Crest Audio CPL 5C+ User manual

www.crestaudio.com
Passive 2-way Coaxial
Loudspeaker System
Operating
Manual
CPL™ 5C+

Dealer Name:
Serial Number:
Date of Purchase:
Model Number or Name:

1
Features
• Ultra-compact passive two-way coaxial loudspeaker
• Premium 5” woofer, 1.5“ voice coil
• 1” Neodymium compression driver, 1.4“ voice coil
• Continuous power handling: 100 Watts
• Nominal impedance: 16 Ohms
• Coverage pattern (HxV): 80° x 80°
• Provides a consistent sound character all through it's rated coverage angle due to the coaxial conguration
• Connectors: 2 x 4-pin twist-lock & 4-pin Euroblock
• 2+/2- Loop rough
• Advanced crossover network
• Tweeter protection
• U-Bracket included
• 15 mm Plywood construction
• Textured polyurea paint
• Available in Black and White
e Crest Audio CPL 5C+is an ultra-compact passive two-way coaxial loudspeaker designed for music playback,
public address and live performance reinforcement applications where space is at a premium.
e CPL 5C+can be utilized for both permanent installations and portable live sound applications. Perfect for
public address, monitoring and background audio reinforcement purposes typically required in houses of
worship, clubs, bars/restaurants, retail outlets plus education and corporate meeting facilities or anywhere high
quality discrete audio distribution is required.
e CPL 5C+is equipped with a premium 5 inch woofer having a 1.5 inch voice coil together with a coaxially
mounted 1 inch exit Neodymium compression driver known for its smooth frequency response and
non-fatiguing mid range. Conical directivity pattern of the loudspeaker is measured at 80° providing a wide yet
well controlled audio coverage. An internal advanced crossover network maintains EQ and driver protection.
Impedance of the loudspeaker is 16 Ohms allowing for easy daisy chaining. Connectivity is made via either
looping 4-pin twist-lock or 4-pin Euroblock connectors.
e CPL 5C+enclosure is built from prime-grade 15 mm plywood that oers sturdy mechanical and low resonant
electro-acoustic characteristics together with a heavy-duty steel grille backed with acoustic foam to ensure
maximum protection of the internal components. e loudspeaker is equipped with a total of 3 threaded
suspension points oering multiple mounting options for various applications. Available in durable black and
white nish.
Crest Audio® CPL™ 5C+
DESCRIPTION EN

2
Conguration: Ultra-compact 2-way coaxial passive speaker
Power Handling*: 100 Watts Continuous, 200 Watts Program, 400 Watts Peak
*To reach the rated power, there must be an infrasonic lter set to 100 Hz, 12 dB / Octave Butterworth minimum ltering. If the CPL 5C+is used with a crossover for a
Subwoofer, then the high pass section needs to meet this criteria at a minimum. A higher frequency and/or lter slope is acceptable.
Nominal Impedance: 16 Ohms
Sensitivity (1W/1m): 92 dB
Maximum SPL (1m): 112 dB @ 100 Watts; 118 dB @ 400 Watts Peak
Frequency Response*: 261 Hz - 20 kHz, ±3 dB
*1m on-axis, swept-sine in anechoic environment
Frequency Range*: 91 Hz - 20 kHz, -10 dB
*1m on-axis, swept-sine in anechoic environment
Box Tuning Frequency: 103 Hz
Nominal Coverage Pattern (-6 dB): 80° H x 80° V
LF Driver: 1 x 5" (165 mm) Woofer - Crest Audio KP5W38
LF Driver Voice Coil: 1.5" (38 mm)
HF Driver: 1 x 1" (25.4 mm) Neodymium Compression Driver - Crest Audio 5C36NP1
HF Driver Voice Coil: 1.4" (36 mm)
Input Connections: 2 x 4-pin twist-lock (NL-4 style) & 1 x 4-pin Euroblock
Input, Pin 1+ = (+) positive; Pin 1- = (-) negative / Loop rough, Pin 2+ = (+) positive; Pin 2- = (-) negative
Enclosure Material: 0.6" (15 mm) Plywood
Finish: Textured polyurea paint, available in Black & White
Black Finish: RAL: 9004 Signal Black (Pantone: Black 6)
White Finish: RAL: 9003 Signal White (Pantone: 705)
Front: Full-coverage perforated steel grille, backed with acoustically neutral foam
Mounting Provisions: U-Bracket included. ree (3) M8 suspension points (1 top, 1 bottom, and 1 rear), top and
bottom suspension points for U-Bracket, rear for safety chain or wire
Overall Dimensions (HWD):
Front - 7.28" x 7.28" x 8.0" (185 x 185 x 203 mm)
Net Weight: 11.6 lbs (5.3 kg)
EN SPECIFICATIONS

3
Before attempting to suspend this speaker, consult with a certified structural engineer. Speaker can fall from
improper suspension, resulting in serious injury and property damage. Do not suspend or mount any other
product or device from this enclosure! Use only the correct mating hardware. All associated rigging is the
responsibility of others. Maximum enclosure angle 30 degrees.
Whenever possible, in addition to the nominal primary mounting method, use a suitable safety chain or wire rope
attached to one of the other groups of fly point inserts, and firmly attached to a suitable structural member as
indicated by a certified structural engineer.
We recommend the use of thread-locker at the insert point bolts, so the bolts cannot vibrate loose. Never
transport the cabinet using the array bracket or other mounting brackets as a structural member, while the cabinet
is mounted on an array bracket or other mounting bracket and unsupported otherwise, as this may unduly stress
the mounting inserts.
This Crest Audio loudspeaker should be suspended overhead only in accordance with the procedures and
limitations specified in the User's Manual and possible manual update notices. This system should be suspended
with certified rigging hardware by an authorized rigging professional and in compliance with local, provincial or
national suspension ordinances.
CAUTION
WARNING
The CPL 5C+coaxial passive 2-way loudspeaker system is very efficient and powerful! This sound system can
permanently damage hearing! Use extreme care setting the overall maximum loudness!
The apparent sound level of the CPL 5C+can be deceiving due to its clear, clean sound output. The lack of
distortion or obvious distress can make the sound level seem much lower than it actually is. This system is capable
of sound pressure levels (SPL) in excess of 118 dB at 1 meter from the speaker!
INSTALLATION
A total of three (3) M8 1.25 mm per thread threaded mounting suspension points (1 top, 1 bottom, and 1 rear) are
provided. The rear one is plugged with a hex key beveled head bolt.
The top and bottom mounting suspension points are for use with the included U-Bracket. The mounting
suspension point on the rear is for use of a forged shoulder machinery eyebolt for a safety chain or wire rope. The
forged shoulder machinery eyebolt should be an M8 size, 1.25 mm per thread, and must conform to at least DIN
580 or ASTM A489, or whatever local, provincial or national suspension ordinances or regulations may
additionally require. Eyebolts must be used at a minimum as a pair, never use just one eyebolt to hang the speaker
overhead.
EN
SAFETY

4
EN RIGGING & MOUNTING
Installation methods for included mounting accessories
Installation Method 1 - U-Bracket
Bolt hole
Lockwasher
M8 knob-headed bolt
Lockwasher
M8 knob-headed bolt
M8 knob-headed bolt Insert for safety chain or
wire rope
Diagram 1
Diagram 2
Use the large handled knob-headed bolts to mate the U-Bracket to the cabinet, placing lockwashers between the
bracket and bolt. (See diagram 1 & 2 on page 4). Tighten the knob very firmly to retain the desired angle.
For permanent installations where the cabinet may be within reach of the public, regular hex head bolts can be
used instead of the knob-headed bolts. These should be an M8, grade 8.8 or better, 1.25 mm per thread, metric
bolt, that does not penetrate the cabinet past the cabinet surface more than 20 mm (approximately 3/4”). Metric
M8 steel washers (not supplied) should be used to keep the hex head from pulling through the lockwasher
(supplied rubber gasket).
It is then recommended that thread-locker be used. Using hex head bolts with thread-locker will reduce the
possibility for someone to attempt to unscrew the knob-headed bolts by hand to vandalize or otherwise alter the
cabinets mounting.
To connect a safety chain or wire rope, an M8 eyebolt can be used in the insert point illustrated on page 4 (diagram
2). Specifications for the eyebolt are as follows: A forged steel shoulder-type lifting eyebolt, which meets the
requirements of DIN 580 or ASTM A489, or whatever local, provincial or national ordinances or regulations may
additionally require.
Note: The U-Bracket is a standard accessory, which has been included in the product package.

5
EN
INPUT & LOOP THROUGH SCHEMATICS
Input Cup
4-pin twist-lock
IN / THRU
LOOP THRU
1+
1-
2-
2+
4-pin twist-lock
IN / THRU
LOOP THRU
1+
1-
2-
2+
IN / THRU
LOOP THRU
1+
1-
2-
2+
4-pin Euroblock
X-Over & Speakers
1+
1-
X-Over
+
-
+
-
HF
LF
CPL+Series Input & Loop Through Schematics

6
4-conductor cable 2-
4-conductor cable 2+
4-conductor cable 1-
4-conductor cable 1+
Poweramp
Combination Output
Channel B
Channel A
Poweramp
Channel B
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
Poweramp
Channel B
Poweramp
Channel A
1+
1-
2+
2-
1+
1-
2+
1+
1-
2+
2-
Poweramp
Channel A
2-
Speaker #1Speaker #2
Speaker n#Speaker #2
Signal Changer Adapter Cable
2+ -> 1+
2- -> 1-
1+1-
2-2+
1+
1-
2+
2-
1+
1-
2+
2-
1+
1-
2+
2-
Poweramp
Channel B
1+
1-
2+
2-
Poweramp
Channel A
Speaker #1
Speaker n#
Speaker n#: The number of speakers in
parallel must refer to the rated impedance.
It is recommended that the impedance in
parallel is not less than 4.
CPL+Series Loop rough System Schematics
INPUT & LOOP THROUGH SCHEMATICS
EN

Unit: mm
7
DIMENSIONS EN
58.5
294.5 203
217.2
185
80
185
225
92.5
91.6
57.5

8
ARCHITECT'S & ENGINEER'S SPECIFICATIONS
EN
e ultra-compact coaxial loudspeaker shall consist of a 5 inch (130 mm) low frequency transducer with 1.5 inch
(38 mm) voice coil and a coaxially mounted 1 inch (25.4 mm) exit Neodymium compression driver with a 1.4 inch
(36 mm) voice coil and a frequency dividing network installed within the enclosure.
Performance specications of a typical production unit shall be: Measured sensitivity SPL at 1 m (3.3) with 4.0V
input, shall be 92 dB-SPL. Usable frequency response shall extend from 91 Hz to 20 kHz (10 dB below rated
sensitivity, in full space, with no external equalization). Nominal impedance shall be 16 Ohms. Rated power
capacity shall be at least 100 Watts continuous power and 400 Watts peak power, dened as 6 dB above a test signal
of ltered random noise.
e system shall be protected against damage from occasional over-powering limiting the power to the network
and transducers. e coaxial neodymium compression driver shall be capable of even coverage at a nominal 80°
horizontal through 80° vertical distributed pattern.
e enclosure shall be constructed from prime-grade 15 mm plywood. e loudspeaker shall be equipped with a
total of three (3) suspension points. e grille shall be of heavy-duty steel backed with acoustically transparent
foam. e external wiring shall be via either two 4-pin twist-lock or one 4-pin Euroblock connectors. e
loudspeaker shall be 7.28 inches (185 mm) high by 7.28 inches (185 mm) wide by 8 inches (203 mm) deep
weighing 11.6 pounds (5.3 kg). e nish shall be a paintable lightly textured black or white.
e ultra-compact coaxial loudspeaker shall be the Crest Audio CPL 5C+with included U-Bracket.

9
FREQUENCY RESPONSE & IMPEDANCE EN
Frequency Response
Impedance

10
NOTES
EN

©2023-Rev_P1_2023_01_23
Features and specifications subject to change without notice.
Crest Audio 5022 HWY 493 N. Meridian, MS 39305 [phone] FAX [phone]
