Crest Audio CJ-3412C User manual

CJ-3412C Color Camera
Miniature Color Camera
Specification
Packing List
No Name Model Number
1. Miniature Color Camera CJ-3412C 1
2.
User Guide CJ-3412C 1
 ALLIANCE DRIVE
GREENSBORO, NC -
 -CREST/--
FAX: --
www.crestelectroics.co
NOTE: Please read this guide
BEFORE installing
Model CJ-3412C
Pick up Element 1/3" SONY Super HAD CCD II
Effective Picture Elements
(H×V) NTSC:768(H)×494(V)
Horizontal Resolution 650 TV Line
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s
Gama Characteristic 0.45
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/150mA
Lens 3.7mm Taper Pinhole
Dimension (in) .98(W) x.40(H) x.98(D)
Weight (lb) .27
Storage Temperature -22°~140°F RH95% MAX
Operating Temperature 14°~122°FRH95% MAX

INTRODUCTION
The Crest Electronics CJ-3412C camera is based on the
latest high-resolution 960H sensor and is capable of deliv-
ering a resolution of 650TVL. The Wide Dynamic Range
of the sensor allows the camera to capture detailed imag-
es even in challenging lighting conditions. With built in
OSD menu, this camera can be adjusted to suit a wide
variety of needs.
Please read this instruction manual carefully to ensure
proper use of the camera.
CONNECTING
BRIEF OF PRODUCT
* Sensor (CCD)
SONY 1/3" CCD Sensor.
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can capture high definition pictures in low Lux conditions.
* Scanning Mode
NTSC
DC12V Power Supply
Monitor
CJ-3412C
Link wire rule：
Power
Video
Video
DC12V
Note
:
MENU
UP
DOWN
RIGHT
LEFT
PRES
KEY BOARD
OSD
SET
LENS MANUAL/DC/VIDEO
EXPO-
SURE
SHUTTER AUTO,FLK,1/50,1/250,1/500,1/2000,1/40000,
1/5000,1/10000,1/100000
AGC LOW/MIDDLE/HIGH/OFF
D-WDR OFF/ON(LEVEL:0-63)
WHITE
BAL
ATW/AWB/AWC-SET/ANTI.CRL/MANUAL:(INDOOR、OUTDOOR、
MANUAL)
BACK
LIGHT
OFF
BLC:AREA SEL/AREA STATE/GAIN/HEIGHT/LEFT/RIGHT/TOP/
BOTTOM
HLC:LEVEL(0-255)/ MODE(ALL DAY/NIGHT ONLY)
DAY &
NIGHT
COLOR
B/W
BURST(OFF/ON)/IR SMART(OFF/ON:IR GAIN/HEIGHT/
WIDTH/LEFT/RIGHT/TOP/ BOTTOM)/IR LEVEL(HIGH/
LOW)
AUTO D-N(LEVEL/DELAY) /N-D(LEVEL/DELAY)
EXT D→N DELAY/N→D DELAY
DPC COVER THE LENS THEN PRESS ENTER KRY
SPE-
CIAL
CAM TITLE ON/OFF
MOTION
OFF/ON
AREA SEL:AREA1-4
AREA STATE:OFF/ON
HEIGHT/WIDTH/LEFT/RIGHT/TOP/BOTTOM /DEGREE/
VIEW
PRIVACY
OFF/ON
AREA SEL:AREA1-8
AREA STATE:OFF/ON
HEIGHT/WIDTH/LEFT/RIGHT/TOP/BOTTOM /COLOR
PARK.LINE OFF/ON(LT/LB/RT/RB/F/N/T/V1/V2/V3)
IMAGE ADJ
LENS SHAD:OFF/ON
2DNR:OFF/ON
MIRROR:OFF/ON
FONT COLOR:FONT(0-15)/ID&TITLE(0-15)
CONTRAST:0-255 SHARPNESS:0-31 NEG.IMAGE:OFF/
ON
DISPLAY:CRT(PED LEVEL:0-63/COLOR GAIN:0-255)/LCD
(GAMMA:0-1/PED LEVEL:0-63/COLOR:0-255)/USER
(GAMMA:0-1/PED LEVEL:0-63/COLOR:0-255)
COMM ADJ CAM ID(0-255)/BAUD RATE/PROTOCOL/DISPLAY ID/ID
POS
LAN-
GUAGE
CHINESE/ENGLISH/ESPANYOL/PYCCKNN/DEUTSCH/
PORTUGUES/FRANCAIS/JAP
RESET FACTORY RESET
Note:
● Please note the camera’s operating temperature is -4°F~131°
F .
Use of the product outside this range is not recommended.
● This installation should be made by a qualified service person
and conform to all local codes. Crest Electronics will not be
responsible for damages or injuries as a result of improper
installation
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER OR BACK. NO USER
SERVICEABLE PARTS INSIDE. . REFER SERVICING
TO OUALIFIED SERVICE PERSONNEL.
CAUTION: CSA CERTIFIED/UL LISTED CLASS 2 POWER
ADAPTORS MUST BE USED IN ORDER TO
COMPLY WITH ELECTRICAL SAFETY STANDARDS.
NOTICE: For best results, please read this instruction
booklet prior to installing the CJ-3412C camera.
CAUTION:
RISK OF ELECTRIC. DO NOT OPEN
TROUBLESHOOTING
NO VIDEO
◆Power Supply
Check input power
connections at the
terminal (AC/DC input
wires)
◆Voltage Range
Measure the voltage at
the terminal block. The
supply range is:
12VDC.
◆Video Connection
Determine if wiring
polarity at “Video
Connector” is correct.
If ok, the problem may be
with the interconnections/
splices.
ROLLING PICTURE
◆Check to make sure the
coax shield is not
touching “ground”
POOR PICTURE
◆Ensure that the video
cable is terminated with
75 ohms at each end.
