit does not
cover items that have been subjected
to operator abuse or negligence. To
receive full value from the warranty,
the operator must maintain unit as
instructed in this manual. Various ad-
justments will need to be made peri-
odically to properly maintain your unit.
BEFORE EACH USE
CHECK FOR LOOSE
FASTENERS AND PARTS
•Housing Screws
• Assist Handle
• Debris Shield
REPLACING THE LINE
CHECK FOR DAMAGED OR
WORN PARTS
Contact Sears Service Center for re-
placement of damaged or worn parts.
• Trigger Switch - Ensure switch
functions properly by pressing and
releasing the trigger switch. Make
sure motor stops.
• Debris Shield - Discontinue use of
unit if debris shield is damaged.
AFTER EACH USE
INSPECT AND CLEAN UNIT AND
LABELS
• After each use, inspect complete
unitfor loose or damaged parts,
Clean the unit using a damp cloth
with a mild detergent.
• Wipe off unit with a clean dry cloth.
Pre-wound spools offer the most
convenient method for replacing line
and ensuring optimum performance,
• Replacement spools are color-
coded to ensure use of the correct
spool with your unit, Be sure to use
7
the same color spool as the existing
spool,
NOTE: Always clear dirt and debris
from cutting head components when
performing any type of maintenance.
• Hold spool and unscrew cap by turn-
ing in the direction shown on top of
the cap,

• Removelineguideringandspool.
Useapre-woundspoolorrefillspool
withline.Ifusingapre-woundspool,
removetapestripfromlineand spool.
REFILLING THE SPOOL WITH LINE
_WARNING: Use only 0.080
inch (2 mm) diameter round line.
Other sizes and shapes of line will
not advance properly and will result in
improper cutting head function or can
cause serious in ury. Do not use other
mater as such as w re, str ng, rope,
etc. Wire can break off during cutting
and become a dangerous missile that
can cause serious injury.
1. Cut a length of 25 feet of 0.080
inch (2 mm) diameter round
Craftsman brand line.
2. Insert one end of line into center
cavity of empty spool. Ensure
line will feed into spool in the di-
rection shown on the spool (coun-
terclockwise).
3. Continue feeding line into spool,
leaving 4 - 6 inches (10 - 15 cm)
unwound from center of spool.
INSTALLING SPOOL WITH LINE
1. Install replacement spool.
2. Thread line through line guide
ring.
Replacement Spool
3. Rest guide ring on spool and
place line in slot. Allow line to ex-
tend 4 - 6 inches (10 - 15 cm)
from center of spool.
4. Ensure line remains in slot while
screwing cap on to the shaft.
Only tighten cap hand tightI
ACCESSORIES
Safety Glasses ........ 71-85707 Extension Cord ........ 71-5702
USER REPLACEABLE SERVICE PARTS
REPLACEMENT PART
Spool with 0.080 inch Trimmer Line
Line Guide Ring
Cap Assembly
Assist Handle
Bolt Carriage, 1/4-20
Wing Nut
Shield Assembly
Screw, Line Limiter Blade
Line Limiter Blade
PARTNUMBER
71-85843
530403949
530095762
530038584
530015820
530016152
530069752
530015880
530095387
8

_ WARNING: Perform the follow-
ing steps after each use.
•Stop the unit and disconnect the
power source when not in use.
• Carry the unit with motor stopped.
• Store the unit so the line limiter
blade cannot cause injury.
• Store unit and extension cord in-
doors in a high, dry place out of the
reach of children. Store unit un-
• plugged.
Store unit with all guards in place.
Position unit so that any sharp object
cannot accidentally cause injury.
TROUBLESHOOTING TABLE
,_ WARNING: Always stop unit and disconnect from the power source before
performing all of the recommended remedies below except remedies that re-
quire unit to be operating.
TROUBLE
Trimmer head
stops under a
load or does not
turn when switct
_s pressed,
Line does not
advance or
D_aks while
_u_ing,
CAUSE
1. Crowding trimmer line
against material being
cut.
2. Electrical failure.
3. Thrown circuit breaker.
4. Debris stopping head,
1. Line improperly routed
in head.
2. Line improperly
wound into spool.
3. Incorrect line size
4. Not enou h line
outside u_ head.
5. Dirt buildup on unit.
1. Line size is incorrect.
2. Incorrect spool.
3. Line is being crowded
against material being
cut.
1. Line improperly
routed in head,
2. Spool damaged.
REMEDY
1.Mow tip of line to do the cutting,
2. Contact Sears Service (see back
cover).
3. Check Breaker Box.
4. Remove debris,
1. Check line routing.
2. Rewind line tightly and evenly,
3. Use only 0,080 inch (2 mm) dia. line,
4. Remove cover and pull 4 inches
(10 cm) of line out of head.
5. Clean unit.
1. Use only 0.080 inch (2 mm) dia. line.
2. Replace with correct spool.
3. Cut with tip of line fully extended.
Line welds onto
spool.
Line releases 1, Check line routing.
sontinuously. 2, Replace spool.
Line usage is 1. Line improperly routed 1, Check line routing.
_=xcessive, in head.
2. Line size is incorrect. 2. Replace spool.
3. Crowding line against 3, Cut with tip of line fully extended.
material being cut,
4. Spool worn or damaged, 4, Replace spool.
Line pulls back 1, Too little line outside 1. Remove cover and pull 4 inches
into head. of head. (10 cm) of line outside of head.
2, Line size incorrect. 2. Use only 0,080 inch (2 ram) dia, line.
9

Declaraci6n de Garantia Limitadal0 Servicio y Ajustes 16
Reglas de Seguridad 10 Piezas de Repuesto 17
Montaje 13 AImacenamiento 18
Us® 14 Tabla Diagn6stica 18
Mantenimiento 16 Piezas y Encargos Contratapa
GARANTIA COMPLETA DE UN A_IO PARA LA CORTADORA ABNEA ELEC-
TRICO CRAFTSMANe
Siesta Cortadora EI6ctrica Weedwacker ® Craftsman tiene aiguna faila de funcio-
namiento debida amateriales omano de obra, durante un aSo a partir de la fe-
cha de compra, Sears la repondr_ gratuitamente,
Esta garantia excluye la linea de nylon,
EL SERVICIO BAJO GARANTIA ESTA A SU DISPOSICION CON SOLO DEVOLVER LA
CORTADORA A LINEA ELECTRICA WEEDWACKER CRAFTSMAN AL TtENDA CE SEARS
O CENTRO DE SERVlClO SEARS MAS CERCANO EN LOS ESTADOS UNIDOS,
Esta garantia le confiere derechos juridicos especificos adem_s ud. Podr_ tener
otros derechos que varian entre estados,
Sears, Roebuck and Co., D/817WA, Hoffman Estates, IL 60179
_ADVERTENCIA: Siempre que
se use cualquier cortador el6ctrico,
deben observarse precauciones
b_sicas de seguridad para reducir el
riesgo de incendio, choque el6ctrico
y graves heridas. Lea y cumpla con
todas las instrucciones.
INFORMACI6N DE
SEGURIDAD EN EL
APARATO
Este aparato de fuerza puede set pe-
ligroso. El usuario tiene la responsa-
bilidad de cumplir con todas las
instrucciones y advertencias en el
aparato yen el manual. Lea el manu-
al de instrucciones en su totalidad
antes de usar el aparato! Fami-
liaricese completamente con los con-
troles y el us® correct® del aparato.
Limite el us® de este aparatc a aquel-
las personas que lean, comprendan,
y cumplan con las advertencias e
instrucciones en el aparato yen el
manual. Nunca permita a los niSos
que usen el aparato. Toda su atenci6n
es necesaria cuando use este aparato
cerca de lugares en donde haya niSos.
,_ PELIGRO: Nunca use cuchillas
ni dispositivos desgrandores. Este
aparato ha sido diseSado exclusiva-
mente corn® cortador a linea. El us®de
cualguier otro accesorio o pieza incre-
mentar_ el peligro de heridas.
@©0
z%
_ADVERTENCIA: La linea de
corte arroja ob etos violentamente.
Los objetos arro ados pueden cegar-
Io o herido austed y a terceros. Use
anteojos de seguridad, botas y pro-
tecdci6n para las piernas. Mantenga
el cuerpo alejado de la linea girante.
Anteojos de seguridad o protecci6nsimila
de ojos. Zo°ape," m
Mantenga a los niSos, los animales y
los espectadores a una distancia
minima de 15 metros (50 pies). Pare
el aparato inmediatamente si alguien
se le acerca.
Si acontece alguna situaci6n no pre-
vista en este manual, tenga cuidado
y use buen criterio, si necesita ayuda,
Ilame al 1-800-235-5878.
10
