Crosscall SHARK-X3 User manual

2
Thank you for placing your trust in Crosscall and purchasing
this IP68 certified mobile telephone.
Please read all safety precautions and this manual
carefully before using your device to ensure safe and proper
use.
Content, images and screenshots used in this manual may
differ in appearance from the actual product.
No part of this manual may be reproduced, distributed,
translated, or transmitted in any form or by any means,
electronic or mechanical, including photocopying,
recording, or storing in any information storage and retrieval
system, without the prior written permission.
Copyright © 2017, all rights reserved

3
TABLE OF CONTENTS
PRIOR INSTRUCTIONS 5
SAFETY MEASURES 5
SAFETY AND USE OF THE BATTERY 6
WARNING 6
HEARING PROTECTION 8
8
ENVIRONMENTAL PROTECTION 8
RECOMMENDATIONS TO REDUCE THE USER'S EXPOSURE TO RADIATION 9
COMPLIANCE 9
FREQUENCY BAND AND POWER 10
ACCESSORIES AND INFORMATION ON THE SOFTWARE 11
SPECIFIC ABSORPTION RATE OR "SAR" 12
TECHNICAL CHARACTERISTICS 14
TELEPHONE 14
MENUS AND FUNCTIONS 16
FILE MANAGER 16
CONTACTS 16
CALLS 17
C ALL HISTORY 17
CALL SETTINGS 17
MESSAGES 18
MULTIMEDIA 19
CAMERA 19
M EDIA PLAYER 19
I MAGE VIEWER 20
R ECORDER 20
FM R ADIO 21
ORGANIZER 22
A LARM 22
C ALCULATOR 22
C ALENDAR 22
W ORLD CLOCK 23
N OTES 23
C ONVERTER 23
T IMER 23
T ASK LIST 24
TORCH 24
K EEP A LIVE F UNCTION 24
W HISTLE 28
SETTINGS 29
PHONE SETTINGS 29
CALL SETTINGS 30

4
CONNECTIVITY 31
SECURITY SETTINGS 32
RESTORE DEFAULT SETTINGS 32
PROFILES 34
SERVICES 35
INTERNET SERVICES 35
IMPORTANT SAFETY INSTRUCTIONS 36

5
PRIOR INSTRUCTIONS
SAFETY MEASURES
■ You have just acquired a mobile telephone that meets the
international IP67 waterproofing standards. In order to
guarantee optimal use and waterproofness, ensure that all the
flaps covering the opening and the cover are correctly sealed
■ Do not open the back cover of the device if it is in the water or in a
very humid environment
■ The rubber seal fixed on the back cover is an important
component of the device. Ensure that the rubber seal is not
damaged when you open or close the cover. Ensure that the seal is
free from any debris, such as sand or dust, to avoid damaging the
device.
■ The cover and the flaps can come loose in the event it is dropped
or hit. Ensure that all the covers are properly aligned and completely
closed.
■ If the device has been submerged in water or the microphone or
speaker is wet, the sound may not be clear during a call. Ensure that
the microphone or speaker is clean and dry by wiping it with a dry
cloth.
■ If the device gets wet, dry it thoroughly with a soft,
clean cloth

6
■ The water resistance of the device can lead to slight vibrations
under certain circumstances. Such vibrations, for example when the
volume is turned up high, are entirely normal and do not affect the
performance of the device.
■ Do not disassemble the waterproof membrane of the microphone
or the speakers and do not use a device that can damage it.
■ Temperature fluctuation can lead to an increase or decrease in the
pressure, which may affect the quality of the sound. If required, open
the flaps to release the air.
SAFETY AND USE OF THE BATTERY
Use with the correct charger.
Do not throw into fire.
Do not short-circuit.
Do not expose to temperatures over 60 ºC / 140 °F.
Recycle according to the standards in force.
WARNING
■ Respect all the measures and safety standards relating to the
use of your device when you are driving.
■ Keep your telephone at least 15mm from your body when you take
calls.
■ Small parts may cause choking.

7
■ Your telephone can emit a loud sound.
■ Do not only rely on your telephone to make emergency calls.
■ Do not use it in service stations.
■ Avoid exposing to magnetic fields.
■ Keep it away from pacemakers and other electronic medical
devices (15cm).
■ Keep the device on the side opposite the implant.
■ Please switch off your telephone in hospitals and other medical
facilities requiring it.
■ Please switch off your telephone in airplanes and airports when
you are asked to.
■ Please switch off your telephone when near to explosive
materials or liquids.
■ Avoid extreme temperatures. Do not keep your device in extremely
hot or cold places.
■ Do not disassemble your telephone.
■ Avoid impacts or damage to your telephone.
■ Avoid using the connector to perform several actions and
ensure that the terminals of the battery do not touch any
conductive elements, such as metal or liquid.
■ Stop using your device if any of its parts are cracked, broken or if
it overheats.
■ Do not allow your children or pets to chew or lick the device.
■ Do not press on your eyes, ears or any part of the body with your
device and do not put it in your mouth.
■ Do not use the flash close to the eyes of people or animals.
■ Do not use your device outside during a thunderstorm.

8
■ Use only original accessories with this telephone and do not use the
battery on another telephone.
HEARING PROTECTION
■ This telephone adheres to the current regulations in terms of limiting
the maximum output volume. Prolonged listening with earphones at a
high volume may cause hearing damage!
■ Stop using the product or lower the volume if you feel that your ears
are ringing.
■ Do not adjust the volume to too high a level, medical professionals
do not recommend being exposed to a high volume for a prolonged
period of time.
■ Use the earphones smartly, as excessive sound pressure coming
from them or an audio headset can cause hearing loss.
■ In order to avoid any hearing damage, a high volume over long
periods of time must be avoided.
■ Please only use headphones suitable for your telephone.
ENVIRONMENTAL PROTECTION
Please observe the local regulations on the phone's packaging
concerning the battery and the disposal of used telephones, by
depositing them in the selective collection points so that they can
be properly recycled. Do not dispose of telephones or used

9
batteries in ordinary trash cans.
Please dispose of used lithium batteries that you do not want to
keep in a designated place for this purpose. Do not dispose of
them in the trash can.
RECOMMENDATIONS TO REDUCE THE USER'S
EXPOSURE TO RADIATION
■ Use your mobile phone in areas covered by the network in order
to reduce the amount of radiation received (in particular in
underground car parks and when on train or car journeys).
■ Use your telephone in good reception areas (for example maximum
signal bars).
■ Use a hands-free kit.
During a call, keep the phone away from pregnant women's
stomachs and adolescents' lower abdomens.
COMPLIANCE
■ CROSSCALL states that this device complies with the basic
recommendations and other relevant measures of the
2014/53/EU directive. The most recent valid version of the

10
conformity declaration can be viewed at the following
address: http://crosscall.com/wp-content/uploads/2017/07/CE-
INTERNATIONAL-DECLARATION-OF-CONFORMITY-SHARK-X3.pdf
■ This device can be used in all the member states of the
European Union. Please respect the national and local
regulations applicable in the region where you are using the
device. The use of this device can be limited by the local
network.
FREQUENCY BAND AND POWER
■ Frequency band used by radio equipment: Certain bands may not be
available in all countries or all regions. Please contact the local operator to
get more detailed information.
■ Maximum radio signal frequency emitted in the frequency band
where the radio equipment operates: The maximum power for all
the bands is less than the highest specified limit value under the
associated harmonized standard.
The nominal frequency band and power transmission limits
(radiated and/or by conduction) applicable to this radio
equipment are the following:
TECHNO
BAND
TRANSMITTING POWER
2G / GSM
900MHz
32.21 dBm
1800MHz
29.1 dBm
3G / WCDMA
900MHz
22.4 dBm

11
2100MHz
22.8 dBm
Bluetooth
3.87 dBm
ACCESSORIES AND INFORMATION ON THE
SOFTWARE
We advise that you use the following accessories:
ACCESSORIE
S
INFORMATION
MODEL
TECHNICAL DATA
Battery
BA.PO.SH0950
3.7V, 950 mAh
AC Charger
EU type model:
TUEU050055-A00
UK type model:
TUUK050055-A00
INPUT: 100
240V-50/60Hz 150mA
OUTPUT: 5.0VDC,
550mA, 1A
Earphone
JYK-E106Z JWEP1009-Z19
Micro USB
CABLE
JYK-D095Z JWUB1338-Z19
The software version of the product is SHARK_XXXXXXXX_XXXX
(X=0-9, A-Z representing the up-to-date information on the user
experience, security fixes, etc.). Software updates are published
by the manufacturer to correct bugs or improve the functions
after the launch of the product. All the software versions
published by the manufacturer have been verified and always
adhere to the applicable regulations.

12
All the radiofrequency settings (for example, the frequency band and
output power) are not accessible by the user and cannot be modified
by him/her. To see the most up-to-date information concerning the
accessories and software, please read the conformity declaration at
the following address: http://crosscall.com/wp-
content/uploads/2017/07/CE-INTERNATIONAL- DECLARATION-
OF-CONFORMITY-SHARK-X3.pdf
SPECIFIC ABSORPTION RATE OR "SAR"
This device adheres to the directives relating to the exposure to
radio frequencies, when it is used near to the head or at a
minimal distance of 5mm from the body. According to the
recommendations from the ICNIRP, the SAR limit is 2.0 watts/kg
on average on 10g of cellular tissue absorbing the majority of
frequencies.
Maximum values for this model:
• 0.800 watts/kg for the head
• 0.370 watts/kg for the body
SHARK-X3, design in France assembled in China
Created & Imported by: CROSSCALL –655 RUE P.S LAPLACE
13290 AIX EN Pce –FRANCE

13
Please visit the www.crosscall.com website to get the complete
version of the user guide.

14
TECHNICAL CHARACTERISTICS
TELEPHONE
Model
SHARK-X3
Dimensions
134 x 62 x 24mm
Weight
138g

15
DESCRIPTION
1
OK / Select
2
Menu
3
Answer
4
Keypad locking
5
Microphone
6
Earpiece
7
Shortcut / Navigation
8
Contacts
9
Hang up / Power
10
Torch
11
Silent
12
USB charging port
13
Jack for earphones
14
Camera
15
Torch
16
Red torch
17
Flash
18
Speaker
19
Whistle

16
MENUS AND FUNCTIONS
FILE MANAGER
You can use the File manager to organize your files into folders.
If you insert a memory card, files which are stored on it are organized
separately.
Select Phone or Memory card, then choose Options to browse, copy,
delete, rename and move files.
• Open: Select this function to open received files and your pictures,
sounds, e-books, music and photos.
• Format : Select this function to format the phone or memory card.
CONTACTS
You can store the name and telephone number of a contact on the
phone or SIM card.
You can store up to 500 contacts on the phone. Note: The storage
capacity of the SIM card is determined by the card type.
To add a contact, go into the "Phone book" Menu, then select
"Options" and "Add new contact". Then complete the contact form
and select "Options" and "Save".

17
CALLS
Call history
You can view missed calls, the numbers entered and the calls received
with this function, as well as deleting all the call logs.
To do this, go into the "Call history" menu.
To delete a call, select "Options", then "Delete" or "Clear All" to delete
all the call list.
Call settings
You can configure different advanced functions concerning calls. To
do this, go into the "Settings" menu then "Call settings" and "Advanced
settings".
• Blacklist: You can block 20 numbers. When this function is activated,
you cannot receive calls from numbers saved on the blacklist.
• Automatic callback: Select On or Off to activate or deactivate the
automatic callback. If you activate the automatic callback, the
phone will automatically redial the number of the person you tired to
reach a few moments later if they did not answer the first time. During
the callback period, you cannot enter other numbers.

18
To stop the automatic callback function, press the Hang up / Power
key. The maximum number of automatic calls is 10.
Note:
This function requires the assistance of the network operator to which
the SIM is linked.
• Time notification during a call: You can set one or several tones
during a call in order to indicate the time to you.
• Auto hang up: You can choose to activate or deactivate this
function.
• Reject by SMS: You can choose to activate or deactivate this
function.
• Answer mode: Choose an answer mode according to your needs.
MESSAGES
The telephone supports SMS and MMS services. You can send
messages and manage the messages that you have sent and
received.
In standby mode, go to the main menu by pressing the left button,
select the "Messages" menu then "Write a message" to enter the
message writing screen. You can then press the left button to carry out
other operations.

19
The "Messages" menu also lets you access:
-received messages ("Inbox"),
-drafts ("Drafts"),
-messages currently being sent ("Outbox"),
-sent messages ("Sent messages"),
-voicemail ("Voicemail server"),
-message templates ("Templates"),
-message settings ("Message setting").
MULTIMEDIA
Camera
This application lets you take photos or record videos.
To take a photo or video, go into the "Camera" menu:
-On the capture screen, select the up or down key to zoom in or out.
-Press the OK key to take photos or record videos.
-Select the left direction key to access the camera/video camera
settings, or to change the shot mode.
-Select the right direction key to quit the Camera application.
Media player

20
This application lets you play audio and video files.
Go into the "Multimedia" menu then "Multimedia player".
On the media player screen, select the up key to read a file or pause
it. Keep holding the right key to quickly move forward; keep holding
the left key to go back; press 0 to go to full-screen mode. Select the *
or # key to adjust the volume.
Image viewer
This application lets you view pictures saved on your phone or memory
card.
Go to menu "Multimedia" then "Image gallery".
When an image is on the screen, press 1 to turn the image anti-
clockwise; press 3 to turn the image clockwise; press 4 to zoom out;
press 6 to zoom in; press 5 to optimize the image; press OK to turn the
image in the direction indicated by the icon; press the left button to
carry out other adjustments; press the right button to go back.
Recorder
This application lets you make recordings.
