Cres Cor H-339-127-LJ Manual

OPERATING and MAINTENANCE INSTRUCTIONS
MODEL: H339127LJ & H339127PLJ (PASS THRU)
BROILED HOLDING UNIT FOR LONG JOHN SILVER’S
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Holding Cabinet FL-0520-7
Rev. 1 (10/08) Page 1 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
HOW TO INSTALL UNIT: (Figure 1)
Plug cord into receptacle in back of unit.1. (Side of unit for H339127PLJ)
Turn plug clockwise to lock.2. Plug other end into 15 amp. wall outlet.3. Place cabinet in a well ventilated area.4. Push the switch on, turn the thermostat to No. 105. and run the unit for one hour.
NOTE: DO NOT PUT IN FOOD! This step is to
burn off manufacturing oils and excessive
adhesive.
Let the cabinet cool and wipe inside clean with6. detergent and hot water before use.
HOW TO OPERATE UNIT: (Figure 2)
Push switch “ON”. Yellow light will come on.1. Turn thermostat to the temperature you need.2.
NOTE: No. 7½ setting will give you about 180° F.
Proper food holding temperature is 140° F or
higher.
3. Preheat cabinet for 45 minutes
4. Put food into cabinet.
To Turn Off Unit:
Push switch “OFF”. The yellow light will go off.
NOTE: Thermometer in the front door gives the
inside cabinet temperature.
ELECTRICAL SPECIFICATIONS:
MODEL Volts Watts Amps Hertz Phase NEMA
H-339-127-LJ
H-339-127-PLJ 120 900 7.5 60 1 5-15
Models are designed for AC service.
FIGURE 1
FIGURE 2
Thermostat Switch-Light
ON/OFF
Base Receptacle

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
MODEL: H339127LJ & H339127PLJ (PASS THRU)
BROILED HOLDING UNIT FOR LONG JOHN SILVER’S
Insulated
Holding Cabinet FL-0520-7
Rev. 1 (10/08) Page 2 of 4
BEFORE CLEANING CABINET:
1. Unplug power cord from wall.
2. Do NOT hose cabinet with water.
3. Do NOT get water on controls.
4. Do NOT use abrasives or harsh
chemicals.
Hints:
Wipe up spills as soon as possible.1. Clean cabinet regularly to avoid heavy dirt build-up.2. Make a test spot with cleaner.3. Follow manufacturer’s directions on cleaner.4. Do not mix cleaners.5. Avoid drips and splashes.6.
HOW TO CLEAN UNIT:
SOIL CLEANER METHOD
CABINET
Inside and Outside
(Stainless Steel)
ROUTINE CLEANING Soap, Ammonia, or mild* detergent
and water
1. Sponge on with cloth.
2. Rinse with water.
3. Wipe dry.
STUBBORN SPOTS
AND STAINS Mild abrasive made for stainless steel 1. Apply with damp sponge or cloth. 2. Rub lightly.
BURNT-ON FOODS
OR GREASE Chemical oven cleaner for stainless steel Follow oven cleaner manufacturer’s directions.
HARD WATER
SPOTS and SCALE Vinegar 1. Swab or wipe with cloth. 2. Rinse and dry.
* Mild detergents include soaps and non-abrasive cleaners
WARNING
TROUBLE-SHOOTING CHART
FAILURE POSSIBLE CAUSE/CHECK
1. Unit does not heat: 1a. Thermostat turned up.
1b. Switch is “ON”.
1c. Cord is plugged into cabinet.
1d. Cord is plugged into outlet.
1e. Circuit breaker/fuse for
wall outlet.
2. Unit will not turn off: 2a. Thermostat turned down.
2b. Switch is “OFF”
If cause is none of the above, refer to our list of
authorized service agencies, FL-1400.
Instructions for replacing parts are included in
replacement parts kits.
REPLACEMENT PARTS
Cabinet Receptacle 0713-011
Cord Set 0810-031-1
Switch 0808-103
Heater Kit 0811-066-K
Thermostat Kit 0848-008-ACK
Terminal Block 0852-008
Door Latch Kit 1006-142-K1
Strike Kit 1006-142-01-K
Hinge Kit 6507-005
Thermometer Kit 5238-008-K
Gasket Kit 0861-077
Door Kit (w/Thermometer) H339037-15-K
Door Kit (w/o Thermometer) H339037-41-K
Rack Insert H339037-28
Pan Support Frame H339031-33

OPERATING and MAINTENANCE INSTRUCTIONS
MODEL: H339127LJ & H339127PLJ (PASS THRU)
BROILED HOLDING UNIT FOR LONG JOHN SILVER’S
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Holding Cabinet FL-0520-7
Rev. 1 (10/08) Page 3 of 4
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
HOW TO REVERSE DOOR HARDWARE
FOR OPPOSITE HAND
(Refer to Figure 3 [hinge] and Figure 4 [latch]):
Remove hinge covers with a screwdriver.1.
Remove screws from hinges to door (Item 1) and hinge2. brackets to cabinet (Item 2).
Remove screws from latch to door (Item 3) and latch3. bracket to cabinet.
NOTE: Keep hinges and latch strike mounted to the
brackets.
Remove all remaining screws from both sides of4. door and cabinet in that area. Keep all screws.
Turn latch strike bracket 180° and mount it to5. the opposite side of the cabinet with the same
screws you removed. Do the same with the hinge
brackets.
Line up (4) latch holes to door holes on the6. opposite side of the door. Mount latch with same
screws that were removed.
Mount hinges to the opposite side of the door and7. snap on the hinge covers.
Plug remaining holes with screws.8.
HOW TO ADJUST THE DOOR LATCH:
(Refer to Figure 4)
For vertical adjustment (up and down movement):1. a. Loosen (2) screws located in magnetic strike
attached to bracket on cabinet.
b. Move strike up or down for alignment to magnet
on latch.
c. Tighten screws to secure.
For horizontal adjustment (greater or lesser2. magnetic draw):
a. Loosen (4) screws in door latch.
b. Move latch forward or backward to adjust
magnetic draw.
c. Tighten screws to secure. FIGURE 4
FIGURE 3
SCREW, FLAT HEAD
#10-24 X 1-1/2” LONG
LATCH STRIKE
BRACKET
DOOR
TOP
HINGE
BRACKET
SCREW
#10-24 X 1/2"
COVER
HINGE
SCREW
#10-24 X 1"
1
2

5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: [phone] • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
MODEL: H339127LJ & H339127PLJ (PASS THRU)
BROILED HOLDING UNIT FOR LONG JOHN SILVER’S
Insulated
Holding Cabinet FL-0520-7
Rev. 1 (10/08) Page 4 of 4
45678910
TCB
17
t°
SW
A
2
1
84
65
4
6
3
5H1 H2 H3
J
J
7
14
12
9
11
10
3
8
TB
*SEE NOTE "A"
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
H1
H2 & 3
L5-15P
L6-15P
S
SW
TB
TCB
J
HEATER - BOTTOM
HEATER - RIGHT AND LEFT SIDE
FLANGED INLET, 120V. 15A.
FLANGED INLET, 250V. 15A.
SENSOR - AIR
SWITCH - POWER (LIGHTED)
TERMINAL BLOCK
TEMPERATURE CONTROL BOARD
SLEEVING 4-PLACES
JUMPER #807-107
ITEM DESCRIPTION
NOTE "A"
FOR 120V., ATTACH
WIRE #5 TO TERMINAL #9
WIRE #5 TO TERMINAL #10
FOR 250V., ATTACH
LEGEND
G
W
L5-15P
G
X
Y
L6-15P
1
2
15
16
*
15
*16
2
1
WIRE #16 GROUND
TO INNER BODY
*
WIRING DIAGRAM
