Craftsman evolv 172.740100 User manual

durable, affordable_ everyday tools,
000000000000000
10-in. 2.2 Amp
Electric
Weedwacker®
Trimmer
IVlodel No. 172.740100
/
/
CAUTION: Read, understand and follow all
Safety Rules and Operating Instructions in this
Manual before using this product.
Sears Brands Management Corporation,
Hoffman Estates, IL 60179
See the full line of Craftsman ®products
at craftsman,corn
• WARRANTY
• SAFETY
•UNPACKING
•DESCRIPTION
•ASSEMBLY
=OPERATION
•MAINTENANCE
•ESPAhlOL

Warranty.................................................................................... Page 2
Safety Symbols........................................................................... Page 3
Safety Instructions........................................................................ Pages 4- 9
Unpacking.................................................................................. Page 10
Description................................................................................. Pages 11 - 13
Assembly and Adjustments.......................................................... Pages 13 - 14
Operation...................................................................................... Pages 14- 19
Maintenance................................................................................. Page 20
Accessories........................................................................................ Pages 21
Parts List...................................................................................... Pages 22- 23
CRAFTSMAN EVOLV ONE YEAR LiMiTED WARRANTY
FOR ONE YEAR from the date of purchase, this product is warranted against any
defects in material or workmanship. With proof of purchase, a defective product
will be replaced free of charge.
For warranty coverage details to obtain free replacement, visit the
web site: www.craftsman.com
This warranty does not cover the cutting line, which is an expendable part that can
wear out from normal use within the warranty period. This warranty is void if this
product is ever used while providing commercial services or if rented to another
person.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
Sears Brands Management Corporation,
Hoffman Estates, IL 60179
i
WARNING: Some dust created by using power tools contains
chemicals known to the State of California to cause cancer and birth defects 1or other reproductive harm.
SAVE THESE INSTRUCTIONS!
READ ALL iNSTRUCTIONS!
The purpose of safety symbols is to attract your attention to possible
dangers. The safety symbols and the explanations with them deserve your
careful attention and understanding. The symbol warnings do not, by
themselves, eliminate any danger. The instructions and warnings they give
are no substitutes for proper accident prevention measures.
,_ WARNING: Be sure to read and understand all safety instructions in this
manual, including all safety alert symbols such as "DANGER,"
"WARNING," and "CAUTION" before using this electric trimmer. Failure to
follow all instructions listed in this manual may result in electric shock, fire and/or
serious personal injury.
SYMBOL SIGNAL MEANING
,_ SAFETY ALERT SYMBOL: indicates DANGER, WARNING, OR
CAUTION. May be used in conjunction with other symbols or pictographs.
_. DANGER: Indicates a hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the most
extreme situations. Always follow the safety precautions to reduce the risk of
fire, electric shock, and personal injury.
,_ WARNING: Indicates a hazardous situation which, if not avoided, could
result in death or serious injury. Always follow the safety precautions to
reduce the risk of fire, electric shock, and personal injury.
,_ CAUTION: Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
Damage Prevention and Information Messages
These inform the user of important information and/or instructions that could
lead to equipment or other property damage if they are not followed. Each
message is preceded by the word "NOTE," as in the example below:
NOTE: Equipment and/or property damage may result if these instructions
are not followed.
,_ WARNING: To ensure safety and reliability, all repairs
should be performed by a qualified service technician.
_k WARNING: The operation of any power tools can
result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning
power tool operation, always wear safety goggles or
safety glasses with side shield and a full face shield when needed. We
recommend a Wide Vision Safety Mask for use over eyeglasses or standard
safety glasses with side shields. Always use eye protection which is marked
to comply with ANSI Z87.1 shields.

I
I
I
I
z_ WARNING: if correctly used, this electric trimmer is an easy to
handle and efficient tool; if used improperly or without the due precautions
it could become a dangerous tool. For pleasant and safe work, ALWAYS
strictly comply with the safety rules that are contained in this manual.
z_ WARNING: BE SURE to read and understand alt instructions in this
manual before using this electric trimmer. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious personal injury.
Z_ WARNING: To avoid mistakes that could cause serious injury, DO NOT
plug in this trimmer until the following instructions have been read and
understood.
WORK AREA SAFETY
1. ALWAYS avoid dangerous conditions. DO NOT use in wet or damp areas or
expose to rain.
2. DO NOT operate in the presence of flammable liquids, gases, or dust.
Electric tools create sparks which may ignite dust or fumes.
3. ALWAYS keep bystanders and visitors at a safe distance while operating
a trimmer. NEVER allow children near the tool. Flying objects can injure
anyone in the area.
4. CHILDPROOF your tools with padlocks and master switches. Lock tools away
when not in use. This trimmer is not a toy.
5. DO NOT use trimmer at night. ALWAYS make sure you have adequate lighting.
6. BEFORE using the trimmer, remove any stones, sticks, debris or objects that could
be entangled in or thrown by the trimmer.
PERSONAL SAFETY
i1.
2.
3.
4.
1
/!k WARNING:The operation of any trimmer can result in FOREIGN |
OBJECTS BEING THROWN, which can result in personal injury or property 1
damage. ALWAYS use proper safety equipment.
KNOW your tool. Read the operator's manual carefully. Learn the electric trimmer's
applications and limitations, aswell as the specific potential hazards related to this tool.
STAY ALERT, watch what you are doing and use common sense when operating
this tool.
DO NOT use tool while tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating this tool may result in serious personal injury.
DRESS properly. Wear rubber gloves and substantial rubber soled footwear when
working outdoors. DO NOT operate lawn and garden tools when barefoot or wearing
open sandals. Wear long pants and long sleeves to protect your legs and arms.
Trimmers can pick up objects such as rocks and send them flying at fast speeds.
DO NOT wear loose clothing or jewelry. Keep your hair, clothing, and gloves away
from moving parts. Loose clothing or long hair can be caught in moving parts.
PERSONAL SAFETY cont.
5. USE SAFETY EQUIPMENT. Always wear safety goggles or safety glasses with
side shields or full face shield, proper work shoes with rubber non-slip soles,
heavy-duty non-slip rubber gloves and dust mask or respirator and hearing
protection. Hard hat should be used for appropriate conditions.
6. DO NOT overreach. Keep proper footing and balance at all times. Proper footing
and balance enables better control of the tool in unexpected situations.
TOOL USE AND CARE SAFETY
i
1
z_ WARNING: BE SURE to read and understand all instructions before
operating this tool. Failure to follow all instructions listed below may 1
result in electric shock, fire and/or serious personal injury.
.DO NOT use the tool if switch does not turn it "On" or "Off". Any tool that
cannot be controlled with the switch is dangerous and must be repaired.
2. DISCONNECT the plug from the power source before making any adjustments,
changing cutting line, or storing the tool. Such preventive safety measures reduce
the risk of starting the tool accidentally.
3. Avoid Unintentional Starting. Do not insert power cord with finger on switch.
Be sure switch is off when inserting power cord.
4. STORE idle tools out of the reach of children and other untrained persons.
Children MUST NOT operate the tool Tools are dangerous in the hands of
untrained users.
5. Maintain Trimmer With Care. Keep line cutter sharp and clean for best performance
and to reduce the risk of injury. Follow instructions for lubricating and changing
accessories. Inspect appliance cord periodically, and if damaged, have it repaired by
an authorized service facility. Inspect extension cords periodically and replace if
damaged. Keep handles dry, clean, and free from oil and grease.
6. CHECK for misaHgnment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool's operation, if damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
7. USE ONLY cutting line that is recommended for this trimmer. Cutting line that may
be suitable for one trimmer may become hazardous when used on another trimmer.
ELECTRICAL SAFETY
i Z_ WARNING: Do not permit fingers to
touch the terminals of plug when installing
or removing the plug from the outlet.
1. To reduce the risk of electric shock, this
appliance has a polarized plug (one blade
is wider than the other) and will require the
use of a polarized extension cord. The appliance
plug will fit intoa polarized extension cord only one
way. If the plug does not fit fully into the extension
cord, reverse the plug. If the plug still does not fit,
obtain a correct polarized extension cord. A polarized
extension cord will require the use of a polarized wall
outlet. This plug will fit into the polarized outlet only
one way. If the plug does not fit fully into the outlet,
reverse the plug. Ifthe plug still does not fit, contact
a qualified electrician to install the proper outlet.
Do not change the equipment plug, extension cord
receptacle, or extension cord plug in any way.
PolarizedExtensio
CordReceptacle
Cover of
GCFI Grounded
Polarized -_----...._
Outlet Box
®
®
on Extension Cord
I
I
I
I

ELECTRICAL SAFETY cont.
2. Double insulation [] eliminates the need for the three-wire grounded power cord and
grounded power supply system. Applicable only to Class II (double-insulated) tools.
This trimmer is a double insulated tool.
Z_ WARNING: GFCl (Ground Fault Circuit Interrupter) protection should be
provided on all circuits or outlets to be used for electric lawn and garden power
tools. Receptacles are available having built-in GFCl protection and should be
used for this measure of protection.
A CAUTION: This trimmer has a 12-in. Pigtail Power Cord that must be
plugged into aproper extension cord (see below).
WARNING: Double insulation DOES NOT take the place of normal safety
precautions when operating this tool.
3. BEFORE plugging in the tool, BE SURE that the outlet voltage supplied is within the voltage
marked on the tool's data plate. DO NOT use "AC only" rated tools with a DC power supply.
4. DO NOT expose tools to rain or wet conditions or use electric tools in wet or damp
locations. Water entering an electric tool will increase the risk of electric shock.
5. If operating an electric tool in damp locations is unavoidable, ALWAYS USE a
Ground Fault Circuit Interrupter to supply power to your tool. ALWAYS WEAR
electrician's rubber gloves and footwear in damp conditions.
6. WARNING: To reduce risk of shock. When operating a power tool outside, ALWAYS use an
outdoor extension cord marked SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJOW-A,
SJTW-A, or SJTOW-A, these cords are rated for outdoor use and reduce the risk of
electric shock.
7. INSPECT tool cords for damage. Have damaged tool cords repaired at a certified Service
Center. BE SURE to stay constantly aware of the cord location and keep it well away
from the spinning cutting lines.
8. Do not abuse the cord on the trimmer. Never carry the trimmer by its power cord.
Never pull the power cord to remove from the power outlet. Damage to the cord
could occur and create an electric shock hazard. Keep cord away from heat, oil, sharp
edges or moving parts. Replace damaged cords immediately. Damaged cords increase
the risk of electric shock.
EXTENSION CORDS
Use a proper polarized extension cord (see page 5). ONLY use cords listed by Underwriters
Laboratories (UL). Other extension cords can cause a drop in line voltage, resulting in a loss
of power and overheating of tool.
For this tool an AWG (American Wire Gauge) size of a least 14-gauge is recommended
for an extension cord of 25-ft. or less in length. Use 12-gauge for an extension cord
of 50-ft. Extension cords 100-ft. or longer are not recommended.
Remember, a smaller wire gauge size has greater capacity than a larger number
(14-gauge wire has more capacity than 16-gauge wire; 12-gauge wire has more capacity
than 14-gauge). When in doubt use the smaller number.
Z_ CAUTION: Keep the extension cord clear of the work area. Position the ]
cord so that it will not get caught on bushes, hedges, tree trunks, lawnmowers 1
or other obstructions while you are working with the trimmer.
EXTENSION CORDS cont.
Z_ WARNING: Check extension cords
before each use. if damaged replace
immediately. Never use tool with a damaged
cord since touching the damaged area could
cause electrical shock, resulting in serious
injury.
The label on your tool may include
the following symbols.
V....................................................................... Volts
A...................................................................... Amps
Hz.................................................................... Hertz
W..................................................................... Watts
rain.................................................................. Minutes
.................................................................... Alternating current
................................................................... Direct current
no .................................................................... No-load speed
Correct Cord Size Chart
Volts Total lengthof cord in feet
240v s0! 100I 200! 300
Ampere Rating
More than Not AWG
more than
0-6 18 16 16 14
6-10 18 16 14 12
10-12 16 16 14 12
Not
12-16 14 12 recommended
[] .................................................................... Class II construction, Double Insulated
RPM.......................................................... Revolutions per minute
SPM........................................................... Strokes per minute
OPM .......................................................... Orbits per minute
/tk .................................................................... Indicates danger, warning or caution.
Itmeans attention! Yoursafety is involved.
O Arrows show direction will be thrown
objects
bytrimmer line rotation.
(',.,_ ................................................................... Do not expose to moisture
Switch off! Remove plug from mains before adjusting,
cleaning or if cable is entangled or damaged.
SERVICE SAFETY
1. if any part of this trimmer is missing or should break, bend, or fail in any
way; or should any component fail to perform properly: SHUT OFF the
power switch and remove the trimmer plug from the power source and have the
missing, damaged or failed parts replaced BEFORE resuming operation.
2. Tool service must be performed only by a qualified service dealer. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
SAFETY RULES FOR ELECTRIC TRIMMERS
1. KNOW your electric trimmer. Read operator's manual carefully. Learn the
applications and limitations, as well as the specific potential hazards related to this tool.
Following this rule will reduce the risk of electric shock, fire or serious injury.
2. DO NOT use trimmer without adequate lighting. ALWAYS make sure that you can
see what you are trimming.
3. Use trimmer ONLY when grass and weeds are dry.
4. ALWAYS remove objects such as stones, sticks, and debris from the trimming
path that could become entangled in, or thrown by, the trimmer.
5. ALWAYS hold the trimmer by both the main rear handle and the auxiliary handle
for greater control and balance. NEVER reach under the safety guard.
6 7

SAFETY RULES FOR ELECTRIC TRIMMERS cont.
6. USE RIGHT TRIMMER. Do not use trimmer for any job except that for which it is intended.
7. AVOID accidental starting. DO NOT carry a plugged in trimmer with your finger
on the switch.
8. DO NOT carry the trimmer bythe cord or pull the cord to disconnect it from the
receptacle. Keep cord away from heat, oil and sharp edges.
9. DO NOT grasp or touch the exposed cutting line when picking up or holding the trimmer.
10. DO NOT FORCE the trimmer. Do not try to cut more than what the trimmer isdesigned
for. It will do a better job with less chance of injurywhen used at the rate for which it is
designed.
11. MAINTAIN the trimmer with care. ALWAYS inspectthe extension cord and replace
it ifdamaged.
12. KEEP the handle dry, clean and free of oil and grease. Use a clean cloth when cleaning.
DO NOT use solvents, brake fluids, gasoline, or other petroleum products to clean the
trimmer. They can damage plastic parts.
13. NEVER, for any reason, touch the cutting line or other moving parts during use.
14. When changing cutting line spool be careful of the line cutter on the guard.
Cutter is sharp and can cause injury.
15. DO NOT use this product without the guard being fitted.
16. WHEN INSTALLING SAFETY GUARD OR CHANGING CUTTING LINE SPOOL
be careful of the line cutter on the guard. Cutter is sharp and can cause injury
17. KEEP guard in place and in good working order. Keep guard positioned between you
and cutting line. Keep hands and feet away from cutting line.
18. ALWAYS store the trimmer indoors when not in use. It should be stored in a dry place,
high up or locked in a place that is out of the reach of children.
19. ALWAYS use only the cutting line provided with this trimmer or sold by qualified service dealer.
Use of any other cutting line may create a hazardous situation.
20. ALWAYS keep ventilation openings clear of debris.
21. BEFORE using the trimmer, remove any stones, sticks, debris or objects that could be
entangled in or thrown by the trimmer.
22. NYLON CUTTING LINE Keep face, hands and feet clear of rotating nylon line at all times.
23. ALWAYS use only 0.065 inch (1.65 mm) round cutting line with this
trimmer. Use of any other cutting line may create a hazardous situation.
Do not use heavier lines than recommended in this manual.
24. THE ROTATING LINE PERFORMS A CUTTING FUNCTION. Use care when trimming
around screens and flowers and other objects that you DO NOT want damaged or cut.
25. KEEP ALL BYSTANDERS AWAY at a safe distance from the work area, especially children.
Make sure that persons and pets are at least 100 feet away.
SAFETY RULES FOR ELECTRIC TRIMMERS cont.
iMPORTANT WARNING:
When this tool is being used as a trimmer, stones and other objects can be thrown
out at high speed by the line. The tool and guard are designed to help reduce the
danger. However, the following special precautions should be taken.
TO REDUCE THE RISK of rebound or ricochet injury, always work away from any
solid objects such as walls, steps, large stones, landscape bricks, timbers, trees,
etc. Use extreme care when working close to solid objects and when necessary
edge or trim by hand.
Z_ WARNING: Some dust particles created by lawn and garden tools contain
chemicals known to the State of California to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
•Compounds in fertilizers, herbicides, pesticides, and insecticides.
•Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending upon how often you do this
type of work. To reduce your exposure to these chemicals:
•Work in a well-ventilated area
•Work with approved safety equipment, such as those dust masks
that are specially designed to filter out microscopic particles.
Z_ WARNING: NEVER reach under the trimmer (cutting line area) until
trimmer has completely stopped. The trimmer's cutting line will continue to
rotate for a few seconds after it is switched off.
ADDiTiONAL RULES FOR SAFE OPERATION
A WARNING: BE SURE to read and understand all instructions. Failure to
follow all instructions listed below may result in electric shock, fire and/or
serious personal injury.
1.
2.
3.
4.
5.
6,
ALWAYS wear safety glasses or eye shields when using this tool
Everyday eyeglasses have only impact-resistant lenses; they are NOT safety glasses.
PROTECT your lungs. Wear a face mask, dust mask or respirator if the operation is dusty.
PROTECT your hearing. Wear appropriate personal hearing protection during use.
Under some conditions noise from this product may contribute to hearing loss.
ALL VISITORS AND BYSTANDERS MUST wear the same safety equipment that the
operator of the tool wears.
ALWAYS check the tool for damaged parts. Before further use of the tool, a guard
or other part that is damaged should be carefully checked to determine if it will operate
properly and perform its intended function. Check for misalignment or binding of moving
parts, breakage of parts, and any other condition that may affect the tool's operation.
A guard or other part that is damaged should be properly repaired or replaced
at a qualified service center.
SAVE THESE INSTRUCTIONS. Refer to them frequently and use them
to instruct others who may use this tool. If someone borrows this tool, make sure
they have these instructions also.

1.Thetrimmercomesin2pcs.(UpperandLowerShafts),thatmustbeconnectedbyhand.
TheSafetyGuardmustbeattached.
2.RemovetheUpperandLowerShaftsandSafetyGuardfromthecartonandinspect
yourtrimmer.
3.Donotdiscardboxorpackingmaterialuntilallpartsareexamined.
z_ WARNING: If any part of the trimmer is missing or damaged, do not plug
in the trimmer until the damaged part is repaired or replaced. 1
Fig. 1
Auxiliary Handle
Upper Shaft
Trimmer
Head
Lower Shaft
\Screws for attaching Safety Guard Safety Guard
KNOW YOUR TRIMMER (Fig. 2, 2a, 2b and 3)
NOTE: Before attempting to use this product, familiarize yourself with all
operating features and safety rules. 1
Your trimmer/edger has a precision built electric motor and it should only be connected
to a 120-volt, 60 Hz AC ONLY power supply (normal household current). The trimmer
should always be used with a GFCI (Ground Fault Circuit Interrupter) outlet.
DO NOT operate this trimmer on direct current (DC). The large voltage drop would cause
a loss of power and the motor would overheat.
If the trimmer does not operate when plugged into correct 120-volt, 60 Hz AC ONLY outlet,
check the power supply. The trimmer comes with a 12-in. pigtail power cord and should
be plugged into a proper extension cord (see page 6).
PIGTAIL POWER CORD (Figs. 2, 2a and 2b) __._\,
Fig. 2a Fig. 2b __
Fig.2
Hook
Remove the plug guard from the pigtail power cord (see Fig. 2). Make a loop in the
extension cord. Push loop through hole above retension hook (see Fig. 2a). Fasten loop
around cord retention hook, and pull the cord back. Plug trimmer's power cord into extension
cord plug (see Fig. 2b).
Safety, performance and dependability have been given top priority in the design of
this product, making it easy to maintain and operate.
This Electric Trimmer has the following features:
4.
5.
6.
7.
1.10=inch Cutting Path
2.2.2 Amp Electric Corded /11,000 RPM (no=load speed) motor for efficient trimming.
3. Ergonomically Designed Front Auxiliary Handle and Rear Handle for maximum
control and gripping comfort with reduced operator fatigue.
Finger Trigger Switch with Safety "On" Button. Safety On button must
be depressed to operate trigger switch.
Lightweight and Ergonomically Designed for easy use, handling comfort and
efficient trimming.
Bump=Feed Head allows you to simply bump the trimmer head to advance cutting line.
Your Trimmer uses Nylon monofilament round single-wound 0.065 inch line.
For Cutting-Line Replacement: Re-load spool with Craftsman line Item 71-85822,
15 ft. bulk pack of Craftsman .065 line (sold separately).
10 11

This Trimmer has the following features cont.:
8. Cord Retention Hook helps keep the extension cord in place.
9. Safety Guard helps keep cuttings and debris away from operator.
Fig. 3
Auxiliary Handle
Upper Shaft
Lower Shaft
Air
Vents
Safety Guard
/
CuttingLine---/ I
Bump-Feed Head 12
Safety "On" Button
Finger
Trigger Switch
Cord
Retention Hook
Pigtail Power
Cord Plug
Cutting Path
No-Load Speed
Rating
Line Diameter
Line Feed Mechanism
Cord Length
Power Requirement
10 inches
11,000 RPM
2.2 Amp
Nylon monofilament round single-wound 0.065-in. line
Bump feed
12 inch Pigtail power cord
120-volt, 60 Hertz AC Only
ASSEMBLING THE TRIMMER SHAFT (Figs. 4 and 4a)
1.First make sure the cable is not twisted. Locate the Lower Shaft (A) into the
Upper Shaft (B). Grasp both the Lower and Upper Shafts and Push firmly together
until a click can be heard (see Figs 4 and 4a).
NOTE: Once the Upper and Lower Shaft is assembled it can not be disassembled, i
Ensure internal cable is not trapped or twisted. J
Fig. 4
Upper Shaft
Lower Shaft Fig. 4a
iNSTALLiNG THE SAFETY GUARD (Figs. 5)
NOTE: THE GUARD MUST BE ATTACHED to the trimmer head before use.
Z_ WARNING: The guard must always be on the tool to protect the user
1. Disconnect the trimmer from the power supply.
2. Turn the trimmer's motor housing head over to provide access to underside base
of the head by the cutting line spool.
3. Locate the screw in the base of the trimmer head and remove the screw.
13

iNSTALLiNG THE SAFETY GUARD cont. (Figs. 5 and 5a )
4. Attach the Safety Guard to the trimmer head making sure the sides are located
into the grooves.
5. Insert the edge of the guard into the slot along the back of the trimmer's head, carefultly
lining the screw hole in the guard up with the screw hole in the trimmer head.
6. Insert screw and securely attach the safety guard (see Fig. 5).
i Z_ WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing parts or cleaning the trimmer or 1
making any adjustments.
NOTE: Safety Guard will only fit one way.
j A CAUTION: Line cutter on edge of safety guard is sharp. Use cautionwhen handling. 1
Safety
Guard
Line Cutter
Install Guard
with Screw
Z_ WARNING: To avoid injury, DO NOT carry the trimmer with your fingeron the trigger switch.
A WARNING: if any part of the trimmer is missing or damaged, do not plugin the trimmer until the damaged part is repaired or replaced.
PIGTAIL POWER CORD (See Figs. 6 and 6a)
Your edger trimmer has a 12-inch pigtail power cord. This cord must be attached to a proper
extension cord. Refer to Figs. 6 and 6a for attaching extension cord.
For strain relief of the cable, make a loop in the extension cord. Push loop through hole
located above the retension hook (see Fig. 6).
Fasten loop around cord retention hook, and pull the cord back (see Fig. 6a).
Fig. 6
Hook
Fig. 6a
Hole
!
Retension Hook
TURNING TRIMMER ON AND OFF
Your trimmer has an extended length (finger) ON /OFF trigger switch.
Turning Trimmer ON
1. Plug the trimmer's pigtail power cord into extension cord.
2. Plug extension into power outlet.
3. Press down the safety "ON" button and then squeeze trigger switch to start trimmer.
4. The trimmer will stay ON as long as the trigger switch is squeezed.
Turning Trimmer OFF
1. Release the trigger switch to turn trimmer OFE
2. Allow at least 5 seconds for the cutting spool (line) to stop rotating.
Z_ WARNING: The cutting head continues to rotate after the trimmer hasbeen switched off. Wait until it has stopped then lay down the tool.
14 15

TRiMMiNG (Figs. 7)
While trimming, move the trimmer from leftto
right, keeping it well away from the body.
Tilt the front of the trimmer head to cut shorter
grass.
DO NOT overload your trimmer.
Overloading your trimmer can be avoided by
making sure the motor speed does not drop
too much while trimming. (See Fig. 7).
Z_ WARNING: Always wear eye protection.
Never lean over the trimmer head. Rocks or
debris can ricochet or be thrown into the eyes
iand face and cause blindness or other serious
injury.
Wear eye protection and heavy clothing. Hold
front handle with one hand and auxiliary handle
with the other hand. Keep unit below waist level.
Work only from your right to your left to ensure
debris isthrown away from you. Without bending
over, keep line near and parallel to the ground
(perpendicular when edging) and not crowded
into material being cut.
Make sure that line is fed out before operation.
Make sure motor is running at full speed before
trimming.
Use only 0.065"diameter cutting line. Other
sizes of line will not feed properly and will result
iin improper cutting head function or can cause
t....
isenous injury. Do not use other material such as
iwire, string, rope, etc. Wire can break off during
cutting and become a dangerous missile that
can cause serious injury.
Fig. 7
Mask
Gloves
Cutting Around Trees and Bushes
Carefully cut around trees and bushes so that they do not come into contact with the cutting line.
Plants can die if you damage the bark.
NOTE: ALWAYS keep the air vents on the trimmer head (motor housing) free
of obstructions when operating the trimmer.
WARNING: The operation of any trimmer can result in FOREIGN
OBJECTS BEING THROWN, which can result in personal injury or property
damage. ALWAYS use proper safety equipment and keep bystanders safely away.
16
THE CUTTING LINE
Z_ WARNING: DO NOT grasp the exposed cutting line when picking up
or holding the trimmer.
Nylon monofilament round single-wound 0.065 inch line is pre-installed on the trimmer.
For Cutting-Line Replacement: Re-load spool with Craftsman line Item 71-85822,
15ft. bulk pack of Craftsman .065 line (sold separately).
i
EXTENDING THE CUTTING LiNE (Fig. 8)
During operation, cutting lines shorten due to normal wear. For greater convenience and
efficiency, your trimmer has been equipped with a bump feed head that allows you to
simply bump the trimmer head to extend the cutting lines while the trimmer is operating.
Cutting line will wear faster and require more feeding if the cutting or edging is done along
sidewalks or other abrasive surfaces or heavier weeds are being cut.
1. While the trimmer is on and spinning, gently bump the spool housing on a firm surface
(hard ground or sidewalk). This should release additional cutting line from the spool.
2. If no line is released, bump the trimmer head more sharply
or try bumping it on a firmer surface.
3. If there is no change in the cutting line length,
un=plug the trimmer's pigtail power cord
from the extension cord. After the trimmer
head stops rotating, gently pull at the cutting
lines manually. Once the lines are pulled out
(extended), plug the trimmer's pigtail power cord
into the extension cord and resume cutting.
4. Ifthe cutting line still does not feed from the
spool, the spool might be empty or the
cutting line may be tangled or jammed on
the spool. Un-plug the trimmer's pigtail
power cord from the extension cord.
After the trimmer head stops rotating,
remove the spool (see steps
1 through 3 in "Removing the
Spool" on page 18).
Fig. 8
If the line is tangled or
jammed, untangle and
replace the line (see
page 18). If the spool is
empty, replace the
line (see
pages 18-19). Bump on firm surface J
Z_ WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing parts or cleaning the trimmer or
making any adjustments.
17

TOREPLACECUTTINGLINE(Fig.9)
REMOVETHESPOOL
NOTE:Donotuseheavierlinesthanrecommendedinthismanual.
YourTrimmerusesNylonmonofilamentroundsingle-wound0.065inchline.
ForCutting-LineReplacement:Re-loadspoolwithCraftsmanlineItem71-85822,
15ft.bulkpackofCraftsman.065line(soldseparately).
1.Disconnectthetrimmerfromthepowersupply.Turntrimmerovertoaccessspoolheadcover.
i _ WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing parts or cleaning the trimmer
or making any adjustments.
2. Press the release tabs on the spool head
cover and remove cover, pulling it straight
off of spool.
3. Lift the spool out of the spool housing.
REPLACETHESPOOL
Fig. 9
Spool
Rail
Notch
1. First refill the Spool with proper size
Cutting Line (see Fig.10)
2. Insert the end of one line through
an eyelet in the spool housing.
Insert the other line through the
other eyelet.
3. Insert the spool into housing and
press it down gently until you feel
it drop into place.Take care to keep
the line from becoming trapped
under the spool.
4. Snap the spool head cover back on
and at the same time pull lines and
be sure that they are released from
spool rail notch. Eyelet
i
Spool Head Cover
___a Release
bs
Cutting
Line
FILLING SPOOL WITH CUTTING LINE (Fig. 10)
You may' wind new cutting line onto an empty
spool. Replacement bulk packs of 0.065 inch
Craftsman Cutting Line 71-85822
are available from your qualified store.
1. Remove the empty spool from the tool
as described in "REMOVE THE SPOOL? above.
2. Remove any remaining cutting line from the spool.
RIGHT WRONG Fig. 10
3. First wind new line onto the uppermost part of the spool. Feed 3/4 inch of cutting line
into one of the line spool rail notches. Wind the cutting line onto the spool in the direction
of the arrow on the spool. Make sure to wind the line neatly and in layers Do not
crisscross (see Fig. 10). 18
FILLING SPOOL WITH CUTTING LINE cont. (Fig. 10)
4. When the wound cutting line reaches the eyelets (recesses),cut the line.Temporarilypark the line
inthe spool rail notch on one side of the spool as shown in Fig. 10.
5. Repeat the above procedure for the second cutting line on the lower section of the spool.
6. Fit the spool onto the tool as described in"REPLACE THE SPOOL" page 18.
/K CAUTION: Before you begin trimming, only use the appropriate type of i
cutting line. Ensure that cutting line is present in both sections of the spool (Fig. 10). J
MANUALLY FEEDING THE LINE (Fig. 11)
Press and release the manual line feed button,
located on the side of the cutting head, while
gently pulling out the lines until itreaches the
line cutter. When the required amount of line
isfed out, gently pull on the second line
(there isno need to press the manual line
feed button again). Ifthe line extends past the
line cutter, too much line has been fed out.
Iftoo much line isfed out, remove the spool
cap and click the spool counter-clockwise
until the line is at the desired length.
OPERATING TIPS
1.
2.
3.
4.
5.
6.
m
Fig.ll
-:[ ['
Before each use make sure the protective safety guard is securely installed.
Tighten the guard screws, but DO NOT over tighten.
Before trimming, inspect the area for string, wire, branches, rocks, toys, or other
objects that could be entangled in or thrown by the cutting line.
Stand with the cutting head tipped down at an angle in front, guiding the trimmer in a
semi-circular motion around you.
Cut from left to right whenever possible. Cutting to the right improves the unit's cutting
efficiency and clippings are thrown away from the operator.
To produce a smoothly trimmed area, move the trimmer in and out of the area being
cut with constant speed and height.
Use only the tip of the cutting line to do the trimming, especially near walls and fences.
Trimming with the side of the cutting line may overload the motor, wear out the line
faster, and break the line more often.
7. DO NOT rest the trimmer spool on the ground while you are trimming. This will cause
spool wear.
8. When cutting vegetation that is over 6 inches in height, work from top to bottom
in small increments to avoid premature line wear or engine drag.
9. When the trimmer is stopped and the spool stops rotating, the cutting line will relax
and may recede. Feed extra cutting line before storing the trimmer to prevent losing
the line in the spool housing.
10.
11.
If the diameter of the cutting area gets smaller, the line is worn down and needs to be
advanced.
If the trimmer is not cutting correctly, the cutting line may not be feeding properly.
Remove and rewind the line spool.
19

_WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing line, cleaning the trimmer or making
any adjustments.
GENERAL MAINTENANCE
Keep your trimmer clean and in good repair for maximum long-lasting performance. Before
each use, inspect the switch and cord for damage.
Check for damaged, missing, or worn parts. Check for loose screws, misalignment, moving
parts that are jammed, or any other conditions that may affect the operation. If abnormal
vibration or noise occurs, turn off the tool immediately and have the problem corrected
before further use.
DO NOT use the trimmer if it has any broken parts. Have damaged, missing, worn
or broken parts replaced before using trimmer.
When servicing a tool, use only identical replacement parts. Use of unauthorized parts
or failure to follow maintenance instructions may create a risk of electric shock or injury.
/_ WARNING: The use of attachments or accessories (cutting line) that
are not recommended for this tool will be dangerous and can result in serious
personal injury. Do not attempt to use fishing line or other lines that are not
recommended.
REPLACEMENT CUTTING LiNE
If you are replacing the cutting line, ONLY use nylon monofilament round single-wound
0.065 inch line (Craftsman Cutting Line 71-85822).
Cutting Line available at Sears Stores or other Craftsman outlets.
Visit your local Sears store or other Craftsman outlets or shop sears.com/craftsman.
CLEANING
WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing line, cleaning the trimmer or making
any adjustments.
z_ WARNING: To avoid damage or electric shock, DO NOT use strong
solvents or detergents on the plastic housing or plastic components. Certain
household cleaners may damage plastic and may also cause a shock hazard.
Wipe the outside of the trimmer with a dry, soft cloth.
DO NOT hose down or wash the trimmer with water. Scrape the guard and spool
area to remove dried clippings and mud. Brush or blow dust, debris and grass clippings
out of the air vents
ALWAYS keep the air vents free from obstruction when operating the trimmer.
Z_ WARNING: To avoid injury, ALWAYS turn off and disconnect the trimmer
from the power outlet BEFORE installing line, cleaning the trimmer or making
any adjustments.
NEED MORE HELP?
You'tI find the answer and more on managemyhome.com -for free!
•Findthis and a[[ your other product manualsonline.
•Get answersfrom our team of home experts.
•Get a personalized maintenance plan for your home.
•Findinformation and tools to help with home projects.
manage home
brought to you by Sears
20 21

10-in. 2.2 Amp
Weedwacker ®
Electric
Trimmer
Model No. 172.740100
The modelnumberwill
befoundon thenameplate
oftheTrimmer.
Toorder parts,
call 1-800-469-4663
F_
N
n
N
%
...... CO
to
to
/
\
tO
O_
10-in. 2.2 Amp Weedwacker ®Electric Trimmer
Model No, 172,740100
Themodelnumberwillbefoundon thenameplate
oftheTrimmer.To order parts, call 1-800-469-4663
Item No. Parts No. Part Description
• GGT260MU! _ PowerCab[eAndP!u_
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
2O
21
22
23
24
25
26
27
28
Qty.
1
GGT260MU-2
GGT260MU-3
GGT260MU-4
GGT260MU-5
GGT260MU-6
GGT260MU-7
GGT260MU-8
GGT260MU-9
GGT260MU-10
GGT260MU-11
GGT260MU-12
GGT260MU-13
GGT260MU-14
GGT260MU-15
GGT260MU-17
GGT260MU-18
GGT260MU-19
GGT260MU-20
GGT260MU-21
GGT260MU-22
GGT260MU-23
GGT260MU-24
GGT260MU-25
GGT260MU-26
GGT260MU-27
GGT260MU-28
Cable Jacket
Thermal Shrinkage Pipe
Terminal Block
Microswitch
Screw
Press Plate
Spring
Safety Button
Safety Spring
PowerButton
Left/Right Handle
InnerWire I
Shrinkable Tube
Terminal I
Terminal II
InnerWire II
Cuprum Rivet
Spool Seat
Nut
Cap
Spring
Spool
Nylong Line
Spool Cover
Left/Right Housing
Rubber Block
1
5
2
1
2
1
1
1
1
1
1
2
7
2
2
2
2
1
2
1
1
1
1
1
1
2
Item No.
29
30
31
32
33
39
5O
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
Parts No.
GGT260MU-29
GGT260MU-30
GGT260MU-31
GGT260MU-32
GGT260MU-33
GGT260MU-39
GGT260MU-50
GGT260MU-51
GGT260MU-52
GGT260MU-53
GGT260MU-54
GGT260MU-55
GGT260MU-56
GGT260MU-57
GGT260MU-58
GGT260MU-59
GGT260MU-60
GGT260MU-61
GGT260MU-62
GGT260MU-63
GGT260MU-64
GGT260MU-65
GGT260MU-66
GGT260MU-67
GGT260MU-68
Part Description
Screw
Line-Cut Blade
BladeJacket
Screw
Guard
Screw
Jagged Button
Front Bracket
Brush Holder
Carbon Brush(pair)
Spring
Carbon Brush Line
Carbon Brush Cap
Bearing
Washer
Cuprum Rivet
Rotor
Washer
Plug
Stator
Rear Bracket
Bolt
Washer
Washer
Washer
Qty.
1
1
1
1
1
18
3
1
2
1
2
2
2
1
1
2
1
1
2
1
1
2
2
2
1

I
I
I
I
