Crosley iDUET CR3010A User manual

CR3010A
iDUET
In truction Manual

iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.

Welcome
Thank you for purchasing the Crosley Radio iDUET Clock Radio.
Before operating this unit, please read this manual thoroughly and
retain it for future reference.
Features
AroundSound™- Your Crosley iDUET features our exclusive
AroundSound design. Using a single, custom - designed driver, the
iDUET radio simulates surround sound, creating a warm, ambient
tone, regardless of where you may be located with regards to the
radio.
Portable Audio Ready - Your iDUET radio comes ready to play
portable audio products, including mp3 players, satellite radio, gaming
devices, cd players, walkmans, - basically anything with a headphone
jack!
Table of Contents
Getting Started
Control Locators 4
Connector Locators 5
Unpacking 6
Set Up 6
Basic Operation
A /F Radio 7
Alarm Clock 7
Portable Audio Ready 8
iPod/iPhone 8
General
Troubleshooting Guide 9
Warranty 10
Control Locators
1. Volume Knob
2. Tuner Dial
3. Function Switch
4. Power Indicator
5. Tuning Knob
6. Tuning LED
7. Clock
8. Alarm Dial
9. Sleep Indicator
10. Alarm ON/OFF Indicator
11. Alarm Time Pointer
12. Sleep
13. Alarm
14. Snooze
1
2
3
4
5
6
Getting Started
4
7
8
9 10
11
12 13
14

CONNNECTOR LOCATORS
1. Time Set
2. Clock Battery Compartment
3. Aux In
4. Power Input
5. F Antenna
Getting Started
1
234
Getting Started
Unpacking
1. Remove packing material from unit.
Note: Save all packing materials.
2. Remove plastic bag covering radio.
3. Remove ties from AC to DC power adaptor.
4. Remove supplied audio cable from plastic bag.
Note: Save cable for portable audio component hookup.
Set Up
1. Unwind the AC to DC power adaptor.
2. Plug AC end of the power cord into appropriate outlet.
3. Plug the small end of the power adaptor into
the Power Jack in the back of the unit.
5
5 6

Getting StartedGetting Started
A /F RADIO
1. Turn the Function Knob to the desired tuning band.
The Power Indicator will turn green to indicate the power
is turned on.
2. Rotate the Tuning Knob to select the desired station.
The Tuning LED will appear brightest when the best signal is
reached. Some weaker but listenable A stations may not
turn on the Tuning LED.
3. Adjust the volume to the desired level by rotating the Volume Knob.
4. Position the antenna for optimum reception.
ALAR CLOCK
1. Install AA battery in the Clock Battery Compartment.
Note: Check battery occasionally and replace annually.
2. Set the clock to the correct time by pressing and holding the
Time Set button on the back of the unit.
3. Turn the Alarm Dial counter-clockwise to set the Alarm Time
Pointer to the desired alarm time.
4. Set the Function Switch to the desired alarm source and set
the volume level.
5. Press the Alarm button to set the alarm. The Alarm On/Off
Indicator will light up indicating the alarm is set. If you selected
A or F to wake you, the radio will automatically turn off.
Note: If the alarm is set and the Function Switch is in the Off
of Aux mode, the unit will default to Buzzer when the alarm
sounds. In the event of a power outage, the alarm will operate
only in Buzzer mode until power is restored.
6. When alarm sounds at desired time, you may press the Snooze
button to delay the alarm for 5 minutes. This can only be done
6 times. After the 6th press of the snooze button, the alarm
will not sound again.
Note: When in Alarm mode, unit will not operate. Turn Alarm off
to listen to unit.
ALAR CLOCK cont.
Sleep
Once the Alarm has been set, you may press the Sleep button
to listen to your radio for approximately 20 minutes. Once
pressed, the Sleep Indicator will light up indicating the radio is in
sleep mode. After 20 minutes, the radio will turn itself off.
PORTABLE AUDIO READY
1. Turn the function knob to “AUX”. Turn the volume to a lower level.
2. Using the supplied male to male mini pin connector, connect
one end to the AUX INPUT jack on the back of the unit.
3. Turn on your portable audio device and set the volume
on the device to approximately 10% of full volume.
4. Plug the other end into an output or headphone jack on your
external device.
5. Begin playback on your external device.
Adjust the volume to your desired listening level on your iDUET.
For more volume, increase the setting on your portable device.
iPod/iPhone OPERATION
1. Insert the correct dock adapter (suppllied with your iPod or iPhone)
that fits your iPod/iPhone. Your iPod/iPhone should fit snugly into
the correct adapter. Gently press the adapter until it snaps firmly
into place.
2. Place your iPod/iPhone into the dock. Your iPod/iPhone will
begin charging
3. Turn the Function Switch to the iPod position.
4. Browse your iPod/iPhone to select a song or playlist and
press play.
5. Adjust the volume to the desired listening level by turning the
Volume Knob.
6. To remove the dock adapter, push your fingernail into the
slot in the back of the adapter and lift up.
7 8

Crosley Radio, Inc. warrants the product to be free from defects in material and
workmanship under normal use for a period of one year from the original date of
purchase. This warranty is not transferable. If the product is determined to be defective
during the warranty period, the unit will be repaired or replaced at Crosley Radio’s sole
discretion. This warranty covers manufacturing defects and normal consumer use and
does OT cover damage or failure as a result of abuse, accident, alterations, misuse,
neglect, abnormal wear and tear, inadequate maintenance, commercial or unreasonable
use, damage caused by power surges, mishandling, accident, acts of God or attempted
repair by an unauthorized service agent. Also not covered are cosmetic damages, cords
and antennas. Should this product fail to function in a satisfactory manner, it is best to
first return it to the store or retailer where it was originally purchased. If additional service
is still needed, the original purchaser must FIRST contact our offices to obtain an RA
(Return Authorization) umber.
TO OBTAI A RA UMBER
CALL: 1.888.CROSLEY
(1.888.276.7539)
Send the unit prepaid to the address below in the original packaging (or reasonable
substitute to prevent damage). Clearly mark your RA number on the outside packaging
and include the original sales receipt (or a copy) indicating date of purchase, amount
paid, and place of purchase. You must also include your full name, shipping address
and daytime contact number. Please include a check or money order in the amount
of $19.95, made payable to Crosley Radio, to cover handling and return shipping
charges. Returned products will not be shipped to PO Boxes. Crosley Radio will not
be responsible for delays or unprocessed claims resulting from a purchaser’s failure
to provide any or all of the necessary information.
CROSLEY RADIO
ATT : RETUR S DEPT
2001 PRODUCTIO DRIVE
Louisville, KY 40299
For additional support: Crosley Radio Consumer Service Department
24 hours a day / 7 days a week
Telephone: 1.888.CROSLEY (1.888.276.7539)
There are no express warranties except as listed above.
The purchaser’s bill of sale is the only proof of warranty entitlement.
This warranty gives the purchaser specified legal rights in addition to any rights which
may vary from state to state.
In accordance with the “Moss-Magnuson Warranty Act” of July 10, 1975, this is termed
a “limited warranty” which in no way compromises Crosley Radio’s high standards of
quality and workmanship.
LIMITED MANUFACTURERS WARRANTY
9
Troubleshooting Guide
There is no power
1. ake sure AC to DC power cord is plugged in
at the wall and at the back of the unit.
2. Check that the Function Knob is not in the OFF position.
There is no sound
1. ake sure the Function switch is not in the AUX position.
2. ake sure the unit is not in Alarm mode.
The sound is distorted.
1. Adjust the tuner and/or antenna to improve the
signal strength. Under certain circumstances, the
reception may be improved by relocating the unit.
2. When using the “Aux in” plug, turn off any EQ settings
on the portable device.
3. Check the volume level of external device if listening to auxiliary
input. It should be set as low as possible.
Getting Started
10
