Crosley CRSE266FB3 User manual

rigerator 4 = _
at a Glance ........ 7
Temperature Controls... 8 - 11
Looking inside ......... 12 -13
Automatic ice and Water
Dispenser ............... 14 - 20
Food Storage
& Energy Saving Tips ...... 21
Normal Operating Sounds..22
Care & Cleaning ........ 23 -24
Warranty ................... 25
Before You Call
Solutions to
commonProblems............. 26 -29
EspaSol ........... 30
Fran_ais ........... 59
READ AND SAVE THESE INSTRUCTIONS PN:241824401(June2007)

Congratulations on your purchase of a new refrigerator! We
here at Crosley Corporation are very proud of our product and
we are completely committed to providing you with the best
service possible. Your satisfaction is our #1 priority.
Please read this Use & Care Manual very carefully. Itcontains
valuable information on how to properly maintain your new
refrigerator.
We know you'll enjoy your new refrigerator and ThankYou for
choosing our product. We hope you consider us for future
purchases.
PLEASE READ AND SAVETHESE iNSTRUCTiONS
This Use & Care Manual provides specific operating
instructions for your model. Use your refrigerator only as
instructed in this manual. These instructions are not meant to
cover every possible condition and situation that may occur.
Common sense and caution must be practiced when installing,
operating and maintaining any appliance.
Please record your model and serial numbers below for
future reference.This information is found on the serial
plate located inside the refrigerator compartment.
i: a i i
Model Number:
Serial Number:
Purchase Date:
PLEASE COMPLETE
AND MAIL IN THE
PRODUCT
REGiSTRATiON
CARD INCLUDE[
WITH YOUR
REFRIGERATOR.
FOR PRODUCT INFORMATION CONTACT:
336=761=1212
Crosley Corporation
111 Cloverleaf Dr.
Winston-Salem, NC 27103
www.croslev.com
Please attach sales receipt
here for future reference.

FORYOURSAFETY
,, Donotstoreorusegasoline,orotherflammableliquidsin
thevicinityofthisoranyotherappliance.Readproduct
labelsforwarningsregardingflammabilityandother
hazards.
,, Donotoperatetherefrigeratorinthepresenceof
explosivefumes.
,, Avoidcontactwithanymovingpartsofautomaticice
maker.
,, Removeallstaplesfromthecarton.Staplescancause
severecuts,andalsodestroyfinishesiftheycomein
contactwithotherappliancesorfurniture.
CHILDSAFETY
Destroyorrecyclethecarton,plasticbags,andanyexterior
wrappingmaterialimmediatelyaftertherefrigeratoris
unpacked.ChildrenshouldNEVERusetheseitemstoplay.
Cartonscoveredwithrugs,bedspreads,plasticsheetsor
stretchwrapmaybecomeairtightchambers,andcanquickly
causesuffocation.
PROPER DISPOSAL OFYOUR REFRIGERATOR OR
FREEZER
Risk of child entrapment
Child entrapment and suffocation
are not problems of the past.
Junked or abandoned refrigerators
or freezers are still dangerous -
even if they will sit for "just a few
days." If you are getting rid of your
old refrigerator or freezer, please
follow the instructions below to
help prevent accidents.
Before you throw away your old refrigerator/freezer:
,, Remove doors.
,, Leave shelves in place so children may not easily climb
inside.
,, Have refrigerant removed by a qualified service
technician.
ELECTRICAL iNFORMATiON
,The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Nz., 15 Amp, AC only electrical
outlet. The power cord of the appliance is equipped with a
three-prong grounding plug for your protection against
electrical shock hazards. It must be plugged directly into a
properly grounded three prong receptacle. The receptacle
must be installed in accordance with local codes and
ordinances. Consult a qualified electrician. Avoid
connecting refrigerator to a Ground Fault Interruptor (GFI)
circuit. Do not use an extension cord or adapter plug.
,, If the power cord is damaged, it should be replaced by an
authorized service technician to prevent any risk.
,, Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly, and pull straight out
from the receptacle to prevent damaging the power cord.
,, Unplug the refrigerator before cleaning and before
replacing a light bulb to avoid electrical shock.
,, Performance may be affected if the voltage varies by
10% or more. Operating the refrigerator with insufficient
power can damage the compressor. Such damage is
not covered under your warranty.
,, Do not plug the unit into an electrical outlet controlled by a
wall switch or pull cord to prevent the refrigerator from
being turned off accidentally.

ThisUse&CareManualprovidesgeneraloperating
instructionsforyourmodel.Usetherefrigeratoronlyas
instructedinthisUse&CareManual.Beforestartingthe
refrigerator,followtheseimportant first steps.
LOCATION
*Choose a place that is near a grounded electrical outlet.
Do Not use an extension cord or an adapter plug.
*If possible, place the refrigerator out of direct sunlight
and away from the range, dishwasher or other heat
sources.
*The refrigerator must be installed on a floor that is level
and strong enough to support a fully loaded refrigerator.
,Consider water supply availability for models equipped
with an automatic ice maker.
iNSTALLATiON
Installation Clearances
*Allow the following clearances for ease of installation,
proper air circulation, and plumbing and electrical
connections:
Sides & Top 3/8"
Back 1"
DOOR OPENING
To Remove Toe Grille:
1.
2. Open freezer and fresh food compartment doors.
Working from left side of toe grille, slip your fingers
between top of toe grille and cabinet. Gently pull
forward until first set of
tabs are free. Slide
your hand down past Cabinet
the free tabs and pull
forward again until the
second set of tabs are
free. Continue this ,-_./
process until all tabs
are free and the toe
grille can be removed.
(See graphic at top of _
page in right column.)
LEVELING
All four corners of your refrigerator must restfirmly on a solid floor.
Your refrigerator is equipped with adjustable front rollers to help level
your unit. To ensure proper door seal and assist door closing, the
refrigerator should be tilted 1/4" (6 mm), front to back.
ToLeve/ Your Refrigerator:
1. Remove toe grille. (See 'To Remove ToeGrille".)
2. Use fiat-bladescrewdriver or 3/8" socket wrench to adjust
front rollers.
Your refrigerator should be positioned to allow easy access to a
counter when removing food. For best use of drawers and freezer
baskets, the refrigerator should be in a position where both the
refrigerator and freezer doors can be fully opened.
TOE GRILLE iNSTALLATiON /REMOVAL
To/nstafl Toe Grille:
1. Open freezer and fresh food compartment doors.
2. Line up toe grille at base of refrigerator, making sure the
four bottom tabs are resting through holes at base of
cabinet.
3. Starting from left side of toe grille, press in on first top tab
using your thumb and push toe grille forward until it snaps
in place. Continue this process until all tabs are snapped
in place and toe grille is secured to refrigerator.
Raise
3. Check both doors to be sure seals touch cabinet on all four
sides.

To Connect Water Supply Line To Ice Maker Inlet Valve
1. Disconnect refrigerator from electric power source.
2. Place end of water supply line into sink or bucket. Turn ON
water supply and flush supply line until water is clear. Turn
OFF water supply at shutoff valve.
3. Unscrew plastic cap from water valve inlet and discard
cap.
4. Slide brass compression nut, then ferrule (sleeve) onto
water supply line, as shown.
5. Push water supply line into water valve inlet as far as it will
go (¼ inch). Slide ferrule (sleeve) into valve inlet and
finger tighten compression nut onto valve. Tighten another
half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to
rear panel of refrigerator as shown.
7. Coil excess water supply line (about 2Y2turns) behind
refrigerator as shown and arrange coils so they do not
vibrate or wear against any other surface.
8. Turn ON water supply at shutoff valve and tighten any
connections that leak.
9. Reconnect refrigerator to electrical power source.
10. To turn ice maker on, lower wire signal arm (side mounted)
or set the ice maker's On/Off power switch to the "r'
position (rear mounted).
Before installing The Water Supply Line, You Will Need:
,, Basic Tools: adjustable wrench, flat-blade screwdriver,
and Phillips TM screwdriver
,, Access to a household cold water line with water pressure
between 30 and 1OOpsi.
,, A water supply line made of ¼ inch (6.4 mm) OD, copper
tubing. To determine the length of copper tubing needed,
you will need to measure the distance from the ice maker
inlet valve at the back of the refrigerator to your cold water
pipe. Then add approximately 7 feet (2.1 meters), so the
refrigerator can be moved out for cleaning (as shown).
,, A shutoff valve to connect the water supply line to your
household water system. DO NOT use a self-piercing type
shutoff valve.
,, A compression nut and ferrule (sleeve) for connecting the
water supply line to the ice maker inlet valve.
Plastic Water Tubi- j
to Ice Maker
F Tube
Brass
Compression
tSleeve_
'V\X,_Coppe r
walerliee
terValve
Bracket
_-Valvelnlet
Copper water line
from household water supply
i[ncJuae enough tubing in loop to a.ow
moving refrigerator out for clean_ng,_

ToolsNecessary:
and
Fiat Head
Screw Driver
m
Door
Lower
• i
Screws _''_
TO D|SCONNECT
1. Press outer ring against face
remove TUDe
push ur_til mark touches face of fitting
DOOR REMOVAL iNSTRUCTiONS:
if it is necessary to move the refrigerator through narrow doorways, follow
these steps to remove the doors.
Before you start:
1 Make sure the electrical power cord is unplugged from the wall outlet.
2 Remove any food from the door shelves.
3 Close the doors.
To remove the hinge cover:
1 Remove the three screws from the cover over the top door hinges.
2 Pull the cover forward about a half inch and lift it off.
To remove the refrigerator door:
1 Trace lightly around the door's top hinge with a pencil. This makes reinstallation
easier
2 Remove the two screws from the top hinge. Lift the door off of the bottom hinge and
set it aside.
3 Remove the three bottom hinge screws and hinge, if necessary.
To remove the freezer door:
1 Detach the multi-wire cable connector located above the top hinge. Grasp both sides
of the connector firmly and pull apart.
2 Trace lightly around the door's top hinge with a pencil. This makes reinstallation
easier
3 Detach the water tube from the connector located below the freezer door. The
connector releases when you press its outer sleeve inward.
4 Remove the screws from the top hinge and pull the multi-wire cable through it.
5 Lift the door off of the bottom hinge. Lay the door on its side to avoid damage to the
Remove the three bottom hinge screws and hinge, if necessary.
To reinstall the refrigerator and freezer doors, reverse the above steps.
Screws

Features may vary according to model
Fixed -
Door Bin
ice Container
Shelf
Shelf
Tilt Out
Door Bin
Small Basket
Large
Glide Out
Basket
Tilt Out -
Door Bin
Large Basket
Door Bin
Freezer and Refrigerator SpiliProofTM
Controls _ v-Aspect Shelf
ice Cream Shelf_ /
-- .\ / /Water FIter
Ice r,laKer _ i _ /_ ..........................
-- i _ ..........._ ....................il ........
i
CAUTION:
Do Not Remove
let Behind
Dairy
Compartment
_Dairy
Compartment
..... Door Bin
BpilIProof T°
Sliding Shelf
Door Bin
Wine Rack
Tall Bottle
.....Retainer
-- Door Bin
Special Item
Rack
-- Meat Keeper
and Cover
--Can Rack
Crisper Pan
and Cover
--Fixed
Door Bin
--Toe Grille
Electronic Controls
Freezer and Refrigerator
Controls
ice Cream Shelf
SpillSafe"
Shelf
-- Water Filter
Door Bin --
Ice Container -
Pizza Shelf
Wire Shelf
Small Items
Door Bin
Wire Shelf
Door Bin
Small Basket
Large Basket
Door Bin
Large Basket
Door Bin
rDoor
rBin
r Bin
Keeper
and Cover
Fixed Shelf
Special Item
Retainer
and Cover
Door Bin
\ .....................................................Toe Grille
Mechanical Controls

COOL DOWN PERIOD
Toensuresafe foodstorage,allowthe refrigeratorto operatewith the doorsclosedfor at least 8 to 12hoursbeforeloadingit with
food.
REFRIGERATOR & FREEZER CONTROLS
TEMPERATURE ADJUSTMENT
,, After 24 hours, adjust the controls as needed. Adjust temperatures gradually; move the knob in small increments, allowing the
temperature to stabilize.
,, For colder temperatures, turn the knob towards Colder.
,, For warmer temperatures, turn the knob towards Cold.
Tomaintain temperatures, a fan circulates air in the refrigerator and freezer compartments. For good circulation, do not block cold air
vents with food items.
factory 5ettlt1?, factory Settitag
Freezer C_"T_O_ Fresh Food
Refrigerator & Freezer Controls
(Features may vary according to model.)
TEMPERATURE ADJUSTMENT GUmDE
If Fresh Food Compartment Is Too Warm Turn Fresh Food Control Slightly Towards Colder.
If Fresh Food Compartment Is Too Cold Turn Fresh Food Control Slightly Towards Cold.
If Freezer Compartment Is Too Warm Turn Freezer Control Slightly Towards Colder.
If Freezer Compartment Is Too Cold Turn Freezer Control Slightly Towards Cold.
* To Turn Refrigerator Off Turn Freezer and Fresh Food Controls To O.

ALLOWING COOLINGTIME BEFORE USE
Toensure safe food storage, allow your refrigerator to operate with the doors closed for at least 8 to 12 hours before placing food inside. During
this cooling period, you do not need to adjust the controls, which are preset at the factory.
SETTING COOMNGTEMPERATURES
Your refrigerator comes with a state-of-the-art electronic digital control system. The system's control panel is located at the top of the the fresh
food compartment.
The two digital displays on the left half of the control panel indicate the current settings or temperatures of your freezer and fresh food
compartments. The models with a2-digit temperature display are for reference only, and do not display the current accurate compartment
temperature. Should you desire to see what the current accurate temperature is, place a separate thermometer inside the freezer or fresh
food compartment in the desired location.
To adjust the temperature to a higher or lower setting, press the
Up (Cold) or Down (Colder) button closest to the display. The
first time you press the button, the display shows current
setting you entered. Each press of the button after that
changes the setting by one.
The display shows your new setting momentarily, then changes
back to the current temperature.

TEMPERATURE ADJUSTMENT
After 24 hours, adjust the controls as needed. Make your adjustments small and gradual; allowing time for temperatures to change
and stabilize. Refer to the adjacent guidelines for temperature settings.
To adjust the temperature to a higher or lower setting, press the Up or Down button closest to the display. The first time you press
the button, the display shows the last setting you entered. Each press of the button after that increments the setting by one
degree.
The display shows your new setting momentarily, then changes back to the current temperature.
IFTEMPERATURE DISPLAYS FLASH...
If ever you see both temperature displays continously flashing, it may indicate that the control system has detected a performance
problem. Call your service representative, who can interpret the flashing message.
To maintain temperatures, a fan circulates air in the refrigerator and freezer compartments. For good circulation, do not block cold
air vents with food items.
NumeHcD_p_y
Fresh
Freezer Food
Temperature Disp_y(2-DigiO
Freezer Fresh Food
FoC°FoC°
Temperature Adjustment Guide
FreShFo0d0mpartmentist0worm/
p
i_
If Fresh Food €0mpartment iStoo C0id
if Freezei ComPaitmentiSt0o
if Freezer COmpartmentiStoo C01d
Adjust Fresh Food control one degree
colder by pressing Down (Colder) button.
Adjust Fresh Food control one degree
warmer by pressing the Up (Cold) button.
Adjust Freezer control one degree colder
by pressing Down (Colder) button.
Adjust Freezer control one degree warmer
by pressing the Up (Cold) button.
10
