Cretors 7906 User manual

7700-SC/E/SC-E
176 MITTEL DRIVE, WOOD DALE, IL 60191
BOX PUMP MANUAL
Models 7906
120Volt,
S ngle Phase, 60 Hz
230 Volt,
S ngle Phase, 50 Hz
READ and UNDERSTAND these operating and safety
instructions before operating this machine

7700-SC/E/SC-E
SAFETY FIRST
The information in this manual is essential for the safe installation and
maintenance of your Cretors oil pumps. The manual must be read and
understood before installing, operating or maintaining this equipment or
equi alent training must be pro ided.
"The employer shall instruct each employee in the recognition and a oidance
of unsafe conditions and the regulations applicable to his work en ironment
to control or eliminate any hazards or other exposure to illness or injury".
Ref.: 29 CFR 1926.20 (b)(4)(a)(2)
It is understood that safety rules within indi idual companies ery. If a
conflict exists between the safety procedures contained in this manual and
the rules of a using company, the more stringent rule should take
precedence.
I INTRODUCTION
This manual contains information regarding your Cretors oil pumps. There is nothing, howe er,
more important than the safety aids and warnings that are found throughout this document. The
Safety Alert Symbol is used to identify topics of primary safety concern where er they appear.
Furthermore, a separate section has been included which deals exclusi ely with operation and
accident pre ention.
If, after re iewing this manual, anything is unclear or technical problems are encountered, contact
the dealer from whom you purchased your machine for assistance; and, if there are any additional
questions, feel free to contact our Customer Ser ice Department at 800/228-1885. Always ha e the
serial number of your machine a ailable to assist in obtaining the correct information.

7700-SC/E/SC-E
II SAFETY ALERT SYMBOL
The symbol shown below is used to call your attention to instructions concerning your personal
safety and the safety of others. Watch this symbol. It points out important safety precautions. It
means "ATTENTION! Become Alert! Your personal safety is in ol ed!" Read the message that
follows and be alert to the risk of personal injury or death.
III PURPOSE OF MANUAL
This instruction manual is intended to familiarize owners with the operation
and safety procedures associated with your Cretors oil pumps.
This manual should be kept a ailable to operating and maintenance
personnel.
A person who has not read and understood all operating and safety
instructions is not qualified to operate the machine.

7700-SC/E/SC-E
IV PRODUCT IDENTIFICATION
CRETORS OIL PUMPS:
MODELS: 12881 BOX PUMP
MODEL 7906 BOX AUTOMATIC OIL PUMP MODEL
Capacity:
Electrical: 120 Volt, Single Phase, 60 Cycle, 120 Watts, 1 amps
Dimensions: 11”D x 7”W x 5”H
Net Weight: lbs.

7700-SC/E/SC-E
V INSTALLATION AND OPERATION INSTRUCTIONS
A. Locat on
Choose a location for your Cretors oil pump to maximize the ease of operation and
maintenance procedures. Check your local building and fire codes for location restrictions.
B. Connect ng o l pump to power source
Make certain that power supply circuit breakers are in the off position. Make certain
all switches on the machine are in the off position before plugging in your 7906 model
Cretors oil pumps.
Perform work only on de-energized circuits. Failure to do so may lead to electrical
shock resulting in personal injury or death.
C. Plug your machine and oil pump into the correct type of outlet, turn on the circuit breaker
and then turn on the machine switches. If the motor groans, the receptacle has been
improperly wired. Contact an Electrician.
Make certain all switches are in the off position before plugging in your Cretors popcorn machine
and oil pump.
1. Connect the pump to the oil deli ery tube by pushing the quick connect socket at the
end of the deli ery hose, onto the quick disconnect plug mounted on the support co er.
When the plug is fully inserted, the spring will snap into place and hold the connector
securely.
2. Make certain the oil deli ery hose contains no low spots. Oil may solidify in such low
spots and clog the hose.
D. Pump Adjustment
Make sure that the popper heat switch is off during pump adjustments. This is to
a oid touching a hot kettle, which may result in serious burns.
1. To check the output adjustment, place the kettle in the dump position and hold the oil
measure cup under the oil deli ery tube.
Ne er hold the oil measure cup under the oil deli ery tube if the kettle is hot. This
may result in serious burns or injuries.
2. Press the deli ery button and wait for the pump to cycle. Dispose of the oil, and cycle
the pump again. To obtain accurate readings, let the oil drain back to the pail as it
would between popping. Obser e the oil in the tube to confirm that the oil has drained
back to the pail.

7700-SC/E/SC-E
3. After three cycles, the amount of deli ered will be consistent. Check this amount with
the measuring cup.
MACHINES AMOUNT OF OIL SET TIMER TO “X” SECONDS
PT14 4.5 oz. 3 seconds
MR16 5.5 oz. 4 seconds
DI20
PR20
G20 7.5 oz. 5 seconds
DI32
PR32
G32E
G32G 11 oz. 9 seconds
DI48
G48 16 oz. 12 seconds
*Recommended pump timer settings. Machines may differ slightly.
4. If the amount of oil is not correct, it may be adjusted. To adjust the pump:
a. Turn off the pump switch
b. Disconnect oil hose
Make sure you brace the pail step against the cabinet to a oid sliding it off the base of
the cabinet when pulling the pail across it. Use proper mo ing techniques to a oid
injury to back.
c. To set the oil quantity deli ery:
•Remo e the snap out plug on top of the switch box, which is on the top of the
pump, to expose the timer.
•Check to make sure the timer has good contact by pushing down lightly on
timer, making certain not to push any of the switches.
•Switches 1 through 10 are each assigned a certain amount of seconds of delay
time. Each successi e switch is double the amount of delay time for the switch
before it. The amounts of delay time are written at the top, along the
“OPEN”/”OFF” line (i.e. 1,2,4,8, etc).
•The switch must be in the UP position along the “OPEN”/”OFF” line for the
delay time to apply. An example of this for three seconds would ha e the switch
corresponding to the 1 on the “OPEN”/”OFF” line up along with the switch
corresponding to the 2 on the “OPEN”/”OFF” line.
d. Install snap out plug (which was remo ed in first step in section e).
e. Connect oil hose by snapping in place.
f. Turn on the pump switch and re-check the oil output using steps 1thru 4 in the
Pump Adjustment section.

7700-SC/E/SC-E
VI SANITATION INSTRUCTIONS
Be certain the machine is turned ‘OFF’ and power is unplugged before sanitizing this
machine unless a specific cleaning procedure requires power to the machine. Failure
to do so could result in injury or death.
Do not clean heated surfaces until they ha e been gi en sufficient time to cool. Failure
to do so may result in serious burns or scalds.
Do not get the top of the pump wet. Electrical shorts and a shock hazard, which can
cause injury may result if the wires inside the top of the pump get wet.
This manual is filled with timesa ing and money-sa ing information regarding your Cretors
popcorn machine. There is nothing, howe er, more important than the safety aids and warnings
found throughout this document.
If you ha e any questions, feel free to contact our Customer Ser ice at 800/228-1885.
Additional copies of this manual can be obtained from Customer Ser ice.
Cretors warranties this machine to be free of defects in parts, materials and workmanship for two
years. Please fill out and return the registration card to acti ate your warranty. If you ha e
questions concerning the warranty, please contact Customer Ser ice at 800/228-1885.

16
15
14
8
1
5
3 4
2
7
11
6
12
10
9
13
NOTES:
NO SUBSTITUTIONS PRIOR TO ENGINEERING APPROVAL. 1.
REVISIONS
REV DESCRIPTION DATE APPROVED
A DC - XX/XX/XX X. XXXXX
ITEM # QTY. P / N DESCRIPTION
1 1 12881 BOX PUMP PLATE WELDMENT
2 1 12880 PUMP COVER
3 1 2540 TIMER
4 1 3036 RELAY BASE
5 1 1517 NAMEPLATE, SERIAL NO, BLANK
6 1 2573 HOLE COVER WITH 'O' RING
7 1 12175 CONNECTOR PLATE, 7800 PUMP, DOM
8 4 4732 MAGNET
9 2 12892 COUPLINGBODY 3/8" ID QK DISC
10 8 1069 CLAMP HOSE
11 1 2011 RECEPTACLE PUMP
12 1 10863 TUBING 3/8" ID X 9/16" OD SILI
13 2 12891 INSERT- QUICK DISCONNECT FITTING
14 3 1223 TUBING-3/8" ID CLEARFLEX
15 1 14626 FILTER, IN LINE, CLEANABLE
16 1 4673 QCDII BAG CONNECTOR
SEE BOM
SCALE
1:4
X.XX = 0.02
X.XXX = 0.01
ANGLES = 0.5
HOLES = +0.005/-0
FINISH = 125Ra
REMOVE SHARP
EDGES & BURRS.
MATERIAL
UNLESS SPECIFIED
ALL DIMENSIONS
ARE IN INCHES.
A
176 MITTEL DRIVE, WOOD DALE, IL 60191
DRAWN BY
A
ESP
X. XXXXX XX/XX/XX
SHEET
7906A
DATE SIGNATURE
SIZE DWG NO
THIRD ANGLE PROJECTION
TITLE
APPROVED BY
THIS DRAWING CONTAINS INFORMATION PROPRIETARY TO C. CRETORS &
CO. AND IS FURNISHED IN CONFIDENCE FOR THE SOLE PURPOSE OF
SUPPLYING THE RECIPIENT WITH NEEDED ENGINEERING DATA. IT'S
CONTENTS SHOULD NOT BE DISCLOSED OR REPRODUCED IN ANY
MANNER WITHOUT THE WRITTEN CONSENT OF C. CRETORS & CO.
ALL RIGHTS RESERVED.
REV
BOX PUMP ASSEMBLY
1 OF 2
TOLERANCES
D
1
C
2
B
A
12
34
D
C
3
B
4
A
11/24/15
WEIGHT
4.75
LBS

12.70
5.000
25.80
10.158
0.16
.062
CAP
178.08
7.011
NOTES:
DIMENSIONS ARE IN INCHES AND [CENTIMETERS]. 1.
TUBING IS CUT-TO LENGTH AS NEEDED 2.
SEE BOM
SCALE
1:4
X.XX = 0.02
X.XXX = 0.01
ANGLES = 0.5
HOLES = +0.005/-0
FINISH = 125Ra
REMOVE SHARP
EDGES & BURRS.
MATERIAL
UNLESS SPECIFIED
ALL DIMENSIONS
ARE IN INCHES.
A
176 MITTEL DRIVE, WOOD DALE, IL 60191
DRAWN BY
A
ESP
X. XXXXX XX/XX/XX
SHEET
7906A
DATE SIGNATURE
SIZE DWG NO
THIRD ANGLE PROJECTION
TITLE
APPROVED BY
THIS DRAWING CONTAINS INFORMATION PROPRIETARY TO C. CRETORS &
CO. AND IS FURNISHED IN CONFIDENCE FOR THE SOLE PURPOSE OF
SUPPLYING THE RECIPIENT WITH NEEDED ENGINEERING DATA. IT'S
CONTENTS SHOULD NOT BE DISCLOSED OR REPRODUCED IN ANY
MANNER WITHOUT THE WRITTEN CONSENT OF C. CRETORS & CO.
ALL RIGHTS RESERVED.
REV
BOX PUMP ASSEMBLY
2 OF 2
TOLERANCES
D
1
C
2
B
A
12
34
D
C
3
B
4
A
11/24/15
WEIGHT
4.75
LBS
